Canon XWX450ST User Manual

MULTIMEDIA PROJECTOR

Table of Contents

Safety Instructions

Before Use

Projecting an Image

Operation

User’s Manual

Useful Functions Available
During a Presentation

Setting Functions from
Menus

Installation and Maintenance

Installation

Connecting to a Network

Maintenance

Networked Multi-Projection

Networked Multi-Projection
Overview

Operation in Each Mode

Functions in All Modes

Appendix

Other Information

Index

ENG

How to Use This Manual

Symbols Used in This Manual

Meanings of the symbols used in this manual are as follows.

A precaution about operation or restriction is given here.

Indicates supplemental information to note in use.

Symbols of Button Operations

The projector can be operated using the buttons on the remote control or on the
side of the projector. The remote control allows you to operate all functions of the
projector.
In this document, the button’s operations are shown as below.

Operation of buttons
on side of projector

Remote control button
operation

Indicate the buttons to be pressed

Thank you for purchasing a Canon projector.
The WUX450 / WX520 Multimedia Projector (hereinafter referred to as “the
projector”) is a high-performance projector that is capable of projecting a
high-resolution computer screen and high-quality digital image on a large
screen.

This Manual

This manual combines the user’s manual for WUX450/WX520 Multimedia
Projectors. The “Operation” section (P47) describes how to use the projector. The
“Installation and Maintenance” section (P121) describes initial setup and regular
maintenance. For instructions on software for projection by multiple projectors
linked in a local network, refer to the “Networked Multi-Projection (NMPJ)” section
(P201). Read this manual thoroughly to make the most of your projector. Installation
of the projector should be performed by a qualified technician, if possible. Contact
the Canon Customer Support Center for further information.

Selecting Screen Aspect

Select the correct aspect ratio for the screen which is used.

1 Press the MENU button to display the menu window.

Remote control Projector

2 Press the [ ] / [ ] buttons to select the [Install settings] tab.

Remote control Projector

2

How to Use This Manual

Copyright Notice

Please note that enlarging or reducing the size of an image for commercial
purposes or public presentation may infringe on the legally protected copyright
or the copyright holder of the original material.

About Trademarks

• Ethernet is a registered trademark of Xerox Corporation.

• Microsoft, Windows, Windows XP, Windows Vista, Windows 7, Windows 8

and Aero are registered trademarks or trademarks of Microsoft Corporation
in the United States and / or other countries.

• Mac, Mac OS and Macintosh are trademarks of Apple Inc., registered in the
United States and / or other countries.

• HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing, LLC.

• PJLink is a registered trademark, or an application has been submitted for
trademark, in Japan, the United States and / or other countries or regions.

• AMX is a trademark of AMX Corporation.

• Crestron®, Crestron RoomView®, and Crestron Connected™ are registered

trademarks of Crestron Electronics, Inc.

3

Projector Highlights

Minimal Space Needed for Installation

Compact 337 x 134 x 370 mm / 13.3 x 5.3 x 14.6 in (W x H x D) body can be installed
with minimal space requirements. (P292)

High-Resolution LCOS Projection

Projection at 1920x1200 (WUXGA) for the WUX450 or 1440x900 (WXGA+) for the
WX520, thanks to high-resolution reflective liquid crystal (LCOS) panels.

Split-Screen Display

Side-by-side projection of two input images from devices connected to the
projector. (P79)

Manual Lens Shift, Zoom, and Focus

Manually adjust lens shift, zoom, and focus as needed. (P43)

USB File Viewer

Project JPEG images stored on a USB flash. (P77)

Edge Blending

Blend the overlapping edges of images from multiple projectors to make the overall
image more seamless. (P155)

Displaying Test Pattern

Project a range of test patterns, with no image input needed. (P154)

Networked Multi-Projection (NMPJ)

Project images from multiple computers via a network connection. (P201)

4

Quick Reference Guide

This Quick Reference Guide will help you find functions that make full use of the
projector and are useful for producing an attractive presentation, etc.

Connecting the Projector

Connecting to the Computer (P134 - P136)

Connecting to AV Equipment (P137 - P139)

Projecting an Image

Starting Projection (P50)

Selecting an Input Signal (P51 - P52)

Projecting Images from Two Sources at
Once (P79)

Adjusting the Image

Adjusting the Image Size and Focus
(P55 - P56)

Adjusting Keystone Distortion (P65)

Adjusting Aspect Ratio (P57 - P64)

Eliminating Flickers from Computer
Screen and Adjusting Positional Shift
(P87, P88)

Adjusting Colors and Image Quality

Projecting an Image on a Greenboard
(P149)

Selecting an Image Mode Suitable for
the Projecting Image (P95)

Making Fine Color Adjustments (P99)

Removing Noise (P101)

Changing the Remote Control

Channel (P112)

Resetting Projector Setting

Resetting Password (P115)

Initializing the Network Setting (P171)

Resetting to the Default Setting (P119)

Miscellaneous Functions

Using Auto Power-Off (P108)

Turning on the Projector by Connecting
the Power Cord (P109)

Disabling the Beep During Operation
(P109)

Disabling Buttons (P110)

Hiding Guide Messages (P150)

Setting a Password (P114)

Reducing the Lamp Brightness (P105)

Displaying Test Pattern (

Selecting Audio In Terminal (P149)

Combining Images from Multiple
Projectors (P155 - P161)

Supplying Images over a Network (P204)

P154)

Producing a Presentation

Temporarily Blacking Out an Image
(P74)

Freezing the Picture (P74)

Adjusting the Volume (P75)

Muting the Sound (P75)

Zooming an Image (P76)

Projecting Images on a USB Flash Drive
(P77 - P78)

5

Table of Contents

How to Use This Manual......................................................................... 2

Projector Highlights................................................................................ 4

Quick Reference Guide .......................................................................... 5

Safety Instructions................................................................................ 16

Safety Precautions....................................................................................................17

CAUTION ON HANGING FROM THE CEILING ........................................................17

■ READ AND KEEP THIS OWNER’S MANUAL FOR LATER USE. .....................18

AC Power Cord Requirement...................................................................................20

Federal Communication Commission Notice.........................................................21

Canadian Radio Interference Regulations..............................................................21

Precautions for Use .................................................................................................. 23

Precautions for Installation......................................................................................24

Precautions on the lamp ..........................................................................................26

Precautions for the batteries of the remote control .............................................. 27

For Safe Use.......................................................................................... 28

Before Use........................................................................................31

Supplied Accessories........................................................................... 32

■ Attaching the Lens Cap.......................................................................................32

Preparing the Remote Control............................................................. 33

■ Installing Remote Control Batteries.....................................................................33

■ Remote Control Operating Range.......................................................................34

■ Using an Optional Wired Remote (RS-RC05)..................................................... 35

Part Names ............................................................................................ 36

Projector .................................................................................................................... 36

■ Front Side............................................................................................................36

■ Rear Side ............................................................................................................36

■ Bottom Side.........................................................................................................37

Remote control.......................................................................................................... 38

Side Control...............................................................................................................40

LED indicators........................................................................................................... 40

■ LED Indicator Displays........................................................................................41

Input Terminal ........................................................................................................... 42

Lens Shift Control .....................................................................................................43

Projection Lens ......................................................................................................... 43

Open Source Software ......................................................................... 44

■ Software under the GPL and LGPL ....................................................................44

■ Software under the GNU General Public License Version 2...............................44

6

Table of Contents

Operation.....................................................................47

Projecting an Image.........................................................................49

Step 1 Turn the Projector On............................................................... 50

Step 2 Select an Input Signal............................................................... 51

Types of Input Signals..............................................................................................51

Selecting an Input Signal .........................................................................................52

Step 3 Adjust the Image ....................................................................... 53

Setting the Display Resolution of the Computer ................................................... 53

■ Windows 8...........................................................................................................53

■ Windows 7...........................................................................................................53

■ Windows Vista.....................................................................................................54

■ Windows XP........................................................................................................54

■ Mac OS X............................................................................................................54

Auto PC Adjustment ................................................................................................. 55

■ Performing the Auto PC Function .......................................................................55

Adjusting the Image Size..........................................................................................55

Adjusting the Image Position................................................................................... 56

Adjusting the Focus..................................................................................................56

Table of Contents

Step 4 Select an Aspect Ratio (Screen Aspect)

Matching the Screen............................................................................. 57

Selecting Screen Aspect ..........................................................................................57

Moving Image with 16:9 D. Image Shift...................................................................60

Moving Image with 4:3 D. Image Shift.....................................................................61

Resetting the Image Shift .........................................................................................62

Selecting the Aspect.................................................................................................63

Types of Aspect Ratios ............................................................................................63

Selecting an Aspect Ratio ........................................................................................ 64

Step 5 Correct the Image Distortion.................................................... 65

Adjusting Keystone Distortion ................................................................................65

■ Horizontal/Vertical Keystone Correction .............................................................65

■ Corner Adjustment ..............................................................................................66

■ Resetting the Keystone Adjustment ....................................................................67

Step 6 Select the Image Quality (Image Mode) .................................. 68

Image Modes ............................................................................................................. 68

■ Selecting an Image Mode ...................................................................................69

Step 7 Set Power-Saving Settings....................................................... 70

Step 8 Turn the Projector Off............................................................... 71

7

Table of Contents

Useful Functions Available During a Presentation ......................73

Useful Presentation Functions ............................................................ 74

Temporarily Blacking Out an Image........................................................................74

Freezing the Picture..................................................................................................74

Adjusting the Volume ...............................................................................................75

Muting the Sound...................................................................................................... 75

Zooming an Image ....................................................................................................76

Projecting Images on a USB Flash Drive............................................ 77

Split-Screen Display ............................................................................. 79

Setting Functions from Menus .......................................................81

Using Menus.......................................................................................... 82

Menu Configuration .................................................................................................. 82

Basic Menu Operations ............................................................................................83

Setting Display Status (Input Settings)............................................... 85

Selecting the Aspect.................................................................................................85

Setup Using Auto PC ................................................................................................86

Selecting an Input Signal .........................................................................................86

Adjusting the Input Signal (Total dots) ...................................................................87

Adjusting the Input Signal (Tracking) .....................................................................87

Adjusting the Input Signal (Horizontal position).................................................... 88

Adjusting the Input Signal (Vertical Position) ........................................................ 88

Adjusting the Input Signal (Horizontal pixels)........................................................89

Adjusting the Input Signal (Vertical pixels) ............................................................ 89

Adjusting HDMI Input Level .....................................................................................90

Setting the HDMI Color Format................................................................................90

Specifying HDMI Overscan ...................................................................................... 91

Specifying Progressive Processing ........................................................................91

Specifying the Slideshow Interval ...........................................................................92

Specifying Split-Screen Display .............................................................................. 93

Adjusting Image Quality (Image Adjustment) .................................... 94

Specifying Image Priority in Split-Screen Mode ....................................................94

Specifying the Image Mode......................................................................................95

Creating/Saving a User Profile................................................................................. 96

Adjusting Brightness................................................................................................ 97

Adjusting Contrast.................................................................................................... 97

Adjusting Sharpness ................................................................................................ 98

8

Table of Contents

Correcting Gamma.................................................................................................... 98

Adjusting Colors .......................................................................................................99

Adjusting to the Ambient Light (Ambient Light) ..................................................100

Reducing Image Noise (Noise reduction) .............................................................101

Dynamic Gamma Adjustment ................................................................................ 101

Correcting Memory Color.......................................................................................102

Fine-Tuning Colors (6-axis Color Adjustment) ....................................................102

Fine-Tuning Gamma ...............................................................................................103

Controlling Contrast (Iris) ......................................................................................104

Specifying the Lamp Mode..................................................................................... 105

Resetting Image Adjustment Settings ..................................................................105

Customizing System Operation (System Settings) ......................... 106

Registering User Logos..........................................................................................106

Positioning User Logos..........................................................................................106

No Signal Screen.....................................................................................................107

Screen When Blank.................................................................................................107

Selecting a Logo at Startup.................................................................................... 108

Specifying Auto Power-Off..................................................................................... 108

Specifying Direct Power-On...................................................................................109

Specifying Silence or Operating Tones ................................................................109

Table of Contents

Specifying Key Repeat Operation .........................................................................110

Locking Projector or Remote Buttons ..................................................................110

Assigning a Channel for Remote Control.............................................................111

Reducing Motion Blur............................................................................................. 112

Specifying HDMI Input ............................................................................................ 113

Selecting a Display Language ...............................................................................113

Requiring a Password for Operation..................................................................... 114

Setting a Password ................................................................................................. 115

Restoring Original Gamma Settings .....................................................................116

Resetting the Lamp Counter ..................................................................................117

