Alpine CDA-7990 User Manual

CDA-7990

FM/AM CD Player

• OWNER'S MANUAL
Please read before using this equipment.

• MODE D'EMPLOI
Veuillez lire avant d’utiliser cet appareil.

• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.

R

ENGLISHFRANÇAISESPAÑOL

Contents

WARNING

WARNING............................................. 2

CAUTION.............................................. 3

PRECAUTIONS.................................... 3

Basic Operation

Detaching the Front Panel ........................... 6

Attaching the Front Panel............................ 7

Initial System Start-Up ................................ 7

Turning Power On and Off .......................... 8

Adjusting Volume/Subwoofer/Bass/T reble/
Balance (Between Left and Right)/

Fader (Between Front and Rear) .............. 9

Audio Mute Function .................................. 9

Displaying Time ........................................ 10

Setting Time .............................................. 11

Adjusting the Bass/Treble Center

Frequencies ............................................. 12

Setting when Using the Remote Control ... 14

Switching the Tuner Mode ........................ 15

Changing Lighting Color........................... 16

CD Text Scroll Setting............................... 18

Subwoofer On and Off .............................. 19

Digital Optical Output On and Off ............ 20

Setting the AUX Mode .............................. 21

Turning Mute Mode On/Off ...................... 22

Blackout Mode On and Off ....................... 23

Displaying the Title/Text ........................... 24

Titling Discs/Stations ................................ 26

Searching for Titled Stations ..................... 28

Searching for Titled Discs/CD-TEXT....... 29

Erasing Disc Title

(CD/CD Changer only)........................... 30

Recalling the Stored Settings .................... 31

Switching the Disc Mode .......................... 31

Radio Operation

Manual Tuning .......................................... 32

Automatic Seek Tuning ............................. 33

Manual Storing of Station Presets ............. 34

Automatic Memory

of Station Presets .................................... 35

Storing into Direct Access Preset

(D.A.P.) Band..........................................36

Tuning to Preset Stations........................... 37

CD Player Operation

Playback .................................................... 38

Music Sensor (Skip) .................................. 39

Fast Forward and Backward ...................... 39

Repeat Play ................................................ 40

M.I.X. (Random Play) ............................... 41

Scanning Programs .................................... 41

Controlling CD Changer (Optional) .......... 42

Multi-Changer Selection ........................... 43

Information

In Case of Difficulty .................................. 44

Specifications ............................................ 46

LIMITED W ARRANTY

1-EN

WARNING

WARNING

This symbol means important instruc­tions.
Failure to heed them can result in
serious injury or death.

DO NOT OPERATE ANY FUNCTION THAT
TAKES YOUR ATTENTION AWAY FROM
SAFELY DRIVING YOUR VEHICLE.

Any function that requires your prolonged
attention should only be performed after
coming to a complete stop. Always stop the
vehicle in a safe location before performing
these functions. Failure to do so may result in
an accident.

KEEP THE VOLUME AT A LEVEL WHERE YOU
CAN STILL HEAR OUTSIDE NOISE WHILE
DRIVING.

Failure to do so may result in an accident.

MINIMIZE DISPLAY VIEWING WHILE
DRIVING.

Viewing the display may distract the driver
from looking ahead of the vehicle and cause an
accident.

USE THE CORRECT AMPERE RATING WHEN
REPLACING FUSES.

Failure to do so may result in fire or electric
shock.

USE ONLY IN CARS WITH A 12 VOLT
NEGATIVE GROUND.

(Check with your dealer if you are not sure.)
Failure to do so may result in fire, etc.

DO NOT BLOCK VENTS OR RADIATOR
PANELS.

Doing so may cause heat to build up inside and
may result in fire.

DO NOT PLACE HANDS, FINGERS OR
FOREIGN OBJECTS IN INSERTION SLOTS OR
GAPS.

Doing so may result in personal injury or
damage to the product.

DO NOT DISASSEMBLE OR ALTER.

Doing so may result in an accident, fire or
electric shock.

USE THIS PRODUCT FOR MOBILE 12V
APPLICATIONS.

Use for other than its designed application may
result in fire, electric shock or other injury.

KEEP SMALL OBJECTS SUCH AS BATTERIES
OUT OF THE REACH OF CHILDREN.

Swallowing them may result in serious injury.
If swallowed, consult a physician immediately.

2-EN

CAUTION

PRECAUTIONS

This symbol means important instruc­tions.
Failure to heed them can result in
injury or material property damage.

HALT USE IMMEDIATELY IF A PROBLEM
APPEARS.

Failure to do so may cause personal injury or
damage to the product. Return it to your
authorized Alpine dealer or the nearest Alpine
Service Center for repairing.

Temperature

Be sure the temperature inside the vehicle is
between +60°C (+140°F) and –10°C (+14°F)
before turning your unit on.

Moisture Condensation

You may notice the CD playback sound
wavering due to condensation. If this happens,
remove the disc from the player and wait about
an hour for the moisture to evaporate.

Damaged Disc

Do not attempt to play cracked, warped, or
damaged discs. Playing a bad disc could
severely damage the playback mechanism.

Maintenance

If you have problems, do not attempt to repair
the unit yourself. Return it to your Alpine
dealer or the nearest Alpine Service Station for
servicing.

3-EN

Never Attempt the Following

Do not grip or pull out the disc while it is being
pulled back into the player by the automatic
reloading mechanism.
Do not attempt to insert a disc into the unit
when the unit power is off.

Inserting Discs

Your player accepts only one disc at a time for
playback.
Do not attempt to load more than one disc.
Make sure the label side is facing up when you
insert the disc. Your player will automatically
eject any disc that is inserted incorrectly. If the
player continues to eject a correctly inserted
disc, push the Reset switch with a pointed
object such as a ball-point pen.
Playing a disc while driving on a very bumpy
road may result in skips, but this will not
scratch the disc or damage the player.

New Discs

As a protective measure to prevent the CD
from jamming, the CD player will automati­cally eject discs with irregular surfaces or
inserted incorrectly. When a new disc is
inserted into the player and ejected after initial
loading, using your finger, feel around the
inside of the centre hole and outside edge of
the disc. If you feel any small bumps or
irregularities, this could inhibit proper loading
of the disc. To remove the bumps, rub the
inside edge of the hole and outside edge of the
disc with a ball-point pen or other such
instrument, then insert the disc again.

Center Hole

Bumps

Center Hole

New Disc

Outside
(Bumps)

4-EN

Irregular Shaped Discs

Be sure to use round shape discs only for this
unit and never use any special shape discs.
Use of special shape discs may cause damage
to the mechanism.

Installation Location

Make sure the CDA-7990 will not be installed
in a location subjected to:

• Direct sun and heat

• High humidity and water

• Excessive dust

• Excessive vibrations

Handling the Detachable Front Panel

• Do not expose to rain or water.

