Dell WPER 116GN User Manual

WiFi Network card

Quick Installiaton Guide

Version 1.0

PRODUCT SPECIFICATION

Model Name

WPER-116GN

Bus Interface

PCI Express

Form Factor

Mini PCIe

Frequency Band

2.4GHz~2.484GHz

Chipset Solution

Ralink RT3090

RF Chain

1 Transmitter and 1 Receiver

Antenna Port

1 Main: TX0 ; RX0

Dimension

30.00mm x 26.80mm x 3.3mm (+/- 0.15 mm)

Channel Number

802.11b mode

US : Ch 1 ~ Ch 11
EU : Ch 1 ~ Ch 13
Japan : Ch 1 ~ Ch 14

802.11g mode

US : Ch 1 ~ Ch 11
EU : Ch 1 ~ Ch 13
Japan : Ch 1 ~ Ch 13

EWC 20MHz Bandwidth

US : Ch 1 ~ Ch 11
EU : Ch 1 ~ Ch 13
Japan : Ch 1 ~ Ch 13

EWC 40MHz Bandwidth

US : Ch 3 ~ Ch 9
EU : Ch 3 ~ Ch 11

Data Rate

11b mode

1, 2, 5.5, 11Mbps

11g mode

6, 9, 12, 18, 24, 36, 48,54Mbps

EWC mode

Refer Table1.1

Modulation

11b mode

DSSS(PSK/CCK, DBPSK, DQPSK)

11g mode

OFDM(BPSK, QPSK, 16-QAM, 64QAM)

EWC mode

OFDM(BPSK, QPSK, 16-QAM, 64QAM)

RF output power

11b mode

17 dBm ± 1.5 dBm

11g mode

14 dBm ± 1.5 dBm

EWC 20MHz

14 dBm ± 1.5 dBm

EWC 40MHz

14 dBm ± 1.5 dBm

Receive Sensitivity

11b mode

-85dBm@1Mbps, ± 2dB

11g mode

-65dBm@54Mbps, ± 2dB

EWC 20MHz

-65dBm@MCS7, ± 2dB

EWC 40MHz

-60dBm@MCS7, ± 2dB

Power requirements

DC3.3V ± 10%

Power consumption

Continue TX : Max 450mA
Continue RX : Max 300mA
Idle mode : Max 150mA

Security

WEP / WPA / WPA2

Cisco CCX

CCX5 Compliance

Software support

Windows XP/Vista/Win7/Linux/WinCE driver

Operating Range

The transmission speed varies in the surrounding environment.

Temperature

0 ~ 55°C (Operating), -20~85°C (Storing)

WPER-116GN

1

Contents

1. Package Contents ........................................................................................................... 3

2. WiFi Network Card Installation ........................................................................................ 4

3. Connect to Wireless Access Point .................................................................................. 8

2

Copyright statement

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in
any form or by any means, whether electronic, mechanical, photocopying, recording, or
otherwise without the prior writing of the publisher.

April 2012

3

1. Package Contents

Before you starting to use this WiFi network card, please check if there’s anything missing in
the package, and contact your dealer of purchase to claim for missing items:

Package Contents

Please make sure you have the following in the box:

 WiFi network card
 CDROM

Note: if anything is missing, please contact your vendor
