Alinco DJ-V47 E, DJ-V47 T, DJ-V47, DJ-V17 R, DJ-V17 TFH Service Manual

DJ-V17 T/E/TFH/R
DJ- V47 T/E/T1/T2

Service Manual

CONTENTS

SPECIFICATIONS (DJ-V17)

General (DJ-V17)......................................................2

Transmitter (DJ-V17)

Receiver (DJ-V17)....................................................2

General (DJ-V47)......................................................3

Transmitter (DJ-V47)...............................................3

Receiver (DJ-V47)....................................................3

CIRCUIT DESCRIPTION

1) Receiver System...................................................4

2) Transmitter System.............................................6

3) PLL Synthesizer Circuit...................................6,7

4) CPU & Peripheral Ciruits.................................7,8

5) M38268MCA-077GP(XA1121)

SEMICONDUCTOR DATA

1) NMJ2070MT1 (XA0210)

2) S24CS64A01-J8T1 G(XA1117)........................11

3) M62429FP/CF0J(XA1118)

4) LM2902PWR(XA1106)

5) TA31136FN (E L) (XA0404)

6) S80845CLNB-B66-T2G(XA1120)

7) MB15E07SR(XA1107)

8) XC6202P502MR(XA1119)

9) Transistor, Diode and LED Outline Drawing.....16

10) LCD Connection(EL0059)

EXPLODED VIEW

1) Front View.

2) Rear View........................................................... 18

..........................................................17

...............................................2

...................

....................................11

..............................

.....................................

...............................

...................

......................................

..............................

............................

8-10

12
12
13
13
14
15

16

PARTS LIST

MAIN Unit (DJ-V17)
Mechanical Unit (DJ-V17)

Packing Unit (DJ-V17)...........................................25

MAIN Unit (DJ-V47)
Mechanical Unit (DJ-V47)

Packing Unit (DJ-V47)...........................................32

ADJUSTMENT

1) Required Test Equipment .........................33,34

2) Preparation.........................................................34

3) Adjustment Mode

4) Re-assembly.......................................................42

PC BOARD VIEW

MAIN SIDE A(DJ-V17)..........................................43

MAIN SIDE B (DJ-V17)..........................................44

MAIN SIDE A (DJ-V47)..........................................45

MAIN SIDE B (DJ-V47)..........................................46

SCHEMATIC DIAGRAM (DJ-V17)

SCHEMATIC DIAGRAM (DJ-V47)

BLOCK DIAGRAM (DJ-V17)

BLOCK DIAGRAM (DJ-V47)

........................................

...............................

........................................

.....................................32

........................................

............

............

......................

......................

19-24

24,25

26-32

35-42

47

48

49

50

A L IN C O , in c

SPECIFICATIONS (DJ-V17)

General

Frequency range: T: TX144~147.995MHz

RX130-1 73.995MHz

E/EUK:TX144~145.995MHz

RX144-145.995MHZ

TFH/R: TX136-173.995MHz

RX130-1 73.995MHz

* Guaranteed range

*144-147.995MHz
*144~147.995MHz
*144~145.995MHz
*144~145.995MHz
*150-173.995MHz
*150-173.995MHz

Modulation:
Frequency step:
Memory channel:

Ant. impedance:

Frequency stability:
Mic impedance:

Supply voltage:
Current consumption:

Temperature range:

Ground:

Dimension:

Weight:

DTMF:

Sub audible Tone (CTCSS):
Sub audible Tone (CTS):

F3E (FM)
5, 10, 12.5, 15, 20, 25, 30kHz step
200 channels + 1 call channel + 1 Repeater-Access function memory
50 Q unbalanced
±5ppm
2k Q
DC 7.0-16.0V (EXT DC-IN)

1.4A (typical) Transmit high at 5W
250mA (typical) Receive at 500mW
70mA (typical) Standby
25mA (typical) Battery save on
External DC: -10°C~+60°C (+14°F~+140°F)
Battery packs: -10°C~+45°C (+14°F~+113°F)
Negative ground
58(W )x 110(H) x36.4(D)mm
(2.28"(W) x 4.33"(H) x 1,43"(D))
(with EBP-65)
Approx. 280g (9.9oz)
(with EBP-65)
16 Buttons Keypad
encoder/decoder installed (39 tones)
encoder/decoder installed (104codes)

Transmitter

Power output:

Modulation:

Spurious emission:

Max. deviation:
Mic. impedance:

Receiver

System:
Sensitivity:

Intermediate frequency:

Selectivity:

AF output:

2

Approx. 5W (with EBP-65)
Approx. 5W (with DC 13.8V)
Approx. 0.8W (LOW output)
Variable reactance

-60dB or less
±5kHz
2k Q

Double-conversion super heterodyne

-14.0dB/z(0.2/zV)or less

1st IF 21.7MHz 2nd IF 450kHz

-6dB: 12kHz or more

-60dB: 26kHz or less
500mW (MAX)
400mW (8 Q, 10% distortion)

SPECIFICATIONS (DJ-V47)

General

Frequency range:

T: TX420~449.995MHz *420~449.995MHz

RX400~479.995MHz *420~449.995MHz

E: TX430~439.995MHz *430~439.995MHz

RX430~439.995MHz *430~439.995MHz

T1 : TX400~459.995MHz *400~429.995MHz

RX400~459.995MHz *400~429.995MHz

T2: TX440~479.995MHz *450~469.995MHz

RX440~479.995MHz *450~469.995MHz

* Guaranteed range

Modulation:
Frequency step:
Memory channel:

Ant. impedance:

Frequency stability:
Mic impedance:

Supply voltage:
Current consumption:

Temperature range:

Ground:

Dimension:

Weight:

DTMF:

Sub audible Tone (CTCSS):
Sub audible Tone (CTS):

F3E (FM)
5, 10, 12.5, 15, 20, 25, 30kHz step
200 channels + 1 call channel + 1 Repeater-Access function memory
50 Q unbalanced
±2.5ppm
2k Q

DC 7.0-16.0V (EXT DC-IN)

1,7A (typical) Transmit high at 5W
250mA (typical) Receive at 500mW
80mA (typical) Standby
27mA (typical) Battery save on

External DC: -10°C~+60°C (+14°F~+140°F)

Battery packs: -10°C~+45°C (+14°F~+113°F)

Negative ground
58(W )x 110(H) x36.4(D)mm

(2.28"(W) x 4.33"(H) x 1.43"(D))

(with EBP-65)
Approx. 280g (9.9oz)

(with EBP-65)

16 Buttons Keypad
encoder/decoder installed (39 tones)
encoder/decoder installed (104codes)

Transmitter

Power output:

Modulation:

Spurious emission:

Max deviation:
Mic. impedance:

Receiver

System:
Sensitivity:

Intermediate frequency:

Selectivity:

AF output:

Approx. 4.5W (with EBP-65)
Approx. 5W (with DC 13.8V)
Approx. 0.8W (LOW output)
Variable reactance

-60dB or less
±5kHz
2k Q

Double-conversion super heterodyne

-12.0dB /i (0.25 /i V)or less

1st IF 38.85MHz 2nd IF 450kHz

-6dB: 12kHz or more

-60dB: 26kHz or less
500mW (MAX)
400mW (8 Q, 10% distortion)

3

CIRCUIT DESCRIPTION

1) Receiver System

DJ-V17 :The receiver system is a double superheterodyne system with a 21.7 MHz first IF and a 450 kHz

second IF.

DJ-V47 The receiver system is a double superheterodyne system with a 38.85 MHz first IF and a 450 kHz

second IF.

1. Front End
DJ-V17 The received signal at any frequency in the 130.000- to 173.995-MHz

(E version : 144.000- to 145.995-MHz) range is passed through the
low-pass filter (L101, L102, L103, L113, C108, C120, C121, C124,
C125, C126, C127 and C176) and ATT (Attenuator) circuit (Q120,
R161, R187 and D112), and tuning circuit (C192, C193, C215, C216,
D115, D116, L125 and L126), then amplified by the RF amplifier
(Q114). The signal from Q114 is then passed through the tuning
circuit (C200, C201, C219, C220, D117, D118, L128 and L129) and

converted into 21.7 MHz by the mixer (Q116). The tuning circuit,
which consists of C192, C193, C215, C216, L125, L126, variable
capacitance diodes D115 and D116 and C200, C201, C219, C220,

L128, L129, variable capacitance diodes D117 and D118, is
controlled by the tracking voltage from the CPU so that it is optimized
for the reception frequency. The local signal from the VCO is passed
through the buffer (Q113), and supplied to the source of the mixer

(Q116). The radio uses the lower side of the superheterodyne
system.

DJ-V47 The received signal at any frequency in the covering range (T version

: 400.000- to 479.995-MHz, E version : 430.000- to 439.995-MHz, T1
version : 400.000- to 459.995MHz, T2 version : 440.000- to

479.995MHz) is passed through the low-pass filter (L101, L102,

L103, L113, C108, C120, C121, C124, C125, C126, C127 and C176)
and ATT (Attenuator) circuit (Q120, R161, R187 and D112), and
tuning circuit (C192, C193, C215, C216, D115, D116, L125 and

L126), then amplified by the RF amplifier (Q114). The signal from
Q114 is then passed through the tuning circuit (C200, C201, C219,
C220, D117, D118, L128 and L129) and converted into 38.85 MHz

by the mixer (Q116). The tuning circuit, which consists of C192,
C193, C215, C216, L125, L126, variable capacitance diodes D115
and D116 and C200, C201, C219, C220, L128, L129, variable
capacitance diodes D117 and D118, is controlled by the tracking
voltage from the CPU so that it is optimized for the reception
frequency. The local signal from the VCO is passed through the buffer

(Q113), and supplied to the source of the mixer (Q116). The T1/T2
versions use the lower side of the superheterodyne system while TIE
versions switshes the lower and upper system at 420.000MHz; the

lower side foe the frequency up to 419.995MHz and upper side for

420.000MHz and up.

4

2. ATT (Attenuator) Circuit

3. IF Circuit

DJ-V17 The mixer(Q116) mixes the received signal with the local signal to

This circuit is used in case the receiving signal is disturbed by

interfering signal(s), attenuating the receiving signal(s) to reduce the

interference. CPU (IC109)’s pin 10 outputs a DC current to drive
Q120, controlling D112’s resistance to adjust the attenuation value.

obtain the sum of and difference between them. The crystal filter
(FL101 , FL102) selects 21.7 MHz frequency from the results and
eliminates the signals of the unwanted frequencies. The first IF
amplifier (Q119) then amplifies the signal of the selected frequency.
After the signal is amplified by the first IF amplifier (Q119), it is input
to pin 16 of the demodulator IC (IC103). The second local signal of

21.25 MHz (shared with PLL IC reference oscillation), which is
oscillated by the internal oscillation circuit in IC103 and crystal
(X101), is input through pin 1 of IC103. Then these two signals are

mixed by the internal mixer in IC103 and the result is converted into
the second IF signal with a frequency of 450kHz. The second IF
signal is output from pin 3 of IC103 tothe ceramic filter (FL103),
where the unwanted frequency band of that signal is eliminated, and
the resulting signal is sent back to the IC103 through 5 pins.

4. Demodulator Circuit

5. Audio Circuit

DJ-V47 The mixer(Q116) mixes the received signal with the local signal to

obtain the sum of and difference between them. The crystal filter

(FL101) selects 38.85 MHz frequency from the results and eliminates
the signals of the unwanted frequencies. The first IF amplifier (Q119)
then amplifies the signal of the selected frequency. After the signal is
amplified by the first IF amplifier (Q119), it is input to pin 16 of the
demodulator IC (IC103). The second local signal of 38.4 MHz, which

is oscillated by the internal oscillation circuit in IC103 and output of
tripler circuit (L123, C202, C191, L122, Q115), is input through pin 1
of IC103. Then these two signals are mixed by the internal mixer in

IC103 and the result is converted into the second IF signal with a
frequency of 450kHz. The second IF signal is output from pin 3 of

IC103 tothe ceramic filter (FL103), where the unwanted frequency

band of that signal is eliminated, and the resulting signal is sent back
to the IC103 through 5 pins.

The second IF signal input via pin 5 is demodulated by the internal

limiter amplifier and Quadrature detection circuit in IC103, and output
as an audio signal through pin 9.

The audio signal from pin 9 of IC103 is compensated to the audio
frequency characteristics in the de-emphasis circuit (R223, R224,
C241, C242) and amplified by the AF amplifier (Q196). The signal is
then input to pin 1 of the electronic volume (IC107) for volume
adjustment, and output from pin 2. The adjusted signal is sent to the
audio power amplifier (IC106) through pin 2 to drive the speaker.

5

6. Squelch Circuit

2) Transmitter System

1. Modulator Circuit

2. Power Amplifier Circuit

3. APC Circuit

Part of the audio signal from pin 9 of IC103 is amplified by the noise
filter amplifier and the internal noise amplifier in IC103. The desired

noise of the signal is output through pin 14 of IC103 and input to pin
2 of CPU (IC109).

The audio signal is converted to an electric signal in either the

internal or external microphone, and input to the microphone

amplifier (IC102).

IC102 consists of four operational amplifiers; 1st amplifier (pins 1, 2,

and 3) is composed of high-pass filter, 2nd amplifier (pins 12, 13, and

14) is composed of pre-emphasis and IDC circuits, 3rd amplifier (pins
8, 9, and 10) is composed of a splatter filter and 4th amplifier (pins 7,
6, and 5) is composed of a splatter filter. The maximum frequency
deviation is determined to its optimal value by VR104 and input to the
cathode of the variable capacitance diode of the VCO, to change the
electric capacity in the oscillation circuit.

The transmitted signal is oscillated by the VCO, amplified by the pre

drive amplifier (Q104) and drive amplifier (Q103), and input to the
power amplifier (Q102). The signal is then amplified by the power
amplifier (Q102) and led to the antenna switch (D101 and D103) and
low-pass filter (L104, L103, L102, L101, C107, C108, C109, C110,
C111, C120, C121, C124, C125, C126, and C127 ), where unwanted
high harmonic signals are reduced as needed, and the resulting

signal is supplied to the antenna.

Part of the transmission power from the low-pass filter is detected by
D105, converted to DC, and then amplified by a differential amplifier
( Q111 ). The output voltage controls the bias voltage from the gate of
Q102 and Q103 to maintain the transmission power constant.

3) PLL Synthesizer Circuit

1 .CPU control

2. Reference Frequency Circuit

DJ-V17 The reference frequency appropriate for the channel steps is obtained

The dividing ratio is obtained by sending data from the CPU (IC109)
to pin 10, and sending clock pulses to pin 9 of the PLL IC (IC101).
The oscillated signal from the VCO is amplified by the buffer (Q118),
then input to pin 8 of IC101. Each programmable divider in IC101

divides the frequency of the input signal by N-value according to the

frequency data, to generate a comparison frequency of 5 or 6.25

kHz.

by dividing the 21.25MHz reference oscillation (X101) by 4250 or
3400, according to the data from the CPU (IC109). When the
resulting frequency is 5 kHz, channel steps of 5, 10, 15, 20, and 30
kHz are used. When it is 6.25 kHz, steps of 12.5, 25, and 50 kHz are
used.

DJ-V47 :The reference frequency appropriate for the channel steps is obtained

3. Phase Comparator Circuit

4. PLL Loop Fitter Circuit

5. VCO Circuit

DJ-V17 :A Colpitts oscillation circuit driven by Q108 directly oscillates the

by dividing the 12.8MHz reference oscillation (X102) by 2048 or

2560, according to the data from the CPU (IC109). When the

resulting frequency is 5 kHz, channel steps of 5, 10, 15, 20, and 30
kHz are used. When it is 6.25 kHz, steps of 12.5, 25, and 50 kHz are
used.

The PLL (IC101) uses the reference frequency, 5 or 6.25 kHz. The

phase comparator in the IC101 compares the phase of the frequency

from the VCO with that of the comparison frequency, 5 or 6.25 kHz,
which is obtained by the internal divider in IC101.

If a phase difference is found in the phase comparison between the
reference frequency and VCO output frequency, the charge pump

output (pin 5) of IC101 generates a pulse signal, which is converted
to DC voltage by the PLL loop filter and input to the variable
capacitance diode of the VCO unit for oscillation frequency control.

desired frequency. The frequency control voltage determined in the
CPU (IC109) and PLL circuit is input to the variable capacitance
diodes (D107 and D109). This changes the oscillation frequency,
which is amplified by the VCO buffer (Q110) and output from the VCO

unit.

DJ-V47 :A Colpitts oscillation circuit driven by Q108 directly oscillates the

desired frequency. The frequency control voltage determined in the
CPU (IC109) and PLL circuit is input to the variable capacitance
diodes (D109 and D110). This changes the oscillation frequency,
which is amplified by the VCO buffer (Q110) and output from the VCO

unit.

4) CPU and Peripheral Circuits

1. LCD Display Circuit

The CPU turns ON the LCD via segment and common terminals with

1/3 the duty and 1/3

the bias, at the frame frequency of 112.5Hz.

2. Display Lamp Circuit

When the LAMP key is pressed, "L" is output from pin 42 of CPU

(IC109) to the bases of Q152 then turns to ON and "H" is output from

emitter of Q152 to the bases of Q146 to light LEDs (D131, D132).

