Clarion Automobile Accessories User Manual
CLARION PRODUCT REGISTRATION INFORMATION
For USA and Canada only
www.clarion.com
Dear Customer:
Congratulations on your purchase of a Clarion mobile electronic product. We are
confident that you’ll enjoy your Clarion experience.
There are many benefits to registering your product. We invite you to visit our website at
www.clarion.com to register your Clarion product.
We have made product registration simple with our easy to use website. The registration
form is short and easy to complete. Once you’re registered, we can keep you informed of
important product information.
Register at
www.clarion.com - it’s easy to keep your Clarion product up to date.
Contents
1. FEATURES .................................................................................................................... 3
2. PRECAUTIONS ............................................................................................................. 4
Handling Compact Discs ................................................................................................ 5
Front Panel.....................................................................................................................5
3. CONTROLS ................................................................................................................... 6
Names of the Buttons and their Functions ..................................................................... 7
Major button operations when external equipment is connected to this unit .................. 8
Display Items.................................................................................................................. 9
Display Screen ............................................................................................................... 9
Optional Wired Remote Control Unit Operations.......................................................... 10
Wireless Remote Control Unit Operations.................................................................... 12
4. OPERATIONS.............................................................................................................. 14
DCP (Detachable Control Panel).................................................................................. 14
Basic Operations .......................................................................................................... 15
Radio Operations ......................................................................................................... 17
CD/MP3/WMA Operations............................................................................................ 19
Common Operations .................................................................................................... 23
5. ACCESSORIES ........................................................................................................... 27
Sirius Satellite Operations ............................................................................................ 27
iPod Operations............................................................................................................ 30
CD Changer Operations ............................................................................................... 32
TV Operations .............................................................................................................. 34
6. TROUBLESHOOTING................................................................................................. 35
7. ERROR DISPLAYS...................................................................................................... 37
8. SPECIFICATIONS ....................................................................................................... 38
English
1. FEATURES
•iPod® & Satellite Radio Ready + Aux Input
• Corrosion Proof Stainless Steel Chassis
• Wireless Remote Control Included
M475
3
English
2. PRECAUTIONS
1. When it is very cold, the disc and the optical
components may become fogged and not
operate properly. Wipe fogged discs with a
soft cloth. Fogged optical components will
naturally return to normal when the unit is left
for about one hour, after which it will operate
normally.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged to
consult the dealer or an experienced radio/TV
technician for help.
2. When the boat is underway in rough water,
the CD may skip as a result of intense
vibrations and shock.
3. This unit uses a precision mechanism. Even
in the event that trouble arises, never open
the case, disassemble the unit, or lubricate
the rotating parts.
CAUTION
USE OF CONTROLS, ADJUSTMENTS, OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN, MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE.
THE COMPACT DISC PLAYER and MINI DISC
PLAYER SHOULD NOT BE ADJUSTED OR
REPAIRED BY ANYONE EXCEPT PROPERLY
QUALIFIED SERVICE PERSONNEL.
CHANGES OR MODIFICATIONS NOT
EXPRESSLY APPROVED BY THE
MANUFACTURER FOR COMPLIANCE
COULD VOID THE USER'S AUTHORITY TO
OPERATE THE EQUIPMENT.
INFORMATION FOR USERS:
CHANGES OR MODIFICATIONS TO THIS
PRODUCT NOT APPROVED BY THE
MANUFACTURER WILL VOID THE
WARRANTY AND WILL VIOLATE FCC
APPROVAL.
Bottom View of Source Unit
4
M475
Handling Compact Discs
English
Use only compact discs bearing the or
mark.
Do not play heart-shaped, octagonal, or other
specially shaped compact discs.
Some CDs recorded in CD-R/CD-RW mode may
not be usable.
Handling
• Compared to ordinary music CDs, CD-R and
CD-RW discs are easily affected by high
temperature and humidity. Prolonged
exposure to high heat and humidity may make
the discs unplayable. Therefore, do not leave
them for a long time in the boat.
• New discs may
have rough
edges. If such
discs are used,
the player may
not work, or the
sound may skip.
