Alinco DJ-V57 User Manual
ALINCO, INC.
144/430MHz DUAL BAND FM TRANSCEIVER
DJ-V57
Instruction Manual
Thank you for purchasing your new Alinco transceiver. Please read this manual
carefully before using the product to ensure full performance, and keep this manual for
future reference as it contains information on after-sales service.
In case addendum or errata sheets are included with this product, please read those
materials and keep them together with this instruction manual for future reference.
2
NOTICE / Compliance Information Statement
NOTICE / Compliance Information Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Tested to Comply
With FCC Standards
FOR HOME OR OFFICE USE
Information in this document is subject to change without notice or obligation. All
brand names and trademarks are the property of their respective owners. Alinco
cannot be liable for pictorial or typographical inaccuracies. Some parts, options and/or
accessories are unavailable in certain areas. Changes or modifications not expressly
approved by the party responsible for compliance could void the user's authority to
operate the equipment.
144/440MHz FM amateur radio handheld transceiver DJ-V57T
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Manufacturer:
ALINCO, Inc.
Yodoyabashi Dai-bldg. 13F
4-4-9 Koraibashi, Chuo-ku,
Osaka 541-0043 Japan
NOTICE / Compliance Information Statement
3
Conformity Information
Alinco, Inc. Electronics Division hereby declare on our sole responsibility that the
product(s) listed below comply the essential requirements of the Directive 1999/5/EC,
The council of 3/9/99 on Radio Equipment and Telecommunication Terminal
Equipment and the mutual recognition of their conformity and with the provisions of
Annex, after having performed the required measurements at Notified Bodies per
Standards, and relative certificate(s) or document(s) can be reviewed at http://www.
alinco. com/Ce/
DJ-V57E FM amateur radio handheld transceiver
144.000~145.995MHz / 430.000~439.995MHz
This device is authorized for use in all EU and EFTA member states. An operator's
license is required for this device.
Copyright © All rights reserved. No part of this document may be reproduced, copied,
translated or transcribed in any form or by any means without the prior written
permission of Alinco. Inc., Osaka, Japan. English edition Printed in Japan.
Check with your local waste officials for details on recycling or proper disposal in
your area.
2200
4
Contents
Contents
NOTICE / Compliance Information Statement................................................2
Contents .............................................................................................................4
Warning...............................................................................................................7
Introduction......................................................................................................12
Before transmitting..........................................................................................12
1.Features.........................................................................................................13
1.1 Accessories .........................................................................................................13
2.Accessories...................................................................................................14
2.1 Installations.........................................................................................................14
2.1.1 Antenna ......................................................................................................14
2.1.2 Hand Strap..................................................................................................14
2.1.3 Belt Clip .....................................................................................................14
2.1.4 Battery Pack ...............................................................................................15
2.1.5 Prevent Short Circuiting the Battery Pack .................................................18
3.Names and Operations of Parts..................................................................19
3.1 Names and Operations of Keys and Ports...........................................................19
3.2 Keypad ................................................................................................................21
3.3 Display (LCD) ....................................................................................................22
4.Basic Operation ............................................................................................23
4.1 Turning On the Power.........................................................................................23
4.2 Adjusting the Audio Output (Volume) ...............................................................23
4.3 Adjusting the Squelch.........................................................................................23
4.4 Operating Modes.................................................................................................24
4.5 Setting the Frequency in the VFO Mode ............................................................25
4.5.1 Setting the Frequency.................................................................................25
4.5.2 Setting the Tuning Step ..............................................................................26
4.5.3 Shift Direction and Offset Frequency Settings...........................................27
4.6 Memory Mode ....................................................................................................28
4.6.1 How to Program Memory Channel(s) ........................................................28
4.6.2 Recalling a Memory Channel.....................................................................28
4.6.3 Deleting a Memory Channel ......................................................................28
4.6.4 Quick Program Memory Channel(s) ..........................................................29
4.6.5 Transmitter Detecting Function..................................................................29
4.6.6 Programming a Repeater-Access Function Setting....................................30
4.6.7 Programmable Parameters in Memory Channels.......................................30
5
Contents
4.7 Call-Channel Mode.............................................................................................31
4.8 Receiving ............................................................................................................31
4.8.1 Monitor Function........................................................................................32
4.9 Transmitting........................................................................................................32
4.9.1 Selecting the Output Level .........................................................................32
5.Useful Functions...........................................................................................33
5.1 Scan Modes.........................................................................................................33
5.1.1 VFO-Scan...................................................................................................33
5.1.2 Memory-Scan .............................................................................................33
5.1.3 Setting Skip Channels ................................................................................34
5.2 Keylock...............................................................................................................34
5.3 Tone-Burst ..........................................................................................................34
5.4 Naming Memory Channels.................................................................................35
