Blaupunkt Car Multimedia User Manual

Car Multimedia 2005/2006

www.blaupunkt.com

The advantage in your car.

It’s not whether you win or lose, it’s how you play the game. As long as you’re one of the winners.

Each new win raises

the bar: for you as well as for

us. We are well aware of this, not only

because we have come out winning the

tests conducted by trade magazines time and

again, but because we are also an official spon-

sor of the German Touring Car Masters. And we always use the experience we gain in our pioneering technological advances to make you a winner,

too. Take radio reception in CD quality, for example.

Traffic congestion avoidance thanks to proactive

navigation. Travel entertainment and sound

experience customised to meet your specific

needs. Our drive for perfection is reflec-

ted in all Blaupunkt’s products.

And that makes everyone

a winner.

2/3

Introduction

1932 – the first

car radio. 1957 – the first tran-

sistor radio. 1969 – the first stereo radio.

1974 – ARI. 1982 – the first turn-by-turn route

guidance system. 1983 – the first CD player. 1988 –

the first RDS radio. 1989 – the first European naviga-

tion system. 1991 – TIM: Traffic Information Memory.

1994 – DSA: Digital Signal Adaptation. 1996 – the first

fully digital radio. 1997 – the first TMC radio. Digital

Radio/DMB. 1998 – traffic telematics. 1999 – the first pro-

active, dynamic navigation system. 2001 – the first digital

radio with MP3 and MMC. The first MP3 unit with 1 GB. The

first WAP-enabled off-board navigation system incl.

sound and telephone. 2002 – the TwinCeiver. 2003 –

digital recording function. 2004 – the first dynamic,

proactive navigation system with “optimal

route” and CD sound at the same time.

Ultra-flat speakers with front

neodymium magnets.

You’ll find

out what your advantage in

the car is when you take a look

towards the bottom of this page. From

the very first car radio to the first radio-

based navigation system with the “optimal

route” function, we can look back proudly on a

long list of innovative accomplishments. And

if you now take a look to the right, you’ll see

the innovations you have to look forward to.

Whether it’s sound or entertainment, radio

or a navigation system, mobile com-

munications or information: with

Blaupunkt, you’ll always be

right out in front.

Product Guide

Navigation

In Car Entertainment

MP3 Tuners

CD Tuners

13|84 Vancouver CD35 13|84 Bristol CD35 45|84 Kiel CD35 45|85 Malaga CD35

Cassette Tuners

45|85 Ravenna C32

Digital Radios

20|26|85 Woodstock DAB 54

Sound

48|56|62|89 Velocity-Series 50|89 Amplifiers 58|89 Subwoofers 64|90 Speakers

57|62 OD-Series 59|90 Subwoofers 66|90 Speakers

49|53|57|63 GT-Series 53|89 Amplifiers 61|90 Subwoofers 69|91 Speakers

70– 71 Antennas and Accessories

72– 81 Technology

82– 91 Product Overview

User Guide

Fun | 6 – 13 More fun with mobile entertainment

MP3 and CD Tuners

Bremen MP74 Seattle MP74 Acapulco MP54 Calgary MP35 Barcelona MP35 London MP35 Kingston MP35 Madrid MP35 San Diego MP35 Vancouver CD35 Bristol CD35

In Car Entertainment | 30 – 41 More enjoyment with multimedia

Navigation

Chicago IVDN-7003 Aspen IVDN-7003

Multimedia

Chicago IVDM-7003 Aspen IVDM-7003

DVD

DVD ME4

TV Tuner and Signal Controller

IVTV-03, IVSC-5502, IVSC-3302, IVSC-1102

Monitors

IVMS-5802, IVMS-6502, IVMR-7002, IVMR-9002, IVMR-1042, IVMR-1542

Performance | 14 – 21 More fascination with technology and design

Navigation

TravelPilot E TravelPilot E

MP3 Tuners, Digital Radios

Bremen MP74 Acapulco MP54 Woodstock DAB 54

Basic | 42 – 45 More features at the entry level

MP3, CD and Cassette Tuners

Essen MP35 Brighton MP35 Kiel CD35 Malaga CD35 Ravenna C32

Business | 22 – 29 More convenience with mobile communications

Navigation

TravelPilot DX-V Chicago IVDN-7003 Aspen IVDN-7003

Digital Radios, MP3 Tuners

Woodstock DAB 54 Los Angeles MP74 Seattle MP74

Sound | 46 – 69 More enthusiasm for great sound

Amplifiers | Subwoofers | Speakers

Velocity-Series OD-Series TH-Series GT-Series

4/5

Contents

6/7

Fun

Fun – Are you in the market for an attractive, new passenger in your vehicle?