• Do not drop or apply shock.

Correct Handling

Do not drop the disc while handling. Hold the
disc so you will not leave fingerprints on the
surface. Do not affix tape, paper, or gummed
labels to the disc. Do not write on the disc.

Disc Cleaning

Fingerprints, dust, or soil on the surface of the
disc could cause the CD player to skip. For
routine cleaning, wipe the playing surface with
a clean, soft cloth from the center of the disc to
the outer edge. If the surface is heavily soiled,
dampen a clean, soft cloth in a solution of mild
neutral detergent before cleaning the disc.

INCORRECT

CORRECT

CORRECT

Disc Accessories

There are various accessories available on the
market for protecting the disc surface and
improving sound quality.
However, most of them will influence the
thickness and/or diameter of the disc. Using
such accessories can cause the disc to be out of
standard specifications and may create
operational problems. We recommend not
using these accessories on discs played in
Alpine CD players.

Transparent Sheet

Disc Stabilizer

5-EN

Basic Operation

RLS

POWER

Detaching the Front Panel

Press the POWER button for more than 3
seconds to turn off the power.

Press the RLS (Release) button at lower left
corner until the front panel pops out.

Grasp the left side of the front panel and pull it
out.

• The front panel may become hot
in normal usage (especially the
connector terminals), this is not
malfunction.

• To protect the front panel, place
it in the supplied carrying case.

6-EN

Attaching the Front Panel

First, insert the right side of the front panel into

1

the main unit. Align the groove on the front panel
with the projections on the main unit.

Push the left side of the front panel until it locks

2

firmly into the main unit.

2

1

Initial System Start-Up

Make sure that the Power is turned off. When the power is
on, press and hold the POWER button for at least 3
seconds to turn off the power.
Immediately after installing or applying power to the unit, it
should be initialized. To do this, first, remove the detachable
front panel. Behind the front panel, to the right of the
connector, there is a small hole.
Using a ball-point pen or other pointed object, press the
reset switch mounted behind this hole to complete the
initialization procedure.

• Before attaching the front panel,
make sure that there is no dirt or
dust on the connector terminals
and no foreign object between
the front panel and the main unit.

RESET switch

7-EN

Basic Operation

MUTE

MODE(Audio Control)

POWER

Turning Power On and Off

Press the POWER button to turn on the unit.

1

The volume level gradually increases to the
previous level you were listening to before the unit
was turned off. Press the POWER button for more
than 3 seconds to turn off the unit.

• Controllable with Remote
Control

This unit can be controlled with
an optional Alpine remote
control. For details, consult your
Alpine dealer.

Point the optional remote control
transmitter at the remote control
sensor.

Remote control sensor

• Connectable to Remote
Control Interface Box

You can operate this unit from
the vehicle’s control unit when
an Alpine Remote Control
Interface Box (optional) is
connected. For details, contact
your Alpine dealer.

8-EN

• The unit can be turned on by
pressing any other button except
the eject button.

• The very first time the power is
turned on, the volume will start
from –67dB.

Adjusting V olume/Subwoofer/
Bass/Treble/Balance (Between Left
and Right)/Fader (Between Front
and Rear)

Press the MODE (Audio Control) knob repeatedly

1

to choose the desired mode.
Each press changes the modes as follows:

*

VOLUME BASSSUB-W

Rotate the MODE (Audio Control) knob until the

2

desired sound is obtained in each mode.

*

BALANCEFADER

*

TREBLE

*

*

Audio Mute Function

Activating this function will instantly lower the volume level by
20 dB.

• * Not displayed when setting
the SUB-W mode to OFF.
(For the setting of the SUB­W mode, refer to page 19.)

•**To display the BASS or

TREBLE mode:

Press and hold the SETUP

1

button for at least 3 seconds.
Press the

2

button to select the BASS/
TRE mode.
Press the TUNE button to set

3

the BASS/TRE to ON.
Press the SETUP button to

4

complete the setting. Then
perform the step 1 in the left
column.

** “BASS”, “TREBLE” is not

displayed when an external
audio processor is connected
(except PRA-H400).

• If the MODE (Audio Control)
knob is not rotated in 5
seconds after selecting the
BASS, TREBLE, BAL­ANCE, or FADER mode, the
unit automatically returns to
the VOLUME mode.

• When the subwoofer mode is

ON, its respective levels may be
adjusted.

• The settings of the Bass and

Treble will be individually
memorized for each source (FM,
AM and CD) until the setting is
changed. Depending on the
connected devices, some
functions and display indications
do not work.

DN or UP

Press the MUTE button to activate the MUTE

1

mode. The audio level will decrease by about 20
dB.

Pressing the MUTE button again will bring the
audio back to its previous level.

9-EN

Basic Operation

MODE(Audio Control)

Displaying Time

Press the CLK (clock) button repeatedly until the

1

time is displayed.
Each press changes the modes as follows:

Radio mode

Radio frequency

CD Player/Changer modes

Playing time
mode

TITLE mode

Clock priority
mode

Clock priority
mode

TRACK TEXT
mode

TITLE mode

DISC TEXT
mode

CLK

• Selecting any tuner or CD
function while in the clock
priority mode will interrupt the
time display momentarily. The
function selected will be
displayed for about 5 seconds
before the time returns to the
display.

10-EN

Setting Time

Press and hold the CLK (Clock) button for at least

1

3 seconds while the time is displayed until the
time indication blinks.

Rotate the MODE (Audio Control) knob to adjust

2

the hours while the time indication is blinking.

When the hours has been adjusted, press the

3

MODE (Audio Control) knob.

Rotate the MODE (Audio Control) knob to adjust

4

the minutes while the time indication is blinking.
The time is automatically set 5 seconds after the
minute adjustment. The time can also be manu­ally set by pressing the MODE (Audio Control)
knob.

D6T

01

114:

11-EN

Basic Operation

SETUP

DN
UP

TUNE

Adjusting the Bass/Treble
Center Frequencies

You can change the Bass/Treble center frequencies on this unit.
This gives you flexibility in creating your ideal sound field.

Press the hold the SETUP button for at least 3

1

seconds.

Press the

2

mode. Each press changes the modes as shown :

BASS/TRE REM CONT TUNER ILLUMI

After pressing the TUNE button, press the

3

or DN button to select the mode to change.

BASS/TRE REM CONTBC BW TC

UP

button to select the BASS/TRE

SCROLLSUB-WD-OUTAUX-INMUTE

12-EN

• If you press the DN button
the display scrolls in reverse
sequence.

UP

Press the TUNE button to select the desired

4

setting.

1. BC (Setting the Bass Center Frequency):

BC 60Hz BC 70Hz BC 80Hz BC 90Hz

BC 130Hz BC 100HzBC 150HzBC 200Hz

Emphasizes the displayed Bass frequency
ranges.

