DeLonghi DSM700, DSM800 User Manual
Instruction Manual
Stand Mixer Accessories
Mode D’emploi
Accessoires pour mixeur
sur socle
•A938: Mini Food Processor and Chopper /
Mini robot de cuisine et hachoir
•A936: Pasta Maker/ Machine à pâtes
•A998: High-Speed Slicer-Shredder/
Trancheuse-Déchiqueteuse à grande vitesse
•A935: Juice Extractor / Centrifugeuse
•A995: Citrus Juicer / Presse-agrumes
•A950: Professiontal-Quality Food Grinder/ Broyeuse
à aliments de qualité professionnelle
•A941: Grain Mill / Moulin à grains
•A994: 1.2 Liter (40-Ounce) Glass Blender /
Mélangeur en verre de 1,2 litre (40 onces)
•31227:Splash Guard / Pare-éclaboussures
•34654:5-Quart (4,73 litres) / 34655: 7-Quart (6,62
litres): Stainless Steel Bowl / Bol en acier
inoxydable
•A934: 5-Quart (4,73 litres) / A952: 7-Quart (6,62
litres): Potato Peeler / Éplucheuse de
pommes de terre
•A992: 5-Quart (4,73 litres) / A930: 7-Quart (6,62
litres): Fruit and Vegetable Strainer /
Broyeuse pour fruits et légumes
Accessories for Use with
DSM800/DSM700 Series
Accessoires à utiliser avec
les séries DSM800/ DSM700
IMPORTANT
SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to reduce the risk
of fire, electrical shock and/or personal injury .
1) Read all instructions.
2) Close supervision is necessary when any
appliance is used by or near children.
3) To protect against fire, electric shock and/or
personal injury , do not place cord, plugs, or
appliance in water or any other liquid.
4) Turn the stand mixer off and unplug it from the
outlet when not in use, before cleaning and before
installing or removing attachments.
5) Do not operate any appliance with a damaged
cord or plug or after the appliance malfunctions, or
has been damaged in any manner. Return
appliance to an authorized DeLonghi service
center for examination, repair or adjustment.
6) To disconnect, remove stand mixer plug from wall
outlet. Always hold plug, but never pull the cord.
7) Do not use outdoors.
8) Do not let stand mixer cord hang over edge or
counter, or touch hot surfaces.
9) Do not use appliance for other than intended use.
10)Keep fingers away from moving parts and fitted
attachments.
1 1) Do not leave machine unattended.
12)Do not use unauthorized attachments.
READ AND SAVE
THESE INSTRUCTIONS
Read the section pertaining to your specific
accessory for additional important safeguards.
BEFORE YOUR FIRST USE
Carefully unpack your accessory and remove all
packaging material. For accessories with blades,
remove the plastic blade covers from the blade
assembly. Use caution when removing the plastic
covers, the blades are extremely sharp. These covers
should be discarded as they are to protect the blades
during manufacture and shipment. Remove any labels
or stickers from the accessory. To remove any dust
that may have accumulated during packaging, clean
your accessory thoroughly before using for the first
time. Read the section pertaining to your specific
accessory for detailed “Care and Cleaning”
instructions.
CAUTION: Be sure to switch “off” and unplug the
stand mixer before cleaning the body and its
attachments. To protect against electrical shock, do
not immerse cord, plug or unit in water or liquid. After
each use, always make sure plug is first removed
from wall outlet.
NOTE: Before using any of the attachments, plug the
stand mixer into a 120V/60Hz AC only outlet, and then
switch it “on” according to the directions in your stand
mixer instruction manual.
MINI FOOD PROCESSOR AND CHOPPER
(Model A938)
IMPORTANT
SAFEGUARDS
For Your Mini Food Processor and
Chopper
1) Never fit the base and blade unit to your machine
without the container fitted.
2) Never unscrew the container while the mini food
processor and chopper is fitted to your machine.
3) Do not touch the sharp blades. Keep the blade
unit away from children.
4) Only use the container and the blade unit with the
base supplied.
5) Never blend hot liquids.
6) Never remove the unit until the blades have
completely stopped rotating.
7) Never operate the unit for longer than 2 minutes.
8) Switch “off” as soon as you have
reached the right consistency.
Spices take less than 1 second to
process.
