9-INCH ADVANCED NAVI STATION

X0 09

This HD Radio receiver enables:

• OWNER’S MANUAL Please read before using this equipment.

• MODE D’EMPLOI Veuillez lire avant d’utiliser cet appareil.

•MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo.

Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by registering your product now at the following address: www.alpine-usa.com/registration

. You will be informed of product and software updates (if applicable), special promotions, news about Alpine, and entered for a chance to win prizes.

Merci d’avoir acheté ce produit Alpine. Nous vous invitons à consacrer un moment à la protection de votre achat en enregistrant votre produit dès maintenant à l’adresse suivante : www.alpine-usa.com/registration

. Vous serez tenu informé des mises à jour des produits et des logiciels (le cas échéant), des promotions spéciales, de l’actualité d’Alpine, et vous aurez une chance de remporter des prix.

Gracias por adquirir este producto Alpine. Con solo unos pocos pasos podrá proteger su producto, registrándolo a través de la siguiente dirección: www.alpine-usa.com/registration

. Recibirá información sobre nuevos productos y software, promociones especiales, novedades sobre Alpine y participará en el sorteo de premios.

ALPINE ELECTRONICS OF AMERICA, INC.

19145 Gramercy Place, Torrance,

California 90501, U.S.A.

Phone 1-800-ALPINE-1 (1-800-257-4631)

68-24567Z68-A

ALPINE ELECTRONICS MARKETIN G, INC.

1-7, Yukigaya-Otsukamachi, Ota- ku,

Tokyo 145-0067, JAPAN

Phone: 03-5499-4531

ALPINE ELECTRONICS FRANCE S.A.R.L.

(RCS PONTOISE B 338 101 280)

98, Rue de la Belle Etoile, Z.I. Paris Nord Il,

B.P. 50016, 95945 Roissy Charles de Gaulle

Cedex, Fra nce

Phone 01-48638989

ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.

161-165 Princes Highway, Hallam

Victoria 3803, Australia

Phone 03-8787-1200

Wilhelm-Wagenfeld-Str. 1-3, 80807 München, Germany

ALPINE ELECTRONICS GmbH

Phone 089-32 42 640

ALPINE ELECTRONICS OF U.K. LTD.

Fletchamstead Highway, Coventry CV4 9TW, U.K.

Alpine House

Phone 0870-33 33 763

ALPINE ITALIA S.p.A.

Viale C. Colombo 8, 20090 Trezzano

Sul Naviglio (MI), Italy

Phone 02-484781

ALPINE ELECTRONICS DE ESPAÑA, S.A.

Portal de Gamarra 36, Pabellón, 32

01013 Vitoria (Alava)-APDO 133, Spain

Phone 945-283588

ENGLISH

Contents

Operating Instructions

PRECAUTIONS

IMPORTANT INFORMATION ....................... 8

WARNING

Points to Observe for Safe Usage ..................... 8

WARNING ................................................. 9

CAUTION .................................................. 9

NOTICE ................................................... 10

Discs Playable on This Unit ................. 11

Features

Auto user setting change ................................ 15

My Favorites ................................................... 15

Easy sound setting by car type

(i-Personalize) ............................................. 16

About Dual Screen ......................................... 16

Dual Screen Display Position ..................... 17

Getting Started

Accessory List ................................................ 18

Location of Controls ...................................... 18

Turning Power On or Off ............................... 19

Turning the System On ................................... 19

Initial System Start-Up ................................... 19

Inserting/Ejecting a Disc ................................ 19

Inserting the Disc ........................................ 19

Removing the Disc ...................................... 19

Adjusting the Screen Viewing Angle ............. 20

Adjusting the Volume ..................................... 20

Lowering Volume Quickly ............................. 20

Common Operations

Using My Favorites .........................................20

User Registration ............................................21

Setting My Favorites .......................................22

Adding My Favorites ...................................22

Editing My Favorites ...................................22

Displaying the Camera Image .....................23

i-Personalize Setup ......................................23

Easy Sound Setup mode/BASS ENGINE SQ

mode ............................................................24

Easy Sound Setup mode ..............................24

BASS ENGINE SQ mode ...........................24

Access to iDataLink Mode .............................25

Applying TuneIt ..............................................25

Adjusting the sound via the Smartphone .....25

Facebook Notification Function ..................25

Settings When Switching Users ......................27

How to Input Characters and Numbers

(Keypad) ......................................................27

Top banner and Bottom banner Fade Out

Setting ..........................................................28

Switching Sources ...........................................28

Screen Off Function .....................................28

Rear Entertainment Function ..........................29

Switching the Dual Screen Display ................29

Touch operation ..............................................29

Selecting an Item in a List ..............................29

About the Indicator Display ............................30

Radio/HD RadioTM/ RBDS

Listening to the Radio .....................................31

Presetting Stations Manually ..........................31

Presetting Stations Automatically ...................32

Tuning to Preset Stations ................................32

Forced Analog Mode ......................................32

Receiving a Multicast (HD Radio mode

only) .............................................................32

PTY (Program Type) Tuning (Analog

Broadcasts only) ..........................................32

Displaying Radio Text ....................................33

Storing the tag information (HD Radio mode

only) .............................................................33

About the Feature Logos .................................33

3-EN

CD/MP3/WMA/AAC

Playback .......................................................... 34

Repeat Play .....................................................34

M.I.X. (Random Play) .................................... 34

Selecting Folders (Concerning MP3/WMA/

AAC) ...........................................................35

Searching from CD Text ................................. 35

File/Folder Name Search (Concerning MP3/

WMA/AAC) ................................................ 35

About MP3/WMA/AAC .................................35

DVD

Playing a Disc ................................................ 37

If a Menu Screen Appears ........................... 38

Numeric Keypad Input Operations .............38

Displaying the Top Menu Screen ...............39

Displaying the Menu Screen ...................... 39

Stopping Playback (PRE STOP) ................... 39

Stopping Playback .........................................39

Fast-forwarding/Fast-reversing ...................... 39

Finding the Beginnings of Chapters/Tracks/

Files ............................................................ 39

Playing Still Frames (Pausing) ...................... 40

Forward frame-by-frame Playback ................40

Slow Motion Playback ...................................40

Selecting Folders ........................................... 40

Repeat Playback ............................................ 40

Searching by Title Number ............................ 41

Searching Directly by Chapter Number ........41

Searching for a Desired Video File ................ 41

Switching the Angle ...................................... 41

Switching the Audio Tracks ..........................42

Switching the Subtitles (Subtitle

Language) ................................................... 42

About DivX

..................................................42

Setup

Setup Operation

General Setup

General Setup Operation ................................43

iDataLink Setup .............................................. 43

Setting the Source Category ........................ 43

Setting the Hands-free Connection .............44

Setting the Default Vehicle Screen .............. 44

Setting the Maestro Module ........................ 44

Text Display Setting .......................................44

Setting the Scroll .........................................44

Format settings ............................................ 44

Setting the Menu Language ........................ 44

Remote Sensor Setting .................................... 44

Setting Top banner and Bottom banner

Display ........................................................44

Screen/LED Customize .................................. 45

Setting the Brightness of the

Backlighting .............................................45

Adjusting the Minimum Level of

Backlight ..................................................45

Adjusting the Dimmer of Button Lighting at

Night ........................................................45

Switching the Display Color ....................... 45

Adjusting the Touch Panel ..........................45

Initializing the Touch Panel Corrected

Values ....................................................... 45

Visual Setting ..................................................45

Switching Display Modes ........................... 46

Adjusting the Live Contrast ........................ 46

Selecting the Visual EQ Mode

(Factory’s setting) ....................................46

Adjusting Brightness ................................... 46

Adjusting Color of Picture .......................... 46

Adjusting Tint of Picture .............................46

Adjusting Image Contrast ...........................47

Adjusting Picture Quality ............................47

Saving and calling the adjusted picture

quality ......................................................47

About X009 .................................................... 47

Displaying the Product Information ............ 47

Checking the DivX

Initializing the System .................................47

Installation Setup ............................................48

Setting the External Audio Processor

On/Off ......................................................... 48

Setting the Digital Output ............................... 48

Registration ............... 47

4-EN

Sound Setup

Sound Setup Operation ................................... 48

Setting the Balance/Fader/Subwoofer ............ 49

Setting the Balance/Fader ............................ 49

Rear Speaker Setting ................................... 49

Turning Subwoofer ON/OFF ...................... 49

Adjusting the Subwoofer Level ................... 49

Setting the Subwoofer Phase ....................... 49

Setting the MX (Media Xpander) ...................49

Equalizer Presets ............................................. 50

Adjusting the Parametric Equalizer Curve

(Parametric EQ) ........................................... 50

Adjusting the Time Correction (Time

Correction) ..................................................51

Adjusting the Crossover Settings (X-Over) .... 52

Setting Defeat .................................................52

Volume Setting ................................................ 52

Setting the Volume for Each Source ............... 52

About Time Correction ...................................53

About the Crossover ....................................... 54

Source Setup

Source Setup Operation .................................. 55

Source Layout Setting .................................... 55

Setting the Slide Source Change ................. 55

Setting the Easy Sound Setup Position ....... 55

Customizing the Source Banner .................. 55

Disc Setting ..................................................... 56

Changing the language setting .................... 56

Setting of the Menu Language .................... 56

Setting of the Audio Language ................... 56

Setting of the Subtitle Language ................. 56

Changing the Country Code Setting ........... 56

Setting the Rating Level (Parental Lock) .... 56

Setting the TV Screen Mode ....................... 57

SiriusXM Setting ............................................ 58

Managing Artist, Song and Sports Team

Alerts ........................................................58

Setting the Favorite Sports Team Alerts ...... 58

Setting the Parental Lock ............................ 59

Signal Strength Information ........................59

Auxiliary (AUX) Setting ................................60

Setting the Auxiliary (AUX) Mode ............. 60

Setting the Primary Auxiliary (AUX) Name

(AUX 1 Setup) ......................................... 60

Setting the AUX3 ........................................60

Setting the AUX 3 Source Select (Switching

the Visual Input Signal System) ...............60

Rear Seat Entertainment (RSE) Setting .......... 60

Setting the Rear Seat Entertainment

System ......................................................60

Setting the Bluetooth Pandora

TuneIt Setting .................................................61

Setting the Communication Mode with a

Smartphone ..............................................61

Bluetooth Setup

Bluetooth Setup Operation ............................. 61

Setting Hands-free Connection of

iDataLink .....................................................62

Bluetooth Setting ............................................ 62

Displaying Bluetooth Information .................. 62

Registering the Bluetooth Device ................... 62

Automatic Connection setting ........................ 63

Setting the Passcode ....................................... 63

Changing the Character Code of the Phone

Book ............................................................63

Selecting the Output Speaker ......................... 63

Adjusting the Caller Volume .......................... 63

Adjusting the Microphone Level .................... 63

Adjusting the Ring Tone Volume ................... 63

Deleting All the Histories ............................... 63

Camera Setup

Camera Setup Operation .................................64

Direct Camera Setting ....................................64

Setting the Camera Input .............................64

AUX Camera Setting ...................................... 65

Setting the Camera Input .............................65

Camera Interrupt Setting (Power OFF

Mode) ..........................................................66

Reverse Mute Setting ...................................... 66

......................61

Bluetooth Operation

Setup Before Using ......................................... 67

About Bluetooth ..........................................67

About the Hands-Free Phone ......................67

Before Using Bluetooth ............................... 67

5-EN

Hands-Free Phone Control

Connecting a Bluetooth Device ...................... 67

Disconnecting the Bluetooth

Connection ...............................................67

Changing the connecting Bluetooth

Device .......................................................... 68

Answering a Call ............................................68

Adjusting ringtone volume ..........................68

Hanging up the Telephone ..............................68

Calling ............................................................68

Using Short Cut Dialing to Make a Call ..... 68

Dialing a Number In Call History ............... 68

Dialing a Number In the Phone Book ......... 69

Entering a Phone Number to Make a Call ...69

Redial Function ........................................... 69

Using Voice Recognition function .................. 69

Using Siri ....................................................69

Voice Dial Function ..................................... 70

Operations During a Conversation ................. 70

Adjusting the Speech Volume ..................... 70

Changing the Voice Output ......................... 70

DTMF (Touch-Tone) Function .................... 70

Phone Book Function .....................................71

Synchronizing the Phone Book ................... 71

Adding the Phone Book .............................. 71

Deleting the Phone Book Entries ................ 71

Assigning as a Short Cut Dialing Number .....72

Bluetooth Audio

Playback .......................................................... 72

Repeat Play .....................................................73

M.I.X. (Random Play) .................................... 73

Selecting Groups .............................................73

Search Function ..............................................73

Playing the iDataLink- Bluetooth Audio

Auxiliary Device (Optional)

Operating Auxiliary Devices (Optional) ........74

Operating an External DVD Player ................ 74

Change to the External DVD Mode ............74

About the DVD Operation Screen ............... 74

Operating an External DVD Changer ............. 75

Change to the External DVD Changer

Mode ........................................................75

About the DVD Changer Operation

Screen .......................................................75

Operating the Mobile Digital TV Receiver

(DVB-T) ...................................................... 76

Changing to the Mobile Digital TV Receiver

(DVB-T) Mode ........................................76

About the DVB-T operation screen .............76

Operating a TV ...............................................76

Change to the TV mode .............................. 76

About the TV operation screen ................... 76

Camera Operation (Optional)

Rear Camera Operation ..................................77

Displaying the rear view video while the car

is in reverse ..............................................77

Displaying the rear view video manually .... 77

Switching the Image Pattern for the Rear

Camera .....................................................77

Guide Display ON/OFF Setting .................. 77

Adjusting the Caution Display Location ..... 77

About the Rear Camera Guide ........................ 78

Front Camera Operation ................................. 80

Displaying the Front View Video

Manually ..................................................80

Switching the Image Pattern for the Front

Camera .....................................................80

About the adjustment of guide display

ON/OFF setting and adjustment of Caution

display location ........................................80

Other Camera Operation .................................80

About the adjustment of the Caution display

location ....................................................80

SiriusXM Satellite Radio Operation

(Optional)

Receiving Channels with the SiriusXM

Tuner ...........................................................81

Tuning Channels by Category ........................ 81

Changing the Display ..................................... 81

Checking the SiriusXM Radio ID Number ....82

Storing Channel Presets ..................................82

Tuning Channels using Presets .......................82

Tune Start Function ........................................82

Tune Scan Function ........................................82

Search Function ..............................................83

Selecting the Channel directly ........................83

Storing the desired Song/Artist ....................... 83

Receiving and Tuning to an Alert ................... 84

Replay Function .............................................. 84

Parental Lock Function ...................................84

Using Jump Memory and Jump Recall

function .......................................................84

6-EN

Storing the Tag information ............................85

Playing the iDataLink SiriusXM .................... 85

Flash Memory (Optional)

Playback .......................................................... 86

Repeat Play .....................................................87

Random Play (M.I.X.) ....................................87

Random Play (M.I.X. ALL) ........................... 87

Searching for a Desired Song ......................... 87

File/Folder Name Search .............................87

Tag Search ...................................................88

Direct Up/Down Function .............................. 88

Select the desired Folder (Folder up/down) .... 88

Playing the iDataLink USB/iPod .................... 88

iPod/iPhone (Optional)

Playback .......................................................... 90

Searching for a Music File .............................. 90

Searching for a Desired Video File ................. 91

Alphabet Skip Function ..................................91

Direct Up/Down Function .............................. 91

Search Position Memory ................................91

Repeat Play .....................................................92

Random Play (Shuffle) ...................................92

Random Play (Shuffle All) ............................. 92

END USER LICENSE AGREEMENT

(Microsoft) ................................................105

END USER LICENSE AGREEMENT

(NAVTEQ) ................................................107

Installation and Connections

Warning ................................................ 108

Caution ................................................. 108

Precautions .......................................... 108

Installation ....................................................109

Connections ..................................................111

System Example ...........................................114

LIMITED WARRANTY

HDMI Device (Optional)

Pandora® internet radio (optional)

Listening to Pandora® ..................................... 93

iPhone Pandora Bluetooth Pandora

“Thumbs” Feedback .......................................94

Searching for a Desired Station ...................... 94

Creating a New Station ................................... 94

QuickMix ........................................................94

Bookmarking a Desired Track or Artist .........95

......................................... 93

..................................... 93

Information

Product Software Update ................................95

About DVDs ...................................................95

List of Language Codes .................................. 97

List of Country Codes .....................................98

In Case of Difficulty .....................................100

If this Message Appears ...............................101

Specifications ................................................104

7-EN

Operating Instructions

If there is anything in the manual about the operation of

PRECAUTIONS

IMPORTANT INFORMATION

PLEASE READ CAREFULLY BEFORE USING THIS PRODUCT

This product is intended to provide turn by turn instructions to get you to a desired destination. Please make certain that all persons using this navigation system carefully read these precautions and the following instructions fully.

• This product is not a substitute for your personal judgment. Any route suggestions made by this navigation system may never supersede any local traffic regulations or your personal judgment and/or knowledge of safe driving practices. Do not follow route suggestions if the navigation system instructs you to perform an unsafe or illegal maneuver, places you in an unsafe situation, or routes you into an area which you consider unsafe.

• Glance at the screen only when necessary and safe to do so. If prolonged viewing of the screen is necessary, pull over in a safe and legal manner and location.

• Do not input destinations, change settings, or access any functions requiring a prolonged view of the monitor and/or remote control while you are driving. Pull over in a safe and legal manner and location before attempting to access the system.

• Do not use the navigation system to route you to emergency services. Not all locations of emergency services such as police and fire stations, hospitals and clinics are contained in the database. Please use your own judgment and ask for directions in these situations.

• The map database used in the navigation system is the most recent map data available at the time of production. Because of changes in streets and neighborhoods, there may be situations where the navigation system is not able to route you to your desired destination. In these cases, use your own judgment.

• The map database is designed to provide you with route suggestions and does not take into account the relative safety of a suggested route or of factors which may affect the time required to reach your destination. The system does not reflect road closures or construction, road characteristics (i.e. type of road surface, slope or grade, weight or height restrictions, etc.), traffic congestion, weather conditions, or any other factors which may affect the safety or timing of your driving experience. Use your own personal judgment if the navigation system is unable to provide you with an alternate route.

• There may be situations where the navigation system displays the vehicle’s location erroneously. Use your own driving judgment in this situation, taking into account current driving conditions. Please be aware that in this situation the navigation system should correct the vehicle’s position automatically. However, there may be times where you may have to correct the position yourself. If this is the case, pull over in a safe and legal manner and location before attempting operation.

• Make certain that the volume level of the navigation system is set to a level which still allows you to hear outside traffic and emergency vehicles.

the navigation system which you are uncertain about, please contact your local Alpine authorized navigation dealer or Alpine at 1-888-NAV-HELP (1-888-628-4357) before using the navigation system.

FCC COMPLIANCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide more reasonable protection against harmful interference in a residential installation, and are more stringent than “outdoor” requirements.

Operation is subjected to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, you are encouraged to try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult an experienced radio/TV technician.

WARNING

Points to Observe for Safe Usage

• Read this manual carefully before using this disc and the system components. They contain instructions on how to use this product in a safe and effective manner. Alpine cannot be responsible for problems resulting from failure to observe the instructions in this manual.

• This manual uses various pictorial displays to show you how to use this product safely and to alert you to potential dangers resulting from improper connections and operation. Following are the meanings of these pictorial displays. It is important to fully understand the meanings of these pictorial displays in order to use this manual and the system properly.

8-EN

WARNING

DO NOT DISASSEMBLE OR ALTER.

Doing so may result in an accident, fire or electric shock.

• Operation of the system while driving is dangerous. Users

should stop vehicle before operating the software.

• Road conditions and regulations take precedence over information contained on the map display: observe actual traffic restrictions and circumstances while driving.

• This software is designed for use exclusively in the X009. It cannot and may not be used in conjunction with other hardware.

WARNING

This symbol means important instructions. Failure to heed them can result in serious injury or death.

INSTALL THE PRODUCT CORRECTLY SO THAT THE DRIVER CANNOT WATCH TV/VIDEO UNLESS THE VEHICLE IS STOPPED AND THE EMERGENCY BRAKE IS APPLIED.

It is dangerous (and illegal in many states) for the driver to watch TV/Video while driving a vehicle. Installing this product incorrectly enables the driver to watch TV/Video while driving. This may cause a distraction, preventing the driver from looking ahead, thus causing an accident. The driver or other people could be severely injured.

DO NOT WATCH VIDEO WHILE DRIVING.

Watching the video may distract the driver from looking ahead of the vehicle and cause an accident.

DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.

Any function that requires your prolonged attention should only be performed after coming to a complete stop. Always stop the vehicle in a safe location before performing these functions. Failure to do so may result in an accident.

USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.

(Check with your dealer if you are not sure.) Failure to do so may result in fire, etc.

KEEP SMALL OBJECTS SUCH AS SCREWS OUT OF THE REACH OF CHILDREN.

Swallowing them may result in serious injury. If swallowed, consult a physician immediately.

USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES.

Failure to do so may result in fire or electric shock.

DO NOT BLOCK VENTS OR RADIATOR PANELS.

Doing so may cause heat to build up inside and may result in fire.

USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.

Use for other than its designed application may result in fire, electric shock or other injury.

DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN INSERTION SLOTS OR GAPS.

Doing so may result in personal injury or damage to the product.

CAUTION

This symbol means important instructions. Failure to heed them can result in injury or material property damage.

HALT USE IMMEDIATELY IF A PROBLEM APPEARS.

Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Center for repairing.

DO NOT FOLLOW ROUTE SUGGESTIONS IF THE NAVIGATION SYSTEM INSTRUCTS YOU TO PERFORM AN UNSAFE OR ILLEGAL MANEUVER, OR PLACES YOU IN AN UNSAFE SITUATION OR AREA.

This product is not a substitute for your personal judgment. Any route suggestions by this system should never supersede any local traffic regulations or your personal judgment or knowledge of safe driving practice.

KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR OUTSIDE NOISES WHILE DRIVING.

Excessive volume levels that obscure sounds such as emergency vehicle sirens or road warning signals (train crossings, etc.) can be dangerous and may result in an accident. LISTENING AT LOUD VOLUME LEVELS IN A CAR MAY ALSO CAUSE HEARING DAMAGE.

MINIMIZE DISPLAY VIEWING WHILE DRIVING.

Viewing the display may distract the driver from looking ahead of the vehicle and cause an accident.

KEEP FINGERS AWAY WHILE THE MOTORIZED FRONT PANEL OR MOVING MONITOR IS IN MOTION.

Failure to do so may result in personal injury or damage to the product.

9-EN

NOTICE

Product Cleaning

Use a soft dry cloth for periodic cleaning of the product. For more severe stains, please dampen the cloth with water only. Anything else has the chance of dissolving the paint or damaging the plastic.

Temperature

Be sure the temperature inside the vehicle is between +45°C (+113°F) and 0°C (+32°F) before turning your unit on.

Moisture Condensation

You may notice the disc playback sound wavering due to condensation. If this happens, remove the disc from the player and wait about an hour for the moisture to evaporate.

New Discs

To prevent the disc from jamming, “Disc error” is displayed if discs with irregular surfaces are inserted or if discs are inserted incorrectly. When a new disc is ejected immediately after initial loading, use your finger to feel around the inside of the center hole and outside edge of the disc. If you feel any small bumps or irregularities, this could inhibit proper loading of the disc. To remove the bumps, rub the inside edge of the hole and outside edge of the disc with a ballpoint pen or other such instrument, then insert the disc again.

Center Hole

Bumps

Center Hole

New Disc

Outside (Bumps)

Damaged Disc

Do not attempt to play cracked, warped, or damaged discs. Playing a bad disc could severely damage the playback mechanism.

Maintenance

If you have problems, do not attempt to repair the unit yourself. Return it to your Alpine dealer or the nearest Alpine Service Station for servicing.

Never Attempt the Following

Do not grip or pull out the disc while it is being pulled back into the player by the automatic reloading mechanism. Do not attempt to insert a disc into the unit when the unit power is off.

Inserting Discs

Your player accepts only one disc at a time for playback. Do not attempt to load more than one disc. Make sure the label side is facing up when you insert the disc. “Disc error” will be displayed on your player if you insert a disc incorrectly. If “Disc error” continues to be displayed even though the disc has been inserted correctly, push the RESET switch with a pointed object such as a ballpoint pen. Playing a disc while driving on a very bumpy road may result in skips, but this will not scratch the disc or damage the player.

Installation Location

Make sure the X009 will not be installed in a location subjected to:

• Direct sun and heat

• High humidity and water

• Excessive dust

• Excessive vibrations

Correct Handling

Do not drop the disc while handling. Hold the disc so you will not leave fingerprints on the surface. Do not affix tape, paper, or gummed labels to the disc. Do not write on the disc.

CORRECT

INCORRECT CORRECT

Disc Cleaning

Fingerprints, dust, or soil on the surface of the disc could cause the DVD player to skip. For routine cleaning, wipe the playing surface with a clean, soft cloth from the center of the disc to the outer edge. If the surface is heavily soiled, dampen a clean, soft cloth in a solution of mild neutral detergent before cleaning the disc.

Irregular Shaped Discs

Be sure to use round shaped discs only for this unit and never use any special shaped discs. Use of special shaped discs may cause damage to the mechanism.

10-EN

Disc Accessories

There are various accessories available on the market for protecting the disc surface and improving sound quality. However, most of them will influence the thickness and/or diameter of the disc. Using such accessories can cause operational problems. We recommend not using these accessories on discs played in Alpine DVD players.

Transparent Sheet Disc Stabilizer

Operation of some of the functions of this unit is very complex. Because of this, it was deemed necessary to place these functions into a special screen. This will restrict operation of these functions to times when the vehicle is parked. This ensures the focus of the driver’s attention will be on the road and not on the X009. This has been done for the safety of the driver and passengers. Setup operations cannot be made if the car is moving. The car must be parked and the parking brake must be engaged for the procedure described in the Owner’s Manual to be valid. The warning “If you are driving, Please pull over before using this function.” will be displayed if any attempts are made to perform these operations while driving.

• The X009 draws minimal current even when its power switch is

turned off. If the switched power (ignition) lead of the X009 is connected directly to the positive (+) post of the vehicle’s battery, the battery may be discharged. An SPST (Single-Pole, Single-Throw) switch (sold separately) can be added to simplify this procedure. Then, you can simply place it in the OFF position when you leave the vehicle. Turn the SPST switch back ON before using the X009. For connecting the SPST switch, refer to the “Connection Diagram of SPST Switch (sold separately)” (page 110). If the power (ignition) lead is unswitched, it must be disconnected from the battery post should the vehicle be left unused for an extended period of time.

Discs Playable on This Unit

Playable Discs

The discs listed below can be played on this unit.

Mark (logo) Recorded Content Disc size

DVD Video Audio + Video 12 cm*

Music CD Audio 12 cm

DivX

* Two-layer DVD disc compatible

The formatted discs listed below can be played on this unit.

CD Format

MP3 Format (“mp3”)

WMA Format (“wma”)

AAC Format (“aac”, “m4a”)

Audio + Video 12 cm

CD-R/

CD-RW

DVD-R/

DVD-RW

DVD+R/

DVD+RW

DVD Video Format

DivX Format (“avi”, “divx”)

• Discs that are not finalized cannot be played back.

11-EN

Discs that cannot be played

DVD-ROMs, DVD-RAMs, CD-ROMs (excluding MP3/WMA/ AAC files), photo CDs, etc.

DualDisc

This unit is not compatible with DualDisc. Using a DualDisc may cause unit malfunction, and may cause disc damage when the disc is inserted/ejected.

DVD region number (playable region number)

This DVD player will play back any disc whose region number is 1 (or All). DVDs with a region number other than those listed below, cannot be played on this DVD player.

ALL

Using compact discs (CD/CD-R/CD-RW)

If you use unspecified compact discs, correct performance cannot be guaranteed. You can play CD-Rs (CD-Recordables)/CD-RWs (CDReWritables) which have been recorded only on audio devices. You can also play CD-Rs/CD-RWs containing MP3/WMA/AAC formatted audio files.

• Some of the following discs may not play on this unit: Flawed discs, discs with fingerprints, discs exposed to extreme temperatures or sunlight (e.g., left in the car or this unit), discs recorded under unstable conditions, discs on which a recording failed or a re-recording was attempted, copy-protected CDs which do not conform to the audio CD industry standard.

• Use discs with MP3/WMA/AAC files written in a format compliant with this unit. For details, see pages 35 and 36.

To customers using CD-R/CD-RW

• If a CD-R/CD-RW cannot be played back, make sure the last recording session was closed (finalized).

• Finalize the CD-R/CD-RW if necessary, and attempt playback again.

Tips for making your own discs

The X009 plays DVD Video, DivX®, Audio CD and has a built in MP3/WMA/AAC decoder.

The following information is designed to help you create your own music CDs (either Audio CD or MP3/WMA/AAC encoded CD-R/ RW files).

What is the difference between an Audio and MP3/WMA/AAC CD?

An Audio CD is the same format as the commercial CDs you buy in the store (also known as CD-DA). MP3 (MPEG Audio Layer 3)/ WMA (Windows Media Audio)/AAC (Advanced Audio Coding) is a data file that uses a compression scheme to reduce the size of the music file*. * If the first session on a disc containing both CD-DA data and

MP3/WMA/AAC data is a CD-DA file, only CD-DA files will be played.

Multisession CD-R/RW:

Once a recording has been stopped, this is considered one session. If the disc is not closed (finalized), additional data may be added. Once this additional data has been recorded, this becomes a “multisession” CD.

Properly formatted MP3/WMA/AAC Discs:

Use ISO9660 formatting to insure proper playback. You may use standard ISO naming Level 1 (8.3 DOS standard), Level 2 (32 characters) or Joliet (Windows or Macintosh long filenames) file naming conventions*.

* Please consult the Owner’s manual for additional information.

On handling compact discs (CD/CD-R/CD-RW)

• Do not touch the surface.

• Do not expose the disc to direct sunlight.

• Do not affix stickers or labels.

• Clean the disc when it is dusty.

• Make sure that the disc is smooth and flat.

• Do not use commercially available disc accessories.

Do not leave the disc in the car or the unit for a long time. Never expose the disc to direct sunlight.

Heat and humidity may damage the disc and you may not be able to play it again.

12-EN

Using DVD-Rs/DVD-RWs/DVD+Rs/DVD+RWs

• This unit is compatible with discs recorded in the standard DVD-Video format.

• Note that discs not finalized (processed to enable to play on playback-only DVD players) cannot be played on this DVD player.

• Some discs may not play back, depending on the recording device and disc format.

• Discs or files utilizing copy protection, may not be playable. Some recording systems may not properly format copied files to enable proper playback.

• In the following cases, the disc may not play on this unit: discs recorded by certain DVD recorders, certain irregular discs, flawed discs, dirty discs, when the pickup lens of this DVD player is dirty, or when moisture condensation has occurred inside the unit.

