Tube Preamp/Effects Processor & Controller
Please visit Digitech Electronics on the World Wide Web at http://www.digitech.com
User’s Guide
WARNING
FOR YOUR PROTECTION, PLEASE READ THE FOLLOWING:
WATER AND MOISTURE: Appliance should not be used near water (e .g. near a bathtub,
washbowl,kitchen sink, laundry tub,in a wet basement, or near a swimming pool, etc). Care
should be taken so that objects do not fall and liquids are not spilled into the enclosure
through openings.
POWER SOURCES: The appliance should be connected to a power supply only of the
type described in the operating instructions or as marked on the appliance.
GROUNDING ORPOLARIZATION: Precautions should be taken so that the grounding
or polarization means of an appliance is not defeated.
POWER CORD PROTECTION: Power supply cords should be routed so that they are
not likely to be walked on or pinched by items placed upon or against them, paying particular
attention to cords at plugs,convenience receptacles, and the point where they exit from the
appliance.
SERVICING: To reduce the risk of fire or electric shock, the user should not attempt to
service the appliance beyond that described in the operating instructions. All other servicing
should be referred to qualified service personnel.
FOR UNITS EQUIPPED WITH EXTERNALLY ACCESSIBLE FUSE
RECEPTACLE: Replace fuse with same type and rating only.
SAFETY INSTRUCTIONS
NOTICE FOR CUSTOMERS IF YOUR UNIT IS EQUIPPED WITH A
POWER CORD.
WARNING:THIS APPLIANCE MUST BE EARTHED.
The cores in the mains lead are coloured in accordance with the following code:
GREEN and YELLOW - Earth BLUE - Neutral BROWN - Live
As colours of the cores in the mains lead of this appliance may not correspond with
the coloured markings identifying the terminals in your plug,proceed as follows:
• The core which is coloured green and yellow must be connected to the
terminal in the plug marked with the letter E,or with the ear th symbol, or
coloured green,or green and yellow.
• The core which is coloured blue must be connected to the terminal marked N
or coloured black.
• The core which is coloured brown must be connected to the terminal marked
L or coloured red.
This equipment may require the use of a different line cord,attachment plug, or both,
depending on the available power source at installation. If the attachment plug needs
to be changed,refer servicing to qualified service personnel who should refer to the
table below. The green/yellow wire shall be connected directly to the unit's chassis.
WARNING: If the ground is defeated,cer tain fault conditions in the unit or in the
system to which it is connected can result in full line voltage between chassis and
earth ground.Severe injury or death can then result if the chassis and earth ground are
touched simultaneously.
Line
Neutral
Earth Grnd.
CONDUCTOR
L
N
Brown
Blue
Green/Yel.
Black
WIRE COLOR
White
Green
U.K. MAINS PLUG WARNING
A moulded mains plug that has been cut off from the cord is unsafe.Discard the mains
plug at a suitable disposal facility.NEVER UNDER ANY CIRCUMSTANCES
SHOULD YOU INSERT A DAMAGED OR CUT MAINS PLUG INTO A 13
AMP POWER SOCKET. Do not use the mains plug without the fuse cover in place.
Replacement fuse covers can be obtained from your local retailer. Replacement fuses
are 13 amps and MUST be ASTA approved to BS1362.
The symbols shown above are internationally accepted symbols that warn of potential
hazards with electrical products.The lightning flash with arrowpoint in an equilateral
triangle means that there are dangerous voltages present within the unit.The
exclamation point in an equilateral triangle indicates that it is necessary for the user to
refer to the owner’s manual.
These symbols warn that there are no user serviceable parts inside the unit. Do not
open the unit.Do not attempt to service the unit yourself. Refer all servicing to
qualified personnel.Opening the chassis for any reason will void the manufacturer’s
warranty. Do not get the unit wet. If liquid is spilled on the unit, shut it off immediately
and take it to a dealer for service. Disconnect the unit during storms to prevent
damage.
CAUTION
ATTENTION: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
RISK OF ELECTRIC SHOCK
DO NOT OPEN
LITHIUM BATTERY WARNING
CAUTION!
This product may contain a lithium battery.There is danger of explosion if the battery is
incorrectly replaced.Replace only with an Eveready CR 2032 or equivalent.Make sure
the battery is installed with the correct polarity.Discard used batteries according to
manufacturer’s instructions.
ADVARSEL!
Lithiumbatteri - Eksplosjonsfare.Ved utskifting benyttes kun batteri som anbefalt av
apparatfabrikanten. Brukt batteri returneres apparatleverandøren.
ADVARSEL!
Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med
batteri av samme fabrikat og type.Levér det brugte batteri tilbage til leverandøren.
VAROITUS!
Paristo voi räjähtää,jos se on virheellisesti asennettu.Vaihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppin.Hävitä käytetty paristo valmistajan ohjeiden
mukaisesti.
VARNING!
Explosionsfara vid felaktigt batteribyte. Använd samma batterityp eller en ekvivalent typ
som rekommenderas av apparattillverkaren. Kassera använt batteri enligt fabrikantens
instruktion.
ELECTROMAGNETIC COMPATIBILITY
This unit conforms to the Product Specifications noted on the Declaration of
Conformity.Operation is subject to the following two conditions:
• this device may not cause harmful interference,and
• this device must accept any interference received, including interference that
may cause undesired operation. Operation of this unit within significant electromagnetic fields should be avoided.
• use only shielded interconnecting cables.
DECLARATION OF CONFORMITY
Manufacturer’s Name: Digitech Electronics
Manufacturer’s Address: 8760 S. Sandy Parkway
Sandy, Utah 84070, USA
declares that the product:
Product Name: RP-7 Valve
Product Options: All
conforms to the following Product Specifications:
Safety: EN 60065 (1993)
IEC 65 (1985) with Amendments 1, 2 & 3
EMC: EN 55013 (1990)
EN 55020 (1991)
Supplementary Information:
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC and EMC
Directive 89/336/EEC as amended by Directive 93/68/EEC.
Digitech
President of Digitech
8760 S. Sandy Parkway
Sandy, Utah 84070, USA
Tel: 801.566.8800
Fax: 801.566.7005
Effective October 15, 1997
European Contact: Your Local Digitech Sales and Service Office or
International Sales Office
3 Overlook Drive #4
Amherst, New Hampshire 03031, USA
Tel: 603.672.4244
Fax: 603.672.4246
RP-7 Valve
User Guide
I
Quick Start
For those of you who prefer to burn now and read later, we've included this Quick Start section to get you up and running.
Connect Cables:
Connect guitar into the Input jack (located on the rear of the RP-7 Valve). Now run from the Output of the RP-7 Valve to the Input of the
either the Guitar Amp, Power Amp or Mixing board.
Apply Power:
Note: When applying power to the RP-7 Valve, it is recommended that the <Output> knob be turned down prior to powering up the unit.
