Front and Rear Inputs
XDMA760BT
INSTALLATION/OWNER'S MANUAL
CD Receiver
XDMA760BT
BLUE
BLACK
RED
YELLOW
RemoteTurn-On
Conn ect to amplifier or power
antenna. Insulate wire if not used.
Ground
Conn ect to the vehicle
chassis ground.
Accessory
Conn ect to an existing ignition
circuit or switched 12 volt source.
Memory
Conn ect to the battery
circuit or constant 12 volt source.
Right Front
Gray/Black (-)
Gray (+)
Left Front
White/Black (-)
White (+)
Left Rear
Green/Black (-)
Green (+)
Right Rear
Violet/Black (-)
Violet (+)
SUBREARFRONT
L-CH
R-CH
Antenna
Connector
Rear Output
Front Output
Subwoofer Output
Steering Wheel
Preparation
Please read entire manual before installation.
Before You Start
• Disconnect negative battery terminal. Consult a qualified technician for instructions.
• Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting Started
• Remove trim ring from unit.
• Remove 2 transit screws located on top of the unit.
• Insert the supplied keys into the slots as shown, and slide the unit out of the mounting
sleeve.
• Install mounting sleeve into opening, bending tabs to secure.
• Connect wiring harness and antenna. Consult a qualified technician if you are unsure.
• Certain vehicles may require an installation kit and/or wiring harness adapter (sold
separately).
• Test for correct operation and slide into mounting sleeve to secure.
• Snap trim ring into place.
REMOVAL
KEYS
HEAD UNIT
OPTIONAL REAR
MOUNTING SUPPORT
MOUNTING SLEEVE
TYPICAL DIN FRONT-LOAD MOUNTING METHOD
2
Wiring Diagram
Steering Wheel
Subwoofer Output
Rear Output
Front Output
XDMA760BT
SUBREARFRONT
L-CH
Right Front
Gray/Black (-)
Gray (+)
BLUE
BLACK
RED
YELLOW
R-CH
RemoteTurn-On
Conn ect to amplifier or power
antenna. Insulate wire if not used.
Ground
Conn ect to the vehicle
chassis ground.
Accessory
Conn ect to an existing ignition
circuit or switched 12 volt source.
Memory
Conn ect to the battery
circuit or constant 12 volt source.
Right Rear
Violet/Black (-)
Violet (+)
Antenna
Connector
FUSE
When replacing the fuse,
make sure new fuse is the
correct type and amperage.
Using an incorrect fuse could
damage the radio.
The XDMA760BT uses one
10 amp ATM fuse located
in-line.
Left Front
White/Black (-)
White (+)
Left Rear
Green/Black (-)
Green (+)
3
XDMA760BT
Control Locations - Receiver
1 2 3 4 9
17
Open
1 10
Source
2 11
Bluetooth Talk
3 12
Play / Pause
4 13
5 14
Volume Knob/ Select (push)
14
1516
65
7 8
11
1213
Auxiliary Input
Tune / Track Down
Preset Down / Thumbs Down
Display
Mute
10
Preset Up / Thumbs Up
6 15
Tune / Track Up
7 16
Function
8
USB Port
9
4
Band / Go Back
Power
17
Menu
XDMA760BT
Control Locations - Remote
Source
1
Volume Up
2
Power
3
Select
4
5
Tune / Track Up
Volume Down
6
Band / Go Back
7
Key 3 / Intro
8
Key 6 / Folder Up
9
10
Key 9 / Key #
11
Key 8 / Mute
17
16
14
21
20
19
18
15
1
2
3
4
5
6
7
8
9
10
11
12
13
12
Preset Up / Thumbs Up
13
Key 0 / Key +
14
Preset Down / Thumbs Down
15
Key 7 / Key *
16
Key 5 / Folder Down
17
Key 4 / Play / Pause
18
Key 1 / Repeat
19
Key 2 / Random
20
Talk
21
Tune / Track Down
5
XDMA760BT
General Operation
Faceplate Removal
Power On/Off
Source
Auxiliary Input
Volume
Display
Reset
Set the Clock
12/24-hour Clock
Press OPEN to open the face plate, then pull away from
the right side to remove. To re-install, insert right side of
faceplate first then push left side to secure.