Good music

demands good sound. And

that always goes hand-in-hand

with the best possible reception.

Brilliant sound and rich volume.

Perfectly matched components. And

that means technology that is – and

stays – state-of-the-art. And then

there’s individual sound con-

figuration. And it’s all

Blaupunkt.

Fun

MP3 and CD Tuners.

Bremen MP74

The TwinCeiver Bremen MP74, a digital twin receiver with a Digital Directional Antenna (DDA), is clearly the top choice for individualists with the most exacting demands on sound and tuner performance. It is equipped with a four-channel, self-adjusting equalizer with a total of 108 bands and delivers

richly detailed, differentiated, well-balanced sound. It is also possible to adjust all 108 bands on your PC – to reflect your own personal tastes and to accommodate the conditions in your specific vehicle interior. Experience listening pleasure in a new dimension.

Vario

Colour

connectivity

Fun

Seattle MP74

The Seattle MP74 with the Digital DigiCeiver is equipped with a DEQmaxEX equalizer with a self-adjusting function that enables it to determine perfect sound all on its own. Thanks to the digital, self-adjusting parametric 5-band equalizer, you’ll

enjoy differentiated range of sound that can be individually adjusted to accommodate the vehicle acoustics. You can also choose from three key variocolor illuminations; green, red and amber, which make the Seattle look perfect in your dashboard.

Acapulco MP54

The Acapulco MP54 with an MP3-enabled CD drive and DEQmaxEX, a digital, fully parametric, self-adjusting 5-band equalizer, is state-of-the-art in terms of technology as well as looks. Real sound freaks can now use the PC connection to

adjust all the sound parameters on their PCs and the VarioColour display is a delight to the eyes. You can select exactly the display colour you want from more than 4,000 shades.

connectivity

Vario

Colour

Fun

MP3 and CD Tuners.

Nowadays, it’s hard to imagine in-vehicle sound without MP3 sound files. The advantages are obvious: not only is there a diverse range of storage media, you’ve got a choice of different playback devices as well. The most important argument in favour of this technology, however, is the compression standard used for music files, based on the MPEG1 standard –

which gives you hours of music listening enjoyment. And a new interface also makes it possible to connect an iPod, the mobile MP3 player from Apple®. The unique VarioColour feature also offers a great deal of flexibility in looks: 4,096 different shades of colour enable you to match up the radio perfectly to virtually any vehicle dashboard.

Calgary MP35

Barcelona MP35

Aux-in

4-Channel

Preamp-out

4 x45 W

4-Channel

Preamp-out

Equalizer

Fun

London MP35

Kingston MP35

4-Channel

Preamp-out

4-Channel

Preamp-out

Vario

Colour

Speech

output

Vario

Colour

Sub out

Fun

Madrid MP35

Equalizer

Remote Control

4 x45 W

Aux-in

4-Channel

Preamp-out

San Diego MP35

4-Channel

Preamp-out

MP3 Tuners.

Fun

Vancouver CD35

Aux-in

Sound

Presets

Bristol CD35

CD tuners from Blaupunkt exhibit convincing technology with their high-quality, shock and shake-proof CD drives, easy operation and high functionality. The Sound Preset feature, for example, lets you set the ideal frequency response for different

types of music (rock, pop and classical) at the touch of a button. The convenient 4-channel preamp out provides reliable control for external amplifiers and different connection options make it possible to add to your music system.

4-Channel

Preamp-out

Aux-in

Sound

Presets

4-Channel

Preamp-out

CD Tuners.

We just keep raising

the bar, for sound as well as

for navigation. And our claim to the

technical sophistication of our pro-

ducts is also reflected in their modern,

ergonomic design. Advances that we

prove time and again with Digital Radio,

MP3 playback or the TwinCeiver. With

Blaupunkt, you experience the best

ever Car Multimedia. With all

your senses.

Performance – See it with your own two ears.

14/15

Performance

Get to your destination quicker and more conveniently than ever before.

Precise, reliable route guidance with traffic congestion ahead avoidance is good. Individual navigation – with a setting option to combine the quickest and the shortest route – is better.

And being able to listen to music at the same time – CD or MP3 – means technology of the finest.