■ About the Display of the Lamp Counter ............................................................117

Resetting the Air Filter Counter.............................................................................118

Updating the Firmware ...........................................................................................118

Resetting to the Default Setting............................................................................. 119

Checking Projector Information ........................................................ 120

9

Table of Contents

Installation and Maintenance...................................121

Installation......................................................................................123

Before Installation............................................................................... 124

Precautions When Carrying/Shipping the Projector ........................................... 124

Precautions for Installation....................................................................................124

■ When using mounted on the ceiling ..................................................................126

■ Install facing in the correct direction.................................................................. 127

Installation Procedure ........................................................................ 128

Setting Up the Projector .........................................................................................128

■ Positioning the Projector in Front of the Screen................................................128

■ Floor Installation................................................................................................128

■ Upward-Tilted Installation..................................................................................128

■ Projection from High Surfaces ..........................................................................129

■ Ceiling Mounting or Rear Projection .................................................................130

Relationship of Image Size to Projection Distance..............................................131

■ Lens Shift Function ...........................................................................................131

■ Amount of Lens Shift.........................................................................................131

Connection Procedure ....................................................................... 133

Connectable Equipment and Input Terminals......................................................133

Connecting a Computer .........................................................................................134

■ Connecting to RGB Monitor Output Terminal (Analog Connection)..................134

■ Connecting to DVI Monitor Output Terminal (Digital Connection)..................... 135

■ Connecting with an HDMI cable (Input signal type: [HDMI]) .............................136

■ Outputting Audio to Speakers ...........................................................................136

Connecting AV Equipment.....................................................................................137

■ Connecting to Digital Video Output Terminal (Digital Connection) ...................137

■ Connecting to Analog Video Output Terminal (Analog Connection) .................138

■ Outputting Audio to Speakers ...........................................................................139

Plugging the Projector In .......................................................................................140

Starting Projection.............................................................................. 141

Starting and Stopping Projection .......................................................................... 141

■ Starting Projection.............................................................................................141

■ Stopping Projection ...........................................................................................141

■ When the Language Selection Screen Appears ............................................... 141

■ When the Password Input Screen Appears ......................................................141

■ When “No signal” Appears ................................................................................ 142

■ When Notebook Computer Screen Does Not Appear.......................................142

■ Adjusting Image ................................................................................................142

Changing Notebook Computer Screen Output .................................................... 142

■ Turning on External Monitor Output ..................................................................142

10

Table of Contents

Installation-Related Menu Settings ................................................... 143

Locking Installation Settings .................................................................................143

Flipping Image Display ...........................................................................................143

Specifying the Screen Aspect................................................................................ 145

Specifying Keystone Correction............................................................................146

Specifying Digital Image Shift................................................................................ 146

Specifying Micro Digital Image Shift ..................................................................... 147

Adjusting Image Registration ................................................................................147

Specifying the Fan Mode........................................................................................148

Specifying Vertical Projection ...............................................................................148

Selecting the Audio In Terminal ............................................................................149

Adjusting Colors to Suit the Screen Color ...........................................................149

Specifying a Menu Position ...................................................................................150

Showing/Hiding the Guide Screen ........................................................................150

Showing/Hiding Input Status .................................................................................151

Showing/Hiding Overheat Warnings ..................................................................... 151

Table of Contents

Specifying the Menu Display Time ........................................................................ 152

Showing/Hiding Lamp Replacement Warnings....................................................152

Showing/Hiding Filter Cleaning Warnings............................................................153

Showing/Hiding Split-Screen ID ............................................................................153

Showing/Hiding the Test Pattern...........................................................................154

Projecting from Multiple Projectors at Once (Edge Blending) ........................... 155

■ Basic Instructions ..............................................................................................155

■ Advanced Instructions: Black Level Adjustment ............................................... 158

■ Advanced Instructions: Smoother Overlapping Areas ......................................160

Connecting to a Network ..............................................................163

Network Connection Overview .......................................................... 164

Connection Methods............................................................................................... 164

Completing Projector Settings .......................................................... 165

Locking/Unlocking Network Settings....................................................................165

Enabling/Disabling the Network Password ..........................................................166

Registering a Network Password .......................................................................... 167

Enabling/Disabling Wired Network Functions .....................................................167

Specifying Standby Power Consumption.............................................................168

Viewing the IP Address ..........................................................................................168

Viewing the Gateway Address ............................................................................... 169

Viewing the MAC Address...................................................................................... 169

11

Table of Contents

Enabling/Disabling DHCP....................................................................................... 170

Specifying TCP/IP Settings ....................................................................................170

Initializing Network Settings ..................................................................................171

Specifying PJLink Settings .................................................................................... 171

Specifying Use of AMX Device Discovery ............................................................172

Specifying Use of Crestron RoomView.................................................................173

Completing Computer Settings ......................................................... 174

Specifying an IP Address ....................................................................................... 174

■ Windows 7.........................................................................................................174

■ Windows Vista...................................................................................................175

■ Windows XP......................................................................................................176

■ Mac OS X..........................................................................................................176

■ Resetting the IP Address Setting of the Computer ........................................... 177

Setting Up the Network...........................................................................................177

■ Displaying the Network Configuration Screen...................................................177

■ Network setting .................................................................................................179

■ Error notification mails....................................................................................... 190

Control via the Web Screen ...................................................................................191

Maintenance ...................................................................................193

Cleaning the Projector........................................................................ 194

Cleaning and Replacing the Air Filter ............................................... 195

Replacing the Air Filter...........................................................................................195

Cleaning the Air Filter.............................................................................................196

Replacing the Lamp............................................................................ 197

Replacement Lamp ................................................................................................. 198

Replacing the Lamp ................................................................................................198

■ If the lamp cover comes off ...............................................................................200

12

Table of Contents

Networked Multi-Projection (NMPJ)........................201

Networked Multi-Projection Overview .........................................203

Introduction to Networked Multi-Projection ..................................... 204

■ Projection Over a Network ................................................................................204

■ Split-Screen Projection of Multiple Images ....................................................... 204

■ Projection of an Image from Multiple Projectors at Once.................................. 204

■ Selecting the Projection Monitor ....................................................................... 205

Installing the NMPJ Application ........................................................ 206

System Requirements ............................................................................................206

Installation ...............................................................................................................207

■ Uninstallation.....................................................................................................209

From Startup to Shutdown................................................................. 211

■ Projection Sessions...........................................................................................215

Operation in Each Mode................................................................217

Using the Projector in Direct Mode ................................................... 218

Procedure ................................................................................................................ 218

Direct Mode Window............................................................................................... 220

Table of Contents

Using the Projector in Meeting Mode................................................ 222

Creating a Session..................................................................................................222

Joining a Session.................................................................................................... 228

Meeting Mode Window ...........................................................................................230

Using the Projector in Classroom Mode........................................... 232

Leading a New Session ..........................................................................................232

Joining an Existing Session ..................................................................................238

Classroom Mode Window (Starting a Session)....................................................241

Classroom Mode Window (Joining a Session) ....................................................243

Using the Projector in Broadcast Mode............................................ 245

Procedure ................................................................................................................ 245

Broadcast Mode Window .......................................................................................248

Functions in All Modes .................................................................251

Using the Session Selection Menu ................................................... 252

Session Selection Menu ......................................................................................... 252

Finding Sessions ....................................................................................................253

13

Table of Contents

Using the Projector Selection Menu ................................................. 254

Projector Selection Menu ....................................................................................... 254

■ Finding Projectors .............................................................................................256

■ Selecting Password-Protected Projectors......................................................... 257

■ Using the Favorites Function ............................................................................ 258

■ Resorting the Projector List...............................................................................259

■ Turning Projectors On .......................................................................................259

Using Layout Functions ..................................................................... 260

■ Switching Projectors Used for the Layout .........................................................260

■ Controlling all Projectors at Once......................................................................260

■ Projecting from Multiple Projectors (Multi-Projection) ....................................... 261

■ Switching the Primary/Secondary Monitor ........................................................262

■ Temporarily Enlarge Images .............................................................................262

■ Projecting Session Information .........................................................................263

■ Fully Blanking Projection...................................................................................263

■ Blanking Projection from Your Computer.......................................................... 265

■ Checking for Computers That Join or Leave Sessions .....................................266

Completing Application Projection Settings.................................... 268

Reducing Windows to a Compact Size............................................. 270

Tips for Better Networked Projection ............................................... 271

■ Avoid Exceeding Connection Limits..................................................................271

■ Operation if Devices Are Disconnected ............................................................271

■ If Projectors Cannot Be Detected......................................................................271

Restrictions ......................................................................................... 272

■ Router Connections ..........................................................................................272

■ Security Dialog Box Projection..........................................................................272

■ Screen Capture Software..................................................................................272

■ Animated Cursors .............................................................................................272

■ Alternative Cursors............................................................................................272

■ Projection Restrictions ......................................................................................272

■ Network Bandwidth ...........................................................................................272

■ Projection through Firewalls..............................................................................272

■ Application Display............................................................................................272

14

Table of Contents

Appendix ...................................................................273

Appendix ........................................................................................275

Troubleshooting.................................................................................. 276

LED Indicator Meanings .........................................................................................276

Symptoms and Solutions .......................................................................................277

■ You Cannot Turn on the Projector ....................................................................277

■ You Cannot Project an Image from the Projector ............................................. 278

■ There is no Sound.............................................................................................279

■ The Projected Image Is Blurred ........................................................................ 280

■ You Cannot Project an Image Appropriately..................................................... 281

■ The Projector Power Turns Off ......................................................................... 281

■ You Cannot Operate the Remote Control .........................................................282

■ You Cannot Control Networked Multi-Projection...............................................282

Relationship between Aspect and Screen Aspect........................... 283

■ When the image is projected on a 16:10 screen............................................... 283

■ When the image is projected on a 16:9 screen.................................................284

■ When the image is projected on a 4:3 screen................................................... 284

■ When projecting on a 16:10 screen in the aspect ratio of

the connected device ............................................................................................ 285

■ When projecting on a 16:9 screen in the aspect ratio of

the connected device ............................................................................................ 285

■ When projecting on a 4:3 screen in the aspect ratio of

the connected device ............................................................................................ 286

Table of Contents

Displayed Test Patterns ..................................................................... 287

Supported Signal Types..................................................................... 288

Product Specifications....................................................................... 290

■ Projector............................................................................................................ 290

■ Remote control..................................................................................................291

■ External View .................................................................................................... 292

■ ANALOG PC-2 / COMPONENT terminal..........................................................293

■ Service Port (CONTROL)..................................................................................293

Index..................................................................................................... 296

Option .................................................................................................. 299

Menu Configuration ............................................................................ 300

15

Safety Instructions

Before installing and operating the projector, read this manual thoroughly.
This projector provides many convenient features and functions. Operating the
projector properly enables you to manage those features and maintain it in good
condition for many years to come.
Improper operation may result in not only shortening the product life, but also
malfunctions, fire hazards, or other accidents.
If your projector does not seem to be operating properly, read this manual again,
check operations and cable connections, and try the solutions in the
“Troubleshooting” section in the back of this manual. If the problem still persists,
contact the Canon Customer Support Center.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE EXCEPT LAMP REPLACEMENT. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE
CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT
WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT
OPERATING AND MAINTENANCE INSTRUCTIONS FOR THIS
UNIT IN THE OWNER’S MANUAL.

CAUTION

Not for use in a computer room as defined in the Standard for the Protection of
Electronic Computer / Data Processing Equipment, ANSI / NFPA 75.

16

Safety Instructions

Safety Precautions

WARNING:

• THIS APPARATUS MUST BE GROUNDED.

• TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.

• This projector produces intense light from the projection lens. Do not stare

directly into the lens, otherwise eye damage could result. Be especially careful
that children do not stare directly into the beam.

• Install the projector in a proper position. Otherwise it may result in a fire hazard.

• Allowing the proper amount of space on the top, sides, and rear of the projector

cabinet is critical for proper air circulation and cooling of the unit. The diagrams
shown here indicates the minimum space required. If the projector is to be built
into a compartment or similarly enclosed, these minimum distances must be
maintained.

SIDE and TOP REAR

50 cm (1.6')

Safety Instructions

50 cm

(1.6')

• Do not cover the ventilation slots on the projector. Heat build-up can reduce the
service life of your projector, and can also be dangerous.

• If the projector is unused for an extended time, unplug the projector from the
power outlet.

• Do not project the same image for a long time.

An afterimage may remain on the LCD panels due to the characteristics of the
panels of the projector.

