Blaupunkt LS 178-1 User guide

LS 178-1

Bluetooth-Soundboard
Bluetooth sound board

LS 178-1

Important Safety Instructions

Important Safety Instructions

Caution:

To reduce the risk of electric shock, do not dismantle the product and do not expose the
apparatus to rain or moisture. N o user-ser viceable parts inside. Refer servicing to
qualified personnel o nl y.

Explanation of Graphical Symbols:

The l ig htning flash within an equilateral triangle is inte nd ed to aler t you to the
presence of uninsulated dangerous voltage within the product's enclosure that
may b e of sufficient magnitude to constitute a n el ec tric shock to a person or
persons.

The exclamation point within an equilateral triangle is intended to alert you to
the presence of impor tant operating and maintenance (servicing) instruc ti on s
in the lite rature accompanying the product.

To achieve the utmost in enjoy ment and per formance, and in order to become familiar w ith its
features, please read t hi s manual carefu lly before attempting to operate th is p roduct. This wil l
assure you yea rs of trouble free performance and lis tening pleasure.

Important Notes

Thi s safety and operating instruction sho uld be retained for future refere nce.
The a pparatus shou ld not be exposed to dr ipping or splashing o r placed in a humid

atm osphere such as a b athroom.

¡Do not in stall the produ ct in the following a reas:
¡Pla ces exposed to direct sunlight or cl ose to radiators.
¡On to p of other stereo equipment that radiate to o much heat.
¡Block ing ven tilation or in a dust y area.
¡Areas where there is constant vibration.
¡Humid o r moist places.
Do not pl ace near candles or o ther naked flames.
Operate the prod uc t on ly as instructed in thi s ma nual.
Before turning on th e power for the first time, make sure the power adapto r is properly

con nected.

For safe ty reasons, d o not remove any covers or attemp t to gain acces s to the inside of the
product. Refer any ser vicing to q ualified person ne l.
Do not at tempt to re move any screws, or open the casing of th e unit; there are no user
serviceable p ar ts inside. Refer all servicing to qu alified service personnel.

35

LS 178-1

Confor mity

Model num ber: LS 178-1
Descr ip tion: Bluetooth s ound board
Bra nd name: Blaupunkt
Respo nsible par ty: M3 Electroni c GmbH
Gutenbergstras se 5, D- 65830 Krif tel. Germany
Hereby, Blaupunkt Competence Center Audio M3 Electroni c GmbH, declare s th at this Class 1
equip ment is in compli ance with the essential requirement and other relevant provisions of
Direc tive 1999/5/E C.
Letter of conformity can be obtaine d from info @m3- el ec tronic.de.

Safety Instructions

1.

Read In structions - All the safety and operating instructions must be read before

the product is operated.

Retain Instructions - The safety and operating in st ru ctions should be kept with the

2.

product for future reference.

3.

Heed warnings - All warnings on the produc t and in the operating instruc tions

should be adhered to.

Follow instruc tions - All operating and users’ instructions shoul d be followed.

4.

Insta llation - Install in accordan ce with the manufacturer's instruc tions.

5.

Power sources - This product should be operated only from the type of power

6.

source indicated by the marking adjacent to the power cord entry. I f you are not
sure of the t ype of power supply to your home, consult your product dealer or local
power company.

7.

Grounding or polarization - the product is not required to be grounded. Ensure

that the pl ug i s fu lly inserted into the wall outlet or extension cord recep ta cl e to
prevent blade or pin exposure. Some versions of the product are equipped with a
power cord fitted with a polarized alternating line plug (a plug having one blade
wider than the other). This plug will fit onto the power outlet o nl y on e way. This is a
safet y feature. If you a re unable to inser t the plug f ul ly i nto the outlet, tr y reversing
the plug. I f th e plug should still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polarized plug. When using
an extension power-supply cord or a power-supply cord other than th at supplied
with the appliance, it should be fitted with the appro pr iate molded plugs and carr y
safet y ap proval appropriate to the country of use.