The TravelPilot E , the TravelPilot E ’s big brother, is equipped to perfection in terms of technology as well as looks. Enjoy MP3 sound or your favourite CD, while you take advantage of the dynamic corridor function to get wherever you’re going on the optimal route without a traffic jam in sight. Thanks to house number interpolation, the TravelPilot E not only finds the best way to the street

you’re looking for, it takes you directly to the front door. Just insert the Europe navi CD to get you to virtually any destination in Europe. Precise navigation with optional speed signal hook-up (easy to install). Easy installation in just three steps: remove the old system – connect the new one and attach the GPS antenna – slide the Travel-Pilot E right in. You’re done!

Display illumination in white Key pad illumination in white

Display illumination in blue Key pad illumination in red

Display illumination in white Key pad illumination in red

Start/Finish corridor

Shortest route

Quickest route

Optimal route

Performance

The TravelPilot E has been making it easy to go into the navigation mode since 2004. Thanks to a new chip concept, this navigation system is excellent value for money. The TravelPilot E started off as the first radio-based navigation system with optimal route guidance (combination of quickest and shortest route) and a dynamic corridor function.

And while you are listening to your favourite CD, the TravelPilot E gets you to your destination, quickly and reliably. The TravelPilot E is also able to boast easy installation in just three steps thanks to the optional speed signal hook-up.

Other CDs including Major Roads:

Benelux E 2005, Germany E 2005, France E 2005 (incl. Monaco), Great Britain/Ireland E 2005, Italy E 2005 (incl. San Marino and Vatican City), Austria/Switzerland E 2005 (incl. Liechtenstein), Poland (from summer 2005), Czech Republic E 2005, Portugal/Spain E 2005 (incl. Andorra), Scandinavia E 2005 (incl. Denmark, Sweden, Norway and Finland)

Features based on the Germany CD:

• Detailed road network in Germany

• Major connecting roads in: France, Belgium, the Netherlands, Luxembourg, Italy, Great Britain, Ireland, Austria, Switzerland, Portugal, Spain, Norway, Sweden, Denmark, Finland, Andorra, Liechtenstein, San Marino, Vatican City and Monaco

• Dynamic navigation in Germany, Austria, Belgium, Denmark, France, Italy, the Netherlands, Sweden, Switzerland and Spain

• Destination input in Germany via postal codes (complete coverage in Germany)

• More than 260,000 Points of Interest, such as airports, motorways, border crossings, city centres and petrol stations right on up to fast-food restaurants and much more

• Compatible with the TravelPilot E , TravelPilot E

Performance

The Blaupunkt Bremen MP74 is the first car radio to have made it to “autohifi” magazine’s reference class, a prestigious award given by Europe’s well respected Car hifi magazine. Thanks to a self-adjusting equalizer (DSA Max) with 108 bands, which can also be adjusted individually, you’ll experience optimal sound at the touch of a button. And we even added an interface (PC connection) to connect the car radio with a PC so that you

can display all the sound settings conveniently on a large screen while you adjust them in real time. A TwinCeiver equipped with two DSP-based receivers puts the finishing touch on perfect radio reception. The TIM speech memory makes it possible to store traffic messages lasting a total of four minutes, and, last but not least, the high-resolution full-graphic display with VarioColour makes for a fantastic all-round package.

Two of a kind.

Bremen MP74

Vario

Colour

connectivity

Performance

The automatic DEQmaxEX self-adjusting equalizer is the heart of the Acapulco MP54 DigiCeiver. It can optimize the system’s sound at the touch of a button. Or use the PC connection to fine-tune the system’s sound performance on your computer

yourself. This car radio sports a very elegant look, featuring a VarioColour display. Select your favourites from among 4,096 colours and 16 coloured night design shades.

Acapulco MP54

connectivity

Vario

Colour

Performance

Digital Radio – the future on board.

Woodstock DAB 54

The Woodstock DAB 54 digital radio features a professional design with a high-resolution full-graphic display and sophisticated technology. Interference-free listening pleasure in CD quality is guaranteed by digital reception on the DigiCeiver. A one-of-a-kind digital recorder lets you record your favourite

song on an SD/MMC card even when you’re already on the road. And don’t fret if you missed the first few seconds – thanks to Blaupunkt technology, your recording will be complete from start to finish every time.

Performance

Services

With Digital Radio, you can now display additional information visually. Information on the radio programme that is automatically broadcast with the radio signal, for example, can be shown in a display. This service can be specifically related to

the current programme (e. g. song title, artist and CD cover for title currently played) or completely independent of it (e. g. news, weather, traffic, timetables, stock market information, tips).

PDA

Use your Personal Digital Assistant (PDA) in combination with Digital Radio to take advantage of a wide variety of services. Bluetooth technology and an optional interface connect your PDA with the digital radio. And you can download the DAB browser from the Blaupunkt website free of charge.

