Alesis TransActive Wireless User's Guide

TransActive Wireless

USER GUIDE

ENGLISH ( 3 – 5 )

GUÍA DEL USUARIO

ESPAÑOL ( 6 – 8 )

GUIDE D’UTILISATION

FRANÇAIS ( 9 – 11 )

GUIDA PER L'USO

ITALIANO ( 12 – 14 )

BENUTZERHANDBUCH

DEUTSCH ( 15 – 17 )

USER GUIDE (ENGLISH)

1. Make sure all items listed on the front of this guide are included in the box.

2. READ SAFETY INSTRUCTION BOOKLET BEFORE USING THE

PRODUCT.

3. MAKE SURE THAT YOU HAVE COMPLETELY CHARGED THE BATTERY PRIOR TO FIRST USE FOR MAXIMUM BATTERY LIFE.

4. Study this setup diagram.

5. Make sure all input devices such as microphones, CD players, or MP3 players are turned off and volume settings are set at "zero."

6. Connect all devices as shown.

7. Switch everything on in the following order:

• audio input sources (i.e. microphones, instruments, CD/MP3 Players)

• TransActive Wireless

8. When turning off, always reverse this operation:

• TransActive Wireless

• last, any input devices

Go to www.alesis.com for product registration.

TABLET OR OTHER DEVICE*

*SOLD SEPARATELY

MICROPHONE*

TOP PANEL

RECHARGEABLE BATTERIES

Rechargeable lead-acid batteries are the same type used in automobiles. As with your car battery, how you use this battery has a significant impact on its lifespan. With proper use and treatment, a lead-acid battery can last for years. Here are some recommendations for getting the longest life from the internal battery.

GENERAL USAGE

• FULLY CHARGE THE BATTERY BEFORE USING IT.

• CHARGE THE BATTERY COMPLETELY AFTER EACH USE.

• AVOID COMPLETELY DRAINING THE BATTERY.

• You may leave the unit plugged in for up to two weeks.

• For maximum life, drain the battery 80% once a month.

STORAGE

• Avoid storing in high temperatures and moist places.

• For long-term storage, periodically recharge the battery.

• If you do not charge the battery for six months, it may not charge.

REPAIR

• As the battery nears the end of its life, it may lose its ability to recharge. If this occurs, contact technical support at

DISPOSAL

www.alesis.com/supporthome.

• Bring the unit to a recycling center or dispose of in accordance with local ordinances.

BOX CONTENTS

 TransActive Wireless  Power Cable (standard IEC)  User Guide  Safety Instructions & Warranty

Information Booklet

REAR PANEL

POWER

iPad is a trademark of Apple Inc., registered in the U.S. and other countries.

The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Alesis is under license. Other trademarks and trade names are those of their respective owners.

DIAGRAM AND PARTS DESCRIPTION

1. Microphone Input with Volume Control (XLR-1/4"): This mono input

accepts a XLR-1/4" input such as a microphone or other musical instrument.

2. Instrument/Microphone Input with Volume Control: 1/4” TS input, high-

impedance for guitar.

3. Auxiliary Input with volume Control: This stereo 1/8” input can be used to

connect a CD player, MP3 player, or other audio source. Volume control adjusts auxiliary input and Bluetooth volume.

4. Bluetooth: The Paired LED will be lit when a device is paired to

TransActive Wireless. This LED will not be lit when TransActive Wireless is first powered on (unless it was previously paired with a device). Press the Disconnect button to disconnect a paired Bluetooth device.

5. Master Volume Control: This adjusts the speaker’s main mix volume,

which includes Instrument/Microphone Input, Auxiliary Input, Tuner, and the audio of a paired Bluetooth device.

6. Power LED: Indicates whether TransActive Wireless is on or off.

7. Device Charge: Connect your device’s charge cable here to charge it. USB

charging only functions when the unit’s power is turned on. Note: Users with iPad (3 slower charging. We recommend charging with the screen locked when using iPad (3

8. Device Cradle: Place your iPad/iPod touch

9. Power Cable Input (IEC): Insert the included power

10. Voltage Selector*: If your unit has a voltage selector

11. Power ON/OFF Switch: Turns TransActive Wireless on or off. Please note that while TransActive Wireless is

12. Battery Level Indicator: While the unit is powered ON, these four lights indicate the power left in the battery.

® or other device here to be held.

Android

cable here to charge the unit. Note that the TransActive Wireless can run off the power adapter while it simultaneously charges the battery. The charge indicator illuminates when the battery is charging.

switch, change its setting only when necessary (e.g., when traveling to a country or region with a different voltage). Selecting an improper voltage setting can damage the unit. To change its setting, only remove *one* screw of the cover and slide it aside to expose the selector.

connected to a power source, it does not need to be powered on to charge the battery.

Battery life varies based on volume and usage.

iPhone and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.