Press
turn the unit off.
Press SOURCE to enter the Source Menu, then press
SOURCE or rotate the volume knob to select between Tuner,
Disc, Auxiliary Input, USB, iPod, Bluetooth and Pandora
modes. Modes of operation are shown in the display.
The XDMA760BT offers an auxiliary input ports for
connecting an audio device, MP3 player, etc. Press SOURCE
to select auxiliary input mode.
Adjust volume using volume knob (00-46).
Press DISP to toggle between ID3 tag and file/folder name
for MP3/WMA files being played from CDs or USB devices.
Press RESET upon initial installation or if abnormal
operation occurs. Reset button is located behind the front
panel.
The unit will display the time on the LCD display. Clock
settings are adjusted in the General setup menu.
The clock will display 12-hour AM/PM time or 24-hour time
(22:00). Frequency spacing is adjusted in the General setup
menu (refer to page 8).
or any other button to turn the unit on. Press to
6
XDMA760BT
General Operation
Setup Menu
Press MENU to toggle through and select one of the
following setup menus: Audio, General, Gain and Screen.
1. Once the desired menu is displayed, rotate the volume
knob to scroll through the list of menu features.
2. Press SELECT to select a specific feature to adjust, then
rotate the volume knob left/right to adjust or activate
the desired feature.
3. Press SELECT to confirm and save the changes.
Audio Setup Menu
Menu Function Options
Equalization
Curves
Bass Level
Bass Frequency
Middle Level
Middle Frequency
Treble Level
Treble Frequency
Balance
Fader
Subwoofer
Rotate the volume knob to cycle through the following equalization curves: Flat,
Pop, Jazz, Classic, Beat, Rock and User. Any manual adjustment to the Bass or
Treble settings are automatically saved as User.
Rotate the volume knob to adjust the bass level setting
(-6 minimum / +6 maximum).
Rotate the volume knob to select one of the following bass frequency settings:
60 Hz, 80 Hz, 100 Hz or 200 Hz.
Rotate the volume knob to adjust the middle level setting
(-6 minimum / +6 maximum).
Rotate the volume knob to select one of the following middle frequency settings:
500 Hz, 1 kHz, 1.5 kHz or 2.5 kHz.
Rotate the volume knob to adjust the treble level setting
(-6 minimum / +6 maximum).
Rotate the volume knob to select one of the following treble frequency settings:
10 KHz, 12.5 KHz, 15 KHz or 17.5 KHz.
Rotate the volume knob to adjust the balance setting.
(12-L to 12-R; 0 represents equal balance).
Rotate the volume knob to adjust the fader setting.
(12-F to 12-R; 0 represents equal balance)
Rotate the volume knob to turn subwoofer output ON or OFF.
Subwoofer Level
Subwoofer
Frequency
Rotate the volume knob to adjust subwoofer level between 0 and 12.
Rotate the volume knob to select one of the following subwoofer center
frequency settings: Off, 80 Hz, 120 Hz and 160 Hz. "Off" represents a full range
subwoofer output.
7
XDMA760BT
General Operation
General Setup Menu
Menu Function Options Action
Programs the unit to USA tuner spacing.
(200kHz for FM and 10kHz for AM).
Programs the unit to South American tuner spacing.
(100kHz for FM and 10kHz for AM).
Programs the unit to European tuner spacing.
(50kHz for FM and 9kHz for AM).
Press SELECT to seek and save 6 strong stations in the
current band.
Rotate the volume knob to adjust the hours, then press
SELECT to confirm. Repeat to adjust the minutes, and repeat
again to adjust AM/PM setting.
Programs the unit to display 12-hour AM/PM time (example:
10:00 PM)
Programs the unit to not scroll any information on the
display.
Programs unit to scroll information once every 15 seconds
(default).
Programs the head unit to advanced control of the iPod/
iPhone device.
Programs the head unit to manual control of the iPod/iPhone
device and allows music to be controlled from the iPod/
iPhone device.
