ADOBE Fireworks CS4 User Manual [es, en]

Extending

ADOBE® FIREWORKS® CS4

Last updated 12/8/2009

This guide is protected under copyright law, furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by Adobe Systems Incorporated. Adobe Systems Incorporated assumes no responsibility or liability for any errors or inaccuracies that may appear in the informational content contained in this guide.

This guide is licensed for use under the terms of the Creative Commons Attribution Non-Commercial 3.0 License. This License allows users to copy, distribute, and transmit the user guide for noncommercial purposes only so long as (1) proper attribution to Adobe is given as the owner of the user guide; and (2) any reuse or distribution of the user guide contains a notice that use of the user guide is governed by these terms. The best way to provide notice is to include the following link. To view a copy of this license, visit

Adobe, the Adobe logo, Adobe AIR, Dreamweaver, Fireworks, Flash, FreeHand, Illustrator, Photoshop, are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Macintosh is a trademark of Apple Inc., registered in the United States and other countries. Windows is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners.

Updated Information/Additional Third Party Code Information available at http://www.adobe.com/go/thirdparty.

The Proximity/Merriam-Webster Inc. Database © Copyright 1990. The Proximity/Franklin Electronic Publishers Database © Copyright 1994. © Copyright 1990, 1994, 1997 All Rights Reserved. Proximity Technology Inc.

This Program was written with MacApp®: ©1985-1988 Apple Computer, Inc. APPLE COMPUTER, INC. MAKES NO WARRANTIES WHATSOEVER, EITHER EXPRESS OR IMPLIED, REGARDING THIS PRODUCT, INCLUDING WARRANTIES WITH RESPECT TO ITS MERCHANTABILITY OR ITS FITNESS FOR ANY PARTICULAR PURPOSE. The MacApp software is proprietary to Apple Computer, Inc. and is licensed to Adobe for distribution only for use in combination with Adobe Fireworks.

PANTONE® colors displayed here may not match PANTONE-identified standards. Consult current PANTONE Color Publications for accurate color. PANTONE

Portions contributed by Focoltone Colour System.

Portions produced under Dainippon Ink and Chemical, Inc. copyright of color-data-base derived from Sample Books.

® and other Pantone, Inc. trademarks are the property of Pantone, Inc. © Pantone, Inc., 2008

http://creativecommons.org/licenses/by-nc-sa/3.0/

Sorenson Spark™ video compression and decompression technology licensed from Sorenson Media, Inc.

MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.

Adobe Systems Incorporated, 345 Park Avenue, San Jose, California 95110, USA.

Notice to U.S. Government End Users. The Software and Documentation are "Commercial Items," as that term is defined at 48 C.F.R. §2.101, consisting of "Commercial Computer Software" and "Commercial Computer Software Documentation," as such terms are used in 48 C.F.R. §12.212 or 48 C.F.R. §227.7202, as applicable. Consistent with 48 C.F.R. §12.212 or 48 C.F.R. §§227.7202-1 through 227.7202-4, as applicable, the Commercial Computer Software and Commercial Computer Software Documentation are being licensed to U.S. Government end users (a) only as Commercial Items and (b) with only those rights as are granted to all other end users pursuant to the terms and conditions herein. Unpublished-rights reserved under the copyright laws of the United States. Adobe Systems Incorporated, 345 Park Avenue, San Jose, CA 95110-2704, USA. For U.S. Government End Users, Adobe agrees to comply with all applicable equal opportunity laws including, if appropriate, the provisions of Executive Order 11246, as amended, Section 402 of the Vietnam Era Veterans Readjustment Assistance Act of 1974 (38 USC 4212), and Section 503 of the Rehabilitation Act of 1973, as amended, and the regulations at 41 CFR Parts 60-1 through 60-60, 60-250, and 60-741. The affirmative action clause and regulations contained in the preceding sentence shall be incorporated by reference.

Last updated 12/8/2009

Chapter 1: Extending Fireworks Overview

Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Installing an extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

What’s new in Extending Fireworks CS4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Conventions used in this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Additional resources for extension writers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Chapter 2: The Fireworks Object Model

Using the Fireworks Object Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Using Fireworks API functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Using the common API . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Working with selected objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Global methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Core objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Adobe AIR Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

iii

Chapter 3: The Document object

Document object properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Document functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Chapter 4: The Fireworks Object

Fireworks functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Chapter 5: Objects within Fireworks documents

Behavior object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236

Brush object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236

Contour object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

ContourNode object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

ContourNodeDynamicInfo object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240

ControlPoint object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240

Effect object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241

EffectList object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

Element object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

ElementMask object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252

ExportFrameInfo object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

ExportOptions object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

ExportPaletteInfo object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

ExportSettings object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256

Fill object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258

Frame object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259

FrameNLayerIntersection object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259

Gradient object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260

GradientNode object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260

Guides object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260

Last updated 12/8/2009

EXTENDING FIREWORKS

Contents

Layer object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261

PathAttrs object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261

Pattern object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262

RectanglePrimitive object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262

RegisterMoveParms object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262

SingleTextRun object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265

SmartShape object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265

Style object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266

TextAttrs object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267

TextRuns object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268

Widget object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268

Chapter 6: HTML export objects

BehaviorInfo object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270

BehaviorsList object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273

exportDoc object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273

ImageMap object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276

ImagemapList object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276

SliceInfo object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277

Slices object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279

Chapter 7: Cross-Product Extensions

Cross-product architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281

Flash panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292

Chapter 8: Auto Shapes

How Auto Shapes work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298

Creating an Auto Shape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298

Chapter 9: Rich symbols

How Rich symbols work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304

MXML Export . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309

Chapter 10: Additional Fireworks Functions

Property inspector functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 315

History panel functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 318

Static Document Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 322

Index ...............................................................................................................324

Last updated 12/8/2009

Chapter 1: Extending Fireworks Overview

To extend Adobe® Fireworks® CS4, you must write JavaScript code. You can use JavaScript to write your own objects and commands that affect Fireworks documents and the elements within them. To accomplish these tasks, you must be proficient in JavaScript and in Fireworks.