3. Reset and Backup Circuits

TWhen the Output Voltage from pin 3 of IC110 drops to 4.5 V or

below, the output signal from the reset IC (IC104), which has been
input to pin 33 of the CPU (IC109), changes from "H" to "L" level. The

CPU will then be in the backup state.

4. S(Signal)Meter Circuit

The DC potential of pin 12 of IC103 is input to pin 1 of the CPU

(IC109), converted from an analog to a digital signal, and displayed

as the S-meter signal on the LCD.

7

5. Tone Encoder

6. DCS Encoder

7. CTCSS, DCS Decoder

8.Clock Shift

The CPU (IC109) is equipped with an internal tone encoder. The tone
signal (67.0 to 250.3Hz) is output from pin 9 of the CPU to the
variable capacitance diode of the VCO and 21.25MHz reference
oscillation (X101) of the PLL IC (IC101) for modulation.

DJ-V17 :The CPU (IC109) is equipped with an internal DCS code encoder.

The DCS code ( 023 to 754 ) is output from pin 7 of the CPU to 21.25

MHz reference oscillation (X101) of the PLL IC (IC101) for
modulation.

DJ-V47 :The CPU (IC109) is equipped with an internal DCS code encoder.

The DCS code ( 023 to 754 ) is output from pin 7 of the CPU to 12.8

MHz reference oscillation (X102) of the PLL IC (IC101) for
modulation.

The AF signal from the pin 9 of IC103 is filtered by an active filter

(IC108) to eliminate the voice range of the signal then amplified and
input to the pin 4 of the CPU (IC109). The signal is compared in the

CPU with the pre-selected CTCSS and DCS values and the squelch
opens in case the value matches.

In case the selected frequency is disturbed by a CPU clock-noise, it
may be eliminated by changing the CPU clock frequency. When the

clock-shift is set, the pin 31 of the CPU (IC109) becomes Low turning
ON the Q124. When Q124 becomes ON, X104’s oscillation frequency
shifts approximately by 200ppm.

5) M38268MCA-077GP ( XA1121 )

CPU
Terminal Connection
(TOP VIEW )

SEGa — 180
SEG z - « — [8 1
SEG6

------
SEG s — [W
SEG4 — 184
SE G 3 — [jjjF
SE G 2 — 186
S E G i — [87
SEGo — 188

Vcc [89

VREF

----

AVss — ►- [9T

COM 3 — [92

COMi — [94

182

►- [90

35~1

----

►- XCOUT

34]

-----

XciN

33] — RESET
32] — P7o/INTo

8

No. Terminal Signal I/O

Description

1 P67/AN7 SMT I S-meter input

2

P66/AN6
3 P65/AN5
4 P64/AN4 TIN I
5 P63/SCLK22/AN3

P62/SCLK21/AN2 BP2 I Band plan 2

6
7 P61/SOUT2/AN1 DCSW
8 P60/SIN2/AN0

P57/ADT/DA2 CTOUT

9

10

P56/DA1 DTOUT

11 P55/CNTR1 SCL
12
13
14

P54/CNTR0

P53/RTP1 BP4 I Band plan 4
P52/RTP0

15 P51/PWM3

SQL I

Noise level input for squelch

BAT I Low battery detection input

CTCSS tone input / DCS code input

BP1 I Band plan 1

O DCS signal mute

FKEY I Function / Monitor Key input

O CTCSS tone output / DCS tone output
O DTMF output

Serial clock for EEPROM

O

TBST

MUTE
CLK

I/O Tone burst output

I/O Microphone mute / Bank change input while trunking

Serial clock output for PLL, and trunking board

0

Serial data output for PLL, CTCSS / PLL unlock signal input /

16 P50/PWM0

DATA

I/O

EVR control output
Trunking board detection ( when the unit is turned ON ) /

17 P47/SROY1 TRST
18

19
20
21

P46/SCLK1 STBP

P45/TXD UTX
P44/RXD URX I UART data reception input

P43/<DTOUT

BEEP
22 P42/INT2 RE2 I
23

P41/INT1 RE1 I

I/O

Strobe signal to trunking board

0 Strobe for PLL IC

UART data transmission output

0

I/O Beep tone/Band plan 3 ( when the unit is turned on )

Rotary encoder input

24 P40 CLO 0 CLONE ON/OFF output
25
26 P76 CHG

P77 PTTK I

PTT input

I Battery charge ON/OFF output
27 P75 P5C 0 PLL power ON/OFF output
28 P74 T5C 0 TX power ON/OFF output
29 P73 R5C 0
30

P72 AFP

RX power ON/OFF output

AF AMP power ON/OFF output

0
31 P71 CLSFT 0 CLOCK frequency shift
32 P70/INTO BU I Backup signal detection input
33 RESET RESET I Reset input
34 Xcin
35 Xcout
36 Xin XIN
37 Xout XOUT
38 Vss GND

- -

- -

-

Main clock input

-

Main clock output

-

CPU GND
39 P27 PSW I Power switch input
40 P26 SDA 0 Serial data for EEPROM
41 P25 C5C 0 C5V power ON/OFF output
42 P24 LAMP 0 Lamp ON/OFF
43 P23 KI0 I
44 P22 KI1 I
45 P21 KI2 I

Key matrix input
46 P20 KI3 I

47 P17 K03 0
48 P16 K02 0
49 P15/SEG39 KOI 0

Key matrix output
50 P14/SEG38 KOO 0

51 P13/SEG37 DA3 0 DA converter for Tx output power
52 P12/SEG36 DA2 0 DA converter for Tx output power
53 P11/SEG35 DA1 0 DA converter for Tx output power
54 P10/SEG34 AFC/DA0 0 DA converter for Tx output power

Trunking TXDT control / Voice Scrambler Board detection

55 P07/SEG33 EXP I/O

(when the unit is turned on )
56 P06/SEG32 SD/PO 0 Signal detection output / Tx power Hight or Low

9

No. Terminal Signal I/O

57

P05/SEG31 SEG31 0

Description

58 P04/SEG30 SEG30 0
59 P03/SEG29 SEG29 0
60 P02/SEG28 SEG28 0
61
62

P01/SEG27 SEG27
P00/SEG26 SEG26 0

0

63 P37/SEG25 SEG25 0
64 P36/SEG24 SEG24

0
65 P35/SEG23 SEG23 0
66
67 P33/SEG21 SEG21

P34/SEG22 SEG22

0

0
68 P32/SEG20 SEG20 0
69 P31/SEG19 SEG19 0
70 P30/SEG18 SEG18 0
71 SEG17 SEG17
72

SEG16 SEG16 0
73 SEG15 SEG15 0
74 SEG14 SEG14

0

LCD segment signal

0
75 SEG13 SEG13 0
76
77

SEG12 SEG12
SEG11 SEG11 0

0

78 SEG10 SEG10 0
79 SEG9 SEG9 0
80 SEG8 SEG8 0
81
82

SEG7 SEG7
SEG6 SEG6 0

0

83 SEG5 SEG5 0
84 SEG4 SEG4

0
85 SEG3 SEG3 0
86
87

SEG2 SEG2
SEG1 SEG1 0

0

88 SEGO SEGO 0
89 Vcc

VDD
90 Vref Vref
91 Avss Avss
92
93

COM3 COM3 0 LCD COM3 output
COM2 COM2

94 COM1 COM1

-

CPU power terminal

-

AD converter power supply

-

AD converter GND

LCD COM2 output

0

LCD COM1 output

0
95 COMO COMO 0 LCD COMO output
96 VL3 VL3
97 VL2 VL2
98

C2 C2

99 C1 C1

-

LCD power supply

-

- -

- -

100 VL1 VL1 I LCD power supply

1 0

SEMICONDUCTOR DATA

1) NMJ2070MT1 ( XA0210 )

Low Voltage Power Amplifier
Equivalent Circuit

Parameter Condition Symbol Min. Typ.

Supply voltage
Idle current RL=
Output voltage Vo
Input bias current IB

Output power

Distortion
Voltage gain
Input impedance

Equivalent input noise
voltage

Power supply voltage
rejection ratio

Power gain band width
(—3dB)

THD=10%, f=1kHz

THD=10%, f=1kHz

Po=0.4W, RL=4 , f=1kHz
f=1kHz
f=1kHz

Rs=10k

f= 100Hz, Cx=100/<F SVR 24 30

RL=8 , Po=250mW P.B

V+=6V, RL=4
V+=4.5V, RL=4
V+=3V, RL=4
V+=2V, RL=4
V+=6V, RL=4
V+=4.5V, RL=4

A curve

B=22Hz to 22kHz Vn2

v+

IQ

Po

THD -

Av

ZlN

Vn1

1.8

-

2.7

-

200

-

0.5 0.6

0.32

-

120

-

-
500

-
250

-

0.25

41 44

100

-

2.5

-

200

-

30

Max.

-

4

-

3

15

7

-

-

-

-

-

-

-

-

- %

47

-

-

-

-

-

Unit

V

mA

V

nA

W

W
mW
mW
mW
mW

dB

k

M V

M V

dB

kHz

2) S24CS64A01-J8T1G ( XA1117 )

16K bits CMOS Serial EEPROM

Pin

AO Œ
A1 Œ
A2 Œ

GND Œ

1o

8
2 7
3 6

4 5

ZD VCC
ZD WP

=□ SCL
ZD SDA

Number

Remark See Dimensions for details of the package drawings.

Pin

Name

1
2 A1
3 A2 Slave address input
4 GND Groudd
5
6 SCL Serial clock input

7 WP

8

A0 Slave address input

Slave address Input

SDA Serial data input / output

Write protection input

Connected to Vcc: Protection valid
Connected to GND: Protection invalid

VCC

Power supply

Function

1 1

3) M62429FP/CF0J ( XA1118 )

Electronic Volume

Vin1 [T 3

V outI [2

GND[3

DATA [4

0>

ro

IV

(0

3

T1
"0

I T] Vin2

7 ] V out2
1 ] V cc1

5] CLOCK

V in2 V oltt2 Vcc

CLOCK

—® ------

LOGIC

CONTROL

4) LM2902PWR ( XA1106 )

Quad Operational Amplifiers

14 13 12 11 10 9 8

L2902

* * *

* ** *

O

1 2 3 4 5 6 7

DATA

1. Output A

2. Inverting Input A

3. Non-inverting Input A

4. Vcc

5. Non-inverting Input B

5. Inverting Input B

7. Output B

8. Output C

9. Inverting Input C

10. Non-inverting Input C

11.GND

12. Non-inverting Input D

13. Inverting Input D

14. Output D

1 2

5) TA31136FN(EL) ( XA0404 )

Low Power FM IC

16 15 14 13 12 11 10 9

31136

* **

o

1 2 3 4 5 6 7 8

1.0S C IN

2. OSC OUT

3. MIX OUT

4. Vcc

5. IF IN

6. DEC

7. FIL OUT

8. FILIN

9. AF OUT

10. QUAD

11. IF OUT

12. RSSI

13. N-DET

14. N-REC

15.GND

16. MIC IN

6) S80845CLNB-B66-T2G ( XA1120 )

C-MOS Voltage Detector

4 3

e

__

1 2

a

Pin No.

1 OUT Voltage detection output pin
2 VDD
3 NC*1

4 VSS GND pin

*1. The NC pin is electrically open.

The NC pin can be connected to VDD or VSS.

Pin name

Pin description

Voltage input pin

No connection

1 3

7) MB15E07SR ( XA1107 )

PLL Synthesizer

OSC IN

PS

LE

Data

Clock

16 15 14 13 12 11 10 9

E07SR

* ** *

* **

o

1 2 3 4 5 6 7 8

Reference

Oscillator

Intermittent

mode control
(power save)

1-bit

control latch

reference counter

Binary 14-bit

14-blt latch

19-bit shift register

7-bit latch 14-bit latch

Blnaly 7-blt

swallow
counter

1.0S C IN

2. N.C.

3. Vp

4. Vcc

5. Do

6. GND

7. Xfin

8. fin

SW

FC LDS CS

4-bit latch

Blnaly 11-blt

programmable

counter

9. CLOCK

10. Data

11.LE

12. PS

13. N.C.

14. LD/fout

15. N.C.

16. N.C.

Phase

comparator

Lock

detector

LD/fr/fp

selector

Charge pump

LD/fout

Vp

Xfin

fin

VC C

GND

Prescaler

32/33
64/65

SW

Parameter Symbol Condition Min. Typ. Max. Unit

Power supply voltage Vcc

Power supply current

LPF supply voltage

Icc

Vp

Local oscillator input level Vfin

Local oscillator input frequency

fin -

2500M Hz

Vcc=Vp=3.75V

100MH z to 300M Hz

300M Hz to 2500M Hz

Xin input level Vxin -
Xin input frequency Fxin

Do

(Vcc=2.7 to 5.0V, Ta=-40°C to +85oC)

-

-

-

2.7

3.75 5.0

8.0

Vcc

-6

-15

-

5.5
+2
+2

100 2500

0.5

Vcc

3 40

V

mA

V

dBm

MHz
Vp-p
MHz

14

8) XC6202P502MR ( XA1119 )

Voltage Regulator

Pin No.

1
2 VIN Supply Voltage Input
3

Pin name

VOU T Regulated Voltage Output

VSS Ground

1 2

Absolute Maximum Ratings

Parameter Symbol Rating Units

Input Voltage VIN 22 V

Output Current

Output Voltage

Power Dissipation Pd

Operating Ambient Temperature Topr -40~+85 °C

Storage Temperature Tstg -5 5-+ 1 25 °C

IOUT

VOU T

500 mA

VS S -0.3-V IN+0 .3

150

Function

V

mW

15

9) Transistor, Diode and LED outline Drawings

Top View

10) LCD Connection ( EL0059 )

is iiiiiiiiiisssssssssssssL

iwwwwwwcowcowcowcowcowwotwwcowcowcowwwmww

SEGMENT COMMON

16

________

EXPLODED VIEW

1) Front View

To the speaker

MPCL07AA

AF0003

MACL07AA

AF0030

AF0003

MAIN PCB

NK0081

SP0013

FG0423

FG0419

FG0392

ADRV17/ \
(Parts shown such as rotary

encoder and SMA connector
are included)

17

2) Rear View

AF0018

PR0478

DS0446

PR0447

PR0452

FP0254

FG0424

AP0039

FP0264

AX0004Z

ADRV17

DP0181

FG0418

TL0033

DG0046

MPCL07AA

EL0059

ST0089

UJ0060

UJ0061

To the
MAIN PCB

MACL07AA

YX0039

MAIN PCB

ADFV17

(Parts shown such as speaker
and rubber parts are included)

18

PARTS LIST<DJ-V17>

MAIN Unit

Ref.

