Canon Z155 User Manual

Салоп

г Ш SURE SHOT

^155

PRIAAA

SUPER155

PRIAAA

SUPER155

вшт

ГЁ] Instructions [El Mode d’emploi (gì Bedienungsanleitung Ш Istruzioni [sì instrucciones [E Instruçôes

Handling Precautions

1. This camera is not resistant to water, and shouid not be used outdoors if it is raining or snowing, if it is accidentaiiy dropped in water, contact an authorized Canon sen/ice faciiity. Keep the camera out of sait spray and excessive humidity, if used at the beach, ciean it thoroughiy afterward with a dry cioth.

2. Store the camera in a cool, dry, dust-free place. Be sure to keep the camera out of direct sunlight, and away from “hot spots" such as the trunk or rear window shelf of a car. Avoid places where mothballs are used, and use a desiccant in excessive humidity.

3. Do not attempt to disassemble the camera yourself, since there is high-voltage circuitry inside.

4. The battery may explode or cause burns if disassembled, recharged, shorted, exposed to high temperatures, or disposed of in a fire.

5. Use a blower brush to remove dust and sand from the lens and inside the camera. Do not apply any fluids to

the lens or body. Take the camera to an authorized Canon service facility for a more thorough cleaning if necessary.

6. Film passing through X-ray examinations at an airport

may be exposed and ruined even when loaded in the camera. Request a different method of inspection to avoid damage.

7. Color reproduction may be adversely affected if the film

is left In the camera for a long time. Always develop exposed film promptly.

Convention

The following convention is used in these instructions:

Warnings you should observe when using the camera.

Q Additional Information on using the camera.

Refer to the page number indicated in parenthesis, (-> **), for further details.

H-2

Handling Precautions

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Do not make any changes or modifications to the equipment unless othen/vise specified in the instructions. If such changes or modifications should be made, you could be required to stop operation of the equipment. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful Interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference wili not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Consult the dealer or an experienced radio/TV technician for help. This digital apparatus does not exceed the Class B limits for

radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled "Digital Apparatus”, ICES-003 of the Industry Canada,

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe B prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques", NMB-003 édictée par l’Industrie Canada.

The C€ Mark is a Directive conformity mark of the

European Community (EC)

C€

lE-3

Thank you for purchasing this Canon product.

Before taking pictures, please read these instructions carefully for a thorough understanding of how the camera operates.

Handling Precautions......................................................2

Table of Contents ............................................................4

Nomenclature....................................................................6

Dioptric Adjustment Knob..........................................9

H Basic Operations

* Loading the Battery.........................................................10

Loading and Removing the Film..................................11

Loading the Film ......................................................11

Removing the Film

Rewinding the Film in Mid-roll

Turning the Power On....................................................14

Checking the Battery Level...........................................15

fJiM«) Taking Pictures in Autoflash Mode

Shutter Button

Green/Orange Lamps................................................18

Subjects Difficult to Autofocus................................19

Holding the Camera

Close-up Photography..............................................20

Ci) Shooting with Self-timer

O Advanced Operations

^ Shooting with the Best Shot Dial ..........................22

^ Shooting Moving Objects

0 Shooting against Dark Backgrounds

Using Red-eye Reduction Function

Effectively

9 Shooting Portraits ..........................................24

Shooting Close-up..........................................25

...................................................

.................................

..................

...........................................................

.................................................

........................................

..............................

............

.................................................................

13 13

16 17

D-4

SPOT Shooting Very Bright or Very Dark

Subjects.............................................................25 I

PEBSONAL Shooting with Customized Mode

Functions .....................................................25

Changing the Flash Mode Autoflash

» Flash ON (Fires for all shots) ® Flash OFF (Never fires) ®H5 ®-isFlash OFF with Manual

CH Using Center-point Focusing

Using Focus Lock

I Shooting with Remote Control «sia»

Replacing the Remote Control Battery

IMODEI Imprinting the Date and Time etc. eoza» ..33

Imprinting the Date and Time...................................34

Setting the Date and Time

Imprinting Captions..................................................36

............................................................

Autoflash with Red-eye Reduction

Exposure Compensation

Night Scene (Slow-sync)

..........................................................

.................................

................

..............................

........................................

..................

...........................

................................

.....................

...................

.......................................