50 cm

(1.6')

50 cm

(1.6')

CAUTION ON HANGING FROM THE CEILING

When hanging the projector from the ceiling, clean the air intake vents and top of
the projector periodically with a vacuum cleaner. If you leave the projector unclean
for a long time, the cooling fans can be clogged with dust, and it may cause a
breakdown or a disaster.

DO NOT SET THE PROJECTOR IN GREASY, WET, OR SMOKY CONDITIONS
SUCH AS IN A KITCHEN TO PREVENT A BREAKDOWN OR A DISASTER. IF
THE PROJECTOR COMES IN CONTACT WITH OIL OR CHEMICALS, IT MAY
BECOME DETERIORATED.

17

Safety Instructions

■ READ AND KEEP THIS OWNER’S MANUAL FOR LATER

USE.

All the safety and operating instructions should be read before beginning to operate
the product.

Read all of the instructions given here and retain them for later use. Unplug this
projector from the AC power supply before cleaning. Do not use liquid or aerosol
cleaners on the projector. Use a damp cloth for cleaning.

Follow all warnings and instructions marked on the projector.

For added protection of the projector during a lightning storm, or when it is left
unattended or unused for long periods of time, unplug it from the wall outlet. This
will prevent damage due to lightning and power surges.

Do not expose this unit to rain or use near water... for example, in a wet basement,
near a swimming pool, etc...

Do not use attachments not recommended by the manufacturer as they may result
in hazards.

Do not place this projector on an unstable cart, stand, or table. The projector may
fall, causing serious injury to a child or adult, and serious damage to the projector.
Use only with a cart or stand recommended by the manufacturer, or sold with the
projector. Wall or shelf mounting should be carried out in accordance with the
manufacturer’s directions, and should use a mounting kit approved by the
manufacturers.
An appliance and cart combination should be moved with care.
Sudden stops, excessive force, and uneven surfaces may cause
the appliance and cart combination to overturn.

Slots and openings in the rear and front of the cabinet are provided
for ventilation, to insure reliable operation of the equipment and to protect it from
overheating.

The openings should never be covered with cloth or other materials, and the
bottom opening should not be blocked by placing the projector on a bed, sofa, rug,
or other similar surface. This projector should never be placed near or over a
radiator or heat register.

This projector should not be placed in a built-in installation such as a book case
unless proper ventilation is provided.

18

Safety Instructions

Never push objects of any kind into this projector through cabinet slots as they may
touch dangerous voltage points or short out parts that could result in a fire or
electric shock. Never spill liquid of any kind onto the projector.

Do not install the projector near the ventilation duct of air-conditioning equipment.

This projector should be operated using only the type of power source indicated on
the marking label. If you are not sure of the type of power supplied, contact the
Canon Customer Support Center or local power company.

Do not overload wall outlets and extension cords as this can result in fire or electric
shock. Do not allow anything to rest on the power cord. Do not locate this projector
where the cord may be damaged by people walking on it.

Do not attempt to service this projector yourself as opening or removing covers
may expose you to dangerous voltages or other hazards. Refer all servicing to
qualified service personnel.

Unplug this projector from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the projector.
c. If the projector has been exposed to rain or water.
d. If the projector does not operate normally after following the operating

instructions. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and
will often require extensive work by a qualified technician to restore the projector

to normal operating condition.
e. If the projector has been dropped or the cabinet has been damaged.
f. When the projector exhibits a distinct change in performance-this indicates a

need for servicing.

Safety Instructions

When replacement parts are required, be sure the service technician uses
replacement parts specified by the manufacturer that have the same characteristics
as the original parts. Unauthorized substitutions may result in fire, electric shock, or
injury.

Upon completion of any service or repairs to this projector, ask the service
technician to perform routine safety checks to determine that the projector is in safe
operating condition.

19

Safety Instructions

AC Power Cord Requirement

The AC Power Cord supplied with this projector meets the requirements for use in
the country you purchased it.

AC Power Cord for the United States and Canada:

The AC Power Cord used in the United States and Canada is
listed by the Underwriters Laboratories (UL) and certified by
the Canadian Standard Association (CSA).
The AC Power Cord has a grounding-type AC line plug. This is
a safety feature to ensure the plug fits into the power outlet. Do
not try to tamper with this safety feature. Should you be unable
to insert the plug into the outlet, contact your electrician.

THE SOCKET-OUTLET SHOULD BE INSTALLED NEAR THE EQUIPMENT AND
EASILY ACCESSIBLE.

NOTE FOR CUSTOMERS IN THE US

LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE
RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR
FEDERAL LAWS.

Ground

Only for European Union and EEA (Norway, Iceland and
Liechtenstein)

These symbols indicate that this product is not to be disposed of
with your household waste, according to the WEEE Directive (2012/
19/EU), the Battery Directive (2006/66/EC) and/or national
legislation implementing those Directives.
If a chemical symbol is printed beneath the symbol shown above, in
accordance with the Battery Directive, this indicates that a heavy
metal (Hg = Mercury, Cd = Cadmium, Pb = Lead) is present in this
battery or accumulator at a concentration above an applicable
threshold specified in the Battery Directive.
This product should be handed over to a designated collection point,
e.g., on an authorized one-for-one basis when you buy a new similar
product or to an authorized collection site for recycling waste
electrical and electronic equipment (EEE) and batteries and
accumulators. Improper handling of this type of waste could have a
possible impact on the environment and human health due to
potentially hazardous substances that are generally associated with
EEE. Your cooperation in the correct disposal of this product will
contribute to the effective usage of natural resources.
For more information about the recycling of this product, please
contact your local city office, waste authority, approved scheme or
your household waste disposal service or visit
www.canon-europe.com/weee

, or www.canon-europe.com/battery.

20

Safety Instructions

Federal Communication Commission Notice

Multimedia Projector, Model: WUX450 / WX520
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that

may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

Safety Instructions

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio / TV technician for help.

The cable with a ferrite core provided with the projector must be used with this
equipment in order to comply with Class B limits in Subpart B of Part 15 of the
FCC rules.
Use of a shielded cable is required to comply with class B limits in Subpart B of
Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise
specified in the instructions. If such changes or modifications should be made,
you could be required to stop operation of the equipment.
Canon U.S.A. Inc.
One Canon Park, Melville, New York 11747, U.S.A.
Tel No. [phone]

Canadian Radio Interference Regulations

This Class B digital apparatus complies with Canadian ICES-003.

21

Safety Instructions

Safety Symbols in this Manual

This section describes the safety symbols used in this manual. Important projector
safety information is identified by the following symbols. Always observe the safety
information by these symbols.

Denotes the risk of death or serious injury from improper
handling if the information is not observed. To ensure safe use,
always observe this information.

Denotes the risk of injury from improper handling if the
information is not observed. To ensure safe use, always observe
this information.

Denotes prohibited actions.

Denotes required actions or information that must be observed.

22

Safety Instructions

Precautions for Use

As this section contains important safety-related information, be sure to read the
following carefully beforehand in order to use your projector correctly and safely.

If the following situations occur, turn the power off, remove the power plug from the
power outlet and contact the Canon Customer Support Center. Failure to do so could
cause a fire or result in an electric shock.

• If smoke is emitted

• If an unusual smell or noise is emitted

• If a loud noise is heard and the lamp turns off

• If water or other liquid has entered the projector

• If metal or any other foreign material has entered the projector

• If the projector is knocked over or dropped and the cabinet is damaged

Pay attention to the following points for handling the power cord. Failure to do so may
cause a fire, electric shock or personal injury.

Safety Instructions

• Do not place any objects on the power cord and do not allow it to become
trapped under the projector. The power cord may be damaged.

• Do not cover the power cord with a carpet.

• Do not excessively bend, twist, pull or make modifications to the power cord.

• Keep the power cord away from heaters and other sources of heat.

• Do not use the power cord when it is bent finely, coiled or bundled.

• Do not use a damaged power cord. If your power cord is damaged, contact

the Canon Customer Support Center.

• Do not use any power cord other than the type that is included with this
projector.

• Be sure to connect the ground wire of the power cord to ground. Failure to
do so could result in an electric shock.

• Be sure to connect the ground wire before connecting the power plug to the
outlet. Also when you disconnect the ground wire, be sure to unplug the
power plug from the outlet beforehand.

23

Safety Instructions

Pay attention to the following points regarding the power source, power plug and
handling of the connector. Failure to do so may cause a fire, electric shock or personal
injury.

•

Do not use any power source with a voltage other than the voltage indicated
(AC 100–240 V).

• Do not pull the power cord and be sure to hold the power plug or connector
when removing. The cord could be damaged as a result.

• Do not insert any metal objects into the contact parts of the power plug or
connector.

• Remove the power plug from the outlet before performing cleaning or
maintenance of the projector.

• Do not remove the power plug or connector with wet hands.

• Insert the power plug and connector securely up to the base. Additionally, do

not use a damaged power plug or an outlet that is loose.

• If using an extension cord attached to the outlet, make sure that the total
electric power consumption of connected devices does not exceed the rated
capacity.

• Periodically inspect the power plug and outlet and remove any dust or dirt
from between the plug and the outlet.

Precautions for Installation

Pay attention to the following points regarding installation and handling of the projector.
Failure to do so may cause a fire, electric shock or personal injury.

• Do not use the projector in a bathroom or shower room.

• Do not use the projector in rain or snow, by the sea, or in close proximity to a

body of water.

• Do not place containers containing a liquid on top of the projector.

• Do not place the projector in any location where it will be exposed to oily

smoke or steam, such as a kitchen work surface or table etc.

• Do not touch the projector itself, the power cord, or the cable if lightening
strikes.

24

Safety Instructions

Pay attention to the following points regarding installation and handling of the projector.
Failure to do so may cause a fire, electric shock or personal injury.

• Do not move the projector until you have switched off the power, removed
the power plug from the power outlet and unplugged any other cables.

• Do not remove the cabinet from the projector or disassemble it. The interior
of the projector contains high-voltage components as well as parts that are
hot. These could cause an electric shock or burn. If inspection, maintenance
or repair is required, contact the Canon Customer Support Center.

• Do not disassemble or modify the projector (including consumable parts) or
the remote control.

• Do not look directly into the exhaust vents during use.

• Do not insert any object into vents in the projector, such as the air intake vent

or exhaust vents.

• Do not place a pressurized can in front of the exhaust vents. The pressure of
the contents of the can may increase due to heat from the exhaust vents and
this could result in an explosion.

• As strong light beams are emitted while the projector is in use, do not look
directly into the projector lens. Doing so could cause an eye injury. Pay
particular attention to prevent small children from doing so.

• When giving a presentation in front of the projector while it is projecting an
image, conduct your presentation from a position where your shadow will not
be cast on the screen and where you do not feel blinded by light from the
projector.

• When setting the projector on a high surface for projection, be sure the
surface is flat and stable. Failure to do so could result in the projector falling
down and causing an accident or personal injury.

Safety Instructions

Pay attention to the following points regarding installation and handling of the projector.

• If the projector will not be used for a long period of time, be sure to remove
the power plug from the power outlet to ensure safety. Failure to do so could
cause a fire.

• The temperature of the cabinet around and above the exhaust vents can
become hot during projector operation.
Touching these areas during operation could cause burns to the hands. Do
not touch these areas. Doing so may cause burns. Pay particular attention in
preventing young children from touching these parts. Additionally, do not
place any metal objects on these areas. Due to the heat from the projector,
doing so could cause an accident or personal injury.

25

Safety Instructions

Pay attention to the following points regarding installation and handling of the projector.

• Do not place any heavy objects on top of the projector or sit / stand on it. Pay
particular attention to prevent small children from doing so. The projector
may be knocked over and this could result in damage or a personal injury.

• Do not place the projector on an unstable or slanted surface. Doing so may
cause the projector to fall or be knocked over and could result in a personal
injury.

• Do not place any objects in front of the lens while the projector is operating.
Doing so could cause a fire.

• When cleaning off dust or dirt from the projector lens etc., do not use any
kind of spray that is flammable. As the temperature of the lamp inside the
projector is high, it could ignite, causing a fire.

• If the projector is used for a long period of time, dust could accumulate inside
the projector. This could cause a fire or malfunction. It is recommended that
periodic maintenance of the projector be performed. For details of
maintenance costs, contact the Canon Customer Support Center.

Precautions on the lamp

When replacing the lamp, or when the lamp is damaged, pay attention to the following
points. Failure to do so could result in an electric shock or personal injury.

• Be sure to remove the power plug from the power outlet before replacing the
lamp.

• When the lamp is damaged, shards of glass may be scattered inside the
projector. Contact the Canon Customer Support Center for cleaning and
inspection of the projector interior and lamp replacement.