This guide introduces the Fireworks Object Model, explains how to write cross-product extensions (extensions written in, or for, other Adobe applications), and discusses the JavaScript Auto Shape construction. The final chapter is a reference to the Fireworks JavaScript application programming interface (API)—the custom JavaScript functions that are built into Fireworks.

Prerequisites

Because Fireworks extensions must be written in JavaScript, this guide assumes that readers are familiar with JavaScript syntax and with basic programming concepts such as functions, arguments, and data types. It also assumes that readers understand the concept of working with objects and properties. This guide does not attempt to teach programming in general or JavaScript in particular.

Anyone who wants to extend Fireworks should have a good JavaScript reference to help with syntax questions (for example, is it Goodman (IDG), JavaScript: The Definitive Guide by David Flanagan (O’Reilly), and Pure JavaScript by R. Allen Wyke, Jason D. Gilliam, and Charlton Ting (Sams).

substring() or subString()?). Useful JavaScript references include JavaScript Bible by Danny

Installing an extension

As you start learning the process of writing extensions, you might want to explore the extensions and resources already available through the Adobe Exchange website you will become familiar with some of the tools that you need to work with your own extensions.

To install an extension:

1 Download and install the Adobe® Extension Manager, which is available on the Adobe Downloads website

www.adobe.com/exchange/em_download/).

(

2 Log on to the Adobe Exchange website (www.adobe.com/go/exchange).

3 Click the Fireworks Exchange link.

4 From the available extensions, choose one that you want to use. Click the Download link to download the extension

package.

5 Save the extension package in a directory on your machine.

6 In Fireworks, choose Commands > Manage Extensions to start the Extension Manager (or you can start Extension

Manager, located in the Adobe program group, independently from Fireworks).

7 In the Extension Manager, choose File > Install Extension, and choose the extension package you just saved.

The Extension Manager automatically installs the extension into Fireworks.

(www.adobe.com/go/exchange). By installing an existing extension,

Last updated 12/8/2009

EXTENDING FIREWORKS

Extending Fireworks Overview

You cannot begin using some extensions until you restart Fireworks. If you are running Fireworks when you install the extension, you might be prompted to quit and restart the application.

To view basic information on the extension after its installation, go to the Extension Manager (Commands > Manage Extensions) in Fireworks.

What’s new in Extending Fireworks CS4

Fireworks CS4 includes the following new features and interfaces that you can use to develop extensions for the product:

CSS-based layouts Fireworks CS4 now allows you to design complete web pages and export web standards-compliant

CSS-based layouts. You can select a layout and integrate foreground and background graphics with automatic margin and padding detection. You can drop HTML rich symbols on your Fireworks layouts to specify headings, links, and form properties for precise CSS control. You can also use rectangles with rounded corners and gradients for creating layouts.

Adobe Type Engine The new Adobe Type Engine provides enhanced typesetting capabilities similar to Adobe®

Photoshop® and Adobe® Illustrator®. You can import or copy/paste double-byte characters from Illustrator or Photoshop without loss of fidelity, and create advanced effects such as setting text inside a path.

Export to PDF You can generate high-fidelity, interactive, secure PDF documents from your Fireworks design comps

and receive review comments through a shared PDF review.

Smart Guides Use Smart Guides to expertly position and layouts objects on canvas. Use Smart Guides with tool tips

to achieve precise positioning.

Live Styles With Live Styles, you can use professionally designed styles or create your own collection. Enhanced

capabilities include redefining styles, dynamically updating effects, colors, and text attributes by updating the style source.

FXG export You can export designs as FXG files and use them in advanced design tools to develop rich Internet

applications and experiences that can run on Adobe® Flash Player or Adobe® AIR™.

Adobe AIR export You can package your Fireworks documents as Adobe AIR applications that you can secure using

a digital signature.

The following APIs have been added or modified for this release:

Last updated 12/8/2009

Class Property or Method Description

EXTENDING FIREWORKS

Extending Fireworks Overview

AIRExt AIRext.PreviewDocument() Calls the ADL tool to preview an HTML document as an Adobe AIR

AIRext.PackageApplication() Calls the ADT tool package an Adobe AIR application.

AIRext.CreatePackage() Calls the ADT tool to create a signed AIR package.

AIRext.CheckCertificatePasswor d()

AIRext.SaveDigSigPassword() Saves the password for the given digital certificate, for the current

AIRext.GetDigSigPassword() Returns the name of the generated password file.

AIRext.GetLastErrorLogName() Returns the name of the generated error log file if one was

AIRext.GetAIRInstallPath() Returns the full system path name and path of the generated file.

AIRext.GetJREVersion() An object with two properties - maxVersion and minVersion; if an

AIRext.CreateCertificate() Calls the ADT to create a self-signed digital certificate.

exportDoc isBackground Specifies whether the document has a background image. If an

backgroundAttachment Specifies whether the document is fixed or scrolls. Values are

docAlignment Specifies the page alignment as left, center, right. Default is left.

application.

Calls the ADT tool to check a certificate password.

session of Fireworks (no persistent storage).

created.

error occurs the values of the maxVersion and minVersion will be

-1.

image is set in the HTML set up, returns true.