Use a ball-point
pen or the like to
remove any
roughness from the edge of the disc.
• Never stick labels on the surface of the
compact disc or mark the surface with a pencil
or pen.
• Never play a compact disc with any cellophane
tape or other glue on it or with peeling off
marks. If you try to play such a compact disc,
Ball-point pen
Roughness
you may not be able to get it back out of the CD
player or it may damage the CD player.
• Do not use compact discs that have large
scratches, are misshapen, cracked, etc. Use of
such discs may cause malfunction or damage.
• To remove a compact disc from its storage
case, press down on the center of the case and
lift the disc out, holding it carefully by the
edges.
• Do not use commercially available CD
protection sheets or discs equipped with
stabilizers, etc. These may damage the disc or
cause breakdown of the internal mechanism.
Storage
• Do not expose compact discs to direct sunlight
or any heat source.
• Do not expose compact discs to excess
humidity or dust.
• Do not expose compact discs to direct heat
from heaters.
Cleaning
• To remove fingermarks and dust, use a soft
cloth and wipe in a straight line from the center
of the compact disc to the circumference.
• Do not use any solvents, such as commercially
available cleaners, anti-static spray, or thinner
to clean compact discs.
• After using special compact disc cleaner, let
the compact disc dry off well before playing it.
Front Panel
CAUTION
Open the cap before connecting an external
unit. Be careful not to tear the cap when
opening.
Be sure to close the cap whenever no
external unit is connected.
Cap
M475
5
English
3. CONTROLS
Source unit
[
[
SCN
[
RELEASE
]
]
RPT
]
[
RDM
]
[
DIRECT
]
[
VOLUME
]
[
CD SLOT
]
[o]
[D]
[ ]
[ISR]
[
DIRECT
IR-Receiver
AUX
]
] []
BND
Stereo mini-plug cable
External unit
[
SRC
][
6
M475
Names of the Buttons and their Functions
English
[RELEASE] button
• Deeply push in [RELEASE] button to release
the front panel.
[SCN] (Scan) button
• Play 10 seconds of each track while in the CD/
MP3 mode.
• Press and hold the button for 1 second or
longer to folder scan play MP3/WMA files.
[RPT] (Repeat) button
• Repeat play while in the CD/MP3 mode.
• Press and hold the button for 1 second or
longer to folder repeat play MP3/WMA files.
[RDM] (Random) button
• Random play while in the CD/MP3 mode.
• Press and hold the button for 1 second or
longer to folder random play MP3/WMA files.
[DIRECT] (1-6) buttons
• Store a station into memory or recall it directly
while in the radio mode.
[VOLUME] knob
• Adjust the volume by turning the knob right and
left.
[CD SLOT]
• CD insertion slot.
IR-Receiver
• Receiver for remote control unit. (Operating
range: 30° in all directions)
AUX input jack
• Connect external equipment to this unit.
[SRC] (Source) button
• Press the button to turn on the power. Press
and hold the button for 1 second or longer to
turn the power off.
• Switch operation between Radio, CD/MP3,
Aux, and CeNET modes.
[ ] (Play/Pause/Enter) button
• Play or pause a CD while in the CD/MP3 mode.
• Perform preset scan while in the radio mode.
• Press and hold the button for 2 seconds to
perform auto store.
[BND] (Band) button
• Switch the band.
• Press and hold the button to switch between
seek or manual tunings.
• Play the first track of the CD or folder (MP3/
WMA files).
• If the disc is multi-session disc, press and hold
the button for 1 second or longer to switch
between the normal CD type and the MP3/
WMA type.
[E], [e] (Up/Down) buttons
• Recall preset channels.
• The folder is up/down in MP3/WMA files.
• The adjusted value is up/down in sound mode
or adjust mode.
[R], [F] (Search) buttons
• Select a station while in the radio mode or
select a track while in CD/MP3 mode.
• Use to adjust function settings.
• Press and hold the button for 1 second or
longer to switch to fast-forward/fast-rewind.
[ISR] (Instant Station Recall) button
• Recall ISR radio station in memory.