Parts No. Description Parts Name Version

No.
C101 CU3035 Chip C C1608JB1H102KT-AS
C102 CU3035 Chip C C1608JB1H102KT-AS
C103 CU3023 Chip C C1608CH1H101JT-AS
C104 CU3513 Chip C GRP1552C1H150JZ01E

CU3523

C105

CU3503 Chip C GRP1554C1H2ROCZ01E

C106
C107 CU3013 Chip C C1608CH1H150JT-AS

CU3014 Chip C C1608CH1H180JT-AS

C108
C109 CU3016
C109 CU3018 Chip C

CU3017

C110

CU3019

cm

C112 CU3015 Chip C C1608CH1H220JT-AS
C113 CU3015 Chip C C1608CH1H220JT-AS
C114 CU3018 Chip C C1608CH1H390JT-AS TFH, R
C114 CU3019 Chip C C1608CH1H470JT-AS T, E, EUK
C115 CU3516 Chip C GRP1552C1H270JZ01E

CU3535

C116
C117 CU3517 Chip C GRP1552C1H330JZ01E

CU3502

C118

CU3502

C119
C120 CU3012 Chip C C1608CH1H120JT-AS

CU3005

C121

CU3547

C122

CU3517

C123
C124 CU3012 Chip C C1608CH1H120JT-AS
C125 CU3013 Chip C C1608CH1H150JT-AS
C126 CU3013 Chip C C1608CH1H150JT-AS
C127 CU3013 Chip C C1608CH1H150JT-AS

CU3554

C128

CU3535

C129

CU3535

C130

CU3512

C131
C132 CU3547 Chip C GRP155B11C103KA01E

CU3535

C133

CU3547

C134

CU3535

C135

CU3535

C136
C137 CU3511 Chip C GRP1552C1H100JZ01E

CU3523

C138
C139 CU3503 Chip C GRP1554C1H2R0CZ01E

CU3502

C140

CU3535

C141
C142 CS0441 Chip Tantalum TMCMA0J226MTRF

CU3535

C143

CU3535

C144

CU3535

C145

CU3535

C146
C147 CU3516 Chip C GRP1552C1H270JZ01E

CU3535

C148

CU3535

C149

CU3503

C150

CU3502

C151
C152 NC
C153 NC
C154 NC

CU3559 Chip C GRM155B30J105KE18D

C155

Chip C GRP1552C1H101JD01E

Chip C C1608CH1H270JT-AS TFH, R

C1608CH1H390JT-AS
Chip C
Chip C C1608CH1H470JT-AS

Chip C GRP155B11H102KA01E

Chip C GRP1554C1H1R0CZ01E
Chip C GRP1554C1H1R0CZ01E

Chip C C1608CH1H040CT-AS
Chip C GRP155B11C103KA01E
Chip C GRP1552C1H330JZ01E

Chip C GRP155B11A104KA01E
Chip C GRP155B11H102KA01E
Chip C GRP155B11H102KA01E
Chip C GRP1552C1H120JZ01E

Chip C GRP155B11H102KA01E
Chip C GRP155B11C103KA01E
Chip C GRP155B11H102KA01E
Chip C GRP155B11H102KA01E

Chip C GRP1552C1H101JD01E

Chip C GRP1554C1H1R0CZ01E
Chip C GRP155B11H102KA01E

Chip C GRP155B11H102KA01E
Chip C GRP155B11H102KA01E
Chip C GRP155B11H102KA01E
Chip C GRP155B11H102KA01E

Chip C GRP155B11H102KA01E
Chip C GRP155B11H102KA01E
Chip C GRP1554C1H2R0CZ01E
Chip C GRP1554C1H1R0CZ01E

C1608CH1H330JT-AS

T, E, EUK

Model:DJ-V17

Parts No. Description Parts Name Version

Z JO

O CD

C156 CU3515 Chip C GRP1552C1H220JZ01E
C157 CU3502 Chip C GRP1554C1H1R0CZ01E
C158 CU3535 Chip C GRP155B11H102KA01E
C159 CU3535 Chip C GRP155B11H102KA01E

NC

C160

NC

C161
C162 CU3529 Chip C GRP 155B11H331KD01E
C163 CS0426 Chip Tantalum
C164

CS0426 Chip Tantalum
CU3554

C165

CU3535

C166

NC

C167
C168 CU3535 Chip C GRP155B11H102KA01E

CU3535

C169
C170 NC
C171 CU3535 ChipC GRP155B11H102KA01E
C172 NC

CU3535 Chip C GRP155B11H102KA01E

C173
C174

CS0396
C176 CU3511
C177

CU3513

CU3503

C178

CU3133

C179

CU3535

C180

CU3535

C181

CU3133

C182
C183 CS0398 Chip Tantalum TMCP0J225MTR
C184 CU3506 Chip C GRP1552C1H5R0CZ01E
C185 CU3535 Chip C GRP155B11H102KA01E
C186 CU3554 Chip C GRP155B11A104KA01E
C187

CU3511

CU3535

C188

CU3535

C189

CU3504 Chip C

C190

NC

C191
C192 CU3504 Chip C GRP1553C1H3R0CZ01E

CU3503

C193
C193 CU3504 Chip C GRP1553C1H3R0CZ01E T, E, EUK
C194 CU3535 Chip C GRP155B11H102KA01E
C195 CU3512 Chip C GRP1552C1H120JZ01E

CU3559

C196
C197 NC
C198 NC

CU3535 Chip C GRP155B11H102KA01E

C199

CU3503 Chip C GRP1554C1H2ROCZ01E

C200

CU3503

C201
C202 NC
C204 CU3535 Chip C

CU3535

C205

CU3535

C206

CU3547

C207
C208 CU3524 ChipC GRP1552C1H121JD01E

CU3515

C209
C210 NC

CU3547

C211
C212 CU3523 Chip C GRP1552C1H101JD01E

CU3535

C213

Chip C GRP155B11A104KA01E
Chip C GRP155B11H102KA01E

Chip C GRP155B11H102KA01E

Chip Tantalum TMCP1D104MTR
Chip C GRP1552C1H10OJZ01E
Chip C GRP1552C1H150JZ01E
Chip C GRP1554C1H2R0CZ01E
Chip C TMK107BJ105KA-T
Chip C GRP155B11H102KA01E
Chip C GRP155B11H102KA01E
Chip C TMK107BJ105KA-T

Chip C GRP1552C1H100JZ01E
Chip C GRP155B11H102KA01E
Chip C GRP155B11H102KA01E

Chip C GRP1554C1H2R0CZ01E TFH, R

ChipC GRM155B30J105KE18D

Chip C GRP1554C1H2R0CZ01E

Chip C GRP155B11H102KA01E
Chip C GRP155B11H102KA01E
Chip C GRP155B11C103KA01E

ChipC GRP1552C1H220JZ01E

Chip C GRP155B11C103KA01E

Chip C GRP155B11H102KA01E

F931A106MAA
F931A106MAA

GRP1553C1H3R0CZ01E

GRP155B11H102KA01E

19

Ref.

Parts No.

No.
C214 CU3535 Chip C GRP155B11H102KA01E
C215 CU3517 ChipC GRP1552C1H330JZ01E
C216 CU3520 ChipC GRP1552C1H560JD01E
C217 CU3535 ChipC GRP155B11H102KA01E
C218 CU3547 ChipC GRP155B11C103KA01E
C219 CU3521 ChipC GRP1552C1H680JD01E
C220 CU3519 ChipC GRP1552C1H470JZ01E
C221 CU3502 ChipC GRP1554C1H1R0CZ01E
C222

CU3507
CU3502

C223

CU3535

C224
C225 CU3535 ChipC GRP155B11H102KA01E
C226 CU3133 ChipC
C227 CU3536 ChipC GRM36B122K50PT
C228 CU3547 ChipC GRP155B11C103KA01E
C229 CU3547 ChipC GRP155B11C103KA01E
C230 CU3554 ChipC GRP155B11A104KA01E
C231 CU3554 ChipC GRP155B11A104KA01E
C232 CU3522 ChipC GRP1552C1H820JD01E
C233 CU3535 ChipC GRP155B11H102KA01E
C234 CU3554 ChipC GRP155B11A104KA01E

CU3554

C235

CU3523

C236
C237 CU3554

CU3535

C238

CU3535

C239
C240 NC
C241 CU3554 ChipC GRP155B11A104KA01E
C242 CU3547 ChipC GRP155B11C103KA01E
C243 CU3535 ChipC GRP155B11H102KA01E
C244 CU3554 ChipC GRP155B11A104KA01E
C245 CS0441 Chip Tantalum TMCMA0J226MTRF
C246 CU3559 ChipC GRM155B30J105KE18D
C247 CU3535 ChipC GRP155B11H102KA01E

CU3535

C248
C249 CU3547 ChipC

CU3535

C250
C251 CU3547 ChipC GRP155B11C103KA01E
C252 CU3521

CU3535

C253
C254 CU3535 ChipC GRP155B11H102KA01E
C255 CU3553 ChipC GRP155B11A473KA01E
C256 CU3554 ChipC GRP155B11A104KA01E
C257 CS0441 Chip Tantalum TMCMA0J226MTRF
C258 CU3554 ChipC GRP155B11A104KA01E
C259 CU3535 ChipC GRP155B11H102KA01E
C260

CU3527
CU3522

C261

CU3554

C262

CU3535

C263
C264 CU3554
C265 CU3531 ChipC
C266 CU3554 ChipC
C267 CU3527 ChipC
C268 CU3535 ChipC GRP155B11H102KA01E
C269 CU3547 ChipC GRP155B11C103KA01E
C270 CU3535 ChipC GRP155B11H102KA01E
C271 CU3535 ChipC GRP155B11H102KA01E
C272 CU3559 ChipC GRM 155B30J105KE18D
C273 CU3513 ChipC GRP1552C1H150JZ01E

Description

ChipC
ChipC
ChipC

ChipC
ChipC
ChipC GRP155B11A104KA01E
ChipC GRP155B11H102KA01E
ChipC GRP155B11H102KA01E

ChipC

ChipC

ChipC GRP1552C1H680JD01E
ChipC

ChipC GRP1552C1E221J D01E
ChipC GRP1552C1H820JD01E
ChipC
ChipC
ChipC GRP155B11A104KA01E

Parts Name

GRP1552C1H6R0DZ01E
GRP1554C1H1R0CZ01E
GRP155B11H102KA01E

TMK107BJ105KA-T

GRP155B11A104KA01E
GRP1552C1H101JD01E

GRP155B11H102KA01E
GRP155B11C103KA01E
GRP155B11H102KA01E

GRP155B11H102KA01E

GRP155B11A104KA01E
GRP155B11H102KA01E

GRP 155B11H471KD01E
GRP155B11A104KA01E
GRP1552C1E221JD01E

Version

Model:DJ-V17

Ref.

Parts No.
No.

C274 CU3514 Chip C GRP1552C1H180JZ01E
C275 CU3543 ChipC GRP155B11E472KD01E
C276 CU3535 ChipC GRP155B11H102KA01E
C277 CU3133 ChipC TMK107BJ105KA-T
C278 CU3535 ChipC GRP155B11H102KA01E
C279 CS0439 Chip Tantalum TMCMA0J476MTRF
C280 CU3554 ChipC GRP155B11A104KA01E
C281

CE0437

CU3554

C282

CU3551

C283

CU3551

C284
C285 CU3535 ChipC
C286 CU3535 ChipC
C287 CU3554 ChipC GRP155B11A104KA01E
C288 CU3559 ChipC G RM 155B30 J105KE18D
C289 CS0441 Chip Tantalum TMCMA0J226MTRF
C290 CS0397 Chip Tantalum TMCP1C105MTR
C291 CU3535 ChipC GRP155B11H102KA01E
C292 CS0440 Chip Tantalum TMCMB1C476MTRF
C293 CU3559 ChipC GRM155B30J105KE18D
C294 CU3554 ChipC GRP155B11A104KA01E

CU3535

C295

CU3554

C296
C297 CU3553

CU3535

C298

CU3535

C299
C300 NC
C301 NC
C302 CU3535 ChipC GRP155B11H102KA01E
C303 CU3551 ChipC GRP155B11C223KD01E
C304 CU3552 ChipC GRP155B11A333KA01E
C305 CU3554 ChipC GRP155B11A104KA01E
C306 CU3535 ChipC GRP155B11H102KA01E
C307 CS0439 Chip Tantalum TMCMA0J476MTRF

CU3535

C308

CU3535

C309

CU3535

C310

CU3535

C311
C312

CS0426 Chip Tantalum

CU3535

C313
C314 CU3547 ChipC GRP155B11C103KA01E
C315 CU3547 ChipC GRP155B11C103KA01E
C316 CU3535 ChipC GRP155B11H102KA01E
C317 CU3535 ChipC GRP155B11H102KA01E
C318 CU3535 ChipC GRP155B11H102KA01E
C319 CU3535 ChipC GRP155B11H102KA01E
C320 CU3554 ChipC GRP155B11A104KA01E
C321 CS0439 Chip Tantalum TMCMA0J476MTRF
C322 CU3554
C323 CU3547 ChipC
C324

CU3547 ChipC

CU3535

C325
C326 CE0436 Electrolytic C 16CE47BSS
C327 CU3133 ChipC TMK107BJ105KA-T
C328 CU3535 ChipC GRP155B11H102KA01E
C331 CU3535 ChipC GRP155B11H102KA01E
C332 CU3554 ChipC GRP155B11A104KA01E
C334 NC
C336 CS0396 Chip Tantalum TMCP1D104MTR

CU3535

C347

Description

Electrolytic C
ChipC GRP155B11A104KA01E
ChipC
ChipC

ChipC GRP155B11H102KA01E
ChipC
ChipC
ChipC
ChipC

ChipC GRP155B11H102KA01E
ChipC
ChipC
ChipC

ChipC

ChipC

ChipC

ChipC GRP155B11H102KA01E

Parts Name

10CE150BSS

GRP155B11C223KD01E
GRP155B11C223KD01E
GRP155B11H102KA01E
GRP155B11H102KA01E

GRP155B11A104KA01E
GRP155B11A473KA01E
GRP155B11H102KA01E
GRP155B11H102KA01E

GRP155B11H102KA01E
GRP155B11H102KA01E
GRP155B11H102KA01E
F931A106MAA
GRP155B11H102KA01E

GRP155B11A104KA01E
GRP155B11C103KA01E
GRP155B11C103KA01E
GRP155B11H102KA01E

Version

20

Ref.

Parts No.

No.
C348 CU3507 Chip C GRP1552C1H6R0DZ01E
C349 CU3559
C350 CU3559

CU3133

C351
C352 CU3535 ChipC GRP155B11H102KA01E
C353 CU3535 ChipC GRP155B11H102KA01E
C354 CU3535 ChipC GRP155B11H102KA01E
C355 CS0398 Chip Tantalum TMCP0J225MTR
C356 CU3547
C357

NC
C358 NC
C360 CU3535 ChipC
C362

CU3535 ChipC
C363 CU3535 ChipC GRP155B11H102KA01E

CU3035

C370
CN101 NC
CN102 NC
CN103 UE0506 Connector AXK520135P

XD0422

D101
D102

XD0419 Diode 1SS400TE61
D103 XD0422
D104

XD0417

XD0251

D105
D106 NC
D107 XD0421
D108 XD0422
D109 XD0421 Diode 1SV323(TPH3,H)
D110 NC
D111 NC
D112

XD0423 Diode HVC132TRF-E

XD0422

D113

XD0422

D114
D115 XD0421 Diode 1SV323(TPH3,H)
D116 XD0421 Diode 1SV323(TPH3,H)

XD0421 Diode 1SV323(TPH3,H)

D117
D118 XD0421
D119

XL0097

XD0338

D120
D121

XD0419 Diode 1SS400TE61
D122 XD0424 Diode S3JB-T

XD0420

D123
D124 XD0338 Diode 1SS362(TE85L)

XD0420

D125

XL0036

D126
D127 XL0036 Chip LED SML-310MTT86

XL0036

D128

XL0036

D129
D130 XD0416 Diode 1SS423(TE85L,F)

XL0036

D131

XL0036

D132

XD0418

D133
D134

XD0418 Diode RB521S-30TE61
FL101 XF0041 MCF UM5 21.7M 21R15A5
FL102 XF0041 MCF UM5 21.7M 21R15A5
FL103 XC0060 Filter ALFYM450F=K
IC101 XA1107 IC MB15E07SR
IC102

XA1106 IC LM2902PWR
IC103

XA0404 IC TA31136FN(EL)
IC104 XA1120 IC S80845CLNB-B66-T2G
IC105

XA1117

Description

ChipC
ChipC
ChipC TMK107BJ105KA-T

ChipC

ChipC C1608JB1H102KT-AS

Diode HSC277TRF-E

Diode HSC277TRF-E
Diode HVC202BTRU-E
Diode

Diode
Diode

Diode HSC277TRF-E
Diode HSC277TRF-E

Diode
Chip LED SML-521MUWT86
Diode

Diode FA3J3STP

Diode FA3J3STP
Chip LED SML-310MTT86

Chip LED SML-310MTT86
Chip LED SML-310MTT86

Chip LED SML-310MTT86
Chip LED
Diode RB521S-30TE61

IC S24CS64A01-J8T1G

Parts Name

GRM155B30J105KE18D
GRM155B30J105KE18D

GRP155B11C103KA01E

GRP155B11H102KA01E
GRP155B11H102KA01E

MA741WA-(TX)

1SV323(TPH3,H)
HSC277TRF-E

1SV323(TPH3,H)

1SS362(TE85L)

SML-310MTT86

Version

Ref.

Parts No.

No.
IC106 XA0210 IC NJM2070M T1
IC107 XA1118 IC M62429FP/CF0J
IC108

XA1106 IC LM2902PWR

IC109

XA1121 CPU M38268MCA-076GP#UO
IC110 XA1119 IC XC6202P502MR
JK101 UJ0060 Jack HSJ1594-010150
JK102

UJ0061 Jack LD-0208-1.3
L101 QS401556 Coil 0.40-1.55-6TL
L102

QS402006 Coil 0.40-2.0-6TL
L103

QS402006
L104 QS401405
L105

QS501403 Coil 0.50-1.4-3TL
L106

QC0757
L107 QC0809
L108

QS30200D Coil 0.30-2.0-13TL
L109 QC0810
L110 QC0765
L111 QC0808
L112

QC0773
L113

QS402057 Coil 0.40-2.05-7TL
L114

QB0057
L115

QB0057
L116 QC0812

QC0818 Chip Inductor C2012H82NH

L117
L118 QB0057
L120 QC0816
L121 QC0812
L122 NC
L123 NC
L124 QC0773

QC0764 Chip Inductor

L125
L126 QC0763
L127 QC0773
L128 QC0764
L129 QC0763

QC0820 Chip Inductor

L130
L131 QC0842
LCD101

EL0059
MIC101 EY0017 Microphone
Q101 XT0210
Q102

XE0071 FET 2SK3476(TE12L,Q)
Q103

XE0070 FET 2SK3475(TE12L,F)
Q104

XT0180 Transistor
Q105

NC
Q106

XT0213 Transistor 2SC5659T2L
Q107 XT0213
Q108

XT0180 Transistor
Q109

NC
Q110 XT0180

XT0214 Transistor HN2C01 FE-GR(T5L,F)

Q111
Q112 XU0210 Transistor

XT0219 Transistor 15GN03F-TL-E

Q113
Q114 XE0053 FET
Q115 NC
Q116 XE0053 FET
Q117 XU0210
Q118

XT0219
Q119 XT0213
Q120 XT0210
Q121 XU0212

Description

Coil
Coil

Chip Inductor C1608CB22NJ
Chip Inductor

Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor

Chip Inductor
Chip Inductor
Chip Inductor

Chip Inductor
Chip Inductor
Chip Inductor

Chip Inductor

Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor

Chip Inductor
LCD LCD DJ170

Transistor

Transistor

Transistor 2SC5066FT-Y (TE85L)

Transistor
Transistor
Transistor
Transistor
Transistor

Parts Name

0.40-2.0-6TL

0.40-1.4-5TL

MLG1005S56NJT

MLG1005S68NJT
C1608CBR10J
MLG1005S47NJT
C1608CBR47J

MPZ1608S101AT
MPZ1608S101AT
MLG1005SR10JT

MPZ1608S101AT
MLG1005SR22JT
MLG1005SR10JT

C1608CBR47J
C1608CB82NJ
C1608CB68NJ
C1608CBR47J
C1608CB82NJ
C1608CB68NJ
LB2518T151K
LB2518T221K

OB-27P44
2SC6026MFV-GR

2SC5066FT-Y (TE85L)

2SC5659T2L
2SC5066FT-Y (TE85L)

RN1107MFV(TPL3)

3SK293 TE85L

3SK293 TE85L
RN1107MFV(TPL3)
15GN03F-TL-E
2SC5659T2L
2SC6026MFV-GR
RN2115MFV(TPL3)

Model:DJ-V17

Version

21

Ref.

