User’s
Guide
These symbols are internationally accepted symbols that warn of potential
hazards with electrical products.The lightning flash means that there are
dangerous voltages present within the unit.The exclamation point indicates
that it is necessary for the user to refer to the owners manual.
These symbols warn that there are no user serviceable parts inside the unit.
Do not open the unit.Do not attempt to service the unit yourself. Refer all
servicing to qualified personnel. Opening the chassis for any reason will void
the manufacturer’s warranty.Do not get the unit wet.If liquid is spilled on
the unit,shut it off immediately and take it to a dealer for service.
Disconnect the unit during storms to prevent damage
Electromagnetic Compatibility
Operation is subject to the following conditions:
•This device may not cause harmful interference.
•This device must accept any interference received,including interference that may cause undesired operation.
•Use only shielded interconnecting cables.
•Operation of this unit within significant electromagnetic fields should
be avoided.
I
Warning
For your protection,please read the following:
Water and Moisture:Appliances should not be used near water
(e.g. near a bathtub, washbowl,kitchen sink,laundry tub, in a wet
basement,or near a swimming pool,etc.) Care should be taken so
that objects do not fall and liquids are not spilled into the enclosure
through openings.
Power Sources: The appliance should be connected to a power
supply only of the type described in the operating instructions or as
marked on the appliance.
Grounding or Polarization: Precautions should be taken so that
the grounding or polarization means of an appliance is not defeated.
Power Cord Protection: Power supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
.
upon or against them,paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the
appliance.
Servicing: To reduce the risk of fire or electrical shock, the user
should not attempt to service the appliance beyond that described in
the operating instructions.All other ser vicing should be referred to
qualified service personnel.
For units equipped with externally accessible fuse receptacle: Replace fuse with same type and rating only.
DECLARATION OF CONFORMITY
Manufacturer’s Name: DigiTech
Manufacturer’s Address: 8760 S.Sandy Parkway
declares that the product:
Product name: RP200
Note:Product name may be suffixed by the letters EX,EU,JA, and UK.
Product option: all (requires Class II power adapter that conforms
conforms to the following Product Specifications:
Safety: EN 60065 (1993)
EMC: EN 55013 (1990)
Supplementary Information:
The product herewith complies with the requirements of the Low Voltage Directive 72/23/EEC and the EMC Directive
89/336/EEC as amended by Directive 93/68/EEC.
European Contact: Your local DigiTech / Johnson Sales and Service Office or
to the requirements of EN60065,EN60742, or equivalent.)
DigiTech / Johnson
Vice-President of Engineering
8760 S.Sandy Parkway
Sandy,Utah 84070,USA
Date:October 16,2000
Harman Music Group
8760 South Sandy Parkway
Sandy,Utah
84070 USA
Ph:(801) 566-8800
Fax:(801) 568-7573
Sandy,Utah 84070,USA
IEC65 (1985) with Amendments 1, 2,3
EN 55020 (1991)
II
Warranty
We at DigiTech are very proud of our products and back-up each one we sell with the following
warranty:
1.The warranty registration card must be mailed within ten days after purchase date to validate this
warranty.
2.Digitech warrants this product, when used solely within the U.S.,to be free from defects in materials
and workmanship under normal use and service.
3.Digitech liability under this warranty is limited to repairing or replacing defective materials that show
evidence of defect,provided the product is returned to Digitech WITH RETURN AUTHORIZATION,
where all parts and labor will be covered up to a period of one year.A Return Authorization number
may be obtained from Digitech by telephone.The company shall not be liable for any consequential
damage as a result of the product's use in any circuit or assembly.
4.Proof-of-purchase is considered to be the burden of the consumer.
5.Digitech reser ves the right to make changes in design, or make additions to,or improvements upon this
product without incurring any obligation to install the same on products previously manufactured.
6.The consumer forfeits the benefits of this warranty if the product's main assembly is opened and
tampered with by anyone other than a certified Digitech technician or,if the product is used with AC
voltages outside of the range suggested by the manufacturer.
7.The foregoing is in lieu of all other warranties, expressed or implied,and Digitech neither assumes nor
authorizes any person to assume any obligation or liability in connection with the sale of this product.In
no event shall Digitech or its dealers be liable for special or consequential damages or from any delay in
the performance of this warranty due to causes beyond their control.
NOTE:The information contained in this manual is subject to change at any time without notification.Some
information contained in this manual may also be inaccurate due to undocumented changes in the product or
operating system since this version of the manual was completed.The information contained in this version
of the owner's manual supersedes all previous versions.
