ITEM # _______________________________________________ |
|
MODEL # _____________________________________________ |
Modular Cooking Range Line |
PROJECT NAME # ______________________________________ |
S90 Heavy Duty Half Module |
SIS # _________________________________________________ |
Gas Char-Broiler, Island |
AIA # _________________________________________________ |
|
|
|
|
Modular Cooking Range Line
S90 Heavy Duty Half Module Gas
Char-Broiler, Island
584090 (WDGRAAOOOO) S90 Half Module Gas Char-Broiler, open base, island operation
Short Form Specification
Item No. ___________________________________
Unit to be Electrolux S90 Heavy Duty Half Module Gas Char-Broiler with open base. Unit to have high efficiency 41,000 BTU (20 kW) stainless steel burners with self stabilizing flame. Unit to be installed in central island type installations with operations from one side. Cooking surface grids to be of cast iron, easily removable for cleaning. Cast iron grids can be rotated for the grilling of fish or meats. Unit to include drip tray for the collection of grease and fat. Body and open base of unit entirely in 304 type stainless steel and basin made of high grade 316 type stainless steel. Unit shall have heavy duty 304 type stainless steel internal frame with reinforcement on the top of 0.118″ (3 mm). Extra strength work top in heavy duty 0.118″ (3 mm) stainless steel. “Lastertec connection system permits units to be connected to each other creating a seamless work top.
Covered by Electrolux Platinum Star® Service Program two-year parts and one-year labor warranty, installation start-up and performance check-up after one year from installation.
Main features
•Unit for island type installation with operations by chef from one side.
•304 type stainless steel burners with self stabilizing flame.
•Each burner has 3 branches and the gas holes are protected by the radiant elements to prevent fat dripping on them.
•Regulators with fixed high and low positions for precise control.
•Cast iron cooking grid lifts off for ease of cleaning.
•Cast iron grids can be rotated for grilling of fish or meats.
•Drip tray to collect residual cooking grease and fat.
•Stainless steel high splash guards on the rear and sides. Splash guards can be easily removed for cleaning.
•Open base compartment for storage of pots, pans sheet pans etc.
•Piezo spark ignition with thermocouple for added safety.
•Heavy duty internal frame 304 type stainless steel with reinforcement on top of 0.118″ (3 mm).
•Basin made of high grade 316 type stainless steel.
•0.118″ (3 mm) top in 305 type stainless steel.
•“Lasertec connection system” creates seamless work top when units are connected to each other.
•Unit delivered with four 7-7/8″ (200 mm) legs as standard (all round stainless steel plinth as option).
•Scraper for cleaning of grilling grids included.
Optional Accessories
•Set 4 castors (2 with brake).
•Left side stainless steel 0.118″ (3 mm) panel.
•Right side stainless steel 0.118″ (3 mm) panel.
•5″ (130 mm) portioning shelf.
•7.8″ (200 mm) portioning shelf.
•All round stainless steel plinth.
•Shelf for open base.
•Shelf fixation kit for open base.
Approval: ___________________________________________
Electrolux Professional, Inc. www.electroluxusa.com/professional
3225 SW 42nd Street, Fort Lauderdale, Florida, 33312 • Telephone Number: 866-449-4200 • Fax Number: 954-327-6789