Adjust Output:
Now adjust the <Output > level knob on the rear panel of the RP-7 Valve to the desired output level.
Adjust Presence:
The <Presence> knob will act as a quick EQ. Use this knob to fine-tune your tone by turning clockwise (Brighter tone) or counter-clockwise
(Darker tone).
Select Preset:
Begin playing your guitar, and choose any preset by either pressing the <Program UP> or the <Program Down> buttons or by pressing the
bank <Up> and bank <Down> footswitches.
Jam-Along and Learn-A-Lick:
The RP-7 Valve will let you run a CD or Cassette tape signal into the signal of the RP-7 Valve so that you can play along with the music and even
use the Learn-A-Lick function for recording and playing back selected pieces of music. This can be done by simply running the CD or Cassette
headphone output into the Jam-Along jack (located on the rear of the RP-7 Valve).
RP-7 Valve
User Guide
II
Table of Contents
Safety Information
Declaration of Conformity................................................................i
Quick Start........................................................................................ii
Table of Contents ............................................................................iii
Section 1 - Introduction
Congratulations................................................................................1
Included Items..................................................................................1
Product Features ..............................................................................1
Warranty ..........................................................................................2
A Quick Tour of the RP-7 Valve....................................................3
The Front Panel............................................................................3
The Rear Panel..............................................................................5
Section 2 - Setting Up
Making Connections ......................................................................6
RP-7 Valve into Combo Amplifiers ..............................................6
RP-7 Valve direct into a Mixer......................................................7
Section 3 - Basic Operations
About the RP-7 Valve’s Modes ......................................................8
Program Mode..............................................................................8
Bank Mode ..................................................................................8
Edit Mode ....................................................................................8
Store Mode ..................................................................................8
Bypass Mode ................................................................................9
Tuner Mode..................................................................................9
Learn-A-Lick Mode........................................................................9
Section 4 - Effects and Parameters
About the Parameter Matrix ............................................................10
Compressor......................................................................................10
Expression Pedal ..............................................................................10
Preamp..............................................................................................11
Noise Gate........................................................................................12
Equalization......................................................................................12
Wah Wah ..........................................................................................13
Mod/Pitch..........................................................................................13
Chorus..............................................................................................14
Flanger..............................................................................................14
Phaser ..............................................................................................15
Tremolo............................................................................................15
Panner ..............................................................................................16
Pitch Shifter ......................................................................................16
Pitch Bending (Whammy) ................................................................16
Harmony ..........................................................................................17
Dual Delay........................................................................................18
Reverb ..............................................................................................19
Speaker Cabinet Emulator ..............................................................20
Master Volume..................................................................................20
Section 5 - Appendix
Resetting and Re-Calibrating the RP-7 Valve ..................................21
Harmony Interval Charts..............................................................21
Specifications................................................................................22
Preset List ....................................................................................23
RP-7 Valve
User Guide
III
RP-7 Valve
User Guide
IV
Section-1 Introduction
Congratulations...
... you are now the proud owner of a Digitech RP-7 Valve Guitar Preamp/Processor. The RP-7 Valve offers you 4 Tube and 4 Solid State preamp voicings
along with a full palette of studio quality digital effects that can accommodate any style of music. The RP-7 Valve also features the Jam-Along jack for CD
insert and the Learn-A-Lick mode that allows you to sample the incoming music then replay it at 1/2 speed, making the RP-7 Valve a priceless tool.
This owner's manual is your key to understanding the powerful world of the RP-7 Valve. Read it carefully. After you've had time to familiarize yourself
with the unit, try experimenting with unusual effect combinations. You are certain to achieve sounds never thought possible before. Good luck, and
thank you for choosing Digitech.
Your RP-7 Valve was carefully assembled and packaged at the factory. Before you proceed any further, make sure the following items are included:
• (1) Owner’s Manual
• (1) Digitech RP-7 Valve Guitar Preamp/Processor
• (1)Power Supply
• (1) Digitech warranty card
Please save all packing materials. They were designed to protect the unit from damage during shipping. In the unlikely event that the unit requires
service, use only the factory supplied carton to return the unit.
RP-7 Valve
User Guide
Section -1 Introduction
1
RP-7 Valve Features:
• Tube and Solid State Distortions
• Built-in Expression Pedal
• Tube Preamp (12AX7)
• Full bandwidth effects (20-20kHz)
• 24-bit signal path, 48-bit internal data path
• S-DISC II ® Processing
• Harmony Effects
• Jam-Along Jack
• Learn-A-Lick Function
• Programmable Speaker Cabinet Emulator
• Chromatic tuner
• Compact floor design chassis
We at Digitech are very proud of our products and back-up each one we sell with the following warranty:
1. The warranty registration card must be mailed within ten days after purchase date to validate this warranty.
2. Digitech warrants this product, when used solely within the U.S., to be free from defects in materials and workmanship under normal
use and service.
3. Digitech liability under this warranty is limited to repairing or replacing defective materials that show evidence of defect, provided the
product is returned to Digitech WITH RETURN AUTHORIZATION, where all parts and labor will be covered up to a period of one year. A
Return Authorization number may be obtained from Digitech by telephone. The company shall not be liable for any consequential
damage as a result of the product's use in any circuit or assembly.
4. Proof-of-purchase is considered to be the burden of the consumer.
5. Digitech reserves the right to make changes in design, or make additions to, or improvements upon this product without incurring any
obligation to install the same on products previously manufactured.
6. The consumer forfeits the benefits of this warranty if the product's main assembly is opened and tampered with by anyone other than a
certified Digitech technician or, if the product is used with AC voltages outside of the range suggested by the
manufacturer.
7. The foregoing is in lieu of all other warranties, expressed or implied, and Digitech neither assumes nor authorizes any person to assume
any obligation or liability in connection with the sale of this product. In no event shall Digitech or its dealers be liable for special or
consequential damages or from any delay in the performance of this warranty due to causes beyond their control.
Digitech™, S-DISCII™, Whammy™, and Silencer II™ are registered trademarks of the Harman Music Group Incorporated.
NOTE: The information contained in this manual is subject to change at any time without notification. Some information contained in this
manual may also be inaccurate due to undocumented changes in the product or operating system since this version of the manual was
completed. The information contained in this version of the owner's manual supersedes all previous versions.
Section -1 Introduction
RP-7 Valve
User Guide
2
A Quick Tour of the RP-7 Valve
The Front Panel
1) Pedalboard - The RP-7 Valve’s pedalboard consists of six footswitches. The two Mode footswitches to the right of the Parameter Matrix
allow you to change from Program mode to Bank mode by pressing the <UP> & <DOWN> footswitches simultaneously. When changing
modes, the appropriate LED will light to indicate whether you are in Program mode or Bank Mode. In Program Mode, the <UP> and
<DOWN> footswitches allow you to move through Programs, while the four main switches, labeled <1 - 4>, act as toggle On/Off
switches for Distortion, Modulation, Delay, and Reverb. In Bank mode, the <UP> and <DOWN> footswitches allow you to move through
Banks, while the <1-4> footswitches are used to select Programs. If footswitches 1 and 2 are pressed simultaneously, Tuner Mode will be
activated. If footswitches <3> and <4> are pressed simultaneously, Bypass Mode will be activated.