• Press and hold for 2 seconds or longer: Store
current station into ISR memory (radio mode
only).
[ ] (Sound) button
• Use the button to switch to the audio mode
(bass/treble, balance/fader, Z-Enhancer, nonfader)
• Press and hold the button for 1 second or
longer to on/off Magna Bass Extended
adjustment.
[D] (Display) button
• Switch the display indication.
• Switch title while in the CD/MP3 mode.
• Press and hold the button for 1 second or
longer to enter the adjust mode.
[o] (Eject) button
• Eject a CD when it is loaded into the unit.
M475
7
Major button operations when external equipment is
English
connected to this unit
● When the Sirius Satellite Receiver is
connected
* For details, see the section “Sirius Satellite
Operations”.
[DIRECT] (1-6) buttons
• Stores a station into memory or recall it directly.
[] button
• Performs category scan.
• Press and hold the button to perform preset
scan.
[BND] (Band) button
• Switch the band.
• Press and hold the button to switch to the
category selection mode.
[E], [e] (Up/Down) buttons
• Recall preset channels, and select the
category in category selection mode.
[R], [F] (Search) buttons
• Select a station.
[D] (Display) button
• When the button is pressed, switches title.
● When the CD changer is connected
* For details, see the section “CD Changer
Operations”.
[SCN] (Scan) button
• Perform scan play for 10 seconds of each
track.
• Press and hold the button for 1 second or
longer to perform disc scan play.
[RPT] (Repeat) button
• Perform repeat play.
• Press and hold the button for 1 second or
longer to perform disc repeat play.
[RDM] (Random) button
• Perform random play.
• Press and hold the button for 1 second or
longer to perform disc random play.
[ ] (Play/Pause/Enter) button
• Play or pause a CD.
[BND] (Band) button
• Play the first track of the CD.
[E], [e] (Up/Down) buttons
• Select the desired CD.
[R], [F] (Search) buttons
• Select a track.
• Press and hold the button for 1 second or
longer to switch to fast-forward/fast-rewind.
[D] (Display) button
• When the button is pressed, switches title.
● When the TV is connected
* For details, see the section “TV Operations”.
[DIRECT] (1-6) buttons
• Store a station into memory or recall it directly.
[ ] (Play/Pause/Enter) button
• Perform preset scan.
• Press and hold the button for 2 seconds to
perform auto store.
[BND] (Band) button
• Switch the band.
• Press and hold the button to switch between
seek or manual tunings.
[E], [e] (Up/Down) buttons
• Recall preset channels.
[R], [F] (Search) buttons
• Select a station.
● When the iPod is connected
* For details, see the section “iPod Operations”.
[SCN] (Scan)/[DIRECT] (1) button
• Use to select the PLAYLIST menu in the iPod
MENU mode.
[RPT] (Repeat)/[DIRECT] (2) button
• Use to select the ARTIST menu in the iPod
MENU mode.
[RDM] (Random)/[DIRECT] (3) button
• Use to select the ALBUM menu in the iPod
MENU mode.
[DIRECT] (4) button
• Use to select the SONG menu in the iPod
MENU mode.
[DIRECT] (5) button
• Use to select the GENRE menu in the iPod
MENU mode.
[DIRECT] (6) button
• Use to select the COMPOSER menu in the
iPod MENU mode.
[ ] (Play/Pause/Enter) button
• Play or pause a SONG.
[BND] (iPod MENU) button
• Use to switch to the iPod MENU mode.
[E], [e] (Up/Down) buttons
• Use to select menus in the iPod MENU mode.
[R], [F] (Search) button
• Perform the Track up or down operation.
• Press and hold the button for 1 second or
longer to switch to fast-forward/fast-rewind.
• Use to proceed to the next menu in the iPod
MENU mode.
[D] (Display) button
• When the button is pressed, switches title.
8
M475
Display Items
English
: Disc number indication (1 to 6)
: Preset channel indication (1 to 6)
Operation Status indication
* Titles, frequency, clock, etc. are displayed.
