D-Link DAP-2690 User Manual

Table of Contents
Table of Contents
Product Overview ............................................................... 4
Package Contents ............................................................................4
System Requirements ....................................................................4
Introduction ......................................................................................5
Features and Benets .....................................................................6
Wireless Basics ..................................................................................7
Installation .......................................................................... 9
Installation Considerations ..........................................................9
Four Operational Modes ............................................................ 10
Connect to your Network .......................................................... 11
Conguration .................................................................... 13
Wireless Settings ........................................................................... 15
Access Point Mode ................................................................ 15
WDS with AP Mode .............................................................. 17
WDS Mode ............................................................................... 19
Wireless Client Mode ............................................................ 21
WPA-Personal Authentication .................................... 23
WPA-Enterprise Authentication ................................. 24
802.1X authentication ................................................... 25
LAN ............................................................................................ 26
IPv6 ............................................................................................. 27
Advanced Settings ....................................................................... 28
Performance ............................................................................ 28
Wireless Resource Control ......................................................... 30
Multi-SSID ................................................................................. 32
VLAN Settings ......................................................................... 34
VLAN Port List................................................................... 35
VLAN Add/Edit ................................................................. 36
PVID Setting ...................................................................... 37
Intrusion .................................................................................... 38
Schedule ................................................................................... 39
AP Array ..................................................................................... 44
AP Array Scan ................................................................... 44
Conguration Settings .................................................. 45
Auto-RF ............................................................................... 49
Load Balance .................................................................... 50
Captive Portal .......................................................................... 51
Authentication Settings - Passcode ......................... 51
Authentication Settings - Username/Password ... 52
Authentication Settings - Remote RADIUS ............ 53
Authentication Settings - LDAP ................................. 54
Authentication Settings - POP3 ................................. 55
Login Page Upload ......................................................... 56
Web Redirection .............................................................. 57
MAC Bypass ....................................................................... 58
DHCP Server ............................................................................ 59
Dynamic Pool Settings .................................................. 59
Static Pool Setting .......................................................... 61
Current IP Mapping List ................................................ 62
2D-Link DAP-2690 User Manual
Table of Contents
Filters .......................................................................................... 63
Wireless MAC ACL ........................................................... 63
WLAN Partition ................................................................ 64
Trac Control .......................................................................... 65
Uplink/Downlink Setting ............................................. 65
QoS ....................................................................................... 66
Trac Manager ................................................................ 67
Status ................................................................................................ 68
Device Information ............................................................... 68
Client Information ................................................................. 69
WDS Information ................................................................... 70
Channel Analyze .................................................................... 71
Stats ........................................................................................... 72
Ethernet .............................................................................. 72
Wireless Trac Stats ....................................................... 73
Log .............................................................................................. 74
View Log ............................................................................. 74
Time and Date ......................................................................... 81
Conguration ................................................................................. 82
Save and Activate .................................................................. 82
Discard Changes .................................................................... 82
System .............................................................................................. 83
System Settings ...................................................................... 83
Help ................................................................................................... 84
Troubleshooting ............................................................... 88
Technical Specications ................................................... 91
Log Settings ...................................................................... 75
Maintenance .................................................................................. 76
Administrator Settings ......................................................... 76
Limit Administrator ........................................................ 76
System Name Settings .................................................. 76
Login Settings .................................................................. 77
Console Settings ............................................................. 77
SNMP Settings ................................................................. 78
Ping Control Setting ...................................................... 78
Central WiFiManager Settings .................................... 78
Firmware and SSL Certication Upload ......................... 79
Conguration File .................................................................. 80
3D-Link DAP-2690 User Manual
Section 1 - Product Overview

Product Overview

Package Contents

• DAP-2690 AirPremier N Dual Band PoE Access Point
• Power Adapter
• PoE Base Unit
• CD with manual and warranty
• Ethernet Cable
• Mounting Plate
• Mounting Hardware
• Console Cable
• Install Guide
Warning: Using a power adapter with dierent specications than the one included with the DAP-2690 will cause damage and void the warranty for this product. If any of the above items are missing, please contact your reseller.