2) Parameter Matrix - The Parameter Matrix consists of a group of horizontal Effect LEDs and a second group of vertical Parameter LEDs.
The Effect LEDs are: Compressor, Preamp, Equalization, Noise Gate, Wah Wah, Mod/Pitch, Dual Delay, Reverb, and Speaker Cab. This
matrix shows you exactly what Effects and Parameters are in use.
3) Display Window - The display window shows all current operating and programming information and is comprised of two parts: the
seven segment LED displays and the Signal, Clip, and Store indicator LEDs. The first one numeric LED in the display window indicates
whether you are in a User (U) or Factory Bank (F). The second and third LEDs indicates the Bank number currently in use, and the fourth
indicates which Program number is currently in use. These numbers change as you scroll through the available Programs. The functions of
the Signal, Clip, and Store indicator LEDs are as follows:
• Signal - Indicates whether a signal is entering the RP-7 Valve.
• Clip - Indicates analog clipping in the RP-7 Valve. Digital clipping can be detected when the third vertical LED from the top of the
Parameter Matrix flashes. Distortion may be heard in the output signal if either analog or digital clipping occurs. If analog clipping occurs,
check the Preamp On/Off levels. The levels may need to be lowered to eliminate the problem. To reduce digital clipping, the Master
PARAMETER
SELECT
VALUE
EditStore
COMPRESSOR
On/Bypass
Amount
On/Bypass
Type
Gain
On Level
Bypass Level
On/Bypass
Type
On/Bypass
Position (EP1)
Type
On/Bypass
Type Type
Level (EP4)
Amount (EP5)
Key (EP6)
Whammy (EP7)
On/Bypass
Level (EP8)
Time 1
Time 2
Fback (EP9)
On/Bypass
Type
Level (EP10)
Decay
PREAMP
SPEAKER CAB
WAH MOD/PITCH DUAL DELAY REVERB
On/Bypass
Low Gain
Mid Freq
Mid Gain
High Freq
High Gain
EQUALIZER
On/Bypass
Threshold
Attack Time
GATE/SWELL
Speed (EP2)
Depth (EP3)
Dly/Regen
VOLUME
Pre/Post
IN TUNE
EXP PEDAL
Link (EP #)
Max Value
Min Value
BANK PGM
#
STORE
SIGNAL
CLIP
Level (EP11)
8888
24567 81
3
RP-7 Valve
User Guide
Section -1 Introduction
3
Volume and/or Effects levels should be checked and adjusted accordingly. As always, let your ears be the judge.
• Store - Lights when a Parameter has been changed in a Program. When the <STORE> button is pressed once, the first seven segment LED
in the Display window will flash. Once you have selected the Bank and Program location where you want to store your effects, press the
<STORE> button again (see page 8, under Edit Mode for further information on storing a Program).
4) Value, Store and Edit Buttons - The Value <UP> and <DOWN> buttons allow you to scroll through the RP-7 Valve’s Programs, or
change Parameter values in Edit mode. The <STORE> button allows you to store an edited Program in memory for later use. The <EDIT>
button allows you to edit the User and Factory Programs.
5) Parameter Select Buttons -The <LEFT> and <RIGHT> Parameter buttons allow you to navigate the horizontal Effect LEDs of the
Parameter matrix. The <UP> and <DOWN> Parameter buttons allow you to navigate the vertical Parameter LEDs of the Parameter matrix.
These keys are only active in Edit mode.
6) Output Level - Controls the overall output level of the RP-7 Valve. Also controls the overall level of the headphones.
7) Presence - Enhances the high frequency content of the overall sound. This will affect all presets.
8) Expression Pedal - This volume-type pedal allows real time control over Parameters in the RP-7 Valve.
Section 1 Introduction
RP-7 Valve
User Guide
4
The Rear Panel
1) Jam-Along Jack- This is the Jam-Along Jack connection of the RP-7 Valve. Connect output of CD or Cassette player here. This is also the
insert point for music that is to be used in the Lear-A-Lick mode.
2) Input - This is the RP-7 Valve’s audio input. Plug your guitar in here.
3) Headphone Output - 1/4” stereo plug for headphones. The headphone level is controlled by the main output
level knob.
4) Left/Mono Main Output - This is the RP-7 Valve’s left main audio output. This output must be used if a mono effect
is desired.
5) Right Main Output - This is the RP-7 Valve’s right main audio output. Use both left and right main outputs to take
advantage of stereo effects.
6) AC Line Input - This is the AC adapter receptacle. Use only the included PS 0912 power supply.
INPUT
JAM-ALONG
RIGHT
OUTPUT
LEFT/MONO
OUTPUT
HEADPHONES
POWER
9VAC 1.33A
23
4
5
6
1
RP-7 Valve
User Guide
Section -1 Introduction
5
Section-2 Setting Up
Making Connections
Your RP-7 Valve can be connected in several different ways to meet the requirements of specific applications. The following diagrams offer
some different ways your RP-7 Valve can be connected.
RP-7 Valve into two 2X12 Combo Amplifiers
For those of you out there that feel that “bigger is better”, this set-up should work quite nicely for you. First plug into the input of the RP-7
Valve. Connect both RP-7 Valve outputs into the inputs of both of the amplifiers. Using a set-up such as this will let you produce guitar tones
with lots of body. This is also a great set-up to produce lush and thick stereo effects.
Input
PARAMETER
SELECT
VALUE
EditStore
DISTORTION MOD/PITCH DELAY REVERB
BYPASSTUNER
COMPRESSOR
On/Bypass
Amount
On/Bypass
Type
Gain
On Level
Bypass Level
On/Bypass
Type
On/Bypass
Position (EP1)
Type
On/Bypass
Type Type
Level (EP4)
Amount (EP5)
Key (EP6)
Whammy (EP7)
On/Bypass
Level (EP8)
Time 1
Time 2
Fback (EP9)
On/Bypass
Type
Level (EP10)
Decay
PREAMP
SPEAKER CAB
WAH MOD/PITCH DUAL DELAY REVERB
On/Bypass
Low Gain
Mid Freq
Mid Gain
High Freq
High Gain
EQUALIZER
On/Bypass
Threshold
Attack Time
GATE/SWELL
Speed (EP2)
Depth (EP3)
Dly/Regen
VOLUME
Pre/Post
IN TUNE
EXP PEDAL
Link (EP #)
Max Value
Min Value
BANK PGM
#
STORE
SIGNAL
CLIP
Level (EP11)
8888
Section -2 Setting Up
RP-7 Valve
User Guide
6
Running Direct into a Mixer
The RP-7 Valve provides you with a speaker cabinet emulator for running direct to a mixing board.