: Enter indication
: Stereo indication
: Manual indication
: MP3/WMA indication
: Z-Enhancer indication
: Satellite indication
: Channel indication
: Category indication
: All indication
: Random indication
: Repeat indication
: Scan indication
: MAGNA BASS EXTEND indication
: Mute indication
Display Screen
In extreme cold, the screen movement may slow down and the screen may darken, but this is normal.
The screen will recover when it returns to normal temperature.
M475
9
Optional Wired Remote Control Unit Operations
English
■ Following operations are enabled by remote control with the separately sold Wired Remote
Control Unit CMRC1 (shown below) or CMRC2.
Display Items
[
],[ ]
Operation status indication*
Titles, frequency, clock, etc. are displayed.
* Status display may be different from the
control panel.
: Stereo indication
: Satellite indication
: Mute indication
Preset channel indication (1 to 6)
Disc number indication (1 to 6)
[
BAND/DISC
[
POWER/SOURCE
]
[
],[ ]
[
]
]
10
M475
Optional Wired Remote Control Unit Operations
English
CAUTION
Lower the volume level before powering the
source unit off. The source unit stores the
last volume setting. If the source unit is
powered off with the volume up, when the
source unit is powered back on, the sudden
loud volume may harm your hearing and/or
damage the source unit.
[POWER/SOURCE] button
Turning on and off the power
Press the [SOURCE] button to turn the power on
and press and hold it for 1 second or longer to
turn the power off.
Changing the operation mode
Each time the [SOURCE] button is pressed, the
mode switches in the following order:
Radio mode ➜ Satellite mode ➜ CD/MP3
mode ➜ iPod mode ➜ CD changer mode ➜
TV mode ➜ AUX mode ➜ Radio mode.....
Note:
• If the above equipment is not connected,
corresponding mode cannot be selected.
[ ], [ ] buttons
Adjusting the volume
Press the [ ] button to increase the volume and
press the [ ] button to decrease the volume.
[BAND/DISC] button
Changing the band (in Radio mode)
Each time the [BAND] button is pressed, the
band switches in the following order:
FM1 ➜ FM2 ➜ FM3 ➜ AM ➜ FM1.....
Changing the band (in Satellite mode)
Each time the [BAND] button is pressed, the
band switches in the following order:
SR1 ➜ SR2 ➜ SR3 ➜ SR1.....
Changing the band (in TV mode)
Each time the [BAND] button is pressed, the
band switches in the following order:
TV1 ➜ TV2 ➜ TV1.....
Tuning (in Radio mode or TV mode)
Press and hold the [BAND] button for 1 second
or longer to switch between seek tuning and
manual tuning.
Top function (in CD/MP3 mode)
Press the [BAND] button, then the CD will start
from the first track of the folder.
Changing the disc (in CD changer mode)
Each time the [BAND] button is pressed, the disc
switches in the following order:
1 ➜ 2 ➜ 3 ➜ 4 ➜ 5 ➜ 6 ➜ 1.....
[] button
Press the [MUTE] button. The sound is muted
immediately. To cancel, press the [MUTE] button
again.
Press and hold the button for 1 second or longer
to play/pause in CD/MP3, iPod, and CD changer
mode.
[r], [f] buttons
Selecting tracks (in CD changer mode, CD/
MP3 mode or iPod mode)
Press the [f] button to start playback from the
beginning of the following track. Press the [r]
button to start playback from the beginning of the
current track. If pressed again, the track moves to
the previous one.
Fast-forward and fast-rewind (in CD changer
mode, CD/MP3 mode or iPod mode)
Press and hold the [f] button to fast-forward the
disc. Press and hold the [r] button to fastrewind the disc.
* Pressing and holding the [r] or [f] button for 1
second or longer will move forward or backward
faster than normal play, and pressing and holding
it for 3 seconds or longer will do the operation even
faster.
Selecting desired stations (in Radio mode,
Satellite mode or TV mode)
Press the [r] or [f] button to tune in a station
for seek tuning or manual tuning (Radio mode/TV
mode only).