1
SAVE THESE
INSTRUCTIONS
Know Your Mini Food Processor
and Chopper
1) Base
2) Blade Unit and Rubber Seal
3) Container (4 included)
4) Lid for Storage
2
3
4
Operating Your Mini Food Processor
and Chopper
Use the mini food processor and chopper to process
foods such as spices, herbs, nuts, baby food, cooked
fruit, bread and coffee beans.
1) Put your ingredients into the container (3). Do not
fill above the maximum level.
2) Be sure the rubber seal fits tightly in place on the
blade unit (2).
3) Turn the blade unit upside down. Lower it into the
container with the blades facing downward.
4) Screw the base (1) onto the container until it fits
tightly .
5) Remove the high-speed outlet cover from the
stand mixer . Figure 1.
6) Screw the mini food processor and chopper onto
outlet 3.
7) Switch the stand mixer “on” to maximum speed.
Suggestions For Your Mini Food
Processor and Chopper:
1) Herbs are best processed when
clean and dry .
2) Always add a little liquid when
blending cooked ingredients to
make baby food.
Figure 1
Care and Cleaning for Your Mini Food
Processor and Chopper
1) Switch the stand mixer “off” and remove the mini
food processor and chopper from the unit.
2) Containers, Lid and Base: Wash by hand in warm
water with mild detergent, and then rinse and dry
thoroughly . Alternatively, you can place the
container in the top rack of your dishwasher .
3) Blade Unit: Remove and wash the rubber seal by
hand in warm water with mild detergent, and then
rinse and dry thoroughly . Brush the blades clean
under hot running water. Use caution when
handling the blades, they are very sharp.
POTATO PEELER
(Model A934: 5-Quart)
( Model A952: 7-Quart)
Know Your Potato Peeler
1) Cover
2) Rotating Plate
3) Bowl
1
Operating Your Potato Peeler
1) Fit the rotating plate (2) inside the bowl (3).
2) Add cold water to just cover the plate.
2
3
Operating Your Potato Peeler
(continued)
3) Put your potatoes or carrots into the bowl.
Use no more than:
•1/2 lb. (Model A934)
•1 lb. (Model A952)
4) Snap the cover (1) on and then raise the mixer
head.
5) Fit the bowl to the stand mixer by turning it
counterclockwise. Figure 1.
6) Lower the mixer head, and insert the metal pin
into the plastic hole. Figure 2. If the mixer head
will not shut, raise it, and then switch “on” and “off”
to reposition the metal pin. Figure 3.
Figure 1
7) Switch the stand mixer to speed 2-3.
8) Af ter peeling is complete, rinse the veget ables in
cold water.
Suggestions for Your Potato Peeler:
1) Use evenly sized vegetables
2) Cut large vegetables into pieces.
3) New potatoes peel faster than old potatoes.
4) Do not over-peel: the most nutrients lie just under
the skin.
Figure 2
Figure 3
Care and Cleaning for Your Potato Peeler
1) Switch the stand mixer “off” and remove the
potato peeler from the unit.
2) Remove the bowl by turning it clockwise.
3) Rinse the parts by hand in cold water
immediately . Do not place in your dishwasher.
Then leave to dry .
P AST A MAKER
(Model A936)
IMPORTANT
SAFEGUARDS
For Your Pasta Maker
1) Dough that is too dry or fed too quickly can break
your pasta maker . Follow your dough recipe.
2) Only use the spanner (1) handle to push dough
down the feed tube. Do not push too hard.
SAVE THESE
INSTRUCTIONS
Know Your Pasta Maker
1) Spanner
2) Ring Nut
3) Screens
(6 included)
4) Scroll
5) Body
6) Feed Tube
7) Measuring Cup
8) Cleaning Tool
2
1
6
5
4
3
8
7
Assembling Y our Past a Maker
1) Optional: For easier pasta making, warm the
pasta maker parts in hot water, and then dry
thoroughly.
2) Fit the scroll (4) inside the
body (5). Then fit a screen
(3) by putting the notches
over the pins. Figure 1. The
screens are numbered:
1: Spaghetti
2: Macaroni
3: Rigatoni
4: T agliatelle
5: Lasagne
6: Large Macaroni
Operating Your Pasta Maker
1) Make pasta dough according to the directions on
your dough recipe.