A set-up such as this, will give you the ability to run directly to the mixing/recording board to help ensure great recording tones by using the
Speaker Cabinet emulator that is located in the RP-7 Valve. The first thing you will want to do when using this set-up is, first run into the Input
of the RP-7 Valve. Then run out of both of the Outputs into the Mixing board. Now, to use the Speaker Cabinet Emulator, simply press the
<Edit> button and then use the <Parameter Select> buttons to move you through the Effects matrix until you reach the Speaker Cabinet
Emulator effect. The <Parameter Select> buttons and the <Value> buttons will help you fine-tune the Speaker Cabinet emulator.
Pan
Mute
-10
0
+5
+10
-20
-30
-∞
-5
L / R
Mute
L / R
Mute
L / R
Mute
L / R
-5
-4
-3
-2
-10+1
+2
+3
+4
+5
Pan
-5
-4
-3
-2
-10+1
+2
+3
+4
+5
Pan
-5
-4
-3
-2
-10+1
+2
+3
+4
+5
Pan
-5
-4
-3
-2
-10+1
+2
+3
+4
+5
Pan
-5
-4
-3
-2
-10+1
+2
+3
+4
+5
Pan
-5
-4
-3
-2
-10+1
+2
+3
+4
+5
Pan
-5
-4
-3
-2
-10+1
+2
+3
+4
+5
Pan
-5
-4
-3
-2
-10+1
+2
+3
+4
+5
1234
-10
0
+5
+10
-20
-30
-∞
-5
-10
0
+5
+10
-20
-30
-∞
-5
-10
0
+5
+10
-20
-30
-∞
-5
Mute
L / R
5
-10
0
+5
+10
-20
-30
-∞
-5
Mute
L / R
6
-10
0
+5
+10
-20
-30
-∞
-5
Mute
L / R
7
-10
0
+5
+10
-20
-30
-∞
-5
Aux 1
0
2
46
8
10
Aux 2
0
2
46
8
10
Aux 1
0
2
46
8
10
Aux 2
0
2
46
8
10
Aux 1
0
2
46
8
10
Aux 2
0
2
46
8
10
Aux 1
0
2
46
8
10
Aux 2
0
2
46
8
10
Aux 1
0
2
46
8
10
Aux 2
0
2
46
8
10
Aux 1
0
2
46
8
10
Aux 2
0
2
46
8
10
Aux 1
0
2
46
8
10
Aux 2
0
2
46
8
10
Aux 1
0
2
46
8
10
Aux 2
0
2
46
8
10
Mute
L / R
8
-10
0
+5
+10
-20
-30
-∞
-5
Left Output
Input
Right Output
PARAMETER
SELECT
VALUE
EditStore
DISTORTION MOD/PITCH DELAY REVERB
BYPASSTUNER
COMPRESSOR
On/Bypass
Amount
On/Bypass
Type
Gain
On Level
Bypass Level
On/Bypass
Type
On/Bypass
Position (EP1)
Type
On/Bypass
Type Type
Level (EP4)
Amount (EP5)
Key (EP6)
Whammy (EP7)
On/Bypass
Level (EP8)
Time 1
Time 2
Fback (EP9)
On/Bypass
Type
Level (EP10)
Decay
PREAMP
SPEAKER CAB
WAH MOD/PITCH DUAL DELAY REVERB
On/Bypass
Low Gain
Mid Freq
Mid Gain
High Freq
High Gain
EQUALIZER
On/Bypass
Threshold
Attack Time
GATE/SWELL
Speed (EP2)
Depth (EP3)
Dly/Regen
VOLUME
Pre/Post
IN TUNE
EXP PEDAL
Link (EP #)
Max Value
Min Value
BANK PGM
#
STORE
SIGNAL
CLIP
Level (EP11)
8888
RP-7 Valve
User Guide
Section -2 Setting Up
7
Section 3 - Basic Operations
About the RP-7 Valve’s Modes
The RP-7 Valve offers seven modes, allowing easy operation of the Effects and Parameters. The modes are as follows:
PROGRAM MODE
Allows you to scroll through the 40 Factory and User Programs by using the <UP> and <DOWN> buttons as well as the <UP>
and <DOWN> foot switches. Enter Program mode by pressing the <UP> and <DOWN> foot switches simultaneously until the Program LED
lights and a P appears briefly in the display window. Foot switches <1-4> act as on/off toggle switches for the specified effects.
BANK MODE
Allows you to scroll quickly through Factory and User Banks by using the <UP> and <DOWN> foot switches. Enter Bank mode by pressing
the <UP> and <DOWN> foot switches simultaneously until the Bank LED lights and a B appears briefly in the display window. When you
enter Bank mode, the Bank and Program numbers from the previous mode will be retained. When a Program number is displayed in the
display window, you can use the Value <UP> and <DOWN> buttons to scroll through Programs and Banks, exactly like Program mode.
When the <UP> and <DOWN> footswitches are used in Bank mode, you will scroll through Banks only. When you change a Bank using this
method, the previous Program number is not displayed with the new Bank. The LEDs above foot switches <1-4> will begin flashing, indicating
that you can choose a Program in the selected Bank by pressing one of the four foot switches. Once a Program number has been selected, both
the Bank and Program numbers will be displayed. Exit Bank mode by changing to another mode.
EDIT MODE
Allows you to modify effect Parameters in a Program. Enter Edit mode by pressing the <EDIT> button. The Display window now shows the
value of the Parameter indicated by the LEDs in the Matrix. You can scroll through the Parameter matrix using the Parameter Select buttons.
The <UP> and <DOWN> buttons allow you to scroll through the vertical Parameter LEDs, while the <LEFT> and <RIGHT> buttons allow
you to scroll through the horizontal Effect LEDs.
After selecting a Parameter, you can scroll through its values with the <UP> and <DOWN> Value buttons. When changing Parameter values, a
decimal point will flash in the display when the value is not the stored value for the program. The Store LED will light at this time as well. If
you return to the original value, the decimal point will stop flashing and the Store LED will go off. If you exit Edit mode after changing the
Parameters and then return to Edit mode, the last viewed Parameter will be displayed.
STORE MODE
Once you have modified the Parameters and Effects, you can store them to a user Program location. When you change an Effect or Parameter in
a Program, the Store LED will light, indicating that you have changed a Parameter and need to store the changes. Press the <STORE> button
once and the first seven segment LED in the Display window will flash U. Select the User Bank and Program location you want to store your
changes to, and press the <STORE> button again to save the changes.