Programs unit to always turn on at a specific volume
(default is Off). A volume level of 1-30 can be selected.
Tuner
Frequency
Spacing
Auto Station
Store
Local/Distance
Tuning
Set the Clock
Clock Mode
Scrolling
Option
iPod Control
Beep
Confirmation
Programmable
Turn On Volume
USA
S-America
Europe
AUTO STORE
Off Activates distance tuning.
On Activates local tuning for strong station reception only.
Clock
12 Hour
24 Hour Programs the unit to display 24-hour time (example: 22:00)
Off
Once Programs the unit to only scroll information once.
15Sec
On Programs unit to scroll information continuously.
Full
Manual
Off Disables the confirmation beep.
On Enables the confirmation beep.
Variable
Value
8
XDMA760BT
General Operation
Gain Setup Menu
Menu Function Options
Tuner Gain
Disc Gain
Aux Gain
Bluetooth
USB Gain
iPod Gain
Pandora Gain
Menu Function Options
Demo
Backlight
Rotate the volume knob to adjust the tuner gain.
(-6 minimum / +6 maximum)
Rotate the volume knob to adjust the gain for disc playback.
(-6 minimum / +6 maximum)
Rotate the volume knob to adjust the gain for the front auxiliary input.
(-6 minimum / +6 maximum)
Rotate the volume knob to adjust the gain for the rear auxiliary input.
(-6 minimum / +6 maximum)
Rotate the volume knob to adjust the gain for USB playback.
(-6 minimum / +6 maximum)
Rotate the volume knob to adjust the gain for iPod playback.
(-6 minimum / +6 maximum)
Rotate the volume knob to adjust the gain for Pandora playback.
(-6 minimum / +6 maximum)
Screen Setup Menu
Rotate the volume knob to to enable (ON) or disable (OFF) the demonstration
mode.
Rotate the volume knob to adjust the brightness settings of the display screen
from 1 to 7.
9
XDMA760BT
AM/FM Tuner Operation
Manual Tuning
Seek Tuning
Band
Storing Station Presets
Recalling Station Presets
Press TUNE
radio frequency up or down one step at a time. Press and
hold to advance quickly.
Press TUNE
(then release) to automatically seek and tune to the next
strong station.
Press BAND to select between FM1, FM2, FM3, AM1 and
AM2 bands.
Select the desired band and station. Press the
(F)unction button, turn the volume knob until the desired
preset number is highlighted, then press SELECT to store
the preset.
Press the P+ or P- buttons to cycle through the 1-6 presets
in the current band.
or TUNE
nn
or TUNE
nn
momentarily to change
ll
for more than two seconds
ll
10
XDMA760BT
CD Operation
Insert CD
Eject CD
Track Select
Fast Forward/Reverse
Pause
Repeat
Random
Intro
Press OPEN to fold down the front panel and expose the CD
slot. With the label facing up, insert a standard size CD into
the CD slot. The CD will automatically begin playback.
With the front panel open, press EJECT to eject the CD. The
unit will change to previous mode of operation. If the disc is
not removed within 10 seconds, the unit will reload the disc.
The unit does not have to be turned on to eject CD.
Press TRACK
track. Press TRACK
current track. Pressing TRACK
beginning of the previous track.
Press and hold TRACK
control to fast forward or reverse a track.
Press
Press
Press (F)unction and choose Repeat to continuously repeat
the selected track.
Press (F)unction and choose Random to play all the tracks
in random order.
Press (F)unction and choose Intro to play the first 10 seconds of each track.
/ II to temporarily stop CD playback.
l
/ II again to resume playback.
l
to skip to the beginning of the next
ll
to return to the beginning of the
nn
or TRACK
ll
again skips to the
nn
nn
on the remote
CD-R/CD-RW
Compatibility
Some CD-Rs and CD-RWs may be incompatible with this
unit, depending on media type and recording method. In
addition, the following CDs may be incompatible with this
unit:
CDs exposed to extreme temperatures or direct sunlight
for extended periods of time, CDs recorded in which a
recording session failed or a re-recording was attempted
and, or encrypted or copy-protected CDs which do not
conform to the audio CD-DA red book recording standard.