Parts No.

No.
Q122 XU0210 Transistor RN1107MFV(TPL3)
Q123 NC
Q124 XU0220 Transistor RN2111MFV(TLP3)
Q125

XU0210 Transistor RN1107MFV(TPL3)

Q126

XU0210 Transistor RN1107MFV(TPL3)
Q127 XU0220 Transistor RN2111MFV(TLP3)
Q128

XT0210 Transistor 2SC6026MFV-GR
Q129

XT0210 Transistor 2SC6026MFV-GR

Q130 XT0170 Transistor 2SB766A-(TX)R

XT0210 Transistor 2SC6026MFV-GR

Q131
Q132 XT0170 Transistor
Q133 XE0069
Q134 XU0210 Transistor RN1107MFV(TPL3)
Q135 XT0214 Transistor HN2C01 FE-GR(T5L,F)
Q136 XT0170 Transistor 2SB766A-(TX)R
Q137 XT0212 Transistor 2SA1955FV-A(TPL3)
Q138 XT0212 Transistor 2SA1955FV-A(TPL3)
Q139 XT0214 Transistor HN2C01 FE-GR(T5L,F)
Q140 XT0212 Transistor 2SA1955FV-A(TPL3)
Q141 XT0210 Transistor 2SC6026MFV-GR

XU0213

Q142

XU0213 Transistor RN1111 MFV(TPL3),F

Q143
Q144 XU0210 Transistor

XU0211

Q145
Q146 XU0213 Transistor
Q147 XE0069
Q148 XE0069
Q149 XT0210 Transistor 2SC6026MFV-GR
Q152 XU0211 Transistor RN2107MFV(TPL3)
Q153 XU0211
R101 RK3534 Chip R ERJ2GEJ471X
R102 RK3545 Chip R
R103 RK3501 Chip R ERJ2GE0R00X
R104 RK3501 Chip R ERJ2GE0R00X
R105 RK3556 Chip R ERJ2GEJ333X
R106 RK3574 Chip R ERJ2GEJ105X

RK3526 Chip R ERJ2GEJ101X

R107
R108 RK3534
R109 RK3030
R111 RK3542 Chip R
R112 RK3556 Chip R
R113 RK3548 Chip R
R114 RK3574 Chip R ERJ2GEJ105X
R115 RK3550 Chip R ERJ2GEJ103X
R116 RK3022 Chip R MCR03EZHJ470

RK3530 Chip R

R117
R118 RK3526 Chip R ERJ2GEJ101X
R119 RK3566 Chip R ERJ2GEJ224X
R120 RK3550 Chip R ERJ2GEJ103X
R121 RK3538 Chip R
R122

NC
RK3522 Chip R ERJ2GEJ470X

R123
R124 NC
R125 NC
R126 RK3562 Chip R ERJ2GEJ104X
R127 RK3565 Chip R ERJ2GEJ184X
R128 RK3550 Chip R ERJ2GEJ103X
R129 RK3574 Chip R ERJ2GEJ105X
R130 RK3538 Chip R
R131 RK3552 Chip R ERJ2GEJ153X

Description

FET SSM3K15FV(TPL3,Z)

Transistor RN1111 MFV(TPL3),F

Transistor RN2107MFV(TPL3)

FET
FET

Transistor RN2107MFV(TPL3)

Chip R
Chip R MCR03EZHJ221

Parts Name

2SB766A-(TX)R

RN1107MFV(TPL3)

RN1111 MFV(TPL3),F
SSM3K15FV(TPL3,Z)
SSM3K15FV(TPL3,Z)

ERJ2GEJ392X

ERJ2GEJ471X

ERJ2GEJ222X
ERJ2GEJ333X
ERJ2GEJ682X

ERJ2GEJ221X

ERJ2GEJ102X

ERJ2GEJ102X

Version

Réf.

Parts No.

No.
R132 RK3531 Chip R ERJ2GEJ271X
R133 RK3550 Chip R ERJ2GEJ103X
R134 RK3551 Chip R
R135 RK3551 Chip R
R136 RK3538 Chip R ERJ2GEJ102X
R137 RK3551 Chip R
R138 RK3562 Chip R ERJ2GEJ104X
R139 RK3550 Chip R ERJ2GEJ103X
R140

NC
R141 RK3557 Chip R ERJ2GEJ393X
R142

NC
R143 RK3546
R144 NC
R145 RK3550 Chip R ERJ2GEJ103X
R146 RK3537 Chip R
R147 RK3526 Chip R ERJ2GEJ101X
R148 RK3542 Chip R
R149

NC
R150 RK3550 Chip R ERJ2GEJ103X
R151 RK3550 Chip R ERJ2GEJ103X
R152

RK3547
R154 RK3570 Chip R ERJ2GEJ474X
R155 RK3542 Chip R ERJ2GEJ222X
R156 RK3538
R157 RK3550
R159 RK3539 Chip R
R161 RK3538 Chip R ERJ2GEJ102X
R162 RK3564 Chip R ERJ2GEJ154X
R163 RK3522 Chip R ERJ2GEJ470X
R164 RK3550 Chip R ERJ2GEJ103X
R165 RK3544 Chip R
R166 RK3530 Chip R

RK3542 Chip R ERJ2GEJ222X

R167
R168 RK3526 Chip R ERJ2GEJ101X
R169 RK3550 Chip R ERJ2GEJ103X
R170 RK3530 Chip R ERJ2GEJ221X

RK3526 Chip R ERJ2GEJ101X

R171
R172

NC
R173 NC
R174 RK3530 Chip R
R175 RK3550 Chip R ERJ2GEJ103X
R176 RK3570 Chip R ERJ2GEJ474X
R177 RK3550 Chip R ERJ2GEJ103X
R178 RK3550 Chip R ERJ2GEJ103X
R179 RK3538 Chip R ERJ2GEJ102X
R180

NC
R181 RK3550 Chip R ERJ2GEJ103X
R182 RK3566 Chip R ERJ2GEJ224X
R183 NC
R184

NC

RK3562 Chip R

R185
R186 RK3550
R187 RK3526 Chip R ERJ2GEJ101X
R188 RK3538 Chip R ERJ2GEJ102X
R189 RK3539 Chip R
R190

NC
R191 RK3550 Chip R ERJ2GEJ103X
R192 RK3558 Chip R ERJ2GEJ473X
R193 RK3562 Chip R ERJ2GEJ104X
R194 RK3522 Chip R ERJ2GEJ470X

Description

Chip R ERJ2GEJ472X

Chip R ERJ2GEJ562X

Chip R ERJ2GEJ102X
Chip R

Chip R

Parts Name

ERJ2GEJ123X
ERJ2GEJ123X

ERJ2GEJ123X

ERJ2GEJ821X

ERJ2GEJ222X

ERJ2GEJ103X
ERJ2GEJ122X

ERJ2GEJ332X
ERJ2GEJ221X

ERJ2GEJ221X

ERJ2GEJ104X
ERJ2GEJ103X

ERJ2GEJ122X

Model:DJ-V17

Version

22

Ref.

Parts No. Description Parts Name Version

No.
R195 RK3558 Chip R ERJ2GEJ473X
R196 RK3558 Chip R ERJ2GEJ473X
R197 RK3574 Chip R ERJ2GEJ105X
R198 RK3574 Chip R ERJ2GEJ105X
R199 RK3553 Chip R ERJ2GEJ183X
R200 RK3560 Chip R ERJ2GEJ683X
R201 RK3522 Chip R ERJ2GEJ470X
R202 RK3539 Chip R ERJ2GEJ122X

RK3566 Chip R ERJ2GEJ224X

R203
R204

RK3574
R205 RK3574
R206 RK3558 Chip R ERJ2GEJ473X
R207 RK3556 Chip R ERJ2GEJ333X
R208 NC
R209 RK3526 Chip R ERJ2GEJ101X
R210 RK3522 Chip R ERJ2GEJ470X
R211 RK3558 Chip R ERJ2GEJ473X
R212 RK3550 Chip R ERJ2GEJ103X
R213 RK3562 Chip R ERJ2GEJ104X
R214 RK3564 Chip R ERJ2GEJ154X

RK3561 Chip R ERJ2GEJ823X

R215

RK3538 Chip R ERJ2GEJ102X

R216
R218 RK3558
R219

RK3564
R220 RK3556 Chip R ERJ2GEJ333X
R221 RK3548 Chip R ERJ2GEJ682X
R222 RK3558 Chip R ERJ2GEJ473X
R223 RK3550 Chip R ERJ2GEJ103X
R224 RK3550 Chip R ERJ2GEJ103X
R225 RK3554 Chip R ERJ2GEJ223X
R226 RK3554 Chip R ERJ2GEJ223X
R227 RK3559 Chip R ERJ2GEJ563X
R228 RK3550 Chip R ERJ2GEJ103X

RK3550 Chip R ERJ2GEJ103X

R229

RK3562 Chip R ERJ2GEJ104X

R230

RK3538 Chip R ERJ2GEJ102X

R231
R232

RK3568
R234

RK3550
R235 RK3562 Chip R ERJ2GEJ104X
R236 RK3562 Chip R ERJ2GEJ104X
R237 RK3522 Chip R ERJ2GEJ470X
R238 RK3550 Chip R ERJ2GEJ103X
R239 RK3567 Chip R ERJ2GEJ274X
R240 RK3562 Chip R ERJ2GEJ104X
R242 RK3501 Chip R ERJ2GE0R00X
R243 RK3550 Chip R ERJ2GEJ103X
R244 RK3564 Chip R ERJ2GEJ154X

RK3544 Chip R ERJ2GEJ332X

R245

RK3562 Chip R

R246
R247

RK3564
R248 RK3538
R249 RK3565 Chip R ERJ2GEJ184X
R250 RK3550 Chip R ERJ2GEJ103X
R251 RK3562 Chip R ERJ2GEJ104X
R252 RK3561 Chip R ERJ2GEJ823X
R253 RK3566 Chip R ERJ2GEJ224X
R254 RK3550 Chip R ERJ2GEJ103X
R255 RK3562 Chip R ERJ2GEJ104X
R256 RK3562 Chip R ERJ2GEJ104X
R257 RK3538 Chip R ERJ2GEJ102X

Chip R
Chip R

Chip R ERJ2GEJ473X
Chip R

Chip R ERJ2GEJ334X
Chip R

Chip R
Chip R ERJ2GEJ102X

ERJ2GEJ105X
ERJ2GEJ105X

ERJ2GEJ154X

ERJ2GEJ103X

ERJ2GEJ104X
ERJ2GEJ154X

Ref.

Parts No. Description Parts Name Version

No.
R258 RK3574 Chip R ERJ2GEJ105X
R259 RK3566 Chip R ERJ2GEJ224X
R260 RK3553 Chip R ERJ2GEJ183X
R261 RK3574 Chip R ERJ2GEJ105X
R262 RK3562 Chip R ERJ2GEJ104X
R263 RK3562 Chip R ERJ2GEJ104X
R264 RK3558 Chip R ERJ2GEJ473X

RK3536 Chip R ERJ2GEJ681X

R265
R266 RK3518
R267

NC
RK3532 Chip R

R269
R270 RK3560 Chip R ERJ2GEJ683X
R272 RK3556 Chip R ERJ2GEJ333X
R273 RK3566 Chip R ERJ2GEJ224X
R274 RK3544 Chip R ERJ2GEJ332X
R275 RK3566 Chip R ERJ2GEJ224X
R276 RK3560 Chip R ERJ2GEJ683X
R277 RK3552 Chip R ERJ2GEJ153X
R278 RK3562 Chip R ERJ2GEJ104X
R279 RK3558

RK3556 Chip R ERJ2GEJ333X

R280
R281 RK3017
R282

RK3514
R283 RK3554
R284 RK3561 Chip R ERJ2GEJ823X
R285 RK3550 Chip R ERJ2GEJ103X
R286 RK3570 Chip R ERJ2GEJ474X
R287 RK3550 Chip R ERJ2GEJ103X
R288 RK3550 Chip R ERJ2GEJ103X
R289 RK3565 Chip R ERJ2GEJ184X
R290 RK3017 Chip R MCR03EZHJ180
R291 RK3551 Chip R ERJ2GEJ123X
R292 RK3569 Chip R ERJ2GEJ394X

RK3532 Chip R ERJ2GEJ331X

R293
R294 RK3562 Chip R ERJ2GEJ104X
R295 RK3538
R296 RK3530
R297

RK3546
R298 RK3550 Chip R ERJ2GEJ103X
R299 RK3550 Chip R ERJ2GEJ103X
R300 RK3538 Chip R ERJ2GEJ102X
R301 RK3501 Chip R ERJ2GE0R00X
R302 RK3538 Chip R ERJ2GEJ102X
R303 RK3550 Chip R ERJ2GEJ103X
R304 RK3546 Chip R ERJ2GEJ472X
R305 RK3550 Chip R ERJ2GEJ103X

RK3550 Chip R ERJ2GEJ103X

R306

RK3574 Chip R ERJ2GEJ105X

R308
R309 RK3574
R310 RK3550
R311 RK3550
R312 RK3570 Chip R ERJ2GEJ474X
R313 RK3550 Chip R ERJ2GEJ103X
R314 RK3554 Chip R ERJ2GEJ223X
R315 RK3542 Chip R ERJ2GEJ222X
R316 RK3550 Chip R ERJ2GEJ103X
R317 RK3570 Chip R ERJ2GEJ474X
R318 RK3550 Chip R ERJ2GEJ103X
R319 RK3554 Chip R ERJ2GEJ223X

RK3574 Chip R ERJ2GEJ105X

R320

Chip R ERJ2GEJ220X

ERJ2GEJ331X

Chip R ERJ2GEJ473X

Chip R MCR03EZHJ180
Chip R
Chip R ERJ2GEJ223X

Chip R ERJ2GEJ102X
Chip R
Chip R ERJ2GEJ472X

Chip R
Chip R
Chip R

ERJ2GEJ100X

ERJ2GEJ221X

ERJ2GEJ105X
ERJ2GEJ103X
ERJ2GEJ103X

Model:DJ-V17

23

Ref.

Parts No.

