Page 1
PHOTO PRINTER
User’s Guide
V1
Page 2
Table of Contents
Table of Contents
Introduction .....................................................................................................5
How to Use This Manual .................................................................................6
Safety Precautions .........................................................................................8
Printer Parts and Their Functions .................................................................14
Front View ...................................................................................................15
Rear View ....................................................................................................16
Inside the Printer .........................................................................................17
Operation Panel ..........................................................................................18
Printer Driver Functions (Windows) ..............................................................19
Opening the Printer Properties Dialog Box .................................................20
Printer Properties Dialog Box Description ...................................................22
BJ Status Monitor Functions .......................................................................36
Cancelling a Print Job .................................................................................39
Uninstalling Printer Drivers ..........................................................................40
2
Page 3
Table of Contents
Printer Driver Functions (Macintosh) ............................................................41
Description of Print Settings ........................................................................42
BJ Print Monitor ...........................................................................................59
Cancelling a Print Job .................................................................................61
Using the Printer with a Network .................................................................62
Uninstalling Printer Drivers ..........................................................................66
Routine Maintenance ....................................................................................67
When to Replace Ink Tank and Maintain Printhead ....................................68
Replacing an Ink Tank .................................................................................69
Printing the Nozzle Check Pattern ..............................................................74
Printhead Cleaning ......................................................................................78
Printhead Deep Cleaning ............................................................................81
Cleaning the Printer .....................................................................................83
Transporting the Printer ...............................................................................85
Printing Media ...............................................................................................89
Compatible Media Types .............................................................................90
Envelopes ....................................................................................................92
High Resolution Paper ................................................................................96
Glossy Photo Paper ....................................................................................98
High Gloss Photo Film ...............................................................................100
Glossy Photo Cards ..................................................................................102
Photo Paper Pro ........................................................................................104
Photo Paper Pro (Borderless) ...................................................................107
Transparencies ..........................................................................................109
T-Shirt Transfers .......................................................................................111
Banner Paper ............................................................................................113
3
Page 4
Table of Contents
Troubleshooting ..........................................................................................116
Cannot Install the Printer Driver ................................................................117
Print Quality is Poor or Contains Errors ....................................................119
Printer Does Not Start or Stops During Print Jobs ....................................136
Paper Does Not Feed Properly or Paper Jams .........................................142
The POWER Lamp Flashes Orange .........................................................145
An Error Message is Displayed on the Screen ..........................................148
Problems Unique to Windows ...................................................................157
Problems Unique to the Macintosh ...........................................................162
Appendices .................................................................................................165
For Faster Printing ....................................................................................166
Specifications .............................................................................................169
Index ...........................................................................................................181
4
Page 5
Introduction
Introduction
Thank you for purchasing the Canon S820 Photo Printer. This User’s Guide provides
complete explanations of the features and functions of the printer.
This guide uses the following symbols to indicate important information. Always observe
these instructions.
Warning
Caution
Important
Windows
Macintosh
➤
Instructions that, if ignored, could result in death or serious personal injury
caused by incorrect operation of the equipment.
Must be observed for safe operation.
Instructions that, if ignored, could result in personal injury or material
➤
damage caused by incorrect operation of the equipment.
Must be observed for safe operation.
➤
Prohibited actions that, inadvertently performed, could result in equipment
damage, faults or impaired product quality.
Must be avoided for correct operation.
Information for Windows users only.
Information for Macintosh (USB users only).
5
Page 6
How to Use This Manual
How to Use This Manual
To view this User’s Guide, we recommend that you use Acrobat Reader 3.0 or later. The
screens shown below are for Acrobat Reader 4.0. Please note that screens displayed by
Acrobat Reader 3.0 or 5.0 are slightly different.
Use this button to enlarge the viewing
screen. Select this button in the tool bar
and click within the screen.
Displays the previous page.
Displays the next page.
Returns to the page
you were viewing
previously.
Click to jump straight to
this page.
6
Page 7
How to Use This Manual
Use this button to
search for a word.
Displays the table of contents.
Click the heading to jump to the topic.
Click the " " symbol to see the headings for each chapter.
Click the " " symbol to close the headings.
7
Page 8
Safety Precautions
Safety Precautions
Please read the safety warnings and cautions provided in this manual to ensure that you
use the printer safely. Do not attempt to use the printer in any way not described in this
manual.
Warning
■
Choosing a location
Do not place the printer close to flammable solvents, such as alcohol or thinners.
■
Power supply
Never attempt to plug in or unplug the printer from the power supply when your hands
are wet.
Always push the plug all the way into the power outlet.
Never damage, modify, stretch or excessively bend or twist the
power cord. Do not place heavy objects on the power cord.
You may cause an electric shock/fire or damage the printer if you ignore
➤
any of these safety precautions.
8
Page 9
Safety Precautions
Never plug the printer into a power socket (extension cord, double
adapter, etc.) that powers multiple devices.
Never use the printer if the power cord is bundled or knotted.
If you detect smoke, unusual smells or strange noises around the printer, immediately
unplug the printer at the power supply and call the Canon Customer Care Center.
Periodically, unplug the printer and use a dry cloth to wipe off any dust or dirt collected
on the plug and the power outlet. If the printer is placed at a location exposed to a lot of
dust, smoke, or high humidity, the dust that collects on the plug absorbs moisture and
may cause insulation failure and fire.
■
Cleaning the printer
Use a damp cloth to clean the printer. Never use flammable
solvents, such as alcohol, benzene or thinners.
If flammable solvents come in contact with electrical components inside the printer,
it could cause a fire or electric shock.
Always unplug the printer from the power outlet before cleaning the printer.
If you accidentally switch the printer on while cleaning it, you could injure yourself or damage the printer.
9
Page 10
Safety Precautions
■
Maintaining the printer
Do not attempt to disassemble or modify the printer. There are no user serviceable parts
inside the printer.
The printer contains high-voltage components. Ne ver attempt an y maintenance procedure not described in
this guide.
■
Working around the printer
Do not use inflammable sprays near the printer.
This could cause a fire or electric shock if the spray comes into contact with electrical components inside
the printer.
10
Page 11
Safety Precautions
Caution
■
Choosing a location
Do not install the printer in a location that is unstable or subject to excessive vibration.
Do not install the printer in locations that are very humid or dusty, in direct sunlight,
outdoors, or close to a heating source.
To av oid the risk of fire or electric shocks, install the printer in a location with an ambient temperature range
of 41°F to 95°F (5°C to 35°C) and humidity of 10% to 90% (condensation free).
Do not place the printer on a thick rug or carpet.
Ensure that the area around the power outlet is kept clear at all times
so you can easily unplug the power cord if necessary.
➤
You may cause injury or damage the printer if you ignore any of these
safety precautions.
When moving the printer, carry the printer at both ends.
11
Page 12
Safety Precautions
■
Power supply
Never remove the plug by pulling on the cord.
