1. HOW TO LOAD THE PAPER-ROLL
1)Push the paper holder (1) backwards.
2)Install the paper roll (2) into to the paper holder (1).
3)Cut the edge of the paper roll (2) straight with scissors and insert the edge of the paper roll into the paper slot (3).
4)Press [ CEONC ] to turn the calculator on. Press the paper feed key [©] until the paper end comes out from the paper cutter.
2. HOW TO CHANGE THE INK ROLLER
The printer in this model uses a disposable ink roller (IR-30) (cartridge type). If impressions are too light or illegible, replace the ink roller with a new one.
1)Press [OFF] to turn the calculator off.
2)Slide the printer cover (4).
3)Remove the ink roller (5) by pulling it up.
4)Install a new ink roller (5) into the holder in the proper position.
5)Replace the printer cover (4) to the original position.
Note:
Never fill the ink roller with fluid ink as it may run or clog the printer. Use only ink cartridge (IR-30).
-E1-
3. TO REPLACE BATTERIES
1) |
Open the battery compartment cover. |
2) |
Remove the exhausted batteries. |
3) |
Insert new batteries (UM-3 / AA BATTERY x 4) with polarity in correct |
|
directions |
4) |
Replace the cover. |
4. TO USE AC ADAPTER |
|
1) |
Turn the power off. |
2) |
Connect the AC adapter (6V / 300mA , ) to the plug. |
5. RESET:
Electromagnetic interference or electrostatic discharge may cause the display to malfunction or the contents of the memory to be lost or altered. If it occurs, use the tip of a ball point pen (or similar sharp object) to press the [RESET{] button at the bottom of the battery case..
RESET
-E2-
KEYS AND SWITCHES DESCRIPTION
[0]~[9] |
Number Keys |
||
|
|
|
Set the entered numbers. |
[ • ] |
Decimal Point Key |
||
|
|
|
Set the decimal point. |
[ |
ON |
] |
Power On / Clear Entry / Clear Key |
CE C |
|||
|
|
|
ON : Turns the calculator on. |
|
|
|
CE : Press to clear the last entered number (displayed |
|
|
|
number) before any function key is depressed. |
|
|
|
C: Press to clear all except memory contents. |
[OFF] |
Power Off |
||
|
|
|
Turns the calculator off. |
[+] [–] |
Arithmetic Keys |
||
[×] [÷] |
Performs addition, subtraction, multiplication and |
||
|
|
|
division respectively. |
-E3-
[ = ] |
Equal Key |
|
Obtains the result. |
[%]Percentage Key
Converts percentage to the decimal value. Also, converts for add-on and discount calculation.
[+/–] |
Sign Change Key |
|
Uses to change the algebraic sign of a display |
|
number/operand. |
[TAB] |
Decimal Point Selector |
|
F : Floating decimal mode. |
|
0 2 3 : Fixed decimal mode. |
|
A : ADD Mode -- Addition and subtraction calculations |
|
are preformed with an automatic 2-digit decimal so that |
|
decimal point entry is not required. |
[5/4] |
Rounding Selector Key |
|
Used for round-up (S), round-off (5/4), or round-down (T) |
|
to the pre-selected decimal digits in the result. |
[GT] |
Grand Total Key |
|
Obtains grand total value of a series of calculations. |
[ © ] |
Paper Feed Key |
|
Advance the paper roll. |
[#/P] |
Data printout key |
|
Used for printing out displayed content but it does not |
|
affect calculation such as dates and serial numbers. |
|
Figures are printed on the left-hand side of the paper. |
[PRINT] |
Print Mode Selector |
|
Entries and results will appear on the display and will be |
|
printed out. |
[M+] |
Memory Plus Key |
|
Accumulates the displayed number or calculated result |
|
directly into the memory. |
[M−] |
Memory Minus Key |
|
Subtracts the displayed number or calculated result from |
|
the memory storage. |
-E4-
[MRC]
[
] [LOCAL]
[SET]
[ S TO R E ]
+ TA X
[ RECALL-TAX ]
[SELL]
[COST]
[MARGIN]
Memory Recall Key / Memory Clear Key
Recalls the content of the memory to the display and/or the printing paper.
Clears the content of the memory after recalling its contents to the display and/or to printing paper.
Currency Exchange Key
: Convert Local currency into Universal currency. LOCAL : Convert Universal currency into Local currency.
Exchange Rate Setting Key / Tax Rate Setting Key
Add tax key
Used for adding the tax amount to the displayed figure.
Deduct Tax key
Used for deducting the tax amount from the displayed figure.
Selling Price/ Cost / Margin Key
Used for calculating the cost, selling price and profit margin amount. Enter the value of any 2 items to obtain the balance item.
