Original operating instructions
Cordless drill/screwdriver
Art.-Nr.: 45.132.64 I.-Nr.: 11011
RT-CD 18/1-2B Li
Anleitung_RT_CD_18_1_Li_SPK7:_ 19.08.2010 10:58 Uhr Seite 1
1
9 1
7
11
6
8
5
2 3
3
5
5
2
10
4
6
8
2
Anleitung_RT_CD_18_1_Li_SPK7:_ 19.08.2010 10:58 Uhr Seite 3
4
1
5
4
6
8
7
7
11a
11b
1
2
3
a 9
a
10
2
3
Anleitung_RT_CD_18_1_Li_SPK7:_ 19.08.2010 10:58 Uhr Seite 4
4
GB
Change the gear only when the drill is at a standstill. If you fail to observe this point, the gearing
may be damaged.
Store the battery only in dry rooms with an ambient temperature of +10°C to +40°C. Place only
charged batteries in storage (charged at least 40%).
“Caution - Read the operating instructions to reduce the risk of injury”
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Wear a breathing mask.
Dust which is injurious to health can be generated when working on wood and other materials.
Never use the device to work on any materials containing asbestos!
Wear safety goggles.
Sparks generated during working or splinters, chips and dust emitted by the device can cause
loss of sight.
Anleitung_RT_CD_18_1_Li_SPK7:_ 19.08.2010 10:58 Uhr Seite 11
Important!
When using equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating manual with due
care. Keep this manual in a safe place, so that the
information is available at all times. If you give the
equipment to any other person, give them these
operating instructions as well.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.
1. Safety information
Please refer to the booklet included in delivery for the
safety instructions.
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout/Items supplied (Fig. 1)
2.1 Layout
1. Torque selector
2. Battery capacity indicator
3. Changeover switch
4. ON/OFF switch
5. Battery pack
6. Battery charger
7. Selector switch for 1st/2nd gear
8. Pushlock button
9. Quick-change drill chuck
10. LED lamp
11. LED display for counter-clockwise/clockwise
2.2 Items supplied
Open the packaging and take out the equipment
with care.
Remove the packaging material and any
packaging and/or transportation braces (if
available).
Check to see if all items are supplied.
Inspect the equipment and accessories for
transport damage.
If possible, please keep the packaging until the
end of the guarantee period.
IMPORTANT
The equipment and packaging material are not
toys. Do not let children play with plastic bags,
foils or small parts. There is a danger of
Cordless drill/screwdriver
Battery charger
2 x Battery
Original operating instructions
Safety instructions
3. Proper use
The cordless drill/screwdriver is designed for
tightening and undoing screws, as well as for drilling
in wood, metal and plastic.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
.c.d V 81ylppus egatloV
Idling speed: 0-320/0-1350 rpm
1+32 :sgnittes euqroT
Forward and reverse rotation yes
Chuck clamping width max. 10 mm
Battery charging voltage 20 V d.c.
Battery charging current 550 mA
Mains voltage for charger 230 V ~ 50 Hz
gk 6.1thgieW
mm 6:retemaid wercs .xaM
The maximum screw diameter indicates the
maximum diameter of the screw that can be screwed
into wood. The screw diameter can vary depending
on the type of wood.
GB
5
Anleitung_RT_CD_18_1_Li_SPK7:_ 19.08.2010 10:58 Uhr Seite 12
Battery 5 cells Li-ion; 1500 mAh
GB
6
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
LpAsound pressure level 68.9 dB(A)
K
pA
Bd 3 ytniatrecnu
LWAsound power level 79.9 dB(A)
K
WA
Bd 3 ytniatrecnu
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with EN 60745.
Drilling in concrete
Vibration emission value a
h
≤ 2,5 m/s
2
K uncertainty = 1,5 m/s
2
Screwing without hammer action
Vibration emission value a
h
≤ 2,5 m/s
2
K uncertainty = 1,5 m/s
2
Additional information for electric power tools
Warning!
The specified vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equipment
is used and may exceed the specified value in
exceptional circumstances.
The specified vibration value can be used to compare
the equipment with other electric power tools.
The specified vibration value can be used for initial
assessment of a harmful effect.
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever
necessary.
Switch the appliance off when it is not in use.
Wear protective gloves.
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain residual
risks cannot be rules out. The following hazards
may arise in connection with the equipment’s
construction and layout:
1. Lung damage if no suitable protective dust mask
is used.
2. Damage to hearing if no suitable ear protection is
used.
3. Health damage caused by hand-arm vibrations if
the equipment is used over a prolonged period or
is not properly guided and maintained.
Limit the operating time.
All stages of the operating cycle must be considered
(for example, times in which the electric tools are
switched off and times in which the tool is switched
on but operates without load).
5. Before starting the equipment
Be sure to read the following information before you
use your cordless screwdriver for the first time:
1. Charge the battery pack with the charger
supplied. An empty battery pack requires a
charging period of approximately 3-5 hours.