III
Table of Contents
Safety Information.............................................................I
Declaration of Conformity............................................II
Warranty..........................................................................III
Table of Contents..........................................................IV
Section One - Introduction
Getting Acquainted..........................................................1
Included Items ...................................................................1
A Guided Tour...................................................................2
Front Panel......................................................................2
Rear Panel.......................................................................5
Getting Started.................................................................6
Making Connections........................................................6
Mono Operation............................................................6
Stereo Operation..........................................................7
Applying Power.................................................................8
About the RP200..............................................................9
The Presets......................................................................9
Performance Mode........................................................9
Bypass Mode ...................................................................9
Tuner Mode...................................................................10
Section Two - Editing Functions
Editing/Creating Presets...............................................11
The Matrix .......................................................................12
Storing/Copying..............................................................13
Section Three - Effects and Parameters
About the Effects...........................................................15
Effect Definitions ............................................................15
Pickup/Wah...................................................................16
Compressor..................................................................16
Amp Modeling..............................................................17
EQ. ..................................................................................18
Cabinet/Gate................................................................18
Effects. ............................................................................20
Chorus........................................................................20
Flange...........................................................................20
Phaser..........................................................................21
Tremolo.......................................................................21
Panner. .........................................................................21
Vibrato.........................................................................22
Rotary..........................................................................22
Y a Y a™.........................................................................22
Auto Y a™....................................................................23
SynthT alk™................................................................23
Envelope......................................................................23
Detune........................................................................24
Pitch Shift....................................................................24
Whammy™................................................................24
Delay...............................................................................25
Reverb............................................................................26
Section Four - Other Functions
Rhythm T rainer................................................................27
Jam-A-Long......................................................................27
Expression Pedal.............................................................27
Factory Reset..................................................................29
Expression Pedal Calibration.......................................30
Section Five - Appendix
Specifications...................................................................31
Preset List........................................................................32
IV
Section-1 Introduction
Getting Acquainted
Congratulations on your purchase of the RP200.You now have the flexibility,and power to
produce sonic creations never before thought possible. Although the RP200 is so user friendly
you may not even need to read this manual, we recommend that you become better acquainted
with us,and what we have to offer by going through this User’s Guide with your RP200 in front
of you.It is your key to unlocking the potential within the RP200.
Included Items
Before you get started,please make sure that the following items have been included:
• RP200
• PS0913B Power Supply
• User’s Guide
• Warranty Card
The utmost care was taken while your RP200 was being manufactured. Everything should be
included and in perfect working order. If anything is missing,contact the factory at once.Please
help us become acquainted with you and your needs by completing your warranty card. It is your
safeguard should a problem arise with your RP200.
1
A Guided Tour of the RP200
The Front Panel
2
1. Footswitches - These 2 Footswitches are used to select Presets,access the Tuner, or bypass
the RP200. The Footswitch on the right will increase, and the Footswitch on
the left will decrease the selected Preset.Pressing both Footswitches together
will bypass the currently selected Preset.Pressing and holding both
Footswitches will access the Tuner.
2. Parameter Knobs -The Parameter knobs perform various functions depending on which
mode is currently active in the RP200.In performance mode, these knobs
control the Amp Type,Gain, and Master Level.In Edit mode , these knobs
adjust the Parameter values listed directly above each knob for the
selected effect.In Rhythm Trainer,these knobs control the Pattern,Tempo,
and Level.In Tuner mode, these knobs are used to select the desired
tuning reference.
3. Select Button -This button is used to enter the Edit mode, and to select individual effects to
be edited.Successive presses of this button will advance through all available
Effects.
4. Rhythm - The Rhythm button is used to turn on and off the Rhythm Trainer drum loop.When
the Rhythm feature is active, the Rhythm LED lights and the selected drum pattern
plays continuously.
5. Matrix -The matrix provides information regarding the current Preset,and Parameter edit
functions.In performance mode,the LEDs running down the left side of the Matrix
will provide a visual indication of which effects are in use for the currently selected
Preset.In Edit mode , the LEDs indicate the Effect currently selected for editing.In
Tuner mode , the LEDs indicate whether the note played is sharp, flat,or in tune .
3
6. Display -The Display provides information for different functions depending on the mode
that has been selected.In Performance mode, the Display will show the currently
selected Preset name and number.In Edit mode , the Display will show the name and
value of the parameter being adjusted.In Tuner mode, the Display will show the
note played.
7. Store -The Store button is used to save your custom edits to the user Presets.
8. Expression Pedal -The Expression Pedal adjusts RP200’s Volume or the assigned Effect
Parameter in real time. Almost every Parameter is available for
Expression Pedal control.
4
Rear Panel
1. Input - Connect your instrument to this jack.
2. Jam-A-Long - Connect the stereo output of a tape or CD player to this 1/8” stereo TRS jack
for rehearsing with your favorite pre-recorded material.
3. Output - This is a stereo TRS jack. Connect from this jack to the input of a single amplifier for
mono applications,or use a TRS stereo “Y” cord to connect to the inputs of 2
amplifiers for stereo applications.
