GAS BOILING PAN, MG7-10-BM

Boling pans 700

700 Series

GAS BOILING PAN, MG7-10-BM
Made of stainless steel.
Capacity: 80 litres. Double jacket pan (bain-marie system).
Counterweighted folding lid.
Stainless steel burner, with safety valve and thermocouple.
Safety device for the bain-marie extinguishes the burner in the event of
low water level.
Cold and hot water filling tap.
Drainage tap.
Filling tap and control tap for the level of the double jacket pan
(bain-marie).
Over-pressure safety valve.
Power: 15000 Kcal/h. (17.44 kW).
Electrical connection 230 V - 1+N+T.
Dimensions: 700 x 775 x 850 mm.

700,00

775,00

850,00

94,00 120,00

0,78

Length

Depth

Height

Weigth

Volumen

mm

mm

mm

Kg

m3

0,05

2x2,5 - 4A

230V -1+N

230V - III

400V - III+N

GAS

17,44

KW

KWPower

Kcal/h

14.998,40

1,42

37,00

1,80

18,00

LPG

Natural Gas Consumption (m3/h)

Pressure (g/cm2)

Pressure (g/cm2)

0,00

Pressure (Kg/cm2)

Connections points X Y Z Diameter

Cgaz-1312BT5117

Certificate EQNET- CE

Information

DIMENSIONS

740,00

915,00

1.150,00

0,46

ELECTRICITY

STEAM

AIR

Article Packed

Electric power

WATER

Water consumption (lit/h)

Consumption (kg/h)

Not used

Not used

Not used

600 650 150ELECTRICITY

528 700 105COLD WATER Prever llave de corte en la toma3/4''

468 700 105HOT WATER Prever llave de corte en la toma3/4''

662 494 105GAS R.3/4"G

Prever regulador y llave de corte
individual