• Precautions when replacing lamps that stop working
If the illumination suddenly stops when the projector is in use or after you
turn it on, the lamp may be broken. In this case, never attempt to replace the
lamp by yourself. Always request service from the Canon Customer Support
Center. Additionally, with ceiling-mounted projectors, the lamp may fall out
when you open the lamp cover or while you are attempting to replace it.
During replacement, stand to the side of the lamp cover, not directly under it.
If the lamp breaks and any glass shards or other pieces get in your eyes or
mouth, consult a doctor immediately.

• If the lamp is damaged, gas inside the lamp (containing mercury) and dust
may be emitted from the exhaust vents. If this happens, immediately open
the windows and doors to provide ventilation to the room. If you inhale any
gas emitted from the lamp or it has come into contact with your eyes or
mouth, consult a doctor immediately.

26

Safety Instructions

When handling the lamp, pay attention to the following points.

• Be sure not to handle the lamp immediately after it has been used. Be sure
to switch off the power and wait for approximately 1 hour for the lamp and
the projector to cool down sufficiently. Failure to do so could result in a burn
or personal injury due to heat from the lamp or projector.

• When an instruction to replace the lamp has been displayed (LAMP Indicator
Displays (P41)), the possibility of the lamp breaking will increase. Replace
the lamp with a new one as soon as possible.

• When disposing of a used mercury lamp, dispose of it in the same way as a
fluorescent lamp and in accordance with the local regulations where you live.

Precautions for the batteries of the remote control

Safety Instructions

Pay attention to the following points regarding handling of batteries. Failing to do so
could result in a fire or personal injury.

•

Do not heat, short circuit or disassemble the batteries, or place them in a fire.

• Do not attempt to recharge the batteries that are included with the remote
control.

• Remove the batteries when they are flat or when the remote control will not
be used for a long period of time.

• When replacing the batteries, replace both at the same time. Also, do not
use two batteries of a different type at the same time.

• Insert the batteries with the + and - terminals in the correct directions.

• If any liquid from inside the batteries leaks out and contacts your skin, be

sure to wash the liquid off thoroughly.

27

For Safe Use

Pay attention to the following points when carrying or transporting the projector.

• This projector is a precision instrument. Do not knock it over or subject it to
impacts. Doing so may cause a malfunction.

• Do not reuse any packaging or shock-absorbent materials that were
supplied with the projector at the time of purchase for transporting or
shipping the projector. Protection of the projector cannot be guaranteed if
used packaging or shock-absorbent materials are reused. Fragments from
shock-absorbent material may also enter the interior of the projector which
could cause a malfunction.

• Disconnect the cables connected to the projector. Carrying the projector with
the cables attached may cause an accident.

• Retract the adjustable feet.

• Attach the lens cap to protect the lens.

28

Pay attention to the following points when installing or using the projector.

• Do not touch the lens with bare hands. Doing so may result in deterioration
of image quality.

• If the projector is suddenly moved from a location where the temperature is
low to a location where the temperature is high, or if the temperature in the
location where the projector is installed increases suddenly, moisture in the
air could cause condensation to form on the projector lens or mirror. This
may cause a blurred image. Wait until the condensation has evaporated for
the image projected to return to normal.

• Do not install the projector in a location where the temperature is high or low.
Doing so may cause a malfunction. The temperature range for operation and
storage are as follows.

Operating temperature: 0°C to 40°C Humidity level: up to 85%
Storage temperature: -10°C to 60°C

• Do not place any objects on top of the projector that may change shape or
color due to heat.

• When using the projector at altitudes greater than 2,
projecting upward / downward:

When using the projector at altitudes greater than 2,
for upward projection or downward projection, it is necessary to change
the settings of the projector. Specifically, adjust [Fan mode] (P148) or
[Vertical projection] (P148) in the [Install settings] menu.

• Do not install the projector near high-voltage electrical power lines or an
electrical power source.

• Do not use the projector on a soft surface such as carpet or sponge mat, etc.
Doing so could cause heat to build up inside the projector and this could
result in a malfunction.

• Do not block the air intake or exhaust vents of the cooling fan. If the air
intake or exhaust vent is blocked, heat cannot be released from inside the
projector, which may shorten the useful life of the lamp or cause malfunction.

• Installing the projector in the wrong direction may cause a malfunction or
accident. Install the projector so that the left / right incline is within 10°.

• Be sure to install the projector in a location where the air intake and exhaust
vents are separated from the wall by more than 50 cm (1.6'). Failure to do so
could cause a malfunction.

• Do not install the projector in a location that is damp, or where there is a lot
of dust, oily smoke or tobacco smoke. Doing so could cause contamination
of optical components such as the lens and the mirror and may result in
deterioration of image quality.

300 m (7,545.8'), or for

300 m (7,545.8'), or

For Safe Use

For Safe Use

29

30

Table of Contents

Safety Instructions

Before Use

Before Use

Projecting an Image

Operation

Useful Functions Available
During a Presentation

Setting Functions from
Menus

Installation and Maintenance

Installation

Connecting to a Network

Maintenance

31

Networked Multi-Projection

Networked Multi-Projection
Overview

Operation in Each Mode

Functions in All Modes

Appendix

Other Information

Index

Supplied Accessories

Check that the following accessories have been supplied with the projector.

• Remote control • Batteries for the remote control

(AAA size x2)

(part No.: RS-RC06)

Optional remote controls are
also available (RS-RC04, RS­RC05). However, some buttons
are not supported with this
projector. The RS-RC05 can
also be used as a wired remote.
(P35)

• Lens cap

• Computer cable (1.8 m / 5.9')

(mini D-sub 15-pin / mini D-sub 15-pin)

• User’s Manual (CD-ROM)

• Power cord (1.8 m / 5.9')

For the U.S.A. and
Canada

• Warranty Card

• Important Information

■ Attaching the Lens Cap

Align the lens cap notch with the zoom
adjustment lever as shown and attach the cap.

• Always remove the cap before

projection. Accidentally leaving
the cap on during projection may
distort the cap and damage the
projector.

• Align the notch with the zoom

adjustment lever and attach.

For Continental
Europe

32

Preparing the Remote Control

■ Installing Remote Control Batteries

1 Open the battery

compartment lid.

Slide the lid while
pressing it down.

• If buttons on the remote control are inoperative when you attempt to operate the
projector, replace the batteries with new ones.

• Do not drop the remote control or subject it to impact.

• Do not spill any liquids on the remote control. Doing so could damage it.

Pay attention to the following points when handling the batteries.
Failing to do so could result in a fire or personal injury.

• Do not heat, short circuit or disassemble the batteries, or place
them in a fire.

• Do not attempt to recharge the batteries that are included with the
remote control.

2 Insert batteries.

Insert 2 new AAA
batteries in the
compartment with the
+ and – poles
positioned correctly.

3 Close the

compartment lid.

Slide the lid until you
hear a click to
securely close it.

Before Use

• Remove the batteries when they are flat or when the remote control
will not be used for a long period of time.

• When replacing the batteries, replace both at the same time. Also,
do not use two batteries of a different type at the same time.

• Insert the batteries with the + and - terminals in the correct
directions.

• If any liquid from inside the batteries leaks out and contacts your
skin, be sure to wash the liquid off thoroughly.

33

Preparing the Remote Control

■ Remote Control Operating Range

The remote control is an infrared type. Point it at the infrared remote receiver on the
front or rear of the projector to operate it.

25°

8 m (26.3')

25°

8 m (26.3')

25°

25°

• Use the remote control within a distance of approximately 8 m (26.3') from the
projector.

• Use the remote control within an angle of 25° in any direction from directly in front of the
infrared remote receiver.

• The remote control may be inoperative if there is an obstacle between the remote
control and the projector or the infrared remote receiver on the projector is exposed to
direct sunlight or strong light of lighting equipment.

• When you use 2 or more projectors at the same time, you can change the channel
settings to prevent the 2 remote controls from interfering with each other. (P111)

34

Preparing the Remote Control

■ Using an Optional Wired Remote (RS-RC05)

To use a wired remote control with the projector, use the RS-RC05, sold separately.
Use a cable with a ø3.5 mm stereo mini jack (not included).

Remote control

(RS-RC05)

Terminal for wired

remote control

ø3.5 mm stereo mini jack

cable (not included)

• Infrared operations cannot be performed if a cable is connected to the projector or the
remote control.

• Use a cable with a ø3.5 mm stereo mini jack (not included) with a length of 30 m (98.4')
or less.

Before Use

35

Part Names

Projector

■ Front Side

Side control

(P40)

Terminals and
connectors (P42)

Hole caps (P129)
Attach option feet (sold
separately). For instructions
on removing the hole caps,
refer to “Attaching Option
Feet (RS-FT01, Sold
Separately)”.

Projection lens (P43)

Infrared remote receiver (P34)

Air intake vent
Air filter (P195)

Power cord connector
(P140)

■ Rear Side

Lens shift
side control
(P43)

• Do not block the air intake.
Doing so may cause a malfunction.

• Before projection, always remove the
cap. Leaving the cap on may damage
the projector.

Lamp cover

Exhaust vent

Do not block the air exhaust.
Doing so may cause a
malfunction.

Infrared remote receiver (P34)

Anti-theft lock hole

An anti-theft wire cable (not included) can be connected.

36

■ Bottom Side

Adjustable feet (P128)

Mounting the Projector on the
Ceiling

You can mount the projector on the
ceiling.
The ceiling attachment (part No.: RS­CL12) is required in order to mount
the projector on the ceiling.
Depending on the installation
environment, an extension pipe (part
No.: RS-CL08 or RS-CL09) may also
be required. Contact the Canon
Customer Support Center for more
detailed information.

• Make sure to use the optional
ceiling attachment.

• You should never install the
ceiling attachment by yourself.

Part Names

Before Use

If you mount the projector on the
ceiling, you have to invert the
projected image by selecting [Image
flip H/V] from the menu. (P143)

37

Part Names

Remote control

The projector can be operated using buttons on the remote control or the side
control on the projector.
The remote control allows you to operate all functions of the projector.

POWER button (P50, P71)

Turns the projector on or off.

BLANK button (P74)

Toggles between display / non-display
of image.

ASPECT button (P64)

Changes the aspect ratio mode.

KEYSTONE button (P65)

Corrects keystone distortion.
The [Keystone] setting enables both
horizontal/vertical keystone correction
(by adjusting top/bottom/left/right
length) and corner correction.

D.ZOOM button (P76)

Zooms the image in or out digitally.
[+] button: Zooms the image in (up to

12x).

[–] button: Zooms the image out (1x

minimum).

[ ] / [ ] / [ ] / [ ] buttons:

Move the zoom-in location.

IMAGE button (P68)

Switches the image mode (image
quality).

GAMMA button (P98)

Adjusts the gamma of the image.
[ ] button: Corrects dark parts of the

image so that they are
easier to see.

[ ] button: Corrects bright parts of

the image so that they are
easier to see.

38

INPUT button (P52)

Switches the input signal.

Part Names

AUTO PC button (P55)

Adjusts tracking etc. automatically in accordance with the signal
from a computer when the analog PC input is selected.

MENU button (P82)

Displays a menu on the screen. Also used to assign a channel to
the remote control. (P111)

FREEZE button (P74)

Freezes the projected image.

Pointer buttons (P83)

Selects the upper, lower, left or right item in the menu. Also used
to assign a channel to the remote control. (P111)

OK button (P83)

Determines the item selected from the menu.

EXIT button (P84)

Cancels functions such as menu

VOL button (P75)

Adjusts the sound volume.

display or test pattern during operation
and returns to the image display.

[+] button: Increases the volume.
[–] button: Decreases the volume.

Before Use

MUTE button (P75)

Mutes the sound.

ECO button (P70)

Displays the Eco menu, to complete
power-saving settings.

TEST PATTERN button (P154)

Displays the test pattern.

SPLIT button (P79)

Activates the split screen function.

Fn button

Cannot be used on this product.

39

Part Names

Side Control

(6)

(1) POWER button (P50, P71)

Turns the projector on or off.

(2) INPUT button (P52)

Switches the input signal.

(3) AUTO PC button (P55)

Adjusts tracking etc. automatically
in accordance with the signal from
a computer when the analog PC
input is selected.

(4) KEYSTONE button (P65)

Corrects keystone distortion.

LED indicators

(5)(7)

(5) Pointer / VOL buttons (P75, P83)

Adjust the sound volume.
[ ] VOL+ button: Increases the
volume.
[ ] VOL– button: Decreases the
volume.
Selects the upper, lower, left or
right item in the menu.

(6) OK button (P83)

Determines the item selected from
the menu.

(7) MENU button (P82)

Displays a menu on the screen.

