ZEISS Loxia lenses
Manual full frame lenses for
Sony α7 cameras.
The moment you e njoy full
creative freedom.
This is the mome nt we work for.
// INSPIRATION
MADE BY ZEISS
Enjoy classic photography with modern
technology. The lightweight Loxia® lenses from ZEISS
give you the best of both worlds: The fantastic creative
possibilities only available with manual focus and
the benefits of modern full frame photography from the
Sony α7 camera series. Let your creativity run free.
4Photo: Christoph Rieß, ZEISS Loxia 2/50
5
6
Loxia lenses from ZEISS are perfectly suited to
the many strengths of Sony α7 series cameras.
Add to that their compact size and low weight,
and you have a series of lenses you can use just
about anywhere for high quality photographs
and films.
High precision
• Precise and durable construction, low weight.
• The functionality of the Loxia lenses is perfectly matched with
the camera functions of the Sony α7-series.
7
Perfect for photography and video
• High quality images thanks to proven optical design.
• Automatic activation of the magnification function when
turning the focus ring.
• Optional switchable aperture lock, allowing for smooth
adjustment in video mode.
• Consistent 180° focus ring rotation for all lenses in the series.
High quality construction
• Robust, all-metal construction for many years of use.
• Grippy focus ring for fine manual adjustment.
• A special gasket at the mount protects the connection
between camera and lens.
ZEISS Loxia lenses come standard with a matching lens shade.
8
Photo: Tobias Brandstetter, ZEISS Loxia 2/35
ZEISS Loxia 2/35
The subtle reporter. An extended field of view
makes this versatile lens ideal for showing a subject in
their environment. It’s also just as good for reportage
and street photography or even for portraits, detail
shots and landscapes.
9
Design
• Biogon
®
with 9 lens elements in
6 groups
• Lens made of special glass with
anomalous partial dispersion
Focal length 35 mm
Aperture range f/2.0–f/22
Elements/groups 9/6
Focusing range m/ft 0.30–∞/0.98–∞
Field angle* (diag./horiz./vert.) 63°/54°/37°
Coverage** mm/inch
210.2 x 139.4/8.28 x 5.49
*Based on 35 mm format. **At close range.
10Photo: Arato Ogura, ZEISS Loxia 2/35
11
12
Photo: Christoph Rieß, ZEISS Loxia 2/50
ZEISS Loxia 2/50
The flexible all-rounder. Compact and light, this
lens shines in many applications. Regardless of whether
it’s for street photography, landscapes, portraits or
spontaneous discoveries, the ZEISS Loxia 2/50 is the
ideal companion for photographic and filmic exploration.
13
Design
• Planar
®
with 6 lens elements in
4 groups
Focal length 50 mm
Aperture range f/2.0–f/22
Elements/groups 6/4
Focusing range m/ft 0.45–∞/1.48–∞
Field angle* (diag./horiz./vert.) 46.78°/39.38°/26.70°
Coverage** mm/inch
255.1 x 168.3/10.04 x 6.63
*Based on 35 mm format. **At close range.
14
Length
mm/inch
Diameter
mm/inch (max.)
Weight*
g/oz.
Filter thread E
Wide angle
Loxia 2/35 66/2.6 62.1/2.44
340/12 M 52 x 0.75
Standard
Loxia 2/50 66.2/2.6 62.1/2.44
320/11.29 M 52 x 0.75
Technical specifications. How large, how heavy,
available with which mounts? All the technical
information you need is here. For more information,
visit zeiss.com/photo.
15
Weight
g/oz.
Filter thread E
340/12 M 52 x 0.75
•
320/11.29 M 52 x 0.75
•
16
17
Accessories – original accessories and care
products from ZEISS perfectly complement the
unique product experience offered by our lenses.
Please note: a suitable lens hood comes as
standard with all ZEISS lenses.
ZEISS T UV filters and POL filters (circular)
These filters feature T ® anti-reflective coating and are
optimal for protecting your front lens. The UV filters afford
your pictures more brilliance, the POL filters reduce reflections
on nonmetallic surfaces and increase color saturation.
• High fitting accuracy for fast filter change
• Can be used with a lens shade
• Available in all standard sizes
ZEISS Air Cell comfort straps
With patented Air Cell padding, these camera straps minimize
shoulder and neck strain, even with heavy equipment.
• High degree of wearing comfort with Air Cell padding
• Strap length adjustable at both ends
ZEISS lens Cleaning Kit
The Lens Cleaning Kit is designed for use with multi-coated
camera lenses. The cleaning kit is packed in a fabric belt bag
and contains:
• Lens cleaning agent
• Dust brush
• Microfiber cloth
• 10 moistened cleaning cloths
• User manual for professional lens care
18
Photo: Christoph Rieß, ZEISS Loxia 2/50
Share your fascination – together with others.
Visit ZEISS online to stay in touch with other photographers, exchange tips and tricks and get regular
news updates. On our blog, Facebook, Twitter, Flickr
and Vimeo sites, you can find a large community of
photographers and videographers from all over the
world. We look forward to seeing you there!
Become part of the ZEISS community
zeiss.com/photo/social
19
Visit our blog and read the stories of outstanding
photographers and how they master their daily challenges
with the help of ZEISS lenses.
zeiss.com/clnblog
https://flic.kr/s/aHsjYUcnuN
EN_10_025_152l Printed in Germany ZIG-CZ-VIII/2014 NToo
Subject to change in design and scope of delivery and as a result of ongoing technical development.