No.
R321 RK3550 Chip R ERJ2GEJ103X
R322 RK3568 Chip R ERJ2GEJ334X
R323 RK3550 Chip R ERJ2GEJ103X
R324 RK3548 Chip R ERJ2GEJ682X
R325 RK3559 Chip R ERJ2GEJ563X
R326 RK3559 Chip R ERJ2GEJ563X
R327 RK3550 Chip R ERJ2GEJ103X
R328 RK3550 Chip R ERJ2GEJ103X
R330

RK3546
R331 RK3546
R332

RK3546
R333 RK3546
R334 RK3562 Chip R
R335 RK3562 Chip R ERJ2GEJ1Q4X

RK3562

R336
R337 RK3550 Chip R ERJ2GEJ103X

RK3542

R338
R339 RK3550 Chip R ERJ2GEJ103X
R340 RK3550 Chip R ERJ2GEJ103X
R341 RK3550 Chip R ERJ2GEJ103X
R342 RK3538 Chip R ERJ2GEJ102X
R343 RK3550 Chip R ERJ2GEJ103X
R344 RK3537 Chip R ERJ2GEJ821X

RK3558 Chip R ERJ2GEJ473X

R345

RK3537 Chip R

R346
R347

NC
R348 RK3552 Chip R ERJ2GEJ153X
R349 NC
R350 RK3562 Chip R ERJ2GEJ1Q4X
R351 RK3550 Chip R ERJ2GEJ103X
R352

NC
R353

RK3546
R354 RK3550 Chip R ERJ2GEJ103X
R355 RK3550 Chip R ERJ2GEJ103X
R357 RK3501 Chip R ERJ2GE0R00X
R358

NC
R359 NC
R360 NC
R361 NC
R362

RK3536
R363 RK3558 Chip R ERJ2GEJ473X
R364 RK1018 Chip R ERJ8GEYJ101V
R365

RK3546
R366 RK3566 Chip R ERJ2GEJ224X
R367 RK3558 Chip R ERJ2GEJ473X
R368 RK3548 Chip R ERJ2GEJ682X
R369 RK3538 Chip R ERJ2GEJ102X
R370 RK3501 Chip R ERJ2GE0R00X
R371

RK3546
R372 RK3550 Chip R ERJ2GEJ103X
R373 RK3546
R374 RK3562 Chip R
R375 RK3550
R376 RK3562 Chip R ERJ2GEJ104X
R377 RK3562 Chip R ERJ2GEJ104X
R378 RK3566 Chip R ERJ2GEJ224X
R379 RK3562 Chip R ERJ2GEJ104X
R380 RK3566 Chip R ERJ2GEJ224X
R381 RK3554 Chip R ERJ2GEJ223X
R382

NC

Description

Chip R ERJ2GEJ472X
Chip R ERJ2GEJ472X
Chip R ERJ2GEJ472X
Chip R ERJ2GEJ472X

Chip R ERJ2GEJ104X

Chip R ERJ2GEJ222X

Chip R ERJ2GEJ472X

Chip R

Chip R ERJ2GEJ472X

Chip R ERJ2GEJ472X

Chip R ERJ2GEJ472X

Chip R

Parts Name

ERJ2GEJ104X

ERJ2GEJ821X

ERJ2GEJ681X

ERJ2GEJ104X
ERJ2GEJ103X

Version

Model:DJ-V17

Ref.

Parts No.

No.
R384 NC
R385 NC T
R385 RK3038 Chip R MCR03EZHJ102 TFH, R
R385 RK3064 Chip R MCR03EZHJ154 E, EUK
R386

NC

R387

NC
R388 RK3550 Chip R ERJ2GEJ103X
R392 RK3550 Chip R ERJ2GEJ103X
R393 RK3534 Chip R ERJ2GEJ471X
R394 RK3531 Chip R ERJ2GEJ271X

RK3556 Chip R ERJ2GEJ333X

R395
R396 RK3556
R398 RK3558
R398 RK3570 Chip R ERJ2GEJ474X T, E, EUK
R401 RK3501 Chip R ERJ2GE0R00X
R402 RK3501 Chip R ERJ2GE0R00X
R403 RK3570 Chip R ERJ2GEJ474X
R404 RK3550 Chip R ERJ2GEJ103X
R405 RK3542 Chip R ERJ2GEJ222X
R406 RK3546 Chip R ERJ2GEJ472X
R407 RK3562 Chip R ERJ2GEJ104X
R408 RK3526 Chip R ERJ2GEJ101X

UU0041

SW101

UU0041

SW102

UU0041 Switch EVQP4203M

SW103
TC101 CT0050
TH101 XS0052 Thermistor
VR101 RH0233
VR102 NC
VR103 RH0225
VR104 RH0225
VR105

NC
W101 MPCL07AA Wire #30P02-070-02
W102 MACL07AA Wire #30A02-070-02
W103

NC
W103

MACLH2GG
X101 XQ0175
X102

NC
X103 XK0004 Discriminator CDBLB450KCAY24-B0

XQ0184

X104

UP0541 PCB DJ170 INTEGRATED

FM0265 HEATSINK DJ170

TS0183 VCO CASE VCO CASE

TZ0049 SILICON DUMPER

Mechanical Unit

Ref.

Parts No.
No.

ADFV17

ADRV17

AF0018

AF0030 SCREW XQN2+A6FN(58364-0001

AP0039 SCREW PH P2+20 FE/3BBC

AX0004Z SCREW PT 3P 2X8 BBC AX0004

DG0046 LCD LIGHT

DP0181 LCD PANNEL DJV17

FG0392 WATERPROOF

FGQ418 LCD RUBBER CONE

Description

Chip R ERJ2GEJ333X
Chip R ERJ2GEJ473X TFH, R

Switch EVQP4203M
Switch EVQP4203M

Trimmer

Trimmer R

Trimmer R
Trimmer R

Wire #30AH1-025-H1 T, E
Crystal

Crystal AT49 3.6864M

Description Parts Name Version

FRONT CASE ASSY
REAR CASE ASSY

SCREW XQN2+C4FZ

Parts Name

TZY2Z100A001R00
NTCG104LH104JT1
RH02B1C15X

RH02B1CS3X
RH02B1CS3X

SX2112 21.25MHDG0687

FRONT CASE ASSY
REAR CASE ASSY

Version

EUK

Model:DJ-V17

24

Ref.

Parts No. Description Parts Name Version

No.

FG0419 WATERPROOF RUBBER
FG0423 JACK CAP DJ170
FG0424 0 RING (R COVER)
FG0426 MIC RUBBER
FP0254 REAR COVER
FP0255 ROCK LEVER
FP0264 BLIND SEAL
NK0081
SP0013 LECTRA #7800
ST0089
TL0033 REFLECTIVE SHEET
YX0039 LCD TAPE DJS45

VOL KNOB

LCD HOLDER

Model:DJ-V17

Packing Unit

Ref.

Parts No. Description Parts Name

No.

EA0141 ANTENNA ANTENNA EA0141 T, E, EUK
EA0142 ANTENNA ANTENNA EA0142 TFH, R
EG0062 BATTERY EBP-65 P BAG TFH, R
EG0065 BATTERY EBP-65A P BAG T, E, EUK
EDC146 ADAPTOR ADAPTOR 120V T
EDC147
EDC148
PR0478
DS0446
PR0447 WARNING FCC (N)
PR0452
HU0234 INNER DJ170
PS0520A
PH0015 WARRANTY CEAT EXPO T
PK0110 CIRCUIT DIAGRAM V17
HK0637 INDIVIDUAL BOX V17
HP0031 PLA.BAG 5X100X200
BH0017 BELT CLIP BELT CLIP
BB0009Y HAND STRAP HAND STRAP DJS41

AA0076 PH M3+6FE/B-ZN

HP0003

ADAPTOR ADAPTOR 230V E
ADAPTOR ADAPTOR 230V (UK) EUK

SERIAL SEAL
NITTO MODEL PLATE(S)

FCC HOME USE T

INSTRUCTION MANUAL

INSTRUCTION DJV17

PLA.BAG 5X75X110

Model:DJ-V17

Version

T

CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY

AN INCORRECT TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.

25

PARTS LIST<DJ-V47>

MAIN Unit

Réf.

Parts No. Description Parts Name Version

No.
C101 CU3031
C102 CU3031

CU303I

C103
C104

CU3510
C105 CU3511
C106 CU3503
C107

CU3006

CU3006

C108
C109 CU3007 ChipC
C109

CU3009 ChipC

CU3014

C110
C110 CU3010
C110 CU3012

cm CU3013

C112 CU3011 ChipC C1608CH1H100DT-AS C164 CS0426 Chip Tantalum F931A106MAA
C113 CU3011 ChipC C1608CH1H100DT-AS
C114

CU3015
C115 CU3512
C116 CU3531
C117

NC C169 CU3531
C118

CU3501

CU3502

C118
Cl 19

CU3501
C119 CU3502
C120

NC
C121 NC C176 NC
C122

CU3547
C123

NC C178
C124 CU3005

CU3006

C125
C126

CU3006
C127 CU3006

CU3554

C128
C129 CU3531
C130

CU3531

NC C186 CU3554

C131
C132

CU3547 ChipC GRP155B11C103KA01E C187
C133 CU3531 ChipC

CU3547

C134
C135 CU3531
C136 CU3531

CU3511

C137
C138

NC
C139

NC
C140

NC
C141 CU3513
C142 CS0441
C143 CU3531
C144 CU3531
C145 CU3531
C146 CU3531
C147 NC C199 CU3531
C148 CU3507
C149 CU3531
C150 NC
C150

CU3501

CU350I

C151

ChipC
ChipC
ChipC
ChipC
ChipC
ChipC
ChipC
ChipC

ChipC
ChipC
ChipC
ChipC

ChipC
ChipC
ChipC

ChipC
ChipC
ChipC
ChipC

ChipC

ChipC
ChipC
ChipC
ChipC
ChipC
ChipC
ChipC

ChipC
ChipC
ChipC
ChipC

ChipC
Chip Tantalum
ChipC
ChipC
ChipC
ChipC

ChipC
ChipC

ChipC
ChipC

C1608JB1H471KT-AS C152 CU3515
C1608JB1H471KT-AS
C1608JB1H471KT-AS
GRP1552C1H9R0DZ01E
GRP1552C1H100JZ01E C154 CU3523
GRP1554C1H2R0CZ01E C155
C1608CH1H050CT-AS C156 CU3511
C1608CH1H050CT-AS
C1608CH1H060DT-A TA2
C1608CH1H080DT-A EUK
C1608CH1H180JT-AS
C1608CH1H090DT-A
C1608CH1H120JT-AS
C1608CH1H150JT-AS

C1608CH1H220JT-AS C166
GRP 1552C1H120JZ01E C167
GRP155B11H471KD01E C168 CU3531

GRP1554C1HR50CZ01E
GRP1554C1H1R0CZ01E
GRP1554C1HR50CZ01E
GRP1554C1H1R0CZ01E

GRP 155B11C103KA01E C177 CU3505

C1608CH1H040CT-AS
C1608CH1H050CT-AS
C1608CH1H050CT-AS
C1608CH1H050CT-AS
GRP155B11A104KA01E C183
GRP155B11H471KD01E C184
GRP155B11H471KD01E

GRP155B11H471KD01E
GRP 155B11C103KA01E
GRP 155B11H471KD01E C190

GRP 155B11H471KD01E
GRPI552C1H100JZ0IE

GRP1552C1H150JZ01E C195 CU3506
TMCMA0J226MTRF
GRP155B11H471KD01E
GRP155B11H471KD01E C197
GRP155B11H471KD01E
GRP155B11H471KD01E

GRP 1552C1H6R0DZ01E C200 CU3502
GRP 155B11H471KDOIE C201

GRP1554C1HR50CZ01E
GRP1554C1HR50CZ0IE

TA1
TA2
T, E, EUK

T, E, EUK, TA2

TA1

T, E, EUK, TA2

TA1

T, E, EUK, TA2

TA1

Réf.

Parts No. Description Parts Name Version

No.

ChipC
C152 CU3516
C152

CU3519

C153 CU3507

CU3559

C157

CU3501

C158

NC

C159

CU3535 ChipC GRP155B11H102KA01E

C160

CU3511
C16I CU3504
C162 CU3527
C163

CS0426

C165

CU3554 ChipC GRP155B11A104KA01E

CU353I

CU3547

C170 NC
Cl 71 CU3515
C172 NC
Cl 73 CU3531
C174

CS0396

CU3503

CU3I33

C179
C180 CU353I
C181

CU3531
C182

CU3133

CS0398

NC
C185 CU3531

CU3523
C188

CU3531 ChipC
C189

CU3531

CU3505
C19I

CU3505

CU3503

C192
C192 CU3505
C193 CU3502
C194 CU3531

C195 CU3508
C196 CU3559

CU3520
C198

NC
C198

CU3502

CU3502

CU3524

C202
C203 CU3505
C204 CU353I

ChipC
ChipC
ChipC
ChipC
ChipC
ChipC
ChipC

ChipC
ChipC
ChipC
Chip Tantalum

ChipC
ChipC
ChipC
ChipC

ChipC

ChipC
Chip Tantalum

ChipC
ChipC
ChipC
ChipC
ChipC
ChipC
Chip Tantalum

ChipC
ChipC
ChipC GRP1552C1H101JD01E

ChipC
ChipC
ChipC
ChipC
ChipC
ChipC
ChipC
ChipC
ChipC
ChipC
ChipC

ChipC
ChipC
ChipC
ChipC
ChipC
ChipC
ChipC

GRP 1552C1H220JZ0IE
GRP1552C1H270JZ01E
GRP1552C1H470JZ0IE
GRP 1552C1H6R0DZ0IE
GRP1552C1H101JD01E
GRM155B30J105KE18D
GRP1552C1H100JZ01E
GRP1554C1HR50CZ01E

GRP1552C1H100JZ01E
GRP1553C1H3R0CZ01E
GRP 1552C1E221JD01E
F931A106MAA

GRP 155B11H471KD01E
GRP155B11C103KA01E
GRP155B11H471KD01E
GRP155B11H471KD01E

GRP1552C1H220JZ01E

GRP155B11H471KD01E
TMCP1D104MTR

GRP1552C1H4R0CZ01E
GRP 1554C1H2R0CZ0IE
TMK107BJ105KA-T
GRP 155B11H471KD01E
GRP 155B11H471KD01E
TMK107BJ105KA-T
TMCP0J225MTR

GRP155B11H471KD01E
GRP155B11A104KA01E

GRP155B11H471KD01E
GRP 155B11H471KD01E
GRP1552C1H4R0CZ01E

GRP1552C1H4R0CZ01E
GRP1554C1H2R0CZ01E
GRP 1552C1H4R0CZ0IE
GRP1554C1H1R0CZ0IE
GRP155B11H471KD01E
GRP1552C1H5R0CZ01E
GRP1552C1H7R0DZ01E
GRM 155B30J105KE18D
GRP1552C1H560JD01E

GRP1554C1H1R0CZ01E
GRP 155B11H471KD01E
GRP 1554C1H1R0CZ0IE
GRP 1554C1H1R0CZ0IE
GRPI552C1HI2IJD01E
GRP 1552C1H4R0CZ0IE
GRP 155B11H471KD01E

Model :DJ-V47

TA2
T, E, EUK
TA1

T, E, EUK, TA2

TA1

T, E, EUK, TA2

TA1

TA1

T, E, EUK, TA2

26

Ref.

Parts No.

No.
C205 CU3535
C206 CU3531
C207 CU3547
C208 CU3523

CU35I1

C209
C210 CU3547
C211 CU3547
C212 CU3505
C212 CU3515
C213 CU3531
C214

CU3531
C215 CU3512
C216 CU3513
C216 CU3515
C217

CU3531

CU3547

C218
C219 CU3513
C220 CU3513
C220 CU3514

CU3501

C221
C222 CU3506

CU3501

C223
C224 CU3551
C225 CU3531

CU3133

C226
C227

CU3536

CU3547

C228
C229 CU3547
C230 CU3554
C231 CU3554
C232 CU3522
C233 CU3535
C234 CU3554
C235 CU3554
C236 CU3523
C237 CU3554
C238 CU3535
C239 CU3531
C240

NC
C241 CU3554

CU3547

C242
C243 CU3531
C244 CU3554
C245 CS0441
C246 CU3559
C247 CU3531
C248 CU3535
C249 CU3547
C250

CU3531
C251 CU3547
C252

CU3519
C253 CU3535
C254

CU3535
C255 CU3553
C256 CU3554
C257 CS0441
C258 CU3554
C259 CU3531
C260 CU3527
C261 CU3522

Description

Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C

Chip C
Chip C
Chip C
Chip C
Chip Tantalum
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip Tantalum
Chip C
Chip C
Chip C
Chip C

Parts Name

GRP155B11H102KA01E C262 CU3554
GRP155B11H471KD01E C263 CU3531
GRP155B11C103KA01E C264 CU3554
GRP1552C1H101JD01E C265 CU3531
GRP1552C1H100JZ01E C266 CU3554
GRP155B11C103KA01E C267 CU3527
GRPI55B1ICI03KA01E
GRP1552C1H4R0CZ01E
GRP1552C1H220JZ01E
GRP155B11H471KD01E
GRP155B11H471KD01E C272
GRP1552C1H120JZ01E C273 CU3513
GRP1552C1H150JZ01E
GRP1552C1H220JZ01E
GRP155B11H471KD01E C276 CU3531
GRP155B11C103KA01E
GRPI552C1 HI 50JZ01E C278 CU3554
GRPI552C1 HI 50JZ0IE
GRPI552C1HI80JZ0IE
GRPI 554C1HR50CZ01E C28I CE0437
GRPI 552C1H5R0CZ01E C282 CU3554
GRPI 554C1HR50CZ01E C283 CU3551
GRP155B11C223KD01E C284
GRP155B11H471KD01E C285 CU3535
TMK107BJ105KA-T
GRM36B122K50PT C287 CU3554
GRP155B11C103KA01E C288 CU3559
GRP155B11C103KA01E C289 CS0441
GRP155B11A104KA01E C290
GRP155B11A104KA01E C29I CU3531
GRPI 552C1H820JD01E C292 CS0440
GRP155B11H102KA01E C293 CU3559
GRP155B11A104KA01E C294 CU3554
GRPI55B11A104KA01E C295 CU3547
GRPI552CIHI0IJD01E
GRP155B11A104KA01E C297 CU3553
GRP155B11H102KA01E
GRP155B11H471KD01E

GRP155B11A104KA01E C301
GRP155B11C103KA01E C302 CU3531
GRP155B11H471KD01E
GRP155B11A104KA01E
TMCMA0J226MTRF C305 CU3554
GRM155B30J105KE18D C306 CU3531
GRP155B11H471KD01E C307 CS0439
GRP155B11H102KA01E C308 CU3531
GRP155B11C103KA01E C309 CU3531
GRP155B11H471KD01E C310
GRP155B11C103KA01E
GRP1552C1H470JZ01E
GRP155B11H102KA01E
GRP155B11H102KA01E
GRP155B11A473KA01E C315 CU3547
GRP155B11A104KA01E C316 CU3535
TMCMA0J226MTRF
GRP155B11A104KA01E C318 CU3531
GRP155B11H471KD01E C319 CU3531
GRPI 552C1E221JD01E C320 CU3554
GRPI 552C1H820JD01E C32I CS0439

Version

T, E, EUK, TA2

TA1

T, E, EUK, TA2

TA1

T, E, EUK, TA2

TA1

Ref.