(1)(2)(3)(4)

The projector status is shown by the LED indicators (off / on / flashing).
For indicator status, refer to “LED Indicator Displays” (P41).

40

Part Names

• POWER ON (green) : Lights up or flashes under normal conditions when the

power is on.

• WARNING (red) : Lights up or flashes when an error occurs.

• LAMP (orange) : Flashes when the time for replacing the lamp is near.

When a lamp cover error occurs, the [WARNING]
indicator will also flash. When a lamp error occurs, it will
illuminate at the same time as the [WARNING] indicator.

• TEMP (red) : When the temperature inside the projector is high, it will
flash. If the temperature inside the projector increases
further and a temperature error occurs, it will illuminate at
the same time that the [WARNING] indicator illuminates.

■ LED Indicator Displays

The LED indicators flash or illuminate to indicate the operating status of the
projector.

: Off : Lit : Flashing

LED indicator

POWER

ON

(green)

WARNING

(red)

LAMP

(orange)

TEMP

(red)

Projector in standby mode or not plugged in.

Operating status

Before Use

Power is on.

Waking from or entering standby mode.

The time for replacing the lamp is near. (In standby
mode.)

The time for replacing the lamp is near. (When
POWER ON is lit.)

Internal temperature is high.

A lamp error has occurred.

Power was turned off due to high internal
temperature.

The lamp cover is open.

Another error has occurred.

41

Part Names

Input Terminal

(1) (3)

(2)

(4) (5) (6) (7) (8) (9)

(1) AUDIO OUT terminal (AUDIO OUT) (P136, P139)

Outputs the audio to external AV equipment. This outputs the audio signal that
corresponds to the projected image signal.

(2) AUDIO IN terminal (AUDIO IN) (P134, P135, P138)

Receives the audio signal input for 2 kinds of image input other than HDMI.
The internal speaker outputs the audio for the selected image signal.

(3) Terminal for wired remote control (REMOTE) (P35)

This terminal is used to connect the remote control using a cable.

(4) USB port (P77)

Connects a USB flash drive. Used for projection of images on a USB flash
drive, or for firmware updates.

(5) DVI-I input terminal ( DVI-I) (P135)

Connects the external monitor output from a computer.
Receives analog and digital PC signals (Analog PC-1 and Digital PC,
respectively).

(6) ANALOG PC / COMPONENT input terminal ( / COMPONENT)

(P134, P138)

Receives the analog PC signal (Analog PC-2).
A component cable can be used to receive the component image signal
(Component).

(7) HDMI input terminal (HDMI) (P136)

Receives digital video signals (HDMI).
Carries both video and audio signals across a single cable.

(8) LAN port (P164)

Connects the LAN cable (shielded twisted pair).
Used to connect the projector to a network.

(9) Service port (CONTROL)

It is not used during ordinary use.

42

Lens Shift Control

Part Names

(1)

(2)

(1) Vertical lens shift dial

Slides the lens up or down for vertical image adjustment.

(2) Horizontal lens shift dial

Slides the lens left or right for horizontal image adjustment. For details on lens
shift, refer to “Lens Shift Function” (P131).

Projection Lens

(1)

(2)

Before Use

(1) Zoom adjustment

Move the lever to resize the image. (P55)

(2) Focus adjustment

Turn the focus ring to adjust image focus. (P56)

43

Open Source Software

The product contains Open Source Software modules. For details, see
“ThirdPartySoftware.pdf” (Third-Party Software License) in the
OpenSourceSoftware folder in the LICENSE folder on the Setup CD-ROM. Each
module’s license conditions are also available in the same folder.

■ Software under the GPL and LGPL

The product includes modules licensed under the GPL and LGPL.
Source code can be examined in the GPL and LGPL folders on the supplied Setup
CD-ROM.

■ Software under the GNU General Public License Version 2

Contained programs are free software; you can redistribute them and/or modify
them under the terms of the GNU General Public License attached to each copy of
the program.

Each program is distributed in the hope that it will be useful, but WITHOUT ANY
WARRANTY; without even the implied warranty of MERCHANTABILITY or
FITNESS FOR A PARTICULAR PURPOSE. Please see “NO WARRANTY” and
“NO SUPPORT” stated below. For more detail, please see full text of the GNU
General Public License.

NO WARRANTY

BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO
WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY
APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE
COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM
“AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE
ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM
IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME
THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN
WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY
MODIFY AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE
LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR
INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS
OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED
BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE
WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

44

Open Source Software

NO SUPPORT

Canon Inc., and all its subsidiaries or its dealers do not make any support service
regarding the source code. Canon Inc., and all its subsidiaries or its dealers shall
not respond to any questions or enquiries, from you or any other customers,
regarding the source code.

Before Use

45

46

MULTIMEDIA PROJECTOR

Operation

47

48

Table of Contents

Safety Instructions

Projecting an Image

Before Use

Projecting an Image

Operation

Useful Functions Available
During a Presentation

Setting Functions from
Menus

Installation and Maintenance

Installation

Connecting to a Network

Maintenance

49

Networked Multi-Projection

Networked Multi-Projection
Overview

Operation in Each Mode

Functions in All Modes

Appendix

Other Information

Index

Step 1 Turn the Projector On

1 Check the connection between the projector and the computer or AV

equipment. (P134 - P137)

For instructions on connecting the power cord, refer to “Plugging the Projector
In” (P140).

2 Press the POWER button.

The [POWER ON] indicator initially flashes green, after which it remains lit.

Remote control Projector

The countdown window is displayed for approximately 20 seconds, and then
the projection is started. Press the OK or EXIT button to make the countdown
window disappear.

• Network functions are not available for the first 40 seconds after startup.

• A window appears when the projector is turned on for the first time. You can select a
language to be used by the projector for displaying menus and messages in the
window. Select the desired language with the pointer buttons and press the OK button.
(P141)
You can change the language from the menu at a later time. (P113)

• If the language selection screen is out of focus, adjust the focus. (P56)

3 Turn on the computer or AV equipment power.

Changing Operations When Projector is Turned On

You can change operations when the projector is turned on as follows.

• You can turn on the projector by connecting the power cord, without
pressing the POWER button. (P109)

• You can change the countdown window. (P108)

• You can skip the countdown window. (P108)

When the Projector Is Left Idle

If no signal is received, the projector automatically turns off after a certain
period of inactivity (by default, 15 minutes). (P108)

50

Step 2 Select an Input Signal

Select the input signal in the [Input] menu when you want to project a digital PC or
AV equipment signal, or to switch between inputs when multiple computers or
multiple sets of AV equipment are connected.
Skip this step if you have not changed the input signal since the last projection.

Types of Input Signals

The table below shows the relationship among input signals supported by the
projector, input terminals and connection cables.

Input signal Input terminal Types of connection cables

HDMI cable (not included)

HDMI

DVI cable (not included)

Digital PC

VGA-DVI cable (not included)

Analog

PC-1

Computer cable (supplied)

/COMPONENT

BNC cable (not included)

Analog

PC-2

Operation Projecting an Image

/COMPONENT

Component

/COMPONENT

LAN

LAN

USB Connect a USB flash drive. (P77)

USB

Mini D-sub 15-pin - BNC
terminal converter cable
(not included)

Component cable (not included)

D terminal plug - RCA plug
component conversion cable
(not included)

RCA plug - RCA plug
component cable (not included)

LAN cable (shielded twisted pair) (not included)

51

BNC cable
(not included)

Step 2 Select an Input Signal

Selecting an Input Signal

1 Press the INPUT button to display the window shown below.

Remote control Projector

The currently active input signal is marked with a green circle and enclosed by
a orange border.
An input signal that is ready for projection is displayed in white. When no signal
is received, it is displayed in gray. However, [Digital PC] or [Analog PC-1] may
be displayed in gray even if these signals are ready for projection.

2 You can switch the available input signal types by pressing the INPUT

button.

• You can select the target input signal with [ ] / [ ].

3 Press the OK button to confirm the input signal type.

• Screens of computers connected to the projector over a network can be projected
when you have selected [LAN] as the input signal. For details, refer to Networked Multi­Projection (NMPJ).

• Images on USB flash drives can be projected when you have selected [USB] as the
input signal. For details, refer to “Projecting Images on a USB Flash Drive” (P77).

• In split-screen mode, the side without control rights is identified by a white circle.

52

Step 3 Adjust the Image

Setting the Display Resolution of the Computer

Based on the maximum resolution of the projector, set the display resolution of the
computer to the resolution closest to the output signal resolution of the projector.
(P288)

Maximum resolution
WUX450 : 1920 X 1200 dots

WX520 : 1440 X 900 dots

■ Windows 8

1 Move the cursor toward the upper or lower right corner to access the

menu.

2 Click [Settings], and then click [Control Panel].
3 From [Control Panel Home] -

[Appearance and Personalization],
select [Adjust screen resolution].

4 Select the resolution closest to the

maximum output signal resolution of
the projector from the [Resolution] list.

5 Click the [OK] button.

■ Windows 7

1 Open the [Control Panel] from the start

menu, then select [Appearance and
Personalization] - [Adjust screen
resolution] in the [Control Panel Home].

Operation Projecting an Image

2 Click the [Resolution] tab, and move the

slider to select the resolution closest to
the maximum output signal resolution
of the projector.

3 Click the [OK] button.

53

Step 3 Adjust the Image

■ Windows Vista

1 Open the [Control Panel] from

the start menu, then select
[Appearance and
Personalization] - [Adjust screen
resolution] in the [Control Panel
Home].

2 Under [Resolution], use the

slider to select the resolution
closest to the projector’s
maximum resolution.

3 Click the [OK] button.

■ Windows XP

1 Right-click on the desktop

background and select
[Properties] to open the [Display
Properties].

2 Click the [Settings] tab, and

under [Screen resolution], use
the slider to select the resolution
closest to the projector’s
maximum resolution.

3 Click the [OK] button.

■ Mac OS X

1 Open the Apple Menu and select

[System Preferences].

2 In the [System Preferences] window,

click the [Displays] icon to display the
Display window.

3 Select the [Display] tab and select the

resolution closest to the maximum
output signal resolution of the projector
from the [Resolutions] list.

4 Close the [System Preferences] window.

54

Step 3 Adjust the Image

Auto PC Adjustment

If the image display is shifted or there is flickering of the screen when [Analog PC-1]
or [Analog PC-2] is selected, press the AUTO PC button to adjust the projector to
the optimal condition.
The adjustment results will be stored. If the projector is used again with the same
computer, when the input signal is selected the image will be projected
automatically under the same conditions that were previously adjusted.

■ Performing the Auto PC Function

Press the AUTO PC button to perform projector adjustment.

Remote control Projector

If the Auto PC adjustment is insufficient, perform the following operations.

• Select the input signal that matches the resolution of the computer from [Input signal
select]. (P86)

• If adjustment is insufficient even when using the above operation, adjust [Total dots],
[Tracking], [Horizontal position], [Vertical position], [Horizontal pixels] and [Vertical
pixels] in [Input signal settings]. (P87 - P89)

• For the signal types supported by the projector, see the table on page 288.

Operation Projecting an Image

Adjusting the Image Size

To adjust the image size, turn the lever on the projection lens. Change the projector
installation position (P128) if your desired image is too large or too small to adjust it
with the zoom function.

55

Step 3 Adjust the Image

Adjusting the Image Position

Turn the lens shift dials to adjust the projected image vertically or horizontally.
Called “lens shift,” this adjusts the projected image into position by moving the lens
up, down, left, or right.

• Instead of adjusting where the image is projected, you can also move the image itself.
For details, refer to “Specifying Digital Image Shift” (P146).

• You can fine-tune the image position by turning the upper part of the upper lens shift
dial or the lower part of the lower lens shift dial.

Vertical lens shift dial

(2) (1)

(3) (4)

Horizontal lens shift dial

(1) Turning upper lens shift dial clockwise: Moves the image down.
(2) Turning upper lens shift dial counterclockwise: Moves the image up.
(3) Turning lower lens shift dial clockwise: Moves the image left.
(4) Turning lower lens shift dial counterclockwise: Moves the image right.
For details on lens shift, refer to “Lens Shift Function” (P131).

Adjusting the Focus

To adjust the focus, turn the focus ring.

Focus adjustment

Focus ring

56

Step 4

Select an optimum aspect ratio of the projected image (screen aspect) or an
optimum screen mode (aspect) according to the aspect ratio of the screen, type of
input image signal and so on for the projection to make best use of the screen size.

[Screen aspect] Select the same screen aspect ratio as the screen you are

[Aspect] In general, select [Auto].

You may need to change the setting depending on the resolution of the computer or
other AV equipment connected. If the image is not projected with the desired
aspect ratio, refer to “Relationship between Aspect and Screen Aspect” on page

283.