• Be sure to follow all cautions included with your DVD-Rs/ DVD-RWs/DVD+Rs/DVD+RWs discs.

• Do not put stickers, seals, or tape on the label side of DVD-Rs/ DVD-RWs/DVD+Rs/DVD+RWs.

• Compared to the regular discs, DVD-Rs/DVD-RWs/DVD+Rs/ DVD+RWs are more affected by heat, moisture, and direct sunlight. If left in a car, etc., damage may occur and it might not play on this unit.

• The operable temperature range for disc playback is as follows: DVD-R/DVD-RW: -25 ~ +70°C DVD+R/DVD+RW: +5 ~ +55°C

Disc terminology

Title

If titles are programmed for the DVD, these are the largest units of division of the information recorded on the disc.

Chapter

Each Title may also be divided into smaller divisions, called chapters. These can be specific scenes or musical selections.

Protecting the USB connector

• Only an iPod/iPhone or Flash memory can be connected to the USB connector on this unit. Correct performance using other USB products cannot be guaranteed.

• If the USB connector is used, be sure to use only the supplied connector cable with the unit. A USB hub is not supported.

• Depending on the connected Flash memory device, the unit may not function or some functions may not be performed.

• The audio file format that can be played back on the unit is MP3/WMA/AAC.

• The video file format that can be played back on the unit is

DivX

• Artist/song name, etc., can be displayed. Certain, special characters may not be correctly displayed.

CAUTION

Alpine accepts no responsibility for lost data, etc., even if data, etc., is lost while using this product.

On Handling Flash memory

• This unit can control a memory storage device that supports the USB Mass Storage Class (MSC) protocol. Playable audio file formats are MP3, WMA and AAC.

• Flash memory function is not guaranteed. Use Flash memory according to the terms of agreement. Read the Flash memory Owner’s Manual thoroughly.

• Avoid usage or storage in the following locations:

Anywhere in the car exposed to direct sunlight or high temperatures. Anywhere the possibility of high humidity or corrosive substances are present.

• Fix the Flash memory in a location where driver operation will not be hindered.

• Flash memory may not function correctly at high or low temperature.

• Use only certified Flash memory. Note that even certified Flash memory, may not function correctly depending on its type or state.

• Depending on the settings of the Flash memory type, memory state or encoding software, the unit may not play back or display properly.

• Files protected by DRM (Digital Rights Management), cannot be played back on this unit. These include AAC formatted files purchased from the iTunes Store and WMA or other files with some form of copyright protection.

• Flash memory may take time to start playback. If there is a particular file other than audio in the Flash memory, it may take considerable time before the file is played back or searched.

• The unit can play back “mp3”, “wma” or “m4a” file extensions.

• Do not add the above extensions to a file other than audio data. This non-audio data will not be recognized. The resulting playback may contain noise that can damage speakers and/or amplifiers.

• It is recommended to back up important data on a personal computer.

• Do not remove the USB device while playback is in progress. Change SOURCE to something other than USB, then remove the USB device to prevent possible damage to its memory.

13-EN

• This item incorporates copy protection technology that is

protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

• Manufactured under license from Dolby Laboratories. Dolby

and the double-D symbol are trademarks of Dolby Laboratories.

• Windows Media, and the Windows logo are trademarks, or

registered trademarks of Microsoft Corporation in the United States and/or other countries.

• iPhone, iPod, iPod classic, iPod nano, iPod touch, and iTunes

are trademarks of Apple Inc., registered in the U.S. and other countries.

• “Made for iPod,” and “Made for iPhone,” mean that an

electronic accessory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, or iPhone may affect wireless performance.

• Pandora, the Pandora logo, and the Pandora trade dress are

trademarks or registered trademarks of Pandora Media, Inc., used with permission. Pandora is currently available in the U.S., Australia and New Zealand.

• HD Radio Technology manufactured under license from iBiquity

Digital Corporation. U.S. and Foreign Patents. HD Radio™ and the HD, HD Radio, and “Arc” logos are proprietary trademarks of iBiquity Digital Corp.

• Sirius, XM and all related marks and logos are trademarks of

• BlackBerry

trademarks, names and logos are the property of Research In Motion Limited and are registered and/or used in the U.S. and countries around the world. Used under license from Research In Motion Limited.

• Android is a trademark of Google Inc.

• DivX

Rovi Corporation or its subsidiaries and are used under license.

• The Bluetooth

owned by the Bluetooth SIG, Inc. and any use of such marks by Alpine Electronics, Inc. is under license.

• The terms HDMI and HDMI High-Definition Multimedia

Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

• MPEG Layer-3 audio coding technology licensed from

Fraunhofer IIS and Thomson. Supply of this product only conveys a license for private,non-commercial use and does not convey a license nor imply any right to use this product in any commercial (i.e. revenue-generation) real time broadcasting (terrestrial, satellite, cable and/or any other media), broadcasting/streaming via internet, intranets and/or other networks or in other electronic content distribution systems, such as pay-audio or audio-on-demand applications. An independent license for such use is required. For details, please visit http://www.mp3licensing.com

, RIM®, Research In Motion® and related

, DivX Certified® and associated logos are trademarks of

word mark and logos are registered trademarks

14-EN

Features

Auto user setting change

With the X009, you can register up to two users. Each user can configure their own preferred settings. By registering their respective Bluetooth devices to the unit, each user can be identified automatically.

USER1 USER2

USER2

USER1

• For details of how to register a Bluetooth device, refer to “User Registration” (page 21).

• If USER2 is recognized while USER1 is using the system, a confirmation message is displayed.

• If no Bluetooth device has been registered or if you want to switch users manually, touch the user tab key on the top of the screen.

• For details of which settings are affected by switching users, refer to “Settings When Switching Users” (page 27).

My Favorites

Up to 80 My Favorites can be registered as shortcut keys for each registered user. Frequently used functions and handy functions can be customized for your convenience.

USER1 USER2

For details of how to register or add My Favorites, how to change the name, etc., refer to “Using My Favorites” (page 20).

15-EN

Easy sound setting by car type (i-Personalize)

This function lets you set the best audio environment for your car. On the unit, select and set the car category/steering wheel position/speaker type and size/seat material. For details of how to configure the settings, refer to “Car Specific Sound Setup” (page 23).

Display example when setting is completed

About Dual Screen

If you want to display the music playback screen while route guidance is displayed, etc., you can display the Navigation and Audio/Visual screens simultaneously.

Navigation Full screen

Touch the Navigation screen portion.

Press the (NAV) button.

Dual Screen

Touch

Audio/Visual Full screen

Touch *

Press the AUDIO button.

During video playback, [Dual Wide], [Dual Full] and [Full Screen] appear on the screen for selecting the screen size. For details, refer to “Switching the Dual Screen Display” (page 29).

16-EN

Dual Screen Display Position

You can switch the Audio/Visual and Navigation screens using drag & drop. To switch the screens, touch the middle of the Audio/Visual screen and drag it to the navigation screen. The screens will switch positions when you remove your finger.

• Drag and drop the navigation screen will change to navigation full screen.

17-EN

Getting Started

Accessory List

• X009.....................................................................................1

• GPS Antenna .......................................................................1

• Antenna mounting plate ......................................................1

• Cable clamp for antenna................................................1set

• AUX/PRE OUT cable ...........................................................1

• CAMERA/W.REMOTE cable ................................................1

• USB extension cable ...........................................................1

• SD memory card..................................................................1

• Cushion................................................................................1

• Screw (M5×8) ......................................................................8

• Owner’s Manual ..............................................................1set

Location of Controls

For GMC/Chevrolet

For Universal

• This is only an example illustration, about the name and layout of

buttons, please refer to your vehicle.

Microphone*

Used for Hands-Free or Voice Control modes.

(My Favorites/iDataLink mode) button

The My Favorites screen for registered User1 or User2 is displayed. Press and hold this button for at least 3 seconds to switch to iDataLink mode. You can check the car’s status, set the air condition, etc,. when this unit is connected to the car’s iDataLink module box.

AUDIO button

Displays the Audio/Visual screen. If the Audio/Visual screen is already displayed, changes the source. Press and hold this button for at least 3 seconds to activate the “Easy Sound Setup mode” (page 24). You can select this menu to be displayed on the left or right of the screen. For details, refer to “Setting the Easy Sound Setup Position” (page 55).

/ (for GMC/Chevrolet) or -/+ (for Universal)

button

Press to adjust the volume.

(Mute) button

Press to activate/deactivate the mute mode. Press and hold this button for at least 3 seconds to turn the power off.

RESET switch*

The system of this unit is reset.

c (Eject) button

Dimmer Sensor/Remote Sensor

• Sense the brightness of the car interior.

• Point the remote control transmitter towards the remote

sensor within a range of 2 meters.

(iDataLink mode) button*

Press this button to switch to iDataLink mode.

(NAV) button

Recalls the navigation map screen. Press again to switch to Navigation menu screen. Press and hold this button for at least 3 seconds to change to Go Home route screen. If the Home is not set yet, it will change to Home setting screen. For details of navigation operations, refer to “Navigation System OM” in the CD-ROM.

(PHONE) button

Recalls the Telephone Menu screen. When a hands-free phone with Voice Recognition is connected, press and hold for at least 3 seconds to switch to the Voice Recognition mode.

CAM (Camera) button*

Press to display rear camera image. Press again to return to normal screen.

Auxiliary Input connector (AUX INPUT)*

Input auxiliary device’s Video/Audio signal. Correct wiring should be done before use this connector. For details, refer to “Connections” section.

* Only for GMC/Chevrolet or other model.

Optional Remote Control Interface Box

This unit is operable using the vehicle’s secondary radio controls. An Alpine Remote Control Interface Box (optional) is required. For details, contact your Alpine dealer.

Controllable with Remote Control

This unit can be controlled with an optional Alpine remote control. For details, consult your Alpine dealer. Point the optional remote control transmitter at the remote control sensor.

About the button descriptions used in this Owner’s Manual

The buttons found on the face of the unit are expressed in bold (e.g. (My Favorites)). The buttons found on the touch-screen display are shown in bold within brackets, [ ] (e.g. []).

18-EN

Turning Power On or Off

Initial System Start-Up*

Some of this unit’s functions cannot be performed while the vehicle is in motion. Be sure to stop your vehicle in a safe location and apply the parking brake, before attempting these operations.

Turn the ignition key to the ACC or ON position.

The system turns on.

• When turned on, the system displays the last mode screen that

was displayed before the ignition key was turned off. For example, if the unit is in radio mode when ignition is turned off, it will remain in radio mode when ignition is turned back on.

Press and hold the button for at least 3 seconds to turn the power off.

• The unit can be turned on by pressing any button.

• The X009 is a precision device. Careful handling of the unit should

provide you with years of trouble-free operation.

Turning the System On

With the Alpine system, when the ignition key is turned to ACC or ON, the opening screen will be automatically displayed.

When the system is used for the first time, the language selection menu is displayed. There are 24 languages to choose from. Touch [] or [] to scroll the list, and then touch the desired language.

* Only for GMC/Chevrolet or other model. Be sure to press the RESET switch when using the unit for the first time, after changing the car battery, etc.

Turn off the unit power.

Press RESET switch with a ballpoint pen or similar pointed object.

RESET switch

Inserting/Ejecting a Disc

Inserting the Disc

Press c (Eject).

The Open/Tilt screen is displayed.

Touch [c Disc].

• You can also scroll through lists by touching the screen and

sliding your finger up and down.

Touch [OK].

The radio screen is displayed.

• Some of this unit’s functions cannot be performed while the vehicle is

in motion. Be sure to stop your vehicle in a safe location and apply the parking brake before attempting these operations.

Insert the disc with the label side facing up.

SD memory card slot*

Insert the disc until it is automatically pulled into the unit. The unit starts to play the disc.

* The SD memory card does not support Music/Video playback.

For details on how to use SD memory cards, refer to “Navigation system OM” on the supplied CD-ROM.

• To remove the SD memory card, touch [ SD].

• Insert the SD memory card into the slot until it is locked.

If the SD memory card is not inserted properly, the monitor cannot be closed.

Disc Slot

Removing the Disc

Press c (Eject).

The Open/Tilt screen is displayed.

Touch [c Disc].

The monitor will open. Then the disc is ejected. When the disc has been ejected part way, take it out.

• Even if no disc is inserted, the monitor will open after touching

[c Disc].

19-EN

Touch [Close], or press any button.

• If the disc does not eject after touching [c Disc], press and hold c (Eject) for at least 5 seconds.

• Do not apply shock to the monitor when it is open as it may result in malfunction of the unit.

• The monitor will stop at the set tilt angle when closing.

Common Operations

Using My Favorites

CAUTION

Keep hands (or any other object) away from the monitor while it is opening or closing to avoid damage or injury. The back of the monitor tends to become very warm under normal operating conditions. This is not a malfunction, but care should be taken to avoid prolonged contact with it.

Adjusting the Screen Viewing Angle

Adjust the screen’s angle for better visibility.

Press c (Eject).

The Open/Tilt screen is displayed.

Touch [Up] or [Down] of “Tilt” to adjust the desired screen angle.

The screen angle can be adjusted in 5 stages.

Touch [] to return to the normal mode.

• The screen color will vary when viewed at certain angles. Adjust the screen angle for the best viewing position.

• If the voltage of the vehicle’s battery power is low, the screen may blink when the screen angle is changed. This is normal and not a malfunction.

Adjusting the Volume

Adjust the volume by pressing or .

Volume decreases/increases continuously by pressing and holding or . Volume: 0 - 35

Display example of My Favorites screen

User name: Displays the name of the user My Favorites icon: Touching an icon on My Favorites screen will switch to the screen for the selected application Add button: Use to add (register) My Favorites icons (page 22) Edit button: Use to edit My Favorites (page 22) Camera button: Use to display the camera image (page 23) Notification List button: Use to display the Notification List from Facebook in the connected Smartphone via this unit (page 25) i-Personalize button: Use to configure the i-Personalize Setup (page 23)

Lowering Volume Quickly

Activating the Audio Mute function will instantly lower the volume level by 20 dB.

Press to activate the MUTE mode.

The audio level will decrease by about 20 dB.

Pressing again will bring the audio back to its previous level.

20-EN

User Registration

You can register up to two users. Configure the User1 and User2 settings for each user.

Press the (My Favorites) button.

The My Favorites screen is displayed.

• You cannot access My Favorites screen while driving.

Touch [Search].

Touch [Start].

The user name input screen for the first user is displayed.

• After registering the first user, touch [USER2] to access to

USER2’s registration screen.

• Touching [Skip] registers the user name as “USER1” or

“USER2” and no Bluetooth device is registered. In this case, the users will not be switched automatically.

• Touching [Cancel] or pressing the (My Favorites) button

returns to the original screen without registering a user.

Input the user name from the keypad and touch [OK].

The system starts searching for Bluetooth devices. When the search is completed, the Bluetooth Device List is displayed.

• Set the Bluetooth setting on the preregistered Bluetooth device

side to [ON].

Touch a registered Bluetooth device and touch [OK].

My Favorites screen for USER1 or USER2 is displayed.

• You can edit My Favorites icons.

For details of how to add, edit, delete or set My Favorites icons, refer to “Adding My Favorites” (page 22).

Press the (My Favorites) button.

The My Favorites screen is exited and the display returns to the original screen.

The Bluetooth Device Setup screen is displayed.

• Touch [ ] to edit the name.

For details of how to input characters from the keypad, refer to “How to Input Characters and Numbers (Keypad)” (page 27).

Touch [Link], then touch [OK].

The Bluetooth Device List is displayed.

• The Bluetooth devices registered here are used to automatically

identify the user. Also, a cellular phone can be used as a hands-free phone. For details, see “Bluetooth Setting” (page 62).

• Touching [Do not Link] exits user registration without

registering a Bluetooth device.

21-EN

Setting My Favorites

Configure the My Favorites settings.

Press the (My Favorites) button.

My Favorites screen for USER1 is displayed.

• You cannot access My Favorites screen while driving.

• [ ] and [ ] are not available while driving.

• To configure My Favorites settings for USER2, touch [USER2]. The

My Favorites screen is displayed.

[SiriusXM] :

You can register presets No. 1-6 in SiriusXM1, SiriusXM2 and SiriusXM3. Select presets No. 1-6 from SiriusXM1 preset/SiriusXM2 preset/SiriusXM3 preset.

[Disc]/[USB/iPod]/[iDataLink USB/iPod]/[HDMI]/[Pandora]/ [Bluetooth Pandora]/[iDataLink SiriusXM]/[AUX 1]/ [AUX 2]/[AUX 3]/[Bluetooth Audio]/[iDataLink Bluetooth Audio] : You can switch directly to any of these audio

sources.

Editing My Favorites

You can delete names in My Favorites or change the layout.

Adding My Favorites

You can register up to 80 My Favorites for each user. You cannot, however, register the same items (categories).

Touch [].

The addition items (categories) are displayed.

Touch the desired addition item (category).

Current position : Registers your current position in My Favorites Current source

Favorites

• During Radio, CD, etc., main screen, you can directly register the

playing source to My Favorites by touching [ ]. The [ ] will not display when the current source is already registered.

Navigation

search category in My Favorites

[Specific Place] : You can display the places registered in My Favorites and set your destination. Search for a place registered in My Favorites by Address/ Find Place/Address Book/History, then touch Add.

[Quick Place search] : Displays the address search keypad [Help Nearby] : Displays the nearby search screen [POI category] : Displays the selected POI category list

• For details of navigation operations, refer to “Navigation System OM” in the CD-ROM.

Phone

My Favorites for shortcut dialing. Select a name or phone number from the Phonebook list and touch [Add].

• Touch [

• You can only select Phone when a mobile phone is connected.

Audio/Visual

[Radio] :

: Registers the audio source currently playing in My

: Registers the destination search category or nearby place

: Lets you register phone numbers stored in the phonebook in

] or [B] to switch phone numbers.

: Lets you switch directly to an audio source

HD Radio/RBDS: You can register presets No. 1-6 in FM1/ FM2/AM. Select presets No. 1-6 from FM1 preset/FM2 preset/AM preset.

Touch [].

“ ” appears and the mode switches to the Edit mode.

• Touching [Cancel] returns to the previous screen without executing

any changes.

Changing the name

Touch the icon you want to change

The Edit Text screen (Keypad) is displayed.

Enter the name and touch [OK]

The mode returns to the Edit mode.

Touch [OK].

The name is changed.

Deleting Icons

Touch “ ” by the icon you want to delete

The confirmation message is displayed.

Touch [OK].

The mode returns to the Edit mode.

Touch [OK].

My Favorites setup

You can change or delete the current registered user name or change the registered phone number.

Touch [Setup].

The My Favorites Setup screen is displayed.

22-EN

Changing the User Name

Touch the [Name] of the current user.

The Input User Name screen (Keypad) is displayed.

Input the name and touch [OK].

The user name is changed.

• For details of how to input characters using the keypad, refer to

“How to Input Characters and Numbers (Keypad)” (page 27).

Changing a Bluetooth device

You can change the Bluetooth devices associated with the user.

Touch the [Phone].

The Bluetooth Device Setup screen is displayed.

Touch [Link], then touch [OK].

The Bluetooth Device list is displayed.

• The Bluetooth device set by User Registration is highlighted.

For detailed settings, touch [Search].

Select the device you want to change and touch [OK].

The device is changed.

Deleting current Registered User

Touch [Delete].

The confirmation message is displayed.

Touch [OK].

• When the registered user is deleted, all the items affected by switching users are returned to the default settings.

Displaying the Camera Image

When a separately purchased camera is connected to the system, you can display the camera image.

Touch [] or [].

The camera image is displayed.

• For details of camera operations, refer to “Camera Operation

(Optional)” (page 77).

• When the front camera (direct camera) and rear camera or side

camera (AUX camera) are connected simultaneously, the screen for selecting which camera image to display appears.

• Depending on the setting, the camera button may not be displayed.

For details, refer to “Setting the Camera Input” (page 64).

i-Personalize Setup

You can configure the audio settings by car type.

• You cannot access to i-Personalize screen while driving.

Touch [i-Personalize]*.

The i-Personalize Setup screen is displayed.

Changing the Layout

You can change the layout of the shortcut keys.

Drag and drop the icon to the desired location.

Touch [OK].

* This item cannot be adjusted when External Audio Processor is set to

On or BASS ENGINE SQ mode is selected, refer to “Setting the External Audio Processor On/Off” (page 48) / “BASS ENGINE SQ” mode (page 24).

Car Specific Sound Setup

You can set the best audio environment for your car.

Touch [Car Specific Sound Setup].

The vehicle type selection screen is displayed.

Touch the relevant Vehicle type.

• The selected Vehicle type is reflected in the “i-Personalize”

symbol on My Favorites screen.

Touch the position of the driver’s seat.

Touch the size of the front speaker.

Select whether or not there is a tweeter.

23-EN

Select the installation position of the rear speaker.

If you select “No rear speaker”, you cannot adjust the rear speaker in Time Correction/X-Over in sound setup.

Select whether or not there is a subwoofer.

If you select “No”, you cannot adjust the subwoofer level/ subwoofer phase in sound setup.

• If Preset3 was already saved for Time Correction/X-Over/Parametric

EQ, the data will be overwritten.

Easy Sound Setup mode/BASS ENGINE SQ mode

Select the material of the car seats.

The settings confirmation screen is displayed.

• If the car seats are made of both leather and fabric, select

[Half leather].

Check the settings and touch [OK].

• If Preset3 was already saved for Time Correction/X-Over/Parametric EQ, the data will be overwritten.

• The Easy sound settings are reflected in the following Audio Setup items. Setting the MX (Media Xpander)

- Adjusting the Parametric Equalizer Curve (Parametric EQ)

Adjusting the Time Correction (Time Correction) Adjusting the Crossover Settings (X-Over) (only when Subwoofer is set to [On])

The Equalizer Presets settings are disabled.

Downloaded Sound Settings

Using a Flash memory device, the sound settings downloaded from the ALPINE website can be used to configure Time Correction, X-Over and Parametric EQ settings.

Setting item: Downloaded Sound Settings

The file name of download data shall be “A_U*****.MP3”.

Extender (fixed)

Identifier (alphabet or number 5 letters maximum)

Header (fixed)

During normal source play mode, you can activate Easy Sound Setup mode by pressing and holding /AUDIO for at least 3 seconds. Fader/ Balance/Bass level/Treble level/Subwoofer level and BASS ENGINE SQ can be adjusted in this mode.

Easy Sound Setup mode

Adjust the Fader/Balance/Bass level/Treble level.

Display example for Easy Sound Setup screen

• You can choose to display this menu on the left or right of the screen.

For details, refer to “Setting the Easy Sound Setup Position” on page 55.

• Subwoofer level is not adjustable when SubW. is Off. (Page 49)

• The Fader/Balance setting is reflected to “Setting the Balance/

Fader” (page 49).

• In BASS ENGINE SQ mode, touch [BASS ENGINE SQ] to switch to

Easy Sound Setup screen.

BASS ENGINE SQ mode

With the BASS ENGINE SQ function on this unit, several parameters affecting Bass performance are adjusted simultaneously. The Bass Level adjustment varies these parameters uniformly for optimum Bass effect at different levels.

Touch [BASS ENGINE SQ] to switch to BASS ENGINE SQ mode.

Display example for BASS ENGINE SQ screen

• Save the setting data in the root folder.

• For details about procedures of download, see ALPINE’s web site.

Touch [Downloaded Sound Settings].

Setting data files are displayed in a list with a maximum of 5 items.

Touch the desired file.

Touch [OK].

The downloaded setting values are set as the Time Correction/X-Over/Parametric EQ settings, and at the same time saved as Preset3, respectively.

• When no downloaded file is detected in the connected Flash memory, the “Downloaded Sound Settings” function is not available.

24-EN

Display the current BASS ENGINE SQ parameter.

BASS ENGINE SQ:

Adjust the relevant Bass parameters uniformly and automatically.

Easy Sound Setup:

Adjust each audio effect setting separately and manually.

• You can set this item via TuneIt App on a Smartphone. Refer to “Adjusting the sound via the Smartphone” on page 25.

Applying TuneIt

Select the Desired BASS ENGINE Type

You can select your preferable BASS ENGINE type within Standard (Initial setting)/Punch/Rich/Mid Bass/Low Bass.

Adjusting the BASS ENGINE Level

With BASS ENGINE SQ ON, adjusting the Bass Level uniformly effects various sound parameters for optimum Bass effect.

• Adjustable only when Defeat is Off.

• The Bass parameters affected contain Bass Level, Treble Level, EQ

PRESETS, Parametric EQ, SUBWOOFER (when set this item via TuneIt App), Subwoofer Level, Media Xpander, X-Over, Car Specific Sound Setup and Download Sound Setting. These items are set automatically in BASS ENGINE SQ mode and cannot be adjusted separately.

• From Level 0 to Level 6, the effect of BASS ENGINE SQ increases level by level.

About Setup when the external power amplifier is connected.

In order to optimize the BASS ENGINE SQ, we recommend the following power amplifier setup. After setting up, you can adjust the BASS ENGINE SQ Level according to the music.

1 Set gain of the power amplifier to “MIN”. 2 Set the Crossover Mode Sector switch to “OFF”. 3 Set the BASS ENGINE SQ of this unit to “ON”, and the

BASS ENGINE Level to “+3”.

4 Play a song of the genre you frequently listen to, and

adjust gain of the power amplifier.

Access to iDataLink Mode

When the unit is connected to the car’s equipped iDataLink module, you can check the car’s status, set the air conditioning, etc.

Press and hold for at least 2 seconds (or press

)* to activate iDataLink mode.

* Only for GMC/Chevrolet or other model.

Touch the desired tag on the top of the screen.

Adjust or confirm the item/information accordingly.

Display example for the air conditioning screen

This unit’s sound tuning is programmable from a connected Smartphone. It is also possible to download specific parameters for certain vehicles from Alpine’s TuneIt database stored in the Cloud. Using the TuneIt App, customized parameters can also be uploaded for others to share and rate. Through this unit, it is also possible to receive and respond to information from Alpine’s Social Network Service (SNS) available through the connected Smartphone. The installed TuneIt App should be launched on the Smartphone before connection to the head unit. TuneIt, is downloadable from Apple’s App Store; the Android user can download it from Google Play. For details, consult your Alpine dealer. Before these operations, set TuneIt to USB (iPhone) or Bluetooth (Android) depending on the connected Smartphone. For details, refer to “Setting the Communication Mode with a Smartphone” on page 61.

• The application program and related specifications and data may be

deleted or terminated without notice.

• Some TuneIt functions may not be available if the Smartphone is not

in a service area or receives no signal.

Adjusting the sound via the Smartphone

After setting the above procedure, you can adjust the unit’s sound function on the Smartphone.

Make sure the unit is powered on.

Launch the TuneIt App on the Smartphone. Adjust the unit’s sound accordingly on the Smartphone.

• You cannot adjust the sound via a Smartphone when External Audio

Processor is set to On. Refer to “Setting the External Audio Processor On/Off” (page 48).

• Volume level cannot be adjusted via the Smartphone.

• The setting cannot be done on both the Smartphone and this unit at

the same time. While the sound function of this unit is set via the Smartphone, sound function settings on X009 will be displayed as “Sound APP Connected”.

• In some situations, such as the unit is powered off or during a call,

etc., sound setting cannot be done via the Smartphone.

• This function may not be available depending on the paired

Smartphone.

• Please obey all local traffic laws while using this function.

Facebook Notification Function

Some functions may be available in a future version of TuneIt.

• Depending on the paired Smartphone, the following functions may

not be available even though the TuneIt version is updated.

• Text information and Facebook screen are not displayed while

driving.

• Depending on the car type, some functions may not be available even though the iDataLink module is connected.

• You can set the iDataLink mode’s initial screen. For details, refer to “Setting the Default Vehicle Screen” (page 44).

Receiving Notification

When the Smartphone connected to this unit receives notification from Facebook, the incoming message pops up (depending on the TuneIt settings on the phone).

25-EN

Display example for Notification incoming screen

Poster’s picture: Display poster’s picture. (Provided from TuneIt App on Smartphone, displayed with a default image when invalid.) Touch here to switch to Facebook screen. Poster’s name: Display poster’s name. (Provided from TuneIt App on Smartphone, not displayed when invalid.) Touching here can also switch to Facebook screen. Notification List button: Touch to switch to Notification List screen. Text To Speech play/stop button: Touch to play received notification (Depending on the status, operation may not be available). During play mode, touch [] to stop play. Like button: For “Like” operation. (Valid when Wall Posts or Comments is received) Close button: Close the notification screen.

Touch the desired button to operate.

• Touching Audio/Video screen will close the notification screen.

• While you play a Notification by TTS during iPod video mode, the

TTS volume is the same as iPod video source. And adjust the TTS volume will reflect to iPod video source.

• While you play a Notification by TTS during iPod video mode, the iPod VIDEO extension cable should be connected correctly. Otherwise, you cannot hear the TTS. On how to connect an iPod/ iPhone, refer to “Connection of an iPod/iPhone” (page 114).

• The TTS volume is output via the car’s front right and left speakers.

Displaying Facebook Screen

During Notification incoming or Notification List screen, you can switch to Facebook screen.

Display example for Facebook screen

Touch Poster’s picture or Poster’s name to switch to Facebook screen.

The details information of Notification is displayed.

• Touch [ ] to return to previous screen.

• Depending on the status, contents of message and photo may not be

displayed.

• A new received Notification prompt will last for 15 seconds. If there

is no operation within 15 seconds, the unit will return to normal mode.

• In some situations, such as the unit is powered off or during a call,

etc., Notification of the Smartphone will not be prompted by this unit.

Displaying Notification List

You can view the received Notification from Facebook in the connected Smartphone via this unit.

Display example for Notification List screen

Press the (My Favorites) button.

My Favorites screen for User1 or User2 is displayed.

Touch [ ] (Notification List icon).

The received Notification will be displayed according to when it was posted.

Then operate it the same as “Receiving Notification”.

• Touch [ ALL]/[ ALL] to play/stop all Notifications.

• Touch [ ] to return to My Favorites screen.

• You can also access to Notification List screen by touching [ ] on

Notification incoming screen. However, [ ] will not be displayed in Notification List.

• Depending on the status, some functions may not be available.

• When there is no Notification, “No Notifications.” will be displayed.

• The displayable amount of the Notification list depends on the

connected Smartphone.

A part content of message Poster’s photo Close button: Close the Facebook screen.

26-EN

Settings When Switching Users

The functions/settings that are affected when switching users are as shown below.

Item Ref. page

User Registration 21

My Favorites

HD Radio/RBDS Displaying Radio Text 33

General Setup

Sound Setup

Source Setup

Hands-Free

Phone Control

Camera

Operation

BASS ENGINE

SQ mode

Except POI category/i-Personalize Setup

The display pattern can be set when a camera equipped with a switch

function on the Camera screen is connected.