2. Only ever use sharp drill bits and screwdriver bits
which are suitable for the purpose and in
faultless condition.
3. Always check for concealed electric cables and
gas and water pipes when drilling and screwing
in walls.
6. Operation
6.1 Charging the LI battery pack (Fig. 2-3)
1. Remove the battery pack (5) from the handle,
pressing the pushlock buttons (8) downwards to
do so.
2. Check that your mains voltage is the same as that
marked on the rating plate of the battery charger.
Plug the mains plug of the charger (6) into the
mains socket outlet. The red and green LEDs will
come on together for approximately 1 second.
3. Push the battery into the battery charger. The
flashing green LED will come on to indicate that
the battery is being charged. When the charging
process is finished, the green LED will be
permanently lit. The time it takes to fully recharge
an empty battery is approximately 3 to 5 hours.
The temperature of the battery may rise slightly
during the charging operation. This is normal. If
Anleitung_RT_CD_18_1_Li_SPK7:_ 19.08.2010 10:58 Uhr Seite 13
GB
7
the red LED flashes after the battery has been
inserted, the battery is defective. In this case, pull
out the mains plug of the charger immediately
and remove the defective battery. Do not use the
defective battery again. If the red LED on the
charger lights up while the battery pack is
inserted, the charging temperature is either too
high or too low. In this case, pull out the mains
plug of the charger and charge the battery in an
environment in which the temperature is either
warmer or colder.
If the battery pack fails to become charged, please
check
whether there is voltage at the socket-outlet
whether there is proper contact at the charging
contacts on the charger.
If the battery still fails to become charged, please
return
the charger
the battery pack
to our Customer Service Department.
To ensure that the LI battery pack provides long
service you should take care to recharge it promptly.
You must recharge the battery pack when you notice
that the power of the cordless screwdriver drops.
6.2 Torque setting (Fig. 4 / Item 1)
Important! The tool must be at a standstill when
you set the torque with the setting ring.
The cordless screwdriver is fitted with a mechanical
torque selector.
The torque for a specific size of screw is selected
with the set-collar (1). The correct torque depends on
several factors:
on the type and hardness of material in question
on the type and length screws used
on the requirements needing to be met by the
screwed joint.
The clutch disengages with a grating sound to
indicate when the set torque is reached.
6.3 Drilling (Fig. 4 / Item 1)
For drilling purposes, move the set-collar to the last
step „Drill“. In this setting the slip clutch is inactive.
The maximum torque is available in drilling mode.
6.4 Forward/Reverse switch (Fig. 5 / Item 3)
With the slide switch above the On/Off switch you
can select the direction of rotation of the batterypowered drill/screwdriver and secure it against being
switched on accidentally. You can choose between
clockwise and anticlockwise rotation. To avoid
causing damage to the gearing it is advisable to
change the direction of rotation only when the tool is
at a standstill. The On/Off switch is blocked when the
slide switch is in centre position.
6.5 On/Off switch (Fig. 5 / Item 4)
Infinitely variable speed control is possible with the
On/Off switch. The further you press the switch, the
higher the speed of the battery-powered
drill/screwdriver.
6.6 Changing over from 1st gear to 2nd gear
(Fig. 6 / Item 7)
You can work at a higher or lower speed depending
on the position of the selector switch. To avoid
damaging the gear unit you should only change over
gears when the tool has stopped.
6.7 Battery capacity indicator (Fig. 7 – Item 2)
Press the battery capacity indicator switch (a). The
battery capacity indicator (2) shows the charge
status of the battery using 3 LEDs.
All 3 LEDs are lit:
The battery is fully charged.
2 LEDs are lit:
The battery has an adequate remaining charge.
1 LED is lit:
The battery is empty, recharge the battery.
6.8 LED lamp (Fig. 7 / Item 10)
The LED lamp (10) can be used in poor lighting
conditions to illuminate the area where you want to
drill or screw. The LED lamp (10) will be lit
automatically as soon as you press the ON/OFF
switch (4).
6.9 Changing the tool (Fig. 8)
Important. Set the changeover switch (3) to its
centre position whenever you carry out any work (for
example changing the tool, maintenance work, etc.)
on the cordless screwdriver.
The cordless screwdriver is fitted with a quickaction chuck (9) with an automatic spindle stop.
Open the chuck (9). The chuck opening (a) must
be large enough to hold the tool (drill bit or
screwdriver bit).
Select the suitable tool. Push the tool as far as
Anleitung_RT_CD_18_1_Li_SPK7:_ 19.08.2010 10:58 Uhr Seite 14
GB
8
possible into the chuck opening (a).
Tighten the chuck (9) and then check that the
tool is secure.
6.10 Screwdriving
We recommend using self-centering screws (e.g.
Torx screws, recessed head screws) designed for
reliable working. Be sure to use a bit that matches
the screw in shape and size. Set the torque, as
described elsewhere in these operating instructions,
to suit the size of screw.
