DSC 90 DF

Dual Fuel Cooker

Users Operating Instructions

Before operating this cooker,

please read these instructions carefully

Congratulations on your purchase of this Delonghi Dual fuel cooker which has been carefully designed and produced to give you many years of satisfactory use.

Before using this appliance it is essential that the following instructions are carefully read and fully understood. We would emphasise that the installation section must be fully complied with for your safety to ensure that you obtain the maximum benefits from your appliance.

Important:

This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment.

The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. a semi commercial, commercial or communal environment.

Introduction

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service. Disposing of a household appliance separately avoids possible negative consequences for the environment and health deriving from inappropriate disposal and enables the constituent materials to be recovered to obtain significant savings in energy and resources. As a reminder of the need to dispose of household appliances separately, the product is marked with a crossed-out wheeled dustbin.

Declaration of CE conformity

✓

This cooker has been designed, constructed and marketed in compliance with:

- Safety requirements of EU Directive "Gas" 90/396/EEC;

- Safety requirements of EU Directive "Low Voltage" 2006/95/EC;

- Protection requirements of EU Directive "EMC" 89/336/EEC;

- Requirements of EU Directive 93/68/EEC.

IMPORTANT INSTRUCTIONS AND ADVICE FOR THE USE OF ELECTRICAL APPLIANCES

The use of any electrical appliance requires the compliance with some basic rules, namely:

– do not touch the appliance with wet or damp hands (or feet) – do not use the appliance whilst in bare feet – do not allow the appliance to be operated by children or unqualified persons

without supervision.

The manufacturer cannot be deemed responsible for damages caused by wrong or incorrect use.

IMPORTANT SAFEGUARDS AND RECOMMENDATIONS

After having unpacked the appliance, check to ensure that it is not damaged. In case of doubt, do not use it and consult your supplier or a professionally qualified technician. Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not be left around within easy reach of children, as these may cause serious injuries.

■ ATTENTION: please peel plastic cover off both sides and front of the cooker

before use.

■ Do not attempt to modify the technical characteristics of the appliance as this may

cause danger to users.

■ Do not carry out any cleaning or maintenance operations on the appliance without

first disconnecting it from the electric power supply.

■ If you should decide not to use this appliance any longer (or decide to substitute an

older model), before disposing of it, it is recommended that it is made inoperative in an appropriate manner in accordance to health and environmental protection regulations, ensuring in particular that all potentially hazardous parts be made harmless, especially in relation to children who could play with unused appliances.

■ After use, always ensure that the control knobs are in the off position.

■ The appliance is not intended for use by young children or infirm persons unless they

have been adequately supervised by a responsible person to ensure that they can use the appliance safely.

■ During and after use of the cooker, certain parts will become very hot. Do not touch

hot parts.

■ Young children should be supervised to ensure that they do not play with the appli-

ance.

■ Some appliances are supplied with a protective film on steel and aluminium parts.

This film must be removed before using the appliance.

■ WARNING

When correctly installed, your product meets all safety requirements laid down for this type of product category. However special care should be taken around the rear or the underneath of the appliance as these areas are not designed or intended to be touched and may contain sharp or rough edges, that may cause injury.

■ Fire risk! Do not store flammable material in the oven.

■ Make sure that electrical cords connecting other appliances in the proximity of

the cooker cannot come into contact with the hob or become entrapped in the oven door.

■ Do not line the oven walls with aluminium foil. Do not place baking trays or the

drip tray on the base of the oven chamber.

■ The manufacturer declines all liability for injury to persons or damage to proper-

ty caused by incorrect or improper use of the appliance.

■ The various components of the appliance are recyclable. Dispose of them in

accordance with the regulations in force in your country. If the appliance is to be scrapped, remove the power cord.

■ Always use oven gloves when removing the shelves and food trays from the

oven whilst hot.

■ Do not hang towels, dishcloths or other items on the cooker or its handle – as

this could be a fire hazard.

■ Clean the oven regularly and do not allow fat or oils to build up in the oven

base or trays. Remove spillages as soon as they occur.

■ Do not stand on the cooker or on the open oven door.

■ Always stand back from the cooker when opening the oven door to allow

steam and hot air to escape before removing the food.

■ This appliance is for domestic use only.

■ WARNING: Taking care NOT to lift the cooker by the door handles.

■ Safe food handling: leave food in the oven for as short a time as possible

before and after cooking. This is to avoid contamination by organisms which may cause food poisoning. Take particular care during warmer weather.

COOKING HOB

1. Auxiliary burner (A) 1,00 kW

2. Semi-rapid burner (SR) 1,75 kW

3. Rapid burner (R) 3,00 kW

4. Triple-ring burner (TR) 3,50 kW

Important Note:

The electric ignition is incorporated in the knobs.

