The ideal projector - at work, in a
classroom, on the move or at home
Stylish, lightweight, compact and easy to use, the
Epson EMP-X3 multi-functional projector is ideal for
office, education or mobile use. Ready to display in just
4 seconds, it’s one of the quickest projectors on the market.
Versatile, affordable and packed with
the latest Epson technology
The Epson EMP-X3 multi-purpose
projector combines high quality
performance with the latest Epson
technology, in a sleek, stylish, easy to
use projector. The new Epson EMP-X3
has been designed to provide you with a
compact, easily transportable projector
which comes with its own carry-case. At
just 2.6kg, it is also one of the lightest
projectors in its class. As well as desktop
and mobile capability, the Epson EMP-X3
comes with enhanced installation
features, making it great as a permanent
fixture for meetings, training or
educational use.
Quick Start and Instant Off
If increased time constraints in
business seem to add to your daily
pressures, you’ll be delighted that the
Epson EMP-X3 projector takes only
4 seconds before information begins to
be displayed. It also benefits from the
Instant Off feature so there’s no
waiting around after you have finished.
Compact and lightweight - take it wherever
you go
Convenient panel control
Multi-media capability
The Epson EMP-X3 supports SXGA PC
signals, as well as being High Definition
compatible, allowing you to view higher
resolution images and movies. Optional
cables allow you to connect to other
media, such as DVD players and digital
cameras, bringing to life any presentation
in rich, multi-media formats.
E-TORL technology
Our patented E-TORL lamp ensures clear
visibility even in light rooms giving
increased brightness for lower power
consumption than standard lamps.
Smaller, brighter, more energy efficient,
the E-TORL is tomorrow’s lamp, today.
Real home cinema experience
Whatever types of movies you love, you’ll
love the way the Epson EMP-X3
gives you the sharpest, clearest, most
natural looking images. Our patented
3LCD technology gives you the brightest,
richest colours and perfectly smooth
video playback.
With 16:9 movie format compatibility and
wide angle lens, even small projection
distances create a satisfying big screen
effect.
Versatile, affordable, compact - perfect for business, the classroom and home
• Lightweight (2.6kg) and portable
• Exceptional image quality with Epson’s 3LCD technology
• Quick Start and Instant Off functions
• Convenient, intuitive function panel and remote control
• Enhanced security with password protection
• Quiet operation at only 30 dB in low brightness mode
• Brighter, more energy efficient with Epson’s exclusive E-TORL lamp
• Multi-media compatible and amazing big screen entertainment
5
1 3
2
2 2 4
All the connections you need for your
PC, TV, DVD or games console.
1. RGB in for PC input
2. RCA for composite video and audio inputs
3. S-Video
4. USB (B) for PC remote control (with optional cable)
5. RGB out for external monitor
Instant Off
On the back:
Optical zoom
Model
s
t
y
t
y
(
)
e
ge
t
y
EMP-X3 – 2GB – 11/05
Screen Diagonal (inches)
Projection Distance (wide/tele) (metres)
EPSON® is a registered trademark of SEIKO EPSON® Corporation. All other product names and other company
names used herein are for identification purposes only and may be trademarks or registered trademarks of their
respective owners. Errors and omissions excepted, all specifications are subject to change without notice.
Telephone: +44 (0) 1442 261144
E-mail: info@epson.co.uk
Fax: +44 (0) 8702 413093
www.epson.co.uk
Projection System
Projection Method
Specification of Main Part
LCD dots (1024x768) x3; Native Resolution: XGA; Aspect Ratio: 4:3; Pixel Arrangement: Stripe;
Projection Lens Type: Manual: zoom / focus; F-Number: 1.60-1.74; Focal Length: 18.4 mm-22.12 mm;
Lamp Type: 170W UHE; Life: 2000 hours (High brightness) / 3000 hours (Low brightness)
Screen Size
(Projected Distance) 30" to 300" [0.9 to 9.0 m] (Zoom:Wide) / 60" screen 1.8 - 2.1 m