Do not use a powerstrip.
Never use a power supply voltage other than that supplied in the country of purchase.
The correct power supply voltages and frequencies are as follows:
USA/Canada: AC 120V, 60Hz
Europe: AC 230V ± 10%, 50Hz
Australia: AC 240V, 50Hz
12
Page 13
Safety Precautions
■
Working around the printer
Never put your hands or fingers in the printer while it is printing.
Do not place metal objects (paper clips, staples, etc.) or containers of flammable
solvents (alcohol, thinners. etc.) on top of the printer.
If any foreign object (metal or liquid) falls into the printer, unplug the power cord and call
the Canon Customer Care Center.
■
Printheads and ink tanks
For safety reasons store printheads and ink tanks out of the reach of small children.
If a child ingests any ink, consult a doctor immediately.
Do not shake printheads or ink tanks.
Ink may leak out and stain clothing or the surrounding area.
Never touch the electrical contacts on a printhead after printing.
The metal parts may be very hot and could cause burns.
13
Page 14
Printer Parts and Their Functions
Printer Parts and Their Functions
• Front View
• Rear View
• Inside the Printer
• Operation Panel
14
Page 15
Front View
Printer Parts and Their Functions
Operation Panel
For details, refer to
"Operation Panel."
Paper Output Tray
Paper Guide
When loading paper, ensure
that the left edge just
touches this guide.
To move the paper guide,
pinch the knob and slide in
the appropriate direction.
Paper Rest
Sheet Feeder
Load paper here.
Paper feeds
automatically, one sheet
at a time.
Front Cover
Open to replace the
ink tanks or remove
jammed paper.
Front View
15
Page 16
Rear View
Printer Parts and Their Functions
USB Port
Used to connect the printer to a
computer through a USB interface.
Printer Port (Parallel)
Used to connect the printer to a
computer through a parallel interface.
Rear View
16
Page 17
Inside the Printer
Paper Thickness Lever
Adjusts the gap between the printhead and the surface of the printing paper.
Printer Parts and Their Functions
Printhead Holder
Install the printhead here.
Printhead Lock Lever
Locks the printhead into the holder.
Once the printhead is installed, do not touch this lever.
Inside the Printer
17
Page 18
Operation Panel
POWER Button
Press to turn the printer
on or off.
Printer Parts and Their Functions
RESUME/CANCEL Button
Press to resume printing once an error has
been cleared. The printer will then initialize
ready for printing.
Also, to cancel printing in progress, press
this button.
POWER Lamp
Off: The printer is turned off.
Green: The printer is ready to print.
Flashing green: The printer is preparing to print, or is currently printing.
Flashing orange: An error has occurred and the printer is not ready to print.
Flashing orange and green alternately: An error has occurred that may require a call to
the Canon Customer Care Center.
Operation Panel
18
Page 19
Printer Driver Functions (Windows)
Printer Driver Functions (Windows)
• Opening the Printer Properties Dialog Box
• Printer Properties Dialog Box Description
• BJ Status Monitor Functions
• Cancelling a Print Job
• Uninstalling Printer Drivers
19
Page 20
Printer Driver Functions (Windows)
Opening the Printer Properties Dialog Box
The Printer Properties dialog box can be opened from either within an application, or
directly from the Windows
■
Opening the Printer Properties dialog box from an application
This method is generally used to specify printer settings just before printing.
The operations may vary slightly depending on the application. This section describes
only the general procedure for opening the Printer Properties dialog box.
1
In an application, select the command to print a document.
The
Print
File
menu.
Start
menu.
dialog box can usually be opened by selecting
Print
from the
Note
Ensure that
2
Properties
The Printer Properties dialog box opens.
➤
Depending on the application, the command and menu names may differ,
and there may be more steps involved in opening the Printer Properties
dialog box. For further details, see the user's manual for the application.
Canon S820
button.
is selected in the
Opening the Printer Properties Dialog Box
Name
field. Then click the
20
Page 21
Printer Driver Functions (Windows)
■
Opening the Printer Properties dialog box directly from the Start menu
This method is used for maintenance operations, such as printhead cleaning, or to
specify printer settings common to all application programs.
When the Printer Properties dialog box is opened from the
operating system adds several tabs, including the
when the Printer Properties dialog box is opened from within an application.
For further information about these additional tabs, refer to your Windows
documentation.
Details
Start
menu, the Windows
tab. These do not appear
Click the
1
For Windows XP, click
Other Hardware - Printers and Faxes
Select the
2
Open the
3
• Windows Me/Windows 98 ➔
• Windows XP/Windows 2000 ➔
The Printer Properties dialog box opens.
Start
button, then select
Canon S820
File
menu and select:
Start
icon.
and select
Settings, Printers
Control Panel
.
Properties
Printing Preferences...
Opening the Printer Properties Dialog Box
.
-
Printers and
21
Page 22
Printer Driver Functions (Windows)
Printer Properties Dialog Box Description
• Main Tab
• Page Setup Tab
• Stamp/Background
• Effects Tab
• Profiles Tab
• Maintenance Tab
Tab
Note
➤
The screens in this section refer to Windows Me/Windows 98 operation.
The equivalent screens for Windows XP and Windows 2000 may look
slightly different.
Printer Properties Dialog Box Description
22
Page 23
Main T ab
(6)
(5)
Printer Driver Functions (Windows)
(1)
(2)
(3)
(4)
(1)
Media T ype
Ensure that this setting matches the type of media loaded in the printer.
(2) Print Quality
Select the print quality you require from among the different options. To select custom
Print quality, select Custom and click the Set... button.
Printer Properties Dialog Box Description
23
Page 24
Printer Driver Functions (Windows)
(3) Color Adjustment
Select the method of color adjustment. To make detailed color adjustments, select
Manual, then click the Set... button.
(4) Grayscale Printing
Select to print a grayscale version of a color document.
(5) Print Advisor...
Click to start the Print Advisor.
The Print Advisor simplifies configuration of the printer driver. By having the user
answer a series of questions, the Printer Advisor automatically configures the printer
driver settings.
(6) Preview Area
Before printing, verify that settings, such as the lever position, are correct.
Note
➤
To see a description of any item in the Printer Properties dialog box, click
the ? mark then click the desired item. To see a description of operating
procedures, click the Help button. If the button does not appear when using
Windows XP or Windows 2000, click the Start button then select
Programs - Canon S820 - Guide.
Printer Properties Dialog Box Description
24
Page 25
Page Setup Tab
(9)
Printer Driver Functions (Windows)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(1) Page Size
Ensure that the correct paper size is selected.
(2) Orientation
Select landscape or portrait printing and ensure that it is the same orientation used in
the application.
Printer Properties Dialog Box Description
25
Page 26
(3) Printing Type
Select the printing method from among the following.
Normal-size Printing The document is printed according to the original
dimensions. This setting is usually selected by default.