Cooking hob

Fig. 1.1

Control panel

CONTROL PANEL - Controls description

1. Minute counter

2. Oven switch knob

3. Oven thermostat knob

4. Front left burner control knob

5. Rear left burner control knob

6. Central burner control knob

7. Rear right burner control knob

8. Front right burner control knob

9. Thermostat indicator light

Fig. 2.1

145

Please note: This appliance incorporates a safety cooling fan which you will hear operating whenever the oven or grill are in use. This fan is to reduce the external temperature of the appliance and cool the internal components.

Minute counter

MINUTE COUNTER

The minute counter is a timed acoustic warning device which can be set for a maximum of 60 minutes. The knob (Fig. 3.1) must be rotated clockwise as far as the 60 minute position and then set to the required time by rotating it anticlockwise.

Fig. 3.1

HOB BURNERS

Each hob burner is controlled by a separate gas tap operated by a control knob (fig. 4.1) which has 3 positions marked on the control panel, these are:

– Symbol

0 : tap closed (burner off)

– Symbol : High (maximum)

– Symbol : Low (minimum) Push in and turn the knob anti-

clockwise to the selected position.

LIGHTING THE BURNERS

To ignite the burner, the following instructions are to be followed:

1) Lightly press and turn the knob anti-clockwise, and position the knob indicator to the symbol printed on the control panel (fig. 4.1).

2) Press the knob to operate the electric ignition; or, in the case of a mains failure light the burner with a match or lighted taper.

3) Adjust the burner according to the setting required.

Low High

To turn the burner off, fully rotate the knob clockwise to the off position:

The maximum setting of the control tap is for boiling, the minimum setting is for slow cooking and simmering.

All working positions must be choosen between the maximum and minimum setting, never between the maximum setting and the “OFF” position.

Fig. 4.1

Electric ignition

The sparks generated by the electrodes close to the burners will ignite the choosen burner. Whenever the lighting of the burners is difficult due to peculiar conditions of the gas features or supply, it is advised to repeat the ignition with the knob on “minimum” position.

How to use the hob burners

CHOICE OF THE BURNER

On the control panel, near each knob, there is a diagram that indicates which burner is controlled by that knob. Select the burner that is most suitable for the diameter and capacity of the pan to be used. As an indication, the burners and the pans must be used in the following way:

It is important that the base diameter of the pot is at least the same diameter as the burner ring to obtain an efficient heat transfer. Always position pans centrally over the burners.

Adjust the size of the flame so that it does not lick up the side of the pan. Position pan handles so that they cannot be accidentally knocked.

Fig. 4.2

BURNERS POT DIAMETER

Auxiliary 12 ÷ 14 cm Semi-rapid 16 ÷ 24 cm Rapid 24 ÷ 26 cm Triple-ring 26 ÷ 28 cm

do not use pans with concave or convex bases

Fan oven

GENERAL FEATURES

The heating and cooking in electrical hot air ovens take place by forced convection. The two elements which make this process take place are:

- Circular element 2500 W

- Grill element 2200 W NOTE:

Upon first use, it is advisable to operate the oven at the maximum temperature (thermostat knob on position 250) for 60 minutes in the position (fan oven) and for another 15 minutes in the position (thermostat knob on position 200°C), to eliminate possible traces of grease on the heating elements.

WARNING: The door is hot, use the handle.

ATTENTION - MOST IMPORTANT Pay special attention not to touch the hot heating element inside the oven cavity.

OPERATING PRINCIPLES

Heating and cooking in the FAN oven are obtained in the following ways:

a. by forced convection

A fan sucks in the air contained in the oven muffle, which sends it through the circular heating element and then sends it back through the muffle. Before the hot air is sucked back again by the fan to repeat the described cycle, it envelops the food in the oven, provoking a complete and rapid cooking. It is possible to cook several dishes simultaneously.

b. by radiation

The heat is radiated by the infra red grill element.

c. by ventilation

The food is defrosted by using the fan only function without heat.

Attention: the oven door becomes very hot during operation. Keep children away.

Fig. 5.1

Fig. 5.2

FUNCTION SELECTOR KNOB (Fig. 5.1)

Rotate the knob clockwise to set the oven for one of the following functions.

THERMOSTAT KNOB (Fig. 5.2)

This only sets the cooking temperature and does not switch the oven on. Rotate clockwise until the required temperature is reached (from 50 to 250°C). The light above the temperature selector will illuminate when the oven is swiched on and turns off when the oven reaches the correct temperature. The light will cycle on and off during cooking in line with the oven temperature.

OVEN LIGHT

By setting the knob to this position, only the oven light comes on. It remains on in all the cooking modes.

DEFROSTING FROZEN FOODS

Only the oven fan comes on. Use with the thermostat knob set to “0” - other positions have no effect. The food is thawed by ventilation without heating.

Recommended for: Quick thawing of frozen foods; one kg requires approximately 1 hour. Thawing times vary according to the quantity and type of food to be thawed.