O ■ Additional Information

* Troubleshooting................................................................38

Major Specifications .......................................................40 1

26 26

27 27 27

27 28 29 30

Please note that these instructions are for both the model with the caption function and model without caption function. Information relevant only to the model with the caption function is marked with the wMihUh symbol. The separately sold Remote Control RC-5 is available for use with the model only.

U-5

Nomenclature

* AF is an abbreviation for Auto Focus.

U-6

Nomenclature

Refer to the page number indicated in parenthesis, {-> **), for further details.

Vi«wfin(ier

Q Center-point AF button (-» 29)

►t© Mid-roll rewind button (-»13)

Tripod socket

----------

Best shot dial 22)

* Use the strap buckle pin to

push the ►►© button.

Orange famp (-+ 18) Green lamp (-♦ 18)

EE Zoom-cut (wide-angle)/

Selection eazsa button

H 16. 35, 37)

m Zoom-in (telephoto)/

Set cssszza button

(-> 16. 34-37)

Strap buckle pin**

Battery compartment

cover 10)

Attaching the Strap

LCD Panel

(Normally, only the required information is displayed.)

V Flash ON

Red -eye redu ction mark

Manual exp osurecom pensation

Cen ter-p oint AF ~

Con tinuo us shooting

m.wjuiunm

Cap tion imprinting imprinting

Red -eye redu ction mark !

Self-time r/ Rem ote control Con tinuo us shooting _

Cen ter-p oint AF ■

Film mark

* Battery leve l indicator

[m^ (lit) The battery le vel O K.

Is^ (lit) Prepare new batte ry.

(blinking) Loa d a n ew battery. (-> 10)

t1.5 AUTOVn

E]Qù

Battery level indicator*

Date and time or c aptio n nu mber

;8B ss;'88

jLAPTION O/iTE

DATE CAPTIOlir“

Frame counter

Mode se lection indicatorBattery level indicator*

>1-

(Fires for all s hots)

® Flash OFF

(Never fires)

Nighttime (Slow-sync) indicator

j— Self-timer

|‘' Frame counter

Film mark

J Flash ON

(Fires lor all s hots)

® Flash OFF

(Never fires)

— N ighttime (Slow -sync)

indicator

Manual exposure compensation

H-8

Dioptric Adjustment Knob

Turn the dioptric adjustment knob until you can see the image in the viewfinder clearly.

Nomenclature

d-9

Loading the Battery

Applicable Battery: One lithium battery

(CR123A/DL123A)

Open the battery cover.

•To open, insert a coin into the slot.

Load a new battery.

• Align the + - terminals correctly and insert the battery - end first.

^The [™> appears on the

LCD panel.

Close the battery cover.

• Push the cover closed until you hear a clicking sound.

^ The date display “

on the LCD panel blinks. Set the date and time.

(-> 34)

---------------

LS-IO

Loading and Removing the Film

Loading the Film

Open the back cover.

• Push the back cover

release lever down.

Load the film.

Position the film correctly between the film guides.

Pull the film out to the

(fjim leader

position indicator).

• Make sure that there Is no slack in the film when you pull It out.

• If the edge of the film leader

goes beyond the film leader position indicator, rewind some of the film back into

the cartridge.

U-ii

Close the back cover.

^The film will automatically

advance to the first frame on the roll.

“1 ” is displayed on the

AUTO

Q] • Use only film with DX-code. The camera will

automatically detect and set the film speed.

• A film speed of ISO 4tX) Is recommended.

• The film speed Is set to ISO 25 when non^DX film Is loaded. If the film does not have a DX-code, Insert It Into the film compartment, close the back cover and press the shutter button once or twice.

• For slide (reversal) film, you can use DX-coded film speeds of ISO 25, 50, 100, 200, 400, 800, 1600 and

3200.

frame counter.

• If the frame counter shows a blinking “0”, the film did not load correctly. Load the

film again.

[1-12

Loading and Removing the Film

Removing the Film

The film rewinds automatically when it reaches the end. When the film is fully rewound, the frame counter

shows “0” and the h blinks.

Check that the frame counter shows “0”.

Open the back cover.

• Push the back cover release lever down and remove the film.

Rewinding the Film in Mid-roll

‘ Use the strap buckle pin on the

strap buckle (-> 7) to press the

camera.

• Hold the button down until the

film starts to rewind.

[Ej-13