Fit-to-Page Printing The document is automatically resized to fit the paper size.
When using this function, ensure that you have correctly
specified the Page Size and the Printer Paper Size.
Scaled Printing The document is resized when printed. When this is
selected, you can specify the Printer Paper Size and
Scaling.
Page Layout Printing Pages are reduced and printed so that 2 to 16 document
pages fit on each printed page.
Booklet Printing The multiple-page document is printed so that two pages of
the document fit on each printed page. The print order is set
automatically. After the document is printed, you can create
a booklet by folding and saddle-stitching the document.
Poster Printing This enlarges and splits the print image across several
sheets of paper. The printed sheets can then be assembled
to make a large poster.
Banner Printing Select this when printing on banner paper.
Printer Driver Functions (Windows)
(4) Borderless Printing
The image is printed on the entire paper surface, so that no margins are left on the
four sides of the paper.
The media types availab le for Borderless Printing are Photo Paper Pro and
Glossy Photo Paper.
For all other media types, the print quality ma y decrease .
Printer Properties Dialog Box Description
26
Page 27
Printer Driver Functions (Windows)
(5) Amount of Extension
When you select Borderless Printing, the sections that extend beyond the paper are
not printed because the image is enlarged to a size slightly larger than the paper size.
You can use the Amount of Extension slide bar to adjust how much the image
extends beyond the paper.
It is recommended that you normally set the slide bar to the right end.
If you move the slide bar to the left to reduce the extension amount, a border may
appear.
(6) Duplex Printing
The document is printed on both sides of the paper. After printing one side, turn the
ejected page over, and print on the other side.
(7) Reverse Order
When selected, the document starts printing with the last page.
(8) Collate
Select to print multiple copies of the document one copy at a time.
(9) Preview Area
Verify the overall layout, stamps, background, etc., to be applied to the print job.
Printer Properties Dialog Box Description
27
Page 28
Stamp/Background T ab
(8)
Printer Driver Functions (Windows)
(1)
(4)
(2)
(3)
(5)
(7)
(6)
(1) Stamp
Select the check box and choose the stamp.
(2) Place stamp over text
When selected, the stamp is printed over the print data.
(3) Stamp first page only
Prints the stamp only on the first page.
Printer Properties Dialog Box Description
28
Page 29
Printer Driver Functions (Windows)
(4) Define Stamp...
This allows you to create new stamps, or modify details of a selected stamp.
(5) Background
Select the check box and choose the background image you wish to use.
(6) Background first page only
Prints the background image only on the first page.
(7) Select Background...
This allows you to register a new background, or to display details of the background
you have selected.
(8) Preview Area
Shows how the stamp will appear on the printed page.
Printer Properties Dialog Box Description
29
Page 30
Effects T ab
(6)
Printer Driver Functions (Windows)
(1)
(2)
(3)
(4)
(5)
(1) Simulate Illustration
Select the check box to manipulate color image data to produce illustration effects.
Adjust the brightness of the image with the Contrast slide bar.
Printer Properties Dialog Box Description
30
Page 31
Printer Driver Functions (Windows)
(2) Monochrome Effects
Prints a color image in a single color. Select the check box and choose a color or use
a custom color using Select Color.
(3) Vivid Photo
By using this function, you can reproduce breathtaking sceneries in which colors,
especially blues and greens, appear even more vibrant. A major feature of this
function is its ability to create vivid backgrounds of fields, trees , oceans, and sky, while
maintaining the natural skin tones of people that appear in the images.
(4) Image Optimizer
Improves the contours and jaggedness that occur when photographic or graphic
image data is enlarged within an application.
(5) Photo Optimizer PRO
Optimizes the color of images taken from a digital camera or scanner. It is especially
effective for images affected by color imbalance and over- or under-exposure.
When printing several images on one page, optimization is usually applied to each
image according to its requirements. However, if the image data has been
manipulated using cut and paste, rotation or other such operations, group optimization
of all images on the one page is recommended. In such cases, select the Apply
Throughout Page check box.
(6) Preview Area
Shows how the image will appear when printed.
Printer Properties Dialog Box Description
31
Page 32
Profiles T ab
Printer Driver Functions (Windows)
(1)
(4)
(1) Printing Profiles
This list displays the printing settings currently registered in the Profiles tab.
The Current Settings profile contains the settings currently specified in the Main,
Page Setup and Effects tabs. The Default Settings profile contains the factory
default settings.
Printer Properties Dialog Box Description
(2)
(3)
(6)
(5)
32
Page 33
Printer Driver Functions (Windows)
(2) Details
Displays all the printer settings selected in Printing Profiles.
(3) Description
Displays a description of the printer settings selected in Printing Profiles. Y ou can
enter the description when saving the printer settings.
(4) Add to Profiles...
Click to save the settings currently specified in the Main, Page Setup and Effects
tabs. Select Current Settings in the Printing Profiles list then click this button. The
Add to Profiles dialog box appears.
(5) Retrieve from Profiles
Click to activate registered printer settings. The contents of the Main, P age Setup and
Effects tabs are changed by selecting the printer settings in Printing Profiles and
then clicking this button.
This button is disabled when Current Settings is selected.
(6) Delete
Click to delete unwanted printer settings. Select the unwanted item in the Printing
Profiles list and click the Delete button.
Current Settings and Default Settings cannot be deleted.
Printer Properties Dialog Box Description
33
Page 34
Maintenance T ab
(1)
Printer Driver Functions (Windows)
(2)
(3)
(4)
(1) Cleaning
Click to start printhead cleaning.
(2) Deep Cleaning
Click to start printhead deep cleaning.
Use this function only if Cleaning has not improved the print quality.
(5)
(6)
(7)
(8)
Printer Properties Dialog Box Description
34
Page 35
Printer Driver Functions (Windows)
(3) Printhead Alignment
Aligns the printhead. For details on printhead alignment, refer to the
Quick Start Guide
(4) Nozzle Check
Prints the nozzle check pattern to ensure that the printhead nozzles are ejecting ink
normally. For details, refer to “Examining the Nozzle Check Pattern.”
(5) Power Off
Click to turn the printer off.
(6) Custom Settings
Click to modify the printer mode. Change the settings in the Custom Setting dialog
box and click Send to change printer mode.
(7) Quiet Mode
Reduces the printing noise. However, the effect may be small, depending on the print
quality setting.
If you use Quiet Mode, the print speed may become slower than normal.
(8) Start Status Monitor...
Click to start the BJ Status Monitor, where you can check the printer status and the
progress of printing jobs.
.
Printer Properties Dialog Box Description
35
Page 36
Printer Driver Functions (Windows)
BJ Status Monitor Functions
The BJ Status Monitor allows you to check the status of the printer.
If an error occurs, the BJ Status Monitor indicates the nature of the error and suggests an
appropriate solution. It also chec ks the ink tanks and displa ys a warning message when the
ink is low.