Select an Aspect Ratio (Screen Aspect) Matching the Screen

using.

Selecting Screen Aspect

Select the correct aspect ratio for the screen which is used.

1 Press the MENU button to display the menu window.

Remote control Projector

Operation Projecting an Image

2 Press the [ ] / [ ] buttons to select the [Install settings] tab.

Remote control Projector

57

Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen

3 Select [Screen aspect] with the [ ] / [ ] buttons, and then press the OK

button.

Remote control Projector

4 Use the [ ] / [ ] buttons to select the desired contents.

Remote control Projector

16:10

Select this when you use a screen with an aspect
ratio of 16:10. Also select this screen aspect when
projecting on a wall.
You can correct keystone distortion with this mode.
(P65)

16:9

Select this when you use a screen with an aspect
ratio of 16:9.
You can correct keystone distortion with this mode.
(P65)

4:3

Select this when you use a screen with an aspect
ratio of 4:3.
You can correct keystone distortion with this mode.
(P65)

16:10 screen

16:9 screen

4:3 screen

58

Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen

16:9 D. image shift

Select this when you use a screen with an aspect ratio of 16:9.
Keystone correction cannot be performed in this mode. However, it is possible to
move the image up / down when projecting level.
For details about how to move the image, refer to page 60.

4:3 D. image shift

Select this when you use a screen with an aspect ratio of 4:3.
Keystone correction cannot be performed in this mode. However, it is possible to
move the image left / right when projecting level.
For details about how to move the image, refer to page 61.

5 Press the OK button to accept your setting and then press the MENU

button.

Operation Projecting an Image

59

Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen

Moving Image with 16:9 D. Image Shift

This option applies image processing to reposition the image. For this reason, it is
called digital image shift.

1 When the screen aspect is [16:9 D. image shift], press the MENU button to

display the menu.

Projector

2 Press the [ ] / [ ] buttons to select the [Install settings] tab.

Remote control Projector

3 Use the [ ] / [ ] buttons to select [Digital image shift], then press the OK

button.

Remote control Projector

60

Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen

4 Use the [ ] / [ ] buttons to move the image up or down.

Remote control Projector

Operation Projecting an Image

[ ] button

Moves the image up.

Screen

[ ] button

Moves the image down.

5 When the image fits the screen, press the OK button.

Moving Image with 4:3 D. Image Shift

1 When the screen aspect is [4:3 D. image shift], press the MENU button to

display the menu.

Projector

2 Press the [ ] / [ ] buttons to select the [Install settings] tab.

Remote control Projector

61

Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen

3 Use the [ ] / [ ] buttons to select [Digital image shift], then press the OK

button.

Remote control Projector

4 Use the [ ] / [ ] buttons to move the image.

Remote control Projector

[ ] button

Moves the image right.

[ ] button

Moves the image left.

5 When the image fits the screen, press the OK button.

Resetting the Image Shift

Perform the following steps to reset the image shift adjustment.
Access the [D. image shift adjustment] window and press the KEYSTONE button to
display the [D. image shift reset] window.
Next, select [OK] with the [ ] button, and then press the OK button.

62

Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen

Selecting the Aspect

Select [Aspect] based on the input signal type, aspect ratio of the screen and
resolution.

For more details about aspect ratios, refer to “Relationship between Aspect
and Screen Aspect” on page 283.

Types of Aspect Ratios

Auto

An image is projected at the aspect ratio of the input signal. Select this mode for
normal image projection.

16:10

The image is projected using an input signal aspect ratio of 16:10.
Select this if an image of 16:10 aspect ratio cannot be correctly projected in [Auto]
mode.

16:9

The image is projected using an input signal aspect ratio of 16:9. Select this if an
image of 16:9 aspect ratio cannot be correctly projected in [Auto] mode.

Operation Projecting an Image

4:3

The image is projected using an input signal aspect ratio of 4:3. Select this if an
image of 4:3 aspect ratio cannot be correctly projected in [Auto] mode.

Zoom

This cuts the upper/lower or left/right part of the screen according to the screen
aspect and zooms in or out of the center of the image. Select this if a letter box is
displayed (black lines at the top/bottom of the screen) when watching video.

There may be some cases when this cannot be selected, depending on the input signal
and/or resolution.

True size

The image is projected with the original resolution of the input signal. Select this
option for clear projection of computer screens at up to maximum resolution.

There may be some cases when this cannot be selected, depending on the input signal
and/or resolution.

63

Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen

Selecting an Aspect Ratio

Press the ASPECT button on the remote control and select an appropriate aspect
ratio. Press the ASPECT button to change the aspect ratio type.
For more details about aspect ratios, refer to “Relationship between Aspect and

on

Screen Aspect”

Remote control

page 283

.

Example:

You can also select any aspect ratio from [Aspect] in the menu. (P85)

Some aspect ratios may not appear depending on the type of input signal.

64

Step 5 Correct the Image Distortion

Adjusting Keystone Distortion

To correct keystone distortion, press the KEYSTONE button.
Two types of correction are available: horizontal/vertical correction and corner
correction.
Horizontal/vertical keystone correction adjusts image width and height, and corner
correction adjusts the image relative to each corner.
For instructions on switching between the two types of keystone correction, refer to
“Specifying Keystone Correction” (P146). Press the KEYSTONE button to correct
distortion according to the selected keystone correction method.

• Keystone can be adjusted within the range of ±20 degrees. If the keystone distortion is
too large to adjust, move the projector installation position so that it is completely
straight.

• The result of keystone adjustment is stored in memory. If you place the projector in the
same position, the keystone adjustment is not necessary.

• Signals are processed digitally when keystone distortion is corrected. The image may
look different from the original one. In addition, the aspect ratio of the image may
change.

• Keystone correction may not be effective in some lens shift positions.

• The digital image shift function (P60) is accessed when this button is pressed and the
screen aspect is [4:3 D. image shift] or [16:9 D. image shift].

Operation Projecting an Image

■ Horizontal/Vertical Keystone Correction

1 Press either the KEYSTONE button on the remote control or the

KEYSTONE button on the projector to display the window shown below.

Remote control Projector

65

Step 5 Correct the Image Distortion

2 Press the pointer buttons to adjust the dimensions.

Remote control Projector

[ ] button

Reduces the dimensions

of the upper edge.

[ ] button

Reduces the dimension

of the left edge.

Reduces the dimensions of the

Screen

[ ] button

lower edge.

[ ] button

Reduces the dimension

of the right edge.

3 When keystone distortion has been corrected, press the OK button.

■ Corner Adjustment

1 Press either the KEYSTONE button on the remote control or the

KEYSTONE button on the projector in order to display the window shown
below on the right.

Remote control Projector

66

Step 5 Correct the Image Distortion

2 Press the pointer button of the corner for correction, and then press the

OK button.

Remote control Projector

3 Press the pointer buttons to adjust the corner.

Remote control Projector

Operation Projecting an Image

4 When you have finished correcting, press the OK button.

■ Resetting the Keystone Adjustment

Perform the following steps to reset the keystone adjustment.
Press the KEYSTONE button twice to display the [Keystone reset] window. You can
now reset the correction selected in the keystone setting.
Next, select [OK] with the [ ] button, and then press the OK button.

67

Step 6

Select the Image Quality (Image Mode)

You can select an image mode to suit the projected image.
In each image mode, you can further adjust the brightness, contrast, sharpness,
gamma, color adjustment, advanced adjustment, and lamp mode. (P95)

Image Modes

The image modes which can be selected vary somewhat depending on the
selected input signal.

Compatible input signals


Mode

Standard

Presenta­tion

Dynamic

Photo/sRGB

Digital PC

Analog PC-1 / 2

HDMI (when
[HDMI In] is
[Computer])

LAN

USB

Component

HDMI (when
[HDMI In] is
[Auto])

Explanation

Suitable for projecting a computer
screen or watching video in a
brightish room.
This image mode emphasizes white
tones.

Suitable for viewing text-based
images in a brightish room.

Suitable for watching video in a
brightish room.

Suitable for viewing images from
sRGB-compatible digital cameras
or Blu-ray videos in a moderately
dark room.
Compatible with the sRGB color
space.

Video

User 1 - 5

: Compatible : Not compatible

Suitable for watching video taken
with a video camera in a moderately
dark room.

Up to 5 user-selected combinations
of image quality settings can be
stored in the memory. (P96) Stored
settings can be selected as an
image mode.

68

Step 6 Select the Image Quality (Image Mode)

■ Selecting an Image Mode

Press the IMAGE button on the remote control to select.
The image mode changes each time the IMAGE button is pressed. (The displayed
image modes vary depending on the selected input signal.)

Remote control

You can also select any image mode from the [Image mode] menu. (P95)

• User settings 1 - 5 are displayed when the desired image settings have been
created and stored using the user memory function in the image adjustment
menu (P96).

Operation Projecting an Image

69

Step 7 Set Power-Saving Settings

Press the ECO button on the remote control to complete power-saving settings.
The following three settings are available.

•Lamp Settings

For changing lamp and fan power consumption in the current image mode.

• Auto Power-Off

A function for automatically turning the power off after a certain period if the
projector is not used and there is no input signal.

• Network Standby Settings

Specify whether network functions should be active in standby mode.

1 Press the ECO button to display the window shown below.

Remote control

2 Press the [ ] / [ ] buttons to select a menu.

Complete the setting for the selected function. For details, refer to the page
describing each function.

• Lamp Settings (P105)

• Auto Power-Off (P108)

• Network Standby Settings (P168)

70

Step 8 Turn the Projector Off

1 Press the POWER button to display the window shown below.

Remote control Projector

2 When this window is displayed, press the POWER button again to turn off

the power.

After you turn the power off, the projector will enter standby mode once it cools
down.

If you want to continue projecting without turning off the power, press a button other than
POWER, or else wait until the confirmation message disappears.

• After turning off the projector, wait at least 5 minutes before turning it on again. It may
shorten the lamp life if you turn on the projector immediately after turning it off.

• Using the projector for a long time may shorten the life of the lamp and internal optical
components.

• Unplug the projector if it will not be used for an extended period.

Operation Projecting an Image

71

72

Table of Contents

Safety Instructions

Useful Functions Available During a Presentation

Before Use

Projecting an Image

Operation

Useful Functions Available
During a Presentation

Setting Functions from
Menus

Installation and Maintenance

Installation

Connecting to a Network

Maintenance

73

Networked Multi-Projection

Networked Multi-Projection
Overview

Operation in Each Mode

Functions in All Modes

Appendix

Other Information

Index

Useful Presentation Functions

Temporarily Blacking Out an Image

Useful when:

• You have finished the presentation.

• You want to divert attendees’
attention from the screen.

Remote control

Press the BLANK button to black out
the image.
Press the BLANK button again to show
the image.

• You can set the screen state while blacking

out the image in the menu. (P107)

• The lamp remains illuminated while the

image is blacked out.

Freezing the Picture

Useful when:

• You want to perform a computer
operation which is irrelevant to the
proceedings of the presentation.

• You want to stop a moving image.

Remote control

Press the FREEZE button to freeze the
moving image. The projector shows the
following icon.

Screen

Press the FREEZE button again to
return to the original display.

• It is also cancelled when the input signal is

terminated.

74

Useful Presentation Functions

Adjusting the Volume

Useful when:

• You want to adjust the volume level of
the projector or external speakers.

Remote control

Press the VOL button. The following
screen appears.

• You can also adjust the volume level with

the [ ] / [ ] buttons of the projector.

• Adjust the volume or mute setting on the

computer if the volume level is too low.

• You can also adjust the volume level of the

speakers connected via the audio output
terminal.

Muting the Sound

Useful when:

• You want to temporality mute
unnecessary sound.

• You want to immediately mute the
sound.

Remote control

Operation Useful Functions Available During a Presentation

Press the MUTE button to mute the
sound. The projector shows the
following icon.

Screen

Press the

MUTE

button again to cancel the

mute function.

• You can also mute the sound of the

speakers connected via the audio output
terminal.

75

Useful Presentation Functions

Zooming an Image

Useful when:

• Zooming in on an object such as a
small graph during a presentation (up
to 12x).

• Focusing on the current subject.

Press the +D.ZOOM button to enlarge
a part of the image. Press the
–D.ZOOM button to reduce the image
size.

Remote control

You can move the enlarged area by
using the [ ] / [ ] / [ ] / [ ] buttons.

Remote control

Projector

Screen

You can restore the original size of the
image by pressing the OK button.

Screen

• The magnification appears on the screen.

