APC AP7003, AP7004 User Manual
NetworkAIR™ 1000
Portable
Air Conditioner
AP7003
AP7004
User’s Manual
®
Important Safety Information
Warni ng • Read these instructions carefully before using this air
conditioner.
• This air conditioner is designed for indoor use only.
The temperature range for the cooling mode is 61° F
to 86° F.
• To reduce the risk of fire or electric shock, do not
expose the unit to rain or moisture. Do not open the
cabinet while the unit is connected a power source.
Dangerous voltage is present. Have repairs
performed by certified
• Never use or store gasoline or other flammable vapor
or liquid near the unit.
• This air conditioner has no ventilator for taking in
fresh air from outdoors. You must open doors or
windows frequently when you use gas or oil heating
appliances in the same room, which consume a lot of
oxygen from the air. Otherwise, there is a risk of
suffocation in extreme cases.
• Do not use an adapter plug or extension cord.
• Do not use near gas appliances, open flames
(fireplaces) or in the vicinity of flammable liquids.
Caution • Do not operate this unit if it has a damaged cord or
plug, or if it is not working properly, or had been
dropped or damaged in any manner.
• To protect against risk of electrical shock, do not
immerse unit, cord or plug in water or any other
liquid.
• Do not cut or remove the third (ground) prong from
the power cord plug.
• If the plug gets hot, call a qualified electrician.
• Close supervision is required when the unit is used
near children.
• Do not stick anything into the air outlet of the air
conditioner.
• Do not use in a room with poor air circulation.
• Do not expose to direct sunlight.
• Do not use the unit near water.
HVAC technicians.
Contents
General Information . . . . . . . . . . . . . . . . . . . . . . . . 1
About NetworkAIR 1000 1
Inventory 1
Front View 2
Back View 2
Control Panel 3
LCD Indicators 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Warnings 5
Set up the unit 5
Check components 6
Power the unit 6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Power 7
Cooling 7
Dehumidify 7
Fan 7
Louver 7
Timer 8
Installing the Exhaust Kit . . . . . . . . . . . . . . . . . . . . 9
Drainage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Methods of Draining 11
Condensate Tank 11
Emptying the tank 12
The drainage tube 13
Maintaining the Unit . . . . . . . . . . . . . . . . . . . . . . 14
Clean the air filter 14
Clean the cabinet 14
Clean the condensate tank regularly 15
Storing the Unit 16
i
Contents continued
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . .17
Try this first 17
If problems persist 19
Warranty Information . . . . . . . . . . . . . . . . . . . . .20
Limited warranty 20
Warranty limitations 20
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
ii
General Information
A
About NetworkAIR 1000
APC’s NetworkAIR 1000 is a portable, compact, air-
conditioner designed for spot-cooling, emergency-cooling, and
after-hours cooling of server closets, data centers, conference
rooms, home offices, or rooms housing heat-sensitive
equipment.
The NetworkAIR 1000 provides 7,200
BTU (7,500 BTU for
AP7004) of cooling power. It automatically adjusts room
temperature, and reduces moisture while filtering the air.
Additional features of NetworkAIR 1000 include:
• Electronic control panel with LCD display
• Automatic turn-on/shut-off timer
• Automatic swing louvers for even air distribution in the
room
• Ceiling exhaust kit
• Quiet, high-efficiency rotary compressor
Inventory NetworkAIR 1000 is shipped with the items shown below:
Drain Tube
Ceiling
Adapter
Holder
Flange
NetworkAIR 1000
ir Conditioning Unit
Exhaust
Duct
Base
Flange
1
General Information continued
C
l
P
Washabl
Air Fil
Drain Val
Front View
ontrol Pane
Horizontal
Air Flow Guides
Vertical Swing
Louver
Handle
Water Tank
Back View
Caster
Exhaust Vent
ower Cord
& Plug
e
ter
ve
2
General Information continued
Control Panel
Power
Mode
Fan Speed
Louver
Temperature
Timer
Compressor
indicator
Tank Full
indicator
LCD Display
Turns the unit on and off.
Sets the desired operating mode:
fan, cooling, or dehumidifying.
Sets desired fan speed: high,
medium or low.
Directs the air distribution.
Sets the desired temperature (61°–
86°F).
Programs the timer for unattended
shutoff (up to 18 hours for
AP7003, 24 hours for AP7004).
Indicates that the compressor is
running when in cooling or
dehumidifying mode.
Indicates with flashing light and
buzzer that the condensate tank is
full or has not been positioned
correctly.
Displays information about
different modes and settings.
3
General Information continued
LCD Indicators
Temperature
Fan Mode
Cooling Mode
Dehumidify Mode
Louver On
Time r On/Off
Timer Setting
Fan Speed
Set Temperature
Note: Temperature is shown in
Celsius on the AP7004.
4
Installation
20 i
(50
Warni ng s Use the unit on a flat surface where the air outlets are
unobstructed.
Do not place the unit less that 20 inches (50 cm) away from
any wall or obstacle.
Do not install this air conditioner where there are fumes or
flammable gases, or in an extremely humid space such as a
green house.
n
cm
20 in
)(50 cm
Set up the unit 1. Unpack the unit and the accessory kit. Slip the bands off
the unit—do not cut the bands.
2. Inspect the unit and the accessories for damage.
)
Caution: If you find shipping damage, do not operate the
unit. If you have shipping damage, keep all
packaging for inspection by the shipper and call
APC Customer Support at a number listed on the
back cover of this manual.
Note: This unit should not be placed on its side. If it does
get tipped, place the unit upright on a flat, solid
surface and keep it in this position for a minimum
of two hours before operating.
5