Power cord protection - Power-supply cords should be routed so that they are not

8.

likely to b e walked on, k inked or pinched by items placed on or against them,
pay ing particular attenti on to cords from plugs, receptacles and the point where
they exit from the product.

Overloading - Do not overload wa ll o utlets, extension cords, or m ultiple sockets, as

9.

this can result in a risk of fire or electric shock .

Ventilation - The produc t must be properly ventilated. Do not place the product on

10.

a bed, sofa, or other similar sur face. D o not cover the product with any items such as
tablecloths, newspapers, etc.

36

LS 178-1

11.

Heat - The product should be situated away from heat sources such as radiators,

heat registers, stoves, or other prod uc ts, in cl uding amplifiers that produce heat. No
naked flame sources, such as lighted candl es, should be placed on the apparatus.

12.

Water and moisture - To reduce the r isk of fire or electri c sh ock, do not expose the

product to train, dripping, splashing or excessive moisture such as in a sauna or
bathroom. Do not use this product near water, for example, near a bathtub,
washbowl, k itchen sink, laundry tub, in a wet basement or near a swimming pool (or
similar).

Objec t and Liquid Entr y - Never push objects of any kind into this produc t through

13.

openings, as they may touch dangerous voltage points or shor t-circuit parts that
cou ld result in a fire or electric shock. Never spill liquid of any kind on the product.
Do not place any object containing liquid on top of the product.

Cleaning - Unplug the product from the wall outlet before cleaning. Dust in the

14.

woofer may be cleaned with a dry cloth. I f you wish to use an aerosol cleaning spray,
do not spray directly on the cabinet; spray onto the cloth. Be careful not to damage
the drive u nits.

15.

Attachments - Do not use attachments not recommended by the product

manufacturer, as they may cause hazards.

16.

Accessories - Do not place this product on an unstable car t, s ta nd, tripod, bracket

or table. The product may fall, causing serious injury to a child or adult, and serious
damage to t he product. Use only with a cart, stand, tripod, bracket or table
recommended by the manufacturer or sold with the product. Any mounting of the
product should follow the manufacturer’s instructions and should use a mounting
accessory recom me nded by the manufact urer.

Moving the product - A product and cart combination should be moved with care.

17.

Quick stops, excessive force and uneven sur faces may cause the product and cart
com bi nation to overturn.

Unused periods - The power cord of the appliance should be unplugged from th e

18.

outlet during lightni ng s torms or when the apparatus is left unused for a long
period of time.

19.

Servicing - Do not attempt to ser vice this produ ct yours el f, as opening or removing

covers may expose yo u to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
Pleas e remove the power plug form the main power source or wall power source

20.

when not in use. When plugged in to a power source, the system is in stand by mode,
so the power is not entirely cut off.

Replacement parts - When replacement parts are required, ensure that t he ser vice

21.

tec hn ic ian has used replacement parts specified by the manufacturer or have the
same charac teristics as the origina l pa rt. Unauthorized substitutions may result in
fire, electric shock or other hazards.

Mains f uses - For continued protection against fire hazard, use fuses only of the

22.

cor rect type and rating. The correct fuse specification for each voltage range is
marked on the product.
Do not turn up the volu me w hi le listening to a section with ver y low level inputs or

23.

no audio signals. If you do, the s pe ak er may be damaged when a peak level section
is suddenly played.

37

LS 178-1

The o nl y means of completely disconnecting the product from the power supply is

24.

by removing the power cord from the wall outlet or the produc t. The wall outlet or
the power cord entry to the product must remain free ly a ccessible at all times while
the product is in use.
Try to install the product near a wall socket or extension cord and shall be easily

25.

accessible.

26.

The h ig hest environmental te mp erature suitable for this product is 35°C.

ESD hints - The normal function of the product may be disturbed by strong Electro-

27.

Magnetic Interference. If so, simply reset the p roduct to resume normal operation
by following the instruction manual. In case the function could not resume, please
use the product in other location.