Section -3 Basic Operations
RP-7 Valve
User Guide
8
BYPASS MODE
Allows you to bypass the RP-7 Valve’s Effects. Enter this mode by pressing footswitches <3 & 4> simultaneously. BYP will appear in the
display window to indicate you are in Bypass mode. Exit this mode by pressing any of the footswitches. When you exit this mode, the RP-7
Valve will default to the last mode you used.
TUNER MODE
Allows you to tune your guitar. Enter Tuner mode by pressing footswitches <1 & 2> simultaneously. tune will appear briefly in the display
window followed by
---
to indicate that you are in Tuner mode. To begin tuning play a note on your guitar (a harmonic at the 12th fret will
work best). The display window will show the note being played and the horizontal Parameter Matrix LEDs just under the tuning bar will light.
Once the green LED directly under the IN TUNE of the tuning bar is lit, the note will be in tune. If the note is not in tune, 1 or 2 of the LEDs
left or right of the IN TUNE LED will be lit. If they are to the left, the note is flat and should be tuned up. If the LEDs are to the right, the note
is sharp and should tuned down. You can change your tuning preference by using the value <UP> and <DOWN> buttons. The default
factory setting is : A=440 Hz. The tuning reference control ranges from 427 Hz to 453 Hz, which is the equivalent of ± 50 cents (1/2
semitone) in either direction form 440 Hz.
When you scroll down from 427 Hz, you will also find alternate dropped tunings. Alternate tunings are A = Ab (415), A = G (392), and A =
Gb (370). The display window will briefly flash the currently selected tuning preference.
Exit this mode by pressing any of the footswitches. When you exit this mode, the RP-7 Valve will default to the last mode you used.
LEARN-A-LICK MODE
The Learn-A-Lick function allows you to record a 12 second passage of music and play it back as slow as 1/2 speed with no change in pitch.
This is very useful for picking out the notes of a fast solo passage.
There are 4 functions for Learn-A-Lick. They include:
• Start / Stop
• Rewind
• Fast Forward
• Record
Using Learn-A-Lick
• Connect the output of your CD or tape player headphone output to the Jam-a-long input jack on the rear panel. Set the level to a desired
listening level.
• Press foot switches <2> and <3> to enter Learn-a-lick mode.
• Cue up to the passage you want to record and hit pause on the CD or tape player.
• Release the pause button and press the <4> foot switch when you are ready to begin recording the passage. The display will read:
rEC and recording will begin. When recording is completed, the phrase is then set into an auto-loop playback mode. Stop or press
pause on the CD or Tape player.
• Pressing the <Tempo Dn> foot switch will slow the playback down to 1/2 speed in 1/8th speed intervals.
• Pressing the <Tempo Up> foot switch will increase the playback speed to normal speed at 1/8th speed intervals.
• Pressing the <Rewind> foot switch steps back through the loop at 1 second intervals.
• Pressing the <F Forward> foot switch steps forward through the loop at 1 second intervals.
• The Expression pedal will control output level of auto loop.
• To re-record a passage, press the <Record> foot switch again.
• To exit the Learn-A-Lick mode, Press footswitches <2> and <3> at the same time.
RP-7 Valve
User Guide
Section - 3 Basic Operations
9
SECTION 4 - EFFECTS AND PARAMETERS
About the Parameter Matrix
The Parameter Matrix displays all the Effects and Parameters you can find in the RP-7 Valve. The Parameters are arranged in rows and columns.
Use the Parameter Select keys to navigate the matrix. The Effects and their Parameters are as follows:
The RP-7 Valve’s Compression can be used to increase sustain and to tighten up guitars, and is particularly useful on clean sounds.
Parameters of the RP-7 Valve compressor are as follows:
On / Bypass Turns the Compressor on or off.
Amount Controls the amount of compression applied to the signal. Higher settings yield a tighter, more focused
sound, while lower settings allow better dynamics. Ranges from 1-Lo to 78-Hi.
The RP-7 Valve’s Expression Pedal allows you to control various Parameters in real time during performance.
Link (EP) There are eleven Parameters that can be controlled by the Expression Pedal. These Parameters are
highlighted and labeled with parenthesis in the Parameter Matrix, indicating which EP link controls that
Parameter.
Max Value Sets the maximum value that the parameter assigned to the Expression Pedal will reach when the Pedal is
in the forward position. Range varies according to the parameter selected.
Min Value Sets the minimum value that the parameter assigned to the Expression Pedal will reach when the Pedal is
in the back position. Range varies according to the parameter selected.
Expression Pedal
Parameters
Displayed Values
Link (EP) OFF ... EP1 ... EP11
Max Value Parameter dependent
Min Value Parameter dependent
Compressor
Parameters
Displayed Values
On/Bypass On-byp
Threshold LO-1...78-HI
Section - 4 Effects and Parameters
RP-7 Valve
User Guide
10
The distortion section of the RP-7 Valve has six extremely flexible distortion types, capable of producing the smoothest of the blues tones to
the full shred gain of a cranked up stack.
On / Bypass Turns the Preamp on or off.
Type Selects the type of preamp voicing used. CLN1 is a warm clean tube tone, CLN2 is a bright clean tube
tone, BLUE is a bluesy distortion with moderate gain, SAT is a high gain tube distortion which is ideal
for soloing. On the solid state side, odr is a low to medium gain distortion, and Gru is an over the top
high gain distortion, HStn is a warm sustaining distortion, and FuZZ is a vintage full-frequency fuzz.
Gain Controls the amount of distortion produced by the RP-7 Valve. High settings produce greater gain and
drive for effortless soloing, while low settings offer better nuance and dynamic control. Ranges from 1 to
11.0.
Note: The Gain control parameter is not available in CLN 1 and CLN 2 preamp types.
On Level Sets the output level of the Distortion while the effect is ON. Ranges from -∞ to 12.
Off Level Sets the output level of the Distortion while the effect is OFF. Ranges from -∞to 12.
Preamp
Parameters
Displayed Values
On/Bypass On-byp
Gain 1...11
Type CLN1-CLN2-Blue-SAT-odr-Gru-Hstn-Fu22
On Level -oo...12
Off Level -oo...12
RP-7 Valve
User Guide
Section - 4 Effects and Parameters
11
The RP-7 Valve’s Silencer offers you a professional quality digital noise reduction effect.
On / Bypass Turns the Gate on or off.
Threshold Sets the level at which the Silencer™ gate will open. Ranges are Lo and High.
Attack Time Controls how fast the Silencer™ gate opens after detecting a signal above the threshold. Large numbers
yield slower attack times, while small numbers give a fast attack. Varies from 0 to 2000 milliseconds (2
seconds).
The RP-7 Valve offers a three band equalizer. The center frequency of the Mid and High bands is adjustable along with its gain (boost or
cut).
On / Bypass Turns the Gate on or off.