4. Headphones - Connect a pair of stereo headphones to this 1/8” jack.
5. Power Input - Connect only the DigiTech PS0913B power supply to this jack.
5
Getting Started
Making Connections
There are several different connection options available with the RP200.Before connecting the
RP200,make sure that the power to your amplifier and the RP200 is turned off.There is no
power switch on the RP200.To turn the RP200 on or off,simply connect or disconnect the
included PS0913B power supply from the Power Jack to an AC outlet.
Mono Operation
Connect your guitar to the Input of the RP200. Connect a single mono instrument cable from
the Stereo Output of the RP200 to the instrument input or effect return on your amplifier,or
to the line input of a power amp.
6
Stereo Operation
For stereo operation connect the guitar to the Input of the RP200.Connect a TRS stereo “Y”
cord to the RP200’s Stereo Output.Connect one end of the “Y” cord to the input of one
amplifier, channel of a mixer, or power amp.Connect the second end of the “Y” cord to a second
amplifier, second channel of a mixer, or power amp.If connecting to a mixing console, set the pan
controls of the mixer hard left and right in order to retain stereo separation and be sure to
engage the RP200’s Cabinet Emulator. See page 18 for more on selecting the Cabinet Emulator.
NOTE: When using a guitar amp, it may be best to connect the guitar to the input of the RP200
and the Output of the RP200 to the effect return of the amplifier.
7
Applying Power
Before applying power to anything, set your amp(s) to a clean tone and set the tone controls to
a flat EQ response (on most amps,this would be 0 or 5 on the tone controls).Then follow the
steps listed below.
1. Turn the amp volume all the way down.
2.Connect the plug of the PS0913B power supply to the power jack on the rear panel of the
RP200.
3.Connect the other end of the PS0913B power supply to an AC outlet.
4.Turn the power of your amplifier(s) to the on position and adjust the volume(s)to a normal
playing level.
5.Gradually increase the RP200’s Master Level to achieve the desired volume.
8
About the RP200
The Presets
Presets are named and numbered locations of programmed sounds which reside in the RP200.
Presets are recalled with the Footswitches. The active effects in each Preset will be indicated by
the lighted LEDs in the Effect Matrix.The RP200 comes with 40 User Presets (Presets 1-40) and
40 Factory Presets (Presets 41-80).The User Presets are locations where your creations may be
stored.The Factor y Presets will not allow you to store any changes to them.From the factory,
the 40 User Presets are exact duplicates of the 40 Factory Presets.This allows you to create
your own Presets without the worry of losing any of the sounds that came with the RP200.
Performance Mode
When you first apply power to the RP200,it will power up in Performance mode.Performance
mode provides access to all of the Presets within the RP200 via the Up and Down
Footswitches.The Parameter 1 (left) knob will adjust the Amp Type, the Parameter 2
(middle) knob will select the Amp Gain (distortion), and the Parameter 3 (right) knob will
adjust the Master Level (volume).
Bypass Mode
The RP200 Presets can be bypassed for a clean,unprocessed guitar tone.To bypass the RP200,
press both Footswitches simultaneously.The Display will read Bypass indicating the Preset is
bypassed.Pressing either Footswitch will exit Bypass and return the RP200 to the last Preset
used.
9
Tuner Mode
The Tuner in the RP200 allows you to quickly tune or check the tuning on your guitar. Enter
Tuner mode by pressing and holding both Footswitches simultaneously.The Display will briefly
show TUNER indicating that you are in Tuner mode. To begin tuning,play a note on your guitar
(a harmonic at the 12th fret usually works best).The Display shows the note being played.The
Matrix LEDs indicate whether you are sharp or flat.The top 4 Red LEDs indicate the note is
sharp and should be tuned down.The bottom 4 Red LEDs indicate the note is flat and should be
tuned up.The center Green LED indicates the note is in tune. The output is muted in Tuner
mode. The Expression Pedal will unmute the output allowing signal to be heard while tuning.Exit
tuner mode by pressing either Footswitch.
In Tuner mode , you can change your tuning reference.The default factory setting is A=440 Hz.
(displayed as A=440).Rotating the Parameter 1 knob will select alternate dropped tunings.
Alternate tunings are A = Ab (displayed as A=A&),A = G (displayed as A=G),and A = Gb
(displayed as A=G&).The display window will briefly flash the currently selected tuning
preference.
10
Section Two - Editing Functions
Editing/Creating Presets
Creating your own signature sound with the RP200 is easy and intuitive.The RP200 lets you
create your own Presets,or fine tune existing Presets to suit your needs. When creating or
editing a sound,you must first start with one of the User or Factor y Presets. It is not possible to
start with a completely empty Preset.The Preset number does not necessarily need to be the
location which you intend to have it reside, as you can save your creation to any User Preset
location during the store process.
