Citizen E100 User Manual

Setting Instructions for Movement Caliber E100

Contents

1. Outline

2. Specifications

3. About Solar Powered Watches

4. Setting the Time and Calendar

5. Functions of the Solar Power Watch

6. Time Required for Recharge

7. Notes on Recharging

8. About the Eco Drive Rechargeable Battery

9. Care of Your Timepiece

(click on a topic)

Return to Table of Contents

1.OUTLINE

This watch is an analog solar powered timepiece that has a solar cell on its dial that
converts the light into electrical energy to drive the movement.

2. Specifications

Movement Caliber Number

Accuracy Within +/- 15 seconds per month (when worn at normal
Operating temperature range

Display
function

Time
Calendar Day and Date

Additional Functions

Continuous operating times

Battery

E100

temperatures of 5oC to 35 oC/(41oF to 95 oF)

Hour, Minute, Seconds

•

Quick Start Feature

•

Insufficient charge warning function

•

Time setting warning function

•

Overcharging Prevention Function

Fully charged to stopped:

Approximately 6 months

From insufficient charge warning to stop

Approximately 1 week

Eco Drive rechargeable Manganese Titanium battery.
Not user replaceable

3. SOLAR POWER WATCH

This watch is powered not by an ordinary battery, but by converting light energy into
electrical energy.

A rechargeable battery is used in this watch to store electrical energy. This secondary
battery is a clean energy battery that doesn't use any toxic substances such as mercury.
Once fully charged, the watch will continue to run for approximately 6 months without
further charging.

• Since the energy source of this watch is light, expose it to light sufficiently to
charge the battery in it.

• The battery of this watch is never overcharged by exposing it to light.

• If the user wears long-sleeved clothes usually, the watch is covered and its

rechargeable battery may not be charged sufficiently. If so, additional charging
may be necessary when not worn.

• The watch should be put on a well-lit place as long as possible for its normal
operation while it is not worn.

The watch should be exposed to light each day to ensure the watch has a sufficient charge
for proper operation.

Return to Table of Contents

Return to Table of Contents

4. Setting the Time and Calendar

If your watch has a screw-type crown, unscrew the crown from the case loosen it before
operation. Be sure to press the crown down and screw in after setting the time and/or
date.

<Setting the time>

1. Stop the second hand by pulling the crown out to the 2nd click (time setting
position).

2. Turn the crown to set the time.

3. The watch will start after the crown is firmly pushed back into its normal position.

<Setting the calendar>

1. Pull the crown out to the first click (calendar setting position).

2. Set the desired date by turning the crown counterclockwise.

3. Set the desired day of the week by turning the crown clockwise.

4. After you have set the calendar, be sure to press the crown back to its normal

position.

Do not adjust the calendar when the watch is reading between 9:00 pm and 4:00 am.
Otherwise the movement may become damaged and the calendar may not change correctly.

Return to Table of Contents