Parts No.

No.

C268 CU3535
C269 CU3547
C270

CU3535

C271 CU3531

CU3559

C274 CU3514
C275 CU3543

C277

CU3133

C279 CS0439
C280 CU3554

CU3551

C286 CU3535

CS0397

CU3554

C296

C298 CU3535
C299 CU3531
C300

NC
NC

C303

CU3551

C304

CU3552

CU3531
C311 CU3531
C312

CS0426
C313 CU3531

CU3547

C314

C317

CU3531

Description

Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip Tantalum
Chip C
Electrolytic C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip Tantalum
Chip Tantalum
Chip C
Chip Tantalum
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C

Chip C
Chip C
Chip C
Chip C
Chip C
Chip Tantalum
Chip C
Chip C
Chip C
Chip C
Chip Tantalum
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip Tantalum

Parts Name

GRP155B11A104KA01E
GRP155B11H471KD01E
GRP155B11A104KA01E
GRP155B11H471KD01E
GRP155B11A104KA01E
GRP1552C1E22IJD01E
GRP155B11H102KA01E
GRP155B11C103KA01E
GRP155B11H102KA01E
GRP155B11H471KD01E
GRM155B30J105KE18D
GRP1552C1H150JZ01E
GRP1552C1H180JZ01E
GRP155B11E472KD01E
GRP155B11H471KD01E
TMK107BJ105KA-T
GRP155B11A104KA01E
TMCMA0J476MTRF
GRP155B11A104KA01E
10CE150BSS
GRP155B11A104KA01E
GRP155B11C223KD01E
GRP155B11C223KD01E
GRP155B11H102KA01E
GRP155B11H102KA01E
GRP155B11A104KA01E
GRM155B30J105KE18D
TMCMA0J226MTRF
TMCP1C105MTR
GRP155B11H471KD01E
TMCMB1C476MTRF
GRM 155B30J105KE18D
GRP155B11A104KA01E
GRP155B11CI03KA0IE
GRP155B11A104KA01E
GRP155B11A473KA01E
GRP155B11H102KA01E
GRP155B11H471KD01E

GRP155B11H471KD01E
GRP155B11C223KD01E
GRP155B11A333KA01E
GRP155B11A104KA01E
GRP155B11H471KD01E
TMCMA0J476MTRF
GRP155B11H471KD01E
GRP155B11H471KD01E
GRP155B11H471KD01E
GRP155B11H471KD01E
F931A106MAA
GRP155B11H471KD01E
GRP155B11C103KA01E
GRP155B11C103KA01E
GRP155B11H102KA01E
GRP155B11H471KD01E
GRP155B11H471KD01E
GRP155B11H471KD01E
GRP155B11A104KA01E
TMCMA0J476MTRF

Model :DJ-V47

Version

27

Ref.

Parts No.

No.
C322 CU3554

CU3547

C323
C324 CU3547
C325 CU3531

CE0436

C326
C327 CU3133
C328 CU3531
C331 CU3535
C332 CU3554
C334

NC
C334 CU3502
C334

CU3504
C336 CS0396
C347 CU3531
C349 CU3559
C350 CU3559
C351 CU3133
C352 CU3531
C353 CU3531
C354 CU3531
C355

CS0398
C356 CU3547
C357

NC
C358 NC
C359 CU3531
C360 CU3531
C362 CU3531
C363 CU3531
C372 CU3531
CN101 NC L109 QC0804
CN102 NC L110
CN103 UE0506
D101 XD0339
D102 XD0419
D103 XD0339
D104

NC L115
D105 XD0251
D106 NC
D107 NC
D108 XD0422
D109 XD0403
D110 XD0403
D111 NC L123 QC0766
D112

XD0339
D113 XD0339
D114 XD0339
D115 XD0403
D116 XD0403
D117 XD0403
D118

XD0403
D119 XL0097
D120 XD0338
D121 XD0419
D122 XD0424
D123 XD0420
D124 XD0338
D125 XD0420
D126 XL0036
D127 XL0036
D128 XL0036

Description

Chip C
Chip C
Chip C
Chip C
Electrolytic C
Chip C
Chip C
Chip C
Chip C

Chip C
Chip C
Chip Tantalum
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip C
Chip Tantalum
Chip C

Chip C
Chip C
Chip C
Chip C
Chip C

Connector
Diode
Diode
Diode

Diode

Diode
Diode
Diode

Diode
Diode
Diode
Diode
Diode
Diode
Diode
Chip LED
Diode
Diode
Diode
Diode
Diode
Diode
Chip LED
Chip LED
Chip LED

Parts Name

GRP155B11A104KA01E D129 XL0036
GRP155B1ICI03KA0IE
GRP155B11C103KA01E D131 XL0036
GRP155B11H471KD01E D132

16CE47BSS D133 XD0418
TMK107BJ105KA-T
GRP155B11H471KD01E D135 XD0377
GRP155B11H102KA01E FL101 XF0073
GRP155B11A104KA01E FL102

GRP1554C1 HI R0CZ01E
GRP1553C1H3R0CZ01E
TMCP1D104MTR
GRP155B11H471KD01E IC104 XA1120
GRM155B30 J105KE18D IC105
GRM155B30 J105KE18D IC106 XA0210
TMK107BJ105KA-T
GRP155B11H471KD01E
GRP155B11H471KD01E
GRP155B11H471KD01E IC110
TMCP0J225MTR
GRP155B11C103KA01E

GRP155B11H471KD01E
GRP155B11H471KD01E L104
GRP155B11H471KD01E L106 QC0749
GRP155B11H471KD01E L107
GRP155B11H471KD01E

AXK520135P L111 QC0803

1 SV308(TPH3) L112 QC0773

1SS400TE61 L113

1 SV308(TPH3)

MA741WA-(TX) L116

HSC277TRF-E L120

1SV314(TPH3,D

1SV314(TPH3,D

1 SV308(TPH3) L124

1 SV308(TPH3) L125 QC0757

1 SV308(TPH3) L126

1SV314(TPH3,F) L127 QC0768

1SV314(TPH3,F)

1SV314(TPH3,F)

1SV314(TPH3,F) L130
SML-521MUWT86 L131

1 SS362(TE85L)

1SS400TE81 L137
S3JB-T

FA3J3STP

1 SS362(TE85L) Q101

FA3J3STP Q102 XE0071
SML-310MTT86
SML-310MTT86 Q104 XT0180
SML-310MTT86 Q105 XT0180

Version

TA2
T, E, EUK
TA1

Ref.

Parts No.

No.

D130 XD0416

XL0036

D134 XD0418

NC

XC0060

FL103
IC101 XA1107
IC102

XA1106

IC103

XA0404

XA1117

XAH 18

IC107
ICI08

XA1106

ICI09

XA1121
XAH 19

JKIOI

UJ0060
UJ0061

JK102

QS401405

L101
L102 QS401405

QS401405

L103

QS4011Z4

QC0801

L108 QS30200D

QC0763

QS501405
QB0057

L114

QB0057

QC0804
L117 QC0860
L118

QB0057

QC0812

QC0803

L121

QC08I7

L122

QC0768

QC0755

QC0757

L128
L129 QC0755

QC0820

QC0842

QC0812

L138

QC0812
LCD101

EL0059
MIC101

EY0017

XT0210

Q103

XE0070

Description

Chip LED
Diode
Chip LED
Chip LED
Diode
Diode
Diode
MCF

Filter
IC
IC
IC
IC
IC
IC
IC
IC
IC
IC
Jack
Jack
Coil
Coil
Coil
Coil
Chip Inductor
Chip Inductor
Coil
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Coil
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
Chip Inductor
LCD
Microphone
Transistor
FET
FET
Transistor
Transistor

Parts Name

SML-310MTT86
1 SS423(TE85L,F)
SML-310MTT86
SML-310MTT86
RB521S-30TE61
RB521S-30TE61
MAZS0270HL
38M15B5F

ALFYM450F=K
MB15E07SR
LM2902PWR
TA31136FN(EL)
S80845CLNB-B68-T2G
S24CS64A01-J8T1G
NJM2070M T1
M62429FP/CF0J
LM2902PWR
M38268MCA-076GP#l)0
XC6202P502MR
HSJ1594-010150
LD-0208-1.3

0.40-1.4-5TL

0.40-1.4-5TL

0.40-1.4-5TL
E2-0.4-1.1-4TL
C1608CB1N5K
MLG1005S12NJT

0.30-2.0-13TL
MLG1005S22NJT
C1608CB68NJ
MLG1005S18NJT
C1608CBR47J
E2-0.5-1.4-5TL
MPZ1608S101AT
MPZ1608S101AT
MLG1005S22NJT
C2012H10NH
MPZ1608S101AT
MLG1005SR10JT
MLG1005S18NJT
MLG1005SR27JT
C1608CBR12J
C1608CBR18J
C1608CB22NJ
C1608CB15NJ
C1608CBR18J
C1608CB22NJ
C1608CB15NJ
LB2518T151K
LB2518T221K
MLG1005SR10JT
MLG1005SR10JT
LCD DJ170
OB-27P44
2SC6026MFV-GR
2SK3476(TE12UQ)
2SK3475(TE12L,F)
2SC5066FT-Y (TE85L)
2SC5066FT-Y (TE85L)

Model: DJ-V47

Version

28

Ref.

Parts No.

No.
Q106

NC R116

Q107

XT0213

Q108

XT0180

Q109

NC R119 RK3566
XT0180

QUO

QUI

XT0214
XU02I0

Ql 12

Q113

XT0180

Q114

XE0053

Q115

XT0213

Q116

XE0053

Ql 17

XU0210
XT0180

Q118
Ql 19

XT0213

Q120

XT0210

Q121

XU0212
XU0210

Q122
Q123

NC R133 RK3550
XU0220

Q124

XU02I0

Q125

XU02I0

Q126

XU0220

Q127
Q128

XT0210

Q129

XT0210

Q130

XT0170

Q131

XT0210

Q132

XT0170

Q133

XE0069

Q134

XU0210

Q135

XT0214

Q136

XT0170

Q137

XT0212

Q138

XT0212

Q139

XT0214
XT0212

Q140
Q141

XT0210

Q142

XU0213
XU0213

Q143

XU0210

Q144

XU0211

Q145
Q146

XU0213

Q147

XE0069

Q148

XE0069

Q149

XT0210
XU02I1

Q152

XU02I1

Q153
R101

RK3534

R102

RK3545
RK3550

R103
R104

RK3501

R105

NC

R106

NC R169 RK3550

R107

RK3526
RK3534

R108
RI 09

RK3030

R111

RK3542

R112

RK3556

R113

RK3548

R114

NC R176 RK3570

R115

NC R177 RK3562

Description

Transistor
Transistor

Transistor
Transistor
Transistor
Transistor

FET

Transistor

FET
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor

Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor

FET
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor

FET

FET
Transistor
Transistor
Transistor

Chip R

Chip R

Chip R

Chip R

Chip R

Chip R

Chip R

Chip R

Chip R

Chip R

Parts Name

2SC5659T2L
2SC5066FT-Y (TE85L) R118 RK3526

2SC5066FT-Y (TE85Ü R120 NC
HN2C01 FE-GR(T5L.F) R121 RK3538
RN1107MFV(TPL3) R122 RK3542
2SC5066FT-Y (TE85L) R123 RK3522
3SK293 TE85L R124 RK3526
2SC5659T2L
3SK293 TE85L R126 RK3562
RN1107MFVCTPL3)
2SC5066FT-Y (TE85L)
2SC5659T2L R129
2SC6026MFV-GR R130 NC
RN2115MFVCTPL3) R131 RK3552
RN1107MFV(TPL3) R132 RK3530

RN2111MFV(TI-P3) R136 RK3538
RN1107MFV(TPL3) R137 RK3553
RN1107MFV(TPL3) R137 RK3554
RN2111MFV(TI_P3) R137 RK3556
2SC6026MFV-GR
2SC6026MFV-GR R139 RK3550
2SB766A-(TX)R R140
2SC6026MFV-GR R141 RK3555
2SB766A-(TX)R R142
SSM3K15FVCTPL3.Z)
RN1107MFVCTPL3)
HN2C01FE-GR(T5L.F) R145 RK3550
2SB766A-(TX)R R146
2SA1955FV-ACTPL3) R147 RK3526
2SA1955FV-A(TPL3) R148 RK3542
HN2C01 FE-GR(T5I_F)
2SA1955FV-ACTPL3) R150 RK3567
2SC6026MFV-GR R151 NC
RN1111MFV(TPL3),F R152 RK3542
RN1111 MFV(TPL3),F R152 RK3543
RN1107MFVCTPL3) R154 RK3570
RN2107MFVÇTPL3)
RN1111 MFV(TPL3).F
SSM3K15FVCTPL3.Z)
SSM3K15FVCTPL3.Z)
2SC6026MFV-GR R161 RK3538
RN2107MFV(TPL3) R162 RK3564
RN2107MFV(TPL3) R163 RK3522
ERJ2GEJ471X R164 RK3550
ERJ2GEJ392X R165
ERJ2GEJ103X R166 RK3526
ERJ2GE0R00X R167 RK3542

ERJ2GEJ101X
ERJ2GEJ471X R171
MCR03EZHJ221 R172 RK3501
ERJ2GEJ222X
ERJ2GEJ333X R174 RK3530
ERJ2GEJ682X R175 RK3550

Version

Ref.

Parts No.

No.

RK3022

R117

RK3530

R125

NC

R127

RK3562

R128 RK3550

RK3574

R138 RK3562

RK3501

RK3550
R143 RK3546
R144

RK3501

RK3537

R149 RK3532

RK3542

R155
R156 RK3538
R157

RK3550
R159 RK3539

RK3544

R168

NC

R170 RK3530

RK3526

R173 RK3564

Description

Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

Parts Name

MCR03EZHJ470
ERJ2GEJ221X
ERJ2GEJ101X
ERJ2GEJ224X

ERJ2GEJ102X
ERJ2GEJ222X
ERJ2GEJ470X
ERJ2GEJ101X

ERJ2GEJ104X
ERJ2GEJ104X
ERJ2GEJ103X
ERJ2GEJ105X

ERJ2GEJ153X
ERJ2GEJ221X
ERJ2GEJ103X
ERJ2GEJ102X
ERJ2GEJ183X
ERJ2GEJ223X
ERJ2GEJ333X
ERJ2GEJ104X
ERJ2GEJ103X
ERJ2GE0R00X
ERJ2GEJ273X
ERJ2GEJ103X
ERJ2GEJ472X
ERJ2GE0R00X
ERJ2GEJ103X
ERJ2GEJ821X
ERJ2GEJ101X
ERJ2GEJ222X
ERJ2GEJ331X
ERJ2GEJ274X

ERJ2GEJ222X
ERJ2GEJ272X
ERJ2GEJ474X
ERJ2GEJ222X
ERJ2GEJ102X
ERJ2GEJ103X
ERJ2GEJ122X
ERJ2GEJ102X
ERJ2GEJ154X
ERJ2GEJ470X
ERJ2GEJ103X
ERJ2GEJ332X
ERJ2GEJ101X
ERJ2GEJ222X

ERJ2GEJ103X
ERJ2GEJ221X
ERJ2GEJ101X
ERJ2GE0R00X
ERJ2GEJ154X
ERJ2GEJ221X
ERJ2GEJ103X
ERJ2GEJ474X
ERJ2GEJ104X

Ref.

Parts No. Description Parts Name Version

No.