Fixed or scroll.

backgroundURL Specifies the URL of the background image as file:///)

backgroundRepeat Specifies if the background image repeats, and if repeats in X, Y,

leftMargin Specifies the left margin of the page.

topMargin Specifies the top margin of the page.

rightMargin Specifies the right margin of the page.

bottomMargin Specifies the bottom margin of the page.

Repeat (Both) and No Repeat

Last updated 12/8/2009

Class Property or Method Description

EXTENDING FIREWORKS

Extending Fireworks Overview

SliceInfo backgroundHorizontalPosition Horizontal position of the background image. (Left, right, or

backgroundVerticalPosition Horizontal position of the background image. (Left, right, or

backgroundHorizontalPositionValHorizontal position value of the background image if the

backgroundVerticalPositionVal Vertical position value of the background image if the argument

isBackground Specifies whether the slice is background image or foreground

backgroundRepeat Specifies if the background image repeats, and if repeats in X, Y,

backgroundAttachment Specifies if the bg image is fixed or scrolls with the rest of the

RectPrimitive Mode Specifies the roundness units which can be relative (percentage)

instance tranform Specifies the transformation matrix of a symbol instance.

symbolName Specifies the symbol name.

frame name Species the name of the state.

FrameNLayerIntersection name Specifies the name of the layer when the layers are accessed from

center, numeric value)

argument is value.

is value.

image. True = Background.

Repeat (Both) and No Repeat.

page.

or exact (pixels).

states.

document dom.setRectRoundnessMode() Specifies the mode of corner roundness of the rectangle as either

dom.exportElements() Exports an array of elements on the canvas to a 32-bit PNG image,

dom.moveNineScaleGuide() Moves a 9-slice scaling guide’s position by specified pixels.

dom.placeTextInPath() Places the selected text inside the selected path. If no text and

dom.setSliceType() Sets the slice type as image (foreground image), background

dom.redefineStyleByName() Redefines the target style with the source style.

dom.attachTextInPath() Attaches the selected text inside the selected path. If no text and

a percentage value or or exact pixel value.

based on the image export settings.

path are selected, no action occurs.

image, or empty (HTML Slice).

path are selected, no action occurs.

Last updated 12/8/2009

Class Property or Method Description

EXTENDING FIREWORKS

Extending Fireworks Overview

fw fw.saveAs() Saves the specified document in the specified filename and

fw.exportPDF() Exports the specified document to the specified file in PDF

fw.setUseAGMRenderingForSele ction()

fw.currentWorkspaceName() Returns the name of the current workspace layout.

fw.getFamilyNameForPSFont() Gets the family name of a PostScript font.

fw.getPlatformNameForPSFont() Returns the platform name of the PostScript font.

Files writeUTF8 Writes text in UTF8 encoding when the file is opened in UTF8

readLineUTF8 Reads one line from the file that has been opened with UTF8

format.

Sets the currently selected vectors to use the new AGM Rendering.

encoding.

Conventions used in this guide

The following typographical conventions are used in this guide:

• Code font indicates code fragments and API literals, including class names, method names, function names, type

names, scripts, SQL statements, and HTML and XML tag and attribute names.

• Italic code font indicates replaceable items in code.

• The continuation symbol (¬ ) indicates that a long line of code has been broken across two or more lines to fit on

the page. When copying the lines of code, eliminate the continuation symbol and type the code as one line.

• Curly braces ({ }) around a function argument indicate that the argument is optional.

The following naming conventions are used in this guide:

• You refers to the developer who is responsible for writing extensions.

• The user refers to the person using Fireworks.

• The visitor refers to the person who views the graphic that the user created.

Additional resources for extension writers

To communicate with other developers who are writing extensions, you can visit the Adobe online forums at

www.adobe.com/support/forums/.

Last updated 12/8/2009

Chapter 2: The Fireworks Object Model

If you want to extend the functionality of Adobe Fireworks CS4 by writing or modifying a JavaScript extensibility file, you must become familiar with the objects that Fireworks makes available through JavaScript. The hierarchy of these objects comprises the Fireworks Object Model, which contains the following major components:

• Six global methods that are available from any part of the application and need not be declared as methods of a

particular object. For more information, see

• Core objects: Dialogs, Document, pngText, Errors, Files, Find, and System. For more information, see “Core

objects” on page 16 and “The Document object” on page 27. (The App object that was used in Fireworks 3 is

supported for backward compatibility, but its use is deprecated in favor of the Fireworks object.)

• The Fireworks object (for more information, see “The Fireworks Object” on page 189).

• Numerous objects associated with Fireworks documents, such as ExportOptions, Guides, Path, Image, and Text.

For more information, see

• A set of objects that you can use to specify the format of HTML code when exporting from Fireworks. For more

information, see

“HTML export objects” on page 270.

“Objects within Fireworks documents” on page 236.

“Global methods” on page 13.

Using the Fireworks Object Model

When scripting extensions for Fireworks, you write JavaScript commands that send calls to the Fireworks Object Model to determine or change the current settings for a Fireworks document. For example, the following command calls the Fireworks object ( expressed as a file://URL. In other words, is a property (for more information, see resulting value to a variable, as follows:

var expSetDir = fw.appExportSettingsDir;

Accessing a Fireworks document

All the functions listed in “Property inspector functions” on page 315 are methods of the Document object, which represents a Fireworks document. To perform a function on a Document object, you must first get the Document Object Model (DOM) of the document. You then call the functions as methods of that DOM.