11
XDMA760BT
MP3/WMA Operation
Playing MP3/WMA Files
Displaying Information
Repeat
Random
To play MP3/WMA files, insert a data CD or USB device
containing MP3/WMA files. “Loading" will flash in the
display. Depending on the number of files and folders, this
may take several seconds.
Press DISP to cycle between track information and file/
folder information.
*Song title, artist name and album name will only be
displayed if included with the MP3/WMA file.
When referring to MP3/WMA playback, the following terms
are synonymous:
• File name and track name
• Folder name and directory name
Press (F)unction to enter the Function Menu, then rotate
the volume knob until Repeat is highlighted. Press SELECT,
then rotate the volume knob to select one of the following
repeat options.
• All - Plays all songs on disc or device.
• Track - Continuously repeats selected song.
• Folder - Continuously repeats all songs in selected
folder.
Press (F)unction to enter the Function Menu, then rotate the
volume knob until Random is highlighted. Press SELECT,
then rotate the volume knob to select one of the following
options for random playback.
• Off - Cancels the Random function.
• All - Plays all songs in random order.
• Folder - Plays all songs in folder in random order.
Intro
Press (F)unction to enter the Function Menu, then rotate the
volume knob until Intro is highlighted. Press SELECT, then
rotate the volume knob to select one of the following options
for intro playback.
• Off - Cancels the Intro function.
• All - Plays first 10 seconds of each song.
• Folder - Plays first 10 seconds of each song in folder.
Note: Folder repeat, random and intro options only function
on MP3/WMA discs or devices recorded with more than one
folder.
12
XDMA760BT
MP3/WMA Operation
File/Folder Search
Begin Searching
Choose a Song
Menu Navigation
Playing a Song
Press
SELECT
Folder 1 Folder 2 Folder 3 Folder 4 Folder 5 Folder 6 Folder 7
Press SELECT to enter the file/folder search mode. A list of
all the folders from the disc or device will be displayed.
Note: Any files located in the root directory will be located in
the folder named "ROOT".
Turn the volume knob to cycle through all the folders
on the disc or device, and press SELECT to choose the
desired folder. The list of files in the selected folder will be
displayed. Turn the volume knob to cycle through the list of
files.
Pressing GO BACK when viewing the contents of a folder will
return to the list of folders on the disc or device. Press GO
BACK again to exit the search menu.
Once the desired song is displayed, press SELECT to begin
Press SELECT
to begin
Press
BACK
FilesFiles Files Files FilesFilesFiles
SELECT
Turn the
volume knob
13
File/Folder Compatibility and Support - CD
Type Specification
Compatible File
Types
Incompatible File
Types
Recording Format
Compatibility
Sampling Frequency
Rate Compatibility
Transfer Bit Rate
Compatibility
Character Support
ID3 Tag Support
File/Folder Limit
XDMA760BT
MP3/WMA Operation
• CD-ROM (ISO), CD-R, CD-RW
• CD-DA (digital audio)
• MP3 data (.mp3)
• WMA data (.wma)
• DRM protected files
• WMA lossless
• Apple lossless
• WMA Pro
• MP3 Pro
• MP3 playlists
• WAV lossless
• M4A/AAC data
• ISO9660 level 1 & level 2
• Yellow book MODE 1 & MODE 2 FORM 1
• Multi session
• MP3: 8kHz - 48kHz
• WMA: 32kHz - 48kHz
• MP3: 32kbps - 320kbps
• WMA: 32kbps - 192kbps
• Song Title: 32 characters
• Artist Name: 32 characters
• Album Name: 32 characters
• File Name: 32 characters
• Folder Name: 32 characters
• MP3 Tags: Version 1.0 - 2.4
• WMA Tags
• Maximum files: 999
• Maximum folders: 500
• Maximum folder levels: 8
14
File/Folder Compatibility and Support - USB
Type Specification
Compatible File Types
Incompatible File
Types
Sampling Frequency
Rate Compatibility
Transfer Bit Rate
Compatibility
Character Support
ID3 Tag Support
File/Folder Limit
USB/SD File System
XDMA760BT
MP3/WMA Operation
• MP3 data (.mp3)
• WMA data (.wma)
• DRM protected files
• WMA lossless
• Apple lossless
• WMA Pro
• MP3 Pro
• MP3 playlists
• M4A/AAC data
• WAV lossless
• MP3: 8kHz - 48kHz
• WMA: 32kHz - 48kHz
• MP3: 32kbps - 320kbps
• WMA: 32kbps - 192kbps
• Song Title: 32 characters
• Artist Name: 32 characters
• Album Name: 32 characters
• File Name: 32 characters
• Folder Name: 32 characters
• MP3 Tags: Version 1.0 - 2.4
• WMA Tags
• Maximum number of files: 999
• Maximum number of folders: 500 (plus the root folder)
• Maximum number of files in each folder: 999
Note: For devices with more than the maximum number of
files/folders, some files will be ingnored and may not function
properly.