RK3550

R178
R179

RK3538
R180 RK3501
R181 RK3550
R182 RK3566
R183

NC R246 RK3562
R184 NC R247 RK3559
R185 RK3562
R186 RK3550
R187 RK3526
R188 RK3538
R189 RK3538
R190 RK3530

RK3550

R191
R192

RK3558
R193 RK3562
R194 RK3522
R195 RK3558
R196 RK3558

RK3574

R197

RK3574

R198
R199 RK3555
R200 RK3560
R201 RK3522
R202

RK3538
R203 RK3566
R204 RK3574

RK3574

R205
R206 RK3558
R207

RK3558
R208 NC R273 RK3566
R209 RK3574
R210 RK3522
R211 RK3558
R212 RK3550
R213 RK3558
R214 RK3564
R215 RK3561
R216

RK3538
R218 RK3558
R219 RK3564
R220

RK3553
R221

RK3548
R222 RK3558
R223 RK3550
R224 RK3550

RK3554

R225

RK3554

R226
R227 RK3559
R228 RK3550
R229 RK3550
R230 RK3567
R231

RK3538
R232 RK3566
R234 RK3550

RK3562

R235

RK3562

R236
R237 RK3522
R238 RK3550

RK3567

R239

Chip R
Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

ERJ2GEJ103X R240 RK3562
ERJ2GEJ102X
ERJ2GE0R00X
ERJ2GEJ103X
ERJ2GEJ224X R245 RK3544

ERJ2GEJ104X
ERJ2GEJ103X
ERJ2GEJ101X R250 RK3550
ERJ2GEJ102X
ERJ2GEJ102X R252 RK3561
ERJ2GEJ221X R253 RK3566
ERJ2GEJ103X R254 RK3550
ERJ2GEJ473X
ERJ2GEJ104X
ERJ2GEJ470X R257
ERJ2GEJ473X R258 RK3574
ERJ2GEJ473X
ERJ2GEJ105X
ERJ2GEJ105X R261
ERJ2GEJ273X R262 RK3562
ERJ2GEJ683X R263 RK3562
ERJ2GEJ470X
ERJ2GEJ102X R265 RK3536
ERJ2GEJ224X R266
ERJ2GEJ105X
ERJ2GEJ105X
ERJ2GEJ473X R270 RK3560
ERJ2GEJ333X R272

ERJ2GEJ105X R274 RK3544
ERJ2GEJ470X
ERJ2GEJ473X R276 RK3560
ERJ2GEJ103X R277 RK3552
ERJ2GEJ473X R278 RK3562
ERJ2GEJ154X R279
ERJ2GEJ823X R280 RK3556
ERJ2GEJ102X R281 RK3017
ERJ2GEJ473X R282 RK3514
ERJ2GEJ154X R283 RK3554
ERJ2GEJ183X R284
ERJ2GEJ682X R285 RK3550
ERJ2GEJ473X R286 RK3570
ERJ2GEJ103X R287 RK3550
ERJ2GEJ103X R288 RK3550
ERJ2GEJ223X
ERJ2GEJ223X R290 RK3017
ERJ2GEJ563X R291 RK3551
ERJ2GEJ103X R292 RK3569
ERJ2GEJ103X R293 RK3532
ERJ2GEJ274X R294 RK3562
ERJ2GEJ102X
ERJ2GEJ224X R296
ERJ2GEJ103X
ERJ2GEJ104X
ERJ2GEJ104X
ERJ2GEJ470X
ERJ2GEJ103X R301 RK3501
ERJ2GEJ274X

Ref.

Parts No. Description Parts Name Version

No.

R242 RK3501
R243 RK3550
R244 RK3564

R248 RK3538
R249 RK3566

R251 RK3562

R255 RK3563
R256 RK3562

RK3538

R259 RK3566
R260 RK3553

RK3574

R264

RK3558

RK3518

R267

NC
RK3532

R269

RK3550

R275 RK3566

RK3558

RK3561

R289 RK3565

R295 RK3538

RK3530

R297

RK3546

R298 RK3549

RK3544

R299
R300

RK3538

R302 RK3538

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

Model :DJ-V47

ERJ2GEJ104X
ERJ2GE0R00X
ERJ2GEJ103X
ERJ2GEJ154X
ERJ2GEJ332X
ERJ2GEJ104X
ERJ2GEJ563X
ERJ2GEJ102X
ERJ2GEJ224X
ERJ2GEJ103X
ERJ2GEJ104X
ERJ2GEJ823X
ERJ2GEJ224X
ERJ2GEJ103X
ERJ2GEJ124X
ERJ2GEJ104X
ERJ2GEJ102X
ERJ2GEJ105X
ERJ2GEJ224X
ERJ2GEJ183X
ERJ2GEJ105X
ERJ2GEJ104X
ERJ2GEJ104X
ERJ2GEJ473X
ERJ2GEJ681X
ERJ2GEJ220X

ERJ2GEJ331X
ERJ2GEJ683X
ERJ2GEJ333X
ERJ2GEJ224X
ERJ2GEJ332X
ERJ2GEJ224X
ERJ2GEJ683X
ERJ2GEJ153X
ERJ2GEJ104X
ERJ2GEJ473X
ERJ2GEJ333X
MCR03EZHJ180
ERJ2GEJ100X
ERJ2GEJ223X
ERJ2GEJ823X
ERJ2GEJ103X
ERJ2GEJ474X
ERJ2GEJ103X
ERJ2GEJ103X
ERJ2GEJ184X
MCR03EZHJ180
ERJ2GEJ123X
ERJ2GEJ394X
ERJ2GEJ331X
ERJ2GEJ104X
ERJ2GEJ102X
ERJ2GEJ221X
ERJ2GEJ472X
ERJ2GEJ822X
ERJ2GEJ332X
ERJ2GEJ102X
ERJ2GE0R00X
ERJ2GEJ102X

30

Ref.

Parts No. Description Parts Name Version
No.

RK3550

R303
R304

RK3546
R305

RK3550 Chip R
R306

RK3550 Chip R
R308

RK3574

RK3574

R309
R310 RK3550
R311 RK3550
R312 RK3570
R313 RK3550
R314 RK3554
R315 RK3542
R316 RK3550 Chip R
R317

RK3570
R318 RK3550
R319 RK3554

RK3574

R320
R321 RK3550
R322 RK3568
R323 RK3550
R324 RK3548
R325 RK3559
R326 RK3559
R327 RK3550
R328 RK3550
R330 RK3546
R331 RK3546
R332

RK3546
R333 RK3546
R334 RK3562

RK3562

R335
R336 RK3562
R337 RK3550
R338 RK3542
R339 RK3550 Chip R
R340 RK3550
R341 RK3550
R342 RK3538
R343

RK3550
R344 RK3537
R345

RK3558

RK3537

R346
R347

NC

RK3552

R348
R349 NC TC101 NC
R350 RK3562
R351 RK3550
R352 NC VR102 RH0233
R353

RK3546
R354 RK3550
R355 RK3550
R357

RK3501
R358

NC
R359

NC W103 NC
R360

NC W103 MACLH2GG
R361 NC X101 NC
R362 RK3536
R363 RK3558
R364 RK1018
R365 RK3546 Chip R

Chip R
Chip R

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

Chip R

Chip R
Chip R

Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R

ERJ2GEJ103X
ERJ2GEJ472X R367

ERJ2GEJI03X
ERJ2GEJ103X

ERJ2GEJ105X R370 RK3501
ERJ2GEJI05X
ERJ2GEJI03X
ERJ2GEJI03X
ERJ2GEJ474X R374 RK3562
ERJ2GEJI03X
ERJ2GEJ223X R376 RK3562
ERJ2GEJ222X R377 RK3562
ERJ2GEJI03X

ERJ2GEJ474X R379 RK3562
ERJ2GEJ103X
ERJ2GEJ223X
ERJ2GEJ105X R382
ERJ2GEJ103X
ERJ2GEJ334X R385
ERJ2GEJI03X
ERJ2GEJ682X R385 RK3059
ERJ2GEJ563X R385
ERJ2GEJ563X
ERJ2GEJI03X
ERJ2GEJ103X R387 NC
ERJ2GEJ472X R388
ERJ2GEJ472X R392
ERJ2GEJ472X
ERJ2GEJ472X R394
ERJ2GEJ104X
ERJ2GEJ104X
ERJ2GEJ104X R398 RK3566
ERJ2GEJI03X
ERJ2GEJ222X R402 RK3501

ERJ2GEJ103X
ERJ2GEJI03X
ERJ2GEJ103X R405 RK3542

ERJ2GEJI02X
ERJ2GEJ103X R407 RK3562
ERJ2GEJ821X
ERJ2GEJ473X
ERJ2GEJ821X SW101 UU0041

ERJ2GEJ153X

ERJ2GEJI04X
ERJ2GEJI03X

ERJ2GEJ472X VR103 RH0225
ERJ2GEJ103X VR104 RH0225
ERJ2GEJ103X VR105 RH0225
ERJ2GE0R00X W101 MPCL07AA

ERJ2GEJ681X
ERJ2GEJ473X
ERJ8GEYJ101V X104 XQ0184
ERJ2GEJ472X

Ref.

Parts No. Description Parts Name Version

No.

RK3566

R366

RK3558
R368 RK3548
R369

RK3538 Chip R

R371 RK3546
R372 RK3550
R373 RK3546

R375 RK3550

R378 RK3566 Chip R ERJ2GEJ224X

R380

RK3566

RK3554

R381

NC
R384 RK3058

NC
R385 RK3038

RK3064

NC

R386
R386

RK3038

RK3550

RK3550

RK3534

R393

RK3530
R395 RK3556
R396 RK3556

R401 RK3501

R403 RK3570 Chip R
R404 RK3550

R406 RK3546

R409

RK3534

RK0107

R410

SW102 UU0041

UU0041

SW103

TH101 XS0052
VR101 RH0233

W102

MACL07AA

X102

XQ0194

X103 XK0004

UP0541 PCB DJ170 INTEGRATED

Chip R
Chip R
Chip R ERJ2GEJ682X

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R

Chip R

Chip R
Chip R
Chip R

Chip R

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Chip R

Chip R
Chip R
Chip R
Chip R
Chip R
Chip R
Switch
Switch
Switch

Thermistor
Trimmer R
Trimmer R
Trimmer R
Trimmer R
Trimmer R
Wire
Wire

Wire

Crystal
Discriminator
Crystal

ERJ2GEJ224X
ERJ2GEJ473X

ERJ2GEJ102X
ERJ2GE0R00X

ERJ2GEJ472X
ERJ2GEJI03X
ERJ2GEJ472X
ERJ2GEJI04X
ERJ2GEJ103X
ERJ2GEJI04X
ERJ2GEJ104X

ERJ2GEJ104X
ERJ2GEJ224X
ERJ2GEJ223X

MCR03EZHJ473

MCR03EZHJI02
MCR03EZHJ563
MCR03EZHJI54

MCR03EZHJI02

ERJ2GEJ103X
ERJ2GEJ103X
ERJ2GEJ471X
ERJ2GEJ221X
ERJ2GEJ333X
ERJ2GEJ333X
ERJ2GEJ224X
ERJ2GE0R00X
ERJ2GE0R00X

ERJ2GEJ474X
ERJ2GEJI03X
ERJ2GEJ222X
ERJ2GEJ472X
ERJ2GEJ104X
ERJ2GEJ471X
ERJ6GEY0R00V
EVQP4203M
EVQP4203M
EVQP4203M

NTCG104LH104JT1
RH02B1C15X
RH02B1C15X
RH02B1CS3X
RH02B1CS3X
RH02B1CS3X
#30P02-070-02
#30A02-070-02

#30AH1-025-H1

NT3225SA12.8M
CDBLB450KCAY24-B0
AT49 3.6864M

Model: DJ-V47

T
TA2
TA1

E, EUK
T, E, EUK
TA1.TA2

TA1.TA2
T, E, EUK

31

Ref.

Parts No. Description Parts Name Version

No.

FM0265A HEAT SINK DJ170
TS0183
TZ0049 SILICON DUMPER

VCO CASE

VCO CASE

Model: DJ-V47

Mechanical Unit

Ref.

Parts No.

No.

AF0018
AF0030 XQN2+A6FN(58364-0001

AP0039
AX0004Z

DG0046

DP0183

FG0392 WATERPROOF

FG0418

FG0419 WATERPROOF RUBBER

FG0423 JACK CAP DJ170

FG0424

FG0426 MIC RUBBER

FP0254

FP0255

FP0284 BUND SEAL

NK0081 VOL KNOB

SP0013 LECTRA #7800

ST0089 LCD HOLDER
TL0033
YX0039 LCD TAPE DJS45

Description

Parts Name

XQN2+C4FZ

PH P2+20 FE/3BBC
PT 3P 2X8 BBC AX0004
LCD UGHT
LCD PANNEL DJV47

LCD RUB CONE

0 RING (R COVER)

REAR COVER
ROCK LEVER

REFLECTIVE SHEET

Packing Unit

Ref.

Parts No. Description Parts Name Version

No.

EA0143

EA0144

EA0152

EG0062 BATTERY E BP-65 P BAG

EG0065 BATTERY EBP-65A P BAG T , E , EUK

EDC146 ADAPTOR ADAPTOR 120V T

EDC147 ADAPTOR ADAPTOR 230V E,T1,T2

EDC148 ADAPTOR ADAPTOR 230V (UK) EUK

PR0478

DS0446 NITTO MODEL PLATE(S)

PR0447 WARNING FCC (N)

PR0452 FCC HOME USE T

HU0234

PS0520B

PH0015

PK0116 CIRCUIT DIAGRAM V47

HK0646

HP0031 PLA.BAG 5X100X200

AA0076 PH M3+6FE/B-ZN

BB0009Y HAND STRAP HAND STRAP DJS41

BH0017 BELT CLIP BELT CLIP

HP0003

ANTENNA EA0143 T , E , EUK
ANTENNA
ANTENNA EA0152 T1

INSTRUCTION MANUAL

EA0144 T2

SERIAL SEAL

INNER DJ170
INSTRUCTION DJV17

WARRANTY CEAT EXPORT

INDIVIDUAL BOX V47

PLA.BAG 5X75X110

Model: DJ-V47

Version

Model :DJ-V47

T1.T2

T

T

32

CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY

AN INCORRECT TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.

ADJUSTMENTS

1) Required Test Equipment

The following items are required to adjust radio parameters

Test Equipment

1. Regulated power supply Supply voltage 13.8 DC
Current 3A or more

2.Digital multimeter Voltage range
Current 10A or more
Input resistance High impedance

3.Oscilloscope Measurable frequency

4.Audio dummy load Impedance 8Q
Dissipation 1W or more
Jack 3.5mm$

5.SSG

6.Power meter

7.Audio voltmeter

Output frequency 200MHz or more 500MHz or more
Impedance 50Q, unbalanced
Modulation FM
Measurable frequency
Impedance 50Q, unbalanced
Measuring range 10W or more
Measurable frequency Up to 100kHz

DJ-V17 DJ-V47

FS = Approx. 20V

Audio frequency

200MHz or more 500MHz or more

Sensitivity 1mV to 10V

8.Audio generator Output frequency 67Hz to 10kHz
Output impedance 600Q, unbalanced

9.Distortion meter/SINAD meter

10.Frequency counter

11.Linear detector

12. DC Ammeter Current 3A or more

Measurable frequency
Input level
Distortion 1%-100%
Measurable frequency
Measurable stability
Measurable frequency
Characteristics
CN 60dB or more

200MHz or more 500MHz or more

200MHz or more 500MHz or more

1kHz

Up to 40dB

Approx. ±0.1 ppm

Flat

33

Note:

(1). SSG initial setting

Modulation Frequency: 1kHz

Modulation Level:3.5kHz
(2). Necessary optional accessory: EDS-10 ( Microphone/SpeakerCable)
(3). Reference sensitivity: 12dB SINAD
(4). Specified audio output level: 500mW at 8Q
(5). Standard audio output level: 50mW at 8Q
(6). Use an RF cable ( 3D2W:1M ) for test equipment.
(7). Attach a fuse to the RF test equipment.
(8). All SSG outputs are indicated by EMF
(9). Supply voltage for the transceiver: 13.8VDC

2)Preparation:

1. Turn off the power of the adjusting unit (the unit hereafter).

2. Remove the screw © .

3. Remove the rear cover (D.

4. Remove the wire (D. Keep the wire aside as it will be necessary later. This operation is necessary for the

DJ-V17E, DJ-V47E and DJ-V47EUK.

5. Turn on the unit by pressing “F” key and “V/M” key together. The display will be blank out for 2 seconds

then comes back normal.

I ROTMHf EM3O0t )

Chart 1 : Removing the rear cover

©

34

3) Adjustment mode

The adjustment should be operated in the Adjustment mode. Therefore except for the reference frequency,
deviation and tone-deviation adjustments an operator won’t touch the components on the board, but most
of the adjustments should be done by operating the dial and keys on the unit. During such operation,

memory channels are used temporary therefore it is required to program memories before the unit is set to

the adjustment mod. Please refer the chart below for the programming channels. The frequencies may be
varied within the range of ±0.2MHz depending on the RF environment around your work area, and refer

the instruction manual for how to program the memories into the memory-channels.
To enter the adjustment mode, press “F” then “KL” to key-lock the unit. Then press the numeric keys in
order of “4”, “9”, “0”, “2”, “1” and “7”. Observe that decimal points appear on the display below 100MHz
and 10MHz digits. To exit from the adjustment mode, repeat the whole sequence (key-lock then enter the
code in order). NEVER RESET THE UNIT WHILE OPERATING IN THE SET MODE. This may reset whole
adjustment values resulting the malfunction of the unit in the operating mode. The chart below shows the
adjustment points and interface between the unit and instruments. Please use an attenuator in case the
specifications of the linear-detector and frequency counter may exceed the requirement herein.

io ftenora loT

VR10 3 Waveform A d just-

io Huit1/

IDS-10 (Micropone/Speakser Cable )

< ROTARY 1

(f

k!2

■is

*103 ®

m

J

01

ATT( AI tenuulo r )'

ATTC A L lenuatci r )

Linear dfileclo

HM Fre qu e nc y Court I at

■ TC101 Frequency Adjust

■ V R 101 Ton e D e vlati o n A d ju s t

Chart 2 : Adjustment points and interface between the unit and instruments

35

Table 1 : Memory programming for adjustment mode

* Simply memory the frequencies only into the relative memory channels.