When accessing a Fireworks document, consider the following points:

• To use a DOM function with a document other than the active document, use the following syntax; note that

documentIndex is a zero-based index that specifies which document the command will affect.

fw.documents[documentIndex].functionName();

• To use a DOM function with the active document, use fw.getDocumentDOM().functionName() (for more

information, see

fw) to obtain the path to the Export Settings directory (appExportSettingsDir), which is

fw references the Fireworks global object, of which appExportSettingsDir

“The Fireworks Object” on page 189), so a JavaScript command can assign the

fw.getDocumentDOM()).

Passing values

For all properties that are not read-only, you can pass values to change elements of a document. For example, the following command sets the fifth brush in the third open document to a square shape:

Last updated 12/8/2009

fw.documents[2].brushes[4].shape = "square";

EXTENDING FIREWORKS

The Fireworks Object Model

The preceding example includes the following properties:

• documents is a property of the Fireworks object and contains an array of Document objects.

• brushes is a property of the Document object and contains an array of Brush objects.

• shape is a property of the Brush object.

Note: Throughout this manual, optional arguments are enclosed in {braces}.

Fireworks Object Model calls and API calls

In some cases, you can use Fireworks Object Model calls or API calls to perform the same operations. In other cases, a certain function might be available in either the Fireworks Object Model or the API, but not in both.

For example, if the first open document is the current document, the first code fragment has the same effect as the second and third code fragments. The information, see

fw.getDocumentDOM().setDocumentResolution({pixelsPerUnit:72, units:"inch"}); fw.documents[0].resolution =72; fw.documents[0].resolutionUnits ="inch";

“Accessing a Fireworks document” on page 6).

fw.getDocumentDOM() function references the current document (for more

Formatting nonstandard data types

In addition to the standard data types that can be passed to functions as arguments, or used as properties, such as integer, string, and so on, Fireworks accepts other data types.

• Some functions accept values that are Fireworks objects. For more information, see “The Fireworks Object Model”

on page 6.

• Some functions accept a string in a specific format. Others accept value types that are not Fireworks objects but are

JavaScript object types that are specific to Fireworks. These types of arguments are described next, in alphabetical order.

Color string data type

Functions that accept colors as arguments use the HTML syntax "#rrggbb". You can specify a color with an alpha (transparency) component by passing a longer string of the form

Mask data type

The format for a mask is {maskBounds:rectangle, maskKind:string, maskEdgeMode:string, featherAmount:int, maskData:

• maskBounds specifies the bounding rectangle of the mask area.

• Acceptable values for maskKind are "rectangle", "oval", "zlib compressed", "rle compressed", or

• If the value of maskKind is "rectangle" or "oval", the maskData string is ignored, and a mask of the right shape is

• If the value of maskKind is “zlib compressed“, “rle compressed", or “uncompressed", the maskData string is

hex-string}.

"uncompressed".

constructed that fills maskBounds and that has the edge specified by maskEdgeMode and featherAmount.

presumed to contain 8-bit mask data in hexadecimal format that precisely matches the maskBounds to define the mask.

"#rrggbbaa".

Last updated 12/8/2009

EXTENDING FIREWORKS

The Fireworks Object Model

Matrix data type

The format for a matrix is {matrix:[float, float, float, float, float, float, float, float, float]}. This guide assumes that you know how to use these nine values to construct a three-by-three transformation matrix; discussion of the construction of transformation matrices is beyond the scope of this manual.

Point data type

The format for a point is {x:float, y:float}. For instance, dom.addNewLine(startPoint, endPoint) could look like the following example:

fw.getDocumentDOM().addNewLine({x:64.5, y:279.5}, {x:393.5, y:421.5});

Rectangle data type

The format for a rectangle is {left:float, top:float, right: float, bottom: float}. For instance,

dom.addNewOval(boundingRectangle) could look like the following example:

fw.getDocumentDOM().addNewOval({left:72, top:79, right:236, bottom:228});

Resolution data type

The format for resolution is {pixelsPerUnit: float, units: string}. Acceptable values for units are “inch“ or “cm“. For instance,

dom.setDocumentResolution(resolution) could look like the following example:

fw.getDocumentDOM().setDocumentResolution({pixelsPerUnit:72, units:"inch"});

Using Fireworks API functions

Three categories of API functions are described in this book: Document functions, History panel functions, and Fireworks functions. The following rules apply to all functions.

Zero-based indexes

Some functions take an index argument which is a zero-based, one-dimensional array. That means a value of 0 represents the first item in the array, deletes the second layer of the active Fireworks document:

fw.getDocumentDOM().deleteLayer(2);

Functions that take a frameIndex argument can be passed –1 to indicate the current frame. Similarly, functions that take a layerIndex argument may be passed –

Passing null values

In general, passing a null value to a function causes an exception to be thrown. A few functions do allow null as an argument; such cases are noted in the function descriptions.

1 represents the second item, and so on. For example, the following command

1 to indicate the current layer.

Working with selected elements

Many API functions in this chapter refer to a “selection” or to “selected items.” These terms refer to Fireworks elements, such as text boxes or images, that are currently selected. In most cases, the functions work even if only one item is selected. If a function requires more than one selected item, this is noted in the description of the function.

Last updated 12/8/2009

EXTENDING FIREWORKS

The Fireworks Object Model

Palette or panel

Several API functions reference the History panel (see “History panel functions” on page 318). Throughout the Fireworks documentation and online help, the term palette is reserved for discussions of a color palette, and the term panel is used to refer to the floating windows that are available within Fireworks. Therefore, when the function name contains palette, the descriptions refer to a panel.

Using the common API

You can use the common Adobe API if you want commands to use a common syntax (and thus run a single command in multiple applications). You can access this API using supported in Fireworks and Dreamweaver to let developers easily create commands for both applications.

app.toggleFloater()

Identical to fw.toggleFloater().

app.setFloaterVisibility()

Identical to fw.setFloaterVisibility().

app.methodName().The following methods are currently

app.getRootDirectory()

Identical to the Fireworks object property appDir •.

app.browseDocument()

Identical to fw.browseDocument().