System Requirements

Network Requirements
Web-based Conguration
Utility Requirements
• IEEE 802.11n/g wireless clients (AP/bridge modes)
• IEEE 802.11n/g wireless router or access point (client mode)
Computer with the following:
• Windows®, Macintosh, or Linux-based operating system
Browser Requirements:
• Internet Explorer Version 7.0, Chrome 12, Safari 4, or Firefox 12 and above (for web-based conguration)
4D-Link DAP-2690 User Manual
Section 1 - Product Overview

Introduction

D-Link, an industry pioneer in wireless networking, introduces a solution for businesses seeking to deploy next generation draft
802.11n LANs. D-Link unveils its new AirPremier N Dual Band PoE Access Point (DAP-2690), designed specically for business­class environments such as large or enterprise corporations to provide secure and manageable dual band wireless LAN options for network administrators.
Versatile Access Point
The AirPremier N Dual Band PoE Access Point allows network administrators to deploy a highly manageable and extremely robust dual band wireless network. All three dual band antennas are detachable and can provide optimal wireless coverage in either
2.4GHz (802.11g and 802.11n) or 5GHz (802.11a and 802.11n) bands. Enclosed in a plenum-rated metal chassis, the AirPremier N Dual Band PoE Access Point adheres to strict re codes for placement in air passageways. For advanced installations, this new high-speed Access Point has integrated 802.3af Power over Ethernet (PoE) support, allowing installation of this device in areas where power outlets are not readily available.
Enhanced Performance
The AirPremier N Dual Band PoE Access Point delivers reliable wireless performance with maximum wireless signal rates of up to 300Mbps in either the 2.4GHz or 5GHz wireless band. This, coupled with support for Wi-Fi Multimedia™ (WMM) Quality of Service features, makes it an ideal access point for audio, video, and voice applications. Additionally, the DAP-2690 supports load balance features to ensure maximum performance.
Security
To help maintain a secure wireless network, the AirPremier N Dual Band PoE Access Point provides the latest in wireless security technologies by supporting both Personal and Enterprise versions of WPA and WPA2 (802.11i) with support for RADIUS server backend. To further protect your wireless network, MAC Address Filtering, Wireless LAN segmentation, Disable SSID Broadcast, Rogue AP Detection, and Wireless Broadcast Scheduling are also included.
The AirPremier N Dual Band PoE Access Point includes support for up to 16 VLANs for implementing multiple SSIDs to further help segment users on the network. The DAP-2690 also includes a wireless client isolation mechanism, which limits direct client­to-client communication.
5D-Link DAP-2690 User Manual
Section 1 - Product Overview
Features and Benets
• Four dierent operation modes - Capable of operating in one of four dierent operation modes to meet your wireless networking needs: Access Point, WDS with AP, WDS, or Wireless Client.
• Faster wireless networking with the 802.11n standard to provide a maximum wireless signal rate of up to 300 Mbps*.
• Compatible with the 802.11b standard to provide a wireless data rate of up to 11 Mbps, allowing you to migrate your system to the 802.11n and 802.11g standards on your own schedule without sacricing connectivity.
• Compatible with the 802.11g standard to provide a wireless data rate of up to 54 Mbps in the 2.4 GHz frequency range.
• Compatible with the 802.11a standard to provide a wireless data rate of up to 54 Mbps in the 5 GHz frequency range.
• Better security with WPA - The DAP-2690 can securely connect wireless clients on the network using WPA (Wi-Fi Protected Access) to provide a much higher level of security for your data and communications than its previous versions.
• Central WiFiManager management software - The real-time display of the network's topology and AP’s information makes network conguration and management quick and simple.
• SNMP for management - The DAP-2690 is not just fast, but also supports SNMP v.3 for better network management. Superior wireless AP manager software is bundled with the DAP-2690 for network conguration and rmware upgrade. Systems administrators can also set up the DAP-2690 easily with the Web-based conguration.
• Utilizes OFDM technology (Orthogonal Frequency Division Multiplexing).
• Supports 802.3af Power over Ethernet.
• Includes one 10/100/1000 Ethernet port.
• Operates in the 2.4~2.5 GHz or 5.15~5.85 GHz** frequency ranges.
• Web-based interface for managing and conguring.
*Maximum wireless signal rate derived from IEEE Standard 802.11g, 802.11a and 802.11n specications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely aect wireless signal range.
**Please note that operating frequency ranges vary depending on the regulations of individual countries and jurisdictions. The DAP-2690 isn’t supported in the 5.25~5.35 GHz and 5.47 ~ 5.725 GHz frequency ranges in some regions.
6D-Link DAP-2690 User Manual
Section 1 - Product Overview

