D-Link dap-2310 User Manual

Download

Table of Contents

Product Overview ........................................................4

Package Contents....................................................4

System Requirements .............................................4

Introduction ..............................................................5

Features ...................................................................7

Wireless Basics ...........................................................8

Standards-Based Technology ..................................9

Wireless Installation Considerations ......................10

Hardware Overview ...............................................11

LEDs ................................................................ 11

Hardware Overview ...............................................12

Connections ..................................................... 12

Four Operational Modes ........................................... 13

Getting Started .......................................................... 14

Conﬁguration .............................................................15

Save and Activate Settings .................................... 16

Basic Settings ........................................................17

Wireless .......................................................... 17

Access Point mode ....................................... 17

WDS with AP mode ..................................... 19

WDS mode ................................................... 21

Wireless Client mode ................................... 23

Open System/Shared Key Authentication ... 25

WPA/WPA2-Personal Authentication ............ 26

WPA/WPA2-Enterprise Authentication ......... 27

802.1x Authentication ................................... 28

LAN ................................................................. 29

Advanced Settings .................................................30

Performance ....................................................30

Multi-SSID ........................................................32

VLAN ...............................................................34

VLAN List ..................................................... 34

Port List ........................................................ 35

Add/Edit VLAN .............................................36

PVID Setting ................................................. 37

Intrusion ........................................................... 38

Schedule .......................................................... 39

QoS .................................................................. 40

AP Array ...........................................................42

Wireless Basic Settings ................................ 43

Wireless Advanced Settings .........................43

Multiple SSID & VLAN .................................. 44

Advanced Functions ..................................... 44

Administration Settings ................................44

ARP Spooﬁng Prevention ................................ 45

DHCP Server .................................................. 46

Dynamic Pool Settings ................................. 46

Static Pool Setting ........................................ 48

Current IP Mapping List ...............................50

Filters ............................................................... 51

2D-Link DAP-2310 User Manual

Table of Contents

Wireless MAC ACL ....................................... 51

WLAN Partition ............................................. 52

Status ....................................................................53

Device Information ........................................... 53

Client Information .............................................54

WDS Information..............................................55

Stats ................................................................. 56

Ethernet ........................................................ 56

WLAN Trafﬁc ................................................57

Log ................................................................... 58

View Log.......................................................58

Log Settings ................................................. 59

Maintenance ......................................................... 60

Administration Settings .................................... 60

Limit Administrator .......................................61

System Name Settings ................................. 62

System Settings ........................................... 69

Help ....................................................................... 70

Troubleshooting ......................................................... 71

Networking Basics ....................................................71

Check your IP address ..........................................71

Statically Assign an IP address .............................73

Technical Speciﬁcations ...........................................76

Contacting Technical Support ..................................78

Warranty .....................................................................79

Registration ................................................................ 85

Console Settings .......................................... 64

SNMP Settings ............................................. 65

Firmware and SSL Certiﬁcation Upload ................66

Conﬁguration File Upload ......................................67

Time and Date ....................................................... 68

System ............................................................. 69

3D-Link DAP-2310 User Manual

Section 1 - Product Overview

D-Link DAP-2310 AirPremier® N Access Point

Power Adapter

CAT5 Ethernet Cable

CD-ROM with User Manual

Install Guide

Product Overview

Package Contents

Note: Using a power supply with a dierent voltage rating than the one included with the DAP-2310 will cause damage and

void the warranty for this product.

System Requirements

• Computers with Windows®, Macintosh®, or Linux-based operating systems with an installed Ethernet Adapter

• For conguration, the following web browsers are supported:

• Microsoft® Internet Explorer® 6.0 and higher

• Mozilla Firefox 3.0 and higher

• Google™ Chrome 2.0 and higher

• Apple Safari 3.0 and higher

4D-Link DAP-2310 User Manual

Section 1 - Product Overview

Introduction

The DAP-2310 802.11n AP increases productivity by allowing you to work faster and more eciently. With the DAP-2310, bandwidth-intensive applications like graphics or multimedia will benet signicantly because large les are now able to move across the network quickly.

The DAP-2310 is capable of operating in one of four dierent wireless networking modes: Access Point, WDS (Wireless Distribution System) with AP, WDS, or Wireless Client mode.

An ideal solution for quickly creating and extending a wireless local area network (WLAN) in oces or other workplaces, trade shows, and special events, the DAP-2310 provides data transfer rates up to 300Mbps. (The 802.11n standard is backwards compatible with 802.11g and 802.11b devices.)

WPA/WPA2 is oered in two options: Enterprise (used for corporations) and Personal (used for home users). WPA-Personal and WPA2-Personal are directed towards home users who do not have the server-based equipment required for user authentication. This method of authentication is similar to WEP because you dene a “Pre-Shared Key” on the wireless router/AP. Once the pre-shared key is conrmed and satised at both the client and access point, access is then granted. The encryption method used is referred to as the Temporal Key Integrity Protocol (TKIP), which oers per-packet dynamic hashing. It also includes an integrity checking feature which ensures that the packets were not tampered with during wireless transmission.

WPA-Enterprise and WPA2-Enterprise are ideal for businesses that already have existing security infrastructures established. Management and security implementation can now be centralized on a server participating on the network. Utilizing 802.1X with a RADIUS (Remote Authentication Dial-in User Service) server, a network administrator can dene a list of authorized users who can access the wireless LAN. When attempting to access a wireless LAN with WPA-Enterprise congured, the new client will be requested to enter a username with a password. If the new client is authorized by the administration, and enters the correct username and password, then access is granted. In the case where an employee leaves the company, the network administrator is able to remove the previous employee from the authorized list to avoid compromising the network.

5D-Link DAP-2310 User Manual

Section 1 - Product Overview

EAP (Extensible Authentication Protocol) is available through the Windows® XP operating system. You will need to use the same type of EAP protocol on all devices in your network when using the 802.1X feature.

*Maximum wireless signal rate derived from IEEE Standard 802.11n and 802.11g specications. Actual data throughput may vary. Network conditions and environmental factors, including volume of network trac, building materials and construction, and network overhead can lower actual data throughout rate.

6D-Link DAP-2310 User Manual

Section 1 - Product Overview

Features

• Four dierent operation modes - Capable of operating in one of four dierent operation modes to meet your wireless

networking needs: Access Point, WDS with AP, WDS, or Wireless Client.

• Faster wireless networking with the 802.11n standard to provide a maximum wireless signal rate of up to 300 Mbps*.

• Compatible with the 802.11b standard to provide a wireless data rate of up to 11Mbps, allowing you to migrate your

system to the 802.11n and 802.11g standards on your own schedule without sacricing connectivity.

• Compatible with the 802.11g standard to provide a wireless data rate of up to 54Mbps in the 2.4GHz frequency range.

• Better security with WPA - The DAP-2310 can securely connect wireless clients on the network using WPA (Wi-Fi Protected

Access) to provide a much higher level of security for your data and communications than its previous versions.

• AP Manager II management software - The real-time display of the network's topology and AP’s information makes

network conguration and management quick and simple.

• SNMP for management - The DAP-2310 is not just fast, but also supports SNMP v.3 for better network management.

Superior wireless AP manager software is bundled with the DAP-2310 for network conguration and rmware upgrade. Systems administrators can also set up the DAP-2310 easily with the Web-based conguration. A D-Link D-View 6.0 module will be downloadable for network administration and real-time network trac monitoring with D-Link D-View

6.0 software.

• Utilizes OFDM technology (Orthogonal Frequency Division Multiplexing).

• Supports one 10/100/1000M Ethernet port.

• Operates in the 2.4 ~ 2.4835GHz frequency ranges.

• Web-based interface for managing and conguring.

7D-Link DAP-2310 User Manual

Section 2 - Installation

Wireless Basics

D-Link wireless products are based on industry standards to provide high-speed wireless connectivity that is easy to use within your home, business or public access wireless networks. D-Link wireless products provides you with access to the data you want, whenever and wherever you want it. Enjoy the freedom that wireless networking can bring to you.

WLAN use is not only increasing in both home and oce environments, but in public areas as well, such as airports, coee shops and universities. Innovative ways to utilize WLAN technology are allowing people to work and communicate more eciently. Increased mobility and the absence of cabling and other types of xed infrastructure have proven to be benecial to many users.

Wireless adapter cards used on laptop and desktop systems support the same protocols as Ethernet adapter cards, allowing wireless users to use the same applications as those used on a wired network.

People use WLAN technology for many dierent purposes:

Mobility - productivity increases when people can have access to data in any location within the operating range of

their WLAN. Management decisions based on real-time information can signicantly improve the eciency of a worker.

Low implementation costs - WLANs are easy to set up, manage, change and relocate. Networks that frequently change

can benet from WLAN's ease of implementation. WLANs can operate in locations where installation of wiring may be impractical.

Installation and network expansion - by avoiding the complications of troublesome cables, a WLAN system can be fast

and easy during installation, especially since it can eliminate the need to pull cable through walls and ceilings. Wireless technology provides more versatility by extending the network beyond the home or oce.

Inexpensive solution - wireless network devices are as competitively priced as conventional Ethernet network devices.

