pag. 1,2,3,4

LIBRETTO DI ISTRUZIONI

MONOFASE - TRIFASE PER CANCELLI

SCORREVOLI E AUTOMAZIONI CON FINECORSA

SINGLE- AND THREE-PHASE FOR SLIDING GATES

AND AUTOMATIONS FITTED WITH LIMIT SWITCHES

MONOPHASE - TRIPHASE POUR PORTAILS

COULISSANTS ET AUTOMATISMES AVEC FINS DE COURSE

EINPHASIGE - DREIPHASIGE FÜR SCHIEBETORANTRIEBE

UND AUTOMATIONEN MIT ENDSCHALTER

INSTRUCTIONS

NOTICES D'INSTRUCTION

PLUS

ANLEITUNG

PLUS

- FUNZIONE PASSO PASSO

- UOMO PRESENTE

- APERTURA PEDONALE

- SPIA DI SEGNALAZIONE DELLO STATO DELL'AUTOMAZIONE

- POSSIBILITA' DI ESCLUDERE LAMPEGGIANTE IN PAUSA

- STEP BY STEP

- HOLD-ON SWITCHED (DEADMAN) CONTROL

- PEDESTRIAN OPENING

- GATE STATUS INDICATION

- FLASHING LAMP DURING DWELL TIME. MADE SWITCHED ABLE

-FONCTION PAS-PAS

-HOMME MORT

-OUVERTURE PIETON

-VOYANTS A DIODE DE SIGNALISATION DE L'ETAT DE L'AUTOMATISATION

-POSSIBILITE D'ETEINDRE LA LAMPE DE SIGNALISATION EN PAUSE

- SCHRITT-IMPULS-FUNKTION

- TOTMANN-BEDIENUNG

- GEHTÜRFUNKTION

- AUTOMATION-STATUS ANZEIGELAMPE

- MÖGLICHE AUSSCHALTUNG DER BLINKLEUCHTE BEI DER PAUSE

- LUCE DI CORTESIA TEMPORIZZATA

- FUNZIONE OROLOGIO

- ADJUSTABLE COURTESY LIGHT TIME

- TIME CLOCK OPTION

page 1,5,6,7

-LAMPE D'ECLAIRAGE TEMPORISEE

-FONCTION HORLOGE

page 1,8,9,10

- EINSTELLBARES BEDIENUNGSLICHT

- UHR-FUNKTION

Seite 1,11,12,13

FOLLETO DE INSTRUCCIONES

DESLIZANTES Y AUTOMATISMOS CON TOPES DE RECORRIDO

MONOFASICO - TRIFASICO PARA VERJAS

EENFASE - DRIEFASE VOOR SCHUIFHEKKEN EN

AUTOMATISERINGEN MET EINDSCHAKELAAR

Dis. N.

4135

HANDLEIDING

PLUS

- FUNCIONAMIENTO PASO A PASO

- HOMBRE PRESENTE

- ABERTURA PARA PASO DE PEATONES

- LÁMPARA TESTIGO QUE SEÑALA EL ESTADO DEL AUTOMATISMO

- POSIBILIDAD DE EXCLUIR EL DESTELLADOR EN PAUSA

- STAP-VOOR-STAP FUNCTIE

- DODEMANSFUNCTIE

- VOETGANGERSDOORGANG

- SIGNALERINGSLAMP AUTOMATISERINGSSTATUS

- MOGELIJKHEID UITSCHAKELING KNIPPERLICHT BIJ PAUZE

Via Mantova, 177/A - C.P. 126 - 37053 Cerea (Verona) Italy - Tel. +39 0442 330422 r.a.

Fax +39 0442 331054 - e-mail: info@fadini.net - www.fadini.net

s.n.c.

- LUZ AUXILIAR TEMPORIZADA

- FUNCIÓN RELOJ

pág. 1,14,15,16

- INSTELBARE INDICATIELAMP

- KLOKFUNCTIE

pag. 1,17,18,19

PLUS

SINGLE- AND THREE-PHASE FOR SLIDING GATES AND AUTOMATIONS FITTED WITH LIMIT SWITCHES

26 27

PULIN 3

28 3

RADIO PLUG-IN CARD CONNECTOR

SAFETY EDGE

PHOTOCELLS

COMMON

OPEN

DIP-SWITCH

ELPRO 10 plus

MICROPROCESSOR

RADIO

STOP

LIMIT SWITCH CLOSE

OFF

1 radio receiver

2 pairs photocells

24V OUTPUT max. load:

