DeLonghi DS 61 GW User Manual

INSTALLATION and SERVICE INSTRUCTIONS

USE and CARE INSTRUCTIONS

DS 61 GW

DUAL FUEL COOKER

distributed by

DèLonghi

Pty Ltd

Dear Customer,

Thank you for having purchased and given your

preference to our product.

The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.

Please keep this booklet in a safe place. It may be useful in future, either to yourself or to others in the event that doubts should arise relating to its operation.

This appliance must be used only for the task it has explicitly been designed for, that is for cooking foodstuffs. Any other form of usage is to be considered as inappropriate and therefore dangerous.

The manufacturer declines all responsibility in the event of damage caused by improper, incorrect or illogical use of the appliance or be faulty installation.

PRODUCT LABEL

Important:

This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment.

The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. a semi commercial, commercial or communal environment.

FIRST TIME USE THE OVEN

It is advised to follow these instructions:

■ Clean the interior of the oven with cloth soaked in water and detergent

(neutral) then dry carefully.

■ Fit the wire racks as described at chapter “Use and care”.

■ Insert shelves and tray.

■ Switch on the empty oven on max to eliminate grease tracks from the heating

elements.

IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR USE OF ELECTRICAL APPLIANCES

Use of any electrical appliance implies the necessity to follow a series of fundamental rules. In particular:

■ Never touch the appliance with wet hands or feet;

■ do not operate the appliance barefooted;

■ The appliance is not intended for use by young children or infirm persons

with supervision

■ Young children should be supervised to ensure they do not play with the

appliance

The manufacturer cannot be held responsible for any damages caused by improper, incorrect or illogical use of the appliance.

IMPORTANT PRECAUTIONS AND RECOMMENDATIONS

After having unpacked the appliance, check to ensure that it is not damaged. In case of doubt, do not use it and consult your supplier or a professionally qualified technician. Packing elements (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not be left around within easy reach of children, as these may cause serious injuries.

■ Do not attempt to modify the technical characteristics of the appliance as this may

become dangerous to use.

■ Do not carry out cleaning or maintenance operations on the appliance without hav-

ing previously disconnected it from the electric power supply.

■ After use, ensure that the knobs are in off position.

■ Do not allow children or other incapable people to use the appliance without super-

vision.

■ During and after use of the cooker, certain parts will become very hot. Do not touch

hot parts.

■ Keep children away from the cooker when it is in use.

■ Some appliances are supplied with a protective film on steel and aluminium parts.

This film must be removed before using the appliance.

■ Fire risk! Do not store flammable material in the oven, and in the accessory draw-

er.

■ Make sure that electrical cables connecting other appliances in the proximity of the

cooker cannot come into contact with the hob or become entrapped in the oven door.

■ Do not line the oven walls with aluminium foil. Do not place baking trays or the drip

tray on the base of the oven chamber.

■ The manufacturer declines all liability for injury to persons or damage to property

caused by incorrect or improper use of the appliance.

■ IMPORTANT NOTE: This appliance shall not be used as a space heater,

especially if installed in marine craft or caravans.

This cooker has been designed and constructed in accordance with the following codes and specifications:

AGA101 (AS 4551) Approval Requirements for Domestic Gas cooking appliances AS/NZS 3350-1 General Requirements for Domestic electrical appliances AS/NSZ 3350-2-6 Particular Requirements for Domestic electrical cooking appliances AS/NSZ 1044 Electromagnetic Compatibility Requirements.

CAUTION:

■

This appliance must be installed in accordance with these installation instructions.

■

This appliance shall only be serviced by authorized personnel.

■

This appliance is to be installed only by an authorised person.

■

Incorrect installation, for which the manufacturer accepts no responsibility, may cause personal injury of damage.

■

Always disconnect the cooker from mains power supply before carrying out any maintenance operations or repairs.

■

In the room where the cooker is installed, there must be enough air to allow the gas to burn correctly, according to the current local regulations.

INSTALLATION

ELECTRICAL REQUIREMENTS

■ The appliance must be connected to the mains checking that the voltage corre-

sponds to the value given in the rating plate and that the electrical cable sections can withstand the load specified on the plate.

