D-Link DSS-16+
16-port 10/100 Ethernet Switch
Manual
Rev. 072104
Building Networks for People
Ver.1.00
TABLE OF CONTENTS
ABOUT THIS GUIDE ................................................................1
PURPOSE.............................................................................1
TERMS/USAGE....................................................................1
OVERVIEW OF THIS USER’S GUIDE ....................................1
INTRODUCTION .......................................................................2
FAST ETHERNET TECHNOLOGY..........................................2
SWITCHING TECHNOLOGY .................................................3
FEATURES...........................................................................4
UNPACKING AND SETUP .......................................................5
UNPACKING........................................................................5
SETUP .................................................................................5
DESKTOP INSTALLATION....................................................6
RACK MOUNTING...............................................................6
IDENTIFYING EXTERNAL COMPONENTS........................8
TECHNICAL SPECIFICATION ............................................10
WARRANTY..............................................................................12
i
ABOUT THIS GUIDE
Congratulations on your purchase of the DSS-16+ 16-port
10/100Mbps Auto-negotiation Fast Ethernet Switch. This device
integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network
capabilities in a highly flexible package.
Purpose
This guide discusses how to install your DSS-16+.
Terms/Usage
In this guide, the term “Switch” (first letter upper case) refers to DSS-16+
16-port 10/100Mbps Fast Ethernet Switch, and “switch” (first letter lower
case) refers to other Ethernet switches.
Overview of this User’s Guide
Introduction. Describes the Switch and its features.
Unpacking and Installation. Helps you get started with the basic installation
of the Switch.
Identifying External Components. Describes the front panel, rear panel and
LED indicators of the Switch.
Technical Specifications. Lists the technical (general, physical and
environmental, and performance) specifications of the Switch.
1
INTRODUCTION
This chapter describes the features of the DSS-16+ and some background
information about Ethernet/Fast Ethernet switching technology.
Fast Ethernet Technology
The growing importance of LANs and the increasing complexity of desktop
computing applications are fueling the need for high performance networks.
A number of high-speed LAN technologies have been proposed to provide
greater bandwidth and improve client/server response times. Among them,
100BASE-T (Fast Ethernet) provides a non-disruptive, smooth evolution
from the current 10BASE-T technology. The non-disruptive and smooth
evolution nature, and the dominating potential market base, virtually
guarantee cost-effective and high-performance Fast Ethernet solutions in the
years to come.
100Mbps Fast Ethernet is a new standard specified by the IEEE 802.3 LAN
committee. It is an extension of the 10Mbps Ethernet standard with the
ability to transmit and receive data at 100Mbps, while maintaining the
CSMA/CD Ethernet protocol. Since the 100Mbps Fast Ethernet is compatible
with all other 10Mbps Ethernet environments, it provides a straightforward
upgrade and takes advantage of the existing investment in hardware,
software, and personnel training.
2
Switching Technology
Another approach to pushing beyond the limits of Ethernet technology is the
development of switching technology. A switch bridges Ethernet packets at
the MAC address level of the Ethernet protocol, transmitting among
connected Ethernet or Fast Ethernet LAN segments.
Switching is a cost-effective way of increasing the total network capacity
available to users on a local area network. A switch increases capacity and
decreases network loading by dividing a local area network into different
segments, which don’t compete with each other for network transmission
capacity.
The switch acts as a high-speed selective bridge between the individual
segments. The switch, without interfering with any other segments,
automatically forwards traffic that needs to go from one segment to ano ther.
By doing this the total network capacity is multiplied, while still maintaining
the same network cabling and adapter cards.
For Fast Ethernet networks, a switch is an effective way of eliminating
problems of chaining hubs beyond the “two-repeater limit.” A switch can be
used to split parts of the network into different collision domains, making it
possible to expand your Fast Ethernet network beyond the 205-meter network
diameter limit for 100BASE-TX networks. Switches supporting both
traditional 10Mbps Ethernet and 100Mbps Fast Ethernet are also ideal for
bridging between the existing 10Mbps networks and the new 100Mbps
networks.
Switching LAN technology is a marked improvement over the previous
generation of network bridges, which were characterized by higher latencies.
Routers have also been used to segment local area networks, but the cost of a
router, the setup and maintenance required make routers relatively
impractical. Today switches are an ideal solution to most kinds of local area
3
network congestion problems.