Note: The app.getRootDirectory() function is useful if you want to use app.browseDocument() to view files within the applications’s folder.

Working with selected objects

When an object is selected, either programmatically (for example, using the dom.selectAll() function) or by a user, you can return (get) or set the value of that object’s properties using common notation that will work on various objects. In other words, you can write a command that will get or set the value of an object’s properties whether the user selects a Text object, or an Image object, or any other recognized object. In Fireworks, a recognizable object is classified as one of the following element types:

• Hotspot

• SliceHotspot (basically, a slice)

• Path

• Group

• Instance

• Text

Last updated 12/8/2009

• RectanglePrimitive

• PathAttrs

• Image

To test whether a text block is selected, type the following code:

firstSelection = fw.selection[0]; if (firstSelection == "[object Text]"){ alert("I am a text block"); }

You can use the information in the following sections to return or set property values.

Note: The return value for a property may be null.

Working with properties for any selected object

You can get values for the following read-only properties of any type of selected object:

• top

• left

• width

• height

• visible

• opacity

• blendMode

• name

• mask

To return the name of the selected object, type the following code:

EXTENDING FIREWORKS

The Fireworks Object Model

objectName=fw.selection[0].name;

The following properties contain other read-only properties that you can return:

elementMask

• element

• linked

• enabled

• mode

• showAttrs

• autoExpandImages

effectList

• name

• effects

To return the name of the first effect that is applied to the selected object, type the following code:

effectName=fw.selection[0].effectList.effects[0].name;

Last updated 12/8/2009

EXTENDING FIREWORKS

The Fireworks Object Model

Working with specific properties for selected elements

Some elements have specific properties that can be returned in addition to those that can be returned for any selected object (for more information, see properties are available for each of the following elements when the elements are selected.

Hotspot

• shape

• urlText

• altText

• targetText

• contour

• behaviors (returns an array of behaviors)

• color

To return the alt tag that has been applied to the currently selected Hotspot, type the following code:

altTag = fw.selection[0].altText;

“Working with properties for any selected object” on page 10). These specific

SliceHotspot

SliceHotspot is a subclass of Hotspot. A slice has all Hotspot properties, plus the following properties:

• baseName

• htmlText

• tdTagText

• sliceKind ("image" or "empty")

• exportOptions

• sliceID (read-only)

To return the name of the currently selected slice, type the following code:

sliceName = fw.selection[0].baseName;

Path

• pathAttributes

Note: For the complete list of path attributes properties, see “pathAttributes” on page 98.

• randSeed

• textureOffset

• contours

To return the value of the fill color for the currently selected path, type the following code:

fillColor = fw.selection[0].pathAttributes.fillColor

Group

• elements

• groupType

Last updated 12/8/2009

To return the number of objects in a selected group, type the following code:

numOfObjectsinGroup = fw.selection[0].elements.length;

Instance

• symbolID

• transformMode

• instanceType

• urlText

• altText

• targetText

To return the instanceType for the currently selected instance, type the following code:

instance = fw.selection[0].instanceType;

Text

• antiAliased

• antiAliasMode

• autoKern

• orientation

• pathAttributes

Note: For the complete list of pathAttributes properties, see “pathAttributes” on page 98.

EXTENDING FIREWORKS

The Fireworks Object Model

• randSeed

• textRuns

• textureOffset

• transformMode

To return the antiAliasMode setting for the currently selected text block, type the following code:

antiAliasedSetting = fw.selection[0].antiAliasMode;

RectanglePrimitive

• Roundness

• pathAttributes

Note: For the complete list of path attributes properties, see “pathAttributes” on page 98.

• originalSides

• transform

To return the roundness setting for the currently selected rectangle, type the following code:

roundness = fw.selection[0].roundness;

Last updated 12/8/2009

EXTENDING FIREWORKS

The Fireworks Object Model

pathAttributes

Several objects have the pathAttributes property. The following list is the valid set of pathAttributes sub properties that can be returned or set:

• brushColor

• fillColor

• brush

• fill

• brushTexture

• fillTexture

• fillHandle1

• fillHandle2

• fillHandle3

• brushPlacement

• fillOnTop

To return the name of brush on the current path, type the following code:

brush = fw.selection[0].pathAttributes.brush.name; (b

Global methods

The following are the global Fireworks methods, along with their argument data types and, where appropriate, acceptable values and notes.

alert(message)

Availability

Fireworks 3.

Usage

alert(message)

Arguments

message A string containing the message to display.

Returns

Nothing.

Description

Displays the message in a modal alert box, along with an OK button.

Last updated 12/8/2009

confirm(message)

Availability

Fireworks 3.

Usage

confirm(message)

Arguments

message A string containing the message to display.

Returns

True if OK is clicked, false if Cancel is clicked.

Description

Displays a string in a modal alert box, along with OK and Cancel buttons.

prompt(caption, text)

EXTENDING FIREWORKS

The Fireworks Object Model

Availability

Fireworks 3.

Usage

prompt(caption, text)

Arguments

caption A string containing the title of the dialog box.

text A string containing the prompt for the user.

Returns

The string entered if OK is clicked, null if Cancel is clicked.

Description

Prompts the user (with the string that is specified by text) to enter a string in a modal dialog box; the dialog box is titled with the string that is specified by caption.

write(arg1, arg2, ..., argN)

Availability

Fireworks 3.