To edit or create a Preset:
1.Use the Footswitches to select a Preset which will be your starting point.
2.Once you have found a Preset that you wish to edit,press the Select button once.This
will take you into the Editing mode.
3.Use the Select button in conjunction with the Matrix to choose the effect you wish to
edit.
4.Use the 3 Parameter Knobs to change parameter values to achieve the desired sound.
11
The Matrix
The Matrix is where all Effects and Parameters are selected for editing.In Edit mode, successive
presses of the Select button will advance to the next Effect row.The LED will light indicating
which Effect group has been selected.Each Effect group will have up to 3 Parameters which can
be modified. The Knob under each column of Parameters is used to change the value for the
corresponding Parameter of the selected Effect. As a Knob is rotated,the Parameter name and
value or status will be shown in the Display.
When the stored value of a Parameter is changed,the Store LED will light indicating that you
need to store the changes.Changing Presets, or turning the power off before storing any changes
will erase any changes made and the RP200 will revert to the stored values for the Preset.
12
Storing/Copying/Naming a Preset
Once the Preset has been modified to your liking,you may store your settings to any of the 40
User Preset locations (Presets 1-40). The following steps outline the procedure for storing
changes to a Preset or copying a Preset to a different location:
1.Press the Store button once .The Store button LED will blink and the first character in the
Display will Flash indicating that you can now name your custom creation.
2.Use the Parameter 1 Knob to select the alpha-numeric character and the Parameter 2
Knob to select the next character location
3.Once the desired name is shown in the display, press the Store button again to enter the
second stage of the storing process.
4.Select the User Preset location your new sound will reside in using the up and down
Footswitches.The display will alternate between showing the Preset name and number
about to be overwritten.
13
5.Press the Store button again to save the changes.
The procedure for copying one Preset to another Preset location is the same.Simply use the
Footswitches to select the Preset that you want to copy, then follow the steps listed above.
Press the Select button at any time to abort the Store procedure.
14
Section Three - Effects and Parameters
About the Effects
The RP200 can be thought of as several different “virtual” amplifiers and individual, hi-tech stomp
boxes in a single programmable package.With stomp boxes,the order in which they are
connected can drastically affect the overall sound quality.The RP200 has placed the Effects in an
order for optimum sound quality. The following diagram shows the order of the effects contained
in the RP200.
Effect Definitions
Each Effect within the RP200 can be programmed to suit your personal tastes and application.
Understanding how these Effects will alter the sound,and how each Parameter will alter the
Effect will help you achieve the sound you are looking for. The following overview of the RP200’s
Effects outlines what each Effect and Parameter does.
15
Pickup/Wah
The Pickup Simulator provides the thick tone of a humbucker pickup to a guitar with single
coil pickups,or the bright edgy sound of a single coil pickup to a guitar with a humbucker.This
allows you to have the best of both worlds without having to change guitars during a
performance.
Wah is an effect controlled by an Expression Pedal making the guitar sound as if it’s saying “Wah.”
Pickup T ype -The Parameter 1 knob selects the Pick Up type which will be simulated. Values
include:PCk Of (Turns the Pickup Simulator off), SC>HUM (Gives a single coil
pick up the warm tone of a humbucker),and HUM>SC (Gives a humbucker the
unique sound of a single coil).
Wah Type - The Parameter 2 knob selects the Wah Type.Values include:WaH Of (Turns the
Wah Effect off),CRY (Cr y Wah is a traditional sounding Wah), BOUTIQ (Boutique
Wah is a wide sweeping Wah with a more modern sound) and FULRNG (Full Range
Wah sweeps the entire spectrum of audible frequencies).
Wah Position - The Parameter 3 knob adjusts the Wah Pedal Position. Ranges from 1 (toe
up) to 99 (toe down).
Compressor
A Compressor is used to increase sustain, tighten up guitars,and prevent the signal from
clipping the input of other effects.It sets a maximum boundary for the strength of a signal.
Comp T ype -The Parameter 1 Adjusts the length of time it takes for the Compressor to
respond to a signal exceeding the boundary. Values include:Cmp Of (Turns the
Compressor off) to fast, meDIUM,and slOw.
16
Amount -The Parameter 2 knob adjusts the Amount of Compression (ratio and sustain) and
ranges from 1 (slight compression) through 20 (maximum sustain).
Gain -The Parameter 3 knob adjusts the Output Gain from the Compressor. Ranges from 0
to 6.
Amp Modeling
Amp Modeling is a technology which applies the tone of several popular modern and vintage
amps. Amp Modeling also includes an acoustic guitar simulation.