Wireless Basics

D-Link wireless products are based on industry standards to provide high-speed wireless connectivity that is easy to use within your home, business or public access wireless networks. D-Link wireless products provides you with access to the data you want, whenever and wherever you want it. Enjoy the freedom that wireless networking can bring to you.
WLAN use is not only increasing in both home and oce environments, but in public areas as well, such as airports, coee shops and universities. Innovative ways to utilize WLAN technology are allowing people to work and communicate more eciently. Increased mobility and the absence of cabling and other types of xed infrastructure have proven to be benecial to many users.
Wireless adapter cards used on laptop and desktop systems support the same protocols as Ethernet adapter cards, allowing wireless users to use the same applications as those used on a wired network.
People use WLAN technology for many dierent purposes:
Mobility - Productivity increases when people can have access to data in any location within the operating range of their WLAN. Management
decisions based on real-time information can signicantly improve the eciency of a worker.
Low implementation costs - WLANs are easy to set up, manage, change and relocate. Networks that frequently change can benet from WLAN's
ease of implementation. WLANs can operate in locations where installation of wiring may be impractical.
Installation and network expansion - By avoiding the complications of troublesome cables, a WLAN system can be fast and easy during installation,
especially since it can eliminate the need to pull cable through walls and ceilings. Wireless technology provides more versatility by extending the network beyond the home or oce.
Inexpensive solution - Wireless network devices are as competitively priced as conventional Ethernet network devices. The DAP-2690 saves money
by providing users with multi-functionality congurable in four dierent modes.
Scalability - Congurations can be easily changed and range from Peer-to-Peer networks, suitable for a small number of users to larger Infrastructure
networks to accommodate hundreds or thousands of users, depending on the number of wireless devices deployed.
7D-Link DAP-2690 User Manual
Section 1 - Product Overview
Standards-Based Technology
The DAP-2690 Wireless Access Point utilizes the 802.11a, 802.11b, 802.11g, and 802.11n standards.
The IEEE 802.11n standard is an extension of the 802.11a, 802.11b, and 802.1g standards that came before it. It increases the maximum wireless signal rate up to 300 Mbps* within both the 2.4 GHz and the 5 GHz bands, utilizing OFDM technology.
This means that in most environments - within the specied range of this device - you will be able to transfer large les quickly, or even watch a movie in MPEG format over your network without noticeable delays. This technology works by transmitting high-speed digital data over a radio wave utilizing OFDM (Orthogonal Frequency Division Multiplexing) technology. OFDM works by splitting the radio signal into multiple smaller sub-signals that are then simultaneously transmitted at dierent frequencies to the receiver. OFDM reduces the amount of crosstalk (interference) in signal transmissions.
The D-Link DAP-2690 will automatically sense the best possible connection speed to ensure the greatest possible speed and range.
Note: 802.11n oers the most advanced network security features available today, including WPA.
*Maximum wireless signal rate derived from IEEE Standard 802.11g, 802.11a and 802.11n specications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely aect wireless signal range.
8D-Link DAP-2690 User Manual
Section 2 - Installation

Installation

Installation Considerations

The D-Link wireless device lets you access your network using a wireless connection from virtually anywhere within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines:
1. Keep the number of walls and ceilings between the D-Link device and other network devices to a minimum - each wall or ceiling
can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.
2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a 45-degree angle appears to be
almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters) thick! Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.
3. Building Materials make a dierence. A solid metal door or aluminum studs may have a negative eect on range. Try to position
access points, wireless routers, and computers so that the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and concrete will degrade your wireless signal.
4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF noise.
5. If you are using 2.4GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security systems), your
wireless connection may degrade dramatically or drop completely. Make sure your 2.4GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone in not in use.
9D-Link DAP-2690 User Manual
Section 2 - Installation

Four Operational Modes

Access Point (AP)
WDS with AP
WDS
Wireless Client
Create a wireless LAN
Wirelessly connect multiple networks while still functioning as a wireless AP
Wirelessly connect multiple networks
AP acts as a wireless network adapter for your Ethernet enabled device
10D-Link DAP-2690 User Manual
Section 2 - Installation

