Data Sheet
Cisco RV320 Dual Gigabit WAN VPN Router
Product Overview
Figure 1. Cisco RV320 Dual Gigabit WAN VPN Router
Features and Benefits
New model with web filtering to guard against malicious or non-work-related websites.
Dual Gigabit Ethernet WAN ports allow load balancing and business continuity.
Affordable, high-performance Gigabit Ethernet ports enable rapid transfer of large files, supporting multiple users.
Dual USB ports support a 3G/4G modem or flash drive. The WAN can also fail over to the 3G/4G modem connected to the USB port.
SSL VPN and site-to-site VPN enable highly secure connectivity, making the Cisco RV320 perfect for remote employees and multiple offices.
Stateful packet inspection (SPI) firewall and hardware encryption provide strong security.
Easy-to-use wizard-based configuration tools can be used to establish network connectivity and manage security.
Your business and your employees are exposed to phishing, key loggers, spyware, drive-by malware, and other online threats. With the new RV320 with web filtering, you can keep your employees and users safe from unwanted
content and malicious websites. This is accomplished without compromising the users’ online experience and can
even help boost employee productivity and network performance by limiting Internet surfing to appropriate site categories and eliminating unwanted network traffic. Users are also automatically protected from malicious/compromised websites, regardless of site categorization.
© 2015 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 2 of 5
Description
Specification
Dual WAN
Dual Gigabit Ethernet Ports
Failover
Load balancing
Standards
802.3, 802.3u
IPv4 (RFC 791)
IPv6 (RFC 2460)
WAN connectivity
Dynamic Host Configuration Protocol (DHCP) server, DHCP client, DHCP relay agent
Static IP
Point-to-Point Protocol over Ethernet (PPPoE)
Point-to-Point Tunneling Protocol (PPTP)
Transparent bridge
DNS relay, Dynamic DNS (DynDNS.org, 3322.org), DNS local database
IPv6
Routing protocols
Routing Information Protocol (RIP) v1 and v2, and RIP for IPv6 (RIPng)
Inter-VLAN routing
Static routing
VLANs supported: 7
Network Address Translation (NAT)
Port Address Translation (PAT)
One-to-one NAT
NAT traversal
Protocol binding
Protocols can be bound to a specific WAN port for load-balancing purposes
Network edge (DMZ)
DMZ port
DMZ host
Dual USB 2.0 ports
Storage and 3G/4G modem support
Security
Firewall ● SPI firewall
Denial-of-service (DoS) prevention: ping of death, SYN flood, IP spoofing, WinNuke
Access rules
Schedule-based access rules
Up to 50 entries
Port forwarding
Up to 30 entries
Port triggering
Up to 30 entries
Blocking
Java, cookies, ActiveX, HTTP proxy
Content filtering
Static URL blocking or keyword blocking
Secure management
HTTPS web access to device manager
Username/password complexity enforcement
The Cisco RV320 Dual Gigabit WAN VPN Router is the choice for any network in which performance, security, reliability, and adaptability top the list of requirements. The Cisco RV320 supports two connections to one service provider, delivering high performance by using load balancing, or to two different providers to deliver business continuity. High-capacity virtual private networks (VPNs) connect multiple offices and enable dozens of employees to access the information they need from any geographic location just as securely as if they were working at your main office.
Product Specifications
Table 1 lists the product specifications for the Cisco RV320.