The DAP-2310 saves money by providing users with multi-functionality congurable in four dierent modes.

Scalability - Congurations can be easily changed and range from Peer-to-Peer networks, suitable for a small number

of users to larger Infrastructure networks to accommodate hundreds or thousands of users, depending on the number of wireless devices deployed.

8D-Link DAP-2310 User Manual

Section 2 - Installation

Standards-Based Technology

The DAP-2310 Wireless Access Point utilizes the 802.11b, 802.11g, and 802.11n standards.

The IEEE 802.11n standard is an extension of the 802.11b and 802.11g standards that came before it. It increases the maximum wireless signal rate up to 300Mbps* within the 2.4GHz bands, utilizing OFDM technology.

This means that in most environments - within the specied range of this device - you will be able to transfer large les quickly, or even watch a movie in MPEG format over your network without noticeable delays. This technology works by transmitting high-speed digital data over a radio wave utilizing OFDM (Orthogonal Frequency Division Multiplexing) technology. OFDM works by splitting the radio signal into multiple smaller sub-signals that are then simultaneously transmitted at dierent frequencies to the receiver. OFDM reduces the amount of crosstalk (interference) in signal transmissions.

The D-Link DAP-2310 will automatically sense the best possible connection speed to ensure the greatest possible speed and range.

IEEE 802.11n oers the most advanced network security features available today, including WPA.

9D-Link DAP-2310 User Manual

Section 2 - Installation

Wireless Installation Considerations

The D-Link AirPremier® N wireless access point lets you access your network using a wireless connection from virtually anywhere within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines:

1. Keep the number of walls and ceilings between the access point and other network devices to a minimum. Each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters). Position your devices so that the number of walls or ceilings is minimized.

2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a 45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle, it looks over 42 feet (14 meters) thick! Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.

3. Building Materials make a dierence. A solid metal door or aluminum studs may have a negative eect on the range. Try to position access points, wireless routers, and computers so that the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and concrete will degrade your wireless signal.

4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF noise.

5. If you are using 2.4GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone in not in use.

10D-Link DAP-2310 User Manual

Section 2 - Installation

Hardware Overview

LEDs

1 Power LED This light will be solid green when the unit is powered on.

2 WLAN LED This light will be ickering green when the 2.4GHz frequency is in use.

3 LAN LED This light will be ickering green when there is active LAN trac.

11D-Link DAP-2310 User Manual

Section 2 - Installation

Hardware Overview

Connections

1 LAN Port

2 Reset

3 Power Receptor

1 2 3

Connects the DAP-2310 to a switch or PC.

Reset the Access Point.

Receptor for Power Adapter.

12D-Link DAP-2310 User Manual

Section 2 - Installation

Four Operational Modes

Access Point (AP)

WDS with AP

WDS

Wireless Client

Create a wireless LAN

Wirelessly connect multiple networks while still functioning as a wireless AP

Wirelessly connect multiple networks

AP acts as a wireless network adapter for your Ethernetenabled device

13D-Link DAP-2310 User Manual

Section 2 - Installation

LAN

RESET

Getting Started

Desktop

Laptop

DAP-2310

Switch

1. Connect the power adapter to the receptor on the rear panel of the DAP-2310 and then plug the other end of the power adapter to a wall outlet or power strip. The power LED will turn ON to indicate proper operation.

2. Using an Ethernet cable, insert one end of the cable to the LAN port on the rear panel of the DAP-2310 and the other end of the cable to a switch or router’s LAN port .

Note: You can also connect the DAP-2310 directly to the computer that will be used for conguration. The LAN LED will illuminate to indicate a proper Ethernet connection.

3. Computers with 802.11 b/g/n wireless adapters can connect to the DAP-2310.

14D-Link DAP-2310 User Manual

Section 3 - Conguration

Conguration

To congure the DAP-2310, use a computer that is connected to the DAP-2310 with an Ethernet cable (see the

diagram

Launch your web browser.

Type the IP address of the DAP-2310 in the address eld (http://192.168.0.50) and press Enter. Make sure that the IP addresses of the DAP-2310 and your computer are in the same subnet.

Note: If you have changed the default IP address assigned to the DAP-2310, make sure to enter the correct IP address.

Enter the user name (admin) and your password. Leave the password eld blank by default and click Login.

Network Layout

Note: If you have changed the password, make sure to enter the correct password.

15D-Link DAP-2310 User Manual

Section 3 - Conguration

After successfully logging into the DAP-2310, the following screen will appear:

Save and Activate Settings

When making changes on most of the conguration screens in this section, use the button at the bottom of each screen to save (not activate) your conguration changes.

You may change settings to multiple pages before activating. Once you are nished, click the Conguration button located at the top of the page and then click Save and Activate.

16D-Link DAP-2310 User Manual

Section 3 - Conguration

Basic Settings

Wireless

Access Point mode

Wireless Band:

Mode:

Network Name

(SSID):

SSID Visibility:

Auto Channel

Selection:

Select 2.4GHz from the drop-down menu.

Select Access Point from the drop-down menu. The other three choices are WDS with AP, WDS, and Wireless Client.

Service Set Identier (SSID) is the name designated for a specic wireless local area network (WLAN). The SSID’s factory default setting is dlink. The SSID can be easily changed to connect to an existing wireless network or to establish a new wireless network. The SSID can be up to 32 characters and is case-sensitive.

Enable or Disable SSID visibility. Enabling this feature broadcasts the SSID across the network, thus making it visible to all network users. This feature is enabled by default.

Enabling this feature automatically selects the channel that provides the best wireless performance. Enable is set by default. The channel selection process only occurs when the AP is booting up.

Channel:

All devices on the network must share the same channel. To change the channel, rst toggle the Auto Channel Selection setting to Disable, and then use the drop-down menu to make the desired selection.

Note: The wireless adapters will automatically scan and match the wireless settings.

17D-Link DAP-2310 User Manual

Section 3 - Conguration

Channel Width:

Authentication:

Allows you to select the channel width you would like to operate in. Select 20 MHz if you are not using any 802.11n wireless clients. Auto 20/40 MHz allows you to connect to both 802.11n and 802.11b/g wireless devices on your network.

Use the drop-down menu to choose Open System, Shared Key, WPA-Personal, WPA-Enterprise, or 802.11x.

Select Open System to communicate the key across the network.

Select Shared Key to limit communication to only those devices that share the same WEP settings. If multi-SSID is enabled, this option is not available.

Select WPA-Personal to secure your network using a password and dynamic key changes. No RADIUS server is required.

Select WPA-Enterprise to secure your network with the inclusion of a RADIUS server.

Select 802.1x to secure your network using 802.1x authentication.

18D-Link DAP-2310 User Manual

Section 3 - Conguration

WDS with AP mode

In WDS with AP mode, the DAP-2310 wirelessly connects multiple networks while still functioning as a wireless AP.

Wireless Band:

Mode:

Network Name

(SSID):

SSID Visibility:

Auto Channel

Selection:

Select 2.4GHz from the drop-down menu.

WDS with AP mode is selected from the drop-down menu.

Enable or Disable SSID visibility. Enabling this feature broadcasts the SSID across the network, thus making it visible to all network users.

Enabling this feature automatically selects the channel that will provide the best wireless performance. This feature is not supported in WDS with AP mode. The channel selection process only occurs when the AP is booting up.

Channel:

Channel Width:

To change the channel, use the drop-down menu to make the desired selection. (Note: The wireless adapters will automatically scan and match the wireless settings.)

Indicates whether the device is capable of 20MHz operation only or both 20MHz and 40MHz operation.

19D-Link DAP-2310 User Manual

Section 3 - Conguration

Remote AP MAC

Address:

Site Survey:

Authentication:

Enter the MAC addresses of the APs on your network that will serve as bridges to wirelessly connect multiple networks.

Click on the Scan button to search for available wireless networks, then click on the available network that you want to connect with.

Use the drop-down menu to choose Open System, Shared Key, or WPA-Personal. Select Open System to communicate the key across the network.

Select Shared Key to limit communication to only those devices that share the same WEP settings. If multi-SSID is enabled, this option is not available.

Select WPA-Personal to secure your network using a password and dynamic key changes. No RADIUS server is required.

20D-Link DAP-2310 User Manual

Section 3 - Conguration

WDS mode

In WDS mode, the DAP-2310 wirelessly connects multiple networks, without functioning as a wireless AP.

Wireless Band: Select 2.4GHz from the drop-down menu.

Mode:

Network Name

(SSID):

SSID Visibility:

Auto Channel

Selection:

Channel:

WDS is selected from the drop-down menu.

Enable or Disable SSID visibility. Enabling this feature broadcasts the SSID across the network, thus making it visible to all network users.

Enabling this feature automatically selects the channel that will provide the best wireless performance. This feature is not supported in WDS mode.

All devices on the network must share the same channel. To change the channel, use the drop-down menu to make the desired selection.

Channel Width:

Remote AP

MAC Address:

Use the drop-down menu to choose 20 MHz or Auto 20/40 MHz.

Enter the MAC addresses of the APs on your network that will serve as bridges to wirelessly connect multiple networks.

21D-Link DAP-2310 User Manual

Section 3 - Conguration

Site Survey:

Authentication:

Click on the Scan button to search for available wireless networks, then click on the available network that you want to connect with.