Connect to your Network

To power the access point, you can use one of the following 3 methods:
Method 1 - Use if you have a PoE switch. Method 2 - Use if you do not have a PoE switch and do not have a power outlet near the location of the access point. Method 3 - Use if you do not have a PoE switch and have a power outlet near the location of the access point.
Method 1
1. Connect one end of your Ethernet cable into the LAN (PoE) port on the DAP-2690 and then connect the other end to your PoE switch.
11D-Link DAP-2690 User Manual
Section 2 - Installation
Method 2
1. Connect one end of an Ethernet cable into the Data In port on the PoE base unit and the other end into one port on your switch, router, or computer.
2. Connect one end of an Ethernet cable into the P+Data Out port on the PoE base unit and the other end into the LAN (PoE) port on the DAP-2690 access point.
3. Use the supplied power adapter. Connect the power adapter to the Power In receptor on the PoE adapter.
4. Connect the power cable to the power adapter and then connect the other end into a power outlet.
Method 3
1. Connect one end of your Ethernet cable into the LAN (PoE) port on the DAP-2690 and then connect the other end to a switch, router, or computer.
2. Use the supplied power adapter. Connect the power adapter to the Power receptor on the DAP-2690 access point.
3. Connect the power cable to the power adapter and then connect the other end into a power outlet.
12D-Link DAP-2690 User Manual
Section 3 - Conguration
Conguration
To congure the DAP-2690, use a computer that is connected to the DAP-2690 with an Ethernet cable.
Step 1 - Disable the Access the Internet using a proxy server function. To disable this function, go to Control Panel > Internet Options > Connections > LAN Settings and uncheck the enable box.
Step 2 - Open your web browser.
Step 3 - Type the IP address of the DAP-2690 in the address eld (http://192.168.0.50) and press Enter. Make sure that the IP addresses of the
DAP-2690 and your computer are in the same subnet.
Note: If you have changed the default IP address assigned to the DAP-2690, make sure to enter the correct IP address.
Step 4 - Enter admin for the User Name and then click Login. By default the password is blank.
Note: If you have changed the password, make sure to enter the correct password.
13D-Link DAP-2690 User Manual
Section 3 - Conguration
After successfully logging into the DAP-2690 the following window will appear:
When making changes on most of the conguration windows in this section, use either the Apply button or the Save button to save your conguration changes.
Click the Apply button to congure changes.
Click the Save button to congure changes.
Alternatively, click the Save and Activate option on the Conguration drop-down menu at the top of each DAP-2690 window. This will cause the DAP-2690 to save and reboot.
14D-Link DAP-2690 User Manual
Section 3 - Conguration

Wireless Settings

Access Point Mode

In Access Point mode, the DAP-2690 functions as a wireless AP. After conguring the desired settings, click the Save button.
Wireless Band:
Mode:
Network Name
(SSID):
SSID Visibility:
Auto Channel
Selection:
Channel:
Select either 2.4 GHz or 5 GHz from the drop-down menu.
Select Access Point from the drop-down menu. The other three choices are WDS with AP, WDS, and Wireless Client.
Service Set Identier (SSID) is the name designated for a specic wireless local area network (WLAN). The SSID’s default setting is dlink. The SSID can easily be changed to connect to an existing wireless network or to establish a new wireless network. The SSID can be up to 32 characters and is case-sensitive.
Enable or Disable SSID visibility. Enabling this feature broadcasts the SSID across the network, thus making it visible to all network users.
Enabling this feature automatically selects the channel that provides the best wireless performance. Enable is set by default. The channel selection process only occurs when the AP is booting up.
All devices on the network must share the same channel. To change the channel, rst toggle the Auto Channel Selection setting to Disable, and then use the drop-down menu to make the desired selection.
Note: The wireless adapters will automatically scan and match the wireless settings.)
Channel Width:
Captive Prole:
Allows selection of the channel width you would like to operate in. 20 MHz and Auto 20/40 MHz allow both 802.11n and non-802.11n wireless
devices on your network when the wireless mode is Mixed 802.11 b/g/n in 2.4G and Mixed 802.11 a/n in 5G. When the channel width is set to Auto 20/40 MHz, then 802.11n wireless devices are allowed to transmit data using 40 MHz.
Enable or disable captive prole for user authentication.
15D-Link DAP-2690 User Manual
Section 3 - Conguration
Authentication:
Select Open System to communicate the key across the network. Select Shared Key to limit communication to only those devices that share the same WEP settings. If multi-SSID is enabled,
this option is not available. Select WPA-Personal to secure your network using a password and dynamic key changes. No RADIUS server is required. Select WPA-Enterprise to secure your network with the inclusion of a RADIUS server. Select 802.1X if your network is using port-based Network Access Control.
For more information about the dierent types of Authentication oered on the DAP-2690 and the respective settings of each, please go to the rst page of the “Authentication” explanations, which begins on page 23.
16D-Link DAP-2690 User Manual
Section 3 - Conguration