Mid, High Frequency Allows you to select the center frequency of the Mid and High bands. Mid Band ranges from 130 to
16.0 (130 Hz to 16 kHz). High Band ranges from 1000 to 16.0 (1.0 kHz to 16 kHz).
Low, Mid, High Gain Allows you to boost and cut the frequency. Ranges are from -15 to 15.
Equalizer
Parameters
Displayed Values
On/Bypass
Low Gain
Mid Freq
On-Byp
-15...0...15
130...5000
Mid Gain -15...0...15
High Freq 1000...1§0
High Gain -15...0...15
Gate/Swell
Parameters
Displayed Values
On/Bypass On-byp
Threshold LO-HI
Attack Time 0...100
Section - 4 Effects and Parameters
RP-7 Valve
User Guide
12
The RP-7 Valve offers a classic wah wah effect, which can be used with or without Distortion for that classic Wah-Wah sound. The effect’s
position can be controlled with the CC Pedal.
On / Off Turns the Module on and off.
Type The Wah Wah types include; 1. being full-range and 2 through 7 move from darker to lighter tones.
Position The PEDAL POSITION Parameter reflects the current setting of the continuous control device used to
control the wah effect. This Parameter can be modified manually using the RP-7 Valve’s Parameter keys
to perform the wah function. As the Parameter is modified, the tone of the original note will change.
Ranges 0 to 127.
Is the RP-7 Valve’s multi-function module, allowing you to select effects such as; Chorus, Flanger, Phaser, Tremolo, Panner, Pitch Shift,
Whammy™, and Harmony effect. The Parameters of these effects are adjusted in this module.
On / Bypass Turns the Module on or off.
Type Allows you to select a specific type of modulation/pitch effect. The Types are; Chorus, Flanger, Phaser,
Tremolo, Panning, Pitch Shifting, Whammy (Bend), and Harmony.
Level Controls the overall mix level of the mod or pitch shifting effect. Ranges from 0 to 100.
Mod/Pitch
Parameters
Displayed Values
On/Bypass
Type
Level (EP4)
On-byp
Chor
0...100
FLAn
0...100
PHAs
0...100
trE
0...100
PAn
0...100
Ptch
0...100
bend
0...100
Har
0...100
Wah Wah
Parameters
Displayed Values
On/Bypass On-byp
Type ?????
Position (EP1) 0...127
1...7
RP-7 Valve
User Guide
Section - 4 Effects and Parameters
13
The RP-7 Valve offers a chorus that is unique in both character and sound. This dual chorus offers exceptionally rich chorusing using
multiple voices with different phasing characteristics. Chorus Parameters are as follows:
Speed Controls the speed of the chorus sweep. Ranges from 0 to 100.
Depth This Parameter sets the sweep depth (intensity) of the chorus. Ranges from 0 to 100.
Delay Sets the amount of delay present in the chorus effect. Ranges from 0 to 100.
The RP-7 Valve also offers exceptionally rich studio-quiet flanging. Flange Parameters are as follows:
Speed Controls the speed of the flange sweep. Ranges from 0 to 100.
Depth Sets the depth amount and delay present in the flange effect. Ranges from 1 to 16.
Regeneration This Parameter sets the amount of regeneration which is perceived as the sweep depth (intensity) of the
flange. Variable from -99 to 99.
FLAn (Flanger)
Values Displayed Values
Speed (EP2) 0...100
Depth (EP3) 1...16
Regeneration -99...0...99
Chor (Chorus)
Values Displayed Values
Speed (EP2) 0...100
Depth (EP3) 0...100
Delay 0...100
Section - 4 Effects and Parameters
RP-7 Valve
User Guide
14
The RP-7 Valve’s classic adjustable phase shifting effect is reminiscent of mid-70’s keyboard and guitar sounds.
Speed Controls the speed of the phase sweep. Ranges from 0 to 100
Depth Sets the sweep depth (intensity) of the phaser. Ranges from 0 to 100.
Regeneration Controls the amount of phased sound fed back to the input of the Module. High regeneration settings
produce dramatic and interesting unnatural sounds. Ranges from 0 to 99.
Tremolo was one of the first real effects, and appeared mostly on early guitar amplifiers. Because of this, tremolo is sometimes perceived as
sounding “old” or “vintage”. The RP-7 Valve, breathes new life into this classic effect, providing totally transparent volume modulation of
sound sources.
Speed Controls the tremolo speed (speed of modulation). Ranges from 0 to 100.
Depth Adjusts the intensity of the tremolo effect. Ranges from 0 to 100.
trE (Tremolo)
Values Displayed Values
Speed (EP2) 0...100
Depth (EP3) 0...100
PHAs (Phaser)
Values Displayed Values
Speed (EP2) 0...100
Depth (EP3) 0...100
Regeneration 0...99
RP-7 Valve
User Guide
Section - 4 Effects and Parameters
15
An auto panner is a modern relative of the tremolo that modulates the sound from left to right at a given rate. Parameters are as follows:
Speed Controls the panning speed (speed of modulation). Ranges from 0 to 100
Depth Adjusts the intensity of the panning effect. Ranges from 0 to 100.
This RP-7 Valve’s Pitch Shifting effect gives you a shifted signal from 0 to 24 semi-tones above or below the pitch of the input signal.
Amount Sets the interval between the original note and the pitch shifted note. Variable from -24 to 24
Key Determines the amount of detuning applied to the shifted note. Variable from -99 to 99.
bEnd (Pitch Bending/Whammy)
Values Displayed Values
Amount (EP5) 1 ... 16
Not Available
Whammy (EP7) 0 ... 100
Ptch (Pitch Shifting)
Values Displayed Values
Amount (EP5) -24...0...24
Key (EP6) -99...0...99
PAn (Auto Panning)
Values Displayed Values
Speed (EP2) 0...100
Depth (EP3) 0...100
Section - 4 Effects and Parameters
RP-7 Valve
User Guide
16
The RP-7 Valve’s pitch bending effect allows you to smoothly shift between two preset pitch intervals using the CC Pedal.
Amount Selects the function of the Whammy™ Module. There are 16 functions available in regular Whammy
Modules. They are as follows:
1= Up 1 Octave 9=Down 1 Oct - Up 1 Oct
2=Up 2 Octaves 10=Down 4th - Down 3rd
3=Down 2nd Reversed 11=Up 5th - Up 6th
4=Down 2nd 12=Up 4th - Up 5th
5=Down 4th 13=Up m3rd - Up Maj 3rd
6=Down 1 Octave 14=Up 2nd - Up 3rd
7=Down 2 Octaves 15=Shallow Detune
8=Down 6 Octaves 16=Deep Detune
Whammy The Whammy Parameter reflects the current setting of the Whammy™ effect. This Parameter should be
linked to the RP-7 Valve’s CC pedal. As Position is modified, the pitch of the original note will change in
intervals according to the setting of the WHAMMY TYPE. Ranges from 0 to 100.
