MultiQuick 5 Vario
Stapled booklet, 148 x 210, 16 pages (incl. 8 pages cover), 1/1c = black – Print Spec J 92194885
Type 4191
Register your product
www.braunhousehold.com/register
MQ 5025
MQ 5035
English 6
9
De’Longhi Braun Household GmbH
Carl-Ulrich-Straße 4
63263 Neu-Isenburg/Germany
5722112584/02.17 MQ 5025-5035 CN
GB/China
1
1
1
1
.
.
2
2
.
.
5
5
.
.
.
.
.
.
7
7
9
9
.
.
1
1
.
.
.
.
1
1
3
3
.
.
.
.
.
.
.
.
.
.
.
.
.
.
6
1
1
1
1
.
.
2
2
.
.
5
5
.
.
.
.
.
.
7
7
9
9
.
.
1
1
.
.
.
.
1
1
3
3
.
.
.
.
.
.
.
.
.
.
.
.
.
1
.
7b7a
8
9
10
2
3
hchc
caca
4
5
350 ml
500 ml
A
click!
4
B
9a
9b
9c
9d
10a
10b
10c
10d
hchc
ca
ca
C
C
Parmesan
hchc
D
caca
max.
sec.
max.
sec.
1cm
100 g10100 g2050 g510g57
D
300 g
15-30
turbo turbo turbo
1cm
1c
m
1 - 21 1 - 21 1 - 219 - 21 21 1 1
+5 sec
turbo
Parmesan
1c
m
200 g30200 g1030 g2020
90g
80 g
5
10
turbo
200 g15300 g25350 g
20
1 - 5 1 - 21 1 - 21 13 - 21 13 - 21
+
25
ml
45
turbo
80 g5100 g
+5 sec
turbo
+5 sec
turbo
10
+5 sec
turbo
30
+5 sec
turbo
E
caca
5
hchc
caca
English
Our products are engineered to meet the highest
standards of quality, functionality and design.
We hope you thoroughly enjoy your new Braun
appliance.
Before use
Please read the use instructions carefully and
completely before using the appliance.
Caution
•
The blades are very sharp!
To avoid injuries, please handle
blades with utmost care.
•
Care shall be taken when handling
the sharp cutting blades, emptying
the bowl and during cleaning.
•
This appliance can be used by persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and if they understand the
hazards involved.
•
Children shall not play with the appliance.
•
This appliance shall not be used by
children.
•
Children shall be kept away from the
appliance and its mains cord.
•
Always unplug or switch off the appliance when it is left unattended and
before assembling, disassembling,
cleaning and storing.
•
If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
•
Before plugging into a socket, check
whether your voltage corresponds
with the voltage printed on the bottom
of the appliance.
•
This appliance is designed for household use only and for processing normal household quantities.
6
•
Do not use any part in the microwave.
•
Please clean all parts before first
use or as required, following the
instructions in the Care and Cleaning
section.
Description
1 Variable speed regulator
2 Variable speed button (on/off)
3 Turbo button (T)
4 Motor part
5 Release buttons
6 Blender shaft
7a Whisk gearbox
7b Whisk
8 Beaker
9 350 ml chopper «hc»
9a Lid
9b Blade
9c Bowl
9d Anti-slip ring
10 500 ml chopper «ca»
10a Lid
10b Blade
10c Bowl
10d Anti-slip ring
Setting the speed
When activating the variable speed button (2), the
processing speed corresponds to the setting of the
variable speed regulator. The higher the setting, the
faster the chopping results. You can adjust the
speed conveniently during operation by turning the
speed regulator using your thumb or index finger.
Maximum processing speed is achieved by
pressing the turbo button (3). You may also use the
turbo button for instant powerful pulses without
having to manipulate the speed regulator.
Hand blender (A)
The hand blender is perfectly suited for preparing
dips, sauces, soups, mayonnaise and baby food as
well as for mixing drinks and milk shakes.
For best blending results use highest speed.
• Click the motor part (4) into the blender shaft (6).
• Position the hand blender deep in a beaker or
bowl. Then switch the appliance on as described
above.
• After use unplug and press the release buttons (5)
to detach the motor part.
When blending directly in the saucepan while
cooking, remove the pan from the stove first to avoid
splashing of the boiling liquid (risk of scalding).
