Introduction |
a @s @f |
QP |
Thank you for purchasing a Firstech system for your vehicle. In order to truly enjoy the benefits of this system, we recommend that you |
|
|
thoroughly review the following manual. Please note that this manual applies to the 1 Way-4 Button Non Liquid Crystal Display Remotes, |
r @c @O@p @r H I |
QP |
regardless of whether you purchased the alarm only, starter only or alarm/starter combination. There are certain features listed in this manual |
|
|
that may not be available for your system. There may also be features listed in this manual that require additional installation or programming |
p @Qw @Tb @r |
QP |
before they are active. If you have any questions, please contact the original place of purchase. For further information you may also contact our |
|
|
customer support center by calling 888-820-3690. |
r @s @e @d |
|
a @d |
QR |
l @l @w |
QT |
Warranty Coverage
Caution: The Manufacture’s warranty will be voided if this product is installed by anyone other than an authorized Firstech dealer. For complete warranty details visit www.compustar.com or the last page of this manual. Firstech remotes carry a 1 year warranty from original date of purchase.
Warranty registration can be completed online by visiting www.compustar.com. Please complete the registration form within 10 days of purchase. We do not include a mail in warranty registration card with each unit. Registration must be done online. To verify that an authorized dealer installed your system, we highly recommend that you keep a copy of the original proof of purchase, such as the dealer invoice in a safe place.
ByFirstech,LLC 2 |
3 ByFirstech,LLC |
Quick Reference
v @m
When servicing or loaning your vehicle to others, the system should be in Valet mode. Valet mode prevents the system from remote starting and disables all alarm functions.
IMPORTANT: While in Valet mode the remote will still control power lock and unlock systems. The parking lights will not flash.
The system can be put into valet one of three ways:
1. Turn the vehicle’s key to the ignition “on” position and tap buttons simultaneously for 0.5 seconds. The parking lights will flash once and/or siren chirp once to confirm the system is in valet mode. Repeat this process to take the system out of valet mode. The parking lights will flash twice and/or siren chirp once to confirm the system is out of valet mode.
2.If you don’t have your remote control, you can put the system into valet by turning the ignition key “on” and then “off” five times within 7 seconds. The parking lights will flash once to confirm the system is in valet mode. Shortly after the first flash, the parking lights will flash twice. A remote control is required to take the system out of valet mode. IMPORTANT: If your system is set up for a secure valet option, you will not be able to put the system into valet until the proper code has been entered to the secure valet switch.
3.If your system is set up with the secure valet switch (optional), you will not be able to put the system into valet until the proper code has been entered to the secure valet switch. The secure valet switch is the small button with bright blue LED on the front and if installed is the only way to override the alarm and/or remote start. The default code is (3, 3).
r @m Mb @r
The only regular maintenance this system requires is remote control battery replacement. No programming is required when replacing the battery.
First, remove the small Phillips screw located on the back of the remote. Once the screw has been removed, gently pull the remote apart taking care to not damage the circuit board. 1 Way remote batteries differ among the models. Your battery size should be listed on the battery. Replacements can be purchased from your local Firstech dealer or an electronics store.
Q@w @r @b @f
Button |
Duration |
Additional |
Function / Description |
|
|
ProgrammingRequired |
|
|
0.5 seconds |
no |
Locks doors and/or arms alarm. |
|
|
|
|
|
3.5 seconds |
no |
Panic/vehicle locater (flashes vehicle’s parking lights and sounds siren and horn). |
|
|
|
|
|
0.5 seconds |
no |
Unlocks doors and/or disarms alarm. |
|
0.5 seconds |
no |
Aux 1. Triggers the auxiliary 1 output |
|
|
|
(most commonly used for rear defrost or window roll-down) |
|
|
|
|
|
2.5 seconds |
no |
Trunk pop. Triggers the trunk release output and opens the vehicle’s trunk. |
|
|
|
|
ByFirstech,LLC |
4 |
5 ByFirstech,LLC |
Button |
Duration |
Additional |
Function / Description |
ProgrammingRequired |
|||
|
0.5 seconds |
no |
Aux2.Triggerstheauxiliary2output(mostcommonlyusedforreardefrostorwindowroll-down) |
|
|
|
|
|
2.5 seconds |
no |
Activates the remote start. Repeat and remote start will shut off. |
|
|
|
|
|
0.5 seconds |
no |
Turnssirenon/off(Note: Withthesirenoff,itwillstillsoundintheeventthealarmistriggered) |
|
|
|
|
|
0.5 seconds |
no |
Valet mode (see Valet Mode section for details) |
|
|
|
|
|
2.5 seconds |
no |
Turns the shock sensor on/off. (Alarm or Alarm/Starter systems only) |
|
|
|
|
|
0.5 seconds |
yes |
Drive lock. Activates ignition controlled door locks. |
|
|
|
|
|
0.5 seconds |
no |
Activates passive arming (vehicle will arm/lock 30 seconds after the vehicle is disarmed) |
|
|
|
|
|
0.5 seconds |
yes |
Activates timer start mode. Timer start mode has multiple programmable settings: |
|
duration settings, temperature settings and self start settings. |
||
|
|
|
|
|
|
|
|
|
0.5 seconds |
yes |
Activates the built in Turbo timer function. Additional installation is required when using |
|
this feature on automatic transmission vehicle’s. |
||
|
|
|
|
|
|
|
|
|
2.5 seconds |
no |
Car Check (updates vehicle status on remote pager) / Secure Auxiliary |
|
|
|
|
General System Functions
The remote transmitter functions have been predetermined and programmed from the factory. The four button configuration allows for many functions to be performed through a series of tapping, holding and / or multiple presses of buttons. Although Firstech remotes have numerous button functions and capabilities, please keep in mind that the most common functions are performed in one simple step. There are advanced features not described in this manual. Please go to www.compustar.com for more details.