5.4.1 Setting Name-Tag.......................................................................................35
5.4.2 Using the Channel Name Function ............................................................35
5.5 Lamp ...................................................................................................................35
6.Selective Calling............................................................................................36
6.1 Tone Squelch (TSQ) ...........................................................................................36
6.1.1 Setting the Tone Squelch............................................................................36
6.1.2 Switching Off the Tone Squelch ................................................................37
6.1.3 To Differentiate the ENC/EDC Tones .......................................................37
6.1.4 Tone Squelch Operation.............................................................................37
6.2 DCS ....................................................................................................................37
6.2.1 Setting the DCS..........................................................................................37
6.2.2 Changing the DCS Code ............................................................................38
6.2.3 Switching Off DCS ....................................................................................38
6.2.4 DCS Operation ...........................................................................................38
6.2.5 DET Mode in DCS Operation ....................................................................38
6.3 DTMF Tone Encoding........................................................................................39
6.4 Auto Dialer .........................................................................................................40
6.4.1 Setting the Auto Dialer...............................................................................40
6.4.2 Generating the Auto Dialer Codes .............................................................40
6.4.3 Redial (While Receiving)...........................................................................41
7.Special Functions..........................................................................................42
7.1 Repeater-Access..................................................................................................42
7.2 Program Scan......................................................................................................42
7.3 VOX....................................................................................................................43
7.4 ALERT................................................................................................................43
7.5 Battery Type Setting ...........................................................................................44
7.6 Battery Refresh ...................................................................................................44
6
Contents
8.Set Mode........................................................................................................45
8.1 Set Mode Operation ............................................................................................45
8.2 Entering the Set Mode ........................................................................................45
8.3 Available Parameters ..........................................................................................46
8.3.1 Menu 1 Battery Save (BS) Function ..........................................................46
8.3.2 Menu 2 Timer/Busy Scan Setting ..............................................................46
8.3.3 Menu 3 Beep Function ...............................................................................46
8.3.4 Menu 4 VOX delay time setting.................................................................46
8.3.5 Menu 5 Auto-Power-Off Setting................................................................47
8.3.6 Menu 6 FM / NFM Setting.........................................................................47
8.3.7 Menu 7 ATT (Attenuator) Setting..............................................................47
8.3.8 Menu 8 Clock Shift Setting........................................................................48
8.3.9 Menu 9 Busy Channel Lockout Setting .....................................................48
8.3.10 Menu 10 Tone-Burst Frequency Setting ....................................................49
8.3.11 Menu 11 Time Out Timer (TOT) Setting...................................................49
8.3.12 Menu 12 TOT Penalty Time ......................................................................49
8.3.13 Menu 13 DTMF WAIT Time.....................................................................50
8.3.14 Menu 14 DTMF First Digit Burst Time.....................................................50
8.3.15 Menu 15 DTMF Burst Time ......................................................................50
8.3.16 Menu 16 DTMF Pause Time......................................................................50
8.3.17 Menu 17 Stand-by Beep/DTMF Setting ....................................................51
8.3.18 Menu 18 Mid power ...................................................................................52
9.Cloning and Packet Operation ....................................................................53
9.1 Cloning................................................................................................................53
9.1.1 Cable Connection .......................................................................................53
9.1.2 Master/Slave Units .....................................................................................53
9.1.3 Master Unit Operation................................................................................54
9.1.4 Slave Unit Operation ..................................................................................54
9.2 Packet Operation.................................................................................................55
9.2.1 Packet Operation Connections ...................................................................55
10.Maintenance and Reference......................................................................56
10.1 Troubleshooting ..................................................................................................56
10.2 Resetting .............................................................................................................57
10.2.1 All Resetting...............................................................................................57
10.2.2 Partial Resetting .........................................................................................57
10.3 Options................................................................................................................58
10.3.1 Microphone/Speaker Cable (EDS-14)........................................................59
10.3.2 Battery Packs..............................................................................................59
10.3.3 Using the Chargers .....................................................................................60
10.3.4 Dry Cell Case .............................................................................................66
11.Specifications .............................................................................................67
7
Warning
Warning
To prevent any hazard during operation of Alincon's radio product, in this manual and
on the product you may find symbols shown below. Please read and understand the
meanings of these symbols before starting to use the product.