COMMON LIMIT SWITCH

LIMIT SWITCH OPEN

EXT TIME (electric lock and courtesy light) from 2 to 255s

PEDESTRIAN OPENING TIME

from 3 to 30s

DWELL TIME

from 5 to 128s

MOTOR RUN TIME

from 5 to 128s

230V COURTESY LIGHT

12V AC RELAY FOR

ELECTRIC LOCK OR

F6=2A

24V protection

COMMON

MOTOR

230V 400V

CAPACITOR

L10

TRANSFORMER

F5=1A flashing lamp

protection

ELPRO 10 PLUS

230V 25W max

FLASHING LAMP

230/400V

F4=630mA

Transformer

protection

F2=8A mains

F3=8A mains

21 22

LIVE

230V ±10% 50Hz

SINGLE-PHASE

VOLTAGE SUPPLY

LIVE

±10% 50Hz

400V

THREE-PHASE

VOLTAGE SUPPLY

F1=8A mains

2322

NEUTRAL

LIVE

NEUTRAL

General description: the electronic control panel Elpro 10 Plus, new generation, is designed to operate sliding gates. Power supply is 230/400V single-phase and threephase. Built in full compliance with 2006/95/CE Low Voltage and 2004/108/CE - 92/31/CEE Electro-Magnetic Compatibility Regulations. Fitting operations are recommended by a qualified technician in conformity to the existing safety standards.The manufacturing company declines any responsability for incorrect handling and application; also, it reserves the right to change or update the control panel any time. Failure to follow installation regalations may result into serious damage to property and persons.

PLEASE NOTE:

- The control panel must be installed in a sheltered, dry place, inside the box provided with it.

- Make sure that the power supply to the electronic programmer is 230V ±10% or 400V ±10%

- Make sure that the power supply to the Electric Motor is 230V ±10% or 400 V ±10%

- For distances of over 50 metres we recommend using electric cables with bigger sections.

- Fit the mains to the control panel with a 0.03A high performance circuit breaker.

- Use 1.5 mm2 section wires for voltage supply, electric motor and flashing lamp. Maximum recommended distance 50 m.Use 1 mm2 section wires for limit switches, photocells, push-buttons/key-switch and accessories.

- Bridge terminals 1 and 2 if no photocells are required.

- Bridge terminals 3 and 6 if no key- or push-button switches are required.

N.W: To fit extra accessories such as lights, CCTV etc. use only solid state relays to prevent damages to the microprocessor.

Dip-Switch:

1= ON. Photocells. Stop while opening 2= ON. Radio. No reversing while opening 3= ON. Automatic closing

4= ON. Preflashing activated 5= ON. Radio. Step by step. Stop in between 6= ON. Deadman Control (Dip 4=OFF and Dip 3=OFF) 7= ON. No lamp on during dwell time 8= OFF. Blank

DIP-SWITCH

In case of failure of the panel:

- Make sure that the power supply to the electronic programmer is

OFF

230V ±10% or 400V ±10%

- Make sure that the power supply to the Electric Motor is 230V ±10% or 400V ±10%

- Check fuses

- Check photocells if contacts are normally closed

- Check all NC contacts

- Check that no voltage drop has occurred from the control panel to the electric motor

Led Status Indication:

L1= 230V 50Hz power supply. Alight L2= Photocells, if obstructed light goes off L3= Open. Alight whenever an Open pulse is given L4= Close. Alight whenever a Close pulse is given L5= Stop. It goes off on pulsing Stop L6= Radio. It goes on by pressing a transmitter button L7= Gate Status; it flashes on gate moving L8= Limit switch Close; off when gate is closed L9= Limit switch Open; off when gate is open L10= It stays on for a time equal to the time set on T4 Trimmer

Drwg. No.

4135

LOW VOLTAGE ELECTRICAL CONNECTIONS

PLUS

SINGLE- AND THREE-PHASE FOR SLIDING GATES AND AUTOMATIONS FITTED WITH LIMIT SWITCHES

Photocells and Safety Edge:

PHOTOCELLS AND SAFETY EDGE

Button switch:

Radio Contact:

- Open/Close (Standard)

- Travel reversing on pulsing

- Step by step

Push Button Switch Pulin 3:

12 13

24V (500 mA) OUTPUT (MAX. LOAD: 2 PAIRS PHOTOCELLS 1 RADIO RECEIVER)

COMMON

OPEN

STOP

COMMON

DIP-SWITCH 1:

ON: Photocells stop gate while opening, reverse it on closing once obstacle is removed OFF: Photocells do not stop gate while

opening, reverse it on closing in case of an obstacle

Limit switch:

CONTACT

RADIO

Led to indicate status of Open - Stop Close switches

DIP-SWITCH 2 and 5 (NEVER set BOTH of them to ON at the same time):

ON: Gate is not reversed while opening

OFF: Any pulse reverses the gate

ON: Step by step. Stop in between OFF: Standard operating mode

LIMIT SWITCH

COMMON

LIMIT SWITCH

OPEN

24V 3W Indication Light:

Courtesy light:

Connect a 24VAC Modular Relay

T4 Trimmer Time from 2s to 255s)

( to operate a 230V lamp

Electric lock:

Set the T4 Trimmer Time to the lowest value The electric lock is excited for 2 seconds

Light ON = Open gate

Light OFF = Closed gate Flashing (fast) 0.5s = Closing gate Flashing (normally) 1s = Opening gate Flashing (slowly) 2s = gate is stopped

- TIME EXT (Electric lock and

courtesy light) from 2 to 255s

Drwg. No.