Amp T ype - The Parameter 1 knob selects the 12 types of Amp Models.
amp Of - Turns the modeling off
BLKFAC - Based on a ‘65 Fender Twin Reverb
BOUTIQ - Based on a Matchless DC30
RECTIF - Based on a Mesa Dual Rectifier
HOTROD - Based on a Mesa Boogie Mark II C
tweeD - Based on a ‘57 Fender Tweed Deluxe
CLEAN1 - Based on a Vox AC30 top boost
Marshall® is a registered trademark of Marshall Amplification Plc. Vox® is a registered trademark of Korg UK. Fender,
Matchless,and Mesa Boogie, are trademarks of their respective companies and are in no way associated with DigiTech.
Amp Gain - The Parameter 2 knob adjusts the Gain (distor tion) for the selected Amp Model
(not available for Acoustic).The Gain parameter ranges from 0 to 99.
Amp Level - The Parameter 3 knob adjusts the Level (volume) of the selected Amp Model.
The Level parameter ranges from 0 to 99.
CLEAN2 - A clean tube combo setting
STACK - Based on a Marshall JCM900
CRUNCH - A nice crunchy combo
HIGAIN - Based on the Johnson JM150 High Gain
FUZZ - A vintage fuzz distortion
ACOUST - A flat top acoustic guitar
17
EQ
Equalization is an extremely useful tool used to further shape the tonal response of your
guitar signal. The EQ in the RP200 is similar to the tone knobs on an amplifier.All three EQ
parameters range from -12dB to +12 dB.
Bass - The Parameter 1 knob adjusts the amount of low end enhancement (Bass).
MiD - The Parameter 2 knob adjusts the amount of mid range enhancement.
TReB - The Parameter 3 knob adjusts the amount of high end enhancement (Treble).
Cabinet/Gate
The Cabinet Modeling simulates different types of miked speaker cabinets.You have your
choice of 3 Cabinet Types and 4 Mic Placements in relationship to the speaker cabinet.
A Noise Gate is designed to eliminate noise while you are not playing.
Cabinet/Mic - The Parameter 1 knob selects the type of simulated Speaker cabinet and mic
placement in relation to the speaker.
CAB OF - Cabinet Off
DARK 1 - Dark 4x12 Mic 1
DARK 2 - Dark 4x12 Mic 2
DARK 3 - Dark 4x12 Mic 3
DARK 4 - Dark 4x12 Mic 4
18
WARM 1 - Warm 4x12 Mic 1
WARM 2 - Warm 4x12 Mic 2
WARM 3 - Warm 4x12 Mic 3
WARM 4 - Warm 4x12 Mic 4
BRIT 1 - Bright 2x12 Mic 1
BRIT 2 - Bright 2x12 Mic 2
BRIT 3 - Bright 2x12 Mic 3
BRIT 4 - Bright 2x12 Mic 4
Gate T ype - The Parameter 2 knob selects between the Silencer ™ Noise Gate,or the Auto
Swell volume swell effect. Values include:Gat Of (Turns the Noise Gate off),
silNCR (Selects the Silencer™ Noise Gate) and swEl1 through swEl9 (Selects
the Auto Swell volume swell effect. These settings will automatically ramp up the
volume from a 200 milliseconds volume fade in to a 2 second volume fade in).
Gate Thresh - The Parameter 3 knob sets the signal strength (Threshold) required to open
or close the Noise Gate. The Gate Threshold parameter ranges from 1 (opens
easily) to 40 (requiring strong signals to open).
19
Effects
The Effects row in the RP200 is a multi-function module,allowing you to select effects such as;
Chorus,Flanger, Phaser, Tremolo, Panner,Vibrato,Rotar y Speaker,YaYa™, AutoYa™,SynthTalk™,
Envelope Filter (auto wah),Detune , Pitch Shift,and Whammy™ effects. When the Effects row is
selected,the Parameter 1 knob is used to choose the type of Effect or turn the Effect module
off (eff Of).Only one of the effects in this row can be used at a time.After selecting the type
of effect in this module, the Parameter 2 and Parameter 3 knobs can then be used to adjust
the individual parameters associated with the selected effect.The following list describes each
Effect and their Parameters in more detail:
Chorus (CHORUS)
A Chorus adds a short delay to your signal.The delayed signal is modulated in and out of tune
and then mixed back with the original signal to create a thicker sound.
Amount -The Parameter 2 knob simultaneously adjusts the rate (Speed) and intensity
(Depth) of the modulation.Ranges from 1 to 99.
Level -The Parameter 3 knob controls the mix level of the Effect.Ranges from 0 to 99.
Flange (FLaNge)
A Flanger uses the same principle as a Chorus but uses a shorter delay time and adds
regeneration (or repeats) to the modulating delay.This results in an exaggerated up and down
sweeping motion to the effect.
Amount -The Parameter 2 knob simultaneously adjusts the rate (Speed) and intensity
(Depth) of the Effect.Ranges from 1 to 99.