Setting My Favorites*

Displaying the Camera Image*

Setting Top banner and Bottom banner Display

Switching the Display Color 45

Turning Subwoofer ON/OFF 49

Adjusting the Subwoofer Level 49

Setting the Slide Source change 55

Setting the Easy Sound Setup Position 55

Assigning as a Short Cut Dialing Number

Redial Function 69

Phone Book Function 71

Switching the Image Pattern for the Rear Camera*

Switching the Image Pattern for the Front Camera*

Guide Display ON/OFF Setting 77, 80

Adjusting the Caution Display Location 77, 80

Select the desired BASS ENGINE Ty pe

Adjusting the BASS ENGINE Level 25

How to Input Characters and Numbers (Keypad)

Character input is required for user registration, place searches, etc. The displayed screens and procedures may vary slightly depending on the function used, but the basic input method is the same.

Input screen area.

(Delete) Returns to the previous character and erases it. Touching here for more than 2 seconds will erase all input characters. Character keypad Special character selector switch Character keypad Special character keypad Symbol keypad Character keypad

(Space) Input number is confirmed.

Items whose settings are affected when switching registered users, are indicated by “ ” in this manual. Example:

“Source Setup Operation” (page 56).

27-EN

Top banner and Bottom banner Fade Out Setting

When “Top/Bottom Banner Fade Out” is set to ON, the Top banner and Bottom banner on the Audio/Visual Playback screen fade out after 5 seconds if no operation is performed. To display the keys again, touch the middle of the screen.

Top banner

Bottom banner

Switching Sources

During audio/visual playback, press the AUDIO button or touch a source button in the top banner to switch to the desired source.

Switching Sources Using the AUDIO Button

During audio/visual playback, press the AUDIO button repeatedly to switch to the desired source.

Radio Disc* HDMI* iDataLink SiriusXM* AUX 3* Radio…

When no disc is inserted or no Flash memory/iPod/HDMI device/

Smartphone/SiriusXM Tuner/Bluetooth compatible device is connected, this option is not available.

Displayed only when the unit is connected to the car’s iDataLink

module and the iDataLink related setting item is set to “OEM” or “Both” on the unit. (Page 43)

When Bluetooth Pandora is set to “Off”, this option is not available.

(Page 61)

When AUX 1 In is set to “Off”, this option is not available. (Page 60)

When AUX 3 Source Select is set to “iPod Video”, this option is not

available. (Page 60)

Switching Sources Using the Top banner

Touch the source button for the Top banner at the top of the Audio/ Visual Playback screen and select the desired source.

USB/iPod*1 iDataLink USB/iPod*2

Pandora*1 Bluetooth Pandora*3 SiriusXM*1

Bluetooth Audio*1 iDataLink Bluetooth Audio*2

AUX 1*4 AUX 2*4

Source button

• For details of how to set Top/Bottom Banner Fade Out, refer to

“Setting Top banner and Bottom banner Display” (page 44).

Top banner

Swipe here to switch source

If the source button is hidden, touch [b] [B].

• When “Slide Source Change” (page 55) is set to “On”, you can

switch sources by swiping from the middle of the marked area from right to left or from left to right.

• For USB/iPod / SiriusXM / Bluetooth Audio, you can select the

source from this unit or from iDataLink module. Refer to “Setting the Source Category” (page 43).

• The Source display order can be changed. For details, refer to

“Customizing the Source Banner” (page 55).

Screen Off Function

This mode is useful if you feel the unit’s display is too bright at night. To cancel Screen OFF mode, touch the screen or press any button.

• Screen OFF mode is canceled when the power or ACC is turned off.

• When the gear lever is shifted to the reverse (R) position while the

rear camera is connected, the rear camera im age is displayed.

• When a call is received while a Bluetooth device is connected, the

incoming call screen is displayed.

28-EN

Rear Entertainment Function

The rear entertainment function independently routes different sources to the front and the rear inside a car. For example, while listening to the radio or other audio source in the front, DVD can be enjoyed in the rear with the optional rear monitor and headphones.

Press the AUDIO button.

Touch [Rear]* of Top banner.

Rear source Select display appears.

* Displayed only when Rear Seat Entertainment (RSE) is On

(page 60).

• Touching [ ] on the Rear selection screen will change to the main

source screen.

Touch the desired visual source (such as auxiliary input, built-in DVD) to select.

• To uc h [OFF] to cancel the rear entertainment function.

• When the “Setting the AUX Mode” (page 60) is set to Off, the

auxiliary source is not displayed.

• Depending on the status, some Rear source items may not be

available in some case. (For example, when there is no DVD disc inserted on this unit, you cannot set “Disc” as Rear source.)

• Touch [AUTO] to set the rear source the same as the X009’s playing

visual source.

• When iPhone Pandora

select iPod Video or enjoy iPod Video on rear monitor.

• Select iPod audio on X009 may impact the iPod video playing on the

rear monitor.

• You cannot make the AUX 1 and AUX 2 to play on the main unit and

rear monitor at the same time.

source is selected on X009, you cannot

Full Screen

Touch operation

You can operate the system by using the touch panel on the screen.

• Be sure to touch the onscreen button lightly with the pad of your

finger to protect the display.

• If you touch a button and there is no reaction, remove your finger

from the display once, and try again.

• Onscreen buttons that cannot be operated appear dull in color.

Common onscreen buttons

[]:Returns to the previous screen. Depending on the

function, this button may cancel the operations

performed on the screen. []:Closes the window.

Switching the Dual Screen Display

When you touch [MODE] on the dual screen during video playback, the screen size selection message is displayed.

Dual Wide (Initial setting)

Dual Full

Selecting an Item in a List

To scroll through a list, perform the following operations.

Touch the screen and slide your finger up and down.

The screen will scroll along with your finger movement. Also, you can touch [] and [].

• After touching the screen, move your finger away from the screen

before dragging and that item will be selected.

29-EN

About the Indicator Display

The Indicator Bar at the bottom of the screen displays various types of information, like the current time.

The display will differ depending on the source. For details, refer to the display example of each source. Lights up when connected to a Bluetooth compatible device. (Does not display when connection is set to OFF.)

: Bluetooth connection to audio device

: Bluetooth connection to Hands Free Phone

Blinks while reconnecting.

Indicates the battery level of the connected Bluetooth device.

Battery

Level

Icon

This may not be displayed depending on the connected Bluetooth device.

Indicates the signal strength level of the connected Bluetooth compatible device.

Displayed when Bluetooth setting is ON.

No Battery Level 1 Level 2 Level 3

0123No Service

The clock display

You can switch between the 12 hour display and 24 hour display options. For details of the clock display settings, refer to “Navigation System OM” in the CD-ROM.

30-EN

Radio/HD RadioTM/ RBDS

X009 can receive HD Radio signals based on digital radio broadcast standards in addition to analog radio broadcasts using RBDS. HD Radio signals are broadcast in the service areas of the current AM/ FM broadcasters where they provide digital audio distribution and data services. This unit receives the above digital broadcasts for your highquality sound enjoyment. Depending on the signal strength in TUNER mode, X009 will automatically switch between digital signals if they can be received, and analog radio using RBDS if digital signals cannot be received. For details, please refer to “Switching between Digital and Analog,” “Forced Analog Mode.”

• RBDS mode is only available during FM broadcast reception.

This unit is able to receive signals based on the terrestrial digital radio broadcasting standard. When current AM/FM broadcasters are transmitting digital audio and data services, HD Radio signals are on-the-air in their service area. You can receive their digital broadcast and enjoy high quality sound. If there is no HD Radio signal in the current area, after 10 seconds, this unit will switch to receive the RBDS Radio signal automatically. However, the display is still HD Radio mode screen.

Display example for Radio main screen

Listening to the Radio

Press the AUDIO button.

Touch [Radio] of Top banner.

The radio mode is activated and the display changes to the Radio mode screen.

• The display content varies depending on the last band selected.

([RadioFM1], etc.)

Touch [Band] of Bottom banner to select the desired radio band.

Each touch changes the bands as follows:

FM1 FM2 AM FM1

Touch [Tune] to select the tuning mode.

DX Seek Local Seek D.DX Seek

D.Local Seek MANUAL PTY*

*1Displays only when the PTY tuning mode is selected. For

details, refer to “PTY (Program Type) Tuning (Analog Broadcasts only)” (page 32).

• There are two modes you can select for auto tuning, DX and

Local:

- DX (Distance) mode*

Both strong and weak stations will be tuned in.

- Local mode*

Only strong stations will be tuned in. The initial setting is DX.

- D(Digital).DX Seek mode;

Automatically receives a receivable digital broadcast.

- D(Digital).Local Seek mode;

Automatically receives a strong digital broadcast only.

Depending on the signal status, a digital or analog broadcast is

received.

• During Forced Analog mode, digital broadcasts cannot be

received.

;

Touch [<<], [>>]

Band display Displays the band of the signal currently being received. Frequency display Displays the frequency, song name and artist name of the signal currently being received. Preset button Registers and recalls preset frequencies. Seek mode Displays the current Seek mode. TAG Indicator Blinks during tagging. Multicast Indicator Lights during multicast reception. HD Radio Indicator Displays during HD Radio reception.

Touch [], [] or [], [] to change the radio frequency up or down respectively.

In manual mode, touch and hold to change the frequency continuously.

Presetting Stations Manually

Tune in a desired radio station you wish to store in the preset memory by manual or automatic seek tuning.

Touch and hold any one of the preset buttons for at least 2 seconds.

The selected station is stored.

Repeat the procedure to store up to 5 other stations onto the same band.

To use this procedure for other bands, simply select the desired band and repeat the procedure.

A total of 18 stations can be stored in the preset memory (6 stations for each band; FM1, FM2 or AM).

31-EN

• If a preset memory has already been set in the same preset number, it

will be cleared and the new station will be memorized.

Presetting Stations Automatically

The tuner can automatically seek and store 6 strong stations in the selected band in order of signal strength.

After selecting the desired band, touch [A.Memo] of Bottom banner.

The tuner automatically seeks and stores 6 strong stations into the preset buttons in order of signal strength. When automatic storing has completed, the station stored in the preset 1 is selected. If [A.Memo] is not displayed, touch [<<] or [>>] in the bottom banner to display [A.Memo].

• If no stations are stored, the tuner will return to the original station

you were listening to before the automatic storing procedure began.

• You can cancel this process by touching [A.Memo] while the tuner is

automatically seeking stations. Cancelling will return the tuner preset to the previous setting.

Tuning to Preset Stations

Receiving a Multicast (HD Radio mode only)

Multicasting is the ability to broadcast multiple program streams over a single FM frequency. This increases the amount and diversity of content choices. A maximum of 8 multicast station channels can be selected on this unit.

• Multicast indicator appears when signal reception is possible.

• The station number of the current broadcast station appears behind

the frequency (ex. 90.3 MHz-HDs means there are 5 stations on

90.3 MHz).

Touch [] or [].

The sub channel of the received radio station is changed.

• If reception is lost during SPS broadcasting due to weak or no signal,

the screen will display “HDx Signal loss.” If SPS broadcast reception is lost for over 100 seconds, reception will switch over to MPS broadcast (the reception mode will automatically return to SPS when SPS broadcasts become available again).

PTY (Program Type) Tuning (Analog Broadcasts only)

You can tune in the preset stations in memory on either band using its preset number.

Touch [Band] of Bottom banner repeatedly until the desired band is displayed.

Touch any one of the preset buttons that has a station stored to it.

The preset station is received.

Forced Analog Mode

Touch the [Digital/Analog] button to receive analog broadcasts only.

Touch [Digital/Analog].

• If digital broadcast is received, this operation switches reception to

analog mode.

• During Forced Analog mode, only analog broadcasts will be received

even when digital broadcasts become available.

FM Radio mode

Touch [PTY Search] of Bottom banner.

The Select PTY list screen is displayed. If [PTY Search] is not displayed, touch [<<] in the bottom banner to display [PTY Search].

Touch the selected program type to start searching for a station in the type.

If no PTY station is found, “No PTY.” will be displayed.

Touch [Tune] to choose the PTY tuning mode.

The PTY mode is activated.

To select the station in the PTY, touch [<] or [>].

32-EN

Displaying Radio Text

Text messages from a radio station can be displayed.

Tune in a radio station that transmits text messages.

Touch [Info] in the bottom banner in FM radio mode repeatedly to switch to the desired display.

HD Radio

Station Info Mode (Station Name/Frequency/Song Name)

Song Info Mode (Station Name/Song Name/Artist Name/ Album Name)

• During tagging, the iPod/iPhone takes priority to save the tag

information. If no iPod/iPhone is connected, the tag information is saved to this unit.

• When the memory of iPod/iPhone is full, “iPod memory full. Tag

count x.” is displayed. The tag information will be stored to the unit.

• If the tagging operation is interrupted by a hands-free phone call, the

tagging operation will be canceled and the unit will display “Cannot Tag”.

• This unit can store up to 50 tagged songs. When the memory of the

unit is full, “Tuner memory full. Connect iPod” may be displayed.

• When the iPod/iPhone is disconnected from the unit during tagging,

its tag information will be stored in the unit.

• If there is stored tag information on the unit, when an iPod/iPhone

supporting the tag function is connected, the stored tag information will be transferred to the iPod/iPhone automatically. When the iPod/ iPhone memory becomes full, “iPod memory full.” will be displayed, and any remaining tag information on the unit will not be transferred to the iPod/iPhone.

• If tag information already exists, “Already Tagged” will be displayed

when you try to tag information again.

RBDS

Station Info Mode (PS/PTY/ Frequency/Song Name)

Song Info Mode (PS/Song Name/Artist Name/Album Name)

Radio Text Mode (Radio Text)

Storing the tag information (HD Radio mode only)

iTunes Tagging lets you tag songs heard on HD Radio stations. You can preview, buy and download later, songs from your iTunes tagged playlist the next time you sync your iPod/iPhone. If the unit is connected to a Tagging compatible iPod/iPhone, you can use the iTunes Tagging function. For details, refer to the Owner’s Manual of the Tagging compatible iPod/iPhone. When a desired song is heard on an HD Radio station, touch the TAG icon area to save its tag information.

About the Feature Logos

• Digital, CD-quality sound. HD Radio Technology enables local radio stations to broadcast a clean digital signal. AM sounds like today’s FM and FM sounds like a CD.

• Program Service Data: Contributes to the superior user experience of HD Radio Technology. Presents song name, artist, station IDs, HD2/HD3 Channel Guide, and other relevant data streams.

• Adjacent to traditional main stations are extra local FM channels. These HD2/HD3 Channels provide new, original music as well as deep cuts into traditional genre.

• iTunes

• Visual information related to content being played on your HD

Tagging provides you the opportunity to discover a wide range of content and the means to “tag” that content for later review and purchase from the iTunes

Radio receiver, such as Album Art, historical photographs, still art from live broadcasts, among other related content.

Store.

TAG icon area (When tagging is allowed, the TAG icon is displayed.)

If no iPod/iPhone is connected, “Tag Count X” is displayed (X is the total amount of the tag information stored in this unit).

33-EN

CD/MP3/WMA/AAC

Display example for MP3/WMA/AAC main screen

Info mode

Touch [ / ] again or touch [ ] in the middle of the screen to start playback.

• The X009 can play back MP3/WMA/AAC files saved to CD or DVD.

Use a format compliant with this unit. For further information about playing or storing MP3/WMA/AAC files, refer to pages 35 and 36 before using the unit.

• Any file protected by DRM (Digital Rights Management) copy

protection, cannot be played back on this unit.

• If a disc contains both audio data and MP3/WMA/AAC data, this unit

plays back only the audio data.

• The track display for CD audio data playback shows the track

numbers recorded on the disc.

• If an MP3/WMA/AAC disc with many files and folders is played, it

may take longer than normal to start playback.

• The playback time may not be correctly displayed when a VBR

(Variable Bit Rate) recorded file is played back.

Repeat Play

Song title Artist title Album title Current song no./Total song no. Elapsed time

• If there is no CD text, the message “No Text” appears.

About creating a tag information library

You can scan music files in a disc and create a library of tag information in this unit. Library creation starts when the disc is inserted. The time it takes to create the library depends on the number of songs/files recorded in the disc, but it may take several minutes.

About operations during library creation

• Search function does not work properly while a library is being

created.

• The order in which songs are played during library creation may

differ from the order in the disc.

Playback

Press the AUDIO button.

Touch [Disc] of Top banner.

The display shows the Disc mode screen.

When a disc is inserted into the disc slot of this unit, with the label side facing up, the unit starts playback of the disc.

Touch [] or [] to select the desired track (file).

Returning to the beginning of the current (or previous) track (file):

Touch [].

Fast reverse :

Touch and hold [].

Advancing to the beginning of the next track (file) :

Touch [].

Fast forward :

Touch and hold [].

Touch [] to repeatedly play back.

The tracks (files) will be played repeatedly. The repeat mode switches every time the button is touched.

CD:

Repeat (OFF) Repeat

MP3/WMA/AAC:

Repeat Repeat Folder* (OFF) Repeat

* Only files in a folder are repeatedly played back.

• If the Repeat Play mode is activated during M.I.X. playback, the

M.I.X. mode will be canceled.

M.I.X. (Random Play)

Touch [] during playback.

The tracks (files) on the disc will be played back in a random sequence.

The M.I.X. mode switches every time [] is touched.

CD:

M.I.X. (OFF) M.I.X.

MP3/WMA/AAC:

M.I.X. Folder* (OFF) M.I.X. Folder*

* Only files in a folder are played back in random sequence.

• If the M.I.X. mode is activated during Repeat playback, the Repeat

Play mode will be canceled.

• If you select a track by using the search mode, the M.I.X. play mode

will be canceled.

To pause playback, touch [ / ].

[ ] is displayed in the middle of the screen.

34-EN

Selecting Folders (Concerning MP3/WMA/AAC)

About MP3/WMA/AAC

Touch [] or [] of Bottom banner to select the folder.

Searching from CD Text

Touch [ (Search)] of Bottom banner during playback.

The CD text search screen is displayed.

Touch the selected track name.

The selected track will be played back.

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 29).

File/Folder Name Search (Concerning MP3/WMA/AAC)

Touch [ (Search)] of Bottom banner during playback.

The search mode is activated.

Touch [Music].

The folder name list screen is displayed.

Folder Name Search mode

Touch [] in the desired folder.

The first file in the selected folder is played back.

File Name Search mode

Touch the desired folder name.

The File name of the selected folder is displayed.

Touch the desired file name.

The selected file is played back.

• To return to the previous hierarchy, touch [].

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 29).

• After selecting a folder via a Folder name search, touch [] on the

main screen to display the folder search screen.

• After selecting a file via a File name search, touch [] on the

main screen to display the file search screen.

CAUTION

Except for private use, duplicating audio data (including MP3/ WMA/AAC data) or distributing, transferring, or copying it, whether for free or for a fee, without permission of the copyright holder is strictly prohibited by the Copyright Act and by international treaty.

What is MP3?

MP3, whose official name is “MPEG Audio Layer 3”, is a compression standard prescribed by the ISO, the International Standardization Organization and MPEG which is a joint activity institution of the IEC.

MP3 files contain compressed audio data. MP3 encoding is capable of compressing audio data at extremely high ratios, reducing the size of music files to as much as one-tenth their original size. This is achieved while still maintaining near CD quality. The MP3 format realizes such high compression ratios by eliminating the sounds that are either inaudible to the human ear or masked by other sounds.

What is WMA?

WMA, or “Windows Media™ Audio”, is compressed audio data. WMA is similar to MP3 audio data.

What is AAC?

AAC is the abbreviation for “Advanced Audio Coding”, and is a basic format of audio compression used by MPEG2 or MPEG4.

Method for creating MP3/WMA/AAC files

Audio data is compressed using software with MP3/WMA/AAC codecs. For details on creating MP3/WMA/AAC files, refer to the user’s manual for that software. MP3/WMA/AAC files that are playable on this device have the file extensions. MP3: “mp3” WMA: “wma” (ver. 7.x, 8.x, 9.x are supported) AAC: “m4a” WMA is not supported for the following files, Windows Media Audio Professional, Windows Media Audio 9 Voice or Windows Media Audio 9 Pro Lossless.

There are many different versions of the AAC format. Confirm that the software being used conforms to the acceptable formats listed above. It’s possible that the format may be unplayable even though the extension is valid. Playback of AAC files encoded by iTunes is supported.

35-EN

Supported playback sampling rates and bit rates

MP3

Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz,

16 kHz, 12 kHz, 11.025 kHz, 8 kHz

Bit rates: 8 - 320 kbps

WMA

Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 22.05 kHz, 16 kHz,

11.025 kHz, 8 kHz

Bit rates: 48 - 320 kbps

Order of files

Files are played back in the order that the writing software writes them to the disc. Therefore, the playback order may not be what’s expected. Verity the writing order in the software’s documentation. The playback order of the folders and files is as follows. (The following numbers may differ from actually displayed numbers.)

AAC

Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz,

Bit rates: 16 - 320 kbps

This device may not play back correctly depending on sampling rates.

ID3 tags/WMA tags

This device supports ID3 tag v1.0, v1.1, v2.2, v2.3, v2.4, and WMA tag Ver.1.x. If tag data is in an MP3/WMA/AAC file, this device can display the title (track title), artist name, and album name ID3 tag/WMA tag data (maximum 64 characters). For non-supported characters, “?” is displayed. The number of characters may be limited, or not correctly displayed, depending on the tag information.

Playing back MP3/WMA/AAC

MP3/WMA/AAC files are prepared, then written to a CD-R, CDRW (DVD-R/DVD-RW/DVD+R/DVD+RW) using CD-R writing software and Flash memory.

• Maximum numbers of playable files/folders Disc: 1,000 files/folders (including Root Folder/DivX Flash memory: 10,000 files/folders (including Root Folder/ DivX

• Largest playable file size: 512 MB

Playback may not be performed if a disc exceeds the limitations described above. If a file/folder name is long, the maximum possible number of files may decrease.

• Both Audio and Video files are counted if their formats are playable on this unit.

Media supported

The media that this device can play back are CD-ROMs, CD-Rs, CD-RWs, DVD-Rs, DVD-RWs, DVD+Rs, DVD+RWs and Flash memory.

Corresponding File Systems

This device supports discs formatted with ISO9660 Level 1 or Level 2, UDF1.02 and UDF1.02(ISO Bridge).

Under the ISO9660 standard, there are some restrictions to remember.

The maximum nested folder depth is 8 (including the root directory). File names are limited to 256 characters (including the extension).

Valid characters for folder/file names are letters A-Z (all caps), numbers 0-9, and ‘_’ (underscore).

This device can play back discs in Joliet, Romeo, etc., and other standards that conform to ISO9660. However, sometimes the file names, folder names, etc., are not displayed correctly.

Formats supported

This device supports CD-ROM Mode1, CD-ROM XA Mode2(Form1&2), Mixed Mode CD and Multi-Session. This device cannot correctly play back discs recorded with Track At Once or packet writing.

16 kHz, 12 kHz, 11.025 kHz, 8 kHz

file)

Root Folder

Folder MP3/WMA/AAC File

Terminology

Bit rate

This is the “sound” compression rate specified for encoding. The higher the bit rate, the higher the sound quality, but also the larger the files.

Sampling rate

This value shows how many times per second the data is sampled (recorded). For example, music CDs use a sampling rate of 44.1 kHz, so the sound is sampled (recorded) 44,100 times per second. The higher the sampling rate, the higher the sound quality, but also the larger the volume of data.

Encoding

Converting music CDs, WAVE (AIFF) files, and other sound files into the specified audio compression format.

Tag

Song information such as track titles, artist names, album names, etc., written into MP3/WMA/AAC files.

Root folder

The root folder (or root directory) is found at the top of the file system. The root folder contains all folders and files. It is created automatically for all burned discs.

36-EN

DVD

Display example for DVD Video main screen

Touch [<<], [>>]

Display example for DivX

main screen

The DVD operation screen display

Touch the screen while the DVD playback screen is displayed.

The DVD operation screen is displayed.

• The operation screen changes to the visual screen in the DVD mode

for 5 seconds after an operation has been performed.

• If you try to activate the DVD while driving, the display will show the

warning-Picture off for your safety.

• Some operations cannot be carried out depending on the disc or

playback screen.

Playing a Disc

WAR NING It is dangerous for the driver to watch the DVD/TV/ Video while driving the vehicle. The driver may be distracted from looking ahead and an accident could occur.

Touch [<<], [>>]

Information display-1

DVD-Video: Title name/Chapter No.

DivX File name/File No./Current File No./Total File No. in Current Folder

Information display-2

DVD-Video: Audio signal output/Subtitle/Angle

DivX

Audio signal output/Subtitle

Total time for playing Elapsed time

Disc types that can be used for each heading are represented by the following marks.

DVD Commercial Video discs (used for the distribution of movies, etc.) or a DVD-R/DVDRW, DVD+R/DVD+RW recorded in a video mode can be used.

CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/ DVD+RW discs that are recorded in the

DivX

mode can be used.

Install the X009 correctly so that the driver cannot watch DVD/TV/Video unless the vehicle is stopped and the emergency brake is applied.

If the X009 is not installed correctly, the driver will be able to watch the DVD/TV/Video while driving the vehicle and may be distracted from looking ahead causing an accident. The driver or other people could be severely injured.

Caution

• Not all functions will operate for every DVD. See the

individual DVD’s instructions for details on the features supported.

• Fingerprints on a disc may adversely affect

playback. If a problem occurs, remove the disc and check for fingerprints on the playback side. Clean the disc if necessary.

• If you switch the power or Ignition key OFF or

change sources during playback, playback will continue where you left off when you resume playback.

• If you try to perform an invalid operation (based on

the type of disc being played), the following mark is displayed on the monitor screen:

37-EN

• Play Position Memory Function Even if you turn power off or switch the Ignition key to OFF during playback or change the source, playback will continue from the point where playback stopped when the power is turned ON again.

Press the AUDIO button.

Touch [Disc] of Top banner.

The display shows the Disc mode screen. Or insert a disc with the label side facing up. The unit starts to play the disc.

• The reverse side of a double-sided DVD will not be played

automatically. Remove the disc, turn it over, and reinsert it.

• DO NOT insert discs containing maps for the navigation system.

Doing so could result in damage.

• Refer also to “Disc Setting” (page 56).

• While reading a DivX

repeat functions, etc. cannot be used.

• A DivX

file that exceeds 4GB cannot be played back.

file, the fast-forwarding/fast-reversing and

If a Menu Screen Appears

On DVD mode, menu screens may appear automatically. If this happens, perform the operation described below to start playback.

Select a desired menu item by touching [], [], [] or [].

• Touching [] in the operation panel returns to the screen in

step 1.

• Touching [Key] displays the Numeric Keypad Input Mode

screen. For details of the Numeric Keypad Input Mode screen, refer to “Numeric Keypad Input Operations” (page 38).

Touch [Enter] to confirm the selected item.

Numeric Keypad Input Operations

Touch [10KEY] of Bottom banner.

The numeric keypad input mode screen appears If [10KEY] is not displayed, touch [<<] in the bottom banner to display [10KEY].

Touch a desired number.

Direct Menu Operations

Touch the DVD menu directly.

• Some operations cannot be performed depending on the disc.

Menu Operations

Touch [Key].

The menu operation mode will be displayed.

Touch [] or [] to change the Key panel location from right to left or vice-versa. Touch [Return] to return to the previous display.

Touch [] to delete an entered number. Touch [Delete All] to delete all entered number.

Touch [Enter] on the numeric keypad mode screen to confirm your selection.

Touch [] to hide the keypad display.

38-EN

Displaying the Top Menu Screen

When a DVD contains two or more titles, the top menu screen appears.

Touch [TOP MENU] of Bottom banner.

The top menu screen appears.

• To perform necessary operations, refer to “If a Menu Screen

Appears” (page 38).

Displaying the Menu Screen

With a DVD having two or more menus, a menu screen will appear for the programs available, in addition to the main programs.

Touch [MENU] of Bottom banner.

The Root menu screen appears.

• To perform necessary operations, refer to “If a Menu Screen

Appears” (page 38).

Stopping Playback (PRE STOP)

Touch the stop button during playback to stop playback. That position is stored in the memory.

Touch [] during playback.

“Pre ” indicator and [ ] in the middle of the screen are displayed.

Touch [/] in the PRE STOP mode or touch [] in the middle of the screen.

Playback starts from the position at which it was stopped.

• For some discs, the position at which playback was stopped may not

be accurate.

Stopping Playback

Touch and hold [] for at least 2 seconds during playback.

“ ” indicator and [ ] in the middle of the screen are displayed.

• Playback starts from the beginning when [ /ll] or [ ] in the

middle of the screen is touched while playback is stopped.

Fast-forwarding/Fast-reversing

During playback, touch and hold [] (Fast-reverse) or touch and hold [] (Fast-forward).

DVD-Video:

Touch and hold for more than 1 second to forward/reverse at double speed. Every time you touch [ ]/[ ] during fast- reverse/fastforward, the speed changes as follows: 2x 8x 32x 2x.

DivX

Touch and hold for more than 1 second to forward/reverse at 8x speed. Every time you touch [ ]/[ ] during fast- reverse/fastforward, the speed changes as follows: 8x 16x 32x

8x.

• Fo r a D i v X

fast forward and the reverse option is not available.

Touch [/] to return to normal playback.

• No sound is played back during fast-forwarding/fast-reversing.

• On DVD mode, the menu screen may reappear during fast-

forwarding/fast-reversing.

• This operation may not be possible on certain discs.

file that does not contain index information, the

Finding the Beginnings of Chapters/ Tracks/Files

During playback, touch [] or [].

The chapter/track/file switches each time the button is touched, and playback of the selected chapter/track/file starts.

: Touch this to start playback from the beginning of the

following chapter, track or file.

: Touch this to start playback from the beginning of the

current chapter, track or file.

• Some DVDs do not have chapters.

Supplementary explanations

“Chapters” are divisions of movies or musical selections on DVDs.

39-EN

Playing Still Frames (Pausing)

During playback, touch [/] of Bottom banner.

Touch [/] or [] in the middle of the screen to resume playback.

• No sound is played during the still frame mode.

• The image or sound may stop temporarily when playback starts from

the pause mode. This is not a malfunction.

Forward frame-by-frame Playback

In the pause mode, touch [].

The picture advances by one frame each time the button is touched.

Touch [/] or [] in the middle of the screen to return to normal mode.

• No sound is output during forward frame-by-frame playback.

• You cannot execute reverse frame-by-frame playback.

Slow Motion Playback

When [] is touched and held while in the pause mode, the 1/8th speed slow motion playback mode is set. Furthermore, when touched and held [] again, the slow motion speed switches to 1/2 the normal speed.

Touch [/] of Bottom banner to play back.

• No sound is played during slow motion playback.

• 1/2, 1/8 are approximate speeds. The actual speed differs from disc to

disc.

• You cannot execute reverse slow motion playback.