■ Launching the BJ Status Monitor
The BJ Status Monitor launches automatically when data is sent to the printer. When
launched, the BJ Status Monitor appears as an icon on the Task Bar.
1
Click the Canon BJ Status Monitor icon on the Task Bar.
The BJ Status Monitor appears.
BJ Status Monitor Functions
36
Page 37
Printer Driver Functions (Windows)
Note
➤
To open the BJ Status Monitor when the printer is not printing, click the
Maintenance tab in the Printer Properties dialog box and click the Start
Status Monitor button.
BJ Status Monitor Functions
37
Page 38
Printer Driver Functions (Windows)
■ When errors occur or ink runs low
The BJ Status Monitor is automatically displayed when an error occurs (e .g., if the printer
runs out of paper or ink is low).
In such cases, take the appropriate action as described in the Printer Status tab.
In Windows Me or Windows 98, click the Guide tab and follow the instructions on screen.
When paper has run out: When the ink level is low:
Note
➤
For details on the BJ Status Monitor, select the Help menu and click on the
topic of interest.
BJ Status Monitor Functions
38
Page 39
Cancelling a Print Job
To cancel the current print job, first open the BJ Status Monitor.
1
Click the Canon BJ Status Monitor icon on the Task Bar.
2
Click Cancel Printing.
Printer Driver Functions (Windows)
Note
➤
If Cancel Printing is grayed out, press the printer's RESUME/CANCEL
button to terminate the print job.
Cancelling a Print Job
39
Page 40
Printer Driver Functions (Windows)
Uninstalling Printer Drivers
Use the Uninstaller to delete any unwanted printer drivers. This allows you to delete all the
files associated with the printer driver at the same time.
1
Click the Start button and select Programs, Canon S820, Uninstall.
Note
If a message prompts you to restart your computer, click OK to restart your computer.
Note
➤
For Windows XP, click the Start button and select All Programs, Canon
S820, Uninstall.
2
Click Yes when the confirmation message appears.
3
When all the files have been deleted, click OK.
The deletion of the printer driver is complete.
➤
In Windows Me or Windows 98, you can also start the Uninstaller by
double-clicking on Uninstall in the Canon S820 folder on the desktop.
Uninstalling Printer Drivers
40
Page 41
Printer Driver Functions (Macintosh)
Printer Driver Functions (Macintosh)
• Description of Print Settings
• BJ Print Monitor
• Cancelling a Print Job
• Using the Printer with a Network
• Uninstalling Printer Drivers
41
Page 42
Description of Print Settings
• Page Setup Dialog Box
• Print Dialog Box
Printer Driver Functions (Macintosh)
• Printer Utility
Dialog Box
• Detailed Setting Dialog Box
• Options Dialog Box
• Register Settings
Dialog Box
Description of Print Settings
42
Page 43
Printer Driver Functions (Macintosh)
Page Setup Dialog Box
The Page Setup dialog box contains settings for the printed page, such as the size of the
print media, and resizing the printed image. To open the Page Setup dialog box, select
Page Setup from the File menu in an application.
(1)
(2)
(7)
(3)
(10)
(1) Paper Size
Select the size of the paper for the print job . To enter the size manually, select Custom
1 - Custom 3 and click Custom.
(8)
(4)
(5)
(6)
(9)
(2) Banner Printing
Select this check box when printing on banner paper.
Description of Print Settings
43
Page 44
Printer Driver Functions (Macintosh)
(3) Borderless Printing
The image is printed on the entire paper surface, so that no margins are left on the f our
sides of the paper.
The media types availab le for Borderless Printing are Photo Paper Pro and
Glossy Photo Paper.
For all other media types, the print quality ma y decrease .
(4) Amount of Extension
When you select Borderless Printing, the sections that extend beyond the paper are
not printed because the image is enlarged to a size slightly larger than the paper size.
You can use the Amount of Extension slide bar to adjust how much the image
extends beyond the paper.
It is recommended that you normally set the slide bar to the right end.
If you move the slide bar to the left to reduce the extension amount, a border may
appear.
(5) Scale
Specify the scaling percentage to resize the document for printing.
(6) Orientation
Select landscape or portrait printing.
(7) Custom
To specify a custom paper size, click this button to open the Custom dialog box after
selecting Custom 1 to Custom 3 in the P aper Size pop-up menu. The Custom dialog
box allows you to specify the length and width of the paper.
(8) Utilities
Click to open the Printer Utility dialog box for maintenance operations, such as
printhead cleaning and nozzle check pattern printing, as well as for changing the print
mode.
Description of Print Settings
44
Page 45
Printer Driver Functions (Macintosh)
(9) Save Settings
Saves the settings specified in the Page Setup dialog box.
(10) Preview Area
This image allows you to confirm how the document will print with the selected
paper settings.
Description of Print Settings
45
Page 46
Printer Driver Functions (Macintosh)
Printer Utility Dialog Box
The Printer Utility dialog box is displayed when you click the Utilities button in the Page
Setup dialog box.
(1)
(2)
(1) Select the function you wish to perform.
(2) Display area showing the various maintenance functions, including cleaning and test
pattern printing. Click the icon to start this function. For further details, refer to
"Routine Maintenance."
Printing the Nozzle Check Pattern
➡
Description of Print Settings
46
Page 47
Printhead Cleaning
➡
Printhead Deep Cleaning
➡
Printer Driver Functions (Macintosh)
Note
➤
For information about Printhead Alignment, refer to the
Quick Start Guide
.
Description of Print Settings
47
Page 48
Printer Driver Functions (Macintosh)
Print Dialog Box
The Print dialog box specifies the media type and print settings to be used for your print
job. To open the Print dialog box, select Print from the File menu in an application.
(3)
(1)
(2)
(1) Media Type
Ensure that this setting matches the type of paper media loaded in the printer.
(4)
(5)
(6)
(2) Grayscale Printing
Select to print a grayscale version of a color document.
(3) Print Mode
Select the icon that most closely resembles your document and required print results.
(4) Details...
Allows you to manually set the print quality and color settings in the Detailed Setting
Dialog Box.
Description of Print Settings
48
Page 49
Printer Driver Functions (Macintosh)
(5) Options...
Specify the output destination, print order and page layout for the document you
are printing.
(6) Apply...
Allows you to register print settings or to implement a previously registered print setting.
Description of Print Settings
49
Page 50
Printer Driver Functions (Macintosh)
Detailed Setting Dialog Box
To open the Detailed Setting dialog box, select Manual in the Print dialog box and
then click Details....
(1)
(1) Panel display icons
Click these icons to switch between panels in the Detailed Setting dialog box.
Description of Print Settings
(2)
(3)
50
Page 51
Printer Driver Functions (Macintosh)
(2) Print Quality
Move the slide bar to adjust the balance between print quality and speed. Moving the
bar to the right enhances print quality, and moving it to the left increases printing
speed.
(3) Halftoning
Select either Dither or Diffusion ink dot configurations.