Use the drop-down menu to choose Open System, Shared Key, or WPA-Personal. Select Open System to communicate the key across the network. Select Shared Key to limit communication to only those devices that share the same WEP settings. Select WPA-Personal to secure your network using a password and dynamic key changes. No RADIUS server is required.

22D-Link DAP-2310 User Manual

Section 3 - Conguration

Wireless Client mode

Wireless Band:

Mode:

Network Name

(SSID):

SSID Visibility:

Auto Channel

Selection:

Channel:

Channel Width:

Select 2.4GHz from the drop-down menu.

Wireless Client is selected from the drop-down menu.

This option is unavailable in Wireless Client mode.

Enabling this feature automatically selects the channel that will provide the best wireless performance. This feature is not supported in Wireless Client mode.

The channel used will be displayed, and matches the AP that the DAP-2310 is connected to when set to Wireless Client mode.

Use the drop-down menu to choose 20 MHz or Auto

20/40 MHz.

Site Survey:

Authentication:

Click on the Scan button to search for available wireless networks, then click on the available network that you want to connect with. Use the drop-down menu to choose Open System or WPA-Personal.

Select Open System to communicate the key across the network. Select WPA-Personal to secure your network using a password and dynamic key changes. No RADIUS server is required.

23D-Link DAP-2310 User Manual

Section 3 - Conguration

Enable:

MAC Source:

MAC Address:

Check to enable clone MAC. This feature will allow you to change the MAC address of the access point to the MAC address of a client.

Select the MAC source from the drop-down menu.

Enter the MAC address that you would like to assign to the access point.

24D-Link DAP-2310 User Manual

Section 3 - Conguration

Open System/Shared Key Authentication

Encryption:

Key Type*:

Key Size:

Key Index (1-4):

Key:

Use the radio button to disable or enable encryption.

Select HEX or ASCII.

Select 64 Bits or 128 Bits.

Select the 1st through the 4th key to be the active key.

Input up to four keys for encryption. You will select one of these keys in the Key Index drop-down menu.

**Hexadecimal (HEX) digits consist of the numbers 0-9 and the letters A-F.

*ASCII (American Standard Code for Information Interchange) is a code that represents English letters using numbers ranging from 0-127.

25D-Link DAP-2310 User Manual

Section 3 - Conguration

WPA/WPA2-Personal Authentication

WPA Mode:

Cipher Type:

Group Key

Update:

Periodical Key

Change:

PassPhrase:

When WPA-Personal is selected for Authentication type, you must also select a WPA mode from the drop-down menu: AUTO (WPA or WPA2), WPA2 Only, or WPA Only. WPA and WPA2 use dierent algorithms. AUTO (WPA or WPA2) allows you to use both WPA and WPA2.

When you select WPA-Personal, you must also select AUTO, AES, or TKIP from the drop-down menu.

Select the interval during which the group key will be valid. The default value of 1800 is recommended. Select Manual to enter your key (PassPhrase).

You can select Periodical Key Change to have the access point automatically change your PassPhrase. Enter the Activate From time and the time in hours to change the key.

When you select WPA-Personal, please enter a PassPhrase in the corresponding eld.

26D-Link DAP-2310 User Manual

Section 3 - Conguration

WPA/WPA2-Enterprise Authentication

WPA Mode:

Cipher Type:

Group Key

Update

Interval:

Network Access

Protection:

RADIUS Server:

When WPA-Enterprise is selected, you must also select a WPA mode from the drop-down menu: AUTO (WPA or WPA2), WPA2 Only, or WPA Only. WPA and WPA2 use dierent algorithms. AUTO (WPA or WPA2) allows you to use both WPA and WPA2.

When WPA-Enterprise is selected, you must also select a cipher type from the drop-down menu: Auto, AES, or TKIP.

Select the interval during which the group key will be valid. The recommended value is 1800. A lower interval may reduce data transfer rates.

Enable or disable Microsoft Network Access Protection.

Enter the IP address of the RADIUS server.

RADIUS Port:

RADIUS Secret:

Enter the RADIUS port.

Enter the RADIUS secret.

27D-Link DAP-2310 User Manual

Section 3 - Conguration

802.1x Authentication

Key Update Interval:

RADIUS Server:

RADIUS Port:

RADIUS Secret:

Select the interval during which the group key will be valid (300 is the recommended value). A lower interval may reduce data transfer rates.

Enter the IP address of the RADIUS server.

Enter the RADIUS port.

Enter the RADIUS secret.

28D-Link DAP-2310 User Manual

Section 3 - Conguration

LAN

LAN is short for Local Area Network. This is considered your internal network. These are the IP settings of the LAN interface for the DAP-2310. These settings may be referred to as private settings. You may change the LAN IP address if needed. The LAN IP address is private to your internal network and cannot be seen on the Internet.

Get IP From:

IP Address:

Subnet Mask:

Default

Gateway:

Static IP (Manual) is chosen here. Choose this option

if you do not have a DHCP server in your network, or if you wish to assign a static IP address to the DAP-2310. When Dynamic IP (DHCP) is selected, the other fields here will be grayed out. Please allow about two minutes for the DHCP client to be functional once this selection is made.

The default IP address is 192.168.0.50. Assign a static IP address that is within the IP address range of your network.

Enter the subnet mask. All devices in the network must share the same subnet mask.

Enter the IP address of the gateway in your network. If there is a gateway in your network, please enter an IP address within the range of your network.

29D-Link DAP-2310 User Manual

Section 3 - Conguration

Advanced Settings

Performance

Wireless:

Wireless Mode:

Data Rate*:

Use the drop-down menu to turn the wireless function On or O.

The different combination of clients that can be supported include Mixed 802.11n, 802.11g and 802.11b, Mixed 802.11g and 802.11b and 802.11n Only. Please note that when backwards compatibility is enabled for legacy (802.11g/b) clients, degradation of 802.11n wireless performance is expected.

Indicate the base transfer rate of wireless adapters on the wireless LAN. The AP will adjust the base transfer rate depending on the base rate of the connected device. If there are obstacles or interference, the AP will step down the rate. This option is enabled in Mixed 802.11g and 802.11b mode. The choices available are Best (Up to 54), 54, 48, 36, 24, 18, 12, 9, 6, 11, 5.5, 2 or 1.

30D-Link DAP-2310 User Manual

Section 3 - Conguration

Beacon Interval (25-

500):

DTM Interval

(1-15):

Transmit Power:

WMM (Wi-Fi

Multimedia):

Ack Time Out

(2.4 GHZ, 64~200) :

Short GI:

IGMP Snooping:

Beacons are packets sent by an access point to synchronize a wireless network. Specify a value in milliseconds. The default (100) is recommended. Setting a higher beacon interval can help to save the power of wireless clients, while setting a lower one can help a wireless client connect to an access point faster.

Select a Delivery Trac Indication Message setting between 1 and 15. The default value is 1. DTIM is a countdown informing clients of the next window for listening to broadcast and multicast messages.

This setting determines the power level of the wireless transmission. Transmitting power can be adjusted to eliminate overlapping of wireless area coverage between two access points where interference is a major concern. For example, if wireless coverage is intended for half of the area, then select 50% as the option. Use the drop-down menu to select 100%, 50%, 25%, or

12.5%.

WMM stands for Wi-Fi Multimedia. Enabling this feature will improve the user experience for audio and video applications over a Wi-Fi network.

To eectively optimize throughput over long distance links, enter a value for Acknowledgement Time Out from 64 to 200 microseconds in the 2.4 GHz in the eld provided.

Select Enable or Disable. Enabling a short guard interval can increase throughput. However, be aware that it can also increase the error rate in some installations due to increased sensitivity to radio-frequency installations.

Select Enable or Disable. Internet Group Management Protocol allows the AP to recognize IGMP queries and reports sent between routers and an IGMP host (wireless STA). When IGMP snooping is enabled, the AP will forward multicast packets to an IGMP host based on IGMP messages passing through the AP.

Connection Limit:

User Limit (0-64):

Multicast Rate for

2.4G Band

Select Enable or Disable. This is an option for load balancing. This determines whether to limit the number of users accessing this device. The exact number is entered in the User Limit eld below. This feature allows the user to share the wireless network trac and the client using multiple APs. If this function is enabled, when the number of users exceeds this value, the DAP-2310 will not allow clients to associate with the AP.

Set the maximum amount of users that are allowed access (0-64 users). To use this feature, the Connection Limit above must be enabled. For most users, a limit of 10 is recommended. The default setting is 20.

Select the multicast rate for 2.4G band. The choices available are 130,117,78,65,58.5,54, 52,48, 39,36, 26,24, 19.5,18, 13,12, 9, 6.5,6,

11, 5.5, 2 or 1.

31D-Link DAP-2310 User Manual

Section 3 - Conguration

Multi-SSID

The device supports up to four multiple Service Set Identiers. In the Basic > Wireless section, you can set the Primary SSID. The SSID’s factory default setting is dlink. The SSID can be easily changed to connect to an existing wireless network or to establish a new wireless network.

Enable

Multi-SSID:

Band:

Index:

SSID:

SSID Visibility:

Check to enable support for multiple SSIDs.