Selecting Folders

Touch [] or [] of Bottom banner to select the folder.

• Touch [] to play from the first file of the previous folder. Touch [] to play from the first file of the next folder.

Repeat Playback

Use this function to play the disc’s titles, chapters or tracks, etc., repeatedly.

Touch [] of Bottom banner.

The repeat mode switches every time the button is touched.

DVD Video

(Chapter)

(Title)

(OFF)

• The REPEAT mode is always turned off when [] is touched and held for at least 2 seconds.

• Only discs containing a Playlist can be displayed.

DivX

(File)

(Folder)

(Repeat All)

The chapter is played repeatedly.

The title is played repeatedly.

Playback returns to normal mode.

The file is played repeatedly.

The folder is played repeatedly.

The disc is played repeatedly.

40-EN

Searching by Title Number

Use this function to easily find positions on the DVD using the DVD’s titles. Perform operations while playback is stopped.

Touch [10KEY] of Bottom banner.

The numeric keypad input mode screen appears. If [10KEY] is not displayed, touch [<<] in the bottom banner to display [10KEY].

• For DVD Video, the numeric keypad can also be displayed by

touching [Menu Control] of Bottom banner and then touching [Key] twice.

Enter a desired title by touching its number.

See page 38 for operation of the numeric keypad.

Touch [Enter].

Playback will start from the number selected.

Touch [].

• This function cannot be used on discs on which no title numbers are

recorded.

• Some disc may not accept any operation.

Searching Directly by Chapter Number

Use this function to easily move to the beginnings of the chapters on the disc. Perform operations during playback, during PRE-STOP or while playback is paused.

Touch [10KEY] of Bottom banner.

The numeric keypad input mode screen will appear. If [10KEY] is not displayed, touch [<<] in the bottom banner to display [10KEY].

Touch and enter the chapter number you want to play.

See page 38 for operation of the numeric keypad.

Touch [Enter] to confirm your selection.

Playback will start from the selected chapter.

Touch [].

• This function is not available for a disc on which chapters are not

stored.

Searching for a Desired Video File

You can select a video file from the list screen.

Touch [ (Search)] of Bottom banner.

The search mode is activated.

Touch [Video].

The folder list screen appears.

Folder Name Search mode

Touch [] in the desired folder.

The first file in the selected folder is played back.

File Name Search mode

Touch the desired folder name.

The File name of the selected folder is displayed.

Touch the desired file name.

The selected file is played back.

• To return to the previous hierarchy, touch [].

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 29).

• After selecting a folder via a Folder name search, touch [] on the main screen to display the folder search screen.

• After selecting a file via a File name search, touch [] on the main screen to display the file search screen.

Switching the Angle

On DVDs in which scenes have been filmed from multiple angles, the angle can be switched during playback.

Touch [ANGLE] of Bottom banner.

The angle switches between the angles recorded on the disc every time the button is touched. If [ANGLE] is not displayed, touch [<<] in the bottom banner to display [ANGLE].

• Some time may be required for the angle to change.

• Depending on the disc, the angle may switch in one of two ways.

- Seamless: The angle switches smoothly.

- Non-seamless: When the angle is switched, a still picture is

displayed first, after which the angle switches.

41-EN

Switching the Audio Tracks

About DivX

DVDs with multiple audio tracks or languages allow switching the sound during playback.

Touch [AUDIO] of Bottom banner.

The sound switches between the alternate audio tracks recorded on the disc every time the button is touched. If [AUDIO] is not displayed, touch [<<] in the bottom banner to display [AUDIO].

• The alternate track selected becomes the default setting every time

the power is turned on or the disc is replaced. If the disc does not include that track, the disc’s default language is selected instead.

• Not all discs will allow changing the alternate audio tracks during

playback. In these cases, select audio tracks from the DVDs menu.

• There may be a delay before the selected alternate track begins to

play.

Switching the Subtitles (Subtitle Language)

With DVDs on which multiple subtitle languages are recorded, the subtitle language can be switched during playback; moreover, subtitles can be hidden.

Touch [Sub Title] of Bottom banner.

Touching this button repeatedly selects sequentially the subtitle languages recorded on the disc, and then turns the subtitles OFF. If [Sub Title] is not displayed, touch [<<] in the bottom banner to display [Sub Title].

• There may be a delay before the selected subtitle appears.

• Not all discs will allow changing the subtitles during playback. In

these cases, select subtitles from the DVDs menu.

• The subtitle language selected becomes the default setting every time

the power is turned on or the disc is replaced. If the disc does not include that language, the disc’s default language is selected instead. However, the subtitle language may differ depending on the disc.

• For some discs, the subtitles will be displayed even when this is set to

OFF. However, the subtitle language may differ depending on the disc.

DivX® is a codec (software) to compress moving images while maintaining image quality using a highly advanced compression ratio and operating speed.

• Official DivX

ABOUT DIVX VIDEO: DivX DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified more information and software tools to convert your files into DivX videos. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified must be registered in order to play purchased DivX Video-onDemand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.

Certified product

is a digital video format created by

device that plays DivX video. Visit divx.com for

device

Media supported

The unit can play back CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/ DVD+RW discs and Flash memory device that are recorded in

the DivX

mode.

Corresponding extension

“avi”, “divx”

Video Codec

DivX® versions 3, 4, 5, and 6 (versions 5 handle both interlaced and progressive)

Audio Codec

MPEG1 Layer2 (MP2) 32 to 384 kbps MPEG1 Layer3 (MP3) 32 to 320 kbps MPEG2 Layer2 (MP2) 8 to 160 kbps MPEG2 Layer3 (MP3) 8 to 160 kbps Dolby Digital 32 to 448 kbps

42-EN

Setup

Setup Operation

Touch the [SETUP] icon on the Audio/Visual Playback screen to display the Setup main screen.

[SETUP] icon

General Setup

Touch [General].

The General Setup screen appears.

Select the desired item.

General Setup Operation

To display the General Setup Menu screen:

Your vehicle must be parked with the ignition key in the ACC or ON position. To do this, follow the procedures below.

1 Bring your vehicle to a complete stop at a safe

location. Engage the parking brake.

2 Keep pushing the foot brake and release the parking

brake once then engage it again.

3 When the parking brake is engaged for the second

time, release the foot brake.

• For automatic transmission vehicles, place the transmission lever

in the Park position.

Now, the locking system for the General mode operation has been released. Engaging the parking brake can reactivate the General Setup Menu, as long as the car’s ignition has not been turned off. It is not necessary to repeat the above procedure (1 through 3) of “To display the General mode screen.” Each time the ignition is turned OFF, perform the procedure of “To display the General mode screen.”

The following steps 1 to 5 are common operations to each “Setting item” of General Setup. Refer to each section for details.

Tou ch [Setup] icon of Top banner.

The Setup main screen is displayed.

Setting items: iDataLink Setup / Text Display / Remote Sensor

*1Displayed only when Rear Seat Entertainment (RSE) is On

• Depending on the item, repeat step 3.

Touch [] or [] etc., to change its setting.

• When the pop-up window for setup is displayed, touch [] to

Touch [] to return to the previous screen.

• Immediately after changing the settings of General Setup (While the system is writing data automatically) do not turn the ignition key to OFF. Otherwise, the settings may not be changed.

Top/Bottom Banner Fade Out / Screen/ LED Customize / Visual / About / Installation / External Audio Processor / Optical

(page 60).

Available only when External Audio Processor is On.

close the window after setting.

*1 /

iDataLink Setup

[iDataLink Setup] is selected on the General setup menu in step 3. Refer to “General Setup Operation” (page 43).

Setting the Source Category

You can set whether the following source button in the top banner is available.

Setting item: USB/iPod / SiriusXM / Bluetooth Audio

Setting contents: Both (Initial setting) / OEM / Aftermarket

Both: Both the sources listed above from this unit

OEM: Only the source listed above from iDataLink

Aftermarket: Only the source listed above from this unit is

and iDataLink module are available.

module is available. The source from iDataLink module is marked with .

available.

43-EN

• The iDataLink source icons not displayed on the top banner when no

iDataLink module is connected even though “Both” or “OEM” is set.

Setting the Hands-free Connection

Select to pair the Bluetooth compatible phone with this unit or the connected iDataLink module.

Setting item: Hands-free Connection Setting contents: OEM / Aftermarket (Initial setting)

OEM: Select to pair the Bluetooth compatible phone

with the connected iDataLink module.

Aftermarket: Select to pair the Bluetooth compatible phone

with this unit.

• This setting is linked with “Setting Hands-free Connection of

iDataLink” (page 62).

Format settings

The character code to be used for tag text information displayed on the screen can be selected from 7 character codes.

Setting item: Format Setting contents: Latin-1 / Latin-9 (Initial setting) / Russian /

Chinese / Thai / Arabic / Hebrew

Latin-1: ISO 8859-1 Latin-9: ISO 8859-15 Russian: ISO 8859-5 Chinese: GB18030 Thai: CP874 Arabic: CP1256 Hebrew: CP1255

Setting the Menu Language

Setting the Default Vehicle Screen

You can select an item listed below as your preferable screen when you access to iDataLink mode.

Setting item: Default Vehicle Screen Setting contents: Climate / Vehicle Info. / Gauges / Parking Assist /

Last mode

• Depending on the car, some setting contents or this setting item may

not be displayed.

Setting the Maestro Module

You can change the setting of the connected iDataLink module.

Setting item: Maestro Module

• Depending on the iDataLink module, the setting contents may differ.

Text Display Setting

Touch [Text Display] on the General setup menu in step 3. Refer to “General Setup Operation” (page 43).

Setting the Scroll

Scroll display is available if CD text, folder name, file name or tag information is entered.

Setting item: Auto Scroll Setting contents: Off (Initial setting) / On

Off: Turns off the scroll mode. On: Turns on the Auto scroll mode. Scroll display is repeated

as long as the mode is turned on.

The Setup menu, feedback information, etc. for this unit can be changed to appear in the selected language.

Setting item: Language Setting contents:

• Touch [OK] to confirm the language and display the screen in the specified language.

Remote Sensor Setting

[Remote Sensor] is selected on the General setup menu in step 3. Refer to “General Setup Operation” (page 43). For remote control operation, the remote sensor of the external device (monitor, etc.) can be switched, as you prefer.

Setting item: Remote Sensor Setting contents: Front (Initial setting) / Rear

Front: The remote sensor of this unit is effective. Rear: The remote sensor of the external monitor

connected to AUX OUTPUT of this unit becomes effective. The remote control operates the source connected to the AUX OUTPUT terminals.

• If the Rear Seat Entertainment (RSE) (page 60) is “Off”, the setting is not displayed.

44-EN

Setting Top banner and Bottom banner Display

[Top/Bottom Banner Fade Out] is selected on the General setup menu in step 3. Refer to “General Setup Operation” (page 43). You can configure the display setting for the Top banner and Bottom banner for the audio/visual source.

Setting item: Top/Bottom Banner Fade Out Setting contents: Off (Initial setting) / On

Off: Always displayed. On: Fade out after 5 seconds if no operations performed.

Screen/LED Customize

Touch [Screen/LED Customize] on the General setup menu in step 3. Refer to “General Setup Operation” (page 43).

Setting the Brightness of the Backlighting

Backlighting is provided by a fluorescent light built into the liquid crystal panel. The illumination control adjusts the brightness of the backlighting based on the car ambient lighting for easier viewing.

Setting item: Dimmer Setting contents: Auto (Initial setting) / On / Off

Auto: Adjust the brightness of the background illumination of

the monitor automatically to the brightness of the car interior.

On: Keep the background illumination of the monitor dark. Off: Deactivate Auto Dimmer mode to keep the background

illumination of the monitor bright.

Adjusting the Touch Panel

Adjustment becomes necessary when the display position on the LCD and the touch position on the touch panel do not match.

Setting item: Screen Alignment

Touch [Screen Alignment] in the Screen/LED Customize screen.

The adjustment screen appears.

Accurately touch the mark provided in the upper left corner of the screen.

Accurately touch the mark provided in the lower right corner of the screen.

This completes adjustment, and returns to the previous screen.

• If you touch [ done and returns to the previous screen.

Cancel] on the adjustment screen, no adjustment is

• When “Auto” or “On” is set, the setting is also applied for the button

lighting in “Adjusting the Dimmer of Button Lighting at Night” (page 45), and “Adjusting the Minimum Level of Backlight” (page 45).

Adjusting the Minimum Level of Backlight

You can adjust the brightness of the backlight. This function could be used, for instance, to change the screen brightness while traveling at night.

Setting item: Screen Dimmer Level Setting content: -15 to +15 (Initial setting: 0)

You can adjust the level between MIN (-15) and MAX (+15). When it reaches the minimum or maximum point, the display shows “MIN” or “MAX” respectively.

Adjusting the Dimmer of Button Lighting at Night

You can adjust the brightness of the button lighting at night with the dimmer.

Setting item: Key Illumination Level Setting level: -2 to +2 (Initial setting: 0)

Switching the Display Color

You can choose from 5 different display colors.

Setting item: Screen Color Setting contents: Blue / Red / GM GREEN (Initial setting) /

Amber / Black

Initializing the Touch Panel Corrected Values

Initialize the corrected values adjusted by Adjusting the Touch Panel.

Touch [Screen Alignment Reset] in the Screen/ LED Customize screen.

After the confirmation message appears, touch [OK].

The corrected values are initialized.

Visual Setting

[Visual] is selected on the General setup menu in step 3. Refer to “General Setup Operation” (page 43).

Touch the desired item.

• “Video” can be selected while a video is playing.

45-EN

Touch [] of the desired item.

Settable items differ depending on the application.

[Video] (Video media):

Display Mode / Live Contrast / Visual EQ / Brightness / Color / Tint / Contrast / Sharp

[Direct Camera]*:

Live Contrast / Brightness / Color / Contrast

[AUX Camera]*:

Live Contrast / Brightness / Color / Contrast

[Navigation]:

Brightness / Contrast

* The camera names set under the “Direct Camera/AUX Camera”

settings are displayed. The camera names are not displayed when “Off” is set (pages 64, 65).

Touch [] or [] to change its setting.

Touch [] to return to the previous screen.

• Immediately after changing the settings of Display Setup (While the

system is writing data automatically) do not turn the ignition key to OFF. Otherwise, the settings may not be changed.

Switching Display Modes

Setting item: Display Mode Setting contents: WIDE (Initial setting) / CINEMA / NORMAL

In WIDE mode, the monitor displays a normal picture wider to fit in a wide-screen monitor by evenly stretching out the picture horizontally.

Adjusting the Live Contrast

This function automatically adjusts the areas on the screen that are too bright or too dark and corrects them to natural brightness.

Setting item: Live Contrast Setting contents: OFF (Initial setting) / LOW / HIGH

Selecting the Visual EQ Mode (Factory’s setting)

You can select a mode suitable for the subject image.

Setting item: Visual EQ Setting contents: OFF (Initial setting) / NIGHT M. / SOFT /

SHARP / CONTRAST

OFF: Initial Setting NIGHT M.: Suitable for movies in which dark scenes

frequently appear.

SOFT: Suitable for CGs and animated films. SHARP: Suitable for old movies where images are not

clearly shown.

CONTRAST: Suitable for recent movies.

• To return to the default video settings, set this function to OFF. Any Visual EQ selection or changes made are reset their initial settings.

Adjusting Brightness

Setting item: Brightness Setting content: -15 to +15 (Initial setting: 0)

You can adjust the brightness between MIN (-15) and MAX (+15). When it reaches the minimum or maximum point, the display shows “MIN” or “MAX” respectively.

Adjusting Color of Picture

Setting item: Color Setting content: -15 to +15 (Initial setting: 0)

You can adjust the Color between MIN (-15) and MAX (+15). When it reaches the minimum or maximum point, the display shows “MIN” or “MAX” respectively.

In CINEMA mode, the monitor displays a normal picture by stretching out the picture horizontally and vertically. This mode is good for displaying a cinema type picture at the 16:9 ratio.

In NORMAL mode, the monitor displays a normal picture at the center of the screen with a vertical black band at each side.

46-EN

Adjusting Tint of Picture

Setting item: Tint Setting content: R15 to G15 (Initial setting: 0)

Adjust the Color from R15 to G15.

Adjusting Image Contrast

Setting item: Contrast Setting content: -15 to +15 (Initial setting: 0)

You can adjust the contrast between LOW (-15) and HIGH (+15). When it reaches the minimum or maximum point, the display shows “LOW” or “HIGH” respectively.

Adjusting Picture Quality

Setting item: Sharp Setting content: -5 to +5 (Initial setting: 0)

Picture quality adjustment range is -5 to +5. “SOFT” and “HARD” appear as the minimum and maximum values specified.

Saving and calling the adjusted picture quality

When adjusting audio (video media), you can store the settings made for “Adjusting Live Contrast, Brightness, Color, Tint, Contrast and Sharp”.

Setting item: Preset1 / Preset2

1 After completing “Adjusting Live Contrast, Brightness,

Color, Tint, Contrast and Sharp” (page 46), touch and hold [Preset1] or [Preset2] to save the settings.

2 Touch [Preset1] or [Preset2] to call the saved settings.

• Display Mode cannot be registered.

About X009

Touch [About] on the General setup menu in step 3. Refer to “General Setup Operation” (page 43).

Displaying the Product Information

Checking the DivX® Registration

This unit will display the registration code required to play a DivX® VOD (Video On Demand), or you can also display the deregistration code.

Setting item: Warranty / Copyright Information

Displaying the Registration Code

Touch [Warranty/Copyright Information].

Touch [DivX(R) VOD].

Touch [Registration].

The registration code is displayed on the screen.

Touch [OK].

Displaying the Deregistration Code

Touch [Warranty/Copyright Information].

Touch [DivX(R) VOD].

Touch [Deregistration].

The confirmation dialog screen appears.

Touch [OK].

The deregistration code is displayed on the screen.

• When you have finished, touch [Cancel]. If you want to continue and display a new registration code, touch [OK], check the registration code, and then touch [OK] again.

Initializing the System

You can initialize all data, to restore the factory settings. Remove the CD/DVD disc, etc. from the system before operation

Setting item: Restore Factory Setting

You can view the version information of this product. Make note of this information and refer to it whenever you contact Alpine Tech Support or an Alpine-authorized dealer.

Setting item: Version Information Contents: Serial No. / Firmware Version

Touch [Restore Factory Setting].

After the confirmation message appears, touch [OK].

The confirmation screen appears again.

Touch [OK].

The system starts initialization.

• Do not turn on/off the power, change the ignition key position or remove the screen panel until system restart is completed.

47-EN

Installation Setup

[Installation] is selected on the General setup menu in step 3. See “General Setup Operation” (page 43).

Setting item: Installation

The Installation check screen is displayed.

Setting the External Audio Processor On/Off

[External Audio Processor] is selected on the General setup menu in step 3. Refer to “General Setup Operation” (page 43). When a compatible external audio processor is connected, please set this item to “On”.

Setting item: External Audio Processor Setting contents: Off (Initial setting) / On

Off: The connected audio processor is not

recognized by X009.

On: The connected audio processor is recognized

by X009.

Sound Setup

Sound Setup Operation

To display the Sound Setup Menu screen:

Your vehicle must be parked with the ignition key in the ACC or ON position. To do this, follow the procedures below.

1 Bring your vehicle to a complete stop at a safe

location. Engage the parking brake.

2 Keep pushing the foot brake and release the parking

brake once then engage it again.

3 When the parking brake is engaged for the second

time, release the foot brake.

• For automatic transmission vehicles, place the transmission lever

in the Park position.

Now, the locking system for the Sound mode operation has been released. Engaging the parking brake can reactivate the Sound Setup Menu, as long as the car’s ignition has not been turned off. It is not necessary to repeat the above procedure (1 through 3) of “To display the Sound mode screen.” Each time the ignition is turned OFF, perform the procedure of “To display the Sound mode screen.”

The following steps 1 to 5 are common operations to each “Setting item” of Sound Setup. Refer to each section for details.

Touch [Setup] icon of Top banner.

The Setup main screen is displayed.

Touch [Sound].

• Some items of Sound Setup cannot be adjusted from this unit when

External Audio Processor is set to On.

• Press and hold

Processor is set to On .

AUD IO button is invalid when External Audio

Setting the Digital Output

[Optical] is selected on the General setup menu in step 3. Refer to “General Setup Operation” (page 43). To connect an audio processor using optical digital output, set to “On” by the following procedure.

Setting item: Optical Setting contents: Off (Initial setting) / On

• This setting is available only when External Audio Processor is set to

On. Refer to “Setting the External Audio Processor On/Off” (page 48).

• If Optical is set to On, the Optical ( ) indicator appears.

and buttons are invalid when Optical is set to On.

• ,

The Sound Setup screen appears.

Select the desired item.

Setting items: Balance/Fader/Subwoofer*

EQ Presets Time Correction Source Volume Setup

/ Parametric EQ*1 /

/ X-Over*1 / Defeat*1 / Volume /

/ Media Xpander*

48-EN

*1 These items cannot be adjusted when External Audio Processor

is set to On, refer to “Setting the External Audio Processor On/ Off” (page 48).

This item cannot be adjusted when Optical is set to On, refer to

“Setting the Digital Output” (page 48).

Touch [] or [] etc., to change its setting.

• When the pop-up window for setup is displayed, touch [] to

close the window after setting.

Touch [] to return to the previous screen.

• Immediately after changing the Sound Setup (while the system is

writing data automatically) do not turn the ignition key to OFF. Otherwise, the settings may not be changed.

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 29).

• When BASS ENGINE SQ mode is selected or TuneIt is launched,

some setting items are not adjustable. Refer to “BASS ENGINE SQ mode” (page 24)/“Applying TuneIt” (page 25).

Setting the Balance/Fader/Subwoofer

Turning Subwoofer ON/OFF

If an optional subwoofer is connected to the unit, make the following setting.

Setting item: SubW. Setting contents: On / Off (Initial setting)

• Note that if you select “Off” when Subwoofer Installed in Car Specific Sound Setup is set to “Yes”, the setting in Car Specific Sound Setup will be canceled.

Adjusting the Subwoofer Level

You can set the Subwoofer level when a Subwoofer is connected.

Setting item: SubW. LEVEL Setting contents: 0 to 15 (Initial setting: 0)

• If the Subwoofer setting is “Off”, the setting cannot be set.

[Balance/Fader/Subwoofer] is selected on the Audio setup menu in step 3. Refer to “Sound Setup Operation” (page 48).

Image area

Setting the Balance/Fader

Touch the desired point within the image area. Or touch [] [] [] [].

Balance: L15 to R15 Fader: F15 to R15

Rear Speaker Setting

You can set the rear speaker output to “Off”.

Setting item: Rear Speaker Setting contents: On (Initial setting) / Off

• Note that if you select “Off” when the Rear Speaker Position in Car

Specific Sound Setup is set to “Rear Deck” or “Rear Door/Panel”, the setting in Car Specific Sound Setup will be canceled.

Setting the Subwoofer Phase

The subwoofer output phase is toggled Subwoofer Normal (0°) or Subwoofer Reverse (180°).

Setting item: SubW. Phase Setting contents: 0° (Initial setting) / 180°

• If the Subwoofer setting is “Off”, the setting cannot be set.

Setting the MX (Media Xpander)

[Media Xpander] is selected on the Audio setup menu in step 3. Refer to “Sound Setup Operation” (page 48). When the currently playing source is AM radio band, this option is not available. MX (Media Xpander) makes vocals or instruments sound distinct regardless of the music source. The HD Radio, CD, Flash memory and iPod/iPhone, will be able to reproduce the music clearly even in cars with a lot of road noise.

Setting item: Media Xpander

Touch [ON] of “ALL MX OFF/ON” in the MX setup screen.

49-EN

Touch any of [] [] [] [].

Media

SiriusXM

DVD

Compressed Media

Pandora

AUX/AUX3

HD Radio

HDMI

iDataLink

• The MX setting can be performed only when a source is currently

selected.

• MP3/WMA/AAC/iPod/USB/DivX

Audio correspond to MX Compressed Media.

MX SiriusXM

The medium to high frequencies become more clear, and produces well balanced sound in all the bands.

MX DVD

(Movie)

The dialog portion of the video is reproduced more clearly

(DVD Music)

This disc contains a large quantity of data such as music clip. MX uses this data to reproduce the sound accurately.

MX CD

CD mode processes a large quantity of data. This data is used to reproduce the sound cleanly by making use of the data quantity.

MX Compressed Media

This corrects information that was omitted at the time of compression. This reproduces a well-balanced sound close to the original.

MX Pandora

This corrects information that was omitted at the time of compression. This reproduces a well-balanced sound close to the original.

MX AUX /AU X3

Choose the MX mode (Compressed Media, Movie, or Music) that corresponds to the media connected.

MX HD Radio

The medium to high frequencies become more clear, and produces well balanced sound in all the bands.

HDMI

Choose the MX mode (Compressed Media, Movie, or Music) that corresponds to the media connected.

iDataLink

This corrects information that was omitted at the time of compression. This reproduces a well-balanced sound close to the original.

• To cancel MX mode for all music applications, set MX to “Off” in

step 1.

• Each music applications, such as HD Radio, CD, and

MP3/WMA/AAC can have its own MX setting.

• Setting to MX sets MX mode of each music applications to “Off”.

• There is no MX mode for AM radio.

• The function is inoperable when Defeat is set to “On”.

OFF 1 2 3

Level

/Bluetooth Pandora/Bluetooth

Equalizer Presets

[EQ Presets] is selected on the Sound setup menu in step 3. Refer to “Sound Setup Operation” (page 48). 10 typical equalizer settings are preset at the factory for a variety of musical source material.

Setting item: EQ Presets Setting contents: FLAT (Initial setting) / POP / ROCK / NEWS /

• Only one type can be set to ON.

• When Equalizer Presets setting is edited, a Download Sound setting

is disabled.

• When Equalizer Presets is set, the linked Parametric EQ settings are also changed. We recommend storing Parametric EQ settings in a Preset in advance.

• The Equalizer Presets setting can be configured when Defeat is “Off”.

JAZZ / ELECTRONIC / HIP HOP / EASY LISTENING / COUNTRY / CLASSICAL

Adjusting the Parametric Equalizer Curve (Parametric EQ)

[Parametric EQ] is selected on the Sound setup menu in step 3. Refer to “Sound Setup Operation” (page 48). You can modify the Equalizer settings to create a response curve more appealing to your personal taste.

Setting item: Parametric EQ

Adjust the Parametric EQ to your preference.

Adjusting the Band

Touch [Band] to select the band to be adjusted.

Band1 Band2

• You can select a band directly by touching the screen.

···

Band8 Band9

50-EN

Adjusting the Frequency

Touch [] or [] of “Freq.” to adjust the frequency of the selected band.

Adjustable frequency bands: 20 Hz to 20 kHz (in 1/3 octave steps)

Band1: 20 Hz~100 Hz (63 Hz) Band2: 63 Hz~315 Hz (125 Hz) Band3: 125 Hz~500 Hz (250 Hz) Band4: 250 Hz~1 kHz (500 Hz) Band5: 500 Hz~2 kHz (1 kHz) Band6: 1 kHz~4 kHz (2 kHz) Band7: 2 kHz~7.2 kHz (4 kHz) Band8: 5.8 kHz~12 kHz (8 kHz) Band9: 9 kHz~20 kHz (16 kHz)

Adjusting the Level

Touch [] or [] of “Level” to adjust the level of selected band.

Setting contents: -7 to +7 (Initial setting: 0)

Setting the Bandwidth

Touch [] or [] of “Q Adjust” to select the bandwidth.

Setting contents: Wide (Initial setting) / Medium / Narrow

To adjust another band, repeat step 1, and adjust all bands.

To store the adjusted setting value, touch and hold [Preset1], [Preset2], or [Preset3] for at least 2 seconds.

• BAND2 and BAND8 are the same as the Bass and Treble controls.

Their Level adjustment can also be controlled by pressing and holding / AUDIO and selecting Bass Level or Treble Level. Refer to “Easy Sound Setup mode” on page 24.

• Settings exceeding the frequency of adjacent bands are not available.

• While adjusting the Parametric EQ, you should consider the

frequency response of the connected speakers.

• When the parametric EQ is adjusted, the Equalizer Presets are

overridden.

• When Equalizer Presets is set, the linked Parametric EQ settings are

also changed. We recommend storing Parametric EQ settings in a Preset in advance.

• Touch [Flat] to initialize all values.

• The Parametric EQ setting can be configured when Defeat is “Off”.

Calling the Parametric EQ adjusted value

Calling the pre-set Parametric EQ adjusted value.

Touch [Preset1], [Preset2], or [Preset3] on the Parametric EQ screen.

The setting stored in the Preset will be recalled.

Adjusting the Time Correction (Time Correction)

[Time Correction] is selected on the Sound setup menu in step 3. Refer to “Sound Setup Operation” (page 48). Before performing the following procedures, refer to “About Time Correction” (page 53).

Setting item: Time Correction

Touch [cm], [inch] or [ms] to select mode for making adjustments.

Each time you touch, the onscreen button and correction mode changes.

Correction mode

cm/inch: Adjust listening position and distance from each speaker. ms: Adjust time.

Touch [] or [] for each speaker to adjust the time or distance.

0.0 msec to 9.9 msec (0.1 msec/step)

0.0 cm (0.0 inch) to 336.6 cm (132.7 inch) (3.4 cm/step) All speaker setting values are adjustable in the range of 15 ms or 510 cm.

To store the adjusted setting value, touch and hold [Preset1], [Preset2], or [Preset3] for at least 2 seconds.

• Touch [Flat] to set all values to 0.0.

• If the Rear Speaker setting is “Off”, the Rear Speaker setting cannot

be edited (refer to page 49).

• If the Subwoofer setting is “Off”, the Subwoofer setting cannot be edited (refer to page 49).

Calling the Time Correction Value

Calling the pre-set time correction value.

Touch [Preset1], [Preset2], or [Preset3] on the time correction screen.

The setting stored in the Preset will be recalled.

51-EN

Adjusting the Crossover Settings (X-Over)

[X-Over] is selected on the Sound setup menu in step 3. Refer to “Sound Setup Operation” (page 48). Before performing the following procedures, refer to “About the Crossover” (page 54).

Setting item: X-Over

Touch [Channel] to select the channel.

Each time you touch, the channel switches.

• The channel being adjusted is displayed in red.

Front HPF Rear HPF Subw. LPF

Adjust the crossover to your preference.

To store the adjusted setting value, touch and hold [Preset1], [Preset2], or [Preset3] for at least 2 seconds.

• Touch [Flat] to initialize all values.

• If the Rear Speaker setting is “Off”, the Rear Speaker setting cannot

be edited (refer to page 49).

• If the Subwoofer setting is “Off”, the Subwoofer setting cannot be edited (refer to page 49).

• While adjusting the X-Over you should consider the frequency response of the connected speakers.

Calling the X-Over adjusted value

Calling the pre-set X-Over adjusted value.