Usage

write(arg1, arg2, ..., argN)

Last updated 12/8/2009

EXTENDING FIREWORKS

The Fireworks Object Model

Arguments

arg1, arg2, ..., argN Strings containing content for output.

Returns

An output file.

Description

Same as WRITE_HTML; WRITE_HTML was created to let you differentiate HTML output calls from other JavaScript calls in your code.

WRITE_CSS

Availability

Fireworks 3.

Usage

WRITE_CSS

Arguments

None.

Returns

An output file.

Description

Available only when exporting. Writes the CSS as an external file.

WRITE_HTML(arg1, arg2, ..., argN)

Availability

Fireworks 3.

Usage

WRITE_HTML(arg1, arg2, ..., argN)

Arguments

arg1, arg2, ..., argN Strings containing content for output.

Returns

An output file.

Description

Available only when exporting. Converts each argument to a string and writes it to the HTML output file. To enter an end-of-line character, use “\n”; this is converted to the correct line ending for your platform. For more information,

“HTML export objects” on page 270.

see

Last updated 12/8/2009

fw.setUseAGMRenderingForSelection()

Availability

Fireworks 10.

Usage

fw. setUseAGMRenderingForSelection()

Arguments

None.

Returns

Nothing.

Description

Sets the currently selected vectors to use the new AGM Rendering.

Example

fw.getDocumentDOM().setUseAGMRenderingForSelection(true);

EXTENDING FIREWORKS

The Fireworks Object Model

Core objects

This section describes the set of core objects that are always available: Errors, Files, Find, and System. The Document object is described within its own chapter: see

Note: For information on how to format nonstandard data types, such as rectangle or point, see “Formatting

nonstandard data types” on page 7.

Errors object

All Errors object properties are read-only strings that are used to simplify the localizing of scripts. They return localized error messages appropriate to the specific error. For example, the English version of Fireworks returns

"Memory is full." for the EOutOfMem property.

The following list contains the properties of the Errors object alphabetically:

EAppAlreadyRunning, EAppNotSerialized, EArrayIndexOutOfBounds, EBadFileContents, EBadJsVersion, EBadNesting, EBadParam, EBadParamType, EBadSelection, EBufferTooSmall, ECharConversionFailed, EDatabaseError, EDeletingLastMasterChild, EDiskFull, EDuplicateFileName, EFileIsReadOnly, EFileNotFound, EGenericErrorOccurred, EGroupDepth, EIllegalThreadAccess, EInternalError, ELowOnMem, ENoActiveDocument, ENoActiveSelection, ENoFilesSelected, ENoNestedMastersOrAliases, ENoNestedPasting, ENoSliceableElems, ENoSuchElement, ENotImplemented, ENotMyType, EOutOfMem, EResourceNotFound, ESharingViolation, EUnknownReaderFormat, EUserCanceled, EUserInterrupted, EWrongType

Files object

The following table lists the methods of the Files object, along with their data types and, where appropriate, acceptable values and notes.

“The Document object” on page 27.

Last updated 12/8/2009

Method Data type Notes

EXTENDING FIREWORKS

The Fireworks Object Model

copy(docname1, docname2)

createDirectory(dirname)

createFile(fileURL, fileType, fileCreator)

deleteFile(docOrDir)

deleteFileIfExisting (docOrDir)

enumFiles(docOrDir)

string, string Copies the file specified in the first argument to the file

specified in the second argument. Each argument must be the name of a file, which is expressed as file://URL. Only files (not directories) can be copied. The files do not need to reside on the same drive, and the method does not overwrite a file if it already exists. Returns a value of

false otherwise.

true if the copy is successful;

string Creates the specified directory. Returns true if successful;

false otherwise.

string, string, string Creates the specified file. The file must not already exist. The

first argument is the name of the file, which is expressed as file://URL. The last two arguments let you specify the file type and file creator strings. The

fileType and fileCreator

strings should each be strings of exactly four characters in length, for example:

Files.createFile(newFile,".txt","FWMX");

string Deletes the specified file or directory. Returns true if

successful;

false if the file or directory does not exist or

cannot be deleted. Compare with

deleteFileIfExisting().

string Deletes the specified file or directory. Returns true if

successful; Unlike

false if the file or directory cannot be deleted.

deleteFile(), this method returns true if the file or

directory does not exist.

string Returns an array of file URLs. If docOrDir is a directory, the

array contains an entry for every file or directory that is contained in the specified directory. If

docOrDir is a file, the

array contains a single entry (the file passed in).

exists(docOrDir)

getDirectory(docname)

getExtension(docname)

getFilename(docname)

getLanguageDirectory()

getLastErrorString()

string Returns true if docOrDir refers to a directory or file that

false otherwise.

exists;

string Returns only the directory name from docname, which is

expressed as file://URL. For example,

Files.getDirectory("file://work/logo.png")

"file:///work".

returns

string Returns the filename extension, if any, of docname. For

example, returns

Files.getExtension("birthday.png")

".png". If the filename has no extension, an empty

string is returned. A filename that is expressed as file://URL is acceptable.

string Returns just the filename from docname, which is expressed as

file://URL. For example,

Files.getFilename("file:///work/logo.png")

"logo.png".

returns

string Returns the URL of the language directory associated with the

currently running language.

none If the last call to a method in a Files object resulted in an error,

returns a string that describes the error. If the last call succeeded, returns

null.