WDS with AP Mode

In WDS with AP mode, the DAP-2690 wirelessly connects multiple networks while still functioning as a wireless AP. After completing the desired settings, click the Save button to let your changes take eect.
Wireless Band:
Mode:
Network Name
(SSID):
SSID Visibility:
Auto Channel
Selection:
Channel:
Select either 2.4 GHz or 5 GHz from the drop-down menu.
Select WDS with AP mode from the drop-down menu.
Service Set Identier (SSID) is the name designated for a specic wireless local area network (WLAN). The SSID’s factory default setting is dlink. The SSID can easily be changed to connect to an existing wireless network or to establish a new wireless network. The SSID can be up to 32 characters and is case-sensitive.
Enable or Disable SSID visibility. Enabling this feature broadcasts the SSID across the network, thus making it visible to all network users.
Enabling this feature automatically selects the channel that provides the best wireless performance. Enable is set by default. The channel selection process only occurs when the AP is booting up.
All devices on the network must share the same channel. To change the channel, rst toggle the Auto Channel Selection setting to Disable, and then use the drop-down menu to make the desired selection. Note: The wireless adapters will
automatically scan and match the wireless settings.
Channel Width:
Captive Prole:
Allows selection of the channel width you would like to operate in. 20 MHz and Auto 20/40 MHz allow both
802.11n and non-802.11n wireless devices on your network when the wireless mode is Mixed 802.11 b/g/n in 2.4G and Mixed 802.11 a/n in 5G. When the channel width is set to Auto 20/40 MHz, then 802.11n wireless devices are allowed to transmit data using 40 MHz.
Enable or disable captive prole for user authentication.
17D-Link DAP-2690 User Manual
Section 3 - Conguration
Remote AP MAC
Address:
Site Survey:
Authentication:
Allows selection of the channel width you would like to operate in. 20 MHz and Auto 20/40 MHz allow both 802.11n and non-802.11n wireless devices on your network when the wireless mode is Mixed 802.11 b/g/n in 2.4G and Mixed 802.11 a/n in 5G. 802.11n wireless devices are allowed to transmit data using 40 MHz when the channel width is Auto 20/40 MHz.
Manually enter the MAC addresses of the APs on your network that will serve as bridges to wirelessly connect multiple networks. You may also click the Scan button to search for available wireless networks, then click on the available network that you want to connect to.
Use the drop-down menu to choose Open System, Shared Key, or WPA-Personal. Select Open System to communicate the key across the network. Select Shared Key to limit communication to only those devices that share the same WEP settings. If multi-SSID is enabled, this option
is not available. Select WPA-Personal to secure your network using a password and dynamic key changes. No RADIUS server is required.
For more information about the dierent types of Authentication oered on the DAP-2690 and the respective settings of each, please go to the rst page of the “Authentication” explanations, which begins on page 23.
18D-Link DAP-2690 User Manual
Section 3 - Conguration