Touch [Preset1], [Preset2], or [Preset3] on the X-Over screen.

The setting stored in the Preset will be recalled.

Setting Defeat

[Defeat] is selected on the Sound setup menu in step 3. Refer to “Sound Setup Operation” (page 48). If Defeat is “On”, MX, Equalizer Presets, Car Specific Sound Setup and Parametric EQ functions are turned OFF. This disables any settings made for these functions.

Setting item: Defeat Setting contents: Off (Initial setting) / On

Selecting the Cut-Off Frequency

Touch [] or [] of “Freq.”, and then select the cut-off frequency.

Setting contents: 20 / 25 / 31.5 / 40 / 50 / 63 / 80 (Initial setting) /

Adjusting the Slope

Touch [] or [] of “Slope”, and then adjust the HPF or LPF slope.

Setting contents: 0 (Initial setting) / 6 / 12 / 18 / 24 dB/oct.

Adjusting the Level

Touch [] or [] of “Level”, and then adjust the HPF or LPF level.

Setting contents: -12 to 0 dB (Initial setting: 0)

Repeat steps 1 to 2 to make adjustment to the other channels.

100 / 125 / 160 / 200 Hz

Volume Setting

[Volume] is selected on the Sound setup menu in step 3. Refer to “Sound Setup Operation” (page 48). You can change the volume of the sound heard when a button is touched.

Setting item: Key Sound Feedback Setting contents: 0 to 7 (Initial setting: 4)

Setting the Volume for Each Source

[Source Volume Setup] is selected on the Sound setup menu in step 3. Refer to “Sound Setup Operation” (page 48). The volume level for each application can be adjusted.

Setting item: Radio / SiriusXM / DVD / CD / Compressed Media /

iPod Music / iPod Video / HDMI / Pandora / AUX / AUX3 / Bluetooth Audio / iDataLink

Setting contents: -14 to +14 (Initial setting: 0)

• Settable source differ depending on the connected device and settings.

52-EN

About Time Correction

The distance between the listener and the speakers in a car vary widely due to the complex speaker placement. This difference in the distances from the speakers to the listener creates a shift in the sounds image and frequency characteristics. This is caused by the time delay between the sound reaching the listener’s right versus the left ear. To correct this, this unit is able to delay the audio signal to the speakers closest to the listener. This effectively creates a perception of increased distance for those speakers. The listener can be placed at an equal distance between the left and right speakers for optimum staging. The adjustment will be made for each speaker in 3.4 cm steps.

Example 1. Listening Position: Front Left Seat

Adjust the time correction level of the front left speaker to a high value and the rear right to zero or a low value.

5.1ms

0.5m

2.25m

The sound is not balanced because the distance between the listening position and the various speakers is different. The difference in distance between the front left speaker and the rear right speaker is 1.75 m (68-7/8"). Here we calculate the time correction value for the front left speaker in the diagram on the above.

Conditions: Farthest Speaker – listening position : 2.25 m (88-9/16") Front left speaker – listening position : 0.5 m (19-11/16") Calculation: L = 2.25 m – 0.5 m = 1.75 m (68-7/8") Time correction = 1.75 ÷ 343* × 1,000 = 5.1 (ms)

* Speed of sound: 343 m/s (765 mph) at 20°C

In other words, giving the front left speaker a time correction value of

5.1 ms makes it seem as if its distance from the listener is the same as the distance to the farthest speaker.

Time correction eliminates the differences in the time required for the sound to reach the listening position. The time of the front left speaker is corrected by 5.1 ms so that its sound reaches the listening position at the same time as the sound of other speakers.

Example 2. Listening Position: All Seats

Adjust the time correction level of each speaker to almost the same level.

Sit in the listening position (driver’s seat, etc.) and measure the distance (in meters) between your head and the various speakers.

Calculate the difference between the distance correction value to the farthest speaker and the other speakers.

L = (distance to farthest speaker) – (distance to other

speakers)

These values are the time correction values for the different speakers. Setting these values to make each sound reach the listening position at the same time as the sound of other speakers.

Time Correction Value List

Time

Difference

(msec)

Distance

(cm)

0.0 0.0 0.0 5.1 173.4 68.3

0.1 3.4 1.3 5.2 176.8 69.7

0.2 6.8 2.7 5.3 180.2 71.0

0.3 10.2 4.0 5.4 183.6 72.4

0.4 13.6 5.4 5.5 187.0 73.7

0.5 17.0 6.7 5.6 190.4 75.0

0.6 20.4 8.0 5.7 193.8 76.4

0.7 23.8 9.4 5.8 197.2 77.7

0.8 27.2 10.7 5.9 200.6 79.1

0.9 30.6 12.1 6.0 204.0 80.4

1.0 34.0 13.4 6.1 207.4 81.7

1.1 37.4 14.7 6.2 210.8 83.1

1.2 40.8 16.1 6.3 214.2 84.4

1.3 44.2 17.4 6.4 217.6 85.8

1.4 47.6 18.8 6.5 221.0 87.1

1.5 51.0 20.1 6.6 224.4 88.4

1.6 54.4 21.4 6.7 227.8 89.8

1.7 57.8 22.8 6.8 231.2 91.1

1.8 61.2 24.1 6.9 234.6 92.5

1.9 64.6 25.5 7.0 238.0 93.8

2.0 68.0 26.8 7.1 241.4 95.1

2.1 71.4 28.1 7.2 244.8 96.5

2.2 74.8 29.5 7.3 248.2 97.8

2.3 78.2 30.8 7.4 251.6 99.2

2.4 81.6 32.2 7.5 255.0 100.5

2.5 85.0 33.5 7.6 258.4 101.8

2.6 88.4 34.8 7.7 261.8 103.2

2.7 91.8 36.2 7.8 265.2 104.5

2.8 95.2 37.5 7.9 268.6 105.9

2.9 98.6 38.9 8.0 272.0 107.2

3.0 102.0 40.2 8.1 275.4 108.5

3.1 105.4 41.5 8.2 278.8 109.9

3.2 108.8 42.9 8.3 282.2 111.2

3.3 112.2 44.2 8.4 285.6 112.6

3.4 115.6 45.6 8.5 289.0 113.9

3.5 119.0 46.9 8.6 292.4 115.2

3.6 122.4 48.2 8.7 295.8 116.6

3.7 125.8 49.6 8.8 299.2 117.9

3.8 129.2 50.9 8.9 302.6 119.3

3.9 132.6 52.3 9.0 306.0 120.6

4.0 136.0 53.6 9.1 309.4 121.9

Distance

(inch)

Time

Difference

(msec)

Distance

(cm)

Distance

(inch)

53-EN

4.1 139.4 54.9 9.2 312.8 123.3

4.2 142.8 56.3 9.3 316.2 124.6

4.3 146.2 57.6 9.4 319.6 126.0

4.4 149.6 59.0 9.5 323.0 127.3

4.5 153.0 60.3 9.6 326.4 128.6

4.6 156.4 61.6 9.7 329.8 130.0

4.7 159.8 63.0 9.8 333.2 131.3

4.8 163.2 64.3 9.9 336.6 132.7

4.9 166.6 65.7

5.0 170.0 67.0

About the Crossover

Crossover (X-Over):

This unit is equipped with an active crossover. The crossover limits the frequencies delivered to the outputs. Each channel is controlled independently. Thus, each speaker pair can be driven by the frequencies for which they have been optimally designed. The crossover adjusts the HPF (high pass filter) or LPF (low pass filter) of each band, and also the slope (how fast the filter rolls off the highs or lows). Adjustments should be made according to the reproduction characteristics of the speakers. Depending on the speakers, a passive network may not be necessary. If you are unsure about this point, please consult your authorized Alpine dealer.

• HPF (high pass filter): Cuts the lower frequencies and allows the

higher frequencies to pass.

• LPF (low pass filter): Cuts the higher frequencies and allows the lower frequencies to pass.

• Slope: The level change (in dB) for a frequency change of one octave.

• The higher the slope value, the steeper the slope becomes.

• Adjust the slope to FLAT to bypass the HP or LP filters.

• Do not use a tweeter without the HPF on or set to a low frequency, as

it may cause damage to the speaker due to the low frequency content.

• You cannot adjust the crossover frequency higher than the HPF or lower than the LPF.

• Adjustment should be made according to the recommended crossover frequency of the connected speakers. Determine the recommended crossover frequency of the speakers. Adjusting to a frequency range outside that recommended may cause damage to the speakers. For the recommended crossover frequencies of Alpine speakers, refer to the respective Owner’s Manual. We are not responsible for damage or malfunction of speakers caused by using the crossover outside the recommended value.

Low range speaker

Rear high range speaker

Front high range speaker

Level adjusting (0 to –12 dB)

20 Hz

Cut-off frequency (1/3 octave steps)

HPF LPF HPF LPF

20 Hz -

---200 Hz

20 Hz 200 Hz

HPF cut-off frequency

----

Low range High range

(Different from actual display)

Output frequency range

LPF cut-off frequency

Slope

---–

FLAT, –6, –12, –18,

–24 dB/oct.

FLAT, –6, –12, –18,

–24 dB/oct.

Slope adjusting

(Different from actual display)

FLAT, –6, –

12, –18,

24 dB/oct.

----

Slope FLAT

Level

0 to

–12 dB

0 to

–12 dB

0 to

–12 dB

54-EN

Source Setup

Source Setup Operation

Source Layout Setting

[Source Layout] is selected on the Source setup menu in step 3. Refer to “Source Setup Operation” (page 55).

To display the Source Setup Menu screen:

Your vehicle must be parked with the ignition key in the ACC or ON position. To do this, follow the procedures below.

1 Bring your vehicle to a complete stop at a safe

location. Engage the parking brake.

2 Keep pushing the foot brake and release the parking

brake once then engage it again.

3 When the parking brake is engaged for the second

time, release the foot brake.

• For automatic transmission vehicles, place the transmission lever

in the Park position.

Now, the locking system for the Source mode operation has been released. Engaging the parking brake can reactivate the Source Setup Menu, as long as the car’s ignition has not been turned off. It is not necessary to repeat the above procedure (1 through 3) of “To display the Source mode screen.” Each time the ignition is turned OFF, perform the procedure of “To display the Source mode screen.”

The following steps 1 to 5 are common operations to each “Setting item” of Source Setup. Refer to each section for details.

Touch [Setup] icon of Top banner.

The Setup main screen is displayed.

Touch [ (Source)].

The Source Setup screen appears.

Setting the Slide Source Change

You can set whether to switch sources by swiping from the designated area of the Audio/Visual Playback screen from right to left or from left to right. Refer to “Switching Sources” (page 28).

Setting item: Slide Source Change Setting contents: On (Initial setting) / Off

On: Source is changed by a swipe gesture. Off: Source is not changed by a swipe gesture.

Setting the Easy Sound Setup Position

You can select this menu displayed on left or right of screen.

Setting item: Sound Setup Position Setting contents: Left (Initial setting) / Right

Customizing the Source Banner

You can customize the Source Banner order as you prefer. The source switching order is displayed according to your changes.

Select the desired item.

Setting items: Source Layout / Disc / SiriusXM / Auxiliary (AUX) /

Touch [] or [] etc., to change its setting.

• When the pop-up window for setup is displayed, touch [] to

Touch [] to return to the previous screen.

• Immediately after changing the Source Setup (while the system is

writing data automatically) do not turn the ignition key to OFF. Otherwise, the settings may not be changed.

Rear Seat Entertainment (RSE) / Bluetooth Pandora / TuneIt

close the window after setting.

Setting item: Source Banner Customize

Take adjusting the order of Disc and AUX 1 as an example:

Touch the desired source icon ([Disc] etc.).

The [Disc] source icon is displayed highlighted. Touch this icon again to cancel.

Touch another source icon ([AUX 1] etc.).

The Source Banner positions for [Disc] and [AUX 1] are swapped.

55-EN

Disc Setting

Touch [Disc] on the Source setup menu in step 3. Refer to “Source Setup Operation” (page 55).

• You can perform DVD setup in DVD video mode.

• Touch [Stop] before performing Disc setup.

Changing the language setting

The audio language, subtitle language and menu language can be set according to your preferences. Once set, this becomes the default language. This function is convenient if you always want to listen in English, for example. (The language setting is not effective on some discs. In this case, the default language is set at the factory.)

• When the settings are changed, old settings are overwritten. Make a

note of the current settings before making changes.

• To temporarily change the language of the current disc, either do so

from the DVD menu or by using the operation described in the section “Switching the Audio Tracks” (page 42).

• If the disc does not include the selected language, the disc’s default

language is set.

To play in a language other than those displayed

1 Touch [DVD Menu Language Code], [Audio Language

Code] or [Subtitle Language Code].

The numeric keypad screen is displayed.

2 Touch the 4-digit numeral of the language number.

To reference language numbers, refer to “List of Language Codes” (page 97).

3 Touch [OK] to memorize the number.

• The setting content changes to “Other” if the desired language code

is input.

Setting of the Menu Language

Set the language used for the menus (title menu, etc.).

Setting item: DVD Menu Language Setting contents: Auto (Initial setting) / EN / JP / DE / ES / FR / IT /

SE / RU / CN

• When “Auto” is selected, the primary menu language among the

recorded ones is played.

• As for the language abbreviation, refer to “List of Language Codes”

(page 97).

Setting of the Audio Language

Set the audio language produced from the speakers.

Setting item: Audio Language Setting contents: Auto (Initial setting) / EN / JP / DE / ES / FR / IT /

SE / RU / CN

• When “Auto” is selected, the primary audio language among the

recorded ones is applied.

• As for the language abbreviation, refer to “List of Language Codes”

(page 97).

Setting of the Subtitle Language

Set the language of the subtitles displayed on the screen.

Setting item: Subtitle Language Setting contents: Auto (Initial setting) / EN / JP / DE / ES / FR / IT /

SE / RU / CN

• When “Auto” is selected, the primary subtitle language among the

recorded ones is applied.

• As for the language abbreviation, refer to “List of Language Codes”

(page 97).

Changing the Country Code Setting

Set the country code for the country which you want to set the rating level (Parental lock).

Setting item: Country Code Setting contents: Auto (Initial setting) / Other

Auto: The primary country code among those recorded is

played.

Other: The setting content changes to “Other” if the desired

country code is input.

• If settings are changed, the old settings are overwritten. Make a note

of the current settings before making changes. The settings will be cleared if the vehicle’s battery is disconnected.

1 Touch [Country Code Input]. 2 Touch [] or [Delete All].

Delete the displayed country number.

3 Touch the 4-digit country code.

As for the country number, refer to “List of Country Codes” (page 98).

4 Touch [OK] to memorize the code.

Setting the Rating Level (Parental Lock)

This function can help limit the viewing of movies to children of appropriate age levels only.

Setting item: Parental Controls

• If settings are changed, the old settings are overwritten. Make a note

of the current settings before making changes. The memory will be cleared if the vehicle’s battery is disconnected.

• On unrated discs, playback will not be restricted even if the rating

level is set.

• If you want to play back a disc with parental lock, and its use is

currently restricted, change the rating level and the country number in order to play back the disc.

• Once set, this rating level remains in memory until changed. To

enable playback of discs of higher rating levels, or to cancel the parental lock, the setting must be changed.

• Not all discs provide a parental lock. If you are unsure about a disc,

play it first to confirm. Do not leave discs accessible to young children for whom you deem them inappropriate.

1 Touch [Parental Controls].

The numeric keypad screen is displayed.

2 Touch the numeric keypad to input a 4-digit password.

The initial number is 1111. Input number are displayed as “*”.

3 Touch [OK] to memorize the number.

The Parental Controls screen appears.

56-EN

Set the rating level of Parental Controls

4 Touch [Parental]. 5 Touch [ ] or [ ] to turn “On”.

Select “Off” to cancel parental lock or if you do not want

to set a rating level. 6 Touch [] to return to the previous screen. 7 Touch [Parental Level] 8 Touch [] or [] to select the rating level (1 to 8).

The smaller the number, the higher the restriction. 9 Touch [] to return to the previous screen.

Changing the password

1 Touch [Password Change].

The numeric keypad screen is displayed. 2 Touch the input screen to enter a new 4-digit password.

• Keep a note of the number somewhere safe in case you should

forget it.

3 Touch [OK] to memorize the number. 4 Touch [] to return to the previous screen.

Changing the rating level temporarily

Some discs may request that you change the rating level set in the default settings during playback. In this case, the message “Do you wish to change Parental level? [OK] [Cancel]”.

If this screen appears, change the level as follows:

• To change parental level and play, touch [OK].

When [OK] is touched, the numeric keypad input screen is displayed. Input the 4-digit password you set in “Setting the Rating Level (Parental Lock)”, then touch [OK].

• To play without changing the parental level, touch [Cancel].

(If [Cancel] is touched, playback will be at the parental level set in “Setting the Rating Level (Parental Lock)”.)

4:3 PAN-SCAN:

Select this when connected to a conventional 4:3 size monitor. The picture will fill the entire TV screen. However, due to the mismatch in aspect ratio, parts of the movie at the extreme left and right sides will not be visible (when playing a 16:9 size movie).

16:9 WIDE:

Select this when connected to a wide screen TV. This is the factory setting.

Setting the TV Screen Mode

Use the procedure described below to modify the output screen according to the type of TV monitor (rear monitor) being used. If the rear monitor is not connected, the screen setting is 16:9.

Setting item: TV Screen Setting contents: 4:3LB / 4:3PS / 16:9 (Initial setting)

• For some discs, the picture may not be set to the selected screen size.

(For details, refer to the explanation on the disc’s jacket.)

4:3 LETTER BOX:

Select this when connected to a conventional 4:3 size (normal TV aspect ratio) monitor. There may be black stripes visible at the top and bottom of the screen (when playing a 16:9 size movie). The width of these stripes will depend upon the original aspect ratio of the theatrical release of the movie.

57-EN

SiriusXM Setting

[SiriusXM] is selected on the Source setup menu in step 3. Refer to “Source Setup Operation” (page 55).

Managing Artist, Song and Sports Team Alerts

The following operations can be performed to manage the stored Songs, Artists and Sports teams information. (To learn about how to store the information, refer to “Storing the desired Song/Artist” on page 83 and “Setting the Favorite Sports Team Alerts” on page 58.)

Setting item: Alert Setup

Setting ON/OFF of all Songs/Artists/Games Alert

This menu option allows you to temporarily disable the Artist/Song/ Game Alerts for all Artists/Songs/Games. When the Alerts are re-enabled, individual Artist/Song/Game Alert disabled in the Alert List menu setting remain disabled.

Touch [Alert].

Touch [] or [] of the Alert to select ON/OFF.

If On is set, the alert for all stored Artists/Songs/Games is enabled. If Off is set, the alerts for all stored Artists/Songs/Games are disabled.

Deleting all stored Alert

This operation will delete all alerts (artists, songs and teams) stored in memory.

Touch [Delete All].

A message is displayed.

Touch [OK] to clear the information of all stored Artist, Song, and Game alert items.

Touch [Cancel] to cancel.

Setting the Favorite Sports Team Alerts

Setting the Alert individually for an Artist/Song/Sport Team

This menu option allows you to enable the Artist/Song/Team alert for individual Artists/Songs/Teams (On or Off) or to delete individual stored Artist/Song/Team alerts (Delete).

Touch [Alert list].

The Alert List screen is displayed.

Touch [ON] or [OFF] of the desired song, artist or team.

Set to ON to enable the alert for the Artist/Song or Team. Set to OFF to disable the alert for the Artist/Song or Team.

• To delete the list, touch [Delete], and then touch [OK].

This menu option allows you to select your favorite teams, organized by leagues, so that you will be alerted later when your favorite teams are playing on other channels.

Setting item: Game Alert Setup

Touch [Game Alert Setup].

A sports league list is displayed.

Select the desired league.

The display changes to the team list of the selected league.

Touch the abbreviations for your favorite teams.

Once selected, you will be alerted when games that those teams are playing in can be heard on a SiriusXM channel. A “Team Saved X Used/Y Empty” pop up screen is displayed. X is the total number of Artist/Song/Game alert items stored in memory, and Y is the total number of memory slots still available for storage.

• Teams that you have selected will be indicated with an asterisk “*”.

• If the memory is full, you cannot select a new team.

To add another team alert, you need to delete a selected one first. Touch the team (with “*” mark) you want to delete, a message will display. Touch [OK] to delete it and touch [Cancel] to cancel. You can also delete a team from the Alertlist, for details, refer to “Managing Artist, Song and Sports Team Alerts” on page 58.

58-EN

Setting the Parental Lock

You can lock out channels with passcode protection. Channels that are locked cannot be accessed without entering the passcode. You can unlock a channel or change the passcode using this menu option.

Setting item: Parental Lock

Touch [Parental Lock].

A passcode input screen is displayed.

Touch the numeric keypad to input a 4-digit passcode.

The initial default 4-digit passcode is set to 0000. After entering the digit, it is displayed as “*” (asterisk).

Touch [OK].

Or touch [] to cancel entry of the passcode or touch [Delete All] to erase the digits that you have entered so you can start over or touch [] to erase the last digit that you entered. After the correct passcode is entered, the Parental Lock options menu is display.

Changing the Lock Passcode

Touch [Edit Code].

The numeric keypad screen is displayed.

Use the keypad to enter the current (old) 4-digit passcode.

(The initial passcode is set to 0000). Touch [Enter] to confirm the entry. Touch [Delete All] to erase all of the digits that you entered. Touch [] to erase the last digit you entered. Touch [] to abort changing the passcode.

Now use the keypad to enter the new 4-digit passcode.

Touch [OK].

Then use the keypad to enter the new 4-digit passcode a second time to verify it.

• Remember to keep a note of the passcode in a safe place in case you

forget the code.

Clearing the Lock of ALL the locked Channels

Touch [Clear All Locked Channels].

Touch [OK] to clear the lock of all the locked channels.

Touch [Cancel] to cancel.

Setting the Lock status of individual channels

Touch [Locked Channels].

The channels list screen is displayed.

Select the desired channel.

Touch [] or [] to select On/Off.

Touch [] to return to the previous screen.

Signal Strength Information

While listening to a SiriusXM Channel, the Signal strength of the current channel will be displayed.

Setting item: Signal Indicator

This menu item displays the SiriusXM signal strength as Strong, Good, Weak or No Signal.

• If the Signal Indicator reports Weak or No Signal and your vehicle is

parked outside with no obstructions to the southern sky, then your SiriusXM antenna may not be properly installed or may have become damaged.

59-EN

Auxiliary (AUX) Setting

[Auxiliary (AUX)] is selected on the Source setup menu in step 3. Refer to “Source Setup Operation” (page 55).

Setting the Auxiliary (AUX) Mode

Setting item: AUX 1 In Setting contents: Off / On (Initial setting)

Off: AUX source is not displayed. On: AUX source is displayed.

Setting the AUX3

Connection with external input devices is available through the iPod VIDEO connector. An optional adapter cable is required (standard RCA to 3.5ø mini-phono plug or 3.5ø to 3.5ø mini phono plug). You can also play back video connecting with an optional AV cable (4-pole mini AV plug to 3-RCA).

Setting item: AUX 3 Source Select Setting contents: iPod Video (Initial setting) / AUX 3

iPod Video: Set when connected to an iPod or iPhone. AUX 3: Set when connected to an external input device.

Setting the Primary Auxiliary (AUX) Name (AUX 1 Setup)

When AUX 1 In is set to “ON”, this setting is available.

Setting item: Primary Name Setting contents: AUX 1 (Initial setting) / DVD / GAME / EXT.DVD /

DVD-CHG / DVB-T / TV

• When a DVB-T tuner is connected, you can use it to connect one

more External Input device. Setting the Secondary name can change the mode name display of this device.

Setting the Secondary Auxiliary (AUX) Name

Secondary name can be set only when Primary name is set to “DVB-T”.

Setting item: Secondary Name Setting contents: OFF (Initial setting) / AUX 2 / DVD / GAME /

EXT.DVD / DVD-CHG / DVB-T* / TV

• The selected source name is displayed instead of Auxiliary (AUX)

mode name.

* If the Primary Name is DVB-T, DVB-T is not displayed as a

Secondary Name option.

Switching the Visual Input Signal System

After setting to “On” in “Setting the Auxiliary (AUX) Mode”, this setting can be carried out. The video input type can be changed.

Setting item: Signal Setting contents: Auto (Initial setting) / NTSC/PAL

Auto: The video input signal type (NTSC or PAL) will

be automatically selected.

NTSC/PAL: Choose the video input signal type manually.

Usable 4-pole mini AV plug

The unit accepts the following 4-pole mini AV plug pin-out:

Audio L (White) Audio R (Red) Ground

Video (Yellow)

• Please check pin-out carefully before use of this product. Depending

on the cable, there may be no picture and/or sound.

• When an iPod video is selected or the current source is AUX3, this

setting cannot be adjusted.

Setting the AUX 3 Source Select (Switching the Visual Input Signal System)

After setting to “AUX 3” in “Setting the AUX 3 Source Select”, this setting can be carried out. The video input type can be changed.

Setting item: AUX 3 Signal Setting contents: Auto (Initial setting) / NTSC/PAL

Auto: The video input signal type (NTSC or PAL) will

be automatically selected.

NTSC/PAL: Choose the video input signal type manually.

• When the current source is AUX 3, this setting cannot be adjusted.

Rear Seat Entertainment (RSE) Setting

60-EN

[Rear Seat Entertainment (RSE)] is selected on the Source setup menu in step 3. Refer to “Source Setup Operation” (page 55).

Setting the Rear Seat Entertainment System

Video and audio can be output to the rear monitor.

Setting item: Rear Seat Entertainment (RSE) Setting contents: Off (Initial setting) / On

• If you selected the “On” setting, set the “Remote Sensor Setting”

(page 44).

Setting the Bluetooth Pandora

[Bluetooth Pandora] is selected on the Source setup menu in step3. Refer to “Source Setup Operation” (page 55). To use Bluetooth Pandora, set the Bluetooth Pandora setting to “On.”

Setting item: Bluetooth Pandora Setting contents: Off / On (Initial Setting)

• When “On” is set, the Bluetooth Pandora® source is displayed on the

Top banner on the Audio/Visual screen.

• When the current source is Bluetooth Pandora, this setting cannot be

adjusted.

TuneIt Setting

[TuneIt] is selected on the Source setup menu in step 3. Refer to “Source Setup Operation” (page 55).

Setting the Communication Mode with a Smartphone

Set TuneIt to USB (iPhone) when an iPhone is connected, or set to Bluetooth (Android) when an Android Smartphone is paired.

Setting item: TuneIt Setting contents: Off / USB (iPhone) (Initial setting) /

Off: No Smartphone is connected. USB (iPhone): When an iPhone is connected to the unit’s

Bluetooth (Android):

* Not displayed when Bluetooth is set to Off. For details, refer to

“Bluetooth Setting” on page 62.

• For this function to work properly, specific applications must be

installed on your Smartphone before connection. Consult your Alpine dealer or the Alpine website for details.

• Only the iPhone and certain Android Smartphones support this

function.

Bluetooth (Android)

USB port, you can program the unit’s sound tuning parameters, or communicate with SNS.

Set this when an Android Smartphone is paired with this unit via Bluetooth technology. And after Bluetooth Audio is connected, you can program the unit’s sound tuning parameters, or communicate with SNS.

Bluetooth Setup

Bluetooth Setup Operation

To display the Bluetooth Setup Menu screen:

Your vehicle must be parked with the ignition key in the ACC or ON position. To do this, follow the procedures below.

1 Bring your vehicle to a complete stop at a safe

location. Engage the parking brake.

2 Keep pushing the foot brake and release the parking

brake once then engage it again.

3 When the parking brake is engaged for the second

time, release the foot brake.

• For automatic transmission vehicles, place the transmission lever

in the Park position.

Now, the locking system for the Bluetooth mode operation has been released. Engaging the parking brake can reactivate the Bluetooth Setup Menu, as long as the car’s ignition has not been turned off. It is not necessary to repeat the above procedure (1 through 3) of “To display the Bluetooth mode screen.” Each time the ignition is turned OFF, perform the procedure of “To display the Bluetooth mode screen.”

The following steps 1 to 5 are common operations to each “Setting item” of Bluetooth Setup. Refer to each section for details.

Touch [Setup] icon of Top banner.

The Setup main screen is displayed.

Touch (Bluetooth).

The Bluetooth Setup screen appears.

Select the desired item.

Setting items:

*1Not available when both “Bluetooth Audio” and “Hands-free

Connection of iDataLink” are set to OEM.

Not available when Hands-free Connection of iDataLink is set to

OEM.

When External Audio Processor is set to On, phone speaker cannot

be adjusted. Refer to “Setting the External Audio Processor On/Off” (page 48).

Touch [] or [] etc., to change its setting.

• When the pop-up window for setup is displayed, touch [] to

Hands-free Connection of iDataLink / Bluetooth*1 / Bluetooth Information* Auto Connect* Phonebook Encoding* Volume / Microphone Level* Delete Call History*

close the window after setting.

/ Set Bluetooth Device*1 /

/ Passcode Change*1 / Default

/ Phone Speaker*3 / Caller

/ Ring Tone Volume /

61-EN

Touch [] to return to the previous screen.

• Immediately after changing the Bluetooth Setup (while the system is

writing data automatically) do not turn the ignition key to OFF. Otherwise, the settings may not be changed.

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 29).

Setting Hands-free Connection of iDataLink

[Hands-free Connection of iDataLink] is selected on the Bluetooth setup menu in step 3. Refer to “Bluetooth Setup Operation” (page 61)

Setting item: Hands-free Connection of iDataLink Setting contents: OEM / Aftermarket (Initial setting)

OEM: When you pair your Bluetooth compatible

Aftermarket: When using the X009’s built-in Bluetooth

• This setting is linked with “Setting the Hands-free Connection”

(page 44).

phone with the iDataLink module via this unit. If this option is selected, you cannot pair the Bluetooth compatible phone with this unit.

function.

Bluetooth Setting

[Bluetooth] is selected on the Bluetooth setup menu in step 3. Refer to “Bluetooth Setup Operation” (page 61).

Setting item: Bluetooth Setting contents: Off / On (Initial setting)

Off: Bluetooth function is not used. On: Select when you would like to pair your Bluetooth

compatible phone with this unit.

• If the Bluetooth setting is “Off”, you cannot move to the Bluetooth

setting screen.

Registering the Bluetooth Device

[Set Bluetooth Device] is selected on the Bluetooth setup menu in step

3. Refer to “Bluetooth Setup Operation” (page 61). The Bluetooth device is used when a connectable Bluetooth compatible device is searched and connected from this unit, or a new Bluetooth compatible device is registered.

Touch [Set Bluetooth Device].

Touch [Search] of “No Device”.

The Device list displays up to 10 items.

Touch [Audio], [Hands-free] or [Both] of the device you want to connect from the list.