Table 1. Product Specifications
© 2015 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 3 of 5
Description
Specification
VLAN
802.1Q VLAN 7 VLANs supported
Web filtering
Content filtering covering 27+ billion URLs
VPN
IP Security (IPsec)
25 IPsec site-to-site tunnels for branch office connectivity
25 IPsec VPN tunnels via Cisco VPN client and third-party clients such as “The GreenBow” for remote- access VPN connectivity
SSL VPN
10 SSL VPN tunnels for remote client access
PPTP
10 PPTP tunnels for remote access
Encryption
Data Encryption Standard (DES)
Triple Data Encryption Standard (3DES)
Advanced Encryption Standard (AES) encryption: AES-128, AES-192, AES-256
Authentication
MD5/SHA1
IPsec NAT traversal
Supported for gateway-to-gateway and client-to-gateway tunnels
VPN pass-through
PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec
Advanced VPN
Dead peer detection (DPD)
Split DNS
VPN backup
Internet Key Exchange (IKE) with certificate
Quality of Service (QoS)
Service-based QoS
Rate control or priority
Rate control
Upstream/downstream bandwidth per service
Prioritization types
Application-based priority on WAN port
Priority
Services mapped to one of two priority levels
Performance
IPsec VPN throughput
100 Mbps
SSL VPN throughput
20 Mbps
Concurrent connections
20,000
Configuration
Web user interface
Browser-based device manager (HTTP/HTTPS)
Management
Management protocols
Web browser (HTTP/HTTPS)
Simple Network Management Protocol (SNMP) v1, v2c, and v3
Bonjour
Event logging
Local log
Syslog
Email alert
Short Message Service (SMS)
Upgradability
Firmware upgradable through the web browser
Import or export configuration files from or to a USB flash drive
© 2015 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 4 of 5
Description
Specification
Product dimensions (W x H x D)
206 x 132 x 44 mm (8.1 x 5.2 x 1.7 in)
Ports
Four 10/100/1000 Gigabit Ethernet RJ-45 ports One 10/100/1000 Gigabit Ethernet RJ-45 Internet (WAN) port One 10/100/1000 Gigabit Ethernet RJ-45 DMZ/Internet (WAN) port
Power supply
12V 1.5A
Certification
FCC Class B, CE Class B, UL, cUL, CB, CCC, BSMI, KC, Anatel
Operating temperature
0° to 40°C (32° to 104°F)
Storage temperature
0° to 70°C (32° to 158°F)
Operating humidity
10% to 85% noncondensing
Storage humidity
5% to 90% noncondensing
Product Name
Part Number
RV320 Dual WAN VPN Router
RV320-WB-K9-NA
RV320 Dual WAN VPN Router
RV320-WB-K9-G5
System Specifications
Table 2 lists the system specifications for the Cisco RV320.
Table 2. System Specifications
Warranty Information
Find warranty information on Cisco.com at the Product Warranties page.
Ordering Information
Help customers understand all the components or parts they need to purchase in order to install and use the product. Table 3 lists ordering information for the Cisco RV320. This section also provides a direct link to the Cisco Ordering Tool and lists part numbers for customer convenience.
To place an order, visit the Cisco Ordering Home Page. To download software, visit the Cisco Software Center.
Table 3. Ordering Information
Cisco Limited Lifetime Warranty for Cisco Small Business Products
This Cisco Small Business product comes with a limited lifetime hardware warranty. Product warranty terms and other information applicable to Cisco products are available at http://www.cisco.com/go/warranty.
Cisco Small Business Support Service
This optional service offers affordable, 3-year peace-of-mind coverage. This subscription-based, device-level service helps you protect your investment and derive maximum value from Cisco Small Business products. Delivered by Cisco and backed by your trusted partner, this comprehensive service includes software updates, extended access to the Cisco Small Business Support Center, and expedited hardware replacement, should it be required.
© 2015 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 5 of 5
Printed in USA C78-726132-03 10/15
Cisco Capital
Financing to Help You Achieve Your Objectives
Cisco Capital can help you acquire the technology you need to achieve your objectives and stay competitive. We can help you reduce CapEx. Accelerate your growth. Optimize your investment dollars and ROI. Cisco Capital financing gives you flexibility in acquiring hardware, software, services, and complementary third-party equipment.
And there’s just one predictable payment. Cisco Capital is available in more than 100 countries. Learn more.
For More Information
For more information on the Cisco RV320 Dual Gigabit WAN VPN Router, visit http://www.cisco.com/go/rv320. For more information on Cisco Small Business products and solutions, visit http://www.cisco.com/smallbusiness.
