ZTE MF75 User Manual

Manual

MobiiConnect 4G Manual 2

MobiiConnect 4G Overview 4

LED indicators guide 5

Manually running the installation software 6

Logging in to the Web Management page 7

Web Management - Status icons 8

Web Management Home Page 9

Web Management - Information tab 10

Information > Statistics 11

Information > Data Limit Settings 12

Web Management - SD Card tab 13

Web Management – SMS tab 14

Web Management – Phonebook tab 14

Web Management - Settings tab 14

Settings > Network Settings > Dial up Settings 15

Settings > Network Settings > Network selection 16

Settings > Network Settings > APN 17

Settings > Wi-Fi Settings > Basic Settings 18

Settings > Wi-Fi Settings > Advanced Settings 19

Settings > WPS 20

Settings > Device settings > Account Management 21

MobiiConnect 4G Manual 3

Settings > Device settings > PIN Management 21

Settings > Device settings > Reset 23

Settings > Device settings > Power Save 24

Settings > Device settings > Update Management 24

Settings > Firewall > Port Filtering 25

Settings > Firewall > Port Mapping 26

Settings > Firewall > System Security 27

Settings > DMZ 27

Settings > Firewall > Router Settings 28

Settings > Firewall > Internet Wi-Fi 29

Using the External Antenna Ports 30

How to Factory Reset the MobiiConnect 4G 31

Uninstalling the MobiiConnect 4G software 32

Precautions and Safety Information 33

RF Safety Information 34

Radio Frequency Energy 34

Declaration of Conformity - SAR 34

Technical Specifications 35

Contact Details 38

MobiiConnect 4G Overview

1. USB plug for computer, AC

adapter or car charger adapter

2. Reset button

MobiiConnect 4G Manual 4

3. microSD™ memory card slot

4. SIM card slot (Standard size only)

5. LED status lights

LED indicators guide

Wi-Fi Status Light Meaning

Not Lit Wi-Fi is Off. Use Web Management page to turn back on

Blue solid WPS (Wi-Fi Protected Setup) is active

Blue blinking Wi-Fi is active

MobiiConnect 4G Manual 5

4G Status Light Meaning

Red Offline, not registered on a mobile network

Green solid Registered on 3G or 2G network

Green blinking Active data transfer on 3G or 2G network

Blue solid Registered on 4G network

Blue blinking Active data transfer on 4G network

MobiiConnect 4G Manual 6

Manually running the installation software

The installation software is pre-loaded onto your USB modem. Typically, it will run automatically when you plug it in
to a computer for the first time, but you can run it manually by doing the following.

1. Plug the modem into a USB port on your computer.

2. If use Microsoft Windows and you see an AutoPlay window pop up, click Open folder to view files.

3. Otherwise, you’ll need to open My Computer (Windows) or Macintosh HD (Mac) and double click on the USB

drive that the MobiiConnect 4G is plugged into e.g. CD Drive (E:) MobiiConnect 4G

4. Double click Autorun.exe

5. Run through the on-screen instructions. The installation will create a shortcut icon on your desktop.

2 3 4

Logging in to the Web Management page

MobiiConnect 4G Manual 7

1. Open your internet browser and go to http://192.168.0.1

2. Log in with the default password admin. If you’ve changed your password from the default, use your custom

password instead.

Web Management - Status icons

You’ll see these icons in the upper right-hand corner of the Web Management page.

Status Icon Meaning

No SIM, PIN locked, PUK locked or faulty SIM

SIM card is inserted

MobiiConnect 4G Manual 8

No Network signal

Network signal level indicator

Internet is disconnected

Internet is connected

Wi-Fi is ON with number of connected users

Web Management Home Page

MobiiConnect 4G Manual 9

The Disconnect button on the Home page will take MobiiConnect 4G offline.

Web Management - Information tab

MobiiConnect 4G Manual 10

You can view the device information on this page.

Tip

Click Change to customise your Wi-Fi network name (SSID).

Information > Statistics

MobiiConnect 4G Manual 11

Select Statistics from the left-hand column to view your data usage on this page.

Please note that data usage shown here is approximate. Always refer to usage records provided by your Mobile

Broadband provider. iiNet Group customers will find their usage records available in toolbox.iinet.net.au or their
equivalent account management page.

Information > Data Limit Settings

MobiiConnect 4G Manual 12

Select Data Limit Settings from the left-hand column to set data usage limits and reminders on your device.

Please note that data usage recorded is approximate and may not be aligned with your billing cycle. Always refer

to the usage alerts sent by your Mobile Broadband provider via SMS and/or email.