76

Projecting Images on a USB Flash Drive

Images stored on a USB flash drive in the projector can be projected as follows.
You can select the images to project, or you can project images automatically, one
after another. JPEG images up to 7000x7000 can be projected.

• USB flash drives with security features are not recognized by the projector and cannot
be selected as the image source.

• If the projector cannot mount the file system, the drive name is grayed out and the
following icon is displayed. In this case, the USB flash drive cannot be used.

1 Insert the USB flash drive in the USB port.

Insert the USB flash drive directly into the projector’s USB port. The USB flash
drive will not be recognized if you connect it via a hub.

Operation Useful Functions Available During a Presentation

2 Press the INPUT button.

Remote control Projector

3 Press the INPUT button repeatedly to select [USB].

JPEG files on the USB flash drive are now listed.

• If the USB flash drive contains multiple partitions, a screen is displayed for you to select
the desired partition. Use the pointer buttons to select the partition, and then press the
OK button. Files on the partition are now listed.

• Enlargement with the D.ZOOM button and split-screen display are not available when
[USB] is selected as the input signal.

77

Projecting Images on a USB Flash Drive

4 Use the pointer buttons to select a file, and then press the OK button to

project the image.

Press the [ ] / [ ] buttons to select a file.
To view another page, press the [ ] / [ ] buttons (if other pages are available).
To navigate to a higher or lower folder, select a folder and press the OK button.

Motion blur reduction is not available when projecting JPEG files on a USB flash drive.
(P112)

Remote control Projector

5 Switch to other images as needed.

To switch to the previous image, press the [ ] button.
To switch to the next image, press the [ ] button.
To rotate images left 90°, press the [ ] button.
To rotate images right 90°, press the [ ] button.

6 After projection is finished, remove the USB flash drive.

The projector can also play a slideshow of images on a USB flash drive automatically.
(P92)

78

Split-Screen Display

Two input images can be projected side by side. This is split-screen display. When
you activate split-screen display, the current image is shown on the left side, and
the new image is shown at right. You can change the source of images shown on
each side by pressing the INPUT button. However, you cannot specify the same
input signal (terminal) as the source for both sides.

Network and USB input cannot be combined with other types of input for split-screen
display.

1 Supply two signals to the projector.
2 Press the SPLIT button on the remote control.

Remote control

• A number is displayed in the center of one image area. (1 applies to the left image and
2 to the right image.) The image labeled with a number has “control rights,” and the
sound for that image will be played. This is also the image with control rights if you
adjust [Image priority]. (P94)

• The number is no longer displayed after a little while, but you can view it again by
pressing the SPLIT button.

• To exit split-screen display, press the EXIT button.

• Split-screen display can also be accessed by selecting [Split screen] in the [Input
settings] menu. (P93)

• These functions cannot be adjusted in this mode: sharpness (P98), dynamic gamma
(P101), and motion blur reduction (P112).

• Some functions are not available, such as [Image flip H/V] (P143), [Screen aspect]
(P145), [Keystone] (P146), and [Logo capture] (P106).

• Image mode colors differ somewhat from those in single-image mode.

Operation Useful Functions Available During a Presentation

3

If or is displayed in the center of the image area, you can switch control
to the other side by pressing the [ ] / [ ] buttons on the remote control.

(Example of display in split-screen mode.)

79

Split-Screen Display

4 Press the INPUT button to select the input signal for the side with control

rights.

The [Input] menu is displayed. To determine which side is currently under
control, check the screen ID in orange in the upper right of the menu. The side
without control rights is labeled with a white circle.
For details on selecting input signals, refer to “Selecting an Input Signal” (P52).

Side currently under

control (input signal can

be switched)

To exit split-screen display, press the EXIT button on the remote control.

Current input signal of side
with control rights

Current input signal of side
without control rights

80

Table of Contents

Safety Instructions

Setting Functions from Menus

Before Use

Projecting an Image

Operation

Useful Functions Available
During a Presentation

Setting Functions from
Menus

Installation and Maintenance

Installation

Connecting to a Network

Maintenance

81

Networked Multi-Projection

Networked Multi-Projection
Overview

Operation in Each Mode

Functions in All Modes

Appendix

Other Information

Index

Using Menus

Use the menus to set the operation of the projector in detail.

Menu Configuration

The menu screen is divided into 6 tabs as shown below.

[Install settings] tab

This setting is used when installing
the projector.

[Image adjustment] tab

You can adjust the image quality
and colors according to your
preference.

[Input settings] tab

You can set the type of signal
or the method of projection of
the images input.

[System settings] tab

You can set the operation of the
projector.

[Network settings] tab

These settings are for when using
the projector from a PC via a
network.
For the network settings, refer to
“Connecting to a Network” (P163).

[Information] tab

You can check information
about the signal types of the
images projected and other
information.

Contents of menu

Menu items

Input Signal Types for which a Menu Item is Displayed

Different menu items are displayed for different input signal types.
In the following explanation of each menu item, the input signal type for which
the menu item is displayed is indicated as follows:

Input signal for which the
menu item is displayed
Input signal for which the
menu item is not displayed

HDMI Component LAN
Digital PC Analog PC USB

82

Basic Menu Operations

1 Press the MENU button to display the menu window.

Remote control Projector

Using Menus

2 Press the [ ] / [ ] buttons to select a tab.

Remote control Projector

• If the tab position is not highlighted in orange, press the [ ] / [ ] buttons to
move the current selection to the top.

3 Press the [ ] / [ ] buttons to select an item.

Remote control Projector

Operation Setting Functions from Menus

4 Select contents.

How to select the contents varies depending on the item.

Selecting from a list Example: Aspect (P85)

1. Select [Aspect].

2. Press the OK button or [ ] button
to display a list of the contents.

3. Use the [ ] / [ ] buttons to select
the desired contents.

4. When you have found the
contents you desired, press the
OK button or [ ].

83

Using Menus

Adjusting with the [ ] / [ ] buttons Example: Contrast (P97)

1. Select [Contrast].

2. Use the [ ] / [ ] buttons to adjust
the setting.

Selecting from a different screen (1) Example: Menu position (P150)

1. Select [Menu position].

2. Press the OK button to display a
different screen.

3. Then follow the instruction on the
screen.

Selecting from a different screen (2) Example: Tracking (P87)

1. Select [Input signal settings].

2. Press the OK button to display a different screen.

3. Select [Tracking].

4. Use the [ ] / [ ] buttons to select the setting, then use the [ ] / [ ] buttons
to select the value.

5. When you have completed the settings, press the OK button.

5 Pressing the MENU button causes the menu screen to disappear.

The menu screen will also disappear if the EXIT button is pressed.

84

Setting Display Status (Input Settings)

Selecting the Aspect

> [Input settings] > [Aspect]

HDMI Component LAN
Digital PC Analog PC USB

You can select a projection mode
corresponding to the aspect ratio of
the image. (P63)

• For LAN and USB input, [Auto] is selected
automatically.

• Different contents are displayed for different
screen aspects or input signal types.

• The ASPECT button on the remote control
can also be used to select the [Aspect]
settings.

Auto An image is projected at the aspect

ratio of the input signal. Select this
mode for normal image projection.

16:10 The image is projected using an

input signal aspect ratio of 16:10.

• There may be some cases when
this cannot be selected,
depending on the input signal
and/or resolution.

16:9 The image is projected using an

input signal aspect ratio of 16:9.
Select this if an image of 16:9
aspect ratio cannot be correctly
projected in [Auto] mode.

4:3

Zoom This cuts the upper/lower or left/

True
size

The image is projected using an
input signal aspect ratio of 4:3.
Select this if an image of 4:3 aspect
ratio cannot be correctly projected in
[Auto] mode.

right part of the screen according to
the screen aspect and zooms in or
out of the center of the image.
Select this if a letter box is
displayed (black lines at the top/
bottom of the screen) when
watching video.

• There may be some cases when
this cannot be selected,
depending on the input signal
and/or resolution.

The image is projected with the
original resolution of the input
signal. Select this for clear
projection of computer screens at
up to WUXGA (WUX450) or
WXGA+ (WX520) resolution.

• There may be some cases when
this cannot be selected,
depending on the input signal
and/or resolution.

Operation Setting Functions from Menus

Press the OK button to accept your
setting and then press the MENU
button or EXIT button.

85

Setting Display Status (Input Settings)

Setup Using Auto PC

> [Input settings] > [Auto PC]

HDMI Component LAN
Digital PC Analog PC USB

Automatically adjusts display
position misalignment and screen
flickering. The adjusted result is
stored in the memory.

Press the OK button to accept your
setting.

If the Auto PC adjustment is
insufficient, perform the following
operations.

• Select the input signal that matches
the resolution of the computer from
[Input signal select]. (P86)

• If adjustment is insufficient even
when using the above operation,
adjust [Total dots], [Tracking],
[Horizontal/Vertical position] and
[Horizontal/Vertical pixels] in [Input
signal settings]. (P87 - P89)

• For the signal types supported by
the projector, see the table on page

288.

Selecting an Input Signal

> [Input settings] > [Input signal

select]

HDMI Component LAN
Digital PC Analog PC USB

You can select a suitable resolution
if the auto PC adjustment function
(P55) cannot project the correct
image from a computer.

Press the OK button to accept your
setting and then press the MENU
button or EXIT button.
Select an input signal corresponding to
the resolution of the computer.

• For the signal types supported by the
projector, see the table on page 288.

86

Setting Display Status (Input Settings)

Adjusting the Input
Signal

(Total dots)

> [Input settings] > [Input signal

settings] >

HDMI Component LAN
Digital PC Analog PC USB

You can adjust the total number of
dots in the horizontal direction.
Adjust it when stripes are displayed
on the screen.

Use the [ ] / [ ] buttons to select a
value.
When you have completed the
adjustment, press the OK button to
accept your setting and then press the
MENU button or EXIT button.

• Perform this adjustment if the Auto PC
function (P55) cannot adjust the projected
image correctly.

[Total dots]

Adjusting the Input
Signal

(Tracking)

> [Input settings] > [Input signal

settings] >

HDMI Component LAN
Digital PC Analog PC USB

You can fine-tune the timing for
generating an image from the image
signal.
Adjusts the tracking when the image
distorts or flickers.

Use the [ ] / [ ] buttons to select a
value.
When you have completed the
adjustment, press the OK button to
accept your setting and then press the
MENU button or EXIT button.

• Perform this adjustment if the Auto PC
function (P55) cannot adjust the projected
image correctly.

[Tracking]

Operation Setting Functions from Menus

87

Setting Display Status (Input Settings)

Adjusting the Input
Signal

(Horizontal position)

> [Input settings] > [Input signal

settings] >

HDMI Component LAN
Digital PC Analog PC USB

You can adjust the horizontal
position of the screen when the
projected image is shifted in the
horizontal direction.

Use the [ ] / [ ] buttons to select a
value. As the value increases, the
screen moves to the left.

[Horizontal position]

Adjusting the Input
Signal

(Vertical Position)

> [Input settings] > [Input signal

settings] >

HDMI Component LAN
Digital PC Analog PC USB

You can adjust the vertical position
of the screen when the projected
image is shifted in the vertical
direction.

Use the [ ] / [ ] buttons to select a
value. As the value increases, the
screen moves upward.

[Vertical position]

Screen

When you have completed the
adjustment, press the OK button to
accept your setting and then press the
MENU button or EXIT button.

• Perform this adjustment if the Auto PC
function (P55) cannot adjust the projected
image correctly.

Screen

When you have completed the
adjustment, press the OK button to
accept your setting and then press the
MENU button or EXIT button.

• Perform this adjustment if the Auto PC
function (P55) cannot adjust the projected
image correctly.

88

Setting Display Status (Input Settings)

Adjusting the Input
Signal

(Horizontal pixels)

> [Input settings] > [Input signal

settings] >

HDMI Component LAN
Digital PC Analog PC USB

You can adjust the number of the
pixels in the horizontal direction if
the length of the screen is too long
or too short in the horizontal
direction.

Use the [ ] / [ ] buttons to select a
value.

[Horizontal pixels]

Adjusting the Input
Signal

(Vertical pixels)

> [Input settings] > [Input signal

settings] >

HDMI Component LAN
Digital PC Analog PC USB

You can adjust the number of the
pixels in the vertical direction if the
screen is too long or too short in the
vertical direction.

Use the [ ] / [ ] buttons to select a
value.

[Vertical pixels]

Operation Setting Functions from Menus

Screen

When you have completed the
adjustment, press the OK button to
accept your setting and then press the
MENU button or EXIT button.

• Perform this adjustment if the Auto PC
function (P55) cannot adjust the projected
image correctly.

Screen

When you have completed the
adjustment, press the OK button to
accept your setting and then press the
MENU button or EXIT button.