2. BW (Setting the Bass Band Width):
(Q-Factor)

BW WIDE1 BW WIDE2 BW WIDE3 BW WIDE4

(Narrow) (Wide)

Changes the displayed frequency’s band width
to narrow or wide.

3. TC (Setting the Treble Center Frequency):

TC 10.0kHz TC 12.5kHz TC 15.0kHz TC 17.5kHz

Emphasizes the displayed treble frequency
ranges.

Default values

BC: 80 Hz
BW: WIDE1
TC: 10.0kHz

Press the SETUP button again to return to

5

normal operation.

13-EN

Basic Operation

SETUP

DN
UP

TUNE

Setting when Using the
Remote Control

Press and hold the SETUP button for at least 3

1

seconds.
Press

2

CONT mode. Each press changes the modes as
shown:

BASS/TRE REM CONT TUNER ILLUMI

UP

or DN button to select REM

•

If you press the DN button the
display scrolls in reverse
sequence.

SCROLLSUB-WD-OUTAUX-INMUTE

Press the TUNE button to toggle the REM CONT

3

mode between On and Off.

REM CONT OFF REM CONT ON

• REM CONT ON: Set to ON when using the optional
Remote Control to operate the CDA-7990.

• REM CONT OFF: Resist the inference from the noise
such as ultraviolet rays exist in the natural to provide
a much higher quality sound.

Set to OFF when not using the optional Remote
Control.

<Display of “REM CONT ON”>

REM

CO

When the setting is completed, press the SETUP

4

button to return to the normal mode.

NOT

N

14-EN

•

The initial setting at the factory is
“REM CONT OFF”.

Switching the Tuner Mode

The CDA-7990 incorporates the MAX TUNE SQ for the highest
quality tuner audio. Moreover, you can choose between two
settings to suit your own personal sound preferences and usage.

Press and hold the SETUP button for at least 3

1

seconds.

Press

2

the UP
TUNER mode. Each press changes the modes as
shown.

BASS/TRE REM CONT TUNER ILLUMI

Press the TUNE button to toggle the TUNER

3

mode between NORMAL and Hi-Fi.

TUNER NORMAL TUNER Hi-Fi

NORMAL:Standard setting
Hi-Fi: Sound quality priority setting

<Display of “TUNER NORMAL”>

or DN button to select

SCROLLSUB-WD-OUTAUX-INMUTE

•

If you press the DN button the
display scrolls in reverse
sequence.

•

The initial setting at the factory is
“TUNER NORMAL”.

• If you find the sound is very
noisy while listening to the tuner
in the Hi-Fi mode, we recom­mend you change to the
NORMAL mode.

TUNERLAMN

When the setting is completed, press the SETUP

4

button to return to the normal mode.

OR

• How MaxTune SQ works its
magic

There are a variety of reasons, so
let’s get technical. 1) The FM
section has an extraordinarily high
80dB signal-to-noise ratio, thanks
to a new PLL (phase-locked loop)
circuit with low jitter, and a new
low-noise IF detection circuit. 2)
Lower distortion (typically 0.08%,
but always less than 0.1%) due to
an improved demodulation coil. 3)
High performance ceramic filter
with automatic Wide/Narrow mode
switching for greater selectivity,
important in crowded reception
areas. 4) Improved high-power
input characteristics. 5) The AM
section has new parts and circuitry
that are more resistant to
interference.
What all this adds up to is very
simple: a tuner capable of
delivering radio sound that doesn’t
suffer in comparison with CD
sound.

15-EN

Basic Operation

SETUP

DN

UP

TUNE

Changing Lighting Color

Press and hold the SETUP button for at least 3

1

seconds.

Press the

2

“ILLUMI”.
Each press of the

modes as shown:

BASS/TRE REM CONT TUNER ILLUMI

UP

button repeatedly to select

UP

button changes the

16-EN

• If you press the DN button
the display scrolls in reverse
sequence.

SCROLLSUB-WD-OUTAUX-INMUTE

Press the TUNE button to toggle the mode

3

between Blue and Green.

ILLUMI BLUE ILLUMI GREEN

<Display of “ILLUMI BLUE”>

ILLUM

IEUBL

Press the SETUP button to set the selected

4

mode.

• The initial setting at the factory
is “ILLUMI BLUE”.

17-EN

Basic Operation

SETUP

DN
UP

TUNE

MODE(Audio Control)

CD Text Scroll Setting

This CD player has the ability to scroll the disc and track name
recorded on CD-Text discs. The scrolling feature will work with
names greater than 12 characters. This feature will not work for
the 12 character titles that were input manually.

Press and hold the SETUP button for at least 3

1

seconds.

Press the

2

“SCROLL”.
Each press of the

modes as shown:

BASS/TRE REM CONT TUNER ILLUMI

Press the TUNE button to toggle mode between

3

SCROLL ON and OFF.

• SCROLL ON: the display of CD text is scrolled
continuously.

• SCROLL OFF: the display is scrolled only when
a disc is loaded or when a track is changed and
the text information exceeds 12 digits.

When the setting is completed, press the SETUP

4

button to return to the normal mode.

UP

button repeatedly to select

UP button changes the

SCROLLSUB-WD-OUTAUX-INMUTE

18-EN

• If you press the DN button
the display scrolls in reverse
sequence.

• Initial mode is “SCROLL OFF”.

• The unit scrolls only CD text names.
But, when the MD player is
connected, the unit also scrolls MD
titles. The disc titles input manually
(refer to pages 26, 27) cannot be
scrolled.

Subwoofer On and Off

Press and hold the SETUP button for more than 3

1

seconds.

Press the

2

“SUB-W”.
Each press of the

modes as shown:

BASS/TRE REM CONT TUNER ILLUMI

Press the TUNE button to toggle mode between

3

SUB-W ON and SUB-W OFF.

If an Ai-NET compatible processor with
Subwoofer output is connected:

Press the TUNE button after selecting the SUB-W
ON mode, and the subwoofer output phase is
toggled SUB-W NORMAL (0°) or SUB-W
REVERS (180°).

Press the SETUP button after setting the SUB-W

4

ON.

Press the MODE (Audio Control) knob repeatedly

5

to select the SUB-W mode.

SUB-W

UP

button repeatedly to select

UP

button changes the

BALANCE

VOLUME FADER

SCROLLSUB-WD-OUTAUX-INMUTE

• If you press the DN button
the display scrolls in reverse
sequence.

• “BASS”, “TREBLE” is
displayed when setting the
BASS/TRE mode to ON.

Rotate MODE (Audio Control) knob until the

6

desired sound is obtained in each mode.