This read-only value is the current band setting.

You can select up to three multi-SSIDs. With the Primary SSID, you have a total of four multi-SSIDs.

Service Set Identifier (SSID) is the name designated for a specific wireless local area network ( WLAN). The SSID’s factory default setting is dlink. The SSID can be easily changed to connect to an existing wireless network or to establish a new wireless network.

Enable or Disable SSID visibility. Enabling this feature broadcasts the SSID across the network, thus making it visible to all network users.

Security:

The Multi-SSID security can be Open System, WPA-Personal, WPA-Enterprise, or 802.1x. For a detailed description of the Open System parameters, please go to page 25. For a detailed description of the WPA-Personal parameters, please go to page 26. For a detailed description of the WPA-Enterprise parameters, please go to page 27. For a detailed description of the O802.1x parameters, please go to page 28.

32D-Link DAP-2310 User Manual

Section 3 - Conguration

Priority:

WMM (Wi-Fi

Multimedia):

Encryption:

Key Type:

Key Size:

Key Index (1-4):

Key:

WPA Mode:

Cipher Type:

Check the Enable Priority box at the top of this window to enable. Select the priority from the drop-down menu.

Select Enable or Disable.

When you select Open System, toggle between Enable and Disable. If Enable is selected, the Key Type, Key Size, Key Index (1~4), Key, and Conrm Keys must also be congured.

Select HEX or ASCII.

Select 64 Bits or 128 Bits.

Select from the 1st to 4th key to be set as the active key.

Input up to four keys for encryption. You will select one of these keys in the Key Index drop-down menu.

When you select either WPA-Personal or WPA-Enterprise, you must also choose a WPA mode from the drop-down menu: AUTO (WPA or WPA2), WPA2 Only, or WPA Only. WPA and WPA2 use dierent algorithms. AUTO (WPA or WPA2) allows you to use both WPA and WPA2. In addition, you must congure Cipher Type and Group Key Update Interval.

Select Auto, AES, or TKIP from the drop-down menu.

Group Key

Update Interval:

PassPhrase:

Conrm

PassPhrase:

RADIUS Server:

RADIUS Port:

RADIUS Secret:

Select the interval during which the group key will be valid. The default value of 1800 seconds is recommended.

When you select WPA-Personal, please enter a PassPhrase in the corresponding eld.

When you select WPA-Personal, please re-enter the PassPhrase entered in the previous item in the corresponding eld.

When you select WPA-Enterprise, enter the IP address of the RADIUS server. In addition, you must congure RADIUS Port and RADIUS Secret.

Enter the RADIUS port.

Enter the RADIUS secret.

33D-Link DAP-2310 User Manual

Section 3 - Conguration

VLAN

VLAN List

The DAP-2310 supports VLANs. VLANs can be created with a Name and VID. Mgmt (TCP stack), LAN, Primary Multiple SSID, and WDS connection can be assigned to VLANs as they are physical ports. Any packet which enters the DAP-2310 without a VLAN tag will have a VLAN tag inserted with a PVID.

The VLAN List tab displays the current VLANs.

VLAN Status:

Use the radio button to toggle between Enable or Disable. Next, go to the Add/Edit VLAN tab to add or modify an item on the VLAN List tab.

34D-Link DAP-2310 User Manual

Section 3 - Conguration

Port List

The Port List tab displays the current ports. If you want to congure the guest and internal networks on a Virtual LAN (VLAN), the switch and DHCP server you are using must also support VLANs. As a prerequisite step, congure a port on the switch for handling VLAN tagged packets as described in the IEEE 802.1Q standard.

VLAN Status:

Port Name:

Tag VID:

Untag VID:

PVID:

Use the radio button to toggle to Enable. Next, go to the Add/Edit VLAN tab to add or modify an item on the VLAN List tab.

The name of the port is displayed in this column.

The Tagged VID is displayed in this column.

The Untagged VID is displayed in this column.

The Port VLAN Identifier is displayed in this column.

35D-Link DAP-2310 User Manual

Section 3 - Conguration

Add/Edit VLAN

The Add/Edit VLAN tab is used to congure VLANs. Once you have made the desired changes, click the Save button to let your changes take eect.

VLAN Status:

VLAN ID:

VLAN Name:

Use the radio button to toggle to Enable.

Provide a number between 1 and 4094 for the Internal VLAN.

Enter the VLAN to add or modify.

36D-Link DAP-2310 User Manual

Section 3 - Conguration

PVID Setting

The PVID Setting tab is used to enable/disable the Port VLAN Identier Auto Assign Status as well as to congure various types of PVID settings. Click the Save button to let your changes take eect.

VLAN Status:

PVID Auto

Assign Status:

Use the radio button to toggle between Enable and Disable.

Use the radio button to toggle PVID auto assign status to Enable.

37D-Link DAP-2310 User Manual

Section 3 - Conguration

Intrusion

The Wireless Intrusion Protection window is used to set APs as All, Valid, Neighborhood, Rogue, and New. Click the Save button to let your changes take eect.

AP List:

Detect:

The choices include All, Valid, Neighbor, Rogue, and New.

Click this button to initiate a scan of the network.

38D-Link DAP-2310 User Manual

Section 3 - Conguration

Schedule

The Wireless Schedule Settings window is used to add and modify scheduling rules on the device. Click the Save button to let your changes take eect.

Wireless

Schedule:

Name:

Index:

SSID:

Day(s):

All Day(s):

Start Time:

Use the drop-down menu to enable the device’s scheduling feature.

Enter a name for the new scheduling rule in the eld provided.

Select the index from the drop-down menu.

Enter the name of your wireless network (SSID).

Toggle the radio button between All Week and Select Day(s). If the second option is selected, check the specic days you want the rule to be eective on.

Check this box to have your settings apply 24 hours a day.

Enter the start time for your rule. If you selected

All Day, this option will be greyed out.

End Time:

Add:

Schedule Rule

List:

Save:

Enter the end time for your rule.

Click to add the rule to the list.

This section will display the list of created schedules.

Click the Save button to save your created rules.

39D-Link DAP-2310 User Manual

Section 3 - Conguration

QoS

Quality of Service (QoS) enhances the experience of using a network by prioritizing the trac of dierent applications. A QoS

Rule identies a specic message ow and assigns a priority to that ow. For most applications, the priority classiers ensure the right priorities and specic QoS Rules are not required. QoS supports overlaps between rules. If more than one rule matches a specic message ow, the rule with the highest priority will be used.

QoS (Quality of

Service):

HTTP:

Automatic:

Enable this option if you want to allow QoS to prioritize your trac Priority Classiers.

Allows the access point to recognize HT TP transfers for many common audio and video streams and prioritize them above other trac. Such streams are frequently used by digital media players.

When enabled, this option causes the access point to automatically attempt to prioritize trac streams that it does not otherwise recognize, based on the behavior that the streams exhibit. This acts to de-prioritize streams that exhibit bulk transfer characteristics, such as le transfers, while leaving interactive trac, such as gaming or VoIP, running at a normal priority.

40D-Link DAP-2310 User Manual

Section 3 - Conguration

Name:

Priority:

Protocol:

Host 1 IP Range:

Host 1 Port

Range:

Host 2 IP Range:

Host 2 Port

Range:

Enter a name for the new QoS rule in the eld provided.

Use the drop-down menu to select the desired priority: Background (BK), Best Eort (BE), Video (VI), or Voice (VO).

Use the drop-down menu to choose the appropriate protocol used by the messages: Any, TCP, UDP, Both, IMCP, or Other.

The rule applies to a ow of messages for which one computer’s IP address falls within the range set here.

The rule applies to a ow of messages for which host 1’s port number is within the range set here when the Protocol is set to TCP, UDP, or Both.

The rule applies to a ow of messages for which the other computer’s IP address falls within the range set here.

The rule applies to a ow of messages for which host 2’s port number is within the range set here when the Protocol is set to TCP, UDP, or Both.

41D-Link DAP-2310 User Manual

Section 3 - Conguration

AP Array

An AP array is a set of devices on a network that are organized into a single group to increase ease of management.

Enable Array:

AP Array Name:

AP Array

Password:

Scan AP Array

List:

AP Array List:

Current Array

Members:

This check box allows the user to enable the AP array function. The three modes that are available are Master, Backup Master, and Slave. APs in the same array will use the same conguration. The conguration will sync the Master AP to the Slave AP and the Backup Master AP when a Slave AP and a Backup Master AP join the AP array.

Enter a name for the AP array you have created.

Enter a password that will be used to access the AP array you have created.

Click this button to initiate a scan of all the available APs currently on the network.

This table displays the current AP array status for the following parameters: Array Name, Master IP, MAC, Master, Backup Master, Slave, and Total.

This table displays all the current array members. The DAP-2310 AP array feature supports up to eight AP array members.

42D-Link DAP-2310 User Manual

Section 3 - Conguration

Wireless Basic Settings

Network Name

(SSID):

SSID Visibility:

Auto Channel

Selection:

Channel Width:

Security:

Data Rate:

Beacon Interval:

DTIM Interval:

Transmit Power:

Select this option to use a Network Name (SSID).

