D-link DSB-C120 User Manual

This product works with the
following operating system
software: Windows
XP/2000/ME/98SE

Before You Begin

You must have at least the following:

z Pentium III 500 MHz, Celeron, AMD Athlon processor, or higher
z 64MB RAM (or minimum OS requirement whichever is higher)
z Microsoft Windows XP/2000/ME/98SE
z Microsoft DirectX 8.1b or higher
z Update Service Pack
z 200MB free hard drive space
z CD-ROM drive
z USB Port (USB specificaiton version 1.1)
z 24Bit color display adapter
z Windows compatible sound card and speakers (full duplex sound card

recommended)

DSB-C120

D-Link 100K Pixel

USB PC Camera

Check Your Package Contents

These are the items included with your purchase:
If any of the below items are missing, please contact your reseller.

DSB-C120 USB PC CAMERA

CD-ROM(containing Drivers, Application
Software, PDF Installation Guide, PDF
Manual, and Warranty)

Run the Driver CD
before you install

USB 1.1 Cable

©2004 D-Link System, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective
holders. Software and specifications subject to change without notice.

the PC Camera.The Driver
CD contains an
installation program that
simplifies your
installation process.

DSB-C120 Driver Installation

Please bring out the attached CD-ROM and follow the steps listed
below carefully to insure the installation of DSB-C120 will be
complete.

Insert the software CD into
CD-ROM. As you can see
the below picture,D-Link
DSB-C120 startup window
will be displayed.

Click Install DSB-C120

Driver

If the Autorun screen does not automatically start, click on Start >
Run, enter ”D:\Autorun.exe” and click OK. ”D” represents the letter

of your CD-ROM drive. Replace it if your CD-ROM drive is a different
letter.

Windows XP Users

Click Next

2

Windows XP Users (Continued)

Click Finish

Plug the USB cable into camera
and USB port on the PC directly.

3

Windows 2000 Users

Click Next

Click Finish

Plug the USB cable into camera
and USB port on the PC directly.

4

Windows 2000 Users (Continued)

Windows ME & 98 Users

The DSB-C120 driver installation will proceed automatically for Windows
ME & 98SE users.

Click Next

Click Finish

5

Windows ME & 98 Users(Continued)

Plug the USB cable into camera
and USB port on the PC directly.

After the DSB-C120 is

connected to your
computer and all set up
procedures are completed,
you MUST restart the
operating system manually.

6

Driver Installation is Completed!

To confirm the DSB-C120 is properly installed, click “START”

→ ”SETTINGS”→”CONTROL PANEL”. Double-click ”SYSTEM”.
Select the ”HARDWARE” tab and click the ”DEVICE MANAGER”

button. Confirm that ”D-Link DSB-C120” appears in the ”IMAGE
DEVICES” section.

Once properly installed, you are ready to start immediately capturing
images and acreating video with the DSB-C120.

Please refer to the DSB-C120 Manual on the CD included with this
product for information on how to install and use the VP-EYE 4.0
software

7

Attention:

1. Make sure to install the driver and software BEFORE
camera into USB port.

2. We recommend plugging the cable connector to USB port on PC directly
to avoid low voltage.

3. If a dialog box pops up and request to have the language setting file
replaced after plugging the camera into USB port, please simply click
“Yes” to continue.

4. Please download the latest update of “Service Pack

Windows Update

5. If you have more than one image device in your system, please select the
“D-Link DSB-C120” as the PC Camera device. In this way, you can use
this camera to capture images.

) to keep the camera running smoothly.

plugging the

” (from

Start Æ

8