• Perform this adjustment if the Auto PC
function (P55) cannot adjust the projected
image correctly.

89

Setting Display Status (Input Settings)

Adjusting HDMI Input Level

> [Input settings] > [HDMI input level]

HDMI Component LAN
Digital PC Analog PC USB

You can select this as required when
you project visual software using an
HDMI signal.

Press the OK button to accept your
setting and then press the MENU
button or EXIT button.

• [Auto] is the factory default.

• You can select this only when the type of
signal sent from AV equipment is RGB.

• The signal level is selected automatically in
[Auto] mode. (Some AV equipment may not
support this.)

• If the HDMI output of your AV equipment
allows switching between [Normal] and
[Expanded], we recommend you to set
[Expanded]. The contrast of images will be
improved and dark scenes will be rendered
more realistically. In this case, select [Auto]
or [Expanded] for [HDMI input level].
For more detailed information, refer to the
user’s manual for the AV equipment
connected to the projector.

Setting the HDMI Color Format

> [Input settings] > [HDMI color

space]

HDMI Component LAN
Digital PC Analog PC USB

Select the color space for the HDMI
signal.

Auto Selects the optimal color format for

the input HDMI signal.

RGB Forces the projector to handle the

input signal as an RGB signal.

YCbCr Forces the projector to handle the

input signal as a color difference
signal.

Press the OK button to accept your
setting and then press the MENU
button or EXIT button.

• [Auto] is the factory default.

90

Setting Display Status (Input Settings)

Specifying HDMI Overscan

> [Input settings] > [HDMI over scan]

HDMI Component LAN
Digital PC Analog PC USB

When projecting images in videos
via HDMI, select this setting to trim
distorted image edges.

Off The entire input signal (100%) is

projected.
The images projected may be smaller
than the full projection screen.

On Images are projected with distortion at

the peripheral section of images
trimmed off. (The central 95% of the
image is projected.)
Note that image edges are trimmed
away, based on resolution. In such a
case, select [Off].

Press the OK button to accept your
setting and then press the MENU
button or EXIT button.

• The factory defaults settings are [On] when
[HDMI In] (P113) is set for [Auto] and [Off]
when it is set for [Computer].

Specifying Progressive Processing

> [Input settings] > [Progressive]

HDMI Component LAN
Digital PC Analog PC USB

Performs progressive processing
optimized for still images in
cinematic content or moving images
in videos.

Off

Film/auto Suitable for still images or

Video 1 Suitable for projecting video

Video 2 Suitable for projecting video

25p/
30p(PsF)

Does not perform progressive
processing.

typical moving images.
Performs progressive
processing for video or
cinematic content.

with high image quality and
relatively slow movement.
Performs progressive
processing optimized for HD
video.

with faster movement.
Performs progressive
processing optimized for fast­moving video.

Performs progressive
processing optimized for 1080
PsF/25 or 1080PsF/30 video
(25 or 30 fps, respectively).

Operation Setting Functions from Menus

Press the OK button to accept your
setting and then press the MENU
button or EXIT button.

91

Setting Display Status (Input Settings)

• [Film/auto] is the factory default.

• Select [Off] when flickers and horizontal
lines are noticeable in media that has a lot
of fast-moving action.

• Not available during split-screen display.

Specifying the Slideshow Interval

> [Input settings] > [Slideshow

Interval]

HDMI Component LAN
Digital PC Analog PC USB

You can project images on a USB
flash drive automatically, one after
another.

Use the [ ] / [ ] buttons to select the
interval for switching images
(min.:sec.).

Press the MENU button or EXIT button.

• The factory default is [--:--], which does not
switch images automatically.

92

Setting Display Status (Input Settings)

Specifying Split­Screen Display

> [Input settings] > [Split screen]

HDMI Component LAN
Digital PC Analog PC USB

You can project two input images
side by side. (P79)

Off Exit split-screen mode.

On Activates split-screen mode.

• [Off] is the factory default.

•The SPLIT button on the remote control can
also be used to select the [Split screen]
settings.

• If or is displayed in the center of the
image area, switch control to the other side
by pressing the [ ] / [ ] buttons on the
remote control.

• When you switch to split-screen display, a
dialog box indicates the left and right
signals and input status.

Operation Setting Functions from Menus

Settings

Split
screen

Control
rights

Off Specify whether to

use split-screen

On

Left
screen

Right
screen

display.

Select the image to
control.

Press the OK button to accept your
setting and then press the MENU
button or EXIT button. The image under
your control is labeled with a split­screen icon.

93

Adjusting Image Quality (Image Adjustment)

Specifying Image Priority in Split-Screen Mode

> [Image adjustment] > [Image

priority]

HDMI Component LAN
Digital PC Analog PC USB

Some image processing in split­screen mode is applied to both
sides. Here, select which side to use
as the primary side, which will be the
basis for secondary-side
processing.

Can be independently configured

Brightness (P97), Contrast (P97),
Gamma (P98), Color adjustment (P99),
Fine-Tune Gamma (P103)

[Primary] setting also applies to
[Secondary]

Image Mode (P95), Advanced adjustment
(except Fine-Tune Gamma) (P100-P104),
Lamp mode (P105)

Primary Selecting [Primary] will prevent

you from reverting to
[Secondary]. Switch control to
the other side, and then select
[Primary] again.

Secondary

Press the OK button to accept your
setting and then press the MENU
button or EXIT button.

Some image adjustment settings in
split-screen mode apply to the left and
right sides independently. For others,
the setting for the [Primary] side is also
applied to the [Secondary] side.

Sets the current side (with
control rights) as the secondary
side.

94

Adjusting Image Quality (Image Adjustment)

Specifying the Image Mode

> [Image adjustment] > [Image mode]

HDMI Component LAN
Digital PC Analog PC USB

You can select an image mode (P68)
suitable for the projected image.
You can also select it with the IMAGE
button on the remote control. (P69)

Standard Suitable for projecting a

computer screen or watching
video in a brightish room.
This image mode emphasizes
white tones.

Presenta­tion

Dynamic Suitable for watching video in

Video Suitable for watching video

Photo/
sRGB

User 1–5 Up to 5 user-selected

Suitable for viewing text-based
images in a brightish room.

a brightish room.

taken with a video camera in a
moderately dark room.

Suitable for projecting images
taken with a digital camera
that supports sRGB in a
moderately dark room.
Compatible with the sRGB
color space.

combinations of image quality
settings can be stored in the
memory. (P96) Stored settings
can be selected as an image
mode.

• [Standard] is the factory default for Analog
PC-1 or 2, Digital PC, or HDMI (when
[HDMI In] is [Computer]), LAN or USB, and
[Photo/sRGB] is the default for HDMI (when
[HDMI In] is [Auto]) or Component.

• You can adjust the image quality by
adjusting the following items in each image
mode:
[Brightness], [Contrast], [Sharpness],
[Gamma], [Color adjustment], [Advanced
adjustment] and [Lamp mode]

• The adjustment you have made is stored as
each combination of input signals and an
image mode.

• When a user memory that was saved in
[Create profile] is selected, [Baseline image
mode] appears in the menu. This indicates
the image mode that was the base when
the user memory was saved.

Operation Setting Functions from Menus

Press the OK button to accept your
setting and then press the MENU
button or EXIT button.

95

Adjusting Image Quality (Image Adjustment)

Creating/Saving a User Profile

> [Image adjustment] > [Create

profile]

HDMI Component LAN
Digital PC Analog PC USB

Up to 5 combinations of image
quality settings can be stored. The
stored image quality can be selected
as an image mode.

• The number of displayed user memories is
5, however it is possible to save different
settings for when the connected equipment
is a computer (ANALOG PC, DIGITAL PC
or HDMI (when [HDMI In] (P113) is
[Computer]) and when AV equipment is
connected (COMPONENT, HDMI (when
[HDMI In] (P113) is [Auto])). As a result, it is
possible to save up to 10 settings.

• The image mode name which was the basis
for the settings change is also saved in the
user memory. When a user memory is
selected as the image mode, the image
mode that was the base for that user
memory is displayed in the menu as
[Baseline image mode].

Use the [ ] / [ ] buttons and select the
save destination. (Saved memories are
indicated by checkmarks.)

When the desired save destination is
selected, press the OK button to accept
your setting and then press [Return].

• The saved settings consist of the
brightness, contrast, sharpness, gamma,
color adjustment, advanced adjustment,
and lamp mode.

96

Adjusting Image Quality (Image Adjustment)

Adjusting Brightness

> [Image adjustment] > [Brightness]

HDMI Component LAN
Digital PC Analog PC USB

You can adjust the brightness of
images.

[ ] Increases the brightness of an

image.

[ ] Decreases the brightness of an

image.

When you have completed the
adjustment, press the MENU or EXIT
button.

• The adjustments you have made are stored
as adjusted values for the input signals and
image mode of the current projection.

Adjusting Contrast

> [Image adjustment] > [Contrast]

HDMI Component LAN
Digital PC Analog PC USB

You can adjust the contrast of
images.
Adjust the difference between the
light and dark parts of the image to
produce an image with emphasized
contrast or an image that is soft.

Operation Setting Functions from Menus

[ ] Increases the contrast of an image.

This emphasizes the darker and
brighter parts of the image on the
projected image.

[ ] Decreases the contrast of an image.

The image becomes less vivid.

When you have completed the
adjustment, press the MENU or EXIT
button.

• The adjustments you have made are stored
as adjusted values for the input signals and
image mode of the current projection.

97

Adjusting Image Quality (Image Adjustment)

Adjusting Sharpness

> [Image adjustment] > [Sharpness]

HDMI Component LAN
Digital PC Analog PC USB

You can adjust the sharpness of
images.

[ ] Increases the sharpness of an

image.

[ ] Decreases the sharpness of an

image.

When you have completed the
adjustment, press the MENU or EXIT
button.

• The adjustments you have made are stored
as adjusted values for the input signals and
image mode of the current projection.

Correcting Gamma

> [Image adjustment] > [Gamma]

HDMI Component LAN
Digital PC Analog PC USB

You can correct portions of an image
that are difficult to see because they
are too dark or bright.
Gamma can be corrected using the
GAMMA button on the remote
control.

[ ] Brightens the dark portion.

[ ] Darkens the bright portion.

When you have completed the
adjustment, press the MENU or EXIT
button.

• The adjustments you have made are stored
as adjusted values for the input signals and
image mode of the current projection.

• More detailed adjustment is possible by
using the detailed gamma correction
(P103).

98

Adjusting Image Quality (Image Adjustment)

Adjusting Colors

> [Image adjustment] > [Color

adjustment]

HDMI Component LAN
Digital PC Analog PC USB

You can adjust the color depth and
hue of images for each primary
color, red, green and blue. The color
temperature can also be adjusted.

Color level Adjusts the intensity of colors.

[ ] Increases the intensity of

color.

[ ] Decreases the intensity of

color.

Color
balance

Color
temperature

R / G / B
Gain

R / G / B
Offset

Adjusts the color balance of a
purplish or greenish image.
[ ] Corrects a purplish image.
[ ] Corrects a greenish

image.
Adjusts the color temperature
of the image.
[ ] Changes to a bluish color

(cold color).
[ ] Changes to a reddish

color (warm color).
Adjusts the intensity of each
color.
[ ] Increases the color

intensity.
[ ] Decreases the color

intensity.
Adjusts the color
reproducibility of dark portions
of each color.
[ ] Increases the color

reproducibility.
[ ] Decreases the color

reproducibility.

When you have completed the
adjustment, press the MENU or EXIT
button.

• The adjustments you have made are stored
as adjusted values for the input signals and
image mode of the current projection.

Operation Setting Functions from Menus

99

Adjusting Image Quality (Image Adjustment)

Adjusting to the
Ambient Light

(Ambient Light)

> [Image adjustment] > [Advanced

adjustment] >

HDMI Component LAN
Digital PC Analog PC USB

You can correct and more effectively
project an image according to the
ambient light on the screen.
The [Ambient light] setting is
available in Photo/sRGB image
mode (P95).

[Ambient light]

Examples of Ambient Light Level
Settings

Level Example Location

L Projection room, sports bar, etc.

H Conference room, lecture room

Press the OK button to accept your
setting and then press the MENU
button or EXIT button.

• [Off] is the factory default.

Off Projects an image with no

correction.

Adjust You can specify the type and

level (brightness) of the ambient
light.

Type Tungsten

Select this if the ambient
light source is a light bulb
or bulb color fluorescent.

Fluorescent

Select this if the ambient
light source is a day white
fluorescent.

Level L Select this if the ambient

light is normal.

H Select this if the ambient

light is high (bright).

100