2) Remove the low-speed
outlet cover by sliding the
catch and then pull. Figure
2.
3) Hold the catch back and
insert the pasta maker, with
the feed tube facing you.
Turn it from side-to-side until
it locks into place.
4) Tighten the ring nut and then switch the st and
mixer to speed 3.
5) Drop small pieces of the mix at a time into the feed
tube (6). Figure 3. Allow the scroll to clear before
continuing. You can push them down gently using
the spanner handle. Do not use anything else or
push too hard. Your pasta could break.
Figure 1
Figure 2
Operating Your Pasta Maker (continued)
6) The first batch will come out curly; the second
batch will be more straight. Note: You can
reprocess the first batch.
7) When the pasta is long enough, cut the desired
length. Figure 4.
Figure 3 Figure 4
8) To change screens, remove the ring nut and
switch briefly to speed 1 to eject the screen.
9) Cook macaroni and rigatoni within 4 hours.
Otherwise, they will become brittle and snap.
Care and Cleaning for Your Pasta Maker
1) Switch the stand mixer “off” and remove the pasta
maker from the unit.
2) Loosen the ring nut manually or with the spanner ,
and then dismantle. Figure 5.
3) Use the cleaning tool (8) to remove all dough.
Note: Allow the dough to dry in the screens before
using the cleaning tool.
4) Wash parts by hand in warm water with mild
detergent or place in the top rack of your
dishwasher.
Figure 5
HIGH-SPEED SLICER / SHREDDER
(Model A998)
IMPORTANT
SAFEGUARDS
For Your High-Speed
Slicer / Shredder
1) Never put your fingers in the
feed tube.
2) Never remove the lid until the disc has completely
stopped.
3) Handle discs with care, they are extremely sharp.
4) Always operate on a low speed.
5) Avoid contact with moving parts - keep fingers out
of feed tube and food outlet.
6) Never feed food by hand, always use the stomper .
SAVE THESE
INSTRUCTIONS
Know Your High-Speed
Slicer / Shredder
1) Stomper
2) Feed Tube
3) Lid
4) Shaft
5) Cutting Discs
(see next page for details)
6) Base Plate
7) Base Unit
8) Food Outlet
1
2
3
4
5
6
7
8
Know Your High-Speed Slicer / Shredder (con’t)
Double Sided Thin and Thick
Slicing / Shredding Discs:
Figure 1 and 2
1) One side
carrot, cabbage, onion, apple,
etc. The other side shreds
cheese, carrot, potato and other
foods of a similar texture.
slices cheese, potato,
Thin: Figure 1
Julienne Disc: Figure 3
1) Cuts potatoes for thin French fries;
ingredients for casseroles and dips
(cucumbers, carrots, apples,
pears)
Assembling Your High-Speed
Slicer / Shredder
1) Put the base plate (6) onto the base
unit (7).
2) Carefully push one cutting disc (5) onto the shaft
(4).
3) Fit the lid (3) onto the base. If it does not fit tightly
to the base plate, try again.
4) Turn the lid clockwise until it clicks into place.
5) Remove the high-speed outlet cover and fit the
high-speed slicer / shredder to the outlet.
6) Plug the stand mixer in and put a bowl under the
food outlet (8).
Thick: Figure 2
Figure 3
Operating Your High-Speed
Slicer / Shredder
1) Put the food into the feed tube. Note: Do not cut
food too small. Pack the feed tube tightly . This
prevents food from slipping sideways during
processing. Do not place fingers in feed tube.
2) Switch the stand mixer “on” to “min” speed (or
speed 1 for cheese). Then push your food down
with the stomper.
Care and Cleaning for Your High-Speed
Slicer / Shredder
1) Switch the stand mixer “off” and remove the highspeed slicer / shredder from the unit.
2) Lid, Stomper, Cutting Discs, Base Plate: Wash by
hand in warm water with mild detergent, and then
rinse and dry thoroughly . Use caution when
handling the cutting discs, they are very sharp.
3) Base: Wipe the inside with a damp cloth. Do not
let the central hole or the underneath get wet. Dry
thoroughly.
4) Note: Some foods such as carrots may discolor
the plastic. To remove this, rub the plastic with a
cloth dipped in vegetable oil.