Select this option to enable SSID Visibility.

Select this option to use Auto Channel Selection.

Select this option to specify the Channel Width.

Select this option to use Wireless Security.

Wireless Advanced Settings

Select this option to specify the Data Rate.

Select this option to specify the Beacon Interval.

Select this option to specify the DTIM Interval.

Select this option to specify the Transmit Power.

WMM (Wi-Fi

Multimedia):

Ack Time Out:

Short GI:

IGMP Snooping:

Link Integrity:

Connection

Limit:

Wireless ACL:

Select this option to use WMM.

Select this option to use Ack Time Out.

Select this option to use a Short GI.

Select this option to enable IGMP Snooping.

Select this option to use Link Integrity.

Select this option to use a Connection Limit.

Select this option to use Wireless ACL.

43D-Link DAP-2310 User Manual

Section 3 - Conguration

Multiple SSID & VLAN

SSID:

SSID Visibility:

Security:

WMM:

VLAN:

Schedule Settings:

QoS Settings:

DHCP Server

Settings:

Log Settings:

Time and Date

Settings:

Select this option to use an SSID.

Select this option to make the SSID Visible.

Select this option to use Wireless Security.

Select this option to use WMM.

Select this option to use VLAN.

Advanced Functions

Select this option to use Scheduled Settings.

Select this option to use Quality of Service.

Select this option to use DHCP.

Select this option to enable the Log Settings.

Select this option to use the Time and Date Settings.

SNMP Settings:

System Name

Settings:

Console Settings:

Administration Settings

Select this option to enable SNMP Settings.

Select this option to use a System Name.

Select this option to use Login Settings.

Select this option to enable Console Settings.

44D-Link DAP-2310 User Manual

Section 3 - Conguration

ARP Spoong Prevention

The ARP Spoong Prevention feature allows users to add IP/MAC address mapping to prevent ARP spoong attack.

ARP Spoong

Prevention:

Gateway IP Address:

Gateway MAC Address:

This check box allows you to enable the ARP spoong prevention function.

Enter a gateway IP address.

Enter a gateway MAC address.

45D-Link DAP-2310 User Manual

Section 3 - Conguration

DHCP Server

Dynamic Pool Settings

The DHCP address pool denes the range of the IP address that can be assigned to stations in the network. A Dynamic Pool allows wireless stations to receive an available IP with lease time control. If needed or required in the network, the DAP-2310 is capable of acting as a DHCP server.

Function

Enable/Disable:

IP Assigned

From:

The Range of

Pool (1-254):

Subnet Mask:

Gateway:

Dynamic Host Configuration Protocol (DHCP) assigns dynamic IP addresses to devices on the network. This protocol simplifies network management and allows new wireless devices to receive IP addresses automatically without the need to manually assign new IP addresses. Select Enable to allow the DAP-2310 to function as a DHCP server.

Input the rst IP address available for assignment on your network.

Enter the number of IP addresses available for assignment. IP addresses are increments of the IP address specied in the “IP Assigned From” eld.

All devices in the network must have the same subnet mask to communicate. Enter the submask for the network here.

Enter the IP address of the gateway on the network.

WINS:

Specify the Windows Internet Naming Service (WINS) server address for the wireless network. WINS is a system that determines the IP address of a network computer that has a dynamically assigned IP address.

46D-Link DAP-2310 User Manual

Section 3 - Conguration

DNS:

Domain Name:

Lease Time

(60-31536000

sec):

Enter the IP address of the Domain Name System (DNS) server. The DNS server translates domain names such as www.dlink.com into IP addresses.

Enter the domain name of the network, if applicable. (An example of a domain name is: www.dlink.com.)

The lease time is the period of time before the DHCP server will assign new IP addresses.

47D-Link DAP-2310 User Manual

Section 3 - Conguration

Static Pool Setting

The DHCP address pool denes the range of IP addresses that can be assigned to stations on the network. A static pool allows specic wireless stations to receive a xed IP without time control.

Function

Enable/Disable:

Assigned IP:

Assigned MAC

Address:

Dynamic Host Conguration Protocol (DHCP) assigns IP addresses to wireless devices on the network. This protocol simplies network management and allows new wireless devices to receive IP addresses automatically without the need to manually assign IP addresses. Select Enable to allow the DAP-2310 to function as a DHCP server.

Use the Static Pool Settings to assign the same IP address to a device every time you start up. The IP addresses assigned in the Static Pool list must NOT be in the same IP range as the Dynamic Pool. After you have assigned a static IP address to a device via its MAC address, click Save; the device will appear in the Assigned Static Pool at the bottom of the screen. You can edit or delete the device in this list.

Enter the MAC address of the device requesting association here.

Subnet Mask:

Dene the submask of the IP address specied in the “IP Assigned From” eld.

48D-Link DAP-2310 User Manual

Section 3 - Conguration

Gateway:

WINS:

DNS:

Domain Name:

Specify the Gateway address for the wireless network.

Specify the Windows Internet Naming Service (WINS) server address for the wireless network. WINS is a system that determines the IP address of a network computer with a dynamically assigned IP address, if applicable.

Enter the Domain Name System (DNS) server address for the wireless network. The DNS server translates domain names such as www.dlink.com into IP addresses.

Specify the domain name for the network.

49D-Link DAP-2310 User Manual

Section 3 - Conguration

Current IP Mapping List

This window displays information about the current assigned DHCP dynamic and static IP address pools. This information is available when you enable DHCP server on the AP and assign dynamic and static IP address pools.

Current DHCP

Dynamic

Prole:

Host Name:

Binding MAC

Address:

Assigned IP

Address:

Lease Time:

Current DHCP

Static Pools:

These are IP address pools the DHCP server has assigned using the dynamic pool setting.

The host name of a device on the network that is assigned an IP address from the DHCP dynamic pool.

The MAC address of a device on the network that is assigned an IP address from the DHCP dynamic pool.

The current corresponding DHCP-assigned IP address of the device.

The length of time that the dynamic IP address will be valid.

These are the IP address pools of the DHCP server assigned through the static pool settings.

Host Name:

Binding MAC

Address:

Assigned IP

Address:

The host name of a device on the network that is assigned an IP address from the DHCP dynamic pool.

The MAC address of a device on the network that is within the DHCP static IP address pool.

The current corresponding DHCP-assigned static IP address of the device.

50D-Link DAP-2310 User Manual

Section 3 - Conguration

Filters

Wireless MAC ACL

Wireless Band:

Access Control

List:

MAC Address:

MAC Address

List:

Upload ACL File:

Displays the current wireless band rate.

Select Disable to disable the lters function.

Select Accept to accept only those devices with MAC addresses in the Access Control List. All other devices not on the list will be rejected.

Select Reject to reject the devices with MAC addresses on the Access Control List. All other devices not on the list will be accepted.

Enter each MAC address that you wish to include in your lter list, and click Add.

When you enter a MAC address, it appears in this list. Highlight a MAC address and click Delete to remove it from this list.

You may create an ACL list and upload it to the access point instead of manually entering the information. Once created, click the Browse button and locate your le. Select it and then click Upload.

Download ACL

File:

Click Download to export the ACL to a le on your computer.

51D-Link DAP-2310 User Manual

Section 3 - Conguration

WLAN Partition

Wireless Band:

Link Integrity:

Ethernet to

WLAN Access:

Internal Station

Connection:

Displays the current wireless band rate.

Select Enable or Disable.

The default is Enable. When disabled, all data from the Ethernet to associated wireless devices will be blocked. Wireless devices can still send data to the Ethernet.

The default value is Enable, which allows stations to inter-communicate by connecting to a target AP. When disabled, wireless stations cannot exchange data through the AP.

52D-Link DAP-2310 User Manual

Section 3 - Conguration

Status

Device Information

Device

Information:

This read-only window displays the configuration settings of the DAP-2310, including the firmware version and the device's MAC address.

53D-Link DAP-2310 User Manual

Section 3 - Conguration

Client Information

Client Information:

This window displays the wireless client information for clients currently connected to the DAP-2310.

The following information is available for each client communicating with the DAP-2310.

SSID:

MAC:

Band:

Authentication:

Signal:

Displays the SSID of the client.

Displays the MAC address of the client.

Displays the wireless band that the client is connected to.

Displays the type of authentication being used.

Displays the client's signal strength.

Power Saving

Mode:

Displays the status of the p ower saving feature.

54D-Link DAP-2310 User Manual

Section 3 - Conguration

WDS Information

WDS

Information:

T h i s w in do w d is p la y s t he Wi re le ss Distribution System information for clients currently connected to the DAP-2310.

The following information is available for each client communicating with the DAP-2310.

Name:

MAC:

Authentication:

Signal:

Status:

Displays the SSID of the client.

Displays the MAC address of the client.

Displays the type of authentication being used.

Displays the client's signal strength.

Displays the status of the power saving feature.

55D-Link DAP-2310 User Manual

Section 3 - Conguration

Stats

Ethernet

Ethernet Trac

Statistics:

This page displays transmitted and received count statistics for packets and bytes.

56D-Link DAP-2310 User Manual

Section 3 - Conguration

WLAN Trac

Statistics:

This page displays wireless network statistics for data throughput, transmitted and received frames, and frame errors.