• FAT/FAT32 file system supported.
• HFS/NTFS/EXT2/EXT3 not supported.
15
XDMA760BT
iPod Operation
Connect an iPod Device
Search Menu Functions
(Not Included)
(step 1)
(step 2)
(step 3)
See the below table for a list of the search menu navigation options.
Search Item
Playlist
Songs
Artists
Albums
Podcase
Menu Playlists Songs
Menu
Menu
Menu
Menu
The XDMA760BT features a direct USB control system for
iPod. To play music from an iPod device, connect the USB
cable (included with your iPod device) to the USB port on the
front panel.
Once connected, "Loading" will flash in the display, then
playback will begin automatically. If a song is playing on the
iPod device before it is connected, it will continue to play.
Search Mode
Press SELECT once to enter the search mode.
Rotate the volume knob to choose between playlist, songs,
artists, albums and podcasts. Press SELECT to select the
desired search type.
Navigate to the desired song and press SELECT to begin
playback of that song. Use the table below for reference
when navigating through the menu options.
Note: Press GO BACK to access the previous level (up one
level). Pressing GO BACK from the search main menu will
exit the search.
Menu Navigation
Songs
Artists Albums Songs
Albums Songs
Podcasts
Full/Manual Control
The XDMA760BT features both full and manual control modes for iPod/iPhone devices. See
page 8 for details to toggle the control between full and manual modes.
Important: To support manual control for iPod/iPhone, the iPod device must be updated to
the newest firmware.
Note: Not all iPod/iPhone devices are compatible with manual control mode.
16
XDMA760BT
iPod Operation
Song Select
Fast Forward and
Reverse
Pause
Repeat
Random
Intro
Press
nn
nn
Press and hold
song.
Press
Press
Press (F)unction to enter the Repeat menu, then turn the
volume knob to select one of the following options:
• Off - Repeats all tracks.
• Current Song - Repeats selected track.
Press (F)unction to enter the Random menu, then turn the
volume knob to select one of the following options:
• Off - Cancels the RDM function.
• All Songs - Plays all tracks in random order.
• Current Album - Plays all tracks in the selected album in
random order.
Press (F)unction to enter the Intro menu, then turn the vol-
ume knob to select one of the following options:
• Off - Cancels the INT function.
• On - Plays first 10 seconds of each track.
to skip to the beginning of next song. Press
ll
to return to the beginning of current song. Pressing
again skips to the beginning of previous song.
or
ll
/ II to temporarily stop playback.
l
/ II again to resume playback.
l
to fast forward or reverse a
nn
Character Support
Only alphanumeric characters can be displayed (ASCII
type). "NO SUPPORT" will be displayed if the file contains
characters that can not be displayed. "NO FILE" will be
displayed if there are no songs in the selected playlist.
Maximum character display information
• *Song title – 32 character maximum
• *Artist name – 32 character maximum
• *Album name – 32 character maximum
*Song Title, Artist Name and Album name will only be
displayed if included with the file.
17
XDMA760BT
Bluetooth Operation
Pairing a Device
Preparation
Pairing a New Device
Pairing Additional
Devices
Before you can use a Bluetooth device, it must be paired and
connected. Make sure that Bluetooth is activated on your
device before you begin the pairing process.