Features
The DSS-16+ is designed for easy installation and high performance in an
environment where traffic on the network and the number of users increase
continuously.
16-port 10/100BASE Ethernet Switch with RJ-45 connectors
Supports Auto-negotiation of speed and duplex modes for each port
Supports Auto-MDI/MDI-X for each port
Wire speed reception and transmission
Store-and-Forward switching method
Integrated address Look-Up Engine, supports 8K absolute MAC
addresses
Supports 4MBits RAM for data buffering
Front-panel diagnostic LEDs
Broadcast storm protection
IEEE 802.3x flow control for full-duplex
Back pressure flow control for half-duplex
4
UNPACKING AND SETUP
This chapter provides unpacking and set u p info rmation for the DSS-16+.
Unpacking
Open the shipping carton for the Switch and carefully unpack its contents.
The carton should contain the following items:
One DSS-16+ 16-port 10/100Mbps Fast Ethernet Switch
One AC power cord, suitable for your area’s electrical power
connections
Four rubber feet to be used for shock cushioning
Screws and two mounting brackets
This User’s Guide
If any item is found missing or damaged, please contact your local reseller
for replacement.
Setup
Please consider the following when setting up the Switch:
1. The surface must support at least 5 kg.
2. The power outlet should be within 1.42 meters (6 feet) of the device.
3. Visually inspect the power cord and see that it is secured fully to the AC
power connector.
4. Make sure that there is proper heat dissipation from and adequate
5
ventilation around the Switch. Do not place heavy objects on the Switch.
Desktop Installation
When installing the Switch on a desktop, the rubber feet
included with the device must be attached first. Attach these
cushioning feet on the bottom at each corner of the device.
Allow enough ventilation space between the device and the
objects around it.
Fast Ethernet Switch installed on a Desktop or Shelf
Rack Mounting
The DSS-16+ can be mounted in an EIA standard-size, 19-inch rack, which
can be placed in a wiring closet with other equipment. Attach the mounting
brackets at the switch’s front panel (one on each side), and secure them with
the provided screws.
6
Attaching the mounting brackets to the Switch
Then, use screws provided with the equipment rack to mount each switch in
the rack.
Installing the Switch in an equipment rack
7
IDENTIFYING EXTERNAL COMPONENTS
This section identifies all the major external components of the DSS-16+.
The figure below shows the front panels of the DSS-16+.
16-port 10/100Mbps Fast Ethernet Switch
1. LED Indicator Panel
Refer to the detailed information about each of the DSS-16+’s LED
indicators.
Power
This indicator lights green when the switch is receiving power; otherwise, it
is off.
Link / Act (Link/Activity)
This indicator lights on when the port is connected to a Fast Ethernet or
Ethernet device; if the light is blinking, it indicates that data is being
transmitted or received.
8
FDX / Col (Full-duplex/Collision)
This LED indicator lights green when a respective port is in full duplex
(FDX) operation mode. Otherwise, it is blinking when collisions are
occurring on the respective port in half duplex operation mode.
100Mbps
This LED indicator lights green when the port is connected to a 100Mbps
Fast Ethernet station. Otherwise, the LED is off when the port is connected to
a 10Mbps Ethernet device.
2. Twisted-Pair Ports
These ports support
modes of full or half duplex. They
auto-negotiation for speeds of 10M or 100M, and operation
also support Auto-MDI/MDIX crossover
detection function for giving a true “plug and play” capability. Just plug the
network cable directly into the Switch. It makes no difference if the end node
is a NIC (Network Interface Card,) a switch, or a hub.
9
TECHNICAL SPECIFICATION
General
Standards
Protocol CSMA/CD
Data Transfer Rate
Topology Star
Network Cables
Number of Ports 16 x 10/100Mbps Auto-MDI ports
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full- duplex)
10BASE-T: 2-pair UTP Cat. 3,4,5, EIA/TIA- 568 100-ohm STP
100BASE-TX: 2-pair UTP Cat. 5, EIA/TIA-568 100-ohm STP
Physical and Environmental
AC inputs 100 to 240 VAC, 50 or 60 Hz internal universal power supply
Power Consumption 6 watts. (max.)