Frequency

Channel Adjustment menu

1

Frequency Adjustment 145.000 162.000 415.000 435.000 445.000 460.000
2 TX-output / High power 145.000 162.000 415.000 435.000 445.000 460.000
3 TX-output / Low power 145.000 162.000 415.000 435.000 445.000 460.000
4

Microphone deviation
5 Check DTMF tone [1] 145.000 162.000 415.000 435.000 445.000 460.000
6 Check DTMF tone [D] 145.000 162.000 415.000 435.000 445.000 460.000
8 CTCSS tone deviation 145.000 162.000 415.000 435.000 445.000 460.000

10 Check DCS deviation 145.000 162.000 415.000 435.000 445.000 460.000
11

Check Tone-burst tone deviation 145.000 162.000 415.000 435.000 445.000 460.000

12 Secsitivity adjustment (lower edge) 130.000 401.000
13 Secsitivity adjustment (center of) 145.000 150.000 420.000 435.000 445.000 460.000
14 Secsitivity adjustment (Upper edge) 173.000 459.000 479.000
15 Secsitivity adjustment (minimum) 145.000 162.000 415.000 435.000 445.000 460.000
16 Secsitivity adjustment (maximum) 145.000 162.000 415.000 435.000 445.000 460.000
17 S-meter adjustment (1) 145.000 162.000 415.000 435.000 445.000 460.000
18 S-meter adjustment (Full) 145.000 162.000 415.000 435.000 445.000 460.000
19 ATT (Attenuator) adjustment

24 Low-battery icon appearance (Li-ion) 145.000 162.000 415.000 435.000 445.000 460.000

Low-battery icon appearance

25

DJ-V17 DJ-V47

T, E, EUK TFH, R T1 E, EUK T T2

145.000 162.000 415.000 435.000 445.000 460.000

145.000 162.000 415.000 435.000 445.000 460.000

145.000 162.000 415.000 435.000 445.000 460.000

1. Frequency adjustment

Select memory ch.1.
Press PTT on the unit to transmit and measure the TX frequency. Align TC101 to bring the value to the
range specified below.

Specification value :

-------------

Specification value

Necessary instrument : Frequency counter

-

------

DJ-V17 DJ-V47

±50Hz

2.TX output - High power

Select memory ch.2.
Press PTT on the unit to transmit. One of digits 10-1F should appear on the display where memory
channel number was shown. Rotate the dial on the unit to adjust the TX power to meet the specification.
Release the PTT to finish the adjustment. Be sure to check the consuming current value after the
adjustment Is completed.

Specification :

TX-output power/High
Current consumption

DJ-V17

5.0 V

vatts

1,5A or less 1,8A or less

DJ-V47

36

Necessary instrument : DC Ammeter / Power meter

3. TX output - Low power

Select memory ch.3.
Press PTT on the unit to transmit. One of digits 0-F should appear on the display where memory channel
number was shown. Rotate the dial on the unit to adjust the TX power to meet the specification. Release
the PTT to finish the adjustment. Be sure to check the consuming current value after the adjustment is
completed.

Specification :

DJ-V17 DJ-V47

TX-output power/Low

Necessary instrument : Power meter

0.8 watts

4. Microphone deviation

Select memory ch.4.
Input the signal as specified below from an Audio generator and transmit. Measure the deviation value
using a Liner-detector. Align VR104 to bring the value to the range specified below.

Specification :

-------

--------

Microphone deviation

DJ-V17 DJ-V47

4.3±0.1kHz

Measuring condition :
(1). Audio generator setting

Frequency: 1kHz

Output Level: 50mV

Necessary instrument : Audio generator / Linear detector

Optional accessory required : EDS-10

5. Check DTMF tone [1] deviation

Select memory ch.5.
Press PTT to automatically transmit DTMF tone [1j. Make sure the value is within the specification.

Specification :

DJ-V17 DJ-V47

DTMF tone [1] deviation

Necessary instrument : Linear detector

2.4~3.6kHz

6. Check DTMF tone [D] deviation

Select memory ch.6.
Press PTT to automatically transmit DTMF tone [D]. Make sure the value is within the specification.

Specification :

DJ-V17 DJ-V47

DTMF tone [D] deviation

2.4~3.6kHz

Necessary instrument : Linear detector

37

7. CTCSS tone 88.5Hz deviation and adjustment of the sign-wave

Select memory ch.8.
Press PTT to automatically transmit 88.5Hz tone. Measure the deviation value using a Liner-detector.
Align VR101 to bring the value to the range specified below. Use an oscilloscope to monitor the sign-wave
then correct the wave shape (see the chart 3 below). Use VR103 to correct the wave shape if necessary.

OK

NG

NG

Chart 3: sign-wave correction

Specification :

MODEL

DJ-V17

T/E/EUK TFH/R

CTCSS tone 88.5Hz deviation 0.80±0.05Hz 0.90±0.05Hz 0.80±0.05Hz

DJ-V47

Necessary instrument : Linear detector / Oscilloscope

8. Check DCS deviation (255)

Select memory ch. 10.
Press PTT to automatically transmit DCS tone (255). Make sure the value is within the specification using
a linear-detector.

Specification :

DJ-V17 DJ-V47

DCS deviation (255)

Necessary instrument : Linear detector

0.7-1.2kHz

9. Check Tone-burst tone 1750Hz deviation

Select memory ch.11.
Press PTT to automatically transmit a tone-burst tone 1750Hz. Make sure the value is within the
specification using a linear-detector.

Specification :

DJ-V17 DJ-V47

1750Hz Deviation

2.6~3.4kHz 2.4~3.6kHz

38

Necessary instrument : Linear detector

10. Receiver sensitivity adjustment

Preparation : Set the speaker audio output level to 50mW.
Operation : There are three points to be adjusted, the lower, central, and upper edges of the receiver’s

covering range. Set the memory channels accordingly. Input an RF signal from the SSG to
the antenna connector then measure output signal at the speaker jack using a SI NAD meter.

Press “F" (FUNC) key on the unit. One of digits 0-FF should appear on the display where
memory channel number was shown. Rotate the dial on the unit to bring the SINAD value to
12dB or better.

a. Lower edge

Condition :
(1). Memory Channel: 12
(2). SSG setting

DEL

MO

DJ-V17 DJ-V47

T/E/EUK TFH/R T1 E/EUK/T/T2
Frequency (MHz) 130.000 401.000
RF Output Level (dB u)
Modulation Frequency (kHz)
Modulation Level (kHz)

-6.0 -5.0 -6.0 -3.0

3.5

b. Center of the covering range

Condition :
(1). Memory Channel: 13
(2). SSG setting

Frequency (MHz) 145.000 150.000 420.000 435.000 445.000 460.000
RF Output Level (dB n) -8.0
Modulation Frequency (kHz) 1
Modulation Level (kHz) 3.5

c. Upper edge

(1). Memory Channel:14
(2). SSG setting

Frequency (MHz)
RF Output Level (dB n) -8.0 -5.0 -6.0
Modulation Frequency (kHz) 1
Modulation Level (kHz) 3.5

MODEL

DJ-V17 DJ-V47

T/E/EUK TFH T1 E/E UK T T2

-6

.0

MODEL

DJ-V47

DJ-V17

173.000 459.000 479.000

T1 E/EUK/T/T2

Necessary instruments : Audio voltmeter / SSG / SINAD Meter / Audio dummy load
Optional accessory required : EDS-10

Note:

Press “FUNC” key or leave the unit for 5 seconds to enter the new values and go to the next adjustment
procedure. Memory number should appear on the display when the unit exits the sensitivity adjustment.

39

11. Squelch adjustments:

Select the memory channel number accordingly to adjust the level Min and Max.
Input an RF signal to the antenna connector from SSG then press FUNC key on the unit. A beep (“pip”)
sounds and completes the adjustment.

a. Squelch level (Min.)

Condition :
(1). Memory Channel: 15
(2). SSG setting

MODEL

DJ-V17 DJ-V47

T/E/EUK TFH T1 E/E UK T T2
Frequency (MHz) 145.000 162.000 415.000 435.000 445.000 460.000
RF Output Level (dB
Modulation Frequency (kHz) 1
Modulation Level (kHz)

b. Squelch level (Max.)

Condition :
(1). Memory Channel: 16
(2). SSG setting

u ) -r

.0

3.5

-1

0.0

MODEL

DJ-V17 DJ-V47

T/E/EUK TFH T1 E/E UK T T2
Frequency (MHz) 145.000 162.000 415.000 435.000 445.000 460.000
RF Output Level (dB
Modulation Frequency (kHz)
Modulation Level (kHz) 3.5

jj ) C

1

Necessary instrument: SSG

12. S-meter adjustments

Select the memory channel number accordingly to adjust the S-meter level 1 and full.
Input an RF signal to the antenna connector from SSG then press FUNC key on the unit. A beep (“pip”)
sounds and completes the adjustment.

a. S-meter level 1

Condition :
(1). Memory Channel: 17
(2). SSG setting

MODEL

DJ-V17 DJ-V47

T/E/EUK TFH T1 E/E UK T T2
Frequency (MHz) 145.000 162.000 415.000 435.000 445.000 460.000
RF Output Level (dB fjt) C
Modulation Frequency (kHz) 1
Modulation Level (kHz) 3.5

40

b. S-meter level Full

Condition:
(1). Memory Channel : 18
(2). SSG setting

MODEL

DJ-V17 DJ-V47

T/E/EUK TFH T1 E/E UK T T2
Frequency (MHz) 145.000 162.000 415.000 435.000 445.000 460.000
RF Output Level (dB u) 20 .0
Modulation Frequency (kHz)
Modulation Level (kHz)

Necessary instrument : SSG

1

3.5

13. Attenuator adjustment

Select the memory ch. 19.
Input an RF signal to the antenna connector from SSG then press FUNC key on the unit.
One of digits 0-FF should appear on the display where memory channel number was shown. Rotate the
dial on the unit to adjust to the point that the S-meter's 3rd segment turns to 4th for DJ-V17, 4th to 5th for
the DJ-V47. It is acceptable if the 4th(V17) or 5th(V47) segment blinks at this moment.

Condition:
(1). SSG setting

MODEL

DJ-V17 DJ-V47

T/E/EUK TFH T1 E/E UK T T2
Frequency (MHz) 145.000 162.000 415.000 435.000 445.000 460.000
RF Output Level (dB u ) 20 .0
Modulation Frequency (kHz) 1
Modulation Level (kHz)

3.5

Necessary instrument : SSG

Note:

(1) Press “FUNC” key or leave the unit for 5 seconds to go to the next adjustment procedure. Memory

number should appear on the display when the unit exits this adjustment point.

(2) The S-meter adjustment should be completed before you perform this operation.

14. Low-battery icon appearance ( Li-ion )

Select the memory ch.24.
Press “F” (FUNC) key on the unit. One of digits 0-FF should appear on the display where memory channel
number was shown. Rotate the dial on the unit to select “67”. The value can be varied by rotating the dial,
but select always 67.

Note:

Press “FUNC” key or leave the unit for 5 seconds to go to the next adjustment procedure.
Memory number should appear on the display when the unit exits this adjustment point.

41

15. Low-battery icon appearance ( Alkaline )

Select the memory ch.25.
Press “F” (FUNC) key on the unit. One of digits 0-FF should appear on the display where memory channel
number was shown. Rotate the dial on the unit to select “69” (DJ-V47:“6A”). The value can be varied by
rotating the dial, but select always 69 (DJ-V47:6A).

Note:

Press “FUNC” key or leave the unit for 5 seconds to go to the next adjustment procedure.
Memory number should appear on the display when the unit exits this adjustment point.

4) Re-assembly

1. Turn off the unit.

2. In case of DJ-V17E, DJ-V47E and DJ-V47EUK, re-solder the wire (D. This sequence is not required for

other versions.

3. According to the instruction below mount the rear-cover (2).

4. Securely screw ® to fix the cover.

5. Turn on the unit by pressing “F" key and “V/M” key together to reset the CPU. The display will be blank

out for 2 seconds then comes back normal.

»3*1

: ROTARY EHCC0F3 ;

&

-l.—fQiJ

Chart 4 : Re-assembly the rear cover

I ® Reassemble the cover

42

PC BOARD VIEW

MAIN SIDE A (DJ-V17)

43

MAIN SIDE B (DJ-V17)

44

MAIN SIDE A (DJ-V47)

45

9fr

S I J in,

Ë b S e "

CE

o

Œ

&

Œ

er 31

~n

f fSäiüäU

33

Im « A W 1®

33

äüjg M gg»

------

S S g s l1

S3 iS

(zwv-ra) g 3ais niviai

SCHEMATIC DIAGRAM (DJ-V17)

0.8V ( 5W TFH/R -155.00MHz)

0.6V (0.8W TFH/R- 155.000MHz)
1,0V (5W T/E -145.000MHz)

1.9V ( 5W TFH/R -155.00MHz)

1.4V ( 0.aW TFH/R-155«» MHz )
2-2V ( 5W T/E -145.000MHz

o

47

-F*.

00

0 )

o

X

m

o

g

>

G)

<

■P*

->i

2.0V { TX ) (DCS : ON)
ÛV ( TX ) (DCS : OFF)

BLOCK DIAGRAM (DJ-V17)

V

CERAMIC FILTER DISCRIMINATOR

J \ FL103 1 _

\ 450KHZ j

T

POWER CONT

<^

------

RECEIVE

^

------

TRANSMIT

^

------

RECEIVE/TRANSMIT

I CPU CONTROL

D101 HSC277
D103 HSC277

o

D113 HSC277

A

POWER AMP BUFFER AMP

-l>

D112HVC132

Q120 2SC6Û26MFV

ÍÍ

D1151SV323

- 0

D116 1SV323

1 i- - 4

— 1>

Q114

3SK293

CTOUT

(TU NV )

T

-W — »

T

—D>

-t>'

T

TX LED

' T SML521MÜW

T

-0

J j D1191/2

D117 1SV323
D1181SV323

—1>

ROTARY ENCODER

0 a 0 0

s 0 0 0
0 0 0 0
□ 0 E s

—>

FL101
FL102

i 21.7MHz I

LOOP FILTER

2nd Local 21,25MHz

T F

DATA

TONE (67-250-3HZ)

RESET

-0 -0 H>

Q132 2SB0766A
Q135HN2C01FE
Q153 RN2107MFV

EXP | = >

¥

RX LED

► D1181/2

T SML521MUW

REFERENCE

Z

--

£tC101

STB
CLK

V

TONE LPF

T

CLONE
MIC INPUT
SPEAKER OUTPUT

T

CPU

10109

T

T F

I T

LAMP

BAT

5V REGULATOR

- > 4

BLOCK DIAGRAM (DJ-V47)

V

T

¥

POWER CO NT

o

D101 1SV308
D103 1SV308
D1131SV3O0

8V308

L

i

W

D112 1SV3O0

-t>

Q120 2SC8028MFV

(AT TC ON T)

Q121 __

RN2115MFV

D1161SV314

-0

D11B1SV314

ft ft

DTOUT

Q104 2SC6066FT Q105 2SC5068FT

MIC AMP I DC SPLATTER FILTER

-----

PT™

H>

0114

3SK293

CTOUT

(TU NV )

H>

« -

D117 1SV314
D118 1SV314

ft

0110

2SC6066FT

H>

c-

T

0106

2SC5066FT

ROTARY ENCOOER

« -

\ FL1Û1 I

\ 38 8 5M Hz/

D109 1SV314
D110 1SV314

« -

e-

CERAMIC FILTER

jJ \ ^103 / _

\45 Q KHz/

2nd Lo aà 38.4MHz

%r~

STB
CLK

DATA

TONE (67-250. JHzJ

T

TRIPLER

T

DISCRIMINATOR

REFERENCE

: VOL102

V

TONE LPF

T

W

Q127
RN2117MFV

CLONE
MIC INPUT
SPEAKER OUTPUT

BATTERY
{ Ni-MH )

BATTERY

( LHon )

^

------ TRANSMIT

^ ------ RECEIVE/TRANSMIT

D123 FA3J3S

D125 FA3J3S

RECEIVE

I CPU CONTROL

D122
S3JB

¥

«

T

7 / 2SA1&55FV

-0

¥
¥

->■4

¥

LAMP

0

0

0

s
□

E

0

0 0

s 0
E 0

0 0

RESET

F

0

BAT

5V REGULATOR

¥

ALINCO, INC.

Head Office: Shin-Dai Building 9th Floor

2 -6 ,1-Chome, Dojimahama, Kita-ku, Osaka 530-0004, JAPAN
Phone: [phone] Fax: [phone]
E-mail: [e-mail]

/

----------------------------
Dealer/Distributor

Copyright Allnco, Inc. Osaka Japan
Printed In Japan
Updated AE3636 (DJ-V17)

AE3637 (DJ-V47)

PM0091

FNNK-NE
