EPX16
AND
EPX8 C
HASSIS
EPX16
AND
EPX8 C
HASSIS
The EPX16™and EPX8™are flexible,
expandable, multi-channel test systems.
They are ideal for an equipment
manufacturer’s production and
verification lab testing in the metro and
long-haul markets.
Using the same modules and software as
gnubi's
™
other test chassis, the EPX16 and
EPX8 support multiple rates and multiple
simultaneous tests.
E
XPANDABLEMULTIPLERATETESTING
Unlike other test equipment, gnubi's EPX
™
Test Systems give you the flexibility to
create the test applications that you need
now and the expandability to grow with
your testing needs in the future. You can
mix test modules for multiple rate testing.
S
IMULTANEOUSMULTI-PORTTESTING
You can install as many as 17 (EPX16)
and 8 (EPX8) modules for simultaneous
multi-port testing. Using EPXam™tools
such as Group Manager, Test Controls, or
Script Runner, control multiple instances
of the same test simultaneously.
Or conduct different tests at the same time.
E
NDURINGVALUE
Frustrated with replacing outdated
equipment? Created in 1996, the original
EPX16 was designed to be updated easily
with new data rates and technology.
The EPX8 uses the same upgradable,
multi-channel design in a smaller footprint.
E
ASY TOUSE
You can start testing quickly and easily
with the EPXam graphical user interface.
Other ease-of-use features include saving
and restoring configurations, connecting
remotely with a web browser, scripting,
logging, and sharing test resources with
other users.
With Checkpoint/Resume, recovering from
a power failure is easy. Module setup and
test data are saved at intervals that you can
define. When the system is restarted after a
power failure, tests are resumed with
minimal data loss.
U
PGRADABLE
As new features are developed for gnubi's
test equipment, download the upgrades
from our website. Visit www.gnubi.com to
learn about the latest features and upgrades.
Specifications are subject to change without notice. Visit www.gnubi.com for the latest information.
©2002 gnubi communications, L.P. Rev. A
EPX16 Features
• Seventeen customizable slots
• Resume measurements and data
collection after power failure
• Test multiple rates and protocols
within the same EPX chassis
• Compatible with all EPX modules
• Full-featured GUI and command
line user interfaces
• Remote access via web browser
• Multiple, concurrent test sessions
• Save and restore test configuration
EPX8 Features
• Eight customizable slots
• Resume measurements and data
collection after power failure
• Test multiple rates and protocols
within the same EPX chassis
• Compatible with all EPX modules
• Full-featured GUI and command
line user interfaces
• Remote access via web browser
• Multiple, concurrent test sessions
• Save and restore test configuration
Specifications
EEPPXX1166™™ aanndd EEPPXX88™™ CChhaassssiiss
gnubi communications, L.P. • 17919 Waterview Parkway, Dallas, Texas 75252-8011 • Phone 972.836.0100 • Fax 972.836.0174
Gnubi Communications GmbH & Co. KG • Ludwig-Erhard-Str. 52-56, D-72760 Reutlingen, Germany • Phone +49 7121-62873-0 • Fax +49 7121-62873-29
©2002 gnubi communications, L.P. All rights reserved.
gnubi, the gnubi logo, EPX, EPXam, EPXam Pro, EPX8, EPX16 and TransPort
are trademarks of gnubi communications, L.P. All rights reserved. All other
trademarks are the property of their respective owners.
1
Includes CPU and clock modules; 2Includes handles; 3For a fully loaded chassis
Model Number EPX16 Rack mount chassis
Installation All modules; 17 open slots
Weight
1
20 lbs; 9.07 kg
Dimensions
2
Height 7 inches; 17.78 cm
Width 19 inches; 48.26 cm
Depth 16-1/2 inches; 41.91 cm
AC Power Input Voltage 120/230 VAC
Maximum 860 Watts
Input Power
3
Maximum 10/5 Amps
Input Current
Circuit Breaker 10 Amps
Frequency 50/60 Hz
DC Power Input Voltage -48 +/-10% VDC
Maximum 860 Watts
Input Power
3
Maximum 17.92 Amps
Input Current
Circuit Breaker 20 Amps
Frequency 50/60 Hz
Environmental Operating +5 to 40° Celsius
Temperature
Storage Temperature -20 to +70° Celsius
Humidity Maximum: 80% for temperature up to 31° Celsius decreasing linearly to 50% for 40° Celsius
Model Number EPX8 Rack mount chassis
Installation All modules; 8 user slots
Weight
1
19 lbs; 8.6 kg
Dimensions
2
Height 3-1/2 inches; 8.89 cm
Width 19-1/8 inches; 48.58 cm
Depth 18-7/8 inches; 47.94 cm
AC Power Input Voltage 110/240 VAC
Maximum 350 Watts
Input Power
3
Maximum 4/2 Amps
Input Current
Fuse 5mm x 20 mm: 100-120 4A-T,250V or 200-240 2A-T,250V
Frequency 50/60 Hz
Environmental Operating 0 to 40° Celsius
Temperature
Storage Temperature -20 to +70° Celsius
Humidity Maximum: 80% for temperature up to 31° Celsius decreasing linearly to 50% for 40° Celsius