Description of Print Settings
51
Page 52
Printer Driver Functions (Macintosh)
■ Special Effects Panel
To display the Special Effects panel, click the Special effects display icon.
(5)
(1)
(2)
(3)
(4)
(1) Simulate illustration
Select the check box to manipulate color image data to produce illustration effects.
Adjust the brightness of the image with the Contrast slide bar.
Description of Print Settings
52
Page 53
Printer Driver Functions (Macintosh)
(2) Monochrome effects
Prints a color image in a single color. Select the check box and choose the color you
wish to use.
(3) Vivid Photo
By using this function, you can reproduce breathtaking sceneries in which colors,
especially blues and greens, appear even more vibrant. A major feature of this
function is its ability to create vivid backgrounds of fields, trees , oceans, and sky, while
maintaining the natural skin tones of people that appear in the images.
(4) Photo Optimizer PRO
Optimizes the color of images taken from a digital camera or scanner. It is especially
effective for images affected by color imbalance and over- or under-exposure.
When printing several images on one printing page, optimization is usually applied to
each image according to its requirements. However, if the image data has been
manipulated using cut and paste, rotation or other such operations, group optimization
of all images on the page is recommended. In such cases, select the Apply
Throughout Page check box.
(5) Preview Area
Shows how the image will look when printed.
Description of Print Settings
53
Page 54
■ Color Panel
To display the Color panel, click the Color display icon.
Printer Driver Functions (Macintosh)
(1)
(2)
(3)
(4)
(5)
(6)
(1) Color Correction
Select a color correction method: BJ Standard, ColorSync or None. BJ Standard is
usually the optimum color correction method for printing with a Bubble Jet printer.
When ColorSync is selected, you should also specify the Print T ype and Printer
Profile settings.
Description of Print Settings
54
Page 55
Printer Driver Functions (Macintosh)
(2) Print Type
For printing that emphasizes intermediate colors, select Photo. For printing that
emphasizes the brightness of primary colors, select Graphics. For documents that
contain large amounts of a basic color, select Spot Color.
(3) Printer Profile
Select optimized color characteristics (a profile) for the media type and other factors.
(4) Gamma Correction
This function adjusts the color contrast (not including pure black and white). To adjust
the contrast, select the check box and move the slide bar. Moving the bar to the right
darkens the entire image while increasing contrast in the lighter areas and decreasing
contrast in the darker areas.
(5) Color Balance
Move the bar for each color to adjust the balance of color intensity. Moving the bar to
the right intensifies the color.
(6) Intensity
Move the slide bar to adjust the print density. Moving the bar to the right increases the
density.
Description of Print Settings
55
Page 56
Printer Driver Functions (Macintosh)
Options Dialog Box
To open the Options dialog box, click the Options... button in the Print dialog box.
(1)
(7)
(2)
(3)
(4)
(1) Layout
Allows you to print two or four pages of a document on a single page, or to enlarge
printing so that a single page spans multiple sheets of paper (Poster Printing). If you
select 2Page/Sheet Printing or 4Page/Sheet Printing, you should also set the Page
Order to specify the document page order for printing. The Border option allows you
to select whether to print a border around the individual document pages.
(5)
(6)
Description of Print Settings
56
Page 57
Printer Driver Functions (Macintosh)
(2) Duplex Printing
The document is printed on both sides of the paper. After printing one side, turn the
ejected page over, and print on the other side.
(3) Fit-to-page Printing
The document is automatically resized to fit the paper size. When using this function,
ensure that you correctly specify the Printer Paper Size.
(4) Destination
Select the print output destination. Printer is the usual selection.
To check the layout or other image elements before printing, select Preview. To save
the document as a PICT file, select PICT File.
(5) Print in reverse order
Prints the document starting with the last page.
(6) Print collated pages
Prints multiple copies of the document one copy at a time.
(7) Preview Area
Shows how the layout will look when printed.
Description of Print Settings
57
Page 58
Printer Driver Functions (Macintosh)
Register Settings Dialog Box
To open the Register Settings dialog box, click the Apply... button in the Print dialog box.
(2)
(1)
(1) Settings
Displays a list of the registered print settings.
(2) Import
Imports a set of print settings. To use the settings, select the desired settings in the
Settings list and click the Import button.
(3) Apply
Saves the settings currently specified in the Print dialog box. After clic king the button,
enter the name under which the settings are to be saved.
(4) Remove
Deletes unwanted print settings. To delete unwanted settings, select the settings in
Settings and click the Remove button.
(5) Defaults
Restores the print settings selected in Settings to defaults. A check mark appears
next to the selected print settings.
(3)
(4)
(5)
Description of Print Settings
58
Page 59
Printer Driver Functions (Macintosh)
BJ Print Monitor
The BJ Print Monitor allows you to check the progress of print jobs.
You can launch the BJ Print Monitor if background printing is enabled in the Chooser utility.
■ Opening the BJ Print Monitor
1
Select Chooser from the Apple menu.
2
Set Backgrounding to On.
3
After starting a print job, select BJ Print Monitor in the Application menu.
The BJ Print Monitor launches.
BJ Print Monitor
59
Page 60
■ BJ Print Monitor Functions
... Click to pause printing of the specified document.
... Click to resume printing.
... Click to cancel printing of the specified document.
Displays the printer status. If an error occurs, instructions on are display ed.
Printer Driver Functions (Macintosh)
Displays the printer status and ink status with images.
Displays information about the documents queued for printing.
The BJ Print Monitor allows you to change the print order of documents queued for printing.
To change the print order , place the mouse pointer ov er the name of the document, hold the
mouse button down while dragging the document name to the new position, then release.
Note, however, that you cannot change the print order of a document already printing.
Note
➤
If you select Print from the File menu, you can print the PICT file saved in
Destination of the Option dialog box.
BJ Print Monitor
60
Page 61
Printer Driver Functions (Macintosh)
Cancelling a Print Job
When the BJ Print Monitor is running, you can use it to cancel or suspend the currently
printing job.
1
Select BJ Print Monitor in the Application menu.
2
Click the name of the print job you wish to cancel, then click .
The document selected in the Print Monitor is deleted from the print list and
the print job is cancelled.
Note
➤
To suspend printing, click the name of the document being printed then
click . To resume printing, click .
Cancelling a Print Job
61
Page 62
Printer Driver Functions (Macintosh)
Using the Printer with a Network
The printer can be used with an Ethernet network environment.
Follow the steps described below to connect the printer to the network.
■ Before Setting up the Printer
• Install the printer driver on each network computer that will use the printer.
For information on installation, refer to the
• Use a USB cable to connect the printer to the computer that will function as the print server .
Quick Start Guide
■ Printer Setup
To use the printer on a network, first set up the print server, then set up each client machine .
• Print server setup procedure
.
1
Select Chooser in the Apple menu.
2
Select Active in AppleTalk.