Alert
Environment and condition of use
The manufacturer declines any responsibilities against loss of life and/or
property due to a failure of this product when used to perform important tasks
like life-guarding, surveillance, and rescue.
a
Use of this product may be prohibited or illegal outside of your country. Be
informed in advance when you travel.
j
Never operate this product in facilities where radio products are prohibited for
use such as aboard aircraft, in airports, in ports, within or near the operating
area of business wireless stations or their relay stations.
j
In case a liquid leaks from the product, do not touch it. It may damage your
skin. Rinse with plenty of cold water if the liquid contacted your skin.
j
Keep the radio out of the reach of children.
a
Do not use this product in close proximity to other electronic devices,
especially medical ones. It may cause interference to those devices.
j
It is recommended that you check local traffic regulations regarding the use of
radio equipment while driving. Some countries prohibit or apply restrictions
for the operation of radios and mobile- phones while driving.
a
d
d
Danger
This symbol is intended to alert the user to an immediate danger that
may cause loss of life and property if the user disregards the warning.
d
Alert
This symbol is intended to alert the user to a possible hazard that
may cause loss of life and property if the user disregards the warning.
d
Caution
This symbol is intended to alert the user to a possible hazard that may
cause loss of property or injure the user if the warning is disregarded.
d
Alert symbol. An explanation is given.
a
Warning symbol. An explanation is given.
m
Instruction symbol. An explanation is given.
8
Warning
Handling this product
About chargers
About power supply
Do not plug multiple devices including the power supply into a single wall
outlet. It may result in overheating and/or fire.
j
Do not connect cables in reverse polarity. It may result in electric shock, fire
and/or malfunction.
j
Use only appropriate, reliable power supply of correct voltage and capacity.
j
Do not use the adapter if the plug or socket contacts are dirty. Overheating and/or
short-circuiting may result in fire, electric shock and/or damage to the product.
j
Securely plug the adapter into the wall outlet. Insecure installation may result
in short-circuit, electronic shock and/or fire.
a
Do not handle adapter with a wet hand. It may result in electric shock.
j
Do not plug multiple devices using an adapter into a single wall outlet. It may
result in overheating and/or fire.
j
Do not use adapters other than having the specified voltage. It may result in
electric shock, fire and/or malfunction.
j
Do not place the product in a container carrying conductive materials, such as
water or metal in close proximity to the product. A short-circuit to the product
may result in electric shock, fire and/or malfunction.
j
Do not operate this product in a wet place such as shower room. It may result
in electric shock, fire and/or malfunction.
l
Do not open the unit without permission or instruction from the manufacturer.
Unauthorized modification or repair may result in electric shock, fire and/or
malfunction.
m
Be sure to reduce the audio output level to minimum before using an earphone
or a headset. Excessive audio may damage hearing.
a
Use of third party accessory may result in damage to this product. It will void
our warranty for repair.
a
The manufacturer declines any responsibilities against loss of life and property due to
a failure of this product when used with or as a part of a device made by third parties.
a
Risk of explosion if battery is replaced with an incorrect type.
Dispose of, or recycle used batteries according to your local regulations.
a
Do not use multiple radios in very close proximity. It may cause interference
and/or damage to the product(s).
j
9
Warning
Cigar-lighter cable
In case of emergency
In case of the following situation(s), please turn off the product, switch off the source
of power, then remove or unplug the power-cord. Please contact your local dealer of
this product for service and assistance. Do not use the product until the trouble is
resolved. Do not try to troubleshoot the problem by yourself.