Android is a trademark of Google Inc.

generation) may experience

generation).

®/iPhone®,

*WARNING: If your unit has a voltage selector switch, change its setting only when necessary (e.g., when traveling to a country or region with a different voltage). Selecting an improper voltage setting can damage the unit. To change its setting, only remove *one* screw of the cover and slide it aside to expose the selector.

TROUBLESHOOTING

If the sound is distorted: Try lowering the volume control of your sound source or musical instrument. Also, try to reduce the overall volume of TransActive Wireless. If there is too much bass: Try adjusting the tone or EQ control on your sound source to lower the bass level. This will allow you to play the music louder before clipping (distortion) occurs. If there is a high-pitched whistling noise when using microphones: This is probably feedback. Point the microphones away from the speaker. If you can’t hear the microphone over the music volume: Turn down the music volume from your source.

PAIRING A BLUETOOTH DEVICE

1. Turn on your Bluetooth device.

2. Power on TransActive Wireless and it will automatically go into pairing mode to search for Bluetooth devices.

You will know you are in pairing mode when the LED is blank.

3. If your Bluetooth device is not able to pair to TransActive Wireless, press the disconnect button on TransActive

Wireless to break previous Bluetooth connections and reset the Bluetooth module.

4. Navigate to your Bluetooth device’s setup screen, find “Alesis TransAct” and connect.

Note: If your Bluetooth device prompts for a pairing code, enter ‘0000’.

5. TransActive Wireless LED will light up solid when it is 'paired'.

Note: Users should consider updating their OS if experiencing trouble with pairing or playing music.

6. To disconnect pairing, press the ‘Disconnect’ button on TransActive Wireless.

7. To connect to another Bluetooth device, repeat steps 3-4.

Note: Maximum range will be achieved when using devices with Bluetooth 4.0.

GUÍA DEL USUARIO (ESPAÑOL)

1. Asegúrese que todos los artículos incluidos al inicio de este guía estén incluidos en la caja.

2. LEA LAS INSTRUCCIONES DEL FOLLETO DE SEGURIDAD

ANTES DE UTILIZAR EL PRODUCTO.

3. ASEGÚRESE DE QUE HA CARGADO COMPLETAMENTE LA BATERÍA. PARA LOGRAR LA MÁXIMA VIDA ÚTIL DE LA BATERÍA, CÁRGUELA TOTALMENTE ANTES DEL PRIMER USO.

4. Estudie este diagrama de instalación.

5. Asegúrese de que todos los dispositivos de entrada tales como micrófonos, reproductores de CD, o reproductores MP3 estén apagados y con el control de volumen en "cero".

6. Conecte todos los dispositivos como se muestra.

7. Encienda todo en el siguiente orden:

• fuentes de entrada de audio (por ejemplo, micrófonos, instrumentos, reproductores de CD/MP3)

• TransActive Wireless

8. Al apagar, realice siempre esta operación en sentido inverso:

• TransActive Wireless

• por último, cualquier dispositivo de entrada

MICRÓFONO*

PANEL

SUPERIOR

*SE VENDE POR SEPARADO

TABLET U OTRO DISPOSITIVO *

BATERÍAS RECARGABLES

Las baterías de plomo-ácido recargables son del mismo tipo que se usa en los automóviles. Al igual que con la batería del vehículo, la forma en que se usa tiene una influencia significativa en la duración de su vida útil. Con un uso y tratamiento correctos, una batería de plomo-ácido puede durar varios años. He aquí algunas recomendaciones para prolongar la vida útil de la batería interna.

USO GENERAL

• CARGUE COMPLETAMENTE LA BATERÍA ANTES DE USARLA.

• CARGUE LA BATERÍA COMPLETAMENTE DESPUÉS DE CADA USO.

• EVITE AGOTARLA COMPLETAMENTE.

• Puede dejar la unidad enchufada durante hasta dos semanas.

• Para obtener máxima vida, descargue la batería el 80% una vez por mes.

ALMACENAMIENTO

• Evite almacenar la batería en lugares húmedos y de alta temperatura.

• Si la almacena durante períodos prolongados, recárguela periódicamente.

• Si no carga la batería durante seis meses, es posible que luego no pueda cargarse.

REPARACIÓN

• Cuando la batería se acerca al final de su vida útil, puede perder su capacidad de recarga. Si esto ocurre,

DISPOSICIÓN FINAL

comuníquese con el soporte técnico de Alesis al www.alesis.com/supporthome.

• Lleve la unidad a un centro de reciclaje o deséchela de acuerdo a las ordenanzas locales.

CONTENIDO DE LA CAJA

 TransActive Wireless  Cable de alimentación  Guía del usuario  Folleto de información sobre la seguridad

y la garantía

Visite www.alesis.com para registrar el producto.

PANEL LATERAL

SUMINISTRO ELÉCTRICO