19-EN

Basic Operation

SETUP

DN

UP

TUNE

SOURCE

Digital Optical Output On and
Off

When connecting to the Multimedia Manager (PXA-H900), set
the D-OUT mode to ON. Set to OFF when not connecting
PXA-H900.

Press and hold the SETUP button for at least 3

1

seconds.

Press the

2

mode. Each press changes the modes as shown:

BASS/TRE REM CONT TUNER ILLUMI

Press the TUNE button to turn on the D-OUT

3

mode.
Each press toggles between D-OUT ON and D-

OUT OFF.

D-OUT ON D-OUT OFF

<Display of “D-OUT ON”>

D-OU

Press the SETUP button again to return to

4

normal operation.

UP

button to select the D-OUT

T

NO

SCROLLSUB-WD-OUTAUX-INMUTE

20-EN

• If you press the DN button
the display scrolls in reverse
sequence.

• The initial setting at the factory
is “D-OUT OFF”.

Setting the AUX Mode

You can input TV/video sound by connecting an optional Ai­NET/RCA Interface cable (KCA-121B) to this component.

Press and hold the SETUP button for more than 3

1

seconds.

Press the

2

“AUX-IN” .
Each press of the

modes as shown:

BASS/TRE REM CONT TUNER ILLUMI

Press the TUNE button to set the mode to

3

AUX-IN ON.

AUX-IN OFF AUX-IN ON

Once AUX-IN is ON, AUXILIARY is displayed by

4

pressing the

AUX-IN MUTEAUXILIARY

Press the TUNE button to select the desired

5

display setting in AUX-IN mode.

AUXILIARY VCR GAMETELEVISION

<Display when setting to “AUXILIARY”>

UP

button repeatedly to select

UP or DN button.

AUXILIARY

UP button changes the

SCROLLSUB-WD-OUTAUX-INMUTE

• If you press the DN button
the display scrolls in reverse
sequence.

• The initial setting at the factory
is AUX-IN OFF.

Press the SETUP button to activate the normal

6

mode.

To adjust the volume, etc., first press the

7

SOURCE button and select the AUXILIARY
mode, then make the necessary adjustment.

TUNER CD AUXILIARY

21-EN

Basic Operation

B. OUT indicator

SETUP

DN

UP

TUNE

B.OUT (Black out)

Turning Mute Mode On/Off

If a device having the interrupt feature is connected, audio will be
automatically muted whenever the interrupt signal is received
from the device. This function can be turned ON or OFF from the
head unit by following procedure below.

Press and hold the SETUP button for at least 3

1

seconds.

Press the

2

mode. Each press changes the modes as shown:

BASS/TRE REM CONT TUNER ILLUMI

Press the TUNE button to turn on or off the Mute

3

mode.
Each press toggles between the MUTE ON and

OFF modes.

Press the SETUP button again to return to

4

normal operation.

UP

button to select the MUTE

SCROLLSUB-WD-OUTAUX-INMUTE

22-EN

• If you press the DN button
the display scrolls in reverse
sequence.

• The initial setting at the factory
is “MUTE ON”.

Blackout Mode On and Off

Turning off the back light of front panel can resist the inference
from the noise caused by the back light and provide you a much
higher quality sound.

Press and hold the B. OUT (Black out) button for

1

at least 3 seconds, the “B-OUT ON” indication
appears and disappears. Then the blackout mode
starts. The back light turns off with only the
B. OUT indicator ON, and the audio signals
bypass the treble and bass circuits. This reduces
noise to give a clean, flat response.

To cancel the blackout mode, press and hold the
B. OUT (Black out) button for at least 3 seconds.

After the “B-OUT OFF” indication appears and
disappears, the back light turns on with the
B. OUT indicator OFF.

• If any button on the unit is
pressed during the blackout
mode, the function will be
displayed for 5 seconds to show
the operation before returning to
Blackout mode.

• The BASS/TREBLE control is
bypassed when the display panel
lighting is OFF.

23-EN

Basic Operation

Displaying the Title/Text

It is possible to display the CD/Station title if the title has been
previously inputted. For details, see Titling Discs/Stations (pages
26, 27). Text information, such as the disc name and the track
name, will be displayed if playing a CD text compatible disc.

Press the TITLE button.

1

The mode will change every time the button is
pressed.

TITLE

About “Title” and “Text”
Title: With this device, it is possible to input the CD/

Station name (see pages 26, 27). This inputted
name is referred to as a “title”.

Text: Text compatible CDs contain text information

such as the disc name and track name. Such
text information is referred to as “text”.

Radio mode:

FREQUENCY DISPLAY

CLOCK DISPLAY

TITLE DISPLAY*

2

24-EN

CD/Changer mode:

ELAPSED TIME DISPLAY

CLOCK DISPLAY

TEXT DISPLAY (DISC NAME)*

TEXT DISPLAY(TRACK NAME)*

TITLE DISPLAY*

1

1

2

*1 Displayed during playback of a text compatible

CD. “NO TEXT” will be displayed when the CD is
not text compatible.

*2 “

------------

” will be displayed when the title has not

been inputted.

Sample display with a text compatible CD.

• Some characters used for CD
Text, may not be compatible with
this device. These characters will
not be displayed correctly.

• CD Text can store more
information than this unit can
display, depending on the CD
changer.

25-EN

Basic Operation

BAND

MODE(Audio Control)

Titling Discs/Stations

It is possible to title your favorite CD’s or radio stations.

Press the TITLE button and select the title display

1

mode.
For details, see “Displaying the Title/Text” (pages

24, 25).

Press and hold the TITLE button for at least 3

2

seconds. The first character will blink.

Press the BAND button to switch to the desired

3

character.

Capital letter Small letter Numeral/symbol

Rotate the MODE (Audio Control) knob to select

4

the desired letter/numeral/symbol available for
naming. (“A” for example).

TITLE

Capital letter :

_ A B C D E F G H I J K L M N O
P Q R S T U V W X Y Z

Small letter :

_ a b c d e f g h i j k l m n o p q r
s t u v w x y z

Numeral/symbol :

_ 0 1 2 3 4 5 6 7 8 9 ! ” # $ % & ’
( ) * + , - . / : ; < = > ? @ \

26-EN

Press the MODE (Audio Control) button to store

5

the first character. The first character will stop
blinking and the display will automatically ad­vance to the next character. When that character
begins to blink, you may choose the next letter or
symbol of your title.

AA

Repeat the steps 3 and 5 above to complete the

6

titling. Pressing the MODE (Audio Control) button
after entering the 12th character, automatically
stores the title into memory.

When entering a title of less than 12 characters
(for example, 3 character title):

After entering 3 characters to complete your title,
the 4th character space will be blinking. Press the
TITLE button to record the title.

The title memory number will be displayed for
about 2 seconds.