The RP-7 also offers intelligent harmony pitching that lets you select the key, scale and amount of shifting in the signal. The parameters are
as follows:
Amount Amount lets select how much the pitch is shifted. This Ranges from: -Octave down-Octave Up
Key This parameter lets you select which key the harmony shifting takes place in. This ranges from: A to G#.
Scale This parameter lets you select the scale that is being used in the Harmony effect. There are fourteen
different scales and they are numbered as follows: 1. Major 2. Minor 3. Harmonic Minor 4. Melodic
Minor 5. Dorian 6. Mixolydian 7. Lydian 8. Lydian Augmented 9. Major Pentatonic 10. Minor
Pentatonic 11. Blues 12. Whole Tone 13. Half-Whole Dimished 14. Whole-Half Dimished
Note: For complete reference guide to these scales, please refer to the Harmony interval charts located in the Appendix section on
page 21.
Har (Harmony)
Values Displayed Values
Amount (EP5) Octd... Octu
Key (EP6) a ... G#
o
Scale (EP7) 1 ... 14
RP-7 Valve
User Guide
Section - 4 Effects and Parameters
17
Delay times 1 & 2 can be programmed independently. However, On/Off, Type, Level, and Feedback will program the same for BOTH Delays
1 & 2. For example, if you choose to program your Level to 50, both Delays 1 & 2 will be 50. Delay Parameters are as follows:
On / Off Turns the Effect on and off.
Type Determines the type of delay. Type 1 is a mono delay, Types 2 through 4 are two tap mono delays, and
Types 5 through 7 are two tap stereo delays (see chart below for further information).
Level Controls the level of the delay in both Delay1 and Delay 2. Ranges from 0 to 100.
Delays 1 & 2 The available delay time ranges are 0 (no delay) to 3.5 seconds.
Feedback The amount of time it takes for the Reverb to fade to inaudibility. Ranges from 0 to 99.
Type:
1
2
3
4
5
6
7
Left Output:
Delay 1
Delays 1 & 2
Delays 1 & 2
Delays 1 & 2
Delay 1
Delay 1
Delay 1
Right Output:
Delay 1
Delays 1 & 2
Delays 1 & 2
Delays 1 & 2
Delay 2
Delay 2
Delay 2
Feedback Source:
Delay 1
Delay 1
Delay 2
Delays 1 & 2
Delay 1
Delay 2
Delays 1 & 2
Dual Delay
Parameters
Displayed Values
On/Off
Type
Level (Mix)
On-Byp
1...7
0...100
Delay 1 0...3500
Delay 2 0...3500
Feedback 0...99
Section - 4 Effects and Parameters
RP-7 Valve
User Guide
18
Ambience, or reverberation, is produced when sound energy is reflected off room surfaces and objects. Using reverb in recorded program
material gives the listener a sense that the material is being performed in an actual room or hall. It is this similarity to actual acoustic spaces
that makes reverberation a useful tool in recorded music. Reverb Parameters and their functions are as follows:
On / Bypass Turns the Reverb on or off.
Type Allows you to choose your ambience or setting you want to use. There are ten available type settings:
CLub=Club Garg=Garage
pLat=Plate HALL=Hall
SStg=Sound Stage Chur=Church
bAth=Bathroom ArEn=Arena
Stud=Studio SPrg=Spring
Level Controls the amount of reverb signal to be mixed in with the dry signal. Ranges from 0 to 100.
Decay Time The amount of time it takes for the Reverb to fade to inaudibility. Ranges from 1 to 10.
Reverb
Parameters
Displayed Values
On/Bypass
Type
Level
On-byp
CLub...SPrg
0...100
Decay Time 1...10
RP-7 Valve
User Guide
Section - 4 Effects and Parameters
19
The RP-7 Valve’s programmable Speaker Cabinet circuitry allows you to use it in both recording and live situations without lugging heavy
amps and/or cabinets around. Just connect the RP-7 Valve’s outputs to a mixing console and kick in the Speaker Cabinet. No miking hassles,
no heavy equipment, just full on miked cabinet sound. Programs can be stored with different Speaker Cabinet settings so you can customize
your Banks for whatever sound types you need. Parameters are as follows:
On / Bypass Turns the Speaker Cabinet Emulator on or off.
Cabinet Type Selects the tonal characteristics of the simulated cabinet. There are 10 different cabinet types; 1-3 are
warm cabinets, 4-6 are medium cabinets, 7-9 are bright cabinets, and 10 is a full bandwidth cabinet for
maximum frequency response.
Note: When headphones are plugged in, the Speaker Cabinet Emulator is engaged globally on all programs. This will affect the
sound at the left and right main outputs.
The RP-7 Valve’s Master Volume controls the overall volume level of the selected program. The level can be controlled with the CC
expression pedal for balancing levels in real-time during live performance. It is also useful to lower the overall digital effects level if clipping
occurs.
Pre/Post Selects whether the Volume pedal effect is pre-digital effects, allowing delays and reverbs to be heard
after the volume is pulled back, or post-digital effects, affecting all volume.
Level Controls the overall volume level. This can be done with the CC pedal or the Value keys. Variable from 0
to 100.
Volume
Parameters
Displayed Values
Pre/Post Pre-post
Level (EP11)
0-100
Speaker Cabinet Emulator
Parameters
Displayed Values
On/Bypass On-Byp
Type 1...10
Section - 4 Effects and Parameters
RP-7 Valve
User Guide
20
Section 5 - Appendix
Reinitializing the RP-7 Valve
This option allows you to restore the contents of the RP-7 Valve’s memory to the original factory condition and calibrate the expression pedal.
WARNING: Performing this function will destroy all user-programmed data. All such data will be lost forever!
To restore the factory Programs and calibrate the expression pedal, the procedure is as follows:
1. Plug in the RP-7 Valve while holding down the Parameter Select <UP> button.
2. When rSt appears in the display window, press the Value <UP> button. The Rp-7 will reset to factory condition.
3. The display will now prompt you to re-calibrate the expression pedal by reading: PEDl CAL
4. When the display reads: toe dn , rock the pedal forward and press any one of the flashing footswitches.
5. When the display reads: toe up , rock the pedal back and press any one of the flashing footswitches. The expression pedal will now
be calibrated and the RP-7 will return to program mode.
Re-calibrating the Expression Pedal
If the Expression Pedal calibration should fail, you can re-calibrate it by disconnecting the power, press and hold the parameter select
<Down> button and re-apply power. Release the button and repeat steps 3-5 as shown in the “Re-initializing the RP-7 “ section above.
Harmony Interval Charts
üOct
ü7th
ü6th
ü#5th
ü#4th
ü3rd
ü2nd
Ref
¨ı2nd
¨ı3rd
¨3rd
¨b5th
¨b6th
¨b7th
¨Oct
Lydian
Aug.
