RN/RQSeries
Packaged Rooftop Units,
Air-Source Heat Pumps, Water-Source/
Geothermal Heat Pumps, & Outdoor
Air Handling Units
RQ Series
Features:
•Air-cooled or water-cooled condenser, with unit capacities from 2-140 tons
•Available as a chilled water or noncompressorized DX air handling unit, from 800-49,100 cfm
•Air-source, water-source, and geothermal heat pump options
•R-410A scroll compressors - one, two, or four compressor systems
•Variable capacity and variable speed R-410A scroll compressors for load matching cooling and improved part load efficiency
•Electric, gas, steam, or hot water heating
•AMCA certified low leakage economizer dampers
•Direct drive backward curved plenum fans
•Power exhaust and power return options
•Factory installed AAONAIRE® total and sensible energy recovery wheels
•Double wall rigid polyurethane foam panel construction with a minimum R-value of 13
•Service access doors with full length stainless steel piano hinges and lockable handles
•Sloped stainless steel drain pans
RN Series
Application Flexibility
Minimizes Installation Time and Reduces Cost
Makeup Air Applications |
Dehumidification and |
Large Tonnage Rooftops |
Factory Installed or Customer |
Up to 100% Outside Air |
Filtration Capabilities |
with Small Footprints |
Specific Controls Options |
RN/RQSeries
Rooftop/Air Handler
AAON RN and RQ Series rooftop units continue to lead the packaged rooftop equipment industry in performance and serviceability. Double wall rigid polyurethane foam insulated cabinet construction and direct drive backward curved plenum fans allow RN and RQ Series units to have quiet, energy efficient airflow with high static pressure capabilities. RN and RQ Series units also feature lockable hinged doors which provide service access to all sections of the unit.
Superior Features
•CabinetconstructionconsistsofrigidpolyurethanefoampanelswithG90 galvanizedsteelonbothsidesandaclosedcellpolyurethanefoaminterior core.Theinnerwallprotectstheinsulationfrommoisturedamage,prevents microbialgrowth,andiseasytoclean.
•Twoinchrigidpolyurethanefoaminsulatedpanelshaveathermalresistance R-valueof13orgreater,whichexceedstheR-valueofacabinetwithfour inchthickfiberglassconstruction.Theyalsomakethecabinetmorerigidand resistanttodamageandprovideincreasedsounddampening.
•Accessdoorswithfulllengthstainlesssteelpianohingesandquarterturn, lockablehandlesprovideimprovedreliabilityoversinglepointhingesand maketheuniteasilyserviceable.
•Corrosionresistantpolyurethanepaintexceedsa2,500hoursaltspraytest.
•AMCACertifiedlowleakagegeardriveneconomizerdampersarestandard onRNandRQSeriesrooftopunits.AAONlowleakagedampersmeetthe CaliforniaTitle24damperairleakagerequirement.OptionalEconomizerFault DetectionandDiagnosticsisalsoavailablewiththelowleakagedampersto meettheCaliforniaTitle24requirements.
•Compressorsandunitcontrolsarecontainedwithinacompartmentisolated fromtheairstreamforeaseofserviceandincreasedsounddampening.
•Directdrivebackwardcurvedplenumfansprovideimprovedenergy efficiencyandreducedmaintenanceversusbeltdrivenfans.
•Doubleslopedstainlesssteeldrainpanseliminate standingwaterwhichcansupportmicrobialgrowthand stainlesssteelconstructionpreventscorrosionthatcould leadtowaterleaksandcontaminantsintheairstream.
•Runtestreport,wiringdiagram,andInstallation, Operation,andMaintenancemanualwithstartupform providedincontrolaccesscompartmentofeveryunit.
•5yearnon-proratedcompressorwarranty,15yearnon- proratedaluminizedsteelgasheatexchangerwarranty, and25yearnon-proratedstainlesssteelgasheat exchangerwarranty.
6-30tonRNSeriesWater-Source/GeothermalHeatPump PackagedRooftopUnitorChilledWaterRooftopAir HandlingUnit
55-140tonRNSeriesMicrochannelAir-Cooled CondenserPackagedRooftopUnit
Air-Cooled or Water-Cooled Condensers
Premier Options
•VariablecapacityandvariablespeedR-410Ascrollcompressorsforload matchingcoolingandimprovedpartloadefficiency.
•Air-source,water-source,andgeothermalheatpumpoptionsforenergy efficientheating.
•FactoryinstalledtotalorsensibleAAONAIREenergyrecoverywheels.
•Humiditycontroloptionsincluding:HighCapacityCoils,ModulatingHumidity Control,ReturnAirBypass,andMixedAirBypass.
•Chilledwatercoolingcoilsallowunittotieintoexistingchilledwatersystem.
•Hotwaterorsteamheatingcoilsallowunittotieintoexistingboilersystem.
•Polymere-coatedcoilsareavailabletoextendthelifeofthecoilsandprotect themincorrosiveenvironments.
•Powerexhaustandpowerreturnfanswitheconomizerforapplication flexibility.
•VFDcontrolledandECMdrivensupply,exhaust,andreturnfansforprecise airflowcontrol,buildingpressurecontrol,andreducedpowerconsumption.
•Modulatinggasheatwithstainlesssteelheatexchangerprovidesgreaterfuel efficiency,longerheaterlife,andimprovedoccupancycomfort.
•SCR(SiliconControlledRectifier)electricheatcontrolforreducedpower consumption,longerheaterlife,andimprovedoccupantcomfort.
•Multiplehighefficiencyairfiltrationoptions.
•Unitcontrolsoptionsincludingfactoryinstalledcustomerprovidedcontrols.
•VFDcontrolledorECMdrivencondenserfansforenergysavingsand refrigerantheadpressurecontrol.
R-13 Double Wall Rigid
Polyurethane Foam Panel Construction
AAON is setting a new standard for performance with double wall construction using closed cell polyurethane foam insulation. Not only does it have several times the insulating R-value, it creates a far more rigid and stronger assembly with less air leakage than fiberglass insulatedpanels.
Dehumidification
AAON offers many humidity control options. High capacitycoolingcoilsareavailablewhichallowformore dehumidification versus standard cooling coils. Return air bypass and mixed air bypass are available on RN Series units for single coil humidity control. Modulating humidity control is available to provide energy efficient dehumidification, even with low sensible heat loads, without the temperature swings common with on/off reheatsystems.
AAONAIRE Energy Recovery Wheels
AAONAIRE energy recovery wheels, total or sensible, provide energy savings by recycling energy instead of losing energy through exhaust air streams. AAONAIRE systems also enhance indoor air quality by allowing largeramountsofoutsideairtobeprovidedtothespace andthroughimprovedhumiditycontrol.
Cutawayofpanelshowing thermalbreakandfoamcore.
FactoryinstalledAAONAIREenergyrecovery wheelsavesheatingandcoolingenergy.
RN/RQSeries
Rooftop / Air Handler