Recipe example: Mayonnaise
250 g oil (e.g. sunflower oil),
1 egg and 1 extra egg yolk,
1–2 tbsp. vinegar (approx. 15 g),
salt and pepper to taste
Place all ingredients (at room temperature) into the
beaker in the order as mentioned above. Place the
hand blender on the bottom of the beaker. Operate
the hand blender at maximum speed, keep it in this
position until the oil starts emulsifying. Then without
switching off slowly raise the shaft to the top of the
mixture and back down to incorporate the rest of
the oil. Processing time: from 1 minute (for salad)
up to 2 minutes for more stiffness (e.g. for dip).
Whisk (A)
Use the whisk only for whipping cream, beating egg
whites and mixing sponges and ready-mix desserts.
• Insert the whisk (7b) into the whisk gear box (7a)
then click the motor part (4) into the gear box.
• Place the whisk in a bowl and only then switch
the appliance on.
• After use, unplug and press the release buttons
(5) to detach the motor part. Then pull the whisk
out of the gear box.
Tips for best results
• Use a medium-sized bowl.
• Move the whisk clockwise, holding it slightly
inclined.
• Whipped cream (max. 400 ml chilled cream, min.
30% fat content, 4–8 °C):
Start with low speed and increase the speed (by
turning the speed regulator) while whipping.
• Beaten egg whites (max. 4 eggs):
Start with a medium speed and increase the
speed (by turning the speed regulator) while
whipping.
Choppers (B)
The choppers (9,10) are perfectly suited for
chopping meat, hard cheese, onions, herbs, garlic,
carrots, nuts, almonds etc.
Always chop hard food at full speed (e.g. parmesan,
chocolate).
For best results see processing tables (C,D).
Maximum operation time for the «hc» chopper:
2 minutes (large amounts of wet ingredients)
/ 30 seconds (dry or hard ingredients or amounts
< 100g / 100 ml). Immediately stop processing
when motor speed decreases and/or strong
vibrations occur.
Before chopping …
• Pre-cut meat, cheese, onions, carrots.
• Remove stems from herbs, shell nuts.
• Remove bones, tendons and gristle from meat.
• Always make sure that the anti-slip ring is
attached to the bowl.
Caution: The blade is very sharp! Always hold it by
the upper plastic part and handle it carefully.
1. Carefully remove the protective cover from the
blade.
2. Place the blade on the centre pin of the bowl,
push it down and give it a turn so that it locks.
3. Fill the chopper bowl with food and put on the
lid.
4. Click the motor part onto the lid.
5. Press button (2) or (3) to operate the chopper.
During processing, hold the motor part with one
hand and the bowl with the other.
6. After use, unplug and press the release buttons
(5) to detach the motor part.
7. Remove the lid.
8. Carefully take out the blade before removing the
processed food. To remove the blade, slightly
turn and pull off.
Recipe example: Vanilla-Honey-Prunes (as a
pancake stuffing or spread):
• Fill the «hc» chopper bowl with 50 g prunes and
70 g creamy honey.
• Chop 4 seconds at maximum speed
• Add 10 ml water (vanilla-flavoured).
• Resume chopping for another 1.5 seconds.
Care and Cleaning (E)
Clean the motor part (4) and the whisk gear box
(7a) with a damp cloth only. The lid (10a)
can be cleaned under running water, but do not
immerse in water, nor clean it in a dishwasher. All
other parts can be cleaned in a dishwasher.
You may remove the anti-slip rings from the
chopper bowls for extra thorough cleaning.
When processing foods with a high pigment content
(e.g. carrots), the plastic parts of the appliance may
become discoloured. Wipe these parts with
vegetable oil before cleaning them.
Accessories
(can be bought individually, not available in every
country)
7
MQ 10: Whisk for whipping cream, beating egg
MQ 20: 350 ml chopper to chop herbs, carrots,
MQ 30: 500 ml chopper to chop carrots, meat,
MQ 40: 1250 ml chopper to chop, mix, blend
MQ 50: puree accessory to puree cooked
MQ 70: Compact kitchen machine accessory
Both the design specifications and these user
instructions are subject to change without notice.
Please do not dispose of the product in the
household waste at the end of its useful life.
Disposal can take place at a Braun Service
Centre or at appropriate collection points
provided in your country.
Materials and accessories coming into
contact with food conform to EEC
regulation 1935/2004.
whites
etc.
onions, etc.
and crush ice
vegatable and potatoes
(1500 ml) to chop, mix, slice and shred.
8
91011
12