The XDMA760BT broadcasts the pairing signal constantly
when no devices are currently connected. Complete the
pairing sequence from your Bluetooth device. Refer to the
owner's manual for your device for more details.
The device name is "Dual BT"
The Bluetooth passcode "1234"
Note: The XDMA760BT can be in any mode of operation
when pairing is performed.
If a device is currently connected, press and hold
disconnect the current device before a new device can
be paired. Then begin the pairing sequence from the new
Bluetooth device.
to
Connecting a Paired Device
Most Bluetooth devices support the auto-connect feature, and will connect automatically
if the device is in range when the XDMA760BT is powered-on. If your device was
previously
paired but does not connect, use these instructions below.
• If your most recently connected Bluetooth device becomes disconnected or does not
reconnect, press
• To connect a previously paired device that was not recently connected:
1) If applicable, press and hold
2) From Bluetooth mode, press SELECT. "Paired Devices" will appear on the LCD.
3) Turn the volume knob to cycle through the list of devices.
4) Press SELECT or
Note: If the Auto Connect setup menu setting is set to OFF, you must press
connect you device after pairing, and each time the XDMA760BT is powered-on.
from Bluetooth mode to reconnect your mobile device.
to disconnect any connected mobile devices.
to connect to the desired device. It must be in range to connect.
to
Disconnecting a Device
Press and hold for 3 seconds to disconnect a connected device. The device will remain
paired and appear in the PAIRED DEVICES menu but will not be connected.
18
XDMA760BT
Bluetooth Operation
Disconnecting a
Device
Manual Dialing
Recent Calls List
Redialing the last number
Receiving a Phone Call
Press and hold for 3 seconds to disconnect a
connected device. The device will remain paired and appear
in the SEARCH menu, but not be connected.
Press
display. Using the remote control, enter the phone number
using the 0-9 buttons. Press
control or front panel to begin dialing.
Note: Placing a phone call from your cell phone will also
initiate Bluetooth function.
Press SELECT from Bluetooth mode to view recent calls
dialed, received or missed while connected to the head unit.
Turn the volume knob to cycle through the recent phone
numbers. Press SELECT or
To redial the last phone number, press
Bluetooth mode. Press
phone number.
Incoming phone calls will automatically appear on the
display and a ring tone will be heard.
Note: The volume of the ring tone depends on the volume
level of the head unit and may not be heard if the volume is
set to a low level or mute is activated.
• Press
• Press and hold
once. “Enter Phone Number” appear on the
or SELECT on the remote
to dial the number.
two times from
or SELECT again to redial the
to receive the incoming phone call.
to refuse the incoming phone call.
Ending a Phone Call
Streaming Audio
Note: If Auto Answer is set to ON in the setup menu, all
phone calls will be received automatically.
During an active phone call, press
If the phone call was received when listening to music
in another mode, the head unit will resume the previous
mode.
The head unit supports A2DP wireless streaming audio
from a Bluetooth mobile device directly to your head unit.
The following functions can be used to control the music:
• Press
• Press
• Press
playback.
to skip to the next available audio track.
ll
to skip to the previous audio track.
nn
/
II
to toggle between play and pause during
l
19
to end a phone call.
XDMA760BT
Bluetooth Operation
Streaming Audio Operation
The XDMA760BT supports A2DP (advanced audio distribution profile) wireless streaming
audio from your Bluetooth mobile device directly to your head unit. You can also control
your music from the front panel of the head unit using AVRCP (audio video remote control
profile).
• To stream music to your head unit, your mobile device must support the A2DP and
AVRCP Bluetooth profiles. Check the owner's manual of your mobile device for details.
• Streaming audio must be enabled from your mobile device. This option will vary
depending on the device. Some devices allow streaming audio to be disabled.
After pairing, connecting and enabling streaming audio from a compatible mobile device,
begin playing music using the music player on your mobile device. Once the music is
playing, the following functions can be used to control the music:
• The button will skip to the next available audio track.
ll
• The button will skip to the previous audio track.
nn
l
II
Bluetooth Reset
• The / button will toggle between play and pause during playback.
Note: Some Bluetooth devices may not fully support these commands.