• When a strange sound, smoke and/or strange odor comes out of the product.
• When the product is dropped or the case is broken or cracked.
• When a liquid penetrated inside.
• When a power cord (including DC cables, AC cables and adapters) is damaged.
Maintenance
Do not open the unit and its accessories. Please consult with your local dealer
of this product for service and assistance.
m
For your safety, turn off then remove all related AC lines to the product and its
accessories from the wall outlet if a thunderstorm is likely.
a
Do not handle cigar cable with a wet hand. It may result in electric shock.
j
Do not use the cable at any other than the specified voltage. It may result in
electric shock, fire and/or malfunction.
j
Do not modify or remove fuse-assembly from the DC cable. It may result in
fire, electric shock and/or damage to the product.
j
Do not plug the power supply into the wall socket if the contacts are dirty.
Short-circuit and/or overheating may result in fire, electric shock and/or
damage to the product.
j
Securely plug the power supply to the wall outlet. Insecure installation may
result in short-circuiting, electronic shock and/or fire.
a
Do not handle a power supply with a wet hand. It may result in electric shock.
j
10
Warning
Caution
Environment and condition of use
About transceiver
About power supply
European users: When a unit is powered from an external DC power source
(adapter, power supply, cigar-plug etc.), make sure that this power supply has
approval to the level of IEC/EN 60950.
a
When using an external antenna, make sure that the antenna ground is not
common with the ground of the power supply.
a
Always turn off the power supply when connecting or disconnecting the cables.
a
Use only reliable power supply of specific DC output range and be mindful of
the polarity of the cable and DC-jack.
a
■
Use a clean, dry cloth to wipe off dirt and condensation from the surface of the
product. Never use thinner or benzene for cleaning.
a
Never pull the cord alone when you unplug AC cable form the wall outlet.
j
Turn off and remove the power source (AC cable, DC cable, battery, cigar
cable, charger adapter etc.) from the product when the product is not in use for
extended period of time or in case of maintenance.
a
Do not connect devices other than specified ones to the jacks and ports on the
product. It may result in damage to the devices.
j
Be cautious of the whip antenna when carried in your shirt-pocket etc. It may
make contact with your eye and cause injury.
a
■
Be cautious of a dew formation. Please completely dry the product before use
when it happens.
j
Do not install the product in proximity to a source of heat and humidity such as
a heater or a stove. Avoid placing the unit in direct sunlight.
j
Do not install in an unstable or vibrating position. It may result in electric
shock, fire and/or malfunction when/if the product falls to the ground.
j
Do not install in a humid, dusty or insufficiently ventilated place. It may result
in electric shock, fire and/or malfunction.
j
Do not use the product in proximity to a TV or a radio. It may cause
interference or receive interference.
j
■
d
11
Warning
Lightning
Any person is not safe outdoor during thunderstorm and lightning. This condition is
getting worse if somebody keeps a hand-held radio; chances of being hit by lightning are
doubled since lightning may hit a radio antenna as well. At this time, there is no handheld radio having any kind of protection against lightning current (which is higher than
10 kA.). Note also that no car provides adequate protection of its passengers or drivers
against lightning as well. Therefore, Alinco will not take responsibility for any danger
associated with using its hand-held radios outdoor or inside the car during lightning.
Limited Power Source
Please note that the transceiver enclosure only provides mechanical protection of its
internal parts; it will not contain a fire within the device if the fire starts under certain
fault conditions. Alinco will not take responsibility for any fire hazard associated with
powering the transceiver or charging its batteries using a power source which does not
belong to the limited power sources in the meaning of EN 60950-1. Excluded from
possible use with the transceiver are most car cigarette lighters and some DC
(AC/DC) power supplies. Make sure that the power supply used with the transceiver
is a limited power source.