WDS Mode

In WDS mode, the DAP-2690 wirelessly connects multiple networks, without functioning as a wireless AP. After completing the desired settings, click the Save button to let your changes take eect.
Wireless Band:
Mode:
Network Name
(SSID):
SSID Visibility:
Auto Channel
Selection:
Channel:
Select either 2.4 GHz or 5 GHz from the drop-down menu.
WDS is selected from the drop-down menu.
Service Set Identier (SSID) is the name designated for a specic wireless local area network (WLAN). The SSID’s factory default setting is dlink. The SSID can be easily changed to connect to an existing wireless network or to establish a new wireless network.
Enable or Disable SSID visibility. Enabling this feature broadcasts the SSID across the network, thus making it visible to all network users.
Enabling this feature automatically selects the channel that will provide the best wireless performance. This feature is not supported in WDS mode.
All devices on the network must share the same channel. To change the channel, use the drop-down menu to make the desired selection.
Channel Width:
Captive Prole:
Allows selection of the channel width you would like to operate in. 20 MHz and Auto 20/40 MHz allow both
802.11n and non-802.11n wireless devices on your network when the wireless mode is Mixed 802.11 b/g/n in 2.4G and Mixed 802.11 a/n in 5G. 802.11n wireless devices are allowed to transmit data using 40 MHz when the channel width is Auto 20/40 MHz.
Disable in WDS mode.
19D-Link DAP-2690 User Manual
Section 3 - Conguration
Remote AP MAC
Address:
Site Survey:
Authentication:
Enter the MAC addresses of the APs on your network that will serve as bridges to wirelessly connect multiple networks.
Click the Scan button to search for available wireless networks, then click on the available network that you want to connect with.
Use the drop-down menu to choose Open System, Shared Key, or WPA-Personal.
Select Open System to communicate the key across the network. Select Shared Key to limit communication to only those devices that share the same WEP settings. Select WPA-Personal to secure your network using a password and dynamic key changes. No RADIUS server is required.
20D-Link DAP-2690 User Manual
Section 3 - Conguration