Audio: Sets for use as an Audio device. Hands-free: Sets for use as a Hands Free Device. Both: Sets for use as both an Audio device and Hands

• You can connect (pair) up to 5 Bluetooth compatible mobile

phones.

When the device registration is complete, a message appears and the device returns to normal mode.

• The Bluetooth registration process differs depending on the device

version and SSP (Simple Secure Pairing). If a 4 or 6 character Passcode appears on this device, enter the Passcode using the Bluetooth compatible device. If a 6 character Passkey appears on this device, make sure the same passkey is displayed on the Bluetooth compatible device and touch “Yes”.

• If all 5 devices have been registered, you cannot register a 6th device.

To register another device, you need to delete one of the other 5 devices first.

Setting the Bluetooth Device

Select one of 5 paired Bluetooth compatible devices that you previously registered.

Touch [Set Bluetooth Device].

Free Device.

Displaying Bluetooth Information

[Bluetooth Information] is selected on the Bluetooth setup menu in step 3. Refer to “Bluetooth Setup Operation” (page 61). You can display the Bluetooth device name and device address of this unit.

Setting item: Bluetooth Information

62-EN

Touch [Audio] or [Hands-free] of the device you want to connect from the Paired Device list.

Deleting a Bluetooth Device from the list

You can delete the information of a previously connected Bluetooth compatible device.

Touch [Set Bluetooth Device].

Touch [Delete] of the Bluetooth compatible device to delete from the Paired Device list.

Touch [OK].

• Touching [Cancel] will cancel the setting.

Automatic Connection setting

Selecting the Output Speaker

[Auto Connect] is selected on the Bluetooth setup menu in step 3. Refer to “Bluetooth Setup Operation” (page 61). If the Automatic Connecting setting is “On”, automatic connection is performed for the audio device registered in the Paired Device list.

Setting item: Auto Connect Setting contents: Off / On (Initial setting)

Setting the Passcode

[Passcode Change] is selected on the Bluetooth setup menu in step 3. Refer to “Bluetooth Setup Operation” (page 61). You can set the code for connecting with a Bluetooth compatible device.

Setting item: Passcode Change

Touch [Passcode Change].

A numeric keypad screen is displayed.

Enter a 4-digit passcode, and then touch [Enter].

• The initial number is 0000.

• For details on how to input the numeric keypad, refer to “Numeric

Keypad Input Operations” (page 38).

Changing the Character Code of the Phone Book

[Default Phonebook Encoding] is selected on the Bluetooth setup menu in step 3. Refer to “Bluetooth Setup Operation” (page 61). You can select the character code that is used when transferring the phone book or history from a mobile phone. If unreadable characters appear in the transferred data, select the correct character code.

Setting item: Default Phonebook Encoding Setting contents: Latin-1 / Latin-9 (Initial setting) / Russian /

Touch [Default Phonebook Encoding].

The Character code list screen is displayed.

Touch the desired character code.

Latin-1: ISO 8859-1 Latin-9: ISO 8859-15 Russian: ISO 8859-5 Chinese: GB18030 Thai: CP874 Arabic: CP1256 Unicode UTF-8 Unicode UTF-16LE Unicode UTF-16BE

Touch [OK].

Chinese / Thai / Arabic / Unicode UTF-8 / Unicode UTF-16LE / Unicode UTF-16BE

[Phone Speaker] is selected on the Bluetooth setup menu in step 3. Refer to “Bluetooth Setup Operation” (page 61). You can select which speaker in the car will output the audio from the phone.

Setting item: Phone Speaker Setting contents: All (Initial setting) / Front L / Front R / Front LR

All: The sound is output from all speakers in car. Front L: The sound is only output from the front left speaker. Front R: The sound is only output from the front right

Front LR: The sound is output from the front left and front

• The setting cannot be adjusted during a phone call. Adjust the setting

before placing a call.

• This option is not available when External Audio Processor is set to

On.

speaker.

right speakers.

Adjusting the Caller Volume

[Caller Volume] is selected on the Bluetooth setup menu in step 3. Refer to “Bluetooth Setup Operation” (page 61). You can adjust the volume of the incoming call.

Setting item: Caller Volume Setting contents: 1 to 11 (Initial setting: 5)

Adjusting the Microphone Level

[Microphone Level] is selected on the Bluetooth setup menu in step 3. Refer to “Bluetooth Setup Operation” (page 61). You can adjust the transmit volume, during the call.

Setting item: Microphone Level Setting contents: 1 to 11 (Initial setting: 5)

Adjusting the Ring Tone Volume

[Ring Tone Volume] is selected on the Bluetooth setup menu in step 3. Refer to “Bluetooth Setup Operation” (page 61). You can adjust the receive volume, during the call.

Setting item: Ring Tone Volume Setting contents: 1 to 11 (Initial setting: 5)

Deleting All the Histories

[Delete Call History] is selected on the Bluetooth setup menu in step 3. Refer to “Bluetooth Setup Operation” (page 61). Dialed/Received/Missed Incoming histories are all deleted.

Setting item: Delete Call History

Touch [Delete Call History]

The confirmation screen is displayed.

• When there is no history, this option is not available.

Touch [OK].

All the histories are deleted.

63-EN

Camera Setup

Camera Setup Operation

With an optional camera connected, its video is output to the monitor. When the camera is connected, set this item.

To display the Camera Setup Menu screen:

Your vehicle must be parked with the ignition key in the ACC or ON position. To do this, follow the procedures below.

1 Bring your vehicle to a complete stop at a safe

location. Engage the parking brake.

2 Keep pushing the foot brake and release the parking

brake once then engage it again.

3 When the parking brake is engaged for the second

time, release the foot brake.

• For automatic transmission vehicles, place the transmission lever

in the Park position.

Now, the locking system for the Camera mode operation has been released. Engaging the parking brake can reactivate the Camera Setup Menu, as long as the car’s ignition has not been turned off. It is not necessary to repeat the above procedure (1 through 3) of “To display the Camera mode screen.” Each time the ignition is turned OFF, perform the procedure of “To display the Camera mode screen.”

The following steps 1 to 5 are common operations to each “Setting item” of Camera Setup. Refer to each section for details.

Direct Camera Setting

[Direct Camera] is selected on the Camera setup menu in step 3. Refer to “Camera Setup Operation” (page 64).

Setting the Camera Input

Setting item: Camera Select / Guide Adjustment* Setting contents: Off (Initial setting) / Front / Rear*

Front: Front camera Rear: Rear camera

*1If “Camera Select” is set to “Off”, this option is not available.

If “Camera Select” in AUX Camera Setting is set to “Rear”, “Rear”

cannot be set in Direct Camera Setting.

Switching video patterns for Rear camera & Front camera

The video pattern can be changed when connected to HCE-C200R/ HCE-C200F/HCE-C210RD/HCE-C212F.

Setting item: Guide Adjustment

Touch [Guide Adjustment].

The camera guide adjustment screen is displayed.

Touch [Back], [Panorama], [Corner], or [Top].

The view will change to the selected view.

• [Back] will not appear for the Front camera.

Touch [] to return to the previous screen.

• For an explanation of video patterns, see the camera Owner’s

Manual.

Touch [Setup] icon of Top banner.

The Setup main screen is displayed.

Touch [ (CAMERA)].

The Camera Setup screen appears.

Select the desired item.

Setting items: Direct Camera / AUX Camera / Camera Interrupt

Touch [] or [] etc., to change its setting.

• When the pop-up window for setup is displayed, touch [] to

Touch [] to return to the previous screen.

• Immediately after changing the Camera Setup (while the system is

writing data automatically) do not turn the ignition key to OFF. Otherwise, the settings may not be changed.

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 29).

(Power OFF Mode) / Reverse Mute

close the window after setting.

Adjusting the Rear/Front Camera Guide

If you select “Rear” or “Front”, you can adjust the camera guide position.

Setting item: Guide Adjustment

Touch [Guide Adjustment].

The camera guide adjustment screen is displayed.

• If the video pattern is set to “Corner”, the camera guide will

not be displayed.

Touch [Adjust].

• If [Adjust] does not appear, proceed to step 3.

Touch the guide you intend to adjust.

Guide line can also be selected by touching [] [].

Display example for rear camera mode

64-EN

Display example for front camera mode

AUX Camera Setting

[AUX Camera] is selected on the Camera setup menu in step 3. Refer to “Camera Setup Operation” (page 64).

Setting the Camera Input

Touch [], [], [] or [] to adjust the position of the guide.

• Touching [Clear] clears adjustments and returns to the setting

before guide line alteration.

After the adjustment is completed, touch [Set].

Adjusting guides simultaneously (for Rear camera only)

Touch [Link].

The 3 vertical guides of the currently-selected guide link together, allowing them to be adjusted simultaneously.

Setting item: Camera Select / Camera Signal*1 / Guide

Setting contents: Off / Rear*2 (Initial setting) / Other

Rear: Rear camera Other: Side camera, Room camera, etc.

*1If “Camera Select” is set to “Off”, this option is not available.

If “Camera Select” in Direct Camera Setting is set to “Rear”,

“Rear” cannot be set in AUX Camera Setting.

Setting the AUX Camera Signal Input

When the AUX camera is connected, the video input signal type can be chosen.

Further setting item: Camera Signal

Setting contents: NTSC (Initial setting) / PAL

Adjusting the Rear Camera Guide

If you select “Rear” you can adjust the camera guide position.

Setting item: Guide Adjustment

Touch [Guide Adjustment].

The camera guide adjustment screen is displayed.

Touch [Adjust].

• If [Adjust] does not appear, proceed to step 3.

Touch the guide you intend to adjust.

Guide line can also be selected by touching [] [].

Adjustment*

Turning guide display ON/OFF

Turning the selected guide off.

Touch [ON/OFF].

The currently selected guide will turn off.

To turn the guide on, touch [ON/OFF] again.

• Guides that are turned off are still adjustable.

Returning guides to default

Touch [Default].

A message window will appear.

Touch [OK].

Adjusted values will return to default settings.

Touch [], [], [] or [] to adjust the position of the guide.

• Touching [Clear] clears adjustments and returns to the setting

before guide line alteration.

After the adjustment is completed, touch [Set].

Adjusting guides simultaneously (for Rear camera only)

Touch [Link].

The 3 vertical guides of the currently-selected guide link together, allowing them to be adjusted simultaneously.

65-EN

Turning guide display ON/OFF

Turning the selected guide off.

Touch [ON/OFF].

The currently selected guide will turn off.

To turn the guide on, touch [ON/OFF] again.

• Guides that are turned off are still adjustable.

Returning guides to default.

Touch [Default].

A message window will appear.

Touch [OK].

Adjusted values will return to default settings.

Camera Interrupt Setting (Power OFF Mode)

[Camera Interrupt] is selected on the Camera setup menu in step 3. Refer to “Camera Setup Operation” (page 64). You can set whether to display the rear camera image when the gear lever is moved to the reverse (R) position while the unit is turned off.

Setting item: Camera Interrupt (Power OFF Mode) Setting contents: On (Initial setting) /Off

On: The rear camera image is displayed Off: The rear camera image is not displayed

Reverse Mute Setting

[Reverse Mute] is selected on the Camera setup menu in step 3. Refer to “Camera Setup Operation” (page 64). You can set whether to mute the playing music when the gear lever is moved to the reverse (R) position.

Setting item: Reverse Mute Setting contents: Off / On (Initial Setting)

On: The playing music is muted when the gear lever is moved

to the reverse (R) position.

Off: Continue playing music even though the gear lever is

moved to the reverse (R) position.

66-EN

Bluetooth Operation

Setup Before Using

About Bluetooth

Bluetooth is a wireless technology allowing communication between a mobile device or personal computer over short distances. This enables a hands-free call or data transmission between Bluetooth compatible devices. Bluetooth transmission is available in the unlicensed 2.4 GHz spectrum if the distance between devices is within 10 meters. For details, refer to the Bluetooth website (http://www.Bluetooth.com/).

• Depending on the Bluetooth version, a Bluetooth compatible device

may not be able to communicate with this unit.

• Proper function of this unit with all Bluetooth compatible devices is

not guaranteed. For handling of the Bluetooth compatible device, consult your ALPINE dealer or ALPINE website.

• Depending on the surroundings, Bluetooth wireless connection may

be unstable.

• When you place a call, or perform setup operations, be sure to stop

your car in a safe place.

• Depending on the connected Bluetooth compatible device(s), the

function may differ. Also refer to the Owner’s Manual of the connected device(s).

About the Hands-Free Phone

Before Using Bluetooth

Before using the hands-free phone/audio function, the following settings need to be made.

Set “Bluetooth” to “On” (see page 62).

• Refer to “Bluetooth Setting” (page 62).

• You can search for this unit using a Bluetooth compatible device, and

then connect that Bluetooth compatible device to this unit. The device name of this unit is “ALPINE NAVI” and the initial number of the passcode is “0000”. Also refer to the Owner’s Manual of the connected device(s).

• Before using the Hands-free function, make sure “Setting Hands-free

Connection of iDataLink” is set to “Aftermarket” (page 44).

Hands-Free Phone Control

Display example for Phone menu screen

Hands-free calls are possible when using a HFP (Hands-Free Profile) compatible mobile phone with this unit.

• Avoid performing a hands-free call in heavy traffic or on narrow or

winding streets.

• Close the windows while calling to reduce background noise.

• If both calling parties are using hands-free devices, or the call is

made in a noisy location, difficulty hearing the other person’s voice is normal.

• Depending on telephone line conditions or certain mobile devices

used, voices may sound unnatural.

• When using a microphone, speak as directly as you can into the

microphone to obtain the best sound quality.

• Certain mobile phone features are dependent on the capabilities and

settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider’s network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in the Owner’s Manual are based upon the latest available information and are believed to be accurate at the time of printing. Alpine reserves the right to change or modify any information or specifications without notice or obligation.

Bluetooth devices Name Favorites Display: Short Cut icon

Dialed/Received/Missed Display: Each histories icon

Connecting a Bluetooth Device

Registering a Bluetooth device in X009 enables automatic connection. If it does not connect automatically, run through the connection procedure again.

Press the (PHONE) button.

The Phone menu screen is displayed.

Touch [Connect].

Bluetooth connection will start.

Disconnecting the Bluetooth Connection

Touch [Disconnect].

The Bluetooth connection is disconnected.

67-EN

Changing the connecting Bluetooth Device

If multiple Bluetooth devices are registered in this device, you can change the connection among the registered devices.

Press the (PHONE) button.

The Phone menu screen is displayed.

Touch [Change].

The Set Bluetooth Device screen is displayed.

Touch [Audio] or [Hands-free] of the selected device.

The connection will transfer to the selected device.

• You can check registered shortcut dialing by touching the Bluetooth

Device List. For how to assign one-touch dialing, refer to “Assigning as a Short Cut Dialing Number” (page 72).

Answering a Call

Incoming calls are announced by the received call ring tone and a displayed message (PHONE No., etc.).

An incoming call triggers the ringtone and an incoming call display.

Touch [] or press (PHONE) button.

The call starts.

• During a call, the audio for the current mode on the unit is muted.

After calling, playback will resume.

• When the caller’s number is transmitted to the system, if the caller’s

name is stored in the phone book, the name is displayed. If the name is not stored, the number is displayed. When neither the name or the number is unavailable, “Unknown” is displayed.

Adjusting ringtone volume

The ringtone volume is adjustable on the incoming call message screen.

Touch [] or [] for “ Vol.”.

Calling

Use the Phone menu screen to make a phone call.

Using Short Cut Dialing to Make a Call

You can assign up to 4 phone numbers for one-touch dialing to make a call easily. For how to assign one-touch dialing, refer to “Assigning as a Short Cut Dialing Number” (page 72).

Press the (PHONE) button.

The phone menu screen is displayed.

Touch [ Favorites].

Touch [Dial1], [Dial2], [Dial3] or [Dial4].

The phone call is sent to the stored number.

• Pressing and holding [Dial1], [Dial2], [Dial3] or [Dial4] displays

the Shortcut Dialing Edit screen. The only available editing operation is deletion.

• If a name has been registered, the name is displayed on the shortcut

button.

Dialing a Number In Call History

You can use 3 types of history to make a phone call. Call History saves up to 60 phone numbers. If the limit is exceeded, the oldest phone number is deleted.

Press the (PHONE) button.

The phone menu screen is displayed.

Touch [ Dialed], [ Received] or [ Missed].

The last four histories are displayed.

Touch the name from the call history.

The details screen of the call history is displayed.

• To display all the histories, touch [All]. Touching [Delete]

deletes the selected histories.

Touch [].

The phone call is started.

Hanging up the Telephone

Touch [].

The call finishes.

68-EN

Dialing a Number In the Phone Book

You can use the phone book of the mobile phone to make a phone call. Before using, you need to transfer the phone book from the mobile phone to the system. For details on how to transfer the phone book, refer to “Synchronizing the Phone Book” (page 71).

Press the (PHONE) button.

The phone menu screen is displayed.

Touch [].

Touch the person name or the telephone number from the Phone Book list.

Touch [].

The phone call is started.

Entering a Phone Number to Make a Call

Press the (PHONE) button.

The phone menu screen is displayed.

Touch [].

The number input screen appears.

Enter the phone number you wish to call.

• You can enter up to 31 digits.

Touch [].

Using Voice Recognition function

You can use Siri function of your iPhone or make a telephone call by using voice operation of your smartphone.

Using Siri

You can use the Siri function of your iPhone. To use this function, set the Siri setting of your iPhone to ON.

• Connect your iPhone to the unit via Bluetooth, then set to “Hands-

free” or “Both”. (Page 62)

• The available functions differ depending on the connected iPhone.

• Ask Siri to play a track from the music library applies only to USB

source.

• Siri and other streaming services are enabled by connecting to

compatible smartphones that are able to receive data. Please ensure that cellular data and/or Wifi is turned on in the smartphone to enjoy these features.

• Extensive use of Siri or other streaming services may increase your

phone’s data usage. Please check with your phone company to ensure you have an appropriate Data plan.

Press and hold the (PHONE) button for at least 3 seconds.

Touch [Call].

The phone call is started.

Redial Function

You can redial the person you have previously called.

Press the (PHONE) button.

The phone menu screen is displayed.

Touch [Redial].

The number is redialed.

Touch [Call].

The phone call is started.

The Voice Control mode screen is displayed.

Speak into the microphone.

• If no speech is detected, the unit may pause depending on

version of the connected iPhone. In that case, touch the microphone icon [ ] in the center of the Voice Control mode screen. You can continue to use the Voice Control mode.

To finish the Voice Control mode, touch [ ] or press and hold the (PHONE) button for at least 3 seconds.

• Depending on the iPhone, the Siri function may finish automatically.

Adjusting the volume

Adjust the speaker/microphone volumes in Voice Control mode. Perform the same procedure to adjust the speaker/microphone volumes of Hands-Free Phone.

Touch [ ] or [ ] of .

Adjust the speaker volume.

Touch [ ] or [ ] of .

Adjust the microphone volume.

Stopping input to the microphone

If the surrounding sound (road noise, etc.) is loud, you may wish to cut input to the microphone for 3 seconds.

Touch [ ].

69-EN

Voice Dial Function

You can make a telephone call by using voice operation.

• Connect your smartphone to the unit via Bluetooth, then set to

“Hands-free” or “Both”. (Page 62)

Press and hold the (PHONE) button for at least 3 seconds.

Operations During a Conversation

Display example

The Voice Dial mode screen is activated.

Say the telephone number* or name* you want to call, into the microphone.

* The number and name depend on the voice dial information stored in

the smartphone.

To finish the Voice Dial mode, touch [ ] or press and hold the (PHONE) button for at least 3 seconds.

• You can perform this operation only when a voice dial compatible

smartphone is connected.

• The Voice Dial function performance depends on the recognition

range of the smartphone.

• Voice dial operation depends on the function being available on the

smartphone. For details, refer to the owner’s manual of the smartphone.

• Depending on the smartphone, the Voice Dial operation may finish

automatically.

Adjusting the volume

Adjust the speaker/microphone volume in Voice Dial mode. Perform the same procedure to adjust the speaker/microphone volume of HandsFree Phone.

Touch [ ] or [ ] of .

Adjust the speaker volume.

Touch [ ] or [ ] of .

Adjust the microphone volume.

Stopping input to the microphone

If the surrounding sound (road noise, etc.) is loud, you may wish to cut input to the microphone for 3 seconds.

Touch [ ].

Name and phone number Conversation time

Adjusting the Speech Volume

You can adjust the transmit volume and receive volume respectively.

Touch [] or [] for “Vol.”.

:Outgoing volume

:Incoming volume

You can adjust the volume in 11 levels. Touch [] to turn down the volume. Touch [] to turn up the volume.

Changing the Voice Output

The voice output for calls is switchable between car speakers and the mobile phone speaker.

Touch [].

• Depending on the mobile phone, this operation may not be possible.

DTMF (Touch-Tone) Function

Transmits a DTMF (Touch-Tone) during a call.

Touch [TONE].

The number input screen appears.

Input number.

• You can transmit a Touch-Tone signal during a call.

• Touching and holding “0” initiates “+” tone transmission.

70-EN

Deleting the Phone Book Entries

Phone Book Function

Display example for Phone Book screen

An icon is displayed to indicate that multiple phone numbers are registered under an entry.

Synchronizing the Phone Book

You can synchronize the system’s phone book with the mobile phone’s phone book.

Press the (PHONE) button.

The phone menu screen is displayed.

Touch [].

Deleting One Entry from the Phone Book

Press the (PHONE) button.

The Phone menu screen is displayed.

Touch [].

The Phone Book screen is displayed.

Touch [Delete] of the phone number you intend to delete.

The confirmation screen is displayed. If multiple phone numbers are registered, they are all deleted.

Touch [OK].

The selected number is deleted.

Deleting All Entries from the Phone Book

Press the (PHONE) button.

The Phone menu screen is displayed.

Touch [].

The Phone Book screen is displayed.

Touch [Delete All].

The confirmation screen is displayed.

Touch [OK].

All entries of the phone book are deleted.

Touch [Download].

Touch [SYNC].

Synchronization of the phone books starts.

• You can store up to 1,000 phone numbers in the phone book for

USER1 and USER2, respectively.

• You can store up to 5 phone numbers by one person’s name.

Adding the Phone Book

Press the (PHONE) button.

The phone menu screen is displayed.

Touch [].

Touch [Download].

Touch [Add].

Stays on standby for connection of the mobile phone.

• Touch [Cancel] to cancel the standby mode.

The mobile phone accesses this unit and then transfers the phone book from the mobile phone to this unit.

• Mobile phone connection is canceled while the phone book is being

transferred.

71-EN

Bluetooth Audio

Assigning as a Short Cut Dialing Number

Assigning from Call History

Press the (PHONE) button.

The Phone menu screen is displayed.

Touch [Dialed], [Received] or [Missed].

The last four histories are displayed.

Touch the person name you intend to assign as the Short Cut dialing number.

The details screen of the Phone book is displayed.

• To display all the histories, touch [All]. Touching [Delete]

deletes the selected histories.

Touch [Preset].

The details screen for the Short Cut is displayed.

Touch [Save].

The phone number is assigned to the selected Short Cut dialing number.

• If Dial1, Dial2, Dial3 or Dial4 is already registered, it is overwritten.

• Touch [Delete] to delete an assigned short cut dialing number.

Assigning from the Phone Book

Press the (PHONE) button.

The Phone menu screen is displayed.

Touch [].

The Phone Book screen is displayed.

Touch the phone number you intend to assign as the Short Cut dialing number.

The details screen of the Phone book is displayed.

Touch [Preset].

The details screen for the Short Cut is displayed.

If a Bluetooth compatible mobile phone, portable player, etc. is connected by wireless, you can play back a song (operation is controllable from the unit).

Display example for Bluetooth Audio main screen

Touch [<<], [>>]

Song title Artist title Album title Elapsed time Bluetooth devices Name

• Before playing the Bluetooth Audio function, make sure “Bluetooth

Audio” is set to other than “OEM” (page 43).

• The displayed onscreen buttons may differ depending on the AVRCP

version.

• Status Indicator/Song title/Artist title/Album title/Elapsed time do not

display for AVRCP Ver. 1.0.

• To play back audio, a mobile phone or a portable player conforming

to A2DP (Advanced Audio Distribution Profile) or AVRCP (Audio/ Video Remote Control Profile) is required. Not all functions work with all devices.

• During a call, sound on the Bluetooth audio source is paused.

Compatible AVRCP versions: 1.0, 1.3, 1.4

• Available functions may differ depending on the AVRCP version.

Touch [Save].

The phone number is assigned to the selected Short Cut dialing number.

• If Dial1, Dial2, Dial3 or Dial4 is already registered, it is overwritten.

• Touch [Delete] to delete an assigned short cut dialing number.

72-EN

Playback

Press the AUDIO button.

Touch [] (Bluetooth Audio) of Top banner.

Touch [] or [] to select the desired track (file).

Returning to the beginning of the current file:

Touch [].

Fast backward the current file:

Touch and hold [].

Advance to the beginning of the next file:

Touch [].

Fast forward the current file:

Touch and hold [].

To pause playback, touch [ / ].

Repeat Play

Playing the iDataLink-

Available for AVRCP Ver. 1.3 and 1.4 only.

Touch [] during playback.

The repeat mode switches every time the button is touched.

(FILE)

(GROUP)

(ALL)

(OFF)

• Operations may differ depending on the connected Bluetooth

compatible device.

M.I.X. (Random Play)

Available for AVRCP Ver. 1.3 and 1.4 only.

Touch [] during playback.

The M.I.X. mode switches every time [] is touched.

(GROUP)

(ALL)

Bluetooth Audio

When the unit is connected to car’s iDataLink module, and “Bluetooth Audio” is set to other than “Aftermarket” (page 43), Bluetooth Audio source via iDataLink module may be available on this unit.

Press the AUDIO button.

Touch [] (Bluetooth Audio) of Top banner.

The iDataLink-Bluetooth Audio source icon is marked with

icon.

• For detailed operation, refer to Owner’s Manual of iDataLink

module.

• Depending on the connected iDataLink module, display screen and

function keys may differ.

(OFF)

• Operations may differ depending on the connected Bluetooth

compatible device.

Selecting Groups

Available for AVRCP Ver. 1.3 and 1.4 only.

Touch [ Group] or [Group ] to select the group.

Search Function

Available for AVRCP Ver. 1.4 only. The displayed list differs with the connected Bluetooth device.

Touch [ (Search)] of Bottom banner during playback.

Select the track, etc., you want to listen to from the displayed list.

73-EN

Auxiliary Device (Optional)

Operating Auxiliary Devices (Optional)

To operate devices connected to the AUX terminals of X009, follow the procedure described below.

• Set AUX 1 In to “On”. Refer to “Setting the Auxiliary (AUX) Mode”

(page 60).

• Depending on the connected unit, the onscreen buttons may not

work, or their operation may differ.

WARNING It is dangerous (and illegal in many states) for the driver to watch TV/video while driving the vehicle. The driver may be distracted from looking ahead and an accident could occur.

Install the X009 correctly so that the driver cannot watch TV/video unless the vehicle is stopped and the emergency brake is applied.

If the X009 is not installed correctly, the driver will be able to watch TV/video while driving the vehicle and may be distracted from looking ahead and cause an accident. The driver or other people could be severely injured.

Example for AUX 1, AUX 2, AUX 3, DVD, Game mode display

• The operation screen changes to the visual screen in the

Auxiliary (AUX) mode for 5 seconds after an operation has been performed. To hide the Auxiliary (AUX) operation screen, touch the video display area.

Touch the display panel to display the operation screen again.

• Setting the Auxiliary (AUX) name for EXT.DVD, DVD-CHG, DVB-T,

and TV mode displays their individual operation switches and enables operation. Refer to “Setting the Primary Auxiliary (AUX) Name (AUX 1 Setup)” (page 60) and “Setting the Secondary Auxiliary (AUX) Name” (page 60).

Operating an External DVD Player

To operate an External DVD player (Optional), set “Setting the Primary Auxiliary (AUX) Name (AUX 1 Setup)” (page 60) or “Setting the Secondary Auxiliary (AUX) Name” (page 60) to “EXT.DVD”.

• If you try to activate the auxiliary device while driving, the display

will show the warning-Picture off for your safety.

Press the AUDIO button.

Touch [AUX 1]*1, [AUX 2]*1 or [AUX 3]*2 of Top banner.

The Auxiliary (AUX) mode screen is displayed.

The name which is given as the mode name in “Setting the Primary Auxiliary (AUX) Name (AUX 1 Setup)” (page 60) and “Setting the Secondary Auxiliary (AUX) Name” (page 60) is displayed.

When “Setting the AUX3” (page 60), AUX3 appears when setting

”AUX3” only.

AUX Operation Screen Display During Video File Playback

Touch the screen.

The Auxiliary (AUX) operation screen is displayed.

Change to the External DVD Mode

Press the AUDIO button.

Touch [EXT.DVD] of Top banner.

The display shows the EXT. DVD mode screen.

About the DVD Operation Screen

When the external DVD player playback screen is displayed, you can touch the screen to display the operation screen. For details on how to operate, refer to the Owner’s Manual of the connected DVD player.

External DVD player display example

Touch [<<], [>>]

74-EN

[]

Touch the switch to go back to the beginning of the current chapter/track/file. Touch the switch once more to find the beginning of the previous chapter/track/file. Touch and hold to fast reverse.

[]

Touch the switch to advance to the beginning of the next chapter/track/file. Touch and hold to fast forward.

[]

Starts/Stop M.I.X. play.

[]

Starts/Stop repeat play.

[/]

Switches between play and pause.

[]

Touching during play initiates a pre stop. Touching again stops play.

[Top Menu]

Calls up the Top Menu screen.

[Menu]

Calls up the Menu screen.

[Menu Control]

Calls up the menu operation mode.

[]

Switches the program/playlist/folder down.

[]

Switches the program/playlist/folder up.

[Angle]

Switches angle.

[Audio]

Switches audio.

[Sub Title]

Switches sub titles.

Operating an External DVD Changer

To operate an External DVD changer (Optional), set “Setting the Primary Auxiliary (AUX) Name (AUX 1 Setup)” (page 60) or “Setting the Secondary Auxiliary (AUX) Name” (page 60) to “DVD-CHG”.

Change to the External DVD Changer Mode

Press the AUDIO button.

Touch [DVD-CHG] of Top banner.

The display shows the DVD-CHG mode screen.

About the DVD Changer Operation Screen

When the External DVD changer playback screen is displayed, you can touch the screen to display the operation screen. For details on how to operate, refer to the Owner’s Manual of the connected DVD changer.

• The DVD-CHG operation mode screen and the Menu operation

mode screen are the same as the external DVD player operation screen. Refer to ”Operating an External DVD Player”.

External DVD changer display example 3/3 (Info mode)

Menu operation mode screen display example

[Key]

The menu operation mode will be displayed.

[], []

Moves key panel location.

[]

Closes menu operation mode.

[]

Closes key panel.

[], [], [], []

Moves menu cursor.