Water-registant
The IPX7 designation provides for limited waterproofing of the radio. The
specifications are immersion in one meter (approx 3ft) of still sweet water for up to 30
minutes. This compatibility is factory guaranteed for a period of one year provided all
the jack covers are securely in place, any accessories connected must be genuine
Alinco water-proof accessories and the radio has not been disassembled by the
customer. The factory has tested and made the equipment compatible to IPX7
certification during engineering. However, please understand that this equipment is
NOT certified IPX7 compliant but is designed to remain operational when used in
rain, severe weather or in accidental cases of dropping it in water when used in
extreme conditions and is in no way stating that you should attempt use the radio
under water or submerge the radio for cleaning. Warranty will not cover radios that
are water / salt damage due to negligence or misuse of the product.
12
Introduction / Before transmitting
Introduction
Thank you very much for purchasing this excellent Alinco transceiver. Our products
are ranked among the finest in the world. This radio has been manufactured with state
of the art technology and it has been tested carefully at our factory. It is designed to
operate to your satisfaction for many years under normal use.
PLEASE READ THIS MANUAL COMPLETELY TO LEARN ALL THE
FUNCTIONS THE PRODUCT OFFERS. WE MADE EVERY ATTEMPT TO
WRITE THIS MANUAL TO BE AS COMPREHENSIVE AND EASY TO
UNDERSTAND AS POSSIBLE. IT IS IMPORTANT TO NOTE THAT SOME OF
THE OPERATIONS MAY BE EXPLAINED IN RELATION TO INFORMATION
IN PREVIOUS CHAPTERS. BY READING JUST ONE PART OF THE MANUAL,
YOU RISK NOT UNDERSTANDING THE COMPLETE EXPLANATION OF THE
FUNCTION.
Before transmitting
There are many business radio stations operating in proximity to the ham bands. Be
careful not to cause interference when transmitting around such radio stations. Even
when amateur radio stations adhere to radio laws, there are unexpected cases of radio
interference. When operating this product while traveling, please be very careful.
1.Features
1
13
1. Features
This transceiver has the following main features.
144/430MHz dual-band handheld transceiver
Choice of 3 power output levels (5/2/0.5W)
Quick-write memory channels
Direct frequency input through illuminated keypad
High-grade water-resistant materials compatible to IPX7 *
Rugged polycarbonate body resists dirt and dust
Great audio with large 40mm internal speaker
39 CTCSS tone squelch (encode + decode) and 104 DCS
Search-scan (programmed scanning) available on each band
Tone burst function (1000, 1450, 1750 and 2100Hz)
Two-touch repeater-setting access
Internal VOX
2-level attenuator
DTMF encode and auto-dialer
* Please read page 11 for more details.
<T - version>
• EBP-65 Ni-MH battery pack (7.2V 700mA)
• EDC-146 (AC 120V) wall charger
• Belt clip
• Hand strap
• Instruction manual
<E - version>
• EBP-63 Li-ion battery pack (7.4V 1100mA)
• EDC-159E Li-ion rapid battery charger
• Belt clip
• Hand strap
• Instruction manual
NOTE:
Accessories may differ depending on the version you have purchased.
Please contact your local dealer for details of standard accessories and the
warranty-policy.
Accessories
1.1
2.Accessories
2
14
2. Accessories
2.1.1 Antenna
Attaching the Antenna
1. Hold the antenna by its base.
2. Align the grooves at the base of the antenna with
the protrusions on the antenna connector.
3. Slide the antenna down and turn it clockwise until
it stops.
4. Confirm that the antenna is securely connected.
Removing the Antenna
Turn the antenna counter-clockwise to disconnect the antenna.
2.1.2 Hand Strap
Attach the hand strap as shown. There are two ways
to attach it.
2.1.3 Belt Clip
Attaching the Belt Clip
1. Put the belt clip on the back of the unit, and turn
the screw clockwise until it stops.
2. Confirm that the belt clip is securely attached.
* Tighten up the screw occasionally.
Removing the Belt Clip
Turn the screw counter-clockwise to remove the belt clip.
■
Belt clip
■
Hand strap
■
■
Installations
2.1
2.Accessories
2
15
2.1.4 Battery Pack
For the specifications and the charging procedures, please refer to "Battery
Packs"(page 59) and "Using the Chargers"(page 60).