FRUIT AND VEGETABLE STRAINER
(Model A992: 5-Quart)
(Model A930: 7-Quart)
Know Your Fruit and
Vegetable Strainer
1) Paddle
2) Screens
(fine or coarse)
3) Bowls
Assembling Your Fruit and Vegetable Strainer
1) Raise the mixer head on the stand mixer .
2) Fit the mixing bowl to the unit.
3) Insert your fruit and vegetable strainer bowl (3).
4) Insert the screen (fine or coarse) (2).
Operating Your Fruit and Vegetable Strainer
Coarse Screen:
1) Place the rough side up for removing fibers from
cooked vegetables (Ex. rhubarb and spinach),
and for pureeing fruit and vegetables
(Ex. bananas and cooked potatoes)
2) Place the smooth side up for straining cooked
fruit (Ex. plums)
Fine Screen:
3) Place the rough side up for pureeing cooked fruit
and vegetables (Ex. tomatoes and potatoes).
4) Place the smooth side up for flour and soft fruit
(Ex. raspberries)
A930
A992
3
2
1
Operating Your Fruit and Vegetable Strainer
(continued)
5) Insert the paddle (1) and turn it until it stops. Then
push into mixer head. Figure 1.
6) To remove it, turn it back in the opposite direction.
7) Lower the mixer head. The paddle blades should
bend slightly against the strainer.
8) Note: If you need to adjust
the height, see the “Adjust
ing the Paddle Height”
section.
9) Allow cooked food to cool.
10) Switch the stand mixer to
“min”. Clear the
screen between batches.
1 1) Keep hands out of bowl and away from the p addle
during operation.
12) Increase the speed slowly to 1 or 2, but reduce
the speed if the ingredients start to splatter .
Adjusting the Paddle Height
1) Unplug the stand mixer and raise the mixer head.
2) Insert the paddle. Hold the paddle, and then loosen
the nut.
3) Lower the mixer head. Adjust the height by turning
the paddle. The paddle blades should bend slightly
against the strainer.
4) Raise the head, hold the paddle and then tighten
the nut.
Care and Cleaning for Your Fruit and
Vegetable Strainer
1) Switch the stand mixer “off” before removing the
paddle. Wash bowl, paddle and screen by hand
with warm water and mild detergent, and then
rinse and dry thoroughly .
Figure 1
JUICE EXTRACTOR
(Model A935)
IMPORTANT
SAFEGUARDS
For Your Juice Extractor
1) Never put your fingers in the feed tube. Use the
stomper.
2) Fit the clip over the lid before switching “on” the
stand mixer.
3) Do not remove the lid until the filter has stopped.
4) Do not touch moving parts.
5) If pulp stops coming out, switch the unit “off” and
unclog the bowl.
SAVE THESE
INSTRUCTIONS
1
2
3
4
Know Your Juice Extractor
1) Stomper
2) Feed Tube
3) Lid
4) Pulp Shield
5) Grater Plate
Dismantling Your Juice Extractor
1) Undo the clip (1 1) and remove the lid. (3)
2) Using the top of the stomper (1), unscrew the
grater plate (5) by turning it clockwise.
3) Remove the strainer (6) and the bowl (9).
6) Strainer
7) Pulp Spout
8) Juice Spout
9) Bowl
10) Base
1 1) Clip
5
6
7
8
9
10
11
Assembling Your Juice Extractor
1) Position the bowl onto the stand mixer by aligning
the tabs with the grooves in the base
(10).
2) Insert the strainer by aligning the
tabs.
3) Using the top of the stomper, screw
the grater plate on counterclockwise.
4) Fit the lid, and then swing the clip up
and click it shut.
5) Slide the pulp shield (4) on. Re-
move the high-speed outlet cover.
Attach the juice extractor , and turn it until it locks
into place. Figure 1.
6) Place a container under the spout.
Preparing Food for Your Juice Extractor
1) Remove pits (Ex. plums, peaches and cherries)
2) Remove tough skins (Ex. melons, pineapples,
cucumbers and potatoes.)
3) Soft-skinned and other food just need washing
(Ex. apples, grapes, pears, strawberries, cabbage, carrots, celery, lettuce, parsley, etc.)