C
B
A
G#
F#
E
D
C
B
A
G#
F#
E
D
C
Int.
üOct
ü6th
ü5th
ü3rd
ü2nd
Ref
¨ı3rd
¨4th
¨ı6th
¨ı7th
¨Oct
Major
Pent.
C
A
G
E
D
C
A
G
E
D
C
Int.
üOct
üb7th
ü5th
ü4th
üı3rd
Ref
¨2nd
¨4th
¨5th
¨6th
¨Oct
Minor
Pent.
C
B b
G
F
E b
C
B b
G
F
E b
C
Int.
üOct
üı7th
ü5th
üı5th
ü4th
üı3rd
Ref Ref Ref Ref
¨2nd
¨4th
¨b5th
¨5th
¨6th
¨Oct
Blues
C
B b
G
F#
F
E b
C
B
G
F#
F
E b
C
¨7th ¨ı7th
Int.
¨ı5th
¨ı6th
¨ı7th
¨Oct
¨4th
¨ı5th
¨ı6th
¨6th
¨Oct
¨3rd
¨ı5th
¨5th
¨6th
¨Oct
üOct
üı7th
ü#5th
ü#4th
ü3rd
ü2nd
¨2nd
¨3rd
Whole
Tone
C
A#
G#
F#
E
D
C
A#
G#
Int.
üOct
üı7th
ü6th
ü5th
ü#4th
ü3rd
ü#2nd üı3rd
ü2nd
¨2nd
¨ı3rd
¨ı2nd
¨ı3rd
Hlf-Whl
Dim.
C
B b
A
G
F#
E
E b
D b
C
B b
A
Int.
üOct
ü6th
ü5th
üı6th
üı5th
ü4th
ü2nd
Whl-Hlf
C
B
A
G#
F#
F
E b
D
C
B
A
G#
F#
Int.
Dim.
F
E b
D
C
F#
E
D
C
G
F#
E
b
E
D b
C
üOct
ü7th
ü6th
ü5th
ü4th
ü3rd
ü2nd
Ref
¨2nd
¨3rd
¨4th
¨5th
¨6th
¨7th
¨Oct
Major
C
B
A
G
F
E
D
C
B
A
G
F
E
D
C
C
B b
A b
G
F
E b
D
C
B b
A b
G
F
E b
D
C
C
B
A b
G
F
E b
D
C
B
A b
G
F
E b
D
C
C
B
A
G
F
E b
D
C
B
A
G
F
E b
D
C
C
B b
A
G
F
E b
D
C
B b
A
G
F
E b
D
C
C
B b
A
G
F
E
D
C
B b
A
G
F
E
D
C
C
B
A
G
F#
E
D
C
B
A
G
F#
E
D
C
Minor Harm.Minor Mel.Minor Dorian Mixolydian LydianInterval
RP-7 Valve
User Guide
Section - 5 Appendix
21
Specifications
A/D Converter: 20 bit
D/A Converter: 20 bit
Sampling Frequency: 40 kHz
DSP Section:
Architecture: Static-Dynamic Instruction Set Computer (S-DISC™)
Digital Signal Path Width: 24 bits (144.5 dB)
Internal Data Path Width: 48 bits (289 dB)
Dynamic Delay Memory: 256k x 24 bits (3.5 seconds)
Static Delay Memory: 256 24-bit registers (6.55 milliseconds)
Data ALU Processing: 10.0 MIPS
Address ALU Processing: 15.0 MIPS
Multiplier Size: 24 bits x 24 bits
Tube Type:
(1) 12AX7
Plate Voltage: 100volts
Input Section:
Connector: 1/4” Unbalanced TRS
Nominal Level: -8 dBu
Maximum Level: +10 dBu
Impedance: 470 kohms
Output Section:
Connector: 1/4” TRS
Nominal Level: +4 dBu
Maximum Level: +18 dBu
Impedance: 50 ohms
General:
Frequency Response: 20 Hz. - 20 kHz. +0, -3 dB
S/N ratio: Greater than 90 dB; ref = max signal, 22 kHz measurement bandwidth
Total Harmonic Distortion: Less than 0.04% (1 kHz.)
Memory Capacity: Factory: 40 Programs User: 40 Programs
Power Requirements:
US and Canada: 120 V AC, 60 Hz
Japan: 100 V AC, 50/60 Hz
Europe: 230 V AC, 50 Hz
UK: 240 V AC, 50 Hz
Power Consumption: 12 watts
Dimensions: Length 18” Width 8.75” Height 2.75”
Section - 5 Appendix
RP-7 Valve
User Guide
22
Preset List
The following is a list of all the factory Programs in the RP-7 Valve.
Bank 1 Rock
11 Star Maker Solo
12 Crunchola
13 Chorused Clean
14 Octavia
Bank 2 Heavy
21 Chunk Head
22 Metal Tube
23 MoshMan
24 Fuzz Buster
Bank 3 Tube Tones
31 Tube Solo
32 Tube Rhythm
33 Bright Clean Tube
34 Hard Tube Crunch
Bank 4 Blues
41 SRV Blues
42 Funky Clean
43 Blues Slide
44 Wah House
Bank 5 Country
51 Lil’ Slap
52 Country Solo (A Mixolydian)
53 Swing Rhythm
54 Pedal Steel
Bank 6 Alternative
61 King Fuzzo
62 Trem-O-Time
63 Whammy Boy
64 Phase to Phase
Bank 7 Vintage
71 Pulp Surf
72 Transistor Tone
73 Rockabilly
74 Fuzz Phase
Bank 8 Jazz
81 Jazz Club
82 Fusion Solo
83 Rotary Speaker Jazz
84 Comp Delay
Bank 9 Studio
91 Panning Rhythm (Stereo Mode Only)
92 Compressed Clean
93 Session Crunch
94 Greasy Solo
Bank 10 Special
10-1 Harmony Solo (A-Minor)
10-2 Guitar Synth
10-3 Sound On Sound*
10-4 12-String
* Play a 2 second pattern and rock the expression pedal
forward. This will engage the Repeat hold on the delay and
allows you to play along with the captured pattern.
RP-7 Valve
User Guide
Section - 5 Appendix
23
8760 South Sandy Parkway
Sandy, Utah, 84070
Telephone 801.566.8800
FAX 801.566.7005
International Distribution:
3 Overlook Drive, Unit 4
Amherst, New Hampshire 03031 U.S.A.
FAX 603.672.4246
Digitech™, RP-7 Valve™, and S-DISC™II are registered trademarks
of the Harman Music Group Incorporated
Copyright © 1997
the Harman Music Group Incorporated
Printed In U.S.A. 10/97
Manufactured in the U.S.A.
RP-7 Valve 18-0534-A
Please Visit Digitech on the World Wide Web at:
http://www.digitech.com
Loading...