For example :

ME 051

Number of titles
memorized

Press the TITLE button to end the title display

7

mode.

[]

1

Memory capacity

• The memory capacity for the disc
title is up to 150 including the
built-in CD, radio station, CD­changer. If you try to store
beyond the limit, the display will
show “FULL DATA.” At this
point, no more titles can be
stored.

• To input a new title, one of the
previously inputted titles must
first be deleted.

• When you want to erase a title,
enter the “ ” symbol into all
spaces.

27-EN

Basic Operation

DN
UP

T.S.M.

Searching for Titled Stations

If a Station is titled, you can do a search for it.
(To title Stations, refer to “Titling Discs/Stations” on pages 26,

27.)

Press and hold the T.S.M. button for at least 2

1

seconds. The title blinks in the display.

Press the DN or

2

desired station title.

Press the T .S.M. b utton to play the selected

3

station.
The unit will automatically search for the station

and begin play.

UP

button to select the

• If no title is entered, the display
will show “No DATA”.

28-EN

Searching for Titled Discs/CD­TEXT

If a CD is titled or contains CD-TEXT, you can do a search for it.
(To title CDs, refer to “Titling Discs/Stations” on pages 26, 27.)

Press and hold the T .S.M. button for at least 2

1

seconds. The title blinks in the display.

Press the DN or

2

desired disc title or CD-TEXT.

For example:

DISC title of CD built-in DISC title of CD Player

CD text of CD changer

• The display scroll sequence varies depending on the
connected source.

Press the T .S.M. b utton to pla y the selected disc.

3

The unit will automatically search for the disc and
begin play.

UP

button to select the

CD text of CD Player

DISC title of CD changer

CD text of CD built-in

• This function cannot be
performed when using a multi­changer switching device.

29-EN

Basic Operation

DN

UP

BAND

Erasing Disc Title (CD/CD
Changer only)

Press the TITLE button to select the disc titling

1

mode. Then, press and hold for at least 3 sec­onds.

Press and hold the button for at least 2

2

seconds to activate the title scanning mode. The
title in the display will blink.

TITLE

Press the DN or

3

unitl the disc title you want to erase is displayed.

Press and hold the button for at least 2

4

seconds to erase the disc title displayed.

Press and hold the TITLE button for at least 3

5

seconds to cancel the disc title erasing mode.

UP

button repeatedly

30-EN

• You cannot erase a CD-TEXT.
This information is stored on the
CD.

Recalling the Stored Settings

Settings stored in the Alpine Multimedia Manager (PXA-H900)
using the optional Remote Control, can be recalled at any time.

Press the A. PROC button on the Remote control.

1

Press the or button within 5 seconds, to recall

2

the stored setting.

Switching the Disc Mode

Use this function when connecting the optional CD/MD player,
changer.

Press the BAND button to switch the Disc mode

1

in the CD/MD/Changer mode.
Disc mode is displayed for about 3 seconds.

DISC EXT DISC CHANGER

(Built-in CD) (Changer)(External CD/MD)

• The display may be different depending on the
production connected.

• Refer to the Owner’s manual of
the optional Remote Control.

31-EN

Radio Operation

DN

UP

TUNE
BAND

SOURCE

Manual Tuning

Press the SOURCE button until a radio frequency

1

appears in the display.

Press the BAND button repeatedly until the

2

desired radio band is displayed.
Each press changes the band:

F1(FM1) F2(FM2) AM

Press the TUNE button repeatedly until “DX

3

SEEK” and “SEEK” disappear from the display.

Press the DN or

4

downward or upward one step respectively until
the desired station frequency is displayed.

<Display example>

F

1

P

1

UP

button to move

1.071

32-EN

• The initial mode is DX SEEK.

• The ST indicator appears on the
display when a Stereo FM station
is tuned in.

Automatic Seek Tuning

Press the SOURCE button until a radio frequency

1

appears in the display.

Press the BAND button repeatedly until the

2

desired radio band is displayed.
Each press changes the band:

F1(FM1) F2(FM2) AM

Press the TUNE button to illuminate the DX and

3

SEEK indicators in the display.
With the DX (Distance) mode activated, both

strong and weak stations will be tuned in the
Auto-Seek operation.

Press again to return to the local mode. The DX
indicator will turn off and the SEEK indicator will
remain illuminated. Now, only strong stations will
be tuned.

Press the DN or

4

cally seek for a station downward or upward
respectively.

The unit will stop at the next station it finds. Press
the same button again to seek the next station.

<Display example>

F

1

P

1

UP

button to automati-

1.071

33-EN

Radio Operation

A. ME
BAND

SOURCE

Manual Storing of Station
Presets

Select the radio band and tune in a desired radio

1

station you wish to store in the preset memory.
Press and hold any one of the Preset buttons (1

2

through 6) for at least 2 seconds until the “ P ”
(Preset) on the display blinks.

Preset buttons
1~6

F

1

P

Press the Preset button into which you wish to

3

store the station while the “ P ” (Preset) display is
blinking (within 5 seconds).

The display stops blinking once the station has
been memorized. The display shows the band,
preset No. with a “ P ” and station frequency
memorized.

F

1

P

1

77.8

77.8

34-EN

Repeat the procedure to store up to 5 other

4

stations onto the same band.
To use this procedure for other bands, simply

select the band desired and repeat the proce­dure.

A total of 24 stations can be stored in the preset
memory (6 stations for each band; FM1, FM2, AM
and D.A.P.).

Automatic Memory of Station
Presets

Press the SOURCE button to select the radio

1

mode.

Press the BAND button repeatedly until the

2

desired radio band is displayed.

• If you store a station in a preset
memory which already has a
station, the current station will be
cleared and replaced with the
new station.

• The function indicator will
always light in green in the radio
mode.

Press and hold the A. ME button for at least 2

3

seconds.
The frequency on the display continues to change

while Automatic Memory is in progress. The tuner
will automatically seek and store 6 strongest
stations into the selected band.

They will be stored into presets 1 to 6 in order of
signal strength.

When Automatic Memory has been completed,
the tuner goes to the station stored in Preset No.

1.

• If no stations are stored, the tuner
will return to the original station
you were listening to before the
auto memory procedure began.

35-EN

Radio Operation

BAND

SOURCE

Storing into Direct Access
Preset (D.A.P.) Band

A combination of radio stations in any band (up to 6
stations) can be manually preset into the D.A.P. band.

D.A.P.
Preset

Press the D.A.P. button to toggle the D.A.P.

1

setting between ON and OFF.

D.A.P. ON D.A.P. OFF

<Display of “D.A.P. ON” >

D.A.

P

NO.

Press the BAND button to select FM or AM. The
selected band will be displayed.

To memorize stations onto the D.A.P. band, follow
the steps for the automatic or Manual Storing of
Station Presets section above.