Attaching the Battery Pack
Align the catches on the battery pack with the
grooves on the unit, and close the latch until it clicks.
Removing the Battery Pack
Push the latch in the direction of the arrow, and pull
out the battery pack.
■
Catch
Groove
Latch
■
2.Accessories
2
16
Caution
• Risk of explosion, generation of heat or leak of chemicals inside if the
battery is replaced by an incorrect type. Use always the recommended
types of batteries in this manual only.
• The battery pack isn't fully charged when shipped. It must be charged
before use.
• Charging should be conducted in a temperature range of 0ºC to +40ºC
(+32ºF to +104ºF).
• Don't modify, dismantle, incinerate or immerse the battery pack in the water
as this can be dangerous.
• Never short-circuit the battery pack terminals, as this can cause damage to
the equipment or lead to heating of the battery which may cause burns.
• Unnecessary prolonged charging (overcharging) can deteriorate battery
performance.
• The battery pack should be stored in a dry place where temperature is in
-10ºC to +45ºC (-14ºF to +113ºF) range. Temperatures outside this range
can cause the battery liquid to leak. Exposure to prolonged high humidity
can cause corrosion of metal components.
• Battery-packs are a consuming part. When its operating time becomes
considerably short after a normal charge, please consider that the pack is
exhausted and replace it with a new one.
• The battery pack is recyclable. Check with your local waste officials for
details on recycling options or proper disposal in your area.
• Use specified genuine chargers only to charge battery packs. Use of other
chargers may cause damage to products, you and your property.
• Li-ion battery packs can't be charged using DC-jack on the unit (Only NiMH battery packs can be charged).
• Even if you do not use the battery pack for a long time, charge it at least
once every three months to prevent deterioration.
2.Accessories
2
17
Charging the Battery Pack Using DC-Jack on the Unit
The unit can charge the EBP-65 and EBP-66 optional Ni-MH battery packs by
supplying DC power through the DC-jack on the unit using EDC-146/147/148 wall
chargers or an optional DC power supply (DC 12V~DC 16V, 1A or more: IEC/EN
60950-1 compliant) and a DC cable such as EDC-37.
1. Attach the battery pack by referring to "Battery Pack" (page 15).
2. Connect the AC adapter plug to the DC-jack on the
unit then connect the charger's adapter to the wall
outlet.
* AC adapter may look different.
3. Turn on the unit and set the battery charge
parameters. (page 44)
* "Battery Type Setting"
Select BAT-NI+.
4. After completing the settings, a flashing
appears on the display. Make sure the icon is
flashing then turn off the unit. It takes about 10
hours/30hours for EBP-65/66 respectively to
complete the charge.
AC adapter plug
AC adapter*
■
NOTE:
• Please read the general safety instructions included in the optional accessories
to correctly and safely use them.
• EDC-146/147/148 can't be used as the adapter for operation. These adapters
are for charging purposes only.
• Chargers can't perform the correct charge when the AC voltage is unstable.
• flashes even EBP-65/66 aren't attached. To avoid short-circuit, never
activate this function when the pack isn't attached to the unit.
• Li-ion battery packs can't be charged in this way.
2.Accessories
2
18
2.1.5 Prevent Short Circuiting the Battery Pack
Be extra cautious when carrying the rechargeable battery pack; short circuiting will
produce surge current possibly resulting in fire.
2.1.6 Battery-Level Icon
During the operation, a black battery icon indicates
that the battery-level is in usable range. When it
turns to empty, please charge the pack or replace the
cells with new ones.
Battery-level icon
The battery is in usable
condition.
Battery-level is low.
Replace or charge the pack.
DON'T carry with
metals of any type, e.g.
chains.
DON'T carry the battery
pack inside bags made
of conductive materials.
DON'T place in the
proximity of metals or
conductives, e.g. nails,
chains.
Do enclose inside a non-conductive enclosure. (bags or
handkerchief made only of non-conductive material)
Do protect by spreading
a non-conductive sheet
on a flat surface.