4135

OPERATING MODES

PLUS

SINGLE- AND THREE-PHASE FOR SLIDING GATES AND AUTOMATIONS FITTED WITH LIMIT SWITCHES

ELECTRICAL POWER CONNECTIONS

Single- (230V) and Three-phase (400V) Motors:

Flashing lamp:

Power supply:

230V

230V MAX 25W

400V

DIP-SWITCH 4 and 7:

ON: Pre-flashing OFF: No pre-flashing

21 22

230V ±10% 50Hz

SINGLE-PHASE

Automatic / Semiautomatic:

Automatic Operation: any pulse opens the gate, the gate stays open as long as the Dwell time

expires as set by T2 trimmer, then it closes automatically, no pulsing is required.

Semi-automatic Operation: any pulse opens the gate that stays open. A second pulse to Close is required for the gate to close.

LIVE

COMMON

MOTOR

CAPACITOR

2322

NEUTRAL

ON: Lamp is not operating during

Dwell Time. Automatic Mode.

OFF: It flashes during Dwell Time .

Automatic Mode.

21 22

LIVE

TRS

400V ±10% 50Hz

THREE-PHASE

Dwell Time

from 5 to 128s

MOTOR RUN TIME

OPEN / CLOSE from 5 to 128s

2322

NEUTRAL

DIP-SWITCH 3

ON= Automatic Closing

OFF= No Automatic. Semi-automatic

closing by pulse

Dwell Time

from 5 to 128s

FADINI

l'apricancello

Pedestrian Opening:

Trimmer T3 to the lowest disactivates Pedestrian Opening From 3 to 30s it can be activated by any pulse (eg. by remote control) superior to 2s

Hold on switched (Deadman) control:

Open and Close operations are achieved "by holding a switch on" (no relay self-holding is involved) therefore a phisical attendance is required to keep the gate opening or closing until either the button or key is released.

DIP-SWITCH 6

ON= Deadman Control. Dip-switch 4=OFF

and Dip-switch 3=OFF

OFF= Standard Operations

PEDESTRIAN TIME

from 3 to 30s

Remote Controlled Operations Excluded during Dwell Time on Automatic Mode:

With this setting it is not possible to operate the gate by remote control during the dwell time on automatic mode. DIP-SWITCH 2=ON, 3=ON and 5=ON

ON: No reversing on opening

OFF: Travel reversing on any pulsing

ON= Automatic Closing

OFF= Closing by Pulse

ON: Step by step. Stop in between

OFF: Standard Operations

Time clock installation:

How it works: Set the clock to the required time. On the pre-set time the gate is automatically opened and held open. Any further pulsing (even by remote control) is not accepted by the system until the time pre-set by the clock has expired. On expiring and after the pre-set dwell time the gate is closed automatically. T3 trimmer on to zero, Dip-Switch 3=ON.

DIP-SWITCH No.3=ON Automatic Closing

Pedestrian Trimmer T3

set on to zero

ON= Automatic Closing

OFF= No Automatic. Semi-automatic

closing by pulse

COMMON

External Time Clock

OPEN

COMMON

Drwg. No.

4135

200

182

09-2010

260 280

110

I -

Prima dell'installazione da parte di personale tecnico qualificato, si consiglia di prendere visione del Libretto Normative di Sicurezza che la Meccanica Fadini mette a disposizione.

GB -

Please note that installation must be carried out by qualified technicians following Meccanica Fadini's Safety Norms Manual.

F -

L'installation doit être effectuée par un technicien qualifié suivant le manuel des Normes de Sécurité de Meccanica Fadini.

D -

Vor der Montage durch einen Fachmann, wird es empfohlen die Anleitung zur Sicherheitsnormen, die Meccanica Fadini zur Verfügung stellt, nachzulesen.

E -

Antes de la instalación por el personal técnico calificado, se recomienda leer detenidamente el Folleto de la Reglamentación de Seguridad que la empresa Meccanica Fadini pone a su disposición.

NL -

Voordat de installatie door gekwalificeerd technisch personeel wordt uitgevoerd, wordt geadviseerd om het boekje met veiligheidsvoorschriften dat Meccanica Fadini ter beschikking stelt door te lezen.

Direttiva 2003/108/CE Smaltimento dei materiali

elettrici ed elettronici

VIETATO GETTARE NEI RIFIUTI

MATERIALI NOCIVI PER L’AMBIENTE

2003/108/CE Directive

for waste electrical and

electronic equipments

DISPOSE OF PROPERLY

ENVIRONMENT-NOXIOUS MATERIALS

s.n.c.

Via Mantova, 177/A - C.P. 126 - 37053 Cerea (Verona) Italy - Tel. +39 0442 330422 r.a. - Fax +39 0442 331054

e-mail: info@fadini.net - www.fadini.net

La ditta costruttrice si riserva di apportare modifiche al presente libretto senza preavviso