Last updated 12/8/2009

Method Data type Notes

EXTENDING FIREWORKS

The Fireworks Object Model

getTempFilePath ({dirname})

isDirectory(dirname)

makePathFromDirAndFile(dirna me, plainFilename)

open(docname, encoding, bWrite)

rename(docname, newPlainFilename)

string The argument, if used, must be expressed as file://URL. Returns

string The argument must be expressed as file://URL. Returns true if

string, string The first argument must be expressed as file://URL.

string, string, Boolean The first argument must be expressed as file://URL. Opens the

string, string The docname argument is a file path or a file URL to the file that

a file URL in the Temporary Files directory or in the specified directory. This method does not create a file; it simply returns a unique file URL that does not conflict with existing files in the directory. If returned indicates a file in the specified directory rather than in the Temporary Files directory.

the specified URL refers to a directory that exists; otherwise.

Concatenates the two arguments to return a file URL that references the specified filename in the specified directory. For example,

Files.makePathFromDirAndFile("file:///work/rep orts", "logo.png") "file:///work/reports/logo.png".

specified file for reading or writing. The second argument specifies the encoding. If the third argument is opens for writing; otherwise it opens for reading. If the file cannot be opened, returns Reference object.

you want to rename.

The newPlainFilename argument is the new name to assign to the file.

The rename method returns a URL path of the newly renamed file if successful; otherwise Fireworks returns

dirname is passed and is not null, the URL that is

false

returns

true, the file

null; otherwise, returns a File

null.

setFilename(docname, newPlainFilename)

swap(docname1, docname2)

string, string The first argument must be expressed as file://URL. Returns a

file URL with example,

Files.setFilename("file:///work/logo.png", "oldlogo.png") "file:///work/oldlogo.png". This method does not

affect the file on disk; it simply provides a convenient way to manipulate file URLs. To change the name on disk, use

rename().

string, string Each argument must be expressed as a file://URL. Swaps the

contents of the two specified files, so that each file contains the contents of the other file. Only files (not directories) can be swapped, and both files must reside on the same drive. Returns

true if the swap is successful; false otherwise.

docname replaced by newPlainFilename. For

returns

File Reference object

The File Reference object is used to refer to a specific open file. The following table lists the methods of the File Reference object, along with their data types and, where appropriate, acceptable values and notes.

Last updated 12/8/2009

Method Data Type Notes

EXTENDING FIREWORKS

The Fireworks Object Model

close()

readline()

readLineUTF8 string Reads one line from the file that has been opened with UTF8

write(textString)

writeUTF8 string Writes text in UTF8 encoding when the file is opened in UTF8

none Closes the current File Reference object. You are not required

none Reads the next line from the current File Reference object and

string Writes the specified string to the current File Reference object.

to use this method (the file is closed when the Files object is destroyed), but it is useful for controlling access to a file.

returns it as a string. The end-of-line character(s) are not included in the string. Returns if the line is longer than 2048 characters.

encoding.

No end-of-line characters are appended; to include one, use

"\n".

encoding.

null if end-of-file is reached or

Find object

There are several ways to specify a Find object, depending on what you want to find and replace. Use the whatToFind property to specify the type of find operation, along with the properties that are associated with each legal value for

whatToFind. These properties are listed in the following tables. Read-only properties are marked with a bullet (•).

Finding and replacing text

Property Data type Notes

whatToFind string In the format: "text"

find string Text to find.

matchCase Boolean If set to true, the search is case-sensitive. Defaults to false.

numItemsReplaced • Integer Number of replacements done in a file using Find and Replace.

regExp Boolean If set to true, the find and replace text is interpreted as a

replace string Text to use as replacement text.

wholeWord Boolean If set to true, only whole words matching the search text are

regular expression. The default is

found. The default is

false.

Finding and replacing fonts and styles

Property Data type Notes

whatToFind string In the format: "font"

find string Name of font to find.

replace string Name of font to use as replacement.

Last updated 12/8/2009

EXTENDING FIREWORKS

The Fireworks Object Model

Property Data type Notes

findStyle integer Number that represents the style to find:

AnyStyle = -1

Plain = 0

Bold = 1

Italic = 2

BoldItalic = 3

Underline = 4

BoldUnderline = 5

ItalicUnderline = 6

BoldItalicUnderline = 7

replaceStyle integer Number that represents the style to be used as replacement.

findMinSize integer 0 to 9999

findMaxSize integer 0 to 9999

replaceSize integer 0 to 9999, or pass -1 to leave size as is

Finding and replacing colors, fills, strokes, and effects

Property Data type Notes

whatToFind string In the format: "color"

find string A color string that specifies the color to find (for more

information, see

replace string A color string that specifies the color to use as a replacement

(for more information, see

fills Boolean If set to true, fills that match the specified colors are replaced.

strokes Boolean If set to true, strokes that match the specified colors are

“Color string data type” on page 7).

replaced.

effects Boolean If set to true, effects that match the specified colors are

replaced.

Finding and replacing URLs

Property Data types Notes

whatToFind string In the format: "url"

find string URL to find, which is expressed as file://URL.

replace string URL to use as replacement text, which is expressed as file://URL.

wholeWord Boolean If set to true, only whole words that match the search text are

found. The default is

false.

matchCase Boolean If set to true, the search is case sensitive. Defaults to false.

regExp Boolean If set to true, the find and replace text is interpreted as a

regular expression. The default value is

false.

Last updated 12/8/2009

Finding and replacing non-websafe colors with the closest websafe color

Property Data type Notes

whatToFind string In the format: "nonwebcolor"

EXTENDING FIREWORKS

The Fireworks Object Model

effects Boolean If set to true, colors in effects are replaced. The default value is

fills Boolean If set to true, colors in fills are replaced. The default value is

strokes Boolean If set to true, colors in strokes are replaced. The default value

false.

System object

The following table lists the properties of the System object, along with their data types and, where appropriate, acceptable values and notes. All System properties are read-only.