Resetting the Bluetooth module will remove the list of paired phones and delete the list of
recent calls from memory.
To reset Bluetooth, perform the following steps:
1) Press SOURCE until the head unit is in Bluetooth mode.
2) Press and hold MENU for 3 seconds to reset Bluetooth settings back to factory default.
Compatibility Note:
Due to the differences in Bluetooth technology, some mobile devices may be incompatible,
function improperly or may not support all features when used with the XDMA760BT.
Bluetooth Setup Menu Options
Function Options Action
Bluetooth BL'TOOTH (ON/OFF) Enables/disables Bluetooth functionality.
Auto Connect AUTO CON (ON/OFF)
Auto Answer AUTO ANS (OFF/ON)
Speaker Output BT SPRKS (FRONT/ALL)
Set to On to allow a Bluetooth device to connect
automatically or Off to require manual connection.
When set to ON, incoming calls will all be answered
after 2-3 rings. When set to off, the
be pressed to answer incoming calls.
Set to FRONT to direct Bluetooth output to the front
speakers only. Set to ALL to enable Bluetooth audio
to output from all 4 speakers.
20
button must
XDMA760BT
Pandora Operation
Requirements
USB Connection
Changing Stations
Shuffle
Control for Pandora requires:
• An iPhone device with a reliable data connection, or an
iPod touch that is connected to wireless internet.
• The Pandora App installed on the iPhone/iPod device.
• An active account with Pandora. Sign up at www.pandora.
com.
• The USB sync cable that came with your iPod/iPhone
device.
Connect an iPod touch or iPhone device (required, sold separately) to the USB port, using the USB sync cable included
with your iPhone device.
1. Press SELECT to display the Stations Menu.
2. Rotate the volume knob to choose to sort channels by
date or alphabetically.
3. Press SELECT to confirm, then turn the volume knob
to cycle through the list of stations.
4. Press SELECT when the desired station is highlighted,
and playback will begin.
Note: Stations must be created on your account prior to
connecting your iPod/iPhone device to the head unit.
Press SELECT to display the Stations Menu. Choose
“Shuffle” from the stations menu to shuffle songs from all of
your stations.
Skipping Tracks
Play/Pause
Thumbs Up
Thumbs Down
Device Compatibility
Troubleshooting
Press
Press l/ II to temporarily stop playback.
Press l/ II again to resume playback.
Press to tell Pandora you like the current track. Pandora
will play more tracks with similar qualities.
Press to tell Pandora you do not like the current track.
Pandora will not play the current track again, and will avoid
playing tracks with similar qualities.
Refer to www.pandora.com/everywhere/mobile for devices
compatible with the Pandora mobile application.
Note: Pandora is an internet service, carrier and data
charges may apply.
to skip the current song.
ll
21
XDMA760BT
Limited One-Year Warranty
This warranty gives you specific legal
rights. You may also have other rights
which vary from state to state.
Dual Electronics Corp. warrants this
product to the original purchaser to be free
from defects in material and workmanship
for a period of one year from the date of the
original purchase.
Dual Electronics Corp. agrees, at our
option, during the warranty period,
to repair any defect in material or
workmanship or to furnish an equal new,
renewed or comparable product (whichever
is deemed necessary) in exchange without
charges, subject to verification of the
defect or malfunction and proof of the date
of purchase. Subsequent replacement
products are warranted for the balance of
the original warranty period.
Who is covered? This warranty is extended
to the original retail purchaser for products
purchased from an authorized Dual dealer
and used in the U.S.A.
What is covered? This warranty covers all
defects in material and workmanship in
this product. The following are not covered:
software, installation/removal costs,
damage resulting from accident, misuse,
abuse, neglect, product modification,
improper installation, incorrect line voltage,
unauthorized repair or failure to follow
instructions supplied with the product, or
damage occurring during return shipment
of the product. Specific license conditions
and copyright notices for the software can
be found via www.dualav.com.
What to do?