3.Names and Operations of Parts
3
19
3. Names and Operations of Parts
Top and Front
Dial
Microphone/Spe
aker jack
TX/RX lamp
Speaker
Power key
Microphone
Display (LCD)
Keypad
Rotate the dial to select the frequency of operation, memory
channel, offset frequency, tone frequency, DCS code, Set mode
settings, and the characters for name-tags. Rotating the dial
while pressing the FUNC key increases or decreases the
frequency in 1MHz order.
For an optional speaker/Mic connection. Securely close the
cover for water-proof while the accessory isn't in use.
Lights green when the squelch is unmuted. Lights red during
transmission.
A speaker is built in.
Press the power key down for approximately one second to turn
on/off the unit.
Speak into the microphone from a distance of about 5cm (2").
Refer to "Display" (page 22).
Refer to "Keypad" (page 21).
■
Names and Operations of Keys and Ports
3.1
3.Names and Operations of Parts
3
20
Side
SMA Antenna
Connector
FUNC key
PTT key
MONI key
DC-IN jack
Attach the whip antenna. If you plan to use an optional antenna,
select one that is tuned to the operating frequency.
The FUNC key is used in combination with the other keys to
access the various functions of the unit. To enter the Set mode
to set operating parameters, press the FUNC key continuously
for about 2 seconds.
Press the PTT key to transmit, release to receive.
When the MONI key is pressed, the squelch unmutes regardless
of the TSQ/DCS setting. Pressing the MONI key after pressing
the FUNC key illuminates display for about 5 seconds. Pressing
the MONI key while pressing the PTT key transmits a tone-burst
signal.
Connect an external power source of DC 7.0V~DC 16.0V at 2A
or more. An optional EDC-36 cigar-cable is available for mobile
operation. EBP-65/66 packs can be charged using this jack
(page 17).
Antenna side Dial side
■
3.Names and Operations of Parts
3
21
key
Without pressing the FUNC key.
Inputs 1.
Inputs 2.
Inputs 3.
Inputs 4.
Inputs 5.
Inputs 6.
Inputs 7.
Inputs 8.
Inputs 9.
Inputs 0.
Batttery type setting (page 44)
Reverse operation (page 27, 42)
Switches between the VFO and
Memory mode (page 24).
Start/Stop scanning (page 33).
Access the Call channel (page 31).
Switches between the VHF and UHF
(page 24).
Quick-write memory (page 29)
SQL adjustment (page 23).
Audio level adjustment (page 23).
While appears after the FUNC key is pressed.
Channel step setting (page 26).
Offset frequency setting (page 27).
Alert Function (page 43).
Tone Encode / Tone Squelch setting
(page 36).
Hi/Mid/Low power setting (page 32).
VOX setting (page 43).
DCS (digital code squelch) setting (page 37).
Auto dialer operation (page 40).
Auto dialer memory setting (page 40).
Repeater-Access function setting (page 42).
Memory programming (page 28).
Key / Frequency lock setting (page 34).
Memory channel skip setting (page 34).
Naming memory channels setting (page 35).
N/A
N/A
* The numeric keys can be used for direct VFO frequency input within the product's
operating range. DTMF tones are generated by pressing the keys during transmissions.
Keypad
3.2
3.Names and Operations of Parts
3
22
/
Appears when the FUNC key is pressed.
Indicates the shift (+/-) direction.
Appears when setting the CTCSS tone encoder.
Appears when setting the tone squelch.
Appears when setting the VOX.
Appears when setting the DCS.
Appears when setting the NFM.
Displays the frequency and scan operation.
Displayed when the frequency or the keypad is locked.
Appears when the Repeater-Access function is activated.
Appears when Auto-Power-Off function is activated.
Indicates battery-level. The black icon flashes when the battery
charge function is on.
Displayed when in the Memory mode.
Displays the memory channel No.
Displayed when the transmission output is in LOW setting.
Displayed when the transmission output is in MID setting.
Displays the operating frequencies, name-tags and parameters
in the setting mode.
Appears when the attenuator is activated.
Appears when setting the channel skip.
Appears when the squelch is unmuted.
Indicates the receiving signal (S-meter) and transmission output
levels (Power-meter).
Display (LCD)
3.3
Loading...