3
Select the S820 icon, then select the printer name in Connected to.
Using the Printer with a Network
62
Page 63
4
Click Share.
5
Confirm that S820 server is selected in Enter new print server name then
click Send.
6
Confirm that the new print server name has been added to Current print
servers then click Close.
7
Click the close box to close the Chooser.
• Client setup procedure
1
Select Chooser in the Apple menu.
2
Select Active in AppleTalk.
Printer Driver Functions (Macintosh)
3
Select the S820 (Server) icon, then select the printer server in Connected to.
4
Click the close box to close the Chooser.
Using the Printer with a Network
63
Page 64
Printer Driver Functions (Macintosh)
■ Checking Print Status
• Checking print status from the print server
To check the status of a print job from the print server, start the BJ Print Monitor.
Select BJ Print Monitor in the Application menu.
To close the BJ Print Monitor, select Close Status Window in the File menu.
• Checking print status from a client
To check the status of a print job from a client, start the BJ Status Monitor. Click the
BJ Status Monitor icon in the BJ Extras folder.
To close the BJ Status Monitor, select Quit in the File menu.
• The BJ Print Monitor and BJ Status Monitor
The BJ Print Monitor and the BJ Status Monitor both display a list of information
concerning documents queued for printing. This information includes the document
name, number of pages, number of copies and the time when the print job was
accepted. The total number of queued documents is also displayed.
The BJ Print Monitor allows you to change the print order of the queued documents.
BJ Print Monitor Functions
➡
BJ Status Monitor Functions
➡
Using the Printer with a Network
64
Page 65
■ BJ Status Monitor Functions
....Click to pause printing of the specified document.
....Click to resume printing.
....Click to cancel printing of the specified document.
Printer Driver Functions (Macintosh)
Note
➤
• You can determine the owner of a computer by selecting the File Sharing
control panel and checking the Owner Name item.
• If you are using two or more printer servers, you can switch between the
BJ Status Monitor displays. Select Print Server in the File menu, then
select the desired print server and click OK.
Using the Printer with a Network
65
Page 66
Printer Driver Functions (Macintosh)
Uninstalling Printer Drivers
When a printer driver is no longer needed, use the Installer to delete all the program files
associated with it.
Before proceeding, ensure that you sa ve any unsa ved files in an y currently running applications.
1
Load the
2
Double-click the Printer Driver folder.
3
Double-click the Installer icon.
4
When the Software License Agreement is display ed, clic k Accept, if you ag ree.
5
Select Uninstall from the pop-up menu and then click Uninstall.
Setup Software & User's Guide CD-ROM
.
Note
➤
If a warning message appears, indicating that other applications are running:
• Click Cancel and save the document(s) if there are any unsaved
documents open in the other applications.
• Click Continue to continue the uninstall operation.
6
After the uninstall is complete, a message appears prompting you to restart
your computer. Click Restart.
Uninstalling Printer Drivers
66
Page 67
Routine Maintenance
• When to Replace Ink Tank and Maintain Printhead
• Replacing an Ink Tank
• Printing the Nozzle Check Pattern
• Printhead Cleaning
• Printhead Deep Cleaning
• Cleaning the Printer
Routine Maintenance
• Transporting the Printer
67
Page 68
Routine Maintenance
When to Replace Ink Tank and Maintain Printhead
When an ink tank is empty, it must be replaced.
The BJ Status Monitor (Windows) or the BJ Print Monitor (Macintosh) will initially advise
you of a low ink level. At this stage, you can still continue to print.
Once an ink tank is empty, the BJ Status Monitor (Windows) or the BJ Print Monitor
(Macintosh) will tell you to replace the ink tank. Attempting to print causes the POWER
lamp to flash four times.
Replacing an Ink Tank
➡
If printing becomes faint or a specific color is no longer printing, even though there is still
enough ink, the printhead nozzles are probably clogged. Follow the procedures below to
clean the nozzles.
Printing the Nozzle Check Pattern
➡
If the print quality is poor
Printhead Cleaning
➡
If the problem remains
Printhead Deep Cleaning
➡
If printhead deep cleaning does not resolve the problem, the printhead may be worn out.
Contact the Canon Customer Care Center.
When to Replace Ink Tank and Maintain Printhead
68
Page 69
Routine Maintenance
Replacing an Ink Tank
When replacing an ink tank, check the model number very carefully. The printer will not print
properly if an incorrect ink tank is used, or installed in an incorrect position.
With this printer, ink tanks must be installed from the right in the order indicated below.
• Yellow: BCI-6Y
• Magenta: BCI-6M
• Cyan: BCI-6C
• Photo Magenta: BCI-6PM Photo
• Photo Cyan: BCI-6PC Photo
• Black: BCI-6BK
Note
➤
Damage caused by using a refilled cartridge is not covered by the Canon
warranty. Canon recommends using only original Canon ink tanks to
ensure the best quality.
1
Ensure that the printer is on, and then open the front cover.
The printhead holder moves to the center.
Replacing an Ink Tank
69
Page 70
2
Remove the empty ink tank.
Push the tab and remove the ink tank.
Do not touch the lock lever; remove only the ink tank.
Routine Maintenance
Important
➤ • Handle ink tanks carefully to avoid staining clothing or the surrounding area.
• Discard empty ink tanks according to the local laws and regulations
regarding disposal of consumables.
Replacing an Ink Tank
70
Page 71
Routine Maintenance
3
Unpack the new ink tank and pull off the orange tape. Discard the pastic
wrapper.
Replacing an Ink Tank
71
Page 72
4
Remove the orange protective cap from the bottom of the ink tank.
Never press here!
Ink may squirt out of the tank.
Routine Maintenance
Important
➤ • Do not re-attach the protective cap once you have removed it.
• Once you have remo ved the protective cap , do not touch the open ink port.
Replacing an Ink Tank
72
Page 73
Routine Maintenance
5
Insert the ink tank in the printhead holder.
Press on the "PUSH" mark until the ink tank snaps firmly into place.
6
Close the front cover.
The printhead holder moves to the right. The ink tank installation process is
now complete.
Note
➤
• To maintain optimal print quality, use an ink tank within six months of first use.
• Once an ink tank has been used, do not remove it from the printer and
leave it out in the open. An ink tank left out in the open and then
reinstalled in the printer may not function.
Replacing an Ink Tank
73
Page 74
Routine Maintenance
Printing the Nozzle Check Pattern
Print the nozzle check pattern to determine whether the ink sprays normally from the
printhead nozzles, and to verify printhead alignment. Use this function when printed results
are blurred or the color is incorrect.
Nozzle check pattern printing can be started from the Windows and Macintosh printer
drivers, or from the printer itself.
■ Printing the Nozzle Check Pattern from the Printer Drivers
Windows
1
With the printer on, load a sheet of Letter or A4 paper in the printer.
2
Open the Printer Properties dialog box.