36-EN

• This function can be used
together with the Automatic
Memory Preset.

Tuning to Preset Stations

Press the SOURCE button to select the radio

1

mode.

Press the BAND button repeatedly until the

2

desired band is displayed.
To select the D.A.P. band, press the D.A.P. b utton

to set the D.A.P. to ON.

Press the station Preset button that has your

3

desired radio station in memory.
The display shows the band, preset number with

a “P” and frequency of the station selected.

F

1

P

1

Preset indicator

Display when receiving the
station stored in “1” to “6”.

1.071

37-EN

CD Player Operation

DN
UP

SOURCE

Playback

Insert a disc with the label side facing up.

Insert a disc with the label side facing up.

1

The disc will be pulled into the unit automatically.
The unit starts to play the CD.

<Display example of CD mode>

CD T

02

CD mode

When a disc is already inserted, press the
SOURCE button to switch to the CD mode. The
mode will change every time the button is
pressed.

TUNER CD CD CHANGER*

(* Only when the CD changer is connected)

230'

CD playback elapsed time

Track Number

Function indicator

• Three-inch (8 cm) CD’s can be
used.

• If the CD is not removed for
several seconds after it has been
ejected, the player automatically
draws the CD into the compart­ment to protect the CD.

• Only compact discs containing
the mark shown can be used.

• We cannot fully guarantee the
playback of CD-R (CD­Recordable). Y ou cannot
playback CD-RW (CD­ReWritable) on this unit.

• The function indicator will
always light in red in the CD
mode.

38-EN

To pause playback, press the button. Press-

2

ing the

To eject the disc, press the button.

3

button again will resume playback.

Music Sensor (Skip)

Momentarily press the DN button once during

1

CD play to return to the beginning of the current
track. If you wish to access the beginning of a
track further back, repeatedly press until you
reach the desired track.

Press the
beginning of the next track. If you wish to access
the beginning of a track further ahead, press
repeatedly until the desired track is reached.

UP

button once to advance to the

• The music sensor feature is
functional in the play or pause
mode.

Fast Forward and Backward

Press and hold the DN or

1

quickly move backward or forward until you reach
the desired section of the track.

UP

button to

39-EN

CD Player Operation

(off)

REPEAT

SCAN
FUNC

Repeat Play

Press the REPEAT button to play back repeatedly

1

the track being played.
The RPT indicator appears and the track will be

played repeatedly.
Press the REPEAT button again and select OFF

to deactivate the repeat play.

M.I.X.

• If a CD Changer is connected

• In case a 6-disc CD changer is

• In case a 12-disc CD changer is

Function indicator

and the RPT ALL mode is
selected, the unit repeatedly
plays back all tracks on the disc
selected.

connected:
In CD changer mode, press the
FUNC button to light the
function indicator in red, set the
Function mode to ON and go to
step 1.
To set the Function mode to OFF,
press the FUNC button again.

connected:
In CD changer mode, press the
FUNC button twice to light the
function indicator in red, set the
Function mode to ON and go to
step 1.
To set the Function mode to OFF,
press the FUNC button again.

40-EN

M.I.X. (Random Play)

Press the M.I.X. button in the play or pause mode.

1

The M.I.X. indicator will illuminate and the tracks
on the disc will be played back in a random
sequence. After all the tracks on the disc have
been played back once, the player will begin a
new random sequence play until the M.I.X. mode
is cancelled.

To cancel M.I.X. play, press the M.I.X. button
again to turn off the M.I.X.

• If a CD Changer equipped with
the ALL M.I.X. function is
connected, ALL M.I.X. will also
be selectable.
In this mode, the tracks on all the
CDs in the current magazine will
be included in the random
playback sequence.

(off)

• In case a 6-disc CD changer is
connected:
In CD changer mode, press the
FUNC button to light the
function indicator in red, set the
Function mode to ON and go to
step 1.
To set the Function mode to OFF,
press the FUNC button again.

• In case a 12-disc CD changer is
connected:
In CD changer mode, press the
FUNC button twice to light the
function indicator in red, set the
Function mode to ON and go to
step 1.
To set the Function mode to OFF,
press the FUNC button again.

Scanning Programs

Press the SCAN button to activate the Scan

1

mode.
The first 10 seconds of each track will be played

back in succession.
To stop scanning, press the SCAN button and

deactivate the Scan mode.

• In case a 6-disc CD changer is
connected:
In CD changer mode, press the
FUNC button to light the
function indicator in red, set the
Function mode to ON and go to
step 1.
To set the Function mode to OFF,
press the FUNC button again.

• In case a 12-disc CD changer is
connected:
In CD changer mode, press the
FUNC button twice to light the
function indicator in red, set the
Function mode to ON and go to
step 1.
To set the Function mode to OFF,
press the FUNC button again.

41-EN

CD Player Operation

BAND

Disc Select buttons
1~6

FUNC

SOURCE

Controlling CD Changer
(Optional)

An optional 6-disc or 12-disc CD Changer may be connected to
the CDA-7990 if it is Ai-NET compatible. With a CD Changer
connected to the Ai-NET input of the CDA-7990, the CD Changer
will be controllable from the CDA-7990.
Using the KCA-400C (the Multi-Changer Switching device)
multiple changers can be controlled by the CDA-7990.
See the Multi-Changer Selection section on page 43 for selecting
the CD Changers.

Press the SOURCE button to activate the

1

CHANGER mode. The display shows the
“Changer”, disc number and track number.

Press the Disc Select buttons (1 through 6)

2

corresponding to one of the discs loaded in the
CD Changer. The selected disc number appears
in the display and CD playback starts.

<Display example of CD changer mode>

D2T

02

Disc Number

110'

CD playback elapsed time

Track Number

Function indicator

• The controls on the CDA-7990
for CD Changer operation are
operative only when a CD
Changer is connected.

• The “Changer” indicator
illuminates in the CD Changer
mode.

• The source indicator varies
depending on the connected
source.

• After selecting the desired disc,
you can operate in the same way
as for the CDA-7990 CD player.
For details, please see the CD
Operation section.

• If the function indicator lights in
red, the Disc Select buttons
become nonfunctional.

• Press the FUNC button to turn
the function indicator to green,
then, select the discs numbered
from 1 to 6.

42-EN

When a 12-disc CD Changer is connected:

To select discs numbered from 1 to 6, the proce­dure is the same as for the 6-disc CD Changer. To
select discs numbered from 7 to 12, first press
the FUNC button. This changes the “D” indicator
to “d”. Then press the desired Disc Select button.
With the FUNC button activated, the Disc Select
buttons 1 to 6 will represent discs 7 to 12 respec­tively.

