CLASSÉ AUDIO
S-700
ULTRA HIGH CURRENT
STEREO/MONO POWER AMPLIIFER
S-700
OWNER'S MANUAL
CLASSÉ DESIGN PHILOSOPHY
1. REPEATED LISTENING DESIGN SESSIONS:
Fine tuning of sound by exchanging and mixing of parts (transistors, capacitors, wiring, PCB boards etc.), and adjusting many specific operating voltages within proper engineering ranges, producing an overall sonic recipe giving the most natural harmonic realism of music typical of instruments in a live performance.
2. UPGRADABLE SINGLE CIRCUIT DESIGNS:
All Classé products (all preamps and all amps) share exactly the same circuit design philosophy (excluding moving coil and moving magnet phono circuits). This means all amplifiers and all high level circuits of the preamps benefit from the same design goals. Similar circuits are then tailored to different power levels etc. Differences between less expensive models and more expensive models are parts quality and compliment, power supply extravagance and the amount of filtering etc., as well as features and packaging.
This means that for years Classé has been constantly sonically fine tuning and technically upgrading this circuit design and its application, thus reaching a very high level of natural musical enjoyment, as well as excellent reliability which benefits all models - least expensive, most expensive, preamps and amplifiers alike.
3. EXTREME LONG LIFE IN REAL WORLD CONDITIONS:
Choosing the best attainable quality parts and materials combined with the advantages of the two above-mentioned areas provides Classé owners with years of proven trouble free reliability and musical enjoyment.
S-700
OWNER'S MANUAL
TABLE OF CONTENTS
UNPACKING & SET-UP................................................................ |
4 |
GENERAL CONNECTIONS.......................................................... |
5 |
CONNECTIONS FOR REGULAR OR BALANCED INPUTS.... |
7 |
WARRANTY.................................................................................... |
8 |
SPECIFICATIONS ......................................................................... |
10 |
WARRANTY REGISTRATION.................................................... |
11 |
-3-
UNPACKING & SET-UP
Your CLASSÉ S-700 power amplifier is packed in high density, semi-rigid foam placed in a special cardboard box. To remove the unit, open and spread all the top flaps of the box and by its sides, lift out the entire unit and put it on a large flat surface. Take it out of the plastic bag and inspect the unit for any concealed damage. Apart from this owner's manual, please ensure the following has also been included:
1)Detachable linecord
2)Allen key for top plate
3)Nut driver for CLASSÉ output bolts
Please report any damage or missing parts to your dealer as soon as possible.
Place the S-700 at or near its final set-up position, allowing 8 inches at the rear for tightening the speaker output connectors.
The power transformer in the S-700 is located at the front-center of the unit. Ideally, a few feet should separate this area from components which potentially could pick up hum. These include preamplifiers, turntables, and interconnect cables. In terms of providing adequate airspace for cooling, a good rule of thumb is to allow 6 inches above and 3 inches on each side of the unit.
Check the Serial Number sticker on the back of the unit for the correct operating voltage. The S- 700 has only one fuse, the rating of which should be as follows:
LINE VOLTAGE |
FUSE RATING |
|
100 or 120 V.A.C. |
12 AMP FAST BLOW |
125 or 250 volts |
220 or 240 V.A.C. |
8 AMP FAST BLOW |
250 volts |
-4-