M475
11
Wireless Remote Control Unit Operations
English
■ Following operations are enabled by remote control with the Wireless Remote Control Unit
RCB-176-600.
Receiver for wireless remote control unit
Wireless remote control unit
Note:
• Wireless Remote Control is not Waterproof.
Please avoid Contact with Water.
Signal transmitter
[
]
SRC
[
], [ ]
[
]
MUTE
[
]
ISR
[
]
SCN
Inserting the Battery
1. Turn over the remote control unit and slide the cover in the
direction indicated by the arrow in the illustration.
2. Insert the battery (CR2025) into the insertion guides, with
the printed side (+) facing upwards.
3. Press the battery in the direction indicated by the arrow so
that it slides into the compartment.
4. Replace the cover and slide in until it clicks into place.
Notes:
Misuse may result in rupture of the battery, producing leakage of
fluid and resulting in personal injury or damage to surrounding
materials. Always follow these safety precautions:
• Use only the designated battery.
• When replacing the battery, insert properly, with +/– polarities
oriented correctly.
• Do not subject battery to heat, or dispose of in fire or water. Do
not attempt to disassemble the battery.
• Dispose of used batteries properly.
Operating range:
30° in all directions
[
]
BND
[6]
[R], [F]
[
]
DISP
[
]
RDM
[
]
RPT
1
Insertion guide
2
R
2
C
0
3
2
5
WARNING
Alkaline(CR) button batteries contain Perchlorate.
--Don’t put in Trash-- Dispose as Hazardous Waste.
12
M475
Wireless Remote Control Unit Operations
Mode
Button
[SRC]
[BND]Switches
[E], [e] Increases and decreases volume (in all modes).
[R], [F] Seeks stations
[6] No function. Switches between playback and
[MUTE] Turns mute on and off.
[ISR] Recalls ISR radio station in memory.
[DISP]
[SCN] Preset scan.
[RPT] No function. Repeat play.
[RDM] No function. Random play.
* Some of the corresponding buttons on the main unit and remote control unit have different functions.
*1:
For satellite mode, performs category scan. When pressed and held for 2 seconds or longer: preset scan.
Radio/Satellite CD/MP3 CD changer TV iPod
Switches among radio, Sirius Satellite Receiver, CD/MP3, iPod, CD changer, TV and AUX.
The power of this unit turns off by pressing and holding or 1 second or longer when the
power is on.
Returns to the
reception band.
When pressed
and held for 1
second or
longer: Seek
tuning/manual
tuning (radio
mode only).
up and down for
seek/manual
tuning (radio
mode only).
When pressed and held for 2 seconds or longer: Stores current station into ISR memory
(radio mode only).
Switches displays.
When pressed
and held for 2
seconds or
longer:
Auto store (radio
mode only).
first track or the
first track of the
folder (MP3/
WMA).
Moves tracks up and down.
When pressed and held for 1
second or longer: Fast-forward/fast-
rewind.
pause.
Scan play.
When pressed
and held for 1
second or longer:
Folder scan
(MP3/WMA).
∗1
When pressed
and held for 1
second or longer:
Folder repeat
(MP3/WMA).
When pressed
and held for 1
second or longer:
Folder random
(MP3/WMA).
Moves the next
disc in
increasing order.
Scan play.
When pressed
and held for 1
second or
longer:
Disc scan play.
Repeat play.
When pressed
and held for 1
second or
longer: Disc
repeat play.
Random play.
When pressed
and held for 1
second or
longer:
Disc random play.
Switches
reception
band.
When pressed
and held for 1
second or
longer: Seek
tuning/manual
tuning.
Seeks stations
up and down
for seek/
manual
tuning.
No function. Switches
Preset scan.
When pressed
and held for 2
seconds or
longer:
Auto store.
No function. Repeat play.
Switches
between TV
and VTR.
No function.
Moves tracks up
and down. When
pressed and
held for 1 second
or longer: Fastforward/fastrewind.
between
playback and
pause.
No function.
When pressed
and held for 1
second or
longer: All
repeat play.
Random play.
When pressed
and held for 1
second or
longer: All
random play.
English
M475
13
Loading...
