Clarke CGS 8K, 7724026 User guide

KEY LOCK GUN SAFE

MODEL NO: CGS3K, CGS5K, CGS8K

PART NO: 7724020,7724023, 7724026

OPERATION & MAINTENANCE

INSTRUCTIONS

ORIGINAL INSTRUCTIONS

LS0519

INTRODUCTION

Thank you for purchasing this CLARKE Key Lock Gun Safe.

Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you and you can look forward to your purchase
giving you long and satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.

Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.

This guarantee does not effect your statutory rights.

SPECIFICATIONS

Model Number CGS3K CGS5K CGS8K

Part Number 7724020 7724023 7724026

External Dimensions (mm) 250 x 250 x 1450 350 x 340 x 1450 490 x 360 x 1450

Fixing Hole diameter (mm) 10 10 10

Capacity 3 Guns 5 Guns 8 Guns

Maximum Gun Length (mm) 1260 1260 1260

Ammunition Box Dimensions (mm) 250 x 135 x 150 340 x 145 x 185 480 x 155 x 190

Wall thickness (mm) 4 4 4

Weight (Empty (kg) 36.4 53 61.5

2

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

CARTON CONTENTS

The following items should be supplied in the carton. If any parts are missing or
damaged, please see your Clarke dealer.

1 x Gun Safe

2 x Gun Safe Keys

2 x Ammunition Safe Keys

2 x Expansion Bolts

PART IDENTIFICATION

3

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

INSTALLATION

Remove everything from the box and dispose of any packaging materials in
an environmentally friendly way.

FIXING THE GUN SAFE IN POSITION

1. Your gun safe must be securely fixed to the structure of the building.

• Ideally it must be in a room or space that does not have direct
access to the outside of the building.

• It must not be in a garage, shed or other outbuilding.

• When considering the larger or heavier gun safes, you should
consider the load bearing strength of your floors.

• Wherever possible, it should be fixed to either a wall that is built from
bricks or concrete blocks or to the floor. if this is not possible then to a
strong joist using suitable fixings.

• The gun safe must be out of sight. If it is in a corner, it is more difficult
for a thief to attack it.

• You should avoid fixing the gun safe near any heat source.

2. The gun safe must be secured using suitable fixings.

• There are two fixing holes on the rear and four on the bottom.

3. Fit the gun safe flush to the wall.

• If needed remove the skirting boards behind/to the side of the gun
safe as they may leave a large enough gaps for a crowbar to be
used to prise the gun safe away.

NOTE:

IF YOU HAVE ANY QUERIES CONTACT YOUR LOCAL FIREARMS
LICENCING TEAM.

KEYS

1. Remember it is YOUR responsibility to ensure that unauthorised persons can
not gain access to your guns.

• Do not let anyone (including family members) know where the keys

are kept. You may lose your shotgun/firearm certificate if you do.

2. Keep the keys to the gun safe in a place where they can’t be found easily.

• “hiding” keys in a drawer is pretty obvious to a thief, so think carefully

about the hiding place. Consider purchasing a small combination
safe where only you know the combination.

4

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

OPERATING INSTRUCTIONS

OPENING THE GUN SAFE

1. Insert the key into the lock and
turn it clockwise 1/3rd of a turn.

2. Push the handle down and pull
the door towards you.

INSERT THE GUNS

1. Unload the guns and secure the
ammunition in the ammunition
safe.

2. Place the guns into the gun safe
making sure they are resting
securely against the foam inserts.

5

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

THE AMMUNITION SAFE

Inside the gun safe is a small
ammunition safe.

Use the key supplied to access this
compartment.

CLOSING THE GUN SAFE

1. Close the door and lift the handle up.

2. Turn the key anti-clockwise 1/3rd of a turn and remove the key.

6

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

MAINTENANCE AND SERVICING

There are no user serviceable parts in this gun safe, any repairs must be carried
out by Clarke service (see bottom of the page for contact number)

CLEANING

Wipe the surfaces with a damp cloth. Do not use harsh cleaners as they may
damage the finish of your gun safe.

REPLACEMENT KEY

A small label is located on the door of each safe with a key number.

This number must be registered with us in the event you require a replacement
key.

Please complete the registration form supplied and send it to the address
stated with the form.

If you fail to register the safe we will not be able to provide you with a
replacement key.

We recommend that in addition to sending the completed form you remove
the label from the safe and fix it to the space below. Please retain this
document for future reference.

Fix or record the key number here

Key Number....................................................................................

7