57D-Link DAP-2310 User Manual

Section 3 - Conguration

Log

View Log

View Log:

The AP’s embedded memory displays system and network messages including a time stamp and message type. The log information includes but is not limited to the following items: cold start AP, upgrading rmware, client associate and disassociate with AP, and web login. The web page holds up to 500 logs.

58D-Link DAP-2310 User Manual

Section 3 - Conguration

Log Settings

Log Server/IP

Address:

Log Type:

Email Notication:

Outgoing Mail

Server (SMTP):

Authentication:

SSL / TLS:

From Email

Address:

To Email Address:

Enter the IP address of the server you would like to send the DAP-2310 log to.

Check the box for the type of activity you want to log. There are three types: System Activity, Wireless Activity, and Notice.

Check to enable Email notication.

Select the SMTP server from the drop-down menu.

Check to enable authentication.

Check to enable SSL/TLS authentication.

Enter the “From” email address.

Enter the destination email address.

Email Server

Address:

SMTP Port:

Username:

Password:

Conrm Password:

Schedule:

Enter the Email Server Address.

Enter the SMTP port.

Enter your email username.

Enter your email password.

Enter your email password again.

Select when to send the log to your email (in hours). You will receive an email when the log is full too.

59D-Link DAP-2310 User Manual

Section 3 - Conguration

Maintenance

Administration Settings

Check one or more of the five main categories to display the various hidden administrator parameters and settings displayed on the next ve pages.

60D-Link DAP-2310 User Manual

Section 3 - Conguration

Limit Administrator

Each of the ve main categories display various hidden administrator parameters and settings.

Limit

Administrator

VLAN ID:

Limit

Administrator IP:

IP Range:

Check the box provided and the enter the specic VLAN ID that the administrator will be allowed to log in from.

Check to enable the Limit Administrator IP address.

Enter the IP address range that the administrator will be allowed to log in from and then click the Add button.

61D-Link DAP-2310 User Manual

Section 3 - Conguration

System Name Settings

Each of the ve main categories display various hidden administrator parameters and settings.

System Name:

Location:

The name of the device. The default name is D-Link DAP-2310.

The physical location of the device, e.g. 72nd Floor, D-Link HQ.

62D-Link DAP-2310 User Manual

Section 3 - Conguration

Login Settings

Each of the ve main categories display various hidden administrator parameters and settings.

Old Password:

New Password:

Conrm

Password:

Enter a user name. The default is admin.

When changing your password, enter the old password here.

When changing your password, enter the new password here. The password is case-sensitive. “A” is a dierent character than “a.” The length should be between 0 and 12 characters.

Enter the new password a second time for conrmation purposes.

63D-Link DAP-2310 User Manual

Section 3 - Conguration

Console Settings

Each of the ve main categories display various hidden administrator parameters and settings.

Status:

Console

Protocol:

Timeout:

Status is enabled by default. Uncheck the box to disable the console.

Select the type of protocol you would like to use, Telnet or SSH.

Set to 1 Min, 3 Mins, 5 Mins, 10 Mins, 15 Mins or Never.

64D-Link DAP-2310 User Manual

Section 3 - Conguration

SNMP Settings

Each of the ve main categories display various hidden administrator parameters and settings.

Status:

Public Community

String:

Private

Community

String:

Trap Status:

Trap Server IP:

Chec k the box to en able the SNMP functions. This option is disabled by default.

Enter the public SNMP community string.

Enter the private SNMP community string.

Check the box to enable Trap Status.

Enter the Trap Server IP address.

65D-Link DAP-2310 User Manual

Section 3 - Conguration

Firmware and SSL Certication Upload

This page allows the user to perform a rmware upgrade. A Firmware upgrade is a function that upgrade the running software used by the access point. This is a useful feature that prevents future bugs and allows for new features to be added to this product. Please go to your local D-Link website to see if there is a newer version rmware available.

Upload

Firmware From

Local Hard Drive:

Language Pack

Upgrade:

Upload SSL

Certication

From Local Hard

Drive:

The current firmware version is displayed above the le location eld. After downloading the most recent version of firmware for the DAP-2310 from http://support.dlink.com to your local computer, use the Browse button to locate the rmware le on your computer. Click Upload to update the rmware version. Please don’t turn the power o while upgrading.

You may load a language pack to display the utility in another language. Click Browse to locate the language pack file on your local computer. After selecting and opening the file, click Upload to upload the file to the DAP-2310.

Click Browse to locate the SSL Certication le on your local computer. After selecting and opening the le, click Upload to upload the le to the DAP-2310.

66D-Link DAP-2310 User Manual

Section 3 - Conguration

Conguration File Upload

Upload File:

Download

Conguration

File:

Click the Browse button to locate a previously saved conguration le on your local computer. After selecting the le, click Upload to apply the conguration settings to the DAP-2310.

Click Download to save the current DAP-2310 configuration to your local computer. Note that if you save one configuration with the administrator’s password now, after resetting your DAP-2310, and then updating to this saved conguration le, the password will be gone.

67D-Link DAP-2310 User Manual

Section 3 - Conguration

Time and Date

Current Time:

Time Zone:

Enable Daylight

Saving:

Daylight Saving

Dates:

Enable NTP

Server:

NTP Server:

Set the Date

and Time

Manually:

Displays the current time and date settings.

Use the drop-down menu to select your correct Time Zone.

Check the box to Enable Daylight Saving Time.

Use the drop-down menu to select the correct Daylight Saving oset.

Check to enable the AP to get system time from an NTP server.

Enter the NTP server IP address.

You can either manually set the time for your AP here, or you can click the Copy Your Computer’s Time Settings button to copy the time from the computer you are using (Make sure that the computer’s time is set correctly).

68D-Link DAP-2310 User Manual

Section 3 - Conguration

System

System Settings

Restart the Device:

Restore to Factory

Default Settings:

Clear Language Pack:

Click Restart to restart the DAP-2310.

Click Restore to restore the DAP-2310 back to factory default settings.

Click Clear to remove any loaded language packs.

69D-Link DAP-2310 User Manual

Section 3 - Conguration

Help

Help:

Scroll down the Help page for topics and explanations.

70D-Link DAP-2310 User Manual

Section 6 - Troubleshooting

Troubleshooting

This chapter provides solutions to problems that can occur during the installation and operation of the DAP-2310. Read the following descriptions if you are having problems. (The examples below are illustrated in Windows® XP. If you have a dierent operating system, the screenshots on your computer will look similar to the following examples.)

1. Why can’t I access the web-based conguration utility?

When entering the IP address of the D-Link access point (192.168.0.50 for example), you are not connecting to a website on the Internet nor do you have to be connected to the Internet.

Networking Basics

Check your IP address

After you install your network adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.

Click on Start > Run. In the run box type cmd and click OK.

At the prompt, type ipcong and press Enter.

This will display the IP address, subnet mask, and the default gateway of your adapter.

71D-Link DAP-2310 User Manual

Section 6 - Troubleshooting

If the address is 0.0.0.0, check your adapter installation, security settings, and the settings on your router. Some rewall software programs may block a DHCP request on newly installed adapters.

• Make sure you have an updated Java-enabled web browser. We recommend the following:

- Microsoft Internet Explorer® 6.0 and higher

- Mozilla Firefox 3.0 and higher

- Google™ Chrome 2.0 and higher

- Apple Safari 3.0 and higher

• Verify physical connectivity by checking for solid link lights on the device. If you do not get a solid link light, try using a dierent cable or connect to a dierent port on the device if possible. If the computer is turned o, the link light may not be on.

• Disable any internet security software running on the computer. Software rewalls such as Zone Alarm, Black Ice, Sygate, Norton Personal Firewall, and Windows® XP rewall may block access to the conguration pages. Check the help les included with your rewall software for more information on disabling or conguring it.

72D-Link DAP-2310 User Manual

Appendix B - Networking Basics

Statically Assign an IP address

If you are not using a DHCP capable gateway/router, or you need to assign a static IP address, please follow the steps below:

Step 1

Windows® 2000: Click on Start > Settings > Control Panel > Network Connections Windows® XP: Click on Start > Control Panel > Network Connections Windows Vista®: Click on Start > Control Panel > Network and Internet > Network and Sharing Center > Manage network

connections

Step 2

Right-click on the Local Area Connection which represents your network adapter and select Properties.

Step 3

Highlight Internet Protocol (TCP/IP) and click Properties.

Step 4

Click Use the following IP address and enter an IP address that is on the same subnet as your network or the LAN IP address on your router.

Example: If the router’s LAN IP address is 192.168.0.1, make your IP address 192.168.0.X where X is a number between 2 and 99. Make sure that the number you choose is not in use on the network. Set Default Gateway the same as the LAN IP address of your router (192.168.0.1).

73D-Link DAP-2310 User Manual

Appendix B - Networking Basics

Set Primary DNS the same as the LAN IP address of your router (192.168.0.1). The Secondary DNS is not needed or you may enter a DNS server from your ISP.

Step 5

Click OK twice to save your settings.

74D-Link DAP-2310 User Manual

Appendix B - Networking Basics

• Congure your Internet settings:

• Go to Start > Settings > Control Panel. Double-click the Internet Options Icon. From the Security tab, click the button to restore the settings to their defaults.