[Enter]

Determines the selected item.

[Return]

Returns to the previous item/screen.

Touch [<<], [>>]

[Disc1]-[Disc6]

Selects a Disc.

75-EN

Operating the Mobile Digital TV Receiver (DVB-T)

To operate the Mobile Digital TV Receiver (DVB-T) (Optional), set “Setting the Primary Auxiliary (AUX) Name (AUX 1 Setup)” (page 60) or “Setting the Secondary Auxiliary (AUX) Name” (page 60) to “DVBT”.

Changing to the Mobile Digital TV Receiver (DVB-T) Mode

Press the AUDIO button.

Operating a TV

To operate a TV Receiver (TV) (Optional), set “Setting the Primary Auxiliary (AUX) Name (AUX 1 Setup)” (page 60) or “Setting the Secondary Auxiliary (AUX) Name” (page 60) to “TV”.

Change to the TV mode

Press the AUDIO button.

Touch [TV] of Top banner.

The display shows the TV mode screen.

Touch [DVB-T] of Top banner.

The display shows the DVB-T mode screen.

About the DVB-T operation screen

When you touch the screen in the DVB-T mode, the operation screen is displayed. For details on how to operate, refer to the Owner’s Manual of the connected Digital TV Receiver (DVB-T).

Menu operation mode screen display example

[<]

Switches the Channel number / Favorite channel number down.

[>]

Switches the Channel number / Favorite channel number up.

[Tune] (Channel or FAV)

Switches between the Channel mode and the Favorite channel mode.

[EPG]

Call up the Electronic Program Guide (EPG).

[MENU]

Call up the menu screen.

[Menu Control]

Call up the menu operation mode.

[A/V]

Switches the source.

[Scan]

Touch the switch to start the scan procedure.

About the TV operation screen

When the TV playback screen is displayed, you can touch the screen to display the operation screen. For details on how to operate, refer to the Owner’s Manual of the connected TV.

Touch [<<], [>>]

[<], [<<]

Switches the Channel number / Preset channel down.

[>], [>>]

Switches the Channel number / Preset channel up.

[Tune] (Channel or PRESET or MANUAL)

Switches amongst Channel mode, Preset mode, and Manual mode.

[Band]

Switches the band.

[A.Memo]

The tuner automatically seeks and stores stations.

76-EN

Camera Operation (Optional)

When an optional camera is connected, the view video of camera can be output to the monitor. Front camera or Rear camera can be connected to this unit. Depending on your camera, please choose the connection method (Direct or AUX) and camera type (Front, Rear or Other) first. For details, refer to “Camera Setup” (page 64).

Front camera:

When the HCE-C212F/HCE-C200F is connected, conditions in front of the vehicle, such as objects, people and other hazards, can be seen.

Rear camera:

If an HCE-C210RD/HCE-C200R/HCE-C117D/HCE-C107D/ HCE-C115/HCE-C105 camera is connected, when the vehicle is reversed, the rear camera view (guide marks for vehicle width and available distance) is displayed automatically on the screen of this unit.

Other camera:

Set when connecting to a camera other than the Front camera or Rear camera, such as a room camera and side camera.

You can adjust the quality of the camera image.

Setting items: Live Contrast / Brightness / Color / Contrast

Refer to “Visual Setting” (page 45).

Switching the Image Pattern for the Rear Camera

If the camera has a view switch function, the Direct Change switch is displayed.

Touch the screen when the image from the rear camera is displayed.

The operation screen is displayed on the screen.

• After a 5-second time-out, the operation screen returns to the

camera display screen.

Touch [Back], [Panorama], [Corner] or [Top].

The image pattern changes.

[Back]: Rear View [Panorama]: Panorama View [Corner]: Corner View [Top]: Ground View

• For detailed information about image patterns, see the camera

Owner’s Manual.

Guide Display ON/OFF Setting

Touch the screen when the image from the camera is displayed.

The operation screen is displayed on the screen.

• After a 5-second time-out, the operation screen returns to the

camera display screen.

Rear Camera Operation

Set “Rear” for “Direct Camera Setting” (page 64) or “AUX Camera Setting” (page 65).

Displaying the rear view video while the car is in reverse

Shift the gear lever to the reverse (R) position.

The rear view image is displayed while the car remains in reverse.

If you shift the gear lever to a position other than reverse (R), the monitor returns to the previous screen.

• Never depend solely on the camera when backing up. Always turn

and look and only use the camera for additional assistance.

• This function is effective when the reverse wire is properly connected.

Displaying the rear view video manually*

* Only for GMC/Chevrolet or other model.

Press CAM.

The Camera mode is activated and the rear view video is displayed.

Press CAM again to return to normal screen.

Touch [Guide OFF] on the Rear camera display screen.

The guide disappears, and then the [Guide OFF] switch changes to [Guide ON].

Touch [Guide ON] to turn on the guide.

Adjusting the Caution Display Location

Touch the screen when the image from the camera is displayed.

The operation screen is displayed on the screen.

• After a 5-second time-out, the operation screen returns to the

camera display screen.

Touch [Caution ].

• For each touch, the caution location moves to the top or bottom of the

screen.

77-EN

About the Rear Camera Guide

To display the guide, set “Guide Display ON/OFF Setting” (page 77) to On. Also, to adjust the guide, refer to “Adjusting the Rear/Front Camera Guide” (page 64). You can also turn off the guide in the Rear camera display screen.

Indication mark meaning

When the car is put into reverse gear, the monitor switches to the rear view camera image. Guides appear to help visualize the car’s width and distance from the rear bumper.

Distance guidance mark

The distance guides represent the ground level distance from the rear bumper. It is difficult to accurately estimate the distance to objects above ground level.

A (about 0.5 m)

about 1 m

1 Car width extension marks (red, yellow and green in

order of distance)

If properly calibrated, the marks indicate the car’s width. This helps guide the car’s path when backing up in a straight line.

The marks represent the distance from the rear of the car (from the rear end of the bumper).

• The marks do not move in synchronization with the steering wheel.

2 Distance guidance marks

The marks represent the distance from the rear of the car (from the rear end of the bumper).

• The marks do not move in synchronization with the steering wheel.

• Each center position of the mark represents about 0.5 m (red), about 1 m (yellow) and about 2 m (green) behind.

• Depending on the condition of the car or road surface, the range of

vision may vary.

• The camera has a limited range of vision. Objects at extreme angles

to the camera (e.g. under the bumper or at opposite ends of the bumper) may not be in the its field-of-vision.

• The rear camera image may have a tint which is different from the

actual surroundings.

• Depending on the car, the guidance may deviate to the right or left.

This is not a malfunction.

In the screen, according to the distance guidance marks, the truck seems to be parked about 1 m away (at the position B). In actual fact, however, if you reversed to position A, you would collide with the truck. In the screen, positions A, B and C seem to be located in order of proximity. However, in actual fact, the position A and C are the same distance, and B is farther away than positions A and C.

• The car width extension mark represents the distance to the road

surface. The distance to an object on the road is not accurately represented by the guides.

• In the following conditions, screen visibility may be impaired. This is

not a malfunction.

- When it is dark (during the night, etc.).

- Under very high or very low temperature conditions.

- When water drops adhere to the camera, or when the humidity

is high (such as rainy weather, etc.).

- When foreign bodies (such as mud, etc.) adhere to the camera

or its peripheral area.

- When sunlight or headlights directly strike the camera lens.

- When a CCD camera is connected, smearing* may occur. This

phenomenon is peculiar to CCD cameras.

78-EN

* Smear phenomenon:

A phenomenon which occurs when a high-intensity spot (such as a reflection of the sunlight on a car body) is shot by the camera. The picture below is an example of ’vertical smear’ common to CCD cameras.

When there is a steep downward slope behind the car (example)

A high-intensity spot

Error between the screen and the actual road surface

In the following conditions, errors are produced between the screen guidance and the actual road surface. (The illustrations represent a case when the camera is installed in the standard position.)

When there is a steep upward slope behind the car (example)

Distance guidance marks

Actual distances

Error Error

In the case of a downward slope behind the car, the distance guides are displayed farther from the rear bumper than the actual distance. If there is an obstacle on the downward slope, it seems closer than its actual position. Also, an error may occur between the guidance and the actual path of the car on the road surface.

Error Error

The distance guidance mark represents the distance to a flat road surface. Therefore in the case of an upward slope behind the car, the distance guides are displayed closer to the rear bumper than the actual distance. For example, if there is an obstacle on the upward slope, it may appear farther away than its actual position. Also, an error may occur between the guidance and the actual path of the car on the road surface.

79-EN

Front Camera Operation

Other Camera Operation

Set “Front” for “Direct Camera Setting” (page 64).

Displaying the Front View Video Manually

Press the (My Favorites) button.

The Favorites screen is displayed.

Tou ch [].

The Camera mode is activated and the front view video is displayed. When the front camera (direct camera) and rear camera or side camera (AUX camera) are connected simultaneously, the screen for selecting which camera image to display appears.

Switching the Image Pattern for the Front Camera

Touch the screen when the image from the front camera is displayed.

The operation screen is displayed on the screen.

• After a 5-second time-out, the operation screen returns to the camera display screen.

Touch [Panorama], [Corner] or [Top].

The image pattern changes. [Panorama]: Panorama View [Corner]: Corner View [Top]: Ground View

• For detailed information about image patterns, see the camera

Owner’s Manual.

Set “Other” for “AUX Camera Setting” (page 65).

Press the (My Favorites) button.

The Favorites screen is displayed.

Touch [] or [].

When the front camera (direct camera) and rear camera or side camera (AUX camera) are connected simultaneously, the screen for selecting which camera image to display appears.

About the adjustment of the Caution display location

As with the rear camera, the Caution display location for other cameras can be adjusted. Refer to “Adjusting the Caution Display Location” (page 77) for the operations.

About the adjustment of guide display ON/ OFF setting and adjustment of Caution display location

As with the rear camera, the front camera guide display ON/OFF setting and Caution display location can be adjusted. Refer to “Guide Display ON/OFF Setting” (page 77) and “Adjusting the Caution Display Location” (page 77) for the operations.

80-EN

SiriusXM Satellite Radio Operation (Optional)

Touch [ < ] or [ > ] to select the desired channel. Touching and holding either button will rapidly browse through the channels.

• Refer to the SiriusXM Tuner User Guide for details on how to install

the SiriusXM Tuner.

• Before using the SiriusXM, make sure “SiriusXM” is set to other

than “OEM” (page 43).

SiriusXM Tuner operation:

When an optional SiriusXM Tuner is connected to this unit, the following operations may be performed.

Display example for SiriusXM main screen

Touch [<<], [>>]

Band display

Displays the band of the signal currently being received.

Channel No. Channel name Artist name Song Title Preset button

Displays the preset channel name or channel number.

TAG Indicator

Blinks during tagging.

Receiving Channels with the SiriusXM Tune r

About SiriusXM Satellite Radio

Everything worth listening to is on SiriusXM, getting over 130 channels, including the most commercial-free music, plus the best sports, news, talk and entertainment. A SiriusXM Tuner and Subscription are required. For more information, visit www.siriusxm.com/activatenow, or call 1-866-635-2349. To activate SiriusXM Canada service, go www.xmradio.ca and click on “ACTIVATE RADIO” in the top right corner, or call 1-877-438-9677.

• The SiriusXM Satellite Radio controls on this unit are available only

when a SiriusXM Tuner is connected.

Press the AUDIO button.

The Home screen is displayed.

Tuning Channels by Category

Channels are grouped into categories based on the type of content heard on the channels.

Touch [Category] on the SiriusXM main screen to activate the category browsing mode.

The channels within the category of the current channel are listed.

Display example of category browsing mode screen

Touching the [Info] button changes the display of information for the channels in the category with the following three options. Channel NO./Channel Name Channel NO./Artist Name Channel NO./Song Title Channel NO./ Content Info Channel NO./ Channel Name

Touch Category [] or [] on the category browsing mode screen to select a desired category.

The Category Name is shown at the top of the display.

Select the desired channel number.

• If no operation is performed for 10 seconds, the category browsing

mode is canceled.

Changing the Display

Text information, such as the channel name, artist name/feature, and song/program title, is available with SiriusXM or channel. The unit can display this text information as explained below.

Touch [Info] in SiriusXM mode.

Each time you touch this button, the display changes as shown below.

Touch the [SiriusXM] of Top banner.

The SiriusXM main screen display appears.

• The SiriusXM source selection icon will not be listed if the SiriusXM Tuner is not connected properly. Check the tuner connections if the icon is not shown.

81-EN

Tuning Channels using Presets

Channel No. Channel Name Artist Name Song Title

Content Info Category Name

Checking the SiriusXM Radio ID Number

To subscribe to the SiriusXM Satellite Radio service, it is necessary to locate and identify the Radio ID of your SiriusXM Tuner. The Radio ID contains 8 characters and can be found on the bottom of your SiriusXM Tuner or can be displayed on when selecting Channel 0 by following the steps below:

While receiving SiriusXM Radio, touch [ < ] or [ > ] to select channel “0”.

The unit displays the ID number.

To cancel the ID number display, change the channel other than “0”.

• The SiriusXM Radio ID does not contain the letters I, O, S, or F.

Storing Channel Presets

You can store 18 of your favorite SiriusXM channels for easy recall with Preset buttons.

Touch [Band] to select the desired band you want to store the preset in.

There are 3 Satellite Radio Preset bands. Each touch of [Band] changes the band: SiriusXM-1 SiriusXM-2 SiriusXM-3 SiriusXM-1

Touch and hold any one of the preset buttons for at least 2 seconds.

The selected channel is stored.

Repeat the procedure to store up to 5 other channels onto the same band.

To use this procedure for other bands, simply select the desired band and repeat the procedure. A total of 18 channels can be stored in the preset memory (6 channels for each band; SiriusXM-1, SiriusXM-2 and SiriusXM-3.)

• If you store a new channel into a preset which already has a channel

assigned, the current channel will be cleared and replaced with the new one.

Touch [Band] of Bottom banner repeatedly until the desired band is displayed.

Touch any one of the preset buttons that has a station stored to it.

The preset station is received.

Tune Start Function

Use Tune Start to play music content from its beginning on programmed preset stations. The user can, therefore, enjoy the full track (i.e. song) rather than hearing what’s left from its current live playback position.

Touch and hold [Tune Start] for at least 2 seconds to activate or deactivate the Tune Start function.

• During Tune Start play mode, touching [Tune Start] will return to

live satellite radio.

• This function is available only when SiriusXM Tuner-SXV200 is

connected.

• Preset stations that play other than music-type content will start

playing the channel from the current live play point when selected.

Tune Scan Function

While listening to SiriusXM Satellite Radio, you can scan through all the songs you missed from your current band of preset channels.

Touch [Tune Scan].

The [Tune Scan] highlighted during TUNE SCAN mode. To uc h [Tune Scan] during scan playback, tune scan mode will be canceled and the selected track will be played back normally. Touch and hold [Tune Scan] for at least 2 seconds during scan playback to cancel Tune Scan mode. The tuner returns to the channel before Tune Scan was initiated.

Notes

• This function is available when SiriusXM Tuner-SXV200 is

connected.

• If no operation is performed during the scanning process, when

scanning finishes, the next mode depends on the SiriusXM Tuner.

• During Tune Scan mode, the artist and song name will be displayed.

• The SiriusXM Tune scans through the songs from the preset music

channels on the current band only, scanning from oldest to newest.

82-EN

Search Function

Touch [ (Search)] of Bottom banner.

Search list screen is displayed.

Touch the desired category.

The channel name search screen of the selected category is displayed.

Touch the selected channel.

• You can change the category directly by touching Category [ ] or [] on the channel name search screen.

Searching by Channel

1 Touch [All Channels] after step 1.

All Channels will be displayed in a list.

2 Touch the selected channel.

• Touch [Info] on the channel name search screen, the information of the broadcasting channels will be displayed. You can choose the desired channel from the artist name list or song name list.

Each time you touch the [Info] button, the display changes as below. Channel name Artist name Song Title Content Info Channel name

Searching by My Music

1 Touch [My Music]*.

The artist names and song titles that you have stored and are currently playing will be displayed in a list.

* Displayed only when the stored song or artist is

broadcasting.

2 Touch the desired artist/song.

The channel of the selected artist/song being broadcast is received.

• Touch [Info] on the channel name search screen, the information of the broadcasting channels will be displayed. You can choose the desired channel from the artist name list or song name list.

Each time you touch the [Info] button, the display changes as below. Channel name Artist name Song Title Channel name

Searching by My Games

1 Touch [My Games]*.

The sport teams that you have stored and the game is currently broadcasting will be displayed in a list.

* Displayed only when the game of stored team is

broadcasting.

2 Touch the desired team.

The channel of the selected game being broadcast is received.

• Touch [Info] on the channel name search screen, the information of the broadcasting channels will be displayed. You can choose the desired channel from the league name list or team name list.

Each time you touch the [Info] button, the display changes as below. Channel name League name Team name Channel name

Searching by Featured Favorites

1 Touch [Featured]*.

The Category that SXM recommends will be displayed in a list.

* Displayed only when the SiriusXM Tuner-SXV200 is

connected.

2 Touch the desired category. 3 Touch the desired channel within the selected category.

• Touch [Info] on the channel name search screen, the information of

the broadcasting channels will be displayed. You can choose the desired channel from the Artist name list or Song name list.

Each time you touch the [Info] button, the display changes as below. Channel name Artist name Song Title Content Info Channel name

Selecting the Channel directly

You can directly select the channel number on the display of the numeric keypad.

Touch [Direct Channel].

The numeric keypad input screen is displayed.

Touch to input the channel number.

Touch [Enter].

The selected channel is received.

• When a triple-digit channel number is input, it is unnecessary to

touch [Enter]; the channel will be received automatically.

Storing the desired Song/Artist

While listening to SiriusXM Satellite Radio, you can be alerted when your favorite songs or artists are playing on other channels. An interruption ALERT will be displayed when a matching artist or song is found on another channel. For receiving interruption ALERT information, refer to “Receiving and Tuning to an Alert”.

Touch [Memo] for at least 2 seconds on the SiriusXM mode screen.

The Memory type selection screen is displayed.

Touch the Save Song or Save Artist to select the store type.

A “Song (Artist) Saved X Used/Y Empty” pop up screen is displayed. X is the total number of song titles, artist names or sports team stored in memory, and Y is the total number of memory song titles, artist names or sports team still available for storage.

• “Artist /Song Unavailable” appears on the display if both the artist

and song is not available to be stored. “Artist (Song) Unavailable” is displayed if the artist (song) is not available to be stored. “Artist (Song) Saved” is displayed if this Artist (Song) was previously stored.

• If there is no memory space, “Memory Full” is displayed and then

you are asked if you want to replace a stored item. If you select “OK,” then the list to stored alert items are displayed. Touch the item that you want to replace.

• For details on how to set up the Games Alert, refer to “Setting the

Favorite Sports Team Alerts” (page 58).

83-EN

Receiving and Tuning to an Alert

Parental Lock Function

Whenever a stored sports team, artist, or song is playing on another channel, an interruption ALERT appears on the unit display. To tune to the game, artist or song identified by the alert, follow the steps below:

When stored information is broadcast, after displaying “Song Alert”, “Artist Alert” or “Game Alert”, the screen changes to My Music list* Games list*

Touch the channel on the list you want to receive.

The display changes to the selected channel and the channel is received.

Only for Song Alert and Artist Alert.

Only for Game Alert.

• To uc h [Info] on the My Music list/My Games list screen, the information of the broadcasting channels will be changed.

Each time you touch the [Info] button, the display changes as below. My Music list (Artist Alert): Artist name Song Title Channel name Artist name My Music List (Song Alert): Song Title Channel Name Artist Name Song Title My Games list: Team name& League name Channel name Team name& League name

If [] is touched, return to the previous screen.

•

• If no operation is performed for 10 seconds, or [] is touched, the

screen returns to the normal mode screen.

display.

or My

Replay Function

In SiriusXM mode, you can pause, rewind and replay up to 30 minutes of live Satellite Radio.

This function can help restrict the listening of channels to children of appropriate age levels only. For information on setting the Parental Control passcode, refer to “Setting the Parental Lock” (page 59). When a locked channel is selected, “Channel <xxx> Locked” is displayed and then the numeric keypad appears for you to enter the passcode.

Input the 4-digit passcode you set in “Setting the Parental Lock” on page 59.

The initial number is 0000.

• If you input a wrong passcode, “Incorrect Pass Code entered” is

displayed.

• After entering the correct passcode, you can access all locked

channels without entering the passcode again until the unit is powered off and then back on.

Using Jump Memory and Jump Recall function

The Jump Channel is a special channel that you can jump to with the press of a dedicated button and then jump back to the previous channel. This channel is often used to select your favorite SiriusXM traffic and weather report channel.

To store the Jump channel in memory, touch and hold [JUMP] for at least 2 seconds.

Touch [JUMP] to recall and tune to the saved Jump channel.

• You can also access to Jump channel by pressing and holding

optional Remote Control’s Band for at least 2 seconds.

• Press optional Remote Control’s Band again to quit Jump channel.

• Only one channel can be stored as the jump source channel. When

you want to store a new channel, the old channel will be cleared and the new one will be memorized.

Touch [/] to Pause playing of the channel content.

The “ (Pause)” icon and replay progress bar is displayed.

Touch [/] again or touch [] in the middle of the screen to resume playing the content.

The “ (Play)” icon lights up and offset playback commences.

• The time difference between the real broadcasting time and the

offset playback time is displayed.

Touch [] to exit Instant Replay and listen to live content.

• To fast reverse, touch and hold [] and to fast forward, touch and hold [].

• Touching [] or [] will move a track up/down.

• If you change channels while in Replay mode, the contents of the

replay buffer are emptied.

• Contents older than 30 minutes are automatically emptied from the replay buffer.

84-EN

Storing the Tag information

Playing the iDataLink SiriusXM

iTunes Tagging lets you tag songs heard on SiriusXM channels. Using this unit in conjunction with an optional SiriusXM Tuner and a Tagging compatible iPod/iPhone, you can tag the music that you listen to, then transfer the tag information to your iPod/iPhone, and later, when your iPod/iPhone is connected to iTunes, you can preview, buy and download your tagged songs. For details, refer to the Owner’s Manual of the Tagging compatible iPod/iPhone. The TAG icon will appear when a song playing on a SiriusXM channel has tag information available. When a desired song is heard on an SiriusXM channel, touch the [TAG] icon to save its tag information

When tagging is allowed, the TAG icon is displayed.

During tagging, the TAG indicator blinks. If no iPod/iPhone is connected, “Tag count X” is displayed (X is the total amount of the tag information stored in this unit).

• During tagging, the iPod/iPhone takes priority to save the tag information. If no iPod/iPhone is connected, the tag information is saved to this unit.

• When the memory of iPod/iPhone is full, “iPod memory full” and “Tag count X” are displayed in succession. The tag information will be stored to the unit.

• If the tagging operation is interrupted by a hands-free phone call, the tagging operation will be canceled and the unit will display “Cannot Tag”.

• This unit can store up to 50 pieces of tag information. When the memory of the unit is full, “Tuner memory full. Connect iPod.” may be displayed.

• When the iPod/iPhone is disconnected from the unit during tagging, its tag information will be stored in the unit.

• If there is stored tag information on the unit, when an iPod/iPhone supporting the tag function is connected, the stored tag information will be transferred to the iPod/iPhone automatically. When the iPod/ iPhone memory becomes full, “iPod memory full <xx> remaining.” may be displayed, and any remaining tag information on the unit will not be transferred to the iPod/iPhone.

• If tag information already exists, “Already Tagged” will be displayed when you try to tag information again.

When the unit is connected to car’s iDataLink module, and “SiriusXM” is set to other than “Aftermarket” (page 43). SiriusXM source via iDataLink module may be available on this unit. The iDataLink SiriusXM source icon is marked with icon.

• For detailed operation, refer to Owner’s Manual of iDataLink

module.

• Depending on the connected iDataLink module, display screen and

function keys may differ.

85-EN

Flash Memory (Optional)

About operations during library creation

• “Tag Search” (page 88) does not work properly while a library is

being created.

• The order in which songs are played during library creation may

differ from the order in the Flash Memory device.

You can play back music files (MP3/WMA/AAC) and video files

(DivX

) stored in a Flash Memory device on the internal player of this system. This section explains music operations only. Refer to the DivX operation section in “DVD” (page 37) for information on video.

• If the first file played is a music file, the mode will be the music play

mode. If the first file played is a video file, the mode will be the video play mode. Also, the mode changes by selecting “AUDIO” or “VIDEO” in step 2 in Search Function. Refer to “Searching for a Desired Song” (page 87) and “Searching for a Desired Video File” (page 41).

• Before playing Flash memory audio, make sure “USB/iPod” is set to

other than “OEM” (page 43).

Display example for the USB main screen (Info mode)

Audio mode

Video mode

Playback

Press the AUDIO button.

Touch [USB] of Top banner.

The USB mode is activated and the display changes to the USB screen.

Touch [] or [] or to select the desired track (file).

Returning to the beginning of the current (or previous) track (file):

Touch [].

Fast reverse :

Touch and hold [].

Advancing to the beginning of the next track (file) :

Touch [].

Fast forward :

Touch and hold [].

To pause playback, touch [ / ].

[ ] is displayed in the middle of the screen. Touch [ screen to start playback.

• Any file protected by DRM (Digital Rights Management) copy

protection, cannot be played back on this unit.

• The playback time may not be correctly displayed when a VBR

(Variable Bit Rate) recorded file is played back.

• If there is tag information, artist name/album name/track name is

displayed.

• ID3 tag/WMA tag

If an MP3/WMA/AAC file contains ID3 tag/WMA tag information, the ID3 tag/WMA tag information is displayed (e.g., song name, artist name, and album name).

• If the combined number of files/folders in the Flash Memory devices

reaches 5,000, the message “The system has reached its limit of recognizable files/folders from the USB device.” will be displayed. To delete the message, remove the Flash Memory devices.

/ ] again or touch [ ] in the middle of the

Touch [<<], [>>]

• Refer to “Display example for MP3/WMA/AAC main screen”

(page 34) and “Display example for DivX for screen element explanations.

• You can display artwork during USB playback.

About creating a tag information library

You can scan music files in a Flash Memory device and create a library of tag information in this unit. Library creation starts when the Flash Memory device is connected. The time it takes to create the library depends on the number of files in the Flash Memory device, but it may take several minutes.

main screen” (page 37)

86-EN

Repeat Play

Random Play (M.I.X. ALL)

Operation differs depending on whether the most recent song search was a Tag Search or a Folder/File Search.

Touch [] during playback.

The repeat mode switches every time the button is touched.

Folder/File Search mode:

Repeat Repeat Folder* (OFF) Repeat

Tag Search mode:

Repeat (OFF) Repeat

* Only files in a folder are repeatedly played back.

• If the Repeat Play mode is activated during M.I.X. playback, the

M.I.X. mode will be canceled.

Random Play (M.I.X.)

Operation differs depending on whether the most recent song search was a Tag Search or a Folder Search.

Touch [] during playback.

The tracks (files) on the disc will be played back in a random sequence. To cancel M.I.X. play, touch [].

Folder Search mode:

M.I.X. Folder*

(OFF) M.I.X. Folder*

Touch [ (Search)] of Bottom banner during playback.

The search mode is activated.

Touch [Music].

The folder name list screen is displayed.

Touch [Shuffle All] during playback.

The tracks (files) on the disc will be played back in a random sequence.

To cancel M.I.X. play, touch [].

• All songs in the Flash Memory are played back in random sequence.

Any one song does not play back again until all songs have been played back.

Searching for a Desired Song

X009 can carry out 2 kinds of searches.

File/Folder Name Search

Touch [ (Search)] of Bottom banner during playback.

Touch [Music].

The search mode is activated.

Tag Search mode:

M.I.X. Songs*2(OFF) M.I.X. Songs*

*1 Only files in a folder are played back in random sequence.

M.I.X. Songs randomly plays back songs within a selected category

(playlist, album, etc.). The songs within the category are played just once until all songs have been played.

• If the M.I.X. mode is activated during Repeat playback, the Repeat

Play mode will be canceled.

• If you select a track by using the search mode, the M.I.X. play mode

will be canceled.

Touch [Folder].

The folder name list screen is displayed.

Folder Name Search Mode

Touch [] of the desired folder.

The first file in the selected folder is played back.

File Name Search Mode

Touch the desired folder name.

The file name of the selected folder is displayed.

Touch the desired file name.

The selected file is played back.

• To return to the previous hierarchy, touch [].

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 29).

• After selecting a folder via a Folder name search, touch [] on the

main screen to display the folder search screen.

• After selecting a file via a File name search, touch [] on the

main screen to display the file search screen.

87-EN

Tag Search

By using file tag information and keeping these songs organized in playlists, this unit’s search functions will ease song searches in large libraries. Each music category has its own individual hierarchy. Use the Playlists/ Artists/Albums/Songs/Genres/Composers search mode to narrow searches based on the table below.

Hierarchy 1 Hierarchy 2 Hierarchy 3 Hierarchy 4

Playlists Songs — —

Artists Albums Songs —

Albums Songs — —

Songs — — —

Genres Artists Albums Songs

Composers Albums Songs —

For example: Searching by Artist name The following example explains how an ARTISTS search is performed. Another search mode can be used for the same operation, although the hierarchy differs.

Searching by artist name

Touch [ (Search)] of Bottom banner during playback.

Touch [Music].

The search mode screen appears.

Touch [Artists].

The Artists search screen is displayed.

Select the desired artist.

To play back the Artist directly

1 Touch [] of the artist’s name.

All songs of the selected artist are played back.

To search for the Album of the Artist

1 Touch the selected artist name.

The Albums search screen of the selected artist is displayed.

2 Touch [] of the desired album’s name.

All songs of the selected album are played back.

Direct Up/Down Function

This operation is available only if the most recent song search was a Tag Search. Playlist/Artist/Album/Genre/Composer can be easily changed. For example, if you listen to a song from a selected album, the album can be changed.

Touch [] or [] to select the desired Playlist/Artist/ Album/Genre/Composer.

• If an album is selected from an artist search, the album can be

searched.

• For details on icon display, refer to “Direct Up/Down switch icon:”

(page 91).

• If search selection mode is not activated, Direct Up/Down Function

is not possible.

• During M.I.X. playback, this operation is not possible.

Select the desired Folder (Folder up/down)

This operation is available only if the most recent song search was a Folder/File Search. If you listen to a file from a selected folder, the folder can be changed.

Touch [] or [] to select the folder.

• During M.I.X. ALL playback, this operation is not possible.

Playing the iDataLink USB/iPod

When the unit is connected to car’s iDataLink module, and “USB/iPod” is set to other than “Aftermarket” (page 43). USB or iPod audio source via iDataLink module may be available on this unit. The iDataLink Flash memory or iPod source icon is marked with icon.