For more information, go to www.digitalradio.de

Business – Even leaders sometimes need a little guidance.

You’ll always know

where you are going with navi-

gation systems from Blaupunkt.

Proactive. Dynamic. Quick and precise.

Simply bypass any traffic congestion ahead

as easily as you insert a CD. And if you like,

you can let your feelings be your guide. As far

as the music is concerned, that is. After all,

this is where you’re in complete control –

with top class sound, easy handling and

future proof technology. In short:

Blaupunkt keeps you heading in

the right direction.

22/23

Business

In full view: Navigation.

TravelPilot DX-V

The TravelPilot DX-V high-end navigation system with an infrared remote control system and wide screen monitor puts on a convincing show in its clear-cut design and 16: 9 format. Proactive navigation with dynamic route guidance and traffic

congestion avoidance via TMC keeps you fully informed all the time. Detailed map displays with different views and a split screen show you everything you need to know at a glance.

Perfect input with the help of the Operating Assistant.

The on-board computer shows you such details as average speed or driving time any time you want.

Select between the arrow or map display or use both at once.

You’ll always know exactly where to find the next hotel, restaurant or petrol station.

Traffic congestion is automatically taken into consideration in route guidance.

Decide for yourself whether or not to avoid motorways, toll roads or ferries.

Steering wheel remote control optional

Hand-held remote control included

Business

Chicago IVDN-7003

In combination with the TravelPilot DX-V navigation computer, the Aspen IVDM-7003 also turns out as a full-fledged multimedia navigation system with an easy-to-follow route and map display.

The addition of the TravelPilot DX-V navigation computer transforms the Chicago IVDM-7003 into a convenient navigation package. The different displays on the easy-to-read 7” monitor help you to get where you’re going, quickly and directly.

DX-TravelGuide CDs with travel-guide function:

Michelin

• Benelux

• France

• Germany

• Great Britain

• Spain/Portugal

De Agostini

•Italy

MERIAN scout

• Alps

• France

• Germany

• Germany Executive

• Germany Sport & Leisure Time

•Italy

TravelGuide information on:

• Hotels

• Restaurants

• Petrol stations

• Points of interest

• Car parks

• Banks

• Hospitals

• Distance indicator

• Credit cards accepted

• Operas

• Museums

• Bars

• Post offices

• Police

• Airports

• Concert halls

• Tennis courts

• Adventure/ amusement parks

• Trade shows

Aspen IVDN-7003

Business

For Business as Usual.

Blaupunkt sets new standards in terms of speed and precision in the business segment. Anyone travelling on business needs information, up-to-date and easy-to-access. And the same high demands are made of entertainment quality. Much of our equipment meets the highest business standards: with its

revolutionary DigiCeiver concept, Blaupunkt offers unparalleled FM reception quality in your car. And the Woodstock DAB 54 is already equipped with the reception standard of the future – Digital Radio. Thanks to the digital recorder, you can even record music on a SD/MMC card from DAB while you’re on the

Woodstock DAB 54

Bluetooth technology makes it possible to connect your PDA (Personal Digital Assistant) to the Woodstock DAB 54. A DAB browser for the PDA can be downloaded from the Blaupunkt website free of charge.

4 x 50 W

Business

road. From start to finish – even if you missed the first few seconds. As another extra feature, you can also connect a Personal Digital Assistant (PDA) with a touch screen and Windows CE operating system. With Bluetooth technology and an optional interface, it can be connected with your

Woodstock DAB 54 to keep you right up to date wherever and whenever. A DAB browser for your PDA can be downloaded from the Blaupunkt website free of charge.

Business

A Perfect Combination of Style and Technology.

With its high-resolution full-graphic display, the Los Angeles MP74 offers you all the information you need at a glance. The tuner with an MP3-enabled CD drive exhibits outstanding sound characteristics and enhanced reception thanks to unique DigiCeiver technology. The digital, self-adjusting, fully parametric DEQmaxEX 5-band equalizer determines the

optimal sound for your vehicle on its own. The flip-release panel is motorised. And thanks to VarioColour, you have more than 4,000 colours to choose from to match your display background colour to the dashboard in your vehicle. The steering-wheel remote control comes as standard, it’s easy to use without distracting you from the traffic situation.

VarioColour

You decide what colour the display of your Los Angeles MP74 should have. Car radios equipped with VarioColour offer you a selection of 4,096 different shades and a colour scan function

at the touch of a button for a wide variety of design options – either matching your instrument cluster or just for fun.

Los Angeles MP74

Vario

Colour

connectivity

+ 64 hidden pages

Blaupunkt Car Multimedia User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