• Click the Connection tab and set the dial-up option to Never Dial a Connection. Click the LAN Settings button. Make sure nothing is checked. Click OK.

• Go to the Advanced tab and click the button to restore these settings to their defaults. Click OK three times.

• Close your web browser (if open) and open it.

• Access the web management. Open your web browser and enter the IP address of your D-Link access point in the address bar. This should open the login page for your the web management.

• If you still cannot access the conguration, unplug the power to the access point for 10 seconds and plug back in. Wait about 30 seconds and try accessing the conguration. If you have multiple computers, try connecting using a dierent computer.

2. What can I do if I forgot my password?

If you forgot your password, you must reset your access point. Unfortunately, this process will change all your settings back to the factory defaults.

To reset the access point, locate the reset button (hole) on the rear panel of the unit. With the access point powered on, use a paperclip to hold the button down for 10 seconds. Release the button and the access point will go through its reboot process. Wait about 30 seconds to access the access point. The default IP address is 192.168.0.50. When logging in, the username is admin and leave the password box empty.

75D-Link DAP-2310 User Manual

Appendix C - Technical Specications

Technical Specications

Standards

• IEEE 802.11b

• IEEE 802.11g

• IEEE 802.11n

• IEEE 802.3

• IEEE 802.3u

• IEEE 802.3ab

• IEEE 802.3af

Network Management

• Web Browser interface HTTP Secure HTTP (HTTPS)

• AP Manager II

• AP Array Tool

• SNMP Support D-View Module Private MIB

• Command Line Interface Telnet Secure SSH Telnet

Data Rates*

For 802.11b:

• 11, 5.5, 2, and 1 Mbps For 802.11g:

• 54, 48, 36, 24, 18, 12, 9, and 6 Mbps For 802.11n: HT20/HT40

• 144.4/300, 130/270, 117/243, 104/216, 78/162, 66/135, 58.5/121.5, 52/108, 39/81, 26/54, 19.5/40.5, 12/27, and 6.5/13.5 Mbps

Security

• WPA™ Personal/Enterprise

• WPA2™ Personal/Enterprise

• 802.1x

• WEP™ 64-/128-bit

• SSID Broadcast Disable

• MAC Address Access Control

Wireless Frequency Range

• 2.4 to 2.4835 GHz

Operating Voltage

• 48V DC +/- 10% for PoE*** or 5V/2A

Radio and Modulation Type

For 802.11g/n:

BPSK, QPSK, 16QAM, and 64QAM with OFDM

For 802.11b:

DQPSK, DBPSK, DSSS, and CCK

Operating Frequency**

For 802.11b/g:

2.4 ~ 2.4835 GHz

For 802.11n:

2.4 GHz Band: 2.4 ~ 2.4835 GHz

Dipole Antenna

• 2dBi Gain @2.4 GHz

Max Transmit Output Power (Dual Chain)

• FCC: 25dBm

• ETSI: 17dBm

Max Power Consumption

• Max. 8W with 5V/DC

• Max. 9W with PoE***

* Maximum wireless signal rate derived from IEEE Standard 802.11g and 802.11n specications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely aect wireless signal range.

76D-Link DAP-2310 User Manual

Appendix E - Warranty

LEDs

• Power

• LAN

• 2.4 GHz

Temperature

• Operating: 0˚C to 40˚C

• Storing: -20˚C to 65˚C

Humidity

• Operating: 10%~90% (non-condensing)

• Storing: 5%~95% (non-condensing)

Certications

Dimensions

• L = 148mm

• W = 111mm

• H = 28mm

Weight

• 238g

77D-Link DAP-2310 User Manual

Appendix D - Contacting Technical Support

Contacting Technical Support

U.S. and Canadian customers can contact D-Link technical support through our web site or by phone.

Before you contact technical support, please have the following ready:

• Model number of the product (e.g. DAP-2310)

• Hardware Revision (located on the label on the bottom of the access point (e.g. rev A1))

• Serial Number (s/n number located on the label on the bottom of the access point).

You can nd software updates and user documentation on the D-Link website as well as frequently asked questions and answers to technical issues.

For customers within the United States:

Phone Support:

(877) 354-6555

Internet Support:

http://support.dlink.com

For customers within Canada:

Phone Support:

(800) 354-6560

Internet Support:

http://support.dlink.ca

78D-Link DAP-2310 User Manual

Appendix E - Warranty

Warranty

Subject to the terms and conditions set forth herein, D-Link Systems, Inc. (“D-Link”) provides this Limited Warranty:

• Only to the person or entity that originally purchased the product from D-Link or its authorized reseller or distributor, and

• Only for products purchased and delivered within the fty states of the United States, the District of Columbia, U.S. Possessions or Protectorates, U.S. Military Installations, or addresses with an APO or FPO.

Limited Warranty:

D-Link warrants that the hardware portion of the D-Link product described below (“Hardware”) will be free from material defects in workmanship and materials under normal use from the date of original retail purchase of the product, for the period set forth below (“Warranty Period”), except as otherwise stated herein.

• Hardware (excluding power supplies and fans): One (1) year

• Power supplies and fans: One (1) year

• Spare parts and spare kits: Ninety (90) days

The customer’s sole and exclusive remedy and the entire liability of D-Link and its suppliers under this Limited Warranty will be, at D-Link’s option, to repair or replace the defective Hardware during the Warranty Period at no charge to the original owner or to refund the actual purchase price paid. Any repair or replacement will be rendered by D-Link at an Authorized D-Link Service Oce. The replacement hardware need not be new or have an identical make, model or part. D-Link may, at its option, replace the defective Hardware or any part thereof with any reconditioned product that D-Link reasonably determines is substantially equivalent (or superior) in all material respects to the defective Hardware. Repaired or replacement hardware will be warranted for the remainder of the original Warranty Period or ninety (90) days, whichever is longer, and is subject to the same limitations and exclusions. If a material defect is incapable of correction, or if D-Link determines that it is not practical to repair or replace the defective Hardware, the actual price paid by the original purchaser for the defective Hardware will be refunded by D-Link upon return to D-Link of the defective Hardware. All Hardware or part thereof that is replaced by D-Link, or for which the purchase price is refunded, shall become the property of D-Link upon replacement or refund.

79D-Link DAP-2310 User Manual

Appendix E - Warranty

Limited Software Warranty:

D-Link warrants that the software portion of the product (“Software”) will substantially conform to D-Link’s then current functional specications for the Software, as set forth in the applicable documentation, from the date of original retail purchase of the Software for a period of ninety (90) days (“Software Warranty Period”), provided that the Software is properly installed on approved hardware and operated as contemplated in its documentation. D-Link further warrants that, during the Software Warranty Period, the magnetic media on which D-Link delivers the Software will be free of physical defects. The customer’s sole and exclusive remedy and the entire liability of D-Link and its suppliers under this Limited Warranty will be, at D-Link’s option, to replace the non-conforming Software (or defective media) with software that substantially conforms to D-Link’s functional specications for the Software or to refund the portion of the actual purchase price paid that is attributable to the Software. Except as otherwise agreed by DLink in writing, the replacement Software is provided only to the original licensee, and is subject to the terms and conditions of the license granted by D-Link for the Software. Replacement Software will be warranted for the remainder of the original Warranty Period and is subject to the same limitations and exclusions. If a material non-conformance is incapable of correction, or if D-Link determines in its sole discretion that it is not practical to replace the non-conforming Software, the price paid by the original licensee for the non-conforming Software will be refunded by D-Link; provided that the non-conforming Software (and all copies thereof) is rst returned to D-Link. The license granted respecting any Software for which a refund is given automatically terminates.

Non-Applicability of Warranty:

The Limited Warranty provided hereunder for Hardware and Software portions of D-Link’s products will not be applied to and does not cover any refurbished product and any product purchased through the inventory clearance or liquidation sale or other sales in which D-Link, the sellers, or the liquidators expressly disclaim their warranty obligation pertaining to the product and in that case, the product is being sold “As-Is” without any warranty whatsoever including, without limitation, the Limited Warranty as described herein, notwithstanding anything stated herein to the contrary.

Submitting A Claim:

The customer shall return the product to the original purchase point based on its return policy. In case the return policy period has expired and the product is within warranty, the customer shall submit a claim to D-Link as outlined below:

• The customer must submit with the product as part of the claim a written description of the Hardware defect or Software nonconformance in sucient detail to allow D-Link to conrm the same, along with proof of purchase of the product (such as a copy of the dated purchase invoice for the product) if the product is not registered.

• The customer must obtain a Case ID Number from D-Link Technical Support (USA 1-877-453-5465 or Canada 1-800-361-5265), who will attempt to assist the customer in resolving any suspected defects with the product. If the product is considered defective, the customer must obtain a Return Material Authorization (“RMA”) number by completing the RMA form. Enter the assigned Case ID Number at https://rma.dlink.com/ (USA only) or https://rma.dlink.ca (Canada only).