-E5-
THE SIGNS OF THE DISPLAY MEAN THE FOLLOWING
M : Memory |
– : Minus ( or negative) |
|||
GT : Grand total |
E : Overflow-error |
|||
COST : Cost |
SELL : Selling price |
|||
MARGIN% : Margin percentage |
|
|
|
|
SET : Exchange rate or Tax rate setting |
|
|
||
% : Tax rate stored |
TAX : Amount of tax |
|||
+TAX : Price including tax |
-TAX : Price excluding tax |
|||
LOCAL : Local currency |
|
: Universal currency |
||
PRINTED SYMBOLS |
|
|
|
|
Various symbols mean the following: |
|
|
|
|
|
|
|
|
|
½ |
Total (result) |
|
|
Print ON/Off |
|
|
|
|
|
T |
Recall Grand Total value |
M |
|
Add to memory |
|
¨ |
|
||
T |
Clear Grand Total value |
M |
|
Subtract from memory |
½ |
– |
|
||
= |
Equals |
M |
|
Memory recall |
|
|
|||
# |
Non−add or date |
M |
|
Memory clear |
½ |
|
|||
% |
Percentage |
C |
|
Cost |
M |
Local currency |
S |
|
Sell price |
M |
|
|||
|
|
|
|
|
C |
Universal currency |
M |
|
Margin |
C |
% |
|
||
|
|
|
||
...... |
Overflow-error |
|
|
|
-E6-
1.Calculation Examples / Ejemplos de calculación / Exemplo de calculos / Berechnungsbeispiele / Exemples de calculs / Operazione del calcolo normale / Voorbeeldberekeningen / Almindelig regningsoperation / Примеры расчётов / Przykladowe obliczenia / بﺎﺴﺤﻝا ﺔﻠﺜﻣأ / Cara kalkulasi biasa / / Παραδείγµατα υπολογισµών
• |
Before performing each calculation, press the [ |
ON |
|
] key. |
|||||||||||||||||||
CE C |
|||||||||||||||||||||||
• |
Presione la tecla [ |
ON |
] antes de cada cálculo. |
||||||||||||||||||||
CE C |
|||||||||||||||||||||||
• |
Antes de executar cada cálculo, pressione a tecla [ |
|
|
ON |
]. |
|
|
|
|||||||||||||||
CE C |
|||||||||||||||||||||||
• |
Drücken Sie vor dem Ausführen einer Berechnung jeweils die [ |
|
ON |
] Taste. |
|||||||||||||||||||
CE C |
|||||||||||||||||||||||
• |
Avant d’effectuer chaque calcul, pressez la touche [ |
ON |
]. |
|
|
||||||||||||||||||
CE C |
|||||||||||||||||||||||
• |
Prima di effettuare ciascun calcolo, premere il tasto [ |
ON |
]. |
|
|||||||||||||||||||
CE C |
|||||||||||||||||||||||
• |
Alvorens een bewerking uit te voeren dient u op de toets [ |
ON |
|
] te drukken. |
|||||||||||||||||||
CE C |
|||||||||||||||||||||||
• |
Før hver beregning, tryk på [ |
ON |
] tasten to gange. |
||||||||||||||||||||
CE C |
|||||||||||||||||||||||
• |
Прежде чем начать вычисления, нажмите клавиш [ |
ON |
]. |
||||||||||||||||||||
CE C |
|||||||||||||||||||||||
• |
Przed rozpoczęciem obliczeń należy nacisnąć klawisz [ |
ON |
]. |
||||||||||||||||||||
CE C |
|||||||||||||||||||||||
|
|
|
|
[ |
ON |
]حﺎﺘﻔﻣ ﻰﻠﻋ ﻂﻐﺿا ،بﺎﺴﺣ ﻞﻜﺑ مﺎﻴﻘﻟا ﻞﻴﻗ • |
|||||||||||||||||
|
|
|
|
CE C |
|||||||||||||||||||
•Sebelum melakukan tiap penghitungan, tekan tombol [ CEONC ].
•[ CEONC ]
•Πριν πραγµατοποιήσετε κάθε πράξη, πατήστε το πλήκτρο [ CEONC ].
Example |
Key operation |
Display |
Print-out |
|
Ejemplo |
Operación con la tecla |
Visualización |
Impresión |
|
Exemplo |
Operação com a tecla |
Visualização |
Impressão |
|
Beispiel |
Tastenkombination |
Anzeige |
Ausdruck |
|
Exemple |
Touche d’Opération |
Affichage |
lmprimer |
|
Stampata |
||||
Esempio |
Operazione con il tasto |
Visualizzazione |
||
Afdruk |
||||
Voorbeeld |
Ingedrukte toetsen |
Weergave op het scherm |
||
Udprint |
||||
Eksempel |
Tastebetjening |
Vis |
||
Распечатка |
||||
Пример |
Клавиши |
Екран |
||
Wydruk |
||||
Przykład |
Klawisze |
Ekran |
||
Print-out |
||||
لﺎﺜﻤﻝا |
حﺎﺘﻔﻤﻟاﺔﻴﻠﻤﻋ |
ضﺮﻌﻝا |
||
Contoh |
Operasi Tombol Tampilan di Layar |
Contoh |
ﺔﻋﺎﺒﻃ |
|
Cetak |
||||
|
|
|
||
|
||||
Παράδειγµα |
Λειτουργίαπλήκτρου |
Οθόνη |
||
Εκτύπωση |
||||
|
|
|
||
|
|
|
|
-1-