1. Before you call for service, check the
2. If you require service during the
3. Please describe your problem in
4. For more information and for the
Exclusion of Certain Damages: This
warranty is exclusive and in lieu of any
and all other warranties, expressed or
implied, including without limitation the
implied warranties of merchantability and
fitness for a particular purpose and any
obligation, liability, right, claim or remedy
in contract or tort, whether or not arising
from the company’s negligence, actual
or imputed. No person or representative
is authorized to assume for the company
any other liability in connection with the
sale of this product. In no event shall the
company be liable for indirect, incidental or
consequential damages.
troubleshooting guide in your owner’s
manual. A slight adjustment of any
custom controls may save you a service
call.
warranty period, you must carefully
pack the product (preferably in the
original package) and ship it by prepaid
transportation with a copy of the original
receipt from the retailer to an
authorized service center.
writing and include your name, a
return UPS shipping address (P.O. Box
not acceptable), and a daytime phone
number with your shipment.
location of the nearest authorized service
center please contact us by one of the
following methods:
• Call us toll-free at 1-866-382-5476
• E-mail us at cs@dualav.com
22
XDMA760BT
Troubleshooting
Problem Cause Action
Unit will not turn on
(no power)
Unit has power
(but no sound)
Unit blows fuses
Excessive skipping
Yellow wire not connected or incorrect
voltage Red wire not connected or
incorrect voltage
Black wire not connected Check connection to ground
Fuse blown Replace fuse
Speaker wires not connected Check connections at speakers
One or more speaker wires touching
each other or touching chassis ground
Yellow or red wire touching chassis
ground
Speaker wires touching chassis ground Check for pinched wire
Incorrect fuse rating Use fuse with correct rating
Unit is not mounted correctly or
backstrap is not secure
Physical defect in media (CD, CD-R or
CD-RW)
Disc read error Press eject or RESET
Focus error or disc is upside down Press eject or RESET
Check connections for proper
voltage (11-16VDC)
Insulate all bare speaker wires
from each other and chassis
Check for pinched wire
Check mounting sleeve and
Check media for scratches
ground
backstrap support
NO FILE appears
on display
Unit will not accept
a disc
NO SUPPORT appears
on display
WMA file is protected by DRM (Digital
Rights Management)
No playable MP3/WMA files found on
the device
Communication error
CD mechanism position out of
alignment
CD transit screws still in place
An invalid ID3 tag version is present
23
Write disc using WMA files that
are not protected
Check the device for valid
MP3/WMA files
Remove and reconnect the
device
Press EJECT to reset CD
mechanism position
Remove 2 transit screws
located on top of the unit
Version 1.0 to 2.4 ID3 tags are
supported.
XDMA760BT
Specifications
CD Player
FM Tuner
AM Tuner
General
Frequency response: 20Hz-20kHz
Channel separation @ 1kHz: >65dB
D/A converter: 1 Bit
Tuning range: 87.5MHz-107.9MHz
Usable sensitivity: 8.5dBf
50dB quieting sensitivity: 10dBf
Stereo separation @ 1kHz: >30dB
Frequency response: 30Hz-13kHz
Tuning range: 530kHz-1710kHz
Usable sensitivity: 22uV
Frequency response: 30Hz-2.2kHz
Speaker output impedance: 4-8 ohms
Line output voltage: 2 Volts RMS
Dimensions: 7" x 7" x 2" (178 x 178 x 50 mm)
Design and specifications subject to change without notice.
CEA-2006 Power Standard Specifications
(reference: 14.4VDC +/- 0.2V, 20Hz-20kHz)
Power Output: 18 Watts RMS x 4 channels at 4 ohms and < 1% THD+N
Signal to Noise Ratio: 70dBA (reference: 1 watt into 4 ohms)
24
XDMA760BT
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
25
Dual Electronics Corp.
Toll Free: 1-866-382-5476
Monday-Friday, 9AM-5PM, EST
©2015 Dual Electronics Corp. All rights reserved.
iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.
“Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod or iPhone,
respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation
of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Namsung is under license.
Pandora, the Pandora logo, and the Pandora trade dress are trademarks of Pandora Media, Inc., used with permission.
Other trademarks and trade names are those of their respective owners.
www.dualav.com
may affect wireless performance.
NSA0515-V01
Loading...