Wireless Client Mode

In Wireless Client mode, the DAP-2690 functions as a wireless client on a wireless network in which an AP already exists. After completing the desired settings, click the Save button to let your changes take eect.
Wireless Band:
Mode:
Network Name
(SSID):
SSID Visibility:
Auto Channel
Selection:
Channel:
Channel Width:
Captive Prole:
Select either 2.4 GHz or 5 GHz from the drop-down menu.
Wireless Client is selected from the drop-down menu.
Service Set Identier (SSID) is the name designated for a specic wireless local area network (WLAN). The SSID’s factory default setting is dlink. The SSID can be easily changed to connect to an existing wireless network.
This option is unavailable in wireless client mode.
Enabling this feature automatically selects the channel that will provide the best wireless performance. This feature is not supported in Wireless Client mode.
The channel used will be displayed, and follow the root AP.
This option is unavailable in wireless client mode.
Disable in Wireless Client mode.
Site Survey:
Click the Scan button to search for available wireless networks, then click on the available network that you want to connect with.
21D-Link DAP-2690 User Manual
Section 3 - Conguration
Authentication: Use the drop-down menu to choose Open System or WPA Personal.
Select Open System to communicate the key across the network. Select WPA-Personal to secure your network using a password and dynamic key changes. No RADIUS server is required.
For more information about the dierent types of Authentication oered on the DAP-2690 and the respective settings of each, please go to the rst page of the Authentication explanations which begins on page 23.
Wireless MAC Clone
Enable:
MAC Source:
MAC Address:
Click the box to enable the Wireless MAC Clone feature. Enabling this option allows the user to manually assign the source MAC address to packets forwarded by the DAP-2690. If disabled, the packet’s source MAC address eld will be automatically selected as the DAP-2690’s MAC address.
Use the drop-down menu to select either Auto or Manual.
If you selected Manual for the MAC Source above, you can either click the Scan button to search for all available devices connected to your DAP-2690’s Ethernet port or manually enter a MAC address in the space provided.
22D-Link DAP-2690 User Manual
Section 3 - Conguration
WPA-Personal Authentication
WPA Mode:
Cipher Type:
Group Key
Update Interval:
PassPhrase:
Conrm
PassPhrase:
When WPA-Personal is selected for Authentication type, you must also select a WPA mode from the drop-down menu: AUTO (WPA or WPA2),
WPA2 Only, or WPA Only. WPA and WPA2 use dierent algorithms. AUTO (WPA or WPA2) allows you to use both WPA and WPA2.
When you select WPA-Personal, you must also select AUTO, AES, or TKIP from the drop-down menu.
Select the interval during which the group key will be valid. The default value of 1800 is recommended.
When you select WPA-Personal, please enter a PassPhrase in the corresponding eld.
Retype the Passphrase entered above in the corresponding eld.
23D-Link DAP-2690 User Manual
Section 3 - Conguration
WPA-Enterprise Authentication
WPA Mode:
Cipher Type:
Group Key Update
Interval:
Network Access
Protection:
RADIUS Server:
RADIUS Port:
When WPA-Enterprise is selected, you must also select a WPA mode from the drop-down menu: AUTO (WPA or WPA2), WPA2 Only, or WPA Only. WPA and WPA2 use dierent algorithms. AUTO (WPA or WPA2) allows you to use both WPA and WPA2.
When WPA-Enterprise is selected, you must also select a cipher type from the drop-down menu: Auto, AES, or TKIP.
Select the interval during which the group key will be valid. The recommended value is 1800, as a lower interval may reduce data transfer rates.
Enable or disable Microsoft Network Access Protection. Enabling this will make the DAP-2690 a NAP enforcement point if you are running the Network Policy Server (NPS) service in Windows Server 2008.
Enter the IP address of the RADIUS server. Click External if the RADIUS server is on your network or Internal if you are using the RADIUS server on the DAP-2690.
Enter the RADIUS port (1812 is the default).
RADIUS Secret:
Accounting Mode:
Accounting Server:
Accounting Port:
Accounting Secret:
Note: You can input the secondary RADIUS server and accounting server settings if you have a backup RADIUS and accounting server.
Enter the RADIUS secret.
Select if you want to use a dierent server for accounting.
Enter the IP address of the Accounting server.
Enter the Accounting port (1813 is the default).
Enter the Accounting secret.
24D-Link DAP-2690 User Manual
Section 3 - Conguration
802.1X authentication
Key Update Interval:
RADIUS Server:
RADIUS Port:
RADIUS Secret:
Accounting Mode:
Accounting Server:
Accounting Port:
Accounting Secret:
Select the interval (in seconds) during which the key will be valid.
Enter the IP address of the RADIUS server. Click External if the RADIUS server is on your network or Internal if you are using the RADIUS server on the DAP-2690.
Enter the RADIUS port (1812 is the default).
Enter the RADIUS secret.
Select if you want to use a dierent server for accounting.
Enter the IP address of the Accounting server.
Enter the Accounting port (1813 is the default).
Enter the Accounting secret.
Note: You can input the secondary RADIUS server and accounting server settings if you have a backup RADIUS and accounting server.
25D-Link DAP-2690 User Manual
Section 3 - Conguration
LAN
LAN is short for Local Area Network. This is considered your internal network. These are the IP settings of the LAN interface for the DAP-2690. These settings may be referred to as private settings. You may change the LAN IP address if needed. The LAN IP address is private to your internal network and cannot be seen on the Internet. After completing the desired LAN settings, click the Save button to let your changes take eect.
Get IP From:
IP Address:
Subnet Mask:
Default
Gateway:
DNS:
Select Static IP (Manual) if you do not have a DHCP server on your network, or if you wish to assign a static IP address to the DAP-2690. When Dynamic IP (DHCP) is selected, the other elds here will be grayed out. Please allow about 2 minutes for the DHCP client to be functional once this selection is made.
The default IP address is 192.168.0.50. Assign a static IP address that is within the IP address range of your network.
Enter the subnet mask. All devices in the network must share the same subnet mask.
Enter the IP address of the gateway in your network. If there is a router/gateway in your network, please enter its IP address.
Enter a DNS server IP address of your choice. In most cases, enter the LAN IP of your router.
26D-Link DAP-2690 User Manual
Section 3 - Conguration
The IPv6 function allows you access DAP-2690 using an IPv6 address.

IPv6

Enable IPv6:
Get IP From:
IP Address:
Prex:
Dafault
Gateway:
Note: If IPv6 is enabled, AP Array, QoS, and Trac Manager will all be disabled. Also, AP Client mode will change to AP mode.
Check this box to enable IPv6.
Select either Static to enter your own IP address or Auto to be automatically assigned by a DHCP server or IPv6 gateway.
Assign an IPv6 IP address.
The Prex is used to determine what subnet an IP address belongs to. It must be 0~128..
Enter the default gateway address. This is usually the IP address of your router.
27D-Link DAP-2690 User Manual
Section 3 - Conguration