4) Cut the food to fit the feed tube.
5) Slide the pulp shield on. Remove the high-speed
outlet cover.
6) Switch the stand mixer to speed 1 and push the
food down with the stomper.
Care and Cleaning for Your Juice Extractor
1) Dismantle before cleaning according to the
directions under “Dismantle the Juice Extractor”.
2) Do not wash any parts in your dishwasher.
Wash parts by hand with mild detergent and
warm water, and then rinse and dry thoroughly.
Figure 1
Care and Cleaning for Your Juice Extractor (con’t)
3) Some foods (Ex. carrots) may discolor the
plastic. Rub the plastic with a cloth dipped in
vegetable oil to help remove the discoloration.
4) Never immerse base in water.
CITRUS JUICER
(Model A995)
Use the citrus juicer to squeeze juice
from citrus fruits (Ex. oranges, lemons,
limes, etc.)
Know Your Citrus Juicer
1) Juicing Cone
2) Strainer
3) Bowl
4) Connector & Washer
Operating Your Citrus Juicer
1) Remove the citrus juicer outlet cover. Use the end
tip of the juicing cone to unscrew the outlet plug.
Figure 1.
2) Screw the connector (with washer) into outlet.
Figure 2. Lower the bowl onto the connector by
turning it clockwise until it drops into place.
Figure 3.
3) Insert the strainer with the pointed part towards
the spout.
1
2
3
4
Figure 1 Figure 2 Figure 3
Operating Your Citrus Juicer (con’t)
4) Insert the juicing cone by turning it until it drops.
5) Cut the fruit in half, Then switch the stand mixer
“on” to speed 4 and press the fruit onto the
cone.
6) The connector may tighten during operation. To
loosen it, refit the bowl and then turn it counterclockwise. Refit the outlet cover after use.
Care and Cleaning for Your Citrus Juicer
1) Wash part s by hand with mild detergent and
warm water , and then rinse and dry thoroughly.
PROFESSIONAL-QUALITY
FOOD GRINDER
(Model A950)
IMPORTANT
SAFEGUARDS
For Your Food Grinder
1) Never feed food by hand. Always use the stomper.
2) Do not use fingers to scrape food from screen
while appliance is operating. This increases the
risk of personal injury .
SAVE THESE
INSTRUCTIONS
Know Your Food Grinder
1) Spanner
2) Ring Nut
3) Three Screens
(fine, medium, coarse)
4) Blade
5) Scroll
6) Grinder Body
7) Tray
8) Stomper
9) Stomper Lid
10) Dish / Cover
1
Assembling Your Food Grinder
1) Fit the scroll (5) inside the grinder body (6). Then
carefully fit the blade (4), with the cutting side on
the outermost part. Figure 1. Be sure that the
blade is fitted properly , otherwise it could damage
the grinder .
2) Fit a grinder screen (3) and put the notch over the
pin using the spanner (1). Figure 2.
3) Note: Use the fine screen for raw meat, fish,
small nuts or cooked meat. Use the medium and
coarse screens for raw meat, fish, nuts, vegetables, hard cheese and peeled or dried fruit.
4) Loosely fit the ring nut (2).
2
5
4
3
10
9
8
7
Figure 1
Figure 2
Operating Your Food Grinder
1) Pull the catch and remove the
low-speed outlet cover from the
stand mixer . Figure 3.
2) Hold the catch back and insert
the grinder. Turn it from side-toside until it locks into place.
3) Tighten the ring nut manually.
4) Fit the tray (7) and put the dish / cover (10) under
the grinder to catch the food.
5) Note: Thaw frozen food thoroughly before mincing. Cut meat into 1-inch strips.
6) Switch the stand mixer to speed 4. Using the
stomper (8), gently push the food through, one
piece at a time. Do not push too hard, you could
damage the grinder.
Sausage Adapater Parts
A) Base Plate
B) Large Nozzle (for thick sausages)
C) Small Nozzle (for thin sausages)
Figure 3
A
B
C
Operating Your Sausage Adapter
1) Note: If you are using skin, soak it in cold water
for 30 minutes first.
2) Pull the catch and remove the low-speed outlet
cover.
3) Hold the catch back and insert the grinder body .
Turn it back and forth until it locks into place.
Loading...