■ The plug must be connected to an earthed socket in compliance with safety

standards.

■ If the appliance is supplied without a plug, fit a standard plug which is suitable

for the power consumed by the appliance.

■ The appliance must be connected directly to the mains placing a two pole

switch with minimum opening between the contacts of 3 mm between the appliance and the mains.

■ The power supply cable must not touch the hot parts and must be positioned so

that it does not exceed 50°C above ambient.

■ Once the appliance has been installed, the switch or socket must always be

accessible.

■

If the supply cord is damaged it must be replaced by the manufacturer or it’s Service Agent or a similarly qualified person in order to avoid a hazard.

WARNING: This cooker must be connected to electrical supply using V105 insulated cable.

N.B. The connection of the appliance to earth is mandatory.

If the installation requires alterations to the domestic electrical system call a qualified electrician. He should also check that the socket cable section is suitable for the power drawn by the appliance.

CLEARANCES

Installation clearances and protection of combustible surfaces shall comply with the current local regulations eg. AG 601 (AS 5601) Gas Installations code. Installation shall comply with the dimension in Fig 1 bearing in mind that

Overhead Clearances

In no case shall the clearances between the highest part of the cooker be less than 600mm or for an overhead exhaust fan 750mm. AII other downward facing combustible surfaces less than 600mm above the cooker surface shall be protected for the full width of the cooking surface in accordance with the standards noted above. In no case shall the clearance be less than 450mm.

Rear and Side Clearances

Where the dimensions from the periphery of the nearest burner to any vertical combustible surface is less than 200mm the surface shall be protected in accordance with the standards to a height of not less than 150mm above the cooking surface for the full width or depth of the cooking surface Where the dimensions from the periphery of the nearest burner to any horizontal combustible surface is less than 200 mm, the horizontal surface shall be greater than 10 mm below the surface of the hob, or the horizontal surface requirement above.

Protection of combustible surfaces.

The standards above specify that where required protection shall ensure that the surface temperature of the combustible surface does not exceed 65°C above room temperature.

If the cooker is located on a pedestal it is necessary to provide safety measures to prevent falling out.

Figure 1

105 m

500 mm

750 mm

450 mm

Cooker overall dimensions [mm]

• height: min 900 - max 935

• width: 600

• depth: 600

Figure 2

ANTI-TILT BRACKET

Warning: This appliance must be restrained to prevent accidental tipping by fitting a

bracket to the rear of the appliance and securely fixing it to the wall. Fixing the anti-tilt bracket:

■ After you have located where the cooker is to be positioned mark, on the wall,

the place where the 2 screws of the anti-tilt bracket have to be fitted. Please follow the indications given in the drawing below.

■ Make two holes of diameter 8mm diameter on the wall and insert the plastic

plugs.

■ Attach the anti-tilt bracket loosely by means of 2 screws.

■ Move the cooker to the wall and adjust the height of the anti-tilt bracket so that

it can engage in one slot of the cooker back.

■ Attach the anti-tilt bracket tight.

■ Push the cooker against the wall so that the anti-tilt bracket is fully inserted in

one slot of the cooker back.

+ 35

5 0

a m

LEVELLING

The cooker is equipped with 4 levelling feet which must be fitted to the base of the cooker in the following manner:

■ Place the cooker on its back as shown in the figure 3.

■ Screw the 4 leveling feet to the cooker.

■ Stand the cooker and level it by screwing or unscrewing the feet with a span-

ner.

Figure 3

GAS SUPPLY:

■ The connection must be performed by an authorised person according to the

relevant standards.

■ Before connecting the appliance to the gas main, mount the brass conical adap-

tor onto the gas inlet pipe, upon which the gasket has been placed (figs. 4-5). Conical adaptor and gasket are supplied with the appliance (packed with con-

version kit for use with Natural gas or Propane gas).

■ This appliance is suitable for use with Natural Gas or Propane gas. (Check the

“gas type” sticker attached to the appliance).

