3D Robotics RTF Y6 User Manual

Unfold arms and legs

Remove the bolts and thumb nuts outside the blue arms. Rotate the blue arms into position, insert the bolts through the plates and the arms, and secure the arms in place with the thumb nuts.

slide arms into position

remove

travel position

Rotate the legs into place and secure through the inner hole with the provided bolt and nut.

ﬂight position

front arms (blue)

secure with bolts

rear arm (black)

ﬂight positiontravel position

Attach propellers

Remove the rings from the propeller packages. Select the ring with the smaller internal diameter, and insert it into the back of the propeller hub.

Remove the nuts and washers from the motors. Add SFP propellers to the the front-left and back-right motors and SF propellers to the front-right and back-left motors with the writing on the propellers facing towards the sky.

Place the washer over the propeller, and secure the nut tightly on top. Always ensure that the propellers are fastened tightly to the motors before ﬂying.

Charge battery

Connect the charger to the power adapter cable and a wall outlet. Connect the red cable to the + port and the black cable to the - port.

SFP

red

black

–

Set the charger to LiPo and 3A.

LiPo 3A

Connect the white connector to the 4S port. Join the two yellow connectors together.

Secure battery inside the guard bag while charging. Charge until the status indicator displays green.

red green

Charging Complete

guard bag

Battery safety

Protect battery from extreme heat, extreme cold, puncturing, and ﬂammable surfaces. Always transport, charge, and store battery in the guard bag.

Charge battery using a designated LiPo balance charger only. Always monitor battery while charging.

Flying with a low battery is a safety risk and can render battery unusable. Always discontinue use when you receive a low battery notiﬁcation, and always ﬂy with a fully charged battery.

Inspect battery for damage before takeo and after landing. If you observe any swelling of the package or battery ceases to function, locate your local battery recycling center to dispose of battery. In the US and Canada, visit call2recycle.org to ﬁnd a location. Do not dispose of battery in the trash.