• For detailed operation, refer to Owner’s Manual of iDataLink

module.

• Depending on the connected iDataLink module, display screen and

function keys may differ.

To search for a Song in the Album of the Artist

1 Touch the desired artist’s name.

All albums of the selected artist are displayed.

Touch the desired album’s name.

All songs of the selected album are displayed.

Touch the desired song’s name.

The selected song is played back.

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 29).

• After selecting a file via a Tag search, touch [] on the main

screen to display the search screen. The hierarchy level you selected last in the search mode is displayed.

88-EN

iPod/iPhone (Optional)

An iPod/iPhone can be connected to this unit by using the cable KCU-461iV (sold separately). You can connect a video-capable iPod to enjoy video as well as music. When the X009 is connected by the above cable, the controls on the iPod are disabled.

• This unit does not support video playback from iPhone 5, etc., which

with Lightning Connector.

• Internet or telephone functions, etc., of the iPhone or iPod touch are

not controllable from the unit, but these functions can be controlled using the iPhone or iPod touch itself.

• To watch the video screen of the file in the iPod/iPhone, the parking

brake must be engaged.

• For automatic transmission vehicles, place the transmission lever in

the Park position.

• Before playing iPod, make sure “USB/iPod” is set to other than

“OEM” (page 43).

• You can also play iDataLink iPod audio, refer to “Playing the

iDataLink USB/iPod” (page 88).

About iPod/iPhone models usable with this unit

• The following devices have been tested and shown to work with this unit. Correct function of earlier versions cannot be guaranteed.

iPod nano 7th generation 16GB: Ver.1.0.2 iPod touch 5th generation 32GB/64GB: Ver.7.0.4 iPod nano 6th generation 8GB/16GB: Ver.1.2 iPod touch 4th generation 8GB/32GB/64GB: Ver.6.1.5 iPod touch 3rd generation 32GB/64GB: Ver.5.1.5 iPod nano 5th generation(video camera) 8GB/16GB: Ver.1.0.2 iPod classic(Late2009) 160GB: Ver.2.0.4 iPod touch 2nd generation 8GB/16GB/32GB: Ver.4.2.1 iPod nano 4th generation(video) 8GB/16GB: Ver.1.0.4 iPod classic 120GB: Ver.2.0.1 iPod touch 1st generation 8GB/16GB/32GB: Ver.3.1.3 iPod nano 3rd generation(video) 4GB/8GB: Ver.1.1.3 iPod classic 80GB/160GB: Ver.1.1.2

• The following devices have been tested and shown to work with this unit. Correct function of earlier versions cannot be guaranteed.

iPhone 5S 16GB/32GB/64GB: Ver.7.0.4 iPhone 5C 16GB/32GB/64GB: Ver.7.0.4 iPhone 5 16GB/32GB/64GB: Ver.7.0.4 iPhone 4S 16GB/32GB/64GB: Ver.7.0.4 iPhone 4 16GB/32GB: Ver.7.0.4 iPhone 3GS 8GB/16GB/32GB: Ver.6.1.3 iPhone 3G 8GB/16GB: Ver.4.2.1

• For clarity in identifying your model of iPod, please see Apple’s own document “Identifying iPod models” at http://support.apple.com/kb/HT1353.

WARNING It is dangerous for the driver to watch video while driving the vehicle. The driver may be distracted from looking ahead and an accident could occur.

Install the X009 correctly so that the driver cannot watch Video unless the vehicle is stopped and the emergency brake is applied.

If the X009 is not installed correctly, the driver will be able to watch the Video while driving the vehicle and may be distracted from looking ahead causing an accident. The driver or other people could be severely injured.

Display example for iPod/iPhone main screen (Info mode)

Audio mode

Video mode

Song title/Episode title* Artist title/Release Date* Album title/Podcast title* Current song no./Total song no. Remaining time for playing Artwork display Elapsed time

:During audio-only playback of a video file in a

Playlist, the Video icon is displayed.

:During audio-only playback of a music file in a video

Playlist, the Music icon is displayed.

Total time for playing

* Podcast mode

89-EN

The iPod/iPhone operation screen display during video file playback

Touch the screen while the iPod/iPhone playback screen is displayed.

The iPod/iPhone operation screen is displayed.

• The operation screen changes to the visual screen in the iPod mode

for 5 seconds after an operation has been performed.

Playback

Press the AUDIO button.

Touch [iPod (Audio or Video)] of Top banner.

The display shows the iPod mode screen.

Touch [] or [] or to select the desired track (file).

Returning to the beginning of the current (or previous) track (file):

Touch [].

Fast reverse the current track :

Touch and hold [].

Advancing to the beginning of the next track (file) :

Touch [].

Fast forward the current track :

Touch and hold [].

To pause playback, touch [ / ].

• If a song is playing on the iPod/iPhone when it is connected to the

X009, it will continue playing after the connection.

• An episode may have several chapters. The chapter can be changed

by touching [] or [].

• If the artist, album or song name, created in iTunes, has too many

characters, songs may not be played back when connected to the X009. Therefore, a maximum of 64 characters is recommended. The maximum number of characters for the unit is 64.

• Some characters may not be correctly displayed.

Searching for a Music File

An iPod/iPhone can contain thousands of songs. For this reason, this unit can make various searches using the search function as shown below. Using the Playlist/Artist/Album/Podcast/Audiobook/Genre/Composer/ Song search mode’s individual hierarchy, you can narrow down your search as shown in the table below.

Hierarchy 1 Hierarchy 2 Hierarchy 3 Hierarchy 4

Playlists Songs — —

Artists Albums Songs —

Albums Songs — —

Songs — — —

Podcasts Episodes — —

Genres Artists Albums Songs

Composers Albums Songs —

Audiobooks — — —

For example: Searching by Artist name

The following example explains how an ARTISTS search is performed. Another search mode can be used for the same operation, although the hierarchy differs.

Searching by artist name

Touch [ (Search)] of Bottom banner during playback.

Touch [Music].

The search mode screen appears.

Touch [Artists].

The Artists search screen is displayed.

Select the desired artist.

To play back the Artist directly

1 Touch [] of the artist’s name.

All songs of the selected artist are played back.

90-EN

To search for the Album of the Artist

1 Touch the selected artist name.

The Albums search screen of the selected artist is displayed.

2 Touch [] of the desired album’s name.

All songs of the selected album are played back.

To search for a Song in the Album of the Artist

1 Touch the desired artist’s name.

All albums of the selected artist are displayed.

Touch the desired album’s name.

All songs of the selected album are displayed.

Touch the desired song’s name.

The selected song is played back.

• Touching [] of “ALL” will play back all songs in the list.

• Touching “ALL” will display the search list in the next hierarchy.

• An alphabet skip function is available. Refer to “Alphabet Skip

Function” (page 91).

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 29).

Searching for a Desired Video File

Direct Up/Down Function

You can select a movie, music video, etc., from the list screen.

• Video search mode depends on the iPod/iPhone. If the specification

of the iPod/iPhone is changed, the search mode on this unit will also be changed.

Examples for the video search mode

• Video Playlists

• Movies

• Music Videos, etc.

For example: Searching by Movie

The following example explains how a Movie search is performed. Another search mode can be used for the same operation, although the hierarchy differs.

Touch [ (Search)] of Bottom banner during playback.

Touch [Video].

The Video search mode screen appears.

Touch [Movies].

The Movies search screen is displayed.

Touch the desired movie.

The selected movie is played back.

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 29).

Alphabet Skip Function

If you touch [] of the album name in the search mode, this album will be played back repeatedly. To go to the previous or next Album, use the Direct Up/Down Function.

Touch [] or [] to select the desired Playlist/Artist/ Album/Genre/Podcast/Composer.

Direct Up/Down switch icon

Direct Up/Down switch icon:

Playlist

Artist

Album

Podcas t

Genre

The unit is provided with a alphabet skip function for effective searching. When you use this function in the search mode, you can quickly search an artist or a song, etc.

Alphabet skip function:

The alphabet skip function is skipped to the next alphabet such as from A to B, B to C by touching [(ALPHABET) ]. You can also skip in reverse order such as from B to A by touching [ (ALPHABET)].

Composer

• You can use the Direct Up/Down Function during video file

playback. The Direct Up/Down Function switches in the video mode are [ ] [].

• If you are searching for a song, this operation cannot be performed.

• If an album is selected from an artist search, the album can be

searched.

• During shuffle playback, this operation is not possible.

Search Position Memory

During iPod/iPhone playback, you can quickly move back up the selected hierarchy, a level at time.

Touch []. (ex. [ Playlists])

The hierarchy level you selected last in the search mode is displayed.

91-EN

Repeat Play

Touch [] to repeatedly play back the currently track.

The tracks (files) will be played repeatedly. Touch [] again to deactivate Repeat play.

Repeat (OFF) Repeat

Random Play (Shuffle)

Touch [] during playback.

The files will be played back in a random sequence. The Shuffle mode switches every time [] is touched.

Shuffle Songs Shuffle Albums (OFF) Shuffle Songs

HDMI Device (Optional)

The device can connect with electronic device supporting HDMI output by HDMI interface and fulfill the play of audio and video with HD signal. But, the unit only displays the electronic device interface by mirror image, you cannot operate the electronic device by this unit.

• The electronic device must possess HDMI output interface.

• Only purchase Alpine Special HDMI connection cable.

• If connecting an iPhone 5, etc., which with Lighting Connector you

need to prepare the optional Digital AV Adapter.

• Hereby take the connection method of iPhone 5 for example.

iPhone 5

Shuffle Albums: The songs on each album are played back

Shuffle Songs: Song shuffle randomly plays back songs

• For details on the search mode, refer to “Searching for a Music File”

(page 90).

in proper order. Upon completing of all the songs on the album, the next album is selected randomly. This continues until all albums have been played.

within a selected category (playlist, album, etc.). The songs within the category are played just once until all songs have been played.

Random Play (Shuffle All)

All files in the iPod are played back in random sequence.

Touch [ (Search)] of Bottom banner during playback.

Touch [Music].

The search mode screen appears.

Touch [Shuffle All] of Bottom banner during playback.

The indicator “ ” lights, and the songs will be played back in random sequence.

• To cancel, set the Shuffle mode to Off. Refer to “Random Play

(Shuffle)” (page 92).

Lightning Digital AV Adapter (Type: A1438)

HDMI connector in X009

Alpine special HDMI connection cable (sold separately)

• Not all devices with HDMI output interface can be recognized by this

unit.

Press the AUDIO button.

Touch [HDMI] of top banner.

• When disconnecting with HDMI device, the source icon of

HDMI is gray.

In HDMI player mode, the screen of the device displays the content of electronic equipment by mirror image.

92-EN

Pandora® internet radio (optional)

Pandora® internet radio is your own FREE personalized radio now available to stream music on your iPhone and smartphone (which runs Android OS or BlackBerry OS). Just start with the name of one of your favorite artists, songs or classical composers and Pandora and more music like it. The X009 enables you to interact with your Pandora connecting an iPhone and smartphone that has the latest version of the

Pandora

application installed.

Display example for iPhone Pandora Radio screen

will create a “station” that plays their music

account by

Listening to Pandora

iPhone Pandora

Connect the iPhone to this unit’s USB terminal before using iPhone

Pandora

Press the AUDIO button.

Touch [PANDORA®] of Top banner.

Follow the confirmation message appears on the iPhone to launch the Pandora Application. The display changes to PANDORA mode screen.

To skip to the next song, touch [].

• The operation to replay a previous song is not available.

• Pandora limits the number of skips allowed on their service. If you

attempt to skip songs beyond the limit, “No skips remaining” is displayed.

• X009 remembers the source just before turning off the power.

Even if you reconnect an iPhone without launching Pandora Application while the power is off, Pandora mode (not iPod mode) is displayed when power is turned back on.

• Depending on the signal status, song may be stopped during

playback. When the advertisement is received, the playback time will be frozen and key operation is invalid.

• The playback time may not be correctly displayed.

Display example for Bluetooth Pandora Radio screen

Touch [<<], [>>]

Station name Song Name Artist Name Album Name Track/Artist bookmark icon Elapsed time Remaining time for playing Artwork display

Bluetooth Pandora

When using Bluetooth Pandora connected Bluetooth compatible smartphone (which runs Android OS or BlackBerry OS) as Bluetooth Audio. For details, refer to “Registering the Bluetooth Device” (page 62). Also, make sure the Bluetooth Pandora (page 61).

Pair the smartphone with this unit.

Press the AUDIO button.

Touch [(Bluetooth) PANDORA®] of Top banner.

Follow the confirmation message appears on the Smartphone to launch the Pandora Application. The display changes to Bluetooth Pandora mode screen. The playback screen appears.

To skip to the next song, touch [].

• If pairing is not registered for the Bluetooth audio device, the

message “No Bluetooth device connected. Please check Bluetooth settings.” appears on the screen. Change the audio device settings as per “Registering the Bluetooth Device” (page 62).

• The operation to replay a previous song is not available.

• Pandora

• X009 remembers the source just before turning off the power. If

• The display content varies when ads are received.

• The playback time may not be correctly displayed.

attempt to skip songs beyond the limit, “No skips remaining.” is displayed.

Pandora SOURCE the next time the unit is power up even if the app is not launched on your smartphone.

limits the number of skips allowed on their service. If you

is the last SOURCE to be played, it will appear as the

, it is necessary to register the

setting is set to “On”

93-EN

“Thumbs” Feedback

Creating a New Station

You can personalize your stations with “Thumbs Up” or “Thumbs Down” feedback, which the system takes into account for future music selections.

During playback, touch [ ] for thumbs up, or touch [ ] for thumbs down.

: The “ ” indicator appears in the display. Pandora® will add

similar music to your station.

: The “ ” indicator is displayed. Pandora from your station, and the current song is skipped. If the number of skips allowed has reached its limit, the current song continues to play back.

• In some situations, “Thumbs” feedback may not be available.

“Unable to save your thumb rating.” will be displayed.

will ban that song

Searching for a Desired Station

You can display your station list and select stations directly from the X009.

Alphabet Search

Touch [ (Search)] of Bottom banner to activate the Search mode.

Touch [By A-Z].

The “By A-Z” search mode is activated and the station names are listed alphabetically.

Touch the desired station.

Pandora will play that station.

Search by Date Added

Touch [ (Search)] of Bottom banner to activate the Search mode.

Touch [By Date].

The “By Date” search mode is activated and the station names are listed by the date they were added to the account.

Touch the desired station.

Pandora will play that station.

• Currently playing station will be highlighted in Alphabet search list.

• The shared station is marked with “ ” in search list.

Basing on the currently playing song or artist, a personalized Pandora station can be created. The new station will play more music like it.

Freeword

During playback, touch [Create New Station].

The Key Pad screen is displayed. You can enter a keyword and search for Artist/Song.

Enter a keyword and touch the [OK] button.

Artist/Track

During playback, touch [Create Station From (Artist/ Track)] of Bottom banner.

• The created station is saved to your station list.

• You can also create stations using the Pandora Application on your

iPhone or on the web at www.pandora.com.

• In some situations, creating a new station may not be available.

“Unable to create station.” will be displayed.

• [Create New Station] is not available while driving.

QuickMix

Use QuickMix to create a playlist based on two or more of your Pandora stations. Edit your QuickMix station selections on the Pandora Compatible Application for iPhone when it is not connected to the X009.

Touch [ (Search)] of Bottom banner to activate the Search mode.

Touch [By A-Z] or [By Date].

The “By A-Z” or “By Date” search mode is activated and the station name is displayed.

Touch [QuickMix].

• The indicator lights, and the songs from the created stations are

played back in random sequence.

• Select another station during search mode to cancel QuickMix.

• During search list mode, the icon will be displayed when the

current station belongs to QuickMix.

94-EN

Bookmarking a Desired Track or Artist

The currently playing song or artist can be bookmarked and saved to your Pandora account.

During playback, touch [Artwork display].

The type selection telop is displayed.

Artwork display

Touch [Track] or [Artist].

The current track or artist is bookmarked. “ ” icon or “ ” icon is displayed.

• Your bookmarks can be viewed on your “Profile” page at

www.pandora.com.

• In some situations, bookmarks may not be available. “Unable to save

your bookmark.” will be displayed.

Information

Product Software Update

This product use software that can be updated through a Flash Memory device. Download the software from the Alpine website and update the product using the Flash Memory device.

Updating this product

Check the Alpine website for details on updating.

http://www.alpine-usa.com

About DVDs

Music CDs and DVDs have grooves (tracks) in which the digital data is recorded. The data is represented as microscopic pits recorded into the track – these pits are read by a laser beam to play the disc. On DVDs, the density of the tracks and pits is twice that of CDs, so DVDs can contain more data in less space.

CDs

Minimum pit length -

0.9 µm

DVDs

Minimum pit length -

0.9 µm

A 12 cm disc can contain one movie or about four hours of music. In addition, DVDs provide sharp picture quality with vivid colors thanks to a horizontal resolution of over 500 lines (compared to less than 300 for VHS tape).

In addition, DVDs offer a variety of functions.

Multiple audio* (page 42)

Movies can be recorded in up to eight languages. The desired language can be selected from the unit.

Subtitles function* (page 42)

Movies can include subtitles in up to 32 languages. The desired subtitle language can be selected from the unit.

Multi angle function* (page 41)

When the DVD contains a movie shot from multiple angles, the desired angle can be selected from the unit.

1.2 mm

0.6 mm

Track pitch -

1.6 µm

Track pitch -

0.74 µm

95-EN

Multi story function*

With this function, a single movie includes various story lines. You can select different story lines to view various versions of the same movie. Operation differs from disc to disc. Story line selection screens including instructions appear during the movie. Just follow the instructions.

* These functions differ from disc to disc. For details, refer to the disc’s

instructions.

96-EN

List of Language Codes

(For details, see page 56.)

Abbre viation

AA AB AF AM AR AS AY AZ BA BE BG BH BI BN BO BR CA CO CS CY DA DE DZ EL EN EO ES ET EU FA FI FJ FO FR FY GA GD GL GN GU HA HI HR HU HY IA

Code

6565 6566 6570 6577 6582 6583 6589 6590 6665 6669 6671 6672 6673 6678 6679 6682 6765 6779 6783 6789 6865

869

6 6890 6976 6978 6979 6983 6984 6985 7065 7073 7074 7079 7082 7089 7165 7168 7176 7178 7185 7265 7273 7282 7285 7289 7365

Language

Af ar Abkhazian Afr ikaans Amhar ic Arabic Assamese A ymara Az erbaijani Bashkir By elor

ussian Bulgar ian Bihari Bislama Bengali, Bangla Tibetan Breton Catalan Corsican Czech W elsh Danish Ger man Bhutani Greek English Esperanto Spanish Estonian Basque P ersian Finnish Fiji

aroese

F F rench F r isian Ir ish Scots Gaelic Galician Guarani Gujarati Hausa Hindi Croatian Hungarian Ar menian Inter lingua

Abbre viation

IE IK IN IS IT IW JP JI JW KA KK KL KM KN KO KS KU KY LA LN LO LT LV MG MI MK ML MN MO MR MS MT MY NA NE NL NO OC OM OR PA PL PS PT QU RM

Code

369

7 7375 7378 7383 7384 7387 7465 7473 7487 7565 7575 7576 7577 7578 7579 7583 7585 7589 7665 7678 7679 7684 7686 7771 7773 7775 7776 7778 7779 7782 7783 7784 7789 7865 7869 7876 7879 7967 7977 7982

8065 8076 8083 8084

81 8277

Language

Inter lingue Inupiak Indonesian Icelandic Italian Hebrew J apanese Yiddish J a v anese Georgian Kazakh Greenlandic Cambodian Kannada K orean Kashmir i K urdish Kirghiz Latin Lingala

Laothi Lithuanian Latvian, Lettish Malagasy Maor i Macedonian Mala y alam Mongolian Moldavian Marathi Mala y Maltese Bur mese Nauru Nepali Dutch Norw egian Occitan (Af an) Oromo Or iy a Punjabi P olish P ashto , Pushto P or tuguese Quechua Rhaeto-Romance

Abbreviation

RN RO RU RW

SA SD SG SH SI SK SL SM SN SO SQ SR SS ST SU SV SW

TA TE TG TH TI TK TL TN TO TR TS TT TW UK UR UZ VI VO WO XH YO ZH ZU

Code

8278 8279 8285 8287

83 8368 8371 8372 8373 8375 8376 8377 8378 8379 8381 8382 8383 8384 8385 8386 8387 8465 8469 8471 8472 8473 8475 8476 8478 8479 8482 8483 8484 8487 8575 8582 8590 8673 8679 8779 8872 8979

9072 9085

Langua g e

Kirundi Romanian Russian Kin y arwanda

Sanskrit Sindhi Sangho Serbo-Croatian Singhalese Slo v ak Slo v enian Samoan Shona Somali Albanian Serbian Sis w ati Sesotho Sundanese

w edish

S Swahili

T amil T elugu T ajik Thai Tig riny a T ur kmen T agalog Sets w ana T onga T ur kish Tsonga T atar T wi Ukrainian Urdu Uzbek Vietnamese V olapuk W olof Xhosa Y or uba Chinese Zulu

97-EN

List of Country Codes

(For details, see page 56.)

Abbreviation

AD AE AF AG AI AL AM AN AO AQ AR AS AT AU AW AZ BA BB BD BE BF BG BH BI BJ BM BN BO BR BS BT BV BW BY BZ CA CC CD

CF CG CH CI CK CL CM CN CO CR CU CV CX CY CZ DE DJ DK

Code

6568 6569 6570 6571 6573 6576 6577 6578 6579 6581 6582 6583 6584 6585 6587 6590 6665 6666 6668 6669 6670 6671 6672 6673 6674 6677 6678 6679 6682 6683 6684 6686 6687 6689 6690 6765 6767 6768

6770 6771 6772 6773 6775 6776 6777 6778 6779 6782 6785 6786 6788 6789 6790 6869 6874 6875

Country

Andorra United Arab Emirates Afghanistan Antigua and Barbuda Anguilla Albania Armenia Netherlands Antilles Angola Antarctica Argentina American Samoa Austria Australia Aruba Azerbaijan Bosnia and Herzegovina Barbados Bangladesh Belgium Burkina Faso Bulgaria Bahrain Burundi Benin Bermuda Brunei Darussalam Bolivia Brazil Bahamas Bhutan Bouvet Island Botswana Belarus Belize Canada Cocos (Keeling) Islands Congo, the Democratic

Republic of the Central African Republic Congo Switzerland Cote d’lvoire Cook Islands Chile Cameroon China Colombia Costa Rica Cuba Cape Verde Christmas Island Cyprus Czech Republic Germany Djibouti Denmark

DM DO DZ EC EE EG EH ER ES ET FI FJ FK FM FO FR GA GB GD GE GF GH GI GL GM GN GP GQ GR GS

GT GU GW GY HK HM

HN HR HT HU ID IE IL IN IO IQ IR IS IT JM JO JP KE KG KH

6877 6879 6890 6967 6969 6971 6972 6982 6983 6984 7073 7074 7075 7077 7079 7082 7165 7166 7168 7169 7170 7172 7173 7176 7177 7178 7180 7181 7182 7183

7184 7185 7187 7189 7275 7277

7278 7282 7284 7285 7368 7369 7376 7378 7379 7381 7382 7383 7384 7477 7479 7480 7569 7571 7572

Country CountryCode CodeAbbreviation Abbreviation

Dominica Dominican Republic Algeria Ecuador Estonia Egypt Western Sahara Eritrea Spain Ethiopia Finland Fiji Falkland Islands Micronesia, Federated States of Faroe Islands France Gabon United Kingdom Grenada Georgia French Guiana Ghana Gibraltar Greenland Gambia Guinea Guadeloupe Equatorial Guinea Greece South Georgia and the

South Sandwich Islands

Guatemala Guam Guinea-Bissau Guyana Hong Kong Heard Island and

McDonald Islands Honduras Croatia Haiti Hungary Indonesia Ireland Israel India British Indian Ocean Territory Iraq Iran, Islamic Republic of Iceland Italy Jamaica Jordan Japan Kenya Kyrgyzstan Cambodia

KI KM KN KP

KR KW KY KZ LA

LB LC LI LK LR LS LT LU LV LY MA MC MD MG MH MK

ML MM MN MO MP MQ MR MS MT MU MV MW MX MY MZ NA NC NE NF NG NI NL NO NP NR NU NZ OM PA

7573

Kiribati

7577

Comoros

7578

Saint Kitts and Nevis

7580

Korea, Democratic People’s Republic of

7582

Korea, Republic of

7587

Kuwait

7589

Cayman Islands

7590

Kazakstan

7665

Lao People’s Democratic Republic

7666

Lebanon

7667

Saint Lucia

7673

Liechtenstein

7675

Sri Lanka

7682

Liberia

7683

Lesotho

7684

Lithuania

7685

Luxembourg

7686

Latvia Libyan Arab Jamahiriya

7689

Morocco

7765

Monaco

7767

Moldova, Republic of

7768

Madagascar

7771

Marshall Islands

7772

Macedonia, The former

7775

Yugoslav Republic of Mali

7776

Myanmar

7777

Mongolia

7778

Macau

7779

Northern Mariana Islands

7780

Martinique

7781

Mauritania

7782

Montserrat

7783

Malta

7784

Mauritius

7785

Maldives

7786

Malawi

7787

Mexico

7788

Malaysia

7789

Mozambique

7790

Namibia

7865

New Caledonia

7867

Niger

7869

Norfolk Island

7870

Nigeria

7871

Nicaragua

7873

Netherlands

7876

Norway

7879

Nepal

7880

Nauru

7882

Niue

7885

New Zealand

7890

Oman

7977

Panama

8065

98-EN

Abbreviation

PE PF PG PH PK PL PM PN PR PT PW PY QA RE RO RU RW SA SB SC SD SE SG SH SI

Peru

8069

French Polynesia

8070

Papua New Guinea

8071

Philippines

8072

Pakistan

8075

Poland

8076

Saint Pierre and Miquelon

8077

Pitcairn

8078

Puerto Rico

8082

Portugal

8084

Palau

8087

Paraguay

8089

Qatar

8165

Reunion

8269

Romania

8279

Russian Federation

8285

Rwanda

8287

Saudi Arabia

8365

Solomon Islands

8366

Seychelles

8367

Sudan

8368

Sweden

8369

Singapore

8371

Saint Helena

8372

Slovenia

8373

Country

Abbreviation CountryCode

SJ SK SL SM SN SO SR ST SV SY SZ TC TD TF TG TH TJ TK TM TN TO TP TR TT TV

Code

Svalbard and Jan Mayen

8374

Slovakia

8375

Sierra Leone

8376

San Marino

8377

Senegal

8378

Somalia

8379

Suriname

8382

Sao Tome and Principe

8384

El Salvador

8386

Syrian Arab Republic

8389

Swaziland

8390

Turks and Caicos Islands

8467

Chad

8468

French Southern Territories

8470

To go

8471

Thailand

8472

Tajikistan

8474

Tokelau

8475

Turkmenistan

8477

Tunisia

8478

Tonga

8479

East Timor

8480

Tu rk e y

8482

Trinidad and Tobago

8484

Tu va l u

8486

CountryCode

Abbreviation

TW TZ UA UG UM

US UY UZ VA VC

VE VG VI VN VU WF WS YE YT YU ZA ZM ZW

8487 8490 8565 8571 8577

8583 8589 8590 8665 8667

8669 8671 8673 8678 8685 8770 8783 8969 8984 8985 9065 9077 9087

Taiwan, Province of China Tanzania, United Republic of Ukraine Uganda United States Minor

Outlying Islands United States Uruguay Uzbekistan Holy See (Vatican City State) Saint Vincent and the

Grenadines Venezuela Virgin Island, British Virgin Islands, U.S Viet Nam Vanuatu Wallis and Futuna Samoa Yemen Mayotte Yugoslavia South Africa Zambia Zimbabwe

99-EN

In Case of Difficulty

If you encounter a problem, please turn the power off, then on again. If the unit is still not functioning normally, please review the items in the following checklist. This guide will help you isolate the problem if the unit is at fault. Otherwise, make sure the rest of your system is properly connected, or then consult your authorized Alpine dealer.

Basic

No function or display.

• Vehicle’s ignition is off.

- If connected according to the instructions, the unit will not operate with the vehicle’s ignition off.

• Improper power lead connections.

- Check power lead connections.

•Blown fuse.

- Check the fuse on the battery lead of the unit; replace with the proper value if necessary.

• Internal micro-computer malfunctioned due to interference noise, etc.

- Press the RESET switch with a ballpoint pen or other pointed

article. (Only for GMC/Chevrolet or other model.)

No sound or unnatural sound.

• Incorrect setting of volume/balance/fader controls.

- Readjust the controls.

• Connections are not properly or securely made.

- Check the connections and firmly connect.

Screen not displayed.

• Brightness/Contrast control is set at the minimum position.

- Adjust the Brightness/Contrast control.

• Temperature in the vehicle is too low.

- Increase the vehicle’s interior temperature to operation

temperature range.

• Connections to the DVD are not securely made.

- Check the connections and firmly connect.

• The Parking Brake Lead is not connected.

• The Parking Brake is not engaged.

- Connect the Parking Brake Lead, then engage the Parking

Brake. (See page 111)

Movement of displayed picture is abnormal.

• Temperature in the vehicle is too high.

- Allow the vehicle’s interior temperature to cool.

The optional remote control is inoperative.

• The remote control sensor setting of “Remote Sensor Setting” (page 44) is not set to this unit (“Front”).

- Set for “Front”.

Radio

Unable to receive stations.

• No antenna, or open connection in the antenna cable.

- Make sure the antenna is properly connected; replace the antenna or cable if necessary.

Unable to tune stations in the seek mode.

• You are in a weak signal area.

- Make sure the tuner is in DX mode.

• If the area you are in is a primary signal area, the antenna may not be grounded and connected properly.

- Check your antenna connections; make sure the antenna is

properly grounded at its mounting location.

• The antenna may not be the proper length.

- Make sure the antenna is fully extended; if broken, replace the

antenna with a new one.

Broadcast is noisy.

• The antenna is not the proper length.

- Extend the antenna fully; replace it if it is broken.

• The antenna is poorly grounded.

Make sure the antenna is grounded properly at its mounting location.

• The station signal is weak and noisy.

- If above solution does not work, tune in another station.

Disc

Disc playback sound is wavering.

• Moisture condensation in the disc Module.

- Allow enough time for the condensation to evaporate (about 1

hour).

Disc insertion not possible.

• A disc is already in this unit.

- Eject the disc and remove it.

• The disc is being improperly inserted.

- Insert the disc correctly. (See page 19)

Unable to fast forward or backward the disc.

• The disc has been damaged.

- Eject the disc and discard it; using a damaged disc in your unit

can cause damage to the mechanism.

Disc playback sound skips due to vibration.

• Improper mounting of the unit.

- Securely re-mount the unit.

• Disc is very dirty.

- Clean the disc.