Opening the Printer Properties Dialog Box
➡
3
Click the Maintenance tab and then click the Nozzle Check icon.
4
When the confirmation message is displayed, click OK.
Examining the Nozzle Check Pattern
➡
Printing the Nozzle Check Pattern
74
Page 75
Macintosh
1
With the printer on, load a sheet of Letter or A4 paper in the printer.
2
Open the Page Setup dialog box.
The Page Setup dialog box can normally be opened by selecting Page
Setup... in the File menu.
3
Click the Utilities button to open the Printer Utilities dialog box.
4
Select Test Print from the pull-down menu, and then click the Nozzle
Check icon.
5
When the confirmation message is displayed, click OK.
Routine Maintenance
Examining the Nozzle Check Pattern
➡
Printing the Nozzle Check Pattern
75
Page 76
■ Printing the Nozzle Check Pattern through the Printer
1
With the printer on, load a sheet of Letter or A4 paper in the printer.
2
Hold the RESUME/CANCEL button down until the PO WER lamp flashes twice.
Examining the Nozzle Check Pattern
➡
Routine Maintenance
Printing the Nozzle Check Pattern
76
Page 77
Routine Maintenance
■ Examining the Nozzle Check Pattern
The nozzle check pattern should appear as follows when ink is discharged properly.
Examine the nozzle check pattern output by the printer.
Lines missing here
indicate the printhead
requires cleaning.
Unevenness in these patterns indicates
the printhead requires alignment.
Printing the Nozzle Check Pattern
77
Page 78
Routine Maintenance
Printhead Cleaning
Clean the printhead if you suspect that the nozzles might be clogged.
Printhead cleaning can be performed either from the printer drivers or from the printer itself.
Note
■ Cleaning the Printhead from the Printer Drivers
Windows
➤
Cleaning the printhead consumes ink, so perform printhead cleaning only
when necessary.
1
Ensure that the printer is on.
2
Open the Printer Properties dialog box.
Opening the Printer Properties Dialog Box
➡
3
Click the Maintenance tab and then click the Cleaning icon.
4
When the confirmation message is displayed, click OK.
Printhead Cleaning
78
Page 79
Macintosh
Routine Maintenance
1
Ensure that the printer is on.
2
Open the Page Setup dialog box.
The Page Setup dialog box can normally be opened by selecting Page
Setup... in the File menu.
3
Click the Utilities button to open the Printer Utility dialog box.
4
Select Cleaning from the pull-down menu, and then click the Cleaning icon.
5
When the confirmation message appears, click OK.
Note
➤
If the problem remains even after you repeat printhead cleaning three
times, perform printhead deep cleaning.
Printhead Cleaning
79
Page 80
Routine Maintenance
■ Cleaning the Printhead from the Printer
1
Ensure that the printer is on.
2
Hold down the RESUME/CANCEL button until the PO WER lamp flashes once.
Now the POWER lamp starts flashing and printhead cleaning begins. Do not perform any
other operations until the printhead cleaning finishes.
After printhead cleaning finishes, print the nozzle check pattern to verify that the printhead
is clean. If not, repeat printhead cleaning. If the printhead is still not clean after the third
cleaning, perform printhead deep cleaning.
Printing the Nozzle Check Pattern
➡
Printhead Deep Cleaning
➡
Printhead Cleaning
80
Page 81
Routine Maintenance
Printhead Deep Cleaning
If print quality does not improve by standard printhead cleaning, try deep cleaning, which is
a more powerful process. Perform printhead deep cleaning from the printer driver.
Note
Windows
➤
Printhead deep cleaning consumes more ink than standard printhead
cleaning, so perform this procedure only when necessary.
1
Ensure that the printer is on.
2
Open the Printer Properties dialog box.
Opening the Printer Properties Dialog Box
➡
3
Click the Maintenance tab and then click the Deep Cleaning icon.
4
When the confirmation message is displayed, click OK.
Printhead Deep Cleaning
81
Page 82
Routine Maintenance
Macintosh
1
Ensure that the printer is on.
2
Open the Page Setup dialog box.
The Page Setup dialog box can normally be opened by selecting Page
Setup... in the File menu.
3
Click the Utilities button to open the Printer Utility dialog box.
4
Select Cleaning from the pull-down menu, and then click the Deep
Cleaning icon.
5
Click OK.
Now the POWER lamp starts flashing and printhead deep cleaning begins. The process
takes one or two minutes to complete, so simply wait until the POWER lamp stops flashing.
After printhead deep cleaning finishes, print the nozzle check pattern to verify that the
printhead is clean. If the printhead is still not clean, repeat printhead deep cleaning and the
nozzle check pattern printing up to three times. If the problem persists, the printhead may
be worn out. Contact the Canon Customer Care Center.
Printing the Nozzle Check Pattern
➡
Printhead Deep Cleaning
82
Page 83
Routine Maintenance
Cleaning the Printer
During normal printing, ink and small scraps of paper accumulate in the printer. When the
accumulated debris becomes clearly visible, clean the printer by the following procedure.
1
Turn the printer off.
2
Ensure that the POWER lamp is off and unplug the printer.
Caution
➤ Always ensure that you unplug the printer before cleaning the printer to
avoid an electric shock.
Cleaning the Printer
83
Page 84
Routine Maintenance
3
Open the front cover, and wipe the interior of the printer with a dry cloth.
Wipe away any stray drops of ink, scraps of paper, and dust. Pay special
attention to cleaning the black panel that can easily become dirty. Do not
touch any of the printer's internal components, such as the Ink Absorber.
Warning
Ink Absorber
➤ Do not use any flammable solvents, such as paint thinner, benzene or
alcohol.
Black panel
Cleaning the Printer
84
Page 85
Routine Maintenance
Transporting the Printer
Pack the printer carefully in its original packing materials.
If you do not hav e the original packing materials, pack the printer carefully and thoroughly in
protective material and place inside a sturdy box.
1
Turn the printer off.
2
After making sure that the POWER lamp is off, unplug the printer.
Important
➤ Do not unplug the printer while the POWER lamp is lit or flashing to protect
the printer from damage.
Transporting the Printer
85
Page 86
Routine Maintenance
3
Remove the paper rest and the paper output tray.
4
Disconnect the printer cable from the computer, and then disconnect the
power cord from the printer.
Transporting the Printer
86
Page 87
5
Secure the printer with adhesive tape, as shown, and then pack it in a
plastic bag.
Routine Maintenance
Transporting the Printer
87
Page 88
Routine Maintenance
6
Attach protective material to both sides of the printer when packing the printer.
Clearly label the box as "Fragile," if using a transport company.
Transporting the Printer
88
Page 89
Printing Media
• Compatible Media Types
• Envelopes
• High Resolution Paper
• Glossy Photo Paper
• High Gloss Photo Film
• Glossy Photo Cards
• Photo Paper Pro
Printing Media
• Photo Paper Pro (Borderless)
• Transparencies
• T-Shirt Transf ers
• Banner Paper
89
Page 90
Compatible Media Types
You can use the following types of paper and other media.