80D-Link DAP-2310 User Manual

Appendix E - Warranty

• After an RMA number is issued, the defective product must be packaged securely in the original or other suitable shipping package to ensure that it will not be damaged in transit, and the RMA number must be prominently marked on the outside of the package. Do not include any manuals or accessories in the shipping package. D-Link will only replace the defective portion of the product and will not ship back any accessories.

• The customer is responsible for all in-bound shipping charges to D-Link. No Cash on Delivery (“COD”) is allowed. Products sent COD will either be rejected by D-Link or become the property of D-Link. Products shall be fully insured by the customer and shipped to D-Link Systems, Inc.

• USA residents send to 17595 Mt. Herrmann, Fountain Valley, CA 92708. D-Link will not be held responsible for any packages that are lost in transit to D-Link. The repaired or replaced packages will be shipped to the customer via UPS Ground or any common carrier selected by D-Link. Return shipping charges shall be prepaid by D-Link if you use an address in the United States, otherwise we will ship the product to you freight collect. Expedited shipping is available upon request and provided shipping charges are prepaid by the customer. D-Link may reject or return any product that is not packaged and shipped in strict compliance with the foregoing requirements, or for which an RMA number is not visible from the outside of the package. The product owner agrees to pay D-Link’s reasonable handling and return shipping charges for any product that is not packaged and shipped in accordance with the foregoing requirements, or that is determined by D-Link not to be defective or non-conforming.

• Canadian residents send to D-Link Networks, Inc., 2525 Meadowvale Boulevard Mississauga, Ontario, L5N 5S2 Canada. D-Link will not be held responsible for any packages that are lost in transit to D-Link. The repaired or replaced packages will be shipped to the customer via Purolator Canada or any common carrier selected by D-Link. Return shipping charges shall be prepaid by D-Link if you use an address in Canada, otherwise we will ship the product to you freight collect. Expedited shipping is available upon request and provided shipping charges are prepaid by the customer. D-Link may reject or return any product that is not packaged and shipped in strict compliance with the foregoing requirements, or for which an RMA number is not visible from the outside of the package. The product owner agrees to pay D-Link’s reasonable handling and return shipping charges for any product that is not packaged and shipped in accordance with the foregoing requirements, or that is determined by D-Link not to be defective or non-conforming. RMA phone number: 1-800-361-5265 Hours of Operation: Monday-Friday, 9:00AM – 9:00PM EST

What Is Not Covered:

The Limited Warranty provided herein by D-Link does not cover: Products that, in D-Link’s judgment, have been subjected to abuse, accident, alteration, modication, tampering, negligence, misuse, faulty installation, lack of reasonable care, repair or service in any way that is not contemplated in the documentation for the product, or if the model or serial number has been altered, tampered with, defaced or removed; Initial installation, installation and removal of the product for repair, and shipping costs; Operational adjustments covered in the operating manual for the product, and normal maintenance; Damage that occurs in shipment, due to act of God, failures due to power surge, and cosmetic damage; Any hardware, software, rmware or other products or services provided by anyone other than D-Link; and Products that have been purchased from inventory clearance or liquidation sales or other sales in which D-Link, the sellers, or the liquidators expressly disclaim their warranty obligation pertaining to the product.

81D-Link DAP-2310 User Manual

Appendix E - Warranty

While necessary maintenance or repairs on your Product can be performed by any company, we recommend that you use only an Authorized D-Link Service Oce. Improper or incorrectly performed maintenance or repair voids this Limited Warranty.

Disclaimer of Other Warranties:

EXCEPT FOR THE LIMITED WARRANTY SPECIFIED HEREIN, THE PRODUCT IS PROVIDED “AS-IS” WITHOUT ANY WARRANTY OF ANY KIND WHATSOEVER INCLUDING, WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.

IF ANY IMPLIED WARRANTY CANNOT BE DISCLAIMED IN ANY TERRITORY WHERE A PRODUCT IS SOLD, THE DURATION OF SUCH IMPLIED WARRANTY SHALL BE LIMITED TO THE DURATION OF THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE. EXCEPT AS EXPRESSLY COVERED UNDER THE LIMITED WARRANTY PROVIDED HEREIN, THE ENTIRE RISK AS TO THE QUALITY, SELECTION AND PERFORMANCE OF THE PRODUCT IS WITH THE PURCHASER OF THE PRODUCT.

Limitation of Liability:

TO THE MAXIMUM EXTENT PERMITTED BY LAW, D-LINK IS NOT LIABLE UNDER ANY CONTRACT, NEGLIGENCE, STRICT LIABILITY OR OTHER LEGAL OR EQUITABLE THEORY FOR ANY LOSS OF USE OF THE PRODUCT, INCONVENIENCE OR DAMAGES OF ANY CHARACTER, WHETHER DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL (INCLUDING, BUT NOT LIMITED TO, DAMAGES FOR LOSS OF GOODWILL, LOSS OF REVENUE OR PROFIT, WORK STOPPAGE, COMPUTER FAILURE OR MALFUNCTION, FAILURE OF OTHER EQUIPMENT OR COMPUTER PROGRAMS TO WHICH D-LINK’S PRODUCT IS CONNECTED WITH, LOSS OF INFORMATION OR DATA CONTAINED IN, STORED ON, OR INTEGRATED WITH ANY PRODUCT RETURNED TO D-LINK FOR WARRANTY SERVICE) RESULTING FROM THE USE OF THE PRODUCT, RELATING TO WARRANTY SERVICE, OR ARISING OUT OF ANY BREACH OF THIS LIMITED WARRANTY, EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE FOREGOING LIMITED WARRANTY IS REPAIR, REPLACEMENT OR REFUND OF THE DEFECTIVE OR NONCONFORMING PRODUCT. THE MAXIMUM LIABILITY OF D-LINK UNDER THIS WARRANTY IS LIMITED TO THE PURCHASE PRICE OF THE PRODUCT COVERED BY THE WARRANTY. THE FOREGOING EXPRESS WRITTEN WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ANY OTHER WARRANTIES OR REMEDIES, EXPRESS, IMPLIED OR STATUTORY.

Governing Law:

This Limited Warranty shall be governed by the laws of the State of California. Some states do not allow exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the foregoing limitations and exclusions may not apply. This Limited Warranty provides specic legal rights and you may also have other rights which vary from state to state.

Trademarks:

D-Link is a registered trademark of D-Link Corporation/D-Link Systems, Inc. Other trademarks or registered trademarks are the property of their respective owners.

No part of this publication or documentation accompanying this product may be reproduced in any form or by any means or used to make any

82D-Link DAP-2310 User Manual

Appendix E - Warranty

derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems, Inc., as stipulated by the United States Copyright Act of 1976 and any amendments thereto. Contents are subject to change without prior notice.

CE Mark Warning:

This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Caution: Any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

For operation within 5.15 ~ 5.25GHz frequency range, it is restricted to indoor environment.

802.11g operation of this product in the U.S.A. is rmware-limited to channels 1 through 11.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

83D-Link DAP-2310 User Manual

Appendix E - Warranty

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Industry Canada Statement

This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions:

1) this device may not cause interference and

2) this device must accept any interference, including interference that may cause undesired operation of the device This device has been designed to operate with an antenna having a maximum gain of 2dBi. Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50ohms.

To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the EIRP is not more than required for successful communication.

Caution:

The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel mobile satellite systems.

Because high power radars are allocated as primary users (meaning they have priority) in 5250-5350 MHz and 5650-5850 MHz, these radars could cause interference and/or damage to license exempt LAN devices.

IMPORTANT NOTE:

IC Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

The availability of some specic channels and/or operational frequency bands are country dependent and are rmware programmed at the factory to match the intended destination. The rmware setting is not accessible by the end user.

For detailed warranty information applicable to products purchased outside the United States, please contact the corresponding local D-Link oce.

84D-Link DAP-2310 User Manual

Appendix F - Registration

Registration

Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights.

Version 1.0

October 3, 2011

85D-Link DAP-2310 User Manual

D-Link dap-2310 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Product Overview

Package Contents

System Requirements

Introduction

Features

Wireless Basics

Standards-Based Technology

Wireless Installation Considerations

Hardware Overview

LEDs

Hardware Overview

Connections

Four Operational Modes

Getting Started

Save and Activate Settings

Basic Settings

Wireless

Access Point mode

WDS with AP mode

WDS mode

Wireless Client mode

Open System/Shared Key Authentication

WPA/WPA2-Personal Authentication

WPA/WPA2-Enterprise Authentication

802.1x Authentication

Advanced Settings

Performance

Multi-SSID

VLAN

VLAN List

Port List

Add/Edit VLAN

PVID Setting

Intrusion

Schedule

AP Array

Wireless Basic Settings

Wireless Advanced Settings

Multiple SSID & VLAN

Advanced Functions

Administration Settings

DHCP Server

Dynamic Pool Settings

Static Pool Setting

Current IP Mapping List

Filters

Wireless MAC ACL

WLAN Partition

Status

Device Information

Client Information

WDS Information

Stats

Ethernet

View Log

Log Settings

Maintenance

Administration Settings

Limit Administrator

System Name Settings

Login Settings

Console Settings

SNMP Settings

Time and Date

System

System Settings

Help

Troubleshooting

Networking Basics

Check your IP address

Statically Assign an IP address

Contacting Technical Support

Warranty

Registration