Level -The Parameter 3 knob controls the mix level of the Effect.Ranges from 0 to 99.
20
Phaser (PHaseR)
A phaser splits the incoming signal,and then changes the phasing of the signal.This signal is then
taken in and out of phase and mixed back in with the original signal. As the phasing changes,
different frequencies get canceled resulting in a warm sort of twisting sound.
Amount -The Parameter 2 knob simultaneously adjusts the rate (Speed) and intensity
(Depth) of the Effect.Ranges from 1 to 99.
Level -The Parameter 3 knob controls the mix level of the Effect.Ranges from 0 to 99.
Tremolo (TREMLO)
A Tremolo effect modulates the volume of the signal at an even rate.
Amount -The Parameter 2 knob adjusts the rate (Speed) at which the volume modulates.
Ranges from 1 to 99.
Level -The Parameter 3 knob adjusts the intensity (Depth) of the modulating volume. Ranges
from 0 to 99.
Panner (PANNER)
An Auto Panner modulates the sound from left to right at an even rate.
Amount -The Parameter 2 knob adjusts the rate (Speed) at which the signal pans from side
to side. Ranges from 1 to 99.
Level -The Parameter 3 knob adjusts the intensity (Depth) of the changing pan. Ranges from
0 to 99.
21
Vibrato (viBRTO)
A Vibrato effect modulates the pitch of the incoming signal at an even rate.
Amount -The Parameter 2 knob adjusts the rate (Speed) at which the pitch modulates.
Ranges from 1 to 99.
Level -The Parameter 3 knob adjusts the intensity (Depth) of the modulating pitch. Ranges
from 0 to 99.
Rotary Speaker (ROTARY)
Rotary Speaker is an emulation of a device that included a spinning horn and woofer.The
rotation of these two speakers produced an interesting combination of the sound panning from
side to side, as well as a slight pitch change due to speed of the sound coming towards, and then
going away from the listener.
Amount -The Parameter 2 knob adjusts the rate (Speed) of the spinning speakers.Ranges
from 1 to 99.
Level -The Parameter 3 knob controls the mix level of the Effect.Ranges from 0 to 99.
YaYa™ (yaya)
The YaYa™ is another effect exclusive to DigiTech products. Like the AutoYa™,it combines the
characteristics of a wah and a flanger together providing a unique talk box type of effect,but is
controlled by the Expression Pedal.
Amount - The Parameter 2 knob adjusts the intensity of the YaYa™ effect. Ranges from 1 to
99.
Level -The Parameter 3 knob adjusts the throaty quality of the YaYa™ effect. Ranges from 0
to 99.
22
AutoYa™ (AUTOYA)
An AutoYa™ combines the characteristics of a Wah and a Flanger together creating an almost
human vowel characteristic as if the guitar were saying “Yah.” The AutoYa™ automatically
provides this animation to the sound at an even rate.
Amount -The Parameter 2 knob adjusts the rate (Speed) of the sweep.Ranges from 1 to
99.
Level -The Parameter 3 knob controls the mix level of the AutoYa™. Ranges from 0 to 99.
SynthTalk™ (syNtLK)
SynthTalk™ is another effect exclusive to DigiTech. It makes your guitar seem to be speaking
based upon the attack or how hard you strike the strings.
Amount -The Parameter 2 knob selects one of the ten different synth voices.Ranges from
vOx 1 to vOx 10.
Level -The Parameter 3 knob adjusts the sensitivity or the input signal required to trigger
the SynthTalk™ effect.Ranges from 0 to 99.
Envelope Filter (eNvlOp)
The Envelope Filter is a dynamic Wah effect that alters your sound based upon how hard you
play.
Amount -The Parameter 2 knob adjusts the sensitivity or the input signal required to trigger
the Wah effect. Ranges from 1 to 99.
Level -The Parameter 3 knob controls the mix of the Envelope effect.Ranges from 0 to 99.
23
Detune (DetUNe)
A Detuner will make a copy of your incoming signal, take the copied signal slightly out of tune
from the original,and mix the two signals together.The result is a doubling type of effect as if
two guitars were playing the same part together.
Amount - The Parameter 2 knob adjusts the amount of pitch difference applied to the copied
signal.Ranges from -12 to 12.
Level -The Parameter 3 knob controls the mix of the detuned note. Ranges from 0 to 99.
Pitch Shift (PitCH)
A Pitch Shifter copies the incoming signal,then shifts the pitch of the copy to a different note.
The shifted note is then mixed back with the original signal sounding as if two guitars were
playing different notes.
Amount -The Parameter 2 knob selects the interval of the shifted pitch. Ranges from -12
(12 semitones below) to 24 (24 semitones above).
Level -The Parameter 3 knob controls the mix level of the shifted pitch.Ranges from 0 to
99.