Multi-Changer Selection

Alpine’s Ai-NET system will support up to 6 CD Changers. When
operating two or more changers, the KCA-400C (Multi-Changer
Switching device) must be used. If you use 1 Switching device,
you can connect up to 4 CD Changers. If you use 2 Switching
devices, you can connect up to 6 CD Changers.

Press the SOURCE button on the CDA-7990 to

1

activate the CD Changer mode.

Alternatively, press the SOURCE button on the
optional Remote Control to activate the CD
Changer mode. Proceed to Step 3 below to select
the desired CD Changer.

• Press the FUNC button to turn
the function indicator off, then,
select the discs numbered from 7
to 12.

Press the BAND button on the CDA-7990 or the

2

optional Remote Control to activate the CD
Changer Selection mode.

The CD Changer Selection mode remains active

3

for 3 seconds after Step 2 is performed. Press the
BAND button until the desired CD Changer

indicator appears on the display.

Alternatively press the BAND button on the
optional Remote Control until the desired changer
indicator appears on the display.

To operate the selected changer, see “CD

4

Operation” section.

• If the selected CD Changer is not
connected, the display will show
“NO CHANGER”.

43-EN

Information

In Case of Difficulty

If you encounter a problem, please review
the items in the following checklist. This
guide will help you isolate the problem if the
unit is at fault. Otherwise, make sure the rest
of your system is properly connected or
consult your authorized Alpine dealer.

Basic

No function or display.

• Vehicle’s ignition is off.

- If connected following instructions, the
unit will not operate with the vehicle’s
ignition off.

• Improper power lead connections.

- Check power lead connections.

• Blown fuse.

- Check the fuse on the battery lead of the
unit; replace with the proper value if
necessary.

• Internal micro-computer malfunctioned
due to interference noise etc.

- Press the Reset switch with a ball-point

pen or other pointed article.

Radio

Unable to receive stations.

• No antenna or open connection in cable.

- Make sure the antenna is properly

connected; replace the antenna or cable
if necessary.

Unable to tune stations in the
seek mode.

• You are in a weak signal area.

- Make sure the tuner is in the DX mode.

• If the area you are in is a primary signal
area, the antenna may not be grounded and
connected properly.

- Check your antenna connections; make

sure the antenna is properly grounded at
its mounting location.

• The antenna may not be the proper length.

- Make sure the antenna is fully extended;

if broken, replace the antenna with a new
one.

Broadcast is noisy.

• The antenna is not the proper length.

- Extend the antenna fully; replace it if it

is broken.

• The antenna is poorly grounded.

- Make sure the antenna is grounded

properly at its mounting location.

CD

CD Player/Changer not function­ing.

• Out of operating temperature range +50˚C
(+120˚F) for CD.

- Allow the vehicle’s interior (or trunk)

temperature to cool.

CD playback sound is wavering.

• Moisture condensation in the CD Module.

- Allow enough time for the condensation

to evaporate (about 1 hour).

CD insertion not possible.

• A CD is already in the CD player.

- Eject the CD and remove it.

• The CD is being improperly inserted.

- Make sure the CD is being inserted

following instructions in the CD Player
Operation section.

44-EN

Unable to fast forward or back­ward the CD.

• The CD has been damaged.

- Eject the CD and discard it; using a
damaged CD in your unit can cause
damage to the mechanism.

CD playback sound skips due to
vibration.

• Improper mounting of the unit.

- Securely re-mount the unit.

• Disc is very dirty.

- Clean the disc.

• Disc has scratches.

- Change the disc.

• Pick-up lens is dirty

- Do not use the lens cleaner disc on the
market.
Consult your nearest ALPINE dealer.

CD playback sound skips without
vibration.

• Dirty or scratched disc.

- Clean the disc; damaged disc should be
replaced.

Error displays.

• Mechanical error

- Press the
indication disappears, insert the disc
again. If the above-mentioned solution
does not solve the problem, consult your
nearest ALPINE dealer.

button. After the error

Indication for CD Changer

HIGH TEMP

• Protective circuit is activated due to high
temperature.

- The indicator will disappear when the

temperature returns to within operation
range.

ERROR - 01

• Malfunction in the CD Changer.

- Consult your Alpine dealer. Press the

magazine eject button and pull out the
magazine.
Check the indication. Insert the
magazine again.
If the magazine cannot be pulled out,
consult your Alpine dealer.

• Magazine ejection not possible.

- Press the magazine eject button. If the

magazine doesnot eject, consult your
Alpine dealer.

ERROR - 02

• A disc is left inside the CD Changer.

- Press the Eject button to activate the

eject function.
When the CD Changer finishes the eject
function, insert an empty CD magazine
into the CD Changer to receive the disc
left inside the CD Changer.

NO MAGAZINE

• No magazine is loaded into the CD
Changer.

- Insert a magazine.

NO DISC

• No indicated disc.

- Choose another disc.

45-EN

Specifications

FM TUNER SECTION

Tuning Range 87.7 – 107.9 MHz
Mono Usable Sensitivity 9.3 dBf (0.8 µV/75 ohms)
50 dB Quieting Sensitivity 13.5 dBf (1.3 µV/75 ohms)
Alternate Channel Selectivity80 dB
Signal-to-Noise Ratio 80 dB
Stereo Separation 50 dB
Capture Ratio 2.0 dB

AM TUNER SECTION

Tuning Range 530 – 1,710 kHz
Sensitivity (IEC Standard) 22.5 µV/27 dB

CD PLAYER SECTION

Frequency Response 5 – 20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.002% (at 1 kHz)
Dynamic Range 100 dB (at 1 kHz)
Signal-to-Noise Ratio 120 dB
Channel Separation 110 dB (at 1 kHz)

GENERAL

Power Requirement 14.4 V DC

(11 – 16 V allowable)

Maximum Pre-Output Voltage
Bass ±12 dB at 60 Hz
Treble ±12 dB at 10 kHz
Weight 1.5 kg (3 lbs. 5 oz)

5V/10 k ohms

CHASSIS SIZE

Width 178 mm (7")
Height 50 mm (2")
Depth 155 mm (6-1/8")

NOSEPIECE SIZE

Width 170 mm (6-3/4")
Height 46 mm (1-13/16")
Depth 23 mm (15/16")

Due to continuous product improvement, specifications and design are subject to change
without notice.

<Components>

Parts name Quantity

Main unit ............................. 1

DC-DC converter ................ 1

Parts for mounting............... 1set

Power cord........................... 1

Carrying case....................... 1

Owner’s manual .................. 1set

46-EN

LIMITED WARRANTY

ALPINE ELECTRONICS OF AMERICA, INC. AND ALPINE OF CANADA INC. ("Alpine"), are dedicated to
quality craftsmanship and are pleased to offer this Warranty. We suggest that you read it thoroughly. Should
you have any questions, please contact your Dealer or Alpine at one of the telephone numbers listed below.

