DSR® x02x/x03x Switch Appliances
Release Notes
Version 3.x.x.17
12 April 2006
This document outlines:
1. Update Instructions
2. Appliance Firmware Version and Language Support Information
3. Enhancements
4. Fixes
5. Known Issues
6. Flash Update Failure Recovery
=============================================================================
Update Instructions
=============================================================================
Please refer to your user manual for detailed instructions to update the Appliance.
=============================================================================
Appliance Firmware Version and Language Support Information
=============================================================================
The following DSR Switch Appliances are supported with this update:
Switch Version English Spanish French German Italian
DSR1021
3.2.0.17 FL0397.fl FL0399.fl FL0398.fl FL0400.fl FL0401.fl
DSR1022
DSR1024 3.2.0.17 FL0377.fl N/A N/A N/A N/A
DSR1031 3.2.0.17 FL0438.fl FL0446.fl FL0447.fl FL0445.fl FL0444.fl
DSR1020
3.6.2.17 FL0344.fl FL0381.fl FL0382.fl FL0383.fl FL0384.fl
DSR2020
DSR4020
DSR8020 3.2.0.17 FL0428.fl FL0430.fl FL0429.fl FL0431.fl FL0432.fl
DSR1030
3.2.0.17 FL0439.fl FL0442.fl FL0443.fl FL0441.fl FL0440.fl
DSR2030
DSR4030
DSR8030
DSR2035
3.2.0.17 FL0498.fl FL0501.fl FL0502.fl FL0500.fl FL0499.fl
DSR8035
=============================================================================
Enhancements
=============================================================================
This release contains the following enhancements:
1. AES Encryption-
Added support for AES encryption of keyboard and mouse, video and virtual media data. This is in
addition to the existing encryption levels already supported (DES, 3DES, 128-bit). AES encryption is
enabled by default for keyboard and mouse data. All encryption is disabled by default for video and
virtual media data. The On Board Web Interface (OBWI) supports AES Encryption.
2. Name SynchronizationThe appliance allows target device names and cascade switch names that are entered in DSView® 3
Management Software to be sent to the appliance and to the DSRIQ modules. If the appliance
receives a target device name or cascade switch name from DSView 3 software that is longer than 15
characters, the appliance will save the longer name, but truncate the name to 15 characters when
storing the name in the DSRIQ module or displaying the name in the OSCAR® graphical user
interface. The OBWI supports name synchronization.
3. Support for Server Technology Power Distribution Units (PDU):
Sentry Switched CDU CW-16V1
Sentry Switched CDU CW-16V2
Sentry Switched CDU CW-24V2
Sentry Switched CDU CW-24V3
Sentry Switched CDU CW-32VD1
Sentry Switched CDU CW-32VD2
Sentry Switched CDU CW-8H1
Sentry Switched CDU CW-8H2
The appliance will support up to two Server Technology PDUs, daisy chained using expansion
modules, connected to the port on the back of the appliance labeled “SPC”.
The OBWI will support Server Technology PDUs that have been licensed by DSView 3 software for
support by the appliance. The OBWI does not support adding Server Technology PDUs.
4. The OBWI supports access control for individual target devices.
5. The OBWI supports Simplified Chinese and Japanese languages.
6. The OBWI supports updating the DSR switch firmware via HTTP binary file upload.
7. The OBWI is now available on the DSR1031, DSR1030, DSR2030, DSR4030, and DSR8030
switches.
=============================================================================
Fixes
=============================================================================
This release contains the following fixes:
1. The ']' key on a Sun Japanese Keyboard is passed to the target device.
2. Added support for Acnodes KD-5154 keyboard/mouse.
3. (DSR1024 only) Keyboard Num Lock LED state properly updates following a remote video session.
4. Improved local port mouse performance.
=============================================================================
Known Issues
=============================================================================
This release contains no known issues.
=============================================================================
FLASH Update Failure Recovery
=============================================================================
1.Visit http://www.avocent.com/support and download the latest FLASH firmware from Avocent.
2.Save the FLASH update file to the appropriate directory on the TFTP server.
3.Set up the TFTP server with the server IP address 10.0.0.3.
4.Rename the download file to DSRxxx.fl (select from the following list) and place it into the TFTP
root directory of the TFTP server.
DSR1021.fl
DSR1024.fl
DSR1031.fl
DSRxx20.fl
DSRxx30.fl
DSRxx35.fl
5.If the DSR switch is not on, turn it on now.
6.The recovery process will start automatically.
NOTE: If you do not have a TFTP server, you can find several shareware and freeware programs on
the Internet that you can download and install.