Offset 10:1
High Brightness Mode 2000 ANSI lumens (Colour mode: Game, Zoom: Wide)
Low Brightness Mode 1500 ANSI lumens (Colour mode: Game, Zoom: Wide)
Contras
Brightness Uniformit
Colour Reproduction
Sound Outpu
Function
Remote Control Infrared
Epson EMP-X3
RGB Liquid Crystal Shutter Projection System
Front / Rear / Ceiling Mount
Size: 0.6" with MLA; Driving Method: Poly-silicon TFT Active Matrix; Pixel Number: 786432
Refresh Rate: 50 Hz - 72 Hz
Zoom Ratio: 1-1.2; Lens Cover: Included
30" to 300" [1.1 to 11 m] (Zoom:Tele)
400:1 (Colour mode : Game, High brightness mode)
85%(Typ.) 70% (Min)
Full Colour (16.77million colours)
1W Monaural
Effect, User Logo, A/V mute, Freeze
Right/Left: -30 to +30 degrees / Upper/Lower: -15 to +15 degrees
Receiver Directivit
Effective Scanning
Frequency Range
Analogue
Adjustment Function
Analogue RGB I/O
Display Performance Native: 1024 x 768 dots
Input Signal Signal Type: Separate signal; Video Signal: Analogue (0.7V p-p, 75 ohm / Mac0.714Vp-p,
Input Terminal Video: Mini D-sub 15pin x 1 Blue-molding; Audio: Output Signal Video Signal: Analogue (0.7V p-p, 75 ohm / Mac 0.714Vp-p, 75ohm); Sync. Signal: Separate
Output Terminal Video: Mini D-sub 15pin x1 Black-molding
Video I/O
Display Performance NTSC: 560 line PAL: 560 line (Depend on observation of the multi burst pattern)
Input Signal Video Standard: NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM; Video Signal:
Input Terminal Video: Composite Video: RCA (Yellow) x 1; S-Video: Mini DIN; "Component Video: Mini D-sub
Control I/O
Operating Temperatur
Start-up Period
Cool-down Period
Power Supply Volta
Power Consumption
Rated Voltage & Curren
Dimension
Weight
Fan Noise
Accessories
Options
Warrant
Pixel Clock: 13.5MHz to 162MHz; Horizontal: 15KHz to 92KHz; Vertical: 50Hz to 85Hz
Projector / Remote Control: Keystone (Vertical) / Brightness / Contrast / Tint / Saturation/
Sound / Input signal etc.; Foot Adjuster: Front-centre; Tilt Angle: 0 to 10 degrees; Keystone
Correction: Vertical: -30 to +30 degrees (Zoom: Tele); Source Search; Auto Detection of
RGB/YCbCr; Operation Panel Protected Function; "Password Protected Function; (Security
function)"; Colour Mode: "PC: Photo, Presentation, Theatre, Game, sRGB, Blackboard; Video:
Sports, Presentation, Theatre, Game, sRGB, Blackboard"; Direct Power On
75ohm); Sync. Signal: Separate (positive & negative, bi-polarity 2-5Vpp) / Composite
(positive & negative, bi-polarity 2-5Vpp) / Sync-on-green (negative, 0.3Vpp); Audio Signal:
500mVrms / 47k-ohm
(positive & negative,TTL) / Composite (positive & negative, TTL) / Sync. on green (negative
0.2-0.4 Vp-p)
Composite Video (1.0Vpp/ Sync.negative, 75ohm) / S-Video (Luminous 0.714Vpp,
Chrominous 0.286Vpp, 75ohm) / Component Video (Analogue Y level 0.7V 75 ohm / Cr Cb
level +/-0.35V 75ohm/ sync.negative 0.3V or 3-state+/-0.3V on Y) / Video-RGB (0.7V p-p,
75 ohm/ Mac 0.714; Audio Signal: 500mVrms / 47k-ohm
15pin Blue-molding; (in common with Analogue RGB connector)"; Video-RGB: Mini D-sub
15pin Blue-molding (in common with Analogue RGB connector)
USB I/O: I/O Terminal: USB connector series B x1 (for mouse, K/B, control)
5°C to 35°C <41°F to 95°F> ( 20%-80% Humidity ) Thermal shut down > 45 °C
about 4 seconds
0 seconds, Instant Off
100-240V ±10% , 50/60Hz AC
230V area (Europe): Lamp On: 240W; Stand-by: 5.0W
100 - 240 VAC 2.9 - 1.2A 50/60Hz
Exclude Feet (D x W x H): 246(D) x 327(W) x 86(H) mm; Maximum Dimension (D x W x H):
246(D) x 327(W) x 98(H) mm
2.6kg
Low Brightness Mode: 30dB
Power Cord: 1.8m; Computer Cable: 1.8m, Slim-cable with blue colour jacks, Mini D-sub 15pin
(Male) - Mini D-sub 15pin (Male); Remote Control; Battery: AAA Alkaline battery x2;
Soft Carrying Case; Frame Air Filter; Password Protect Sticker; User's manual
Spare Lamp: ELPLP34; Air Filter Set: ELPAF08; Soft Carrying Case: ELPKS16;
Ceiling Mount: Silver: ELPMB18
UK - 3 year next day on site repair or replace
Ireland - 3 year next day on site repair or loan