Whammy™ (wHammy)
Whammy™ is an effect that uses an Expression Pedal to bend the pitch of the
incoming signal,or add a bendable harmony with the original signal. As the Pedal
is moved,the note will bend either up or down.When Whammy™ is selected,it is
automatically placed before the Amp Modeling as shown in the block diagram.
Amount -The Parameter 2 knob selects the interval and direction of the pitch bend. Choices
are as follow:
24
Whammy (no Dry Signal)
1OCTUP (1 octave above)
2OCTUP (2 octaves above)
2NDDWN (a second below)
REV2ND (a second below reversed pedal action)
4THDWN (a fourth below)
1OCTDN (an octave below)
2OCTDN (2 octaves below)
DIVBOM (Dive Bomb)
Harmony Bends (Dry Signal Added)
M3>MA3 (a minor third to a Major third)
2NDMA3 (a second above to a Major third above)
3RD4TH (a third above to a fourth above)
4TH5TH (a fourth above to a fifth above)
5THOCT (a fifth above to an octave above)
HOCTUP (one octave above)
HOCTDN (one octave down)
Level -The Parameter 3 knob adjusts the volume of the Whammy™.Ranges from 0 to 99.
Delay
Delay is an effect that will record a portion of the incoming signal, and then play it back a short
time later. The recording can repeat just once or several times.
Type/Level -The Parameter 1 knob selects one of the 3 different types of Delay, as well as
the volume level of the Delay.Values include:DLY OF (Turns the Delay Effect off),
MONO 1 through MONO 9 (Digital Delays with increasing Level amounts),ANLG
1 through ANLG 9 (Analog Delays with increasing Level amounts),PONG 1
through PONG 9 (Ping Pong Delays with increasing Level amounts).
Delay Time -The Parameter 2 knob adjusts the amount of Delay time.Ranges from 1
through 99 (10 through 990 ms in 10 ms increments), and 1.0 through 2.0 (1
seconds through 2 seconds in 100 ms increments).
Delay Feedback - The Parameter 3 knob adjusts the number of repeats.Ranges from 0 to 99
and R-HOLD (infinite repeat).
25
Reverb
Using reverb in recorded program material gives the listener a sense that the material is being
performed in an actual room or hall.It is this similarity to actual acoustic spaces that makes
reverberation a useful tool in recorded music.
Reverb Type - The Parameter 1 knob selects the Type of Reverb or acoustic space.
REV OF = Reverb Off
STUDIO = Studio
ROOM = Wood Room
CLUB = Club
PLATE = Plate
HALL = Hall
AMPTHE = Amphitheater
CHURCH = Church
GARAGE = Parking Garage
ARENA = Arena
SPRING = Spring
Decay -The Parameter 2 knob adjusts the length of time the Reverb is audible. Ranges from
1 to 99.
Reverb Le vel - The Parameter 3 knob adjusts the volume of the Reverb.Ranges from 0 to 99.
26
Section Four - Other Functions
Rhythm T rainer
The RP200 includes several sampled drum patterns which are useful for developing a good sense
of timing.Pressing the Rhythm button will enable Rhythm mode and start playback of the drum
loop (except when in Store or Bypass mode). In Rhythm mode, the Parameter 1 knob selects
the drum Pattern,the Parameter 2 knob adjusts the drum Tempo, and the Parameter 3 knob
adjusts the Level of the drum loop.Press the Rhythm button again to stop playback of the drum
loop.
Jam-A-Long
The Jam-A-Long feature allows you to connect a Tape or CD to the RP200,and Jam with your
favorite artists.The signal from your tape or CD player is output through the left, right,and
headphone outputs of the RP200. To use the Jam-A-Long feature,connect the headphone output
of your tape or CD player to the Jam-A-Long Input on the rear panel of the RP200 using an
1/8” stereo cable,and press play on your tape or CD player.
Expression Pedal
The Expression Pedal on the RP200 can be assigned to control the RP200’s Volume,Wah,
Whammy™,Ya Ya™,or one of several other parameters in real time with your foot. When a
parameter has been assigned to the Expression Pedal,a programmable minimum and maximum
value can also be assigned. The procedure for assigning a parameter to the Expression Pedal is as
follows:
1.Press the Select button until the Expression row has been selected (indicated by the LED
lighting on the Expression row).
2.Rotate the Parameter 1 knob until the desired Parameter appears in the Display. Your
choices include:
27
WAH (Wah) - The Expression Pedal acts as a Wah when the Wah Effect is engaged.
A GAIN (Amp Gain) - Expression Pedal controls the Amp Gain or amount of distortion for
AMPLVL (Amp Level) - Expression Pedal controls the Volume of the selected Amp Type.
AMOUNT (Amount) - Expression Pedal controls the Amount of the selected Effect Type.