6.11 LED display for clockwise/counterclockwise operation (Figure 6/Item 11)
The LED display for counter-clockwise/clockwise (11)
indicates the position of the changeover switch (3).
Green LED (11a) is lit: clockwise
Red LED (11b) is lit: counter-clockwise
7. Cleaning, maintenance and ordering
of spare parts
Always pull out the mains power plug before starting
any cleaning work.
7.1 Cleaning
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
We recommend that you clean the device
immediately each time you have finished using it.
Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts
of the equipment. Ensure that no water can seep
into the device.
7.2 Maintenance
There are no parts inside the equipment which
require additional maintenance.
7.3 Ordering replacement parts
Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
8. Disposal and recycling
The unit is supplied in packaging to prevent its being
damaged in transit. This packaging is raw material
and can therefore be reused or can be returned to
the raw material system.
The unit and its accessories are made of various
types of material, such as metal and plastic.
Defective components must be disposed of as
special waste. Ask your dealer or your local council.
9. Storage
Store the equipment and accessories out of children’s
reach in a dark and dry place at above freezing
temperature. The ideal storage temperature is
between 5 and 30 °C. Store the electric tool in its
original packaging.
Anleitung_RT_CD_18_1_Li_SPK7:_ 19.08.2010 10:58 Uhr Seite 15
The guarantee provided in this Guarantee Certificate is given by Einhell Australia Pty Limited
ACN 134 632 858 of 6/166 Wellington Street, Collingwood, Victoria (Telephone number 1300 922 271)
GUARANTEE
CERTIFICATE
EINHELL AUSTRALIA PTY LTD
6/166 Wellington Street
Collingwood VIC 3066
Australia
Phone: 1300 922 271
Dear
Customer,
All of our products undergo strict quality checks. In the unlikely event that your device develops a fault, please
contact our service department at the address shown on this guarantee certificate. Of course, if you would
prefer to call us then we are also happy to offer our assistance under the service number printed below.
Please note the following terms under which claims under the Einhell Express Guarantee can be made:
1. The benefits conferred by the Einhell Express Guar
antee are in additi
on to all rights and remedies which
you may be entitled to under the Australian Consumer Law, and any other statutory rights you may have
under other applicable laws. This Einhell Express Guarantee does not exclude, restrict or modify any
We do not charge you for the Einhell Express Guarantee.
2. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any othe
r reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure.
3. The Einhell Express Guarantee only covers problems caused by material or manufacturing defects, and
our liability under the Einhell Express Guarantee is limited, at our discretion, to the rectification of these
defects or replacement of the product. Please note that the product has not b
een des
igned for use in
commercial, trade or industrial applications. Consequently, the Einhell Express Guarantee will not apply
if the product is used in commercial, trade or industrial applications or for other equivalent activities.
4. The following are also excluded from the Einhell Express Guarantee: compensation for transport
damage, damage caused by failure to comply with the installation/assembly instructions or damage
caused by unprofessional installation, failure to comply with the op
erat
ing instructions (e.g. connection to
the wrong mains voltage or current type), misuse or inappropriate use (such as overloading of the
product or use of non-approved tools or accessories), failure to comply with the maintenance and safety
regulations, ingress of foreign bodies into the product (e.g. sand, stones or dust), effects of force or
external influences (e.g. damage caused by the product being dropped) and normal wear resulting from
proper operation of the product. The
Einhell
Express Guarantee will also not apply if any attempt is made
5. The Einhell Express Guarantee is valid for a period of 2 years starting from the purchase date of the
product. Claims made under the Einhell Express Guarantee should be submitted before the end of this
guarantee period and within two weeks of the defect being noticed. No claims under the Einhell Express
Guarantee will be accepted if submitted after the end of this guarantee period. The original guarantee
period remains applicable to the
device even i
f repairs are carried out or parts are replaced. In such
cases, the work performed or parts fitted will not result in an extension of the guarantee period for the
Einhell Express Guarantee, and the Einhell Express Guarantee will not apply for the work performed or
6. To make a claim under the Einhell Express Guarantee, please send the relevant product postage-free to
the address shown below and enclose either the original or a copy of your sales receipt or another dated
proof of
purchase. It would help us if you could describe the nature of the problem in as much detail as
possible. If the defect is covered by the Einhell Express Guarantee, your product will be repaired
immediately and returned to you, or we will send you a new device (at our election).
Any costs incurred by you in making a claim under this Einhell Express Guarantee, unless specified
otherwise in this guarantee certificate, must be borne by you.
Of course, we are also happy to offer a chargeable
repair
service for any defects which are not covered by the
scope of the Einhell Express Guarantee or for products which are no longer covered by the Einhell Express
Guarantee. To take advantage of this service, please send the product to our service address.
such rights or remedies.
to tamper with the product.
parts fitted. This also applies when an on-site service is used.
(Einhell Express Guarantee).
EH 04/2012 (03)
EH 04/2012 (03)
EH 04/2012 (03)
Loading...