■ Size
• Standard paper: From A5 size (5.83 x 8.27 in / 148.0 x 210.0 mm)
to legal size (8.5 x 14.0 in / 215.9 x 355.6 mm)
• Non-standard paper: From 3.54 x 4.72 in to 8.5 x 23.0 in
(From 90.0 x 120.0 mm to 215.9 x 584.2 mm)
• Others: Envelopes (US Com. #10 and European DL)
Printing Media
Important
➤ Do not use the following types of paper. Using such paper will not only
produce unsatisfactory results, but can also cause the printer to jam or
malfunction.
• Folded, curled or wrinkled paper
• Wet paper
2
• Paper that is too thin (less than 17 lb / 64 g/m
• Paper that is too thick* (more than 28 lb / 105 g/m2)
• Picture postcards
• Postcards with an adhered photo or sticker
• Envelopes with a double flap
• Sealed envelopes
• Envelopes with an embossed or treated surface
• Paper with holes (such as loose-leaf paper)
* non-Canon branded paper
)
Compatible Media Types
90
Page 91
Printing Media
■ Weight
17 to 28 lb (64 to 105 g/m2)
Do not use paper heavier than this (except for supported Canon-brand media), as it
could jam in the printer.
■ Types
The following types of media can be used.
For more inf ormation about the media and the printing methods, refer to the specific sections.
Plain paper: Refer to the
Envelopes
➡
High Resolution Paper
➡
Glossy Photo Paper
➡
High Gloss Photo Film
➡
Glossy Photo Cards
➡
Photo Paper Pro
➡
Photo Paper Pro (Borderless)
➡
Transparencies
➡
T-Shirt T r ansfers
➡
Banner Paper
➡
Quick Start Guide
Compatible Media Types
.
91
Page 92
Envelopes
Use either US Com. #10 or European DL size envelopes.
■ Preparation for Printing
1
Press down on all four corners and edges of the envelopes to flatten them
as shown below.
2
If the envelopes are curled, hold the opposite corners and gently bend
them in the opposite direction.
Ensure that the flap of the envelope is perfectly straight.
Printing Media
Envelopes
92
Page 93
3
If the leading edge of an envelope is puff ed up or curled, use a pen to press
the envelope flat and sharpen the crease.
Press the envelope completely flat,
working from the middle to the edge.
* The abov e illustrations sho w a side vie w of the leading edge of the en v elope .
The envelopes may jam in the printer if they are not completely flat and the
edges are not aligned.
Printing Media
Ensure that no curl or puff exceeds 0.2 in (5 mm).
■ Unsuitable Envelopes
• Envelopes with an embossed or treated surface
• Envelopes with a double flap or pressure seals
Envelopes
93
Page 94
Printing Media
■ Loading
• Place envelopes lengthwise with the flap to the left and the address side facing upw ards .
• Set the Paper Thickness Lever to the right.
• Up to 10 envelopes can be loaded at once.
Paper
Thickness
Lever
Note
➤
If even after removing any curl in the envelopes they still will not feed
properly, clean the paper feed roller.
1
Ensure that the printer is turned on. If any paper is loaded in the
printer, remove the paper.
2
Hold down the RESUME/CANCEL button; when the POWER lamp
flashes three times, release the RESUME/CANCEL button.
Envelopes
94
Page 95
Printing Media
The paper roller will rotate ten times as it cleans.
Repeat this operation three times.
3
Load a sheet of Letter or A4 plain paper in the printer.
4
Hold down the RESUME/CANCEL button; when the POWER lamp
flashes three times, release the RESUME/CANCEL button.
The paper that is loaded in the printer will feed through the printer and
be ejected.
Repeat this operation three times.
If the printer still will not feed envelopes through even after cleaning the
paper feed roller, perform the procedure described in step 4 again.
■ Printer Driver Settings
• Media T ype: Env elope
• Page Size: Select either #10 Env. or DL Env. according to the envelope size you
are using.
• Orientation: Landscape
■ Handling of Printed Output
Remove each envelope as it is printed.
■ Printable Area
Printing Area
➡
Envelopes
95
Page 96
Printing Media
High Resolution Paper
This type of paper provides better color reproduction than plain paper. It is suitable for
printing business documents that feature graphics, and for photographs.
■ Loading
• Load the paper with the whiter side facing up.
• Set the Paper Thickness Lever to the left.
• Do not load paper higher than the limit mark. A maximum of 80 sheets can be loaded.
Paper Thic kness Lever
Print Side
(Whiter Side)
High Resolution Paper
96
Page 97
Printing Media
■ Printer Driver Settings
• Media T ype: High Resolution Paper
• Page Size: Ensure that the setting matches the size set in the application.
■ Handling of Printed Output
Do not stack more than 50 sheets in the paper output tra y. If the output paper is curled, it
may prevent the next sheet being ejected. In this case, or if the ink takes a long time to
dry, remove each sheet as soon as it is printed.
■ Printable Area
With some images the trailing edge of the image may be b lurred if printing extends out of
the printable area. Canon recommends that you print within the printing area.
Printing Area
➡
High Resolution Paper
97
Page 98
Printing Media
Glossy Photo Paper
This media is thicker than High Resolution Paper with a glossy printing surface to produce
printouts close to photograph quality.
■ Loading
• Load the paper with the whiter side facing up.
• Set the Paper Thickness Lever to the left.
• Load only one sheet at a time.
• Do not use the loading support sheet provided with the package.
Paper Thic kness Lever
Print Side
(Whiter Side)
Glossy Photo Paper
98
Page 99
Printing Media
■ Printer Driver Settings
• Media T ype: Glossy Photo Paper
• Page Size: Ensure that the setting matches the size set in the application.
■ Handling of Printed Output
• Remove each sheet as soon as it is printed.
• Do not touch the printed surface until the ink is fixed (approx. two minutes).
■ Printable Area
With some images the trailing edge of the image may be b lurred if printing extends out of
the printable area. Canon recommends that you print within the printing area.
Printing Area
➡
Note
➤
For photograph and illustration data that you want to print with Borderless
Printing, create the data by using the same size as the paper size, and
paste the data so that it fills the editing screen without leaving any margins.
If you are using an application that allows you to set margins, set the left,
right, top, and bottom margins to 0 inches. For instructions on setting
margins, refer to the user's manual for your application.
Glossy Photo Paper
99
Page 100
Printing Media
High Gloss Photo Film
This film has an extremely glossy surface, ideal for printing photographs with outstanding
results.
■ Loading
• Load only one sheet at a time.
• Load the film with the cut corner at the upper right.
• If the film is curled, flatten it by curling in the opposite direction.
• Set the Paper Thickness Lever to the left.
Cut Corner
Paper
Thickness
Lever
High Gloss Photo Film
100
Loading...