EFFLVL (Effect Level) - Expression Pedal controls the Mix Level of the selected Effect Type .
YAYA (YaYa™) - Expression Pedal acts as a Ya Ya™ Effect when YaYa™ is engaged.
WHAMMY (Whammy™) - Expression Pedal acts as a Whammy™ Pedal when Whammy™ is
FBACK (Feedback) - Expression Pedal controls the amount of Delay Feedback.
DLYLVL (Delay Level) - Expression Pedal controls the Mix Level of the selected Delay Type.
DECAY (Decay) - Expression Pedal controls the length of Reverbs Decay time.
REVLVL (Reverb Level) - Expression Pedal controls the Reverbs Mix Level.
VOLPRE (Volume Pre) - Expression Pedal controls the Volume after the Amp Modeling but
VOLPST (Volume Post) - Expression Pedal controls the Volume at the end of the Effects chain.
3.Rotate the Parameter 2 knob to select the minimum value the assigned parameter will reach
with the Expression Pedal in the toe up position (not available when volume is the assigned
parameter).
4.Rotate the Parameter 3 knob to select the maximum value the assigned parameter will
reach with the Expression Pedal in the toe down position (not available when volume is the
assigned parameter).
5.Store your Expression Pedal assignment to your Preset.See page 13 for more information on
the storing procedure.
the selected Amp Type.
engaged.
before the Effects.
28
Factory Reset
This function resets the RP200 to its original factory settings. This procedure will erase all
custom user Presets, and recalibrate the Expression Pedal.
ATTENTION: Performing this function will erase all user-programmed data.All such data
will be lost forever! Be sure you want to erase the memory and star t fresh
before continuing with this procedure.
The procedure for performing a Factory Reset is as follows:
1.Disconnect the power supply from the RP200.
2.Press and hold the Select button while re-connecting the power to the RP200.
3.When the display shows RST ?, release the Select button and press the Store button.
The display will briefly read RESET indicating that the RP200 has reset the original factory
settings.At this point,the RP200 will automatically advance to the Expression Pedal calibration
menu.Follow steps 4 through 7 of the Expression Pedal calibration section.
29
Expression Pedal Calibration
The Expression Pedal on the RP200 needs to be recalibrated for use after a factory reset has
been performed.This calibration procedure is automatically entered after a factory reset
procedure.In the event the Pedal’s calibration fails,or if the Pedal does not function properly,it
can be re-calibrated using the Pedal Calibration procedure.This will not erase the User Presets.
The procedure for Calibrating the Expression Pedal is as follows:
1.Disconnect the PS0913B power supply from the power jack on the RP200.
2.Press and hold the Up Footswitch while reconnecting the power.
3.Continue to hold the Up Footswitch until the Display reads TOE DN.
4.Rock the Expression Pedal forward to the toe down position.
5.Press either Footswitch and the Display now shows TOE UP.
6.Rock the Expression Pedal back to the toe up position.
7.Press either Footswitch.The RP200 will return to the last selected Preset and the Expression
Pedal is now calibrated.
Note:If the Display shows ERROR,an error has occurred and steps 4 through 7
should be repeated.
30
Section Five - Appendix
Specifications
Input: 1/4” TS
Jam-A-Long: 1 - 1/8” Stereo TRS
Output: 1 - 1/4” Stereo TRS
Headphone: 1/8” Stereo TRS
A/D/A: 24 bit Delta Sigma
Power Supply: 9 VA C, 1.3A (PS0913B)
Power Consumption: 6.8 Watts
Memory: 40 User/40 Factory
Effects: Pickup Simulator,Wah,Compressor, 12 Amp/Guitar Models,3 band EQ, Noise Gate,
Cabinet Modeling,Mic Placement,Chorus, Flange, Phaser,Tremolo,Panner,Vibrato,
Rotary Speaker,AutoYa™,YaYa™, SynthTalk™, Enveloped Filter,Pitch Shift, Detune,
Whammy™, Delay, and Reverb.
Rhythm T rainer: 30 Patterns
Simultaneous Effects: up to 12
Dimensions: 8.5” L x 10” W x 2.25” H
Weight: 3 lbs.
31
Preset List (User/Factory)
32
8760 S. Sandy Parkway, Sandy, Utah 84070
PH (801) 566-8800 FAX (801) 566-7005
International Distribution
8760 S. Sandy Parkway, Sandy, Utah 84070 USA
PH (801) 566-8800 FAX (801) 566-7005
DigiTech
DigiTech and RP200 are trade marks of the
Please visit DigiTech on the World Wide Web at:
Harman Music Group Inc.
Copyright the Harman Music Group
Printed in the USA 11/2000
Manufactured in the USA
RP100 Owners Manual 18-6372-A
http://www.digitech.com
Loading...
