ZTE MF112A User Manual

MF667C

USB Modem

Quick Guide

ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: [phone]
URL: http://www.zte.com.cn
E-mail: [e-mail]

LEGAL INFORMATION

Copyright © 2012 ZTE CORPORATION.

All rights reserved.

No part of this publication may be excerpted, reproduced, translated or utilized in any form or by
any means, electronic or mechanical, including photocopying and microfilm, without the prior
written permission of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve the right to make modifications on print
errors or update specifications without prior notice.

Version No. : R1.0
Edition Time: 2012.08
Manual No. :

Quick Guide

Introduction

The ZTE MF667C USB modem is a multi-mode USB modem, working in
HSPA/HSUPA/HSDPA/WCDMA/EDGE/GPRS/GSM networks. With USB interface connecting
to a laptop or a desktop PC, it integrates the functionality of a modem and a mobile phone (SMS),
and combines mobile communication with Internet perfectly. It supports data and SMS services
through the mobile phone network, enabling you to communicate anytime and anywhere.

Specification

The following table shows the specification of your device.

Interface type USB 2.0 HIGH SPEED

Systems supported Supports most types of laptop and desktop PC.

Operating systems
supported

Functions SMS service, Data service, Applications management, support

Network standards HSPA/HSUPA/HSDPA/WCDMA/EDGE/GPRS/GSM

Transmission speed
(Max)

Temperature

Windows XP (SP3 and above), Vista, Windows 7
MAC 10.4.11 and later
Linux (Kernel 2.6.20 later)

microSD card, etc.

HSDPA: 14.4 Mbps UL
HSUPA: 5.76 Mbps UL

Storage: -20 ℃ ~ +70 ℃

Operation:-10 ℃ ~ +60 ℃

Dimension 72 mm * 27.5 mm * 10.5 mm (Without USB Cap)

Weight About 21.5 g

microSD capability Support up to 32 GB microSD card

Confidential and Proprietary Information of ZTE CORPORATION 1

Notes:

The microSD Logo ( ) is a trademark of SD Card Association.

Getting to know your device

The following figure shows the appearance of the MF667C. It is only for your reference. The
actual product may be different.

1. microSD card slot

2. SIM/USIM card slot

3. USB Connector

4. Modem Cap

5. Front Cover

Hardware Installation

1. Press and push the front cover and remove it.
