4IPNET EAP738 User Manual

Handbook

EAP738

Enterprise Access Point

Handbook

EAP738 Enterprise Access Point ENGLISH

This document is protected by USA copyright laws and other laws. Besides, the document is the property of 4IPNET, INC. You may not copy, reproduce, distribute, publish, display, perform, or modify any part of this publication in any form or by any means without prior written permission from 4IPNET, INC. You may not alter or remove any copyright or other notice from copies of the content. All other brand and product names are claimed or registered marks of their respective companies or organizations.

To download up-to-date version, please visit www.4ipnet.com.

Handbook

EAP738 Enterprise Access Point ENGLISH

FCC CAUTION

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.

For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible.

This device is restricted to indoor use when operated in the 5.15 to 5.25 GHz frequency range.

ġFCC requires this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Handbook

EAP738 Enterprise Access Point ENGLISH

CE CAUTION

Hereby, 4ipnet, inc. declares that the radio equipment type EAP738 is in compliance with Directive

2014/53/EU.

Frequency Range and Transmit Power
Frequency range (MHz)			Max. transmit power (dBm)

2412-2472			20 dBm

5150-5350			23 dBm

5500-5700			30 dBm


	AT	BE		BG	HR	CY	CZ	DK

	EE	FI		FR	DE	EL	HU	IE

	IT	LV		LT	LU	MT	NL	PL

	PT	RO		SK	SI	ES	SE	UK

This device is restricted to indoor use.

Input Power	Operation Temperature
Power from PoE: IEEE802.3af	0 (32 ) to 40 (104 )

Model - EAP738

The device has been tested and passed the requirements of the following standards, and hence fulfills the EMC and safety requirements of RED within the CE marking requirement.

Radio: EN 300 328 V2.1.1, EN 301 893 V2.1.1

EMC: EN 301 489-1 V2.1.1, EN 301 489-17 V3.1.1

EMC: EN 55032:2015 + AC:2016 Class B, EN 55024:2010 + A1:2015 including the followings: EN 61000-4-2, EN 61000-4-3, EN 61000-4-4,

EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11

Safety: EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013

Caution

This declaration is only valid for configurations (combinations of software, firmware, and hardware) provided and supported by 4ipnet Inc. The use of software or firmware not provided and supported by 4ipnet Inc. may result in the equipment no longer being compliant with the regulatory requirements.

Requirements in AT/BE/BG/CZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/CY/LV/LI/LT/LU/HU/MT/NL/NO/PL/PT/RO/SI/SK/TR/FI/SE /CH/UK/HR. 5150MHz ~ 5350MHz is for indoor use only.

In order to ensure compliance with the exposure recommendations to electromagnetic fields, the device should be used at a minimum distance of 20cm from the body.

iii

Handbook

EAP738 Enterprise Access Point ENGLISH

Taiwan NCC Statement

	NCC			:





	5.25 ~ 5.35


)RU 81,,		*+] :/$1 :,),

>		@


03( >		@
		03(	P: FP	FP

Handbook

Preface

4ipnet EAP738 is a high-end, dual radio 802.11 b/g/n + ac (Wave 2) MIMO Access Point (AP) with the best performance for business and industrial applications and is compliant with the latest industrial wireless security standards that are required in the tightly secured enterprise network environments.

EAP738 makes the wireless communication fast, secure and easy. It supports business grade security such as 802.1X, and Wi-Fi Protected Access (WPA and WPA2). The EAP738 supports multiple point-to-point wireless links to form wider wireless network coverage.

EAP738 also features multiple ESSIDs with VLAN tags and multiple Virtual APs; great for enterprise applications, such as separating traffic from different departments using different ESSIDs. The PoE Uplink port is able to receive power from Power over Ethernet (PoE) sourcing devices.

This handbook provides instructions and reference materials to get you started with 4ipnet EAP738.

EAP738 Enterprise Access Point ENGLISH

Package Contents

1.4ipnet EAP738 x 1

2.Handbook x 1

3.Mounting Kit x 1

4.Power Adaptor (12V) x 1

It is recommended to keep the original packing material for possible future shipment when repair or maintenance is required. Any returned product should be packed in its original packaging to prevent damage during delivery.