Temperature
Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90%
Dimensions
EMI: FCC Class A, CE Mark Class A, VCCI Class A
Safety cUL
Operating: 0° ~ 40° C, Storage: -10° ~ 70° C
280(W) × 180(D)× 44(H) mm
10
Performance
Transmits
Method:
RAM Buffer: 4MBits per device
Filtering
Address Table:
Packet
Filtering/Forwar
ding Rate:
MAC Address
Learning:
Store-and-forward
8K entries per device
10Mbps Ethernet: 14,880/pps
100Mbps Fast Ethernet: 148,800/pps
Automatic update
11
WARRANTY AND REGISTRATION
D-Link Systems, Inc. (“D-Link”) provides this 5-Year limited warranty for its product
only to the person or entity that originally purchased the product from:
• D-Link or its authorized reseller or distributor.
• Products purchased and delivered within the fifty United States, the District
of Columbia, US Possessions or Protectorates, US Military Installations,
addresses with an APO or FPO.
5-Year Limited Hardware Warranty: D-Link warrants that the hardware portion of
the D-Link products described below (“Hardware”) will be free from material defects
in workmanship and materials from the date of original retail purchase of the
Hardware, for the period set forth below applicable to the product type (“Warranty
Period”).
3-Year Limited Warranty for the Product(s) is defined as follows
• Hardware (excluding power supplies and fans)
• Spare parts and spare kits Ninety (90) days.
D-Link’s sole obligation shall be to repair or replace the defective Hardware at no
charge to the original owner. Such repair or replacement will be rendered by D-Link
at an Authorized D-Link Service Office. The replacement Hardware need not be new
or of an identical make, model or part; D-Link may in its discretion replace the
defective Hardware (or any part thereof) with any reconditioned product that D-Link
reasonably determines is substantially equivalent (or superior) in all material respects
to the defective Hardware. The Warranty Period shall extend for an additional ninety
(90) days after any repaired or replaced Hardware is delivered. If a material defect is
incapable of correction, or if D-Link determines in its sole discretion that it is not
practical to repair or replace the defective Hardware, the price paid by the original
purchaser for the defective Hardware will be refunded by D-Link upon return to DLink of the defective Hardware. All Hardware (or part thereof) that is replaced by DLink, or for which the purchase price is refunded, shall become the property of DLink upon replacement or refund.
Limited Software Warranty: D-Link warrants that the software portion of the product
(“Software”) will substantially conform to D-Link’s then current functional
specifications for the Software, as set forth in the applicable documentation, from the
12
date of original delivery of the Software for a period of ninety (90) days (“Warranty
Period”), if the Software is properly installed on approved hardware and operated as
contemplated in its documentation. D-Link further warrants that, during the Warranty
Period, the magnetic media on which D-Link delivers the Software will be free of
physical defects. D-Link’s sole obligation shall be to replace the non-conforming
Software (or defective media) with software that substantially conforms to D-Link’s
functional specifications for the Software. Except as otherwise agreed by D-Link in
writing, the replacement Software is provided only to the original licensee, and is
subject to the terms and conditions of the license granted by D-Link for the Software.
The Warranty Period shall extend for an additional ninety (90) days after any
replacement Software is delivered. If a material non-conformance is incapable of
correction, or if D-Link determines in its sole discretion that it is not practical to
replace the non-conforming Software, the price paid by the original licensee for the
non-conforming Software will be refunded by D-Link; provided that the nonconforming Software (and all copies thereof) is first returned to D-Link. The license
granted respecting any Software for which a refund is given automatically terminates.
Submitting A Claim. Any claim under this limited warranty must be submitted in
writing before the end of the Warranty Period to an Authorized D-Link Service
Office.
• The customer must submit as part of the claim a written description of the
Hardware defect or Software nonconformance in sufficient detail to allow
D-Link to confirm the same.
• The original product owner must obtain a Return Material Authorization
(RMA) number from the Authorized D-Link Service Office and, if
requested, provide written proof of purchase of the product (such as a copy
of the dated purchase invoice for the product) before the warranty service is
provided.
• After an RMA number is issued, the defective product must be packaged
securely in the original or other suitable shipping package to ensure that it
will not be damaged in transit, and the RMA number must be prominently
marked on the outside of the package.
• The customer is responsible for all shipping charges to and from D-Link
(No CODs allowed). Products sent COD will become the property of D-
13
Link Systems, Inc. Products should be fully insured by the customer and
shipped to
Valley, CA 92708
D-Link Systems, Inc., 17595 Mt. Herrmann Stree, Fountain
.