Battery

28.

1).

The b atteries must not be exposed to excessive heat such as sunshine, f ire or
the like.
The b atteries should be drawn to the environmental aspects of batter y

2).
disposal.

3).

Battery usage CAUTION-to prevent b attery leakage which may result in body
injuries, property damage, or damag e to the apparatus:
Install all batteries cor rectly, + and – as marked on the apparatus.
Do not mix batter ie s (o ld a nd new or carb on and alk aline, etc.)
Remove batteries when the unit is not used for a long time.

ERP2 - (Energy Related Products) note

Thi s produc t wi th ecodesign complies with the stage 2 requirements of Commission
Regulation (EC) NO. 1275/2008 implementing Directive 2009/125/ EC regard to standby
and off mode electric power consumption of elec tronic household and office equipment.
After 60 minutes without any audio input, the device will automatically switch into
standby mode. Follow up the instruction manual to resume the operation.

Important note:

Thi s de vice is equipped with an energy saving mode: if no signal is given during 60
minutes t he device will switch automatically into standby mode in order to save energy
(ERP 2 standard). Please note that low volume setting in the audio source may be
recognized as “no audio signal”: this will affect the capability of signal detection from the
device an d can also ori ginate an automatic switch into standby mode. If this happens
please reac tivate the audio signal transmission or incre as e th e volume setting on the
audio source player (MP3 player, etc.), in order to resume playback. Please contact the
local service center if the problem remains.

The B lu etooth® word mark and logos are registered trademarks ow ned by Bluetooth SIG,
Inc. and any use of such marks by us is under license. Other trademarks and trade names
are those of their respective owners.

38

LS 178-1

Warning

Thi s ap pliance is not intended for use by persons (including children) with reduced
physical sensor y or mental ca pa bi lities, or lack of experience and knowledge, unless they
have been given supervision or instruct io n concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that th ey d o not play
with the appliance.

1.

To prevent possible hearing damage, do not listen at high volume levels for long
time periods respec tively a sudden high volume level.

2.

Never use the device unsupervised! Switch off the device whenever yo u are not
using it, even if this only for a short while.
The a pp liance is not intended to be operated by means of an external timer or

3.
separate remote control system.
If the supply cord is damaged, it must be replaced by the manufacturer, its ser vice

4.
agent or si mi la rly qual if ie d persons in order to avo id a h az ard.

5.

Before operating this system , ch ec k the voltage of this system to see if it is identical
to th e voltage of your local power supply.
The u ni t should not be impeded by covering the ventilation opening with items

6.
such as newspaper, table -cloths, curtains etc. Make sure that there are at least 20
cm of space a bove and at least 5 cm of space on each side of the unit.
The a pp aratus must not be exposed to dripping or splashing and that objects filled

7.
with liquids, such as vases, must not be placed on the apparatus.
To prevent fire or shock hazard, d o no t expose this equipment to hot places, rain,

8.
moisture or dust.
Do not locate this unit near any water sources e.g. taps, bathtubs, washing

9.
machines or swimming po ol s. Ensure that you place the unit on a dr y, stable
surface.

10.

Do not place this uni t cl os e to a strong magnetic field.
Do not place the unit o n a am pl ifier or receiver.

11.

12.

Do not place this uni t in a d am p area as the moisture will affec t the life of elec tric
com po ne nts.

13.

If the system is brought directly from a cold to a war m lo cation, or is placed in a very
damp room, moisture may condense on the lens inside th e pl ayer. If this occurs, th e
sys tem will not operate properly. Please leave the system turned on fo r ab out an
hour unti l th e mo isture evaporates.
Do not atte mpt to clean the unit with chemical solvents as this might da ma ge t he

14.
finish. Wipe with a clean, dry or slightly damp cloth.
When removing the power plug from the wall outlet, always pull di rectly o n th e

15.
plug, never pull on the cord.
The m ai ns plug is used as the disconnect device, the disconnect device must

16.
remain readily operable.

39