● PRODUCTS COVERED:

This Warranty covers Car Audio/Visual Products
and Related Accessories ("the product"). Products
purchased in the Canada are covered only in the
Canada. Products purchased in the U.S.A. are
covered only in the U.S.A.

● LENGTH OF WARRANTY:

This Warranty is in effect for one year from the date
of the first consumer purchase.

● LIFETIME TAPE HEAD WARRANTY:

All Alpine Car Audio analog tape heads excluding
Video tape heads are warranted for life against
manufacturing defects causing failure.

● WHO IS COVERED:

This Warranty only covers the original purchaser of
the product, who must reside in the United States,
Puerto Rico or Canada.

● WHAT IS COVERED:

This Warranty covers defects in materials or
workmanship (parts and labor) in the product.

● WHAT IS NOT COVERED:

This Warranty does not cover the following:

Damage occurring during shipment of the

1

product to Alpine for repair (claims must be
presented to the carrier).
Damage caused by accident, abuse, negligence,

2

misuse, improper connections, improper
operation or failure to follow instructions
contained in the Owner's manual.
Damage caused by act of God, including without

3

limitation, earthquake, fire, flood, storms or other
acts of nature.
Any cost or expense related to the removal or

4

reinstallation of the product.
Service performed by an unauthorized person,

5

company or association.
Any product which has the serial number

6

defaced, altered or removed.
Any product which has been adjusted, altered or

7

modified without Alpine's consent.
Any product not distributed by Alpine within the

8

United States, Puerto Rico or Canada.
Any product not purchased from an Authorized

9

Alpine Dealer.
Any product that has been determined to contain

p

an excessive amount of dust or dirt and any
product that contains other contaminants
including liquid or foreign objects.

●

HOW TO OBTAIN WARRANTY SERVICE:

You are responsible for delivery of the product to

1

an Authorized Alpine Service Center or Alpine
for repair and for payment of any initial shipping
charges. Alpine will, at its option, repair or
replace the product with a new or reconditioned
product without charge. If the repairs are
covered by the warranty, and if the product was
shipped to an Authorized Alpine Service Center
or Alpine, Alpine will pay the return shipping
charges.

Alpine Electronics of America, Inc., 19145 Gramercy Place, Torrance, California 90501, U.S.A.
Alpine Electronics of Canada, Inc., Suite 203, 7300 Warden Ave. Markham, Ontario, L3R 9Z6, Canada

You should provide a detailed description of the

2

problem(s) for which service is required.
You must supply proof of your purchase of the

3

product.
You must package the product securely to avoid

4

damage during shipment.

● HOW WE LIMIT IMPLIED WARRANTIES:

ANY IMPLIED WARRANTIES INCLUDING
FITNESS FOR USE AND MERCHANTABILITY
ARE LIMITED IN DURATION TO THE PERIOD OF
THE EXPRESS WARRANTY SET FORTH ABOVE
AND NO PERSON IS AUTHORIZED TO ASSUME
FOR ALPINE ANY OTHER LIABILITY IN
CONNECTION WITH THE SALE OF THE
PRODUCT.

● HOW WE EXCLUDE CERTAIN DAMAGES:

ALPINE EXPRESSLY DISCLAIMS LIABILITY FOR
INCIDENTAL AND CONSEQUENTIAL DAMAGES
CAUSED BY THE PRODUCT. THE TERM
"INCIDENTAL DAMAGES" REFERS TO
EXPENSES OF TRANSPORTING THE PRODUCT
TO THE ALPINE SERVICE CENTER, LOSS OF
THE ORIGINAL PURCHASER'S TIME, LOSS OF
THE USE OF THE PRODUCT, BUS FARES, CAR
RENTALS OR OTHERS COSTS RELATING TO
THE CARE AND CUSTODY OF THE PRODUCT.
THE TERM "CONSEQUENTIAL DAMAGES"
REFERS TO THE COST OF REPAIRING OR
REPLACING OTHER PROPERTY WHICH IS
DAMAGED WHEN THIS PRODUCT DOES NOT
WORK PROPERLY. THE REMEDIES PROVIDED
UNDER THIS WARRANTY ARE EXCLUSIVE AND
IN LIEU OF ALL OTHERS.

● HOW STATE/PROVINCIAL LAW RELATES TO

THE WARRANTY:

This Warranty gives you specific legal rights, and
you may also have other rights which vary form
state to state and province to province. In addition,
some states/provinces do not allow limitations on
how long an implied warranty lasts, and some do not
allow the exclusion or limitation of incidental or
consequential damages. Accordingly, limitations as
to these matters contained herein may not apply to
you.

● IN CANADA ONLY:

This Warranty is not valid unless your Alpine car
audio product has been installed in your vehicle by
an Authorized Installation Center, and this warranty
stamped upon installation by the installation center.

● HOW TO CONTACT CUSTOMER SERVICE:

Should the product require service, please call the
following number for your nearest Authorized Alpine
Service Center.

U.S.A. 1-800-ALPINE-1 (1-800-257-4631)
CANADA 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS, INC.

Tokyo office: 1-1-8 Nishi Gotanda,

Shinagawa-ku, Tokyo 141-8501, Japan

Tel.: [phone]

ALPINE ELECTRONICS OF AMERICA, INC.

19145 Gramercy Place, Torrance,

California 90501, U.S.A.

Tel.: 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS OF CANADA, INC.

Suite 203, 7300 Warden Ave. Markham,

Ontario L3R 9Z6, Canada

Tel.: 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.

6-8 Fiveways Boulevarde Keysborough,

Victoria 3173, Australia

Tel.: [phone]

ALPINE ELECTRONICS GmbH

Kreuzerkamp 7-11 40878 Ratingen,

Germany

Tel.: [phone]

ALPINE ITALIA S.p.A.

Via C. Colombo 8, 20090 Trezzano Sul

Naviglio MI, Italy
Tel.: [phone]

ALPINE ELECTRONICS FRANCE S.A.R.L.

(RCS PONTOISE B 338 101 280)

98, Rue De La Belle Etoile, Z.I. Paris Nord II

B.P. 50016 F-95945, Roissy,

Charles de Gaulle Cedex, France

Tel.: [phone]

ALPINE ELECTRONICS OF U. K., LTD.

13 Tanners Drive, Blakelands,

Milton Keynes MK14 5BU, U.K.

Tel.: [phone]

ALPINE ELECTRONICS DE ESPAÑA, S.A.

Portal De Gamarra 36, Pabellón 32

01013 Vitoria (Alava) - Apdo. 133, Spain

Tel.: [phone]

R

Sankei Kikaku Co., Ltd.
1-13-38, Hinodai,
Hino, Tokyo, Japan

Designed by ALPINE Japan

Printed in Japan (S)

68P30540Y87-O