a @l Oa @ @u Od
Tap button |
for 0.5 seconds to lock/arm and unlock/disarm. The LED will flash on your remote. If your vehicle is locked, tap |
|
button |
to unlock; if your vehicle is unlocked, tap button |
to lock. |
IMPORTANT: If the alarm has been triggered (Siren is going off), you must wait up to 5 seconds before disarming the alarm - the first button tap will shut off the alarm and the second will unlock/disarm the system.
a @t @r @ @f
Press the button for 2.5 seconds to remote start an automatic transmission vehicle. If you are in range and if the vehicle is ready to remote start, the parking lights will flash once and/or siren chirp once to indicate that the remote start command has been successfully transmitted.
If you are in range and the parking lights flash and/or vehicle’s siren chirps three times, there is a remote start error. Refer to the “remote start error diagnostic” at the end of this manual for details.
The remote start run time can be programmed for 3, 15, 25, or 45 minutes - ask your local Firstech dealer to adjust Option 2-7 if you would like a run time other than 15 minutes (default).
IMPORTANT: Your vehicle’s key must be inserted into the ignition and turned to the “on” position prior to driving your vehicle. If the foot brake is depressed prior to the key being in the “on” position, the vehicle will shut off.
ByFirstech,LLC 6 |
7 ByFirstech,LLC |
General System Functions
m @t @r @s @f @Hr @m I
In order to remote start a manual transmission vehicle, the system must first be set in Reservation Mode. Reservation Mode must be set each and every time you want to remote start a manual transmission vehicle. The purpose of Reservation Mode is to leave the transmission in neutral before exiting the vehicle.
IMPORANT
The transmission must be left in the neutral position. |
The vehicles windows must be rolled up. |
The vehicles door pins must be in working order. |
Do not set reservation mode or remote start with people in the vehicle. |
Do not install this remote start on a manual transmission vehicle that has a convertible or removable top.
Activating Reservation Mode
STEP 1: While the vehicle is running, place the transmission in neutral, set the emergency / parking brake, and remove pressure from the foot brake.
STEP 2: Remove the key from the vehicle’s ignition. The vehicle’s engine should remain running even after the key has been removed. If the vehicle does not remain running make sure your system is not in Valet mode and then contact your local authorized dealer for service.
STEP 3: Exit the vehicle and close the door. The vehicle’s engine should shut off within 10 seconds upon closing the last door. Most motors will shut off instantly upon closing the last door. If the vehicle’s engine does not shut off, your door trigger may be functioning improperly. Do not use the remote start feature and take your vehicle to a local authorized dealer for service.
IMPORTANT: By default, the system will lock/arm the vehicle upon setting reservation mode. Take care to not lock your keys inside the vehicle.
Cancelling Reservation Mode
Reservation mode will be cancelled for the following reasons;
You did not activate the parking brake prior to turning off the ignition. You pressed the foot brake after the key was removed from the ignition.
You released the parking brake after the key was removed from the ignition.
You entered valet mode, opened the vehicles door, hood, trunk or set off the alarm.
t @r
Hold button for 2.5 seconds to release the trunk or hatch. If you are in range, the vehicle’s parking lights will flash once and/or siren chirp once indicating that the trunk release command has been successfully transmitted.
IMPORTANT: Trunk release is an optional vehicle feature that may require additional parts and labor.
s @a Od
Upon lock/arm and unlock/disarm, you can eliminate vehicle’s audible confirmation by muting the siren. Normally, the siren will chirp once to indicate the system is locked/armed and twice to indicate the system is unlocked/disarmed. To mute the siren tap buttons simultaneously for 0.5 seconds.
IMPORTANT: Even when the siren is muted, it will still go off in the event the alarm is triggered.
s @s @o Oo
Hold buttons simultaneously for 2.5 seconds to turn the shock sensor on and off. The vehicle’s parking lights will flash once and/or siren chirp once to confirm the shock sensor is on. The vehicle’s parking lights will flash twice and/or siren chirp twice
to confirm the shock sensor is off. IMPORTANT: Turning off the shock sensor also turns off the optional sensor(s). The shock sensor does not recognize impact for 30 seconds after the system has been armed.