Advanced Settings

Performance

The Performance Settings window oers a number of user-controlled settings designed to optimize the performance of the DAP-2690. After completing the desired settings, click the Save button to let your changes take eect.
Wireless Band:
Wireless:
Wireless Mode:
Data Rate:
Select either 2.4GHz or 5GHz.
Use the drop-down menu to turn the wireless function On or O.
The dierent combination of clients that can be supported include Mixed 802.11n, 802.11g and 802.11b, Mixed
802.11g and 802.11b, and 802.11n Only in the 2.4 GHz band and Mixed 802.11n and 802.11a, 802.11a only, and 802.11n Only in the 5 GHz band. Please note that when backwards compatibility is enabled for legacy (802.11a/g/b) clients, degradation of 802.11n wireless performance is expected.
Indicate the base transfer rate of wireless adapters on the wireless LAN. The AP will adjust the base transfer rate depending on the base rate of the connected device. If there are obstacles or interference, the AP will step down the rate. This option is enabled in Mixed 802.11g and 802.11b mode (for 2.4 GHz) and 802.11a only mode (for 5 GHz). The choices available are Best (Up to 54), 54, 48, 36, 24, 18, 12, 9, and 6 for 5 GHz and Best (Up to 54), 54, 48, 36, 24, 18, 12, 9, 6, 11,
5.5, 2 and 1 for 2.4 GHz.
Beacon Interval
(40-500):
*Maximum wireless signal rate derived from IEEE Standard 802.11g, 802.11a and 802.11n specications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely aect wireless signal range.
Beacons are packets sent by an access point to synchronize a wireless network. Specify a value in milliseconds. The default (100) is recommended. Setting a higher beacon interval can help to save the power of wireless clients, while setting a lower one can help a wireless client connect to an access point faster.
28D-Link DAP-2690 User Manual
Section 3 - Conguration
DTIM Interval (1-15):
Transmit Power:
WMM (Wi-Fi
Multimedia):
Ack Time Out (2.4
GHZ) or Ack Time Out
(5 GHZ):
Short GI:
IGMP Snooping:
Select a Delivery Trac Indication Message setting between 1 and 15. 1 is the default setting. DTIM is a countdown informing clients of the next window for listening to broadcast and multicast messages.
This setting determines the power level of the wireless transmission. Transmitting power can be adjusted to eliminate overlapping of wireless area coverage between two access points where interference is a major concern. For example, if wireless coverage is intended for half of the area, then select 50% as the option. Use the drop-down menu to select 100%, 50%, 25%, or 12.5%.
WMM stands for Wi-Fi Multimedia. Enabling this feature will improve the user experience for audio and video applications over a Wi-Fi network.
To eectively optimize throughput over long distance links enter a value for Acknowledgement Time Out between 25 and 200 microseconds for 5 GHz or from 48 to 200 microseconds in the 2.4 GHz in the eld provided.
Select Enable or Disable. Enabling a short guard interval can increase throughput. However, be aware that it can also increase the error rate in some installations due to increased sensitivity to radio-frequency installations.
Select Enable or Disable. Internet Group Management Protocol allows the AP to recognize IGMP queries and reports sent between routers and an IGMP host (wireless STA). When IGMP snooping is enabled, the AP will forward multicast packets to an IGMP host based on IGMP messages passing through the AP.
Multicast Rate:
Multicast Bandwidth
Control :
Maximum Multicast
Bandwidth :
HT20/40 Coexistence :
Transfer DHCP Oer to
Unicast :
Adjust the multicast packet data rate here. The multicast rate is supported in AP mode, (2.4 GHZ and 5 GHZ) and WDS with AP mode, including Multi-SSIDs.
Adjust the multicast packet data rate here. The multicast rate is supported in AP mode, and WDS with AP mode, including Multi­SSIDs
Set the multicast packets maximum bandwidth pass through rate from the Ethernet interface to the Access Point.
Enable this option to reduce interference from other wireless networks in your area. If the channel width is operating at 40MHz and there is another wireless network’s channel over-lapping and causing interference, the Access Point will automatically change to 20MHz.
Enable to transfer the DHCP Oer to Unicast from LAN to WLAN, suggest to enable this function if stations number is larger than 30.
29D-Link DAP-2690 User Manual
Loading...
+ 66 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