Property (read-only) Data type Notes

osName string Returns the name of the operating system under which

controlFaceColor string Returns the system color used for the control and panel faces

controlHilightColor string Returns the system color used for control highlights (Windows-

controlShadowColor string Returns the system color used for control shadows (Windows-

controlDarkShadowColor string Returns the system color used for control dark shadows

Fireworks is running.

(Windows®-only property).

only property).

(Windows-only property).

hilightItemColor string Returns the system color used for highlighting selections

hilightTextColor string Returns the system color used for highlighting selected text

textColor string Returns the system color used for text (Windows-only

menuColor string Returns the system color used for menu backgrounds

menuTextColor string Returns the system color used for text in menus (Windows-only

(Windows-only property).

property).

(Windows-only property).

property).

Adobe AIR Extension

AIRext.PreviewDocument()

Availability

Fireworks 10.

Last updated 12/8/2009

EXTENDING FIREWORKS

The Fireworks Object Model

Usage

status= AIRext.PreviewDocument(appXMLPath, siteRootPath);

Arguments

appXMLPath Path to the application descriptor.

siteRootPath Path to the site root folder in which the file that need to be previewed reside.

Returns

0 if the operation succeeded.

Description

Calls the ADL tool to preview an HTML document as an Adobe AIR application. The path to file that needs to be previewed is not specified because it is included in the application descriptor; this path is relative to the site root.

AIRext.PackageApplication()

Availability

Fireworks 10.

Usage

status = AIRext.PackageApplication(siteFullPath, packagePath, fileList);

Arguments

siteFullPath Path to the site root folder in which all files that needs to be included in package reside.

packagePath Full path of the resulting Adobe AIR package.

fileList Array of paths to files and folders that need to be included in package; all paths need to be relative to the

site root.

Returns

0 if the operation succeeded; 1 if an error occurred; 2 if the ADT tool generated an error (this error is saved into an error log file).

Description

Calls the ADT tool package an Adobe AIR application.

AIRext.CreatePackage()

Availability

Fireworks 10.

Usage

status = AIRext.CreatePackage(siteFullPath, packagePath, fileList, appXMLPath, certificatePath, password);

Last updated 12/8/2009

EXTENDING FIREWORKS

The Fireworks Object Model

Arguments

siteFullPath Path to the site root folder in which all files that needs to be included in package reside.

packagePath Full path of the resulting Adobe AIR package.

fileList Array of paths to files and folders that need to be included in package; all paths need to be relative to the

site root.

appXMLPath Path to the application descriptor (if blank or missing, defaults to application.xml in site root).

certificatePath Path to the digital certificate with which to sign the package (if blank or missing, an unsigned AIRI

file will be created instead of a signed AIR file)

password Password for the specified certificate (if blank or missing, user will be prompted for the password).

Returns

0 if the operation succeeded.

Description

Calls the ADT tool to create a signed AIR package.

AIRext.CheckCertificatePassword()

Availability

Fireworks 10.

Usage

status = AIRext.CheckCertificatePassword(certificatePath, password);

Arguments

certificatePath Path to the digital certificate with which to sign the package.

password Password for the specified certificate.

Returns

Exitcode from ADT; 0 if OK, 7 if could not access certificate, and so on.

Description

Calls the ADT tool to check a certificate password.

AIRext.SaveDigSigPassword()

Availability

Fireworks 10.

Usage

AIRext.SaveDigSigPassword(certificatePath, password);

Arguments

certificatePath Path to the digital certificate whose password is being saved.

Last updated 12/8/2009

password Password for the specified certificate.

EXTENDING FIREWORKS

The Fireworks Object Model

Returns

0 if saved successfully.

Description

Saves the password for the given digital certificate, for the current session of Fireworks (no persistent storage).

AIRext.GetDigSigPassword()

Availability

Fireworks 10.

Usage

configurationPath = AIRext.GetDigSigPassword();

Arguments

None.

Returns

The previously saved password for the given digital certificate, or an empty string.

Description

Returns the name of the generated password file.

AIRext.GetLastErrorLogName()

Availability

Fireworks 10.

Usage

errLogName = AIRext.GetLastErrorLogName();

Arguments

None.

Returns

The name of the error log file if it was created, or an empty string.

Description

Returns the name of the generated error log file if one was created.

Last updated 12/8/2009

The Fireworks Object Model

AIRext.GetAIRInstallPath()

Availability

Fireworks 10.

Usage

configurationPath = AIRext.GetAIRInstallPath();

Arguments

None.

Returns

The full system path to the current user configuration folder (for example, "C:\Documents and settings\...\Configuration").

Description

Returns the full system path name and path of the generated file.

EXTENDING FIREWORKS

AIRext.GetJREVersion()

Availability

Fireworks 10.

Usage

jreVersObj = AIRext.GetJREVersion();

Arguments

None.

Returns

An object with two properties - maxVersion and minVersion; if an error occurs the values of the maxVersion and minVersion will be -1.

Description

Get the minimum and maximum versions of the JRE.

AIRext.CreateCertificate()

Availability

Fireworks 10.

Usage

status = AIRext.CreateCertificate(certificatePath, password, keyType, publisher, orgName, orgUnit, country);

Last updated 12/8/2009

Arguments

certificatePath Path to digital certificate file that will be created (required).

password Password for the created certificate (required)

keyType Encryption key type (either "1024-RSA" or "2048-RSA" (required).

publisher Name of publisher (required).

orgName Name of organization (optional).

orgUnit Organizational unit (optional).

country 2-letter code for country (optional, and length is not enforced).

Returns

0 if operation succeeded.

Description

Calls the ADT to create a self-signed digital certificate.

EXTENDING FIREWORKS

The Fireworks Object Model

+ 306 hidden pages