■ For Natural Gas models the gas supply is connected to the pressure regulator

which is supplied with the appliance (fig. 5). Adjust the regulator to obtain a test point pressure of 1 kPa with the two semi-rapid (SR) burners operating at maximum.

■ For Propane gas models the gas supply is connected to the test point adaptor

which is supplied with the appliance (fig. 4) and ensure that the supply pressure is regulated to 2.75 kPa.

■ The connection must be made at the rear of appliance (left or right); the pipe

does not cross the cooker.

■ The inlet not used must be closed off with the cap and sealing gasket supplied.

■ IMPORTANT: Use two spanners to tighten or loosen the connecting pipe (fig. 6)

Gas connection for

PROPANE GAS

Figure 5

Figure 4

Gas connection for

NATURAL GAS

Gas inlet pipe

Nipple

Gasket

Brass conical adaptor

(Thread tight: use suitable seal)

Gas inlet pipe

Nipple

Gasket

Brass conical adaptor

(Thread tight: use suitable seal)

Gas regulator

Test point adaptor

Test point

Figure 6

Figure 7

1. After connecting the gas supply, check the piping and connections for leaks using a soap and water solution. The presence of bubbles indicates a leak, tighten or replace connections as appropriate. Warning: Do not use any naked flame to check for leaks.

2. Adjust the test point pressure or supply pressure to the value which is appropriate for the gas type.

3. The operation of the appliance must be tested when installation is completed.

4. Turn on the appliance gas controls and light each burner individually and in combination. Check for a well defined blue flame without any yellow tipping. If any abnormality is evident then check that the burner cap is located properly and the injector nipple is aligned correctly.

5. Check the minimum burner setting by quickly rotating the gas control knob from the maximum to the minimum position, the flame must not go out. If adjustment is required carry out the “minimum burner setting adjustment" procedure described

6. If satisfacfory performance cannot be obtained, the installer shall check the installation and notify the local gas supply authority for a gas supply problem, or if it is an appliance problem, our Customer Service Centre should be called to obtain the nearest authorized Delonghi Service Agent.

WARNING, This appliance IS NOT SUITABLE for installation with a hose

assembly.

Plug

Figure 8a

Figure 8b

CONVERSION PROCEDURE (to convert to LPG Propane)

REPLACING THE INJECTORS

This appliance is suitable for use with Natural gas or Propane gas (check the “gas type”

sticker attached to the appliance). A label stating the type of gas used after replacing the injectors must be attached at the rear of the appliance, in proximity of the gas inlet connection. The nominal gas consumption and injector size details are provided in table at page 13.

To replace the injectors proceed as follows:

■ Remove pan supports and burners from the cooktop.

■ Using a spanner, remove the injector J (fig. 8a, 8b) and replace it with one

according to the gas type (see following tables - page 13).

■ Affix to the rear of the appliance, in proximity of the gas inlet connections, the

warning label (supplied with the conversion kit) stating that the cooker has been converted for use with Propane gas / Natural gas.

IMPORTANT

■ If the cooker is suitable for use with Natural gas and must be converted for use

with Propane gas, before connecting to gas main remove the appliance gas regulator and replace with test point adaptor (see fig. 4-5)

■ If the cooker is suitable for use with Propane gas and must be converted for use

with Natural gas, before connecting to the gas main remove the appliance test point adaptor and replace with gas regulator (see figs. 4-5).

NOTE: Gas regulator and test point adaptor are supplied with the appliance (packed with conversion kit)

The burners are designed so that regulation of primary air is not required.

MINIMUM BURNER SETTING ADJUSTMENT

Check whether the flame spreads to all burner ports when the burner is lit with the gas tap set to the minimum position. If some ports do not light, increase the minimum gas rate setting.

Check whether the burner remains lit even when the gas tap is turned quickly from the maximum to the minimum position. If the burner does not remain lit, increase the minimum gas rate setting.

The procedure for adjusting the minimum gas rate setting is described below.

■ Turn on the burner

■ Turn the tap to the MINIMUM position

■ Take off the knob

■ With a small flat screwdriver turn the screw “F” (fig. 9) to the correct regulation.

Normally for Propane gas, the regulation screw is tightened up.

Figure 9