D-Link may reject or return any product that is not packaged and shipped in strict
compliance with the foregoing requirements, or for which an RMA number is not
visible from the outside of the package. The product owner agrees to pay D-Link’s
reasonable handling and return shipping charges for any product that is not packaged
and shipped in accordance with the foregoing requirements, or that is determined by
D-Link not to be defective or non-conforming.
What Is Not Covered:
This limited warranty provided by D-Link does not cover: Products that have been
subjected to abuse, accident, alteration, modification, tampering, negligence, misuse,
faulty installation, lack of reasonable care, repair or service in any way that is not
contemplated in the documentation for the product, or if the model or serial number
has been altered, tampered with, defaced or removed; Initial installation, installation
and removal of the product for repair, and shipping costs; Operational adjustments
covered in the operating manual for the product, and normal maintenance; Damage
that occurs in shipment, due to act of God, failures due to power surge, and cosmetic
damage; and Any hardware, software, firmware or other products or services provided
by anyone other than D-Link.
Disclaimer of Other Warranties: EXCEPT FOR THE 5-YEAR LIMITED WARRANTY
SPECIFIED HEREIN, THE PRODUCT IS PROVIDED “AS-IS” WITHOUT ANY
WARRANTY OF ANY KIND INCLUDING, WITHOUT LIMITATION, ANY WARRANTY
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IF ANY IMPLIED WARRANTY CANNOT BE DISCLAIMED IN ANY
TERRITORY WHERE A PRODUCT IS SOLD, THE DURATION OF SUCH IMPLIED
WARRANTY SHALL BE LIMITED TO NINETY (90) DAYS. EXCEPT AS EXPRESSLY
COVERED UNDER THE LIMITED WARRANTY PROVIDED HEREIN, THE ENTIRE
RISK AS TO THE QUALITY, SELECTION AND PERFORMANCE OF THE PRODUCT IS
WITH THE PURCHASER OF THE PRODUCT.
Limitation of Liability: TO THE MAXIMUM EXTENT PERMITTED BY LAW, D-LINK IS
NOT LIABLE UNDER ANY CONTRACT, NEGLIGENCE, STRICT LIABILITY OR OTHER
LEGAL OR EQUITABLE THEORY FOR ANY LOSS OF USE OF THE PRODUCT,
INCONVENIENCE OR DAMAGES OF ANY CHARACTER, WHETHER DIRECT,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL (INCLUDING, BUT NOT LIMITED TO,
DAMAGES FOR LOSS OF GOODWILL, WORK STOPPAGE, COMPUTER FAILURE OR
MALFUNCTION, LOSS OF INFORMATION OR DATA CONTAINED IN, STORED ON,
OR INTEGRATED WITH ANY PRODUCT RETURNED TO D-LINK FOR WARRANTY
SERVICE) RESULTING FROM THE USE OF THE PRODUCT, RELATING TO
14
WARRANTY SERVICE, OR ARISING OUT OF ANY BREACH OF THIS LIMITED
WARRANTY, EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE FOREGOING LIMITED
WARRANTY IS REPAIR, REPLACEMENT OR REFUND OF THE DEFECTIVE OR NONCONFORMING PRODUCT.
GOVERNING LAW: This 5-Year Warranty shall be governed by the laws of the state
of California. Some states do not allow exclusion or limitation of incidental or
consequential damages, or limitations on how long an implied warranty lasts, so the
foregoing limitations and exclusions may not apply. This limited
warranty provides specific legal rights and the product owner may also have other
rights which vary from state to state.
Trademarks
Copyright® 2002 D-Link Corporation. Contents subject to change without prior
notice. D-Link is a registered trademark of D-Link Corporation/D-Link Systems, Inc.
All other trademarks belong to their respective proprietors.
Copyright Statement
No part of this publication may be reproduced in any form or by any means or used to
make any derivative such as translation, transformation, or adaptation without
permission from D-Link Corporation/D-Link Systems Inc., as stipulated by the United
States Copyright Act of 1976.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communication. Operation of
this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
This device complies with part 15 of the F CC ru l es . Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including interference that may
cause undesired operation.
15
REGISTRATION
Register your product on-line at:
http://support.dlink.com/register
Product registration is entirely voluntary and failure to
complete or return this form will not diminish your warranty
rights.
16
Loading...
