Diesel Engine Parts Catalog
YC4D
Yuchai machinery Co. Ltd.
2005, 1
2
Preface
Respected customers of Yuchai:
Thank you for choosing products of Yuchai and reading <YC4D Diesel Engine Parts Catalog>!
The service principles of Yuchai are to try our best to serve you, and serve you wholeheartedly and faithfully. In order to carry out them better, We edit
and print <YC4D Diesel Engine Parts Catalog>. We hope this catalog can let users know our products’ construct and configuration, easily use, maintain
and purchase parts.
This catalog is based on the product’s drawing and data made in 2005. All main parts of YC4D (D0800) are listed in this catalog.
With the product improvement and users’ requirements, part of content will change to some extend. Yuchai keeps the right of modifications which are
not informed in advance. The detail configuration should accord to the product technical documents of the day.
<YC4D Diesel Engine Parts Catalog> is planed by Yuchai machinery Co. Ltd and edited by Yuchai technical design department.
If there is any mistake in <YC4D Diesel Engine Parts Catalog>, please point out and make it better. Thank you!
Yuchai machinery Co. Ltd.
2005, 1
3
Contents
Item
Part No.
Part Name
Page
Remark
Item
Part No.
Part Name
Page
Remark
1
D0200-1002000
Cylinder block assembly
3
23
D30-1307000
Water pump assembly
47 2
D30-1002030A
Timing gear housing parts
5
24
D0200-1308000
Fan assembly
49 3
D0300-1003000
Cylinder head assembly
7
25
D0200-3509000
Air compressor assembly
51 4
D0200-1004000
Piston and connecting rod assembly
9
26
D30-3701000
Charging generator assembly
53
5
D0800-1005000
Crankshaft and flywheel assembly
11
27
D30-3708000
Starter assembly
55
6
D30-1006000A
Camshaft assembly
13
28
D30-3800000
Gauge parts
57 7
D30-1007000A
Valve & drive train assembly
15
8
D0800-1008010
Intake manifold assembly
17
9
D0200-1008020
Exhaust manifold assembly
19
10
D30-1009000
Oil sump assembly
21
11
D30-1010000
Oil strainer assembly
23
12
D30-1011000
Oil pump assembly
25
13
D30-1012000
Oil filter assembly
27
14
D30-1013000A
Oil cooler assembly
29
15
D0800-1104000
Fuel line assembly
31
16
D0200-1105000A
Fuel filter assembly
33
17
D0800-1111000
Fuel injection pump assembly
35
18
D0800-1112000
Fuel injector assembly
37
19
D0200-1118000
Turbocharger assembly
39
20
D30-1303000
Water outlet pipe assembly
41
21
631-1305000
Water drain cock assembly
43
22
6105Q-1305100
Water inlet cock assembly for heater
45
4
1 D0200-1002000 Cylinder block assembly
5
1 D0200-1002000 Cylinder block assembly
Item
Part No.
Part Name
Num.
Remark
Item
Part No.
Part Name
Num.
Remark
1
Q40308
Washer 8 3
23
Q5220408
Pin 4×8
2 2
Q150B0855TF2
Bolt M8×55
3
24
330-1002013
Middle main bearing cover
1 3
D30-1002054
Timing idler gear plate
1
25
330-1002021A
Main bearing bolt
10 4
6105QA-1002011
Camshaft bushing
1
damageable
26
D30-1002012A
Front main bearing cover
1 5
D30-1002051
Timing idler gear
1
27
Q61101
Castle tapered face screw plug NPT1/8
1 6
D30-1002052
Idler shaft 1
28
D30-1002114
Cylinder block
1
7
D30-1002069
Main oil gallery plug
4
29
D30-1002064B
Cylinder liner
4
8
630-1003081
Water jacket plug
2
30
A3000-1002063/B
Cylinder liner seal ring
4
damageable
9
6105Q-1002081A
Dipstick sleeve
1
31
D30-1002011
Camshaft bushing
5
damageable
10
6105Q-1002082
O ring 9×1.6
1
damageable
11
D30-1002090A
Dipstick welded part
1 12
Q72240
Plug 40 2
13
D30-1002062A
Camshaft cover gasket
1
damageable
14
D30-1002061
Camshaft cover
1 15
Q40308
Washer 8 3
16
Q150B0820
Bolt M8×20
3 17
Q5220312
Pin 3×12
4 18
D30-1002170A
Nozzle parts
4 19
430-1002163
Washer 4
20
430-1002162B
Hollow bolt for oil
4 21
D30-1002067A
Plug 2
22
330-1002014
Main bearing cover
3
6
2 D30-1002030A Timing gear housing parts
7
2.D30-1002030A Timing gear housing parts
Item
Part No.
Part Name
Num.
Remark
Item
Part No.
Part Name
Num.
Remark
1
D30-1002211B
V-ribbed belt idler
1
27
GB/T9877.1-FB659012F
Seal ring FB65×90×12F
1
damageable
2
GB/T276-6010-2RS
Antifriction bearing 6010-2RS
2
28
D30-1002037
TDC pointer
1 3
Q43080
Snap ring 80
2
29
Q1200816
Stud M8×16
2 4
D30-1002213B
V-ribbed belt idler shaft
1
30
Q40108
Washer 8 2
5
Q40308
Washer 8 3
31
Q40308
Washer 8 2
6
Q150B0865
Bolt M8×65
3
32
Q150B0865
Bolt M8×65
2 7
Q40110
Washer 10
2
33
D30-1002031C
Timing gear housing cover
1 8
Q40310
Washer 10
2
34
Q5220814
Pin 8×14
1 9
Q150B1025
Bolt M10×25
2
35
D30-1002034C
Timing gear housing cover gasket
1
damageable
10
D30-1002038
Power steering pump cover
1
36
D30-1002033C
Gear housing cover
1 11
GB3452.1--26507500
O ring 75×2.65
1
damageable
37
Q1200818
Stud M8×18
1 12
Q40108
Washer 8 1
38
Q1200820
Stud M8×20
2 13
Q40308
Washer 8 1
39
Q40108
Washer 8
10
14
Q150B0870
Bolt M8×70
1
40
Q40308
Washer 8
10
15
Q40108
Washer 8 1
41
Q150B0822
Bolt M8×22
10 16
Q40308
Washer 8 1
42
Q40308
Washer 8 3
17
Q340B08
Nut M8 2
43
Q340B08
Nut M8 3
18
30-1002040
Fuel injection pump gear cover parts
1
44
Q1200865
Stud M8×65
3 19
Q40108
Washer 8 5
45
Q40108
Washer 8 3
20
Q40308
Washer 8 5
46
Q40308
Washer 8 3
21
Q150B0820
Bolt M8×20
5
47
Q340B08
Nut M8 3
22
D30-1002036
Fuel pump gear cover gasket
1
damageable
48
Q40108
Washer 8 1
23
6105Q--1600011
Flat pin 1
49
Q40308
Washer 8 1
24
Q40108
Washer 8 2
50
Q150B0855
Bolt M8×55
1
25
Q40308
Washer 8 2
51
D30-1002212A
Spacer 1
26
Q150B0850
Bolt M8×50
2
8
3 D0300-1003000 Cylinder head assembly
9
3 D0300-1003000 Cylinder head assembly
Item
Part No.
Part Name
Num.
Remark
Item
Part No.
Part Name
Num.
Remark
1
330-1003013A
Cylinder head long bolt
4
23
1530-1014023
Vent hose
1 2
D30-1003018
Cylinder head short bolt (Ⅱ)
4
24
150-1014022
Clamp 1
3
Q614B06
Square tapered face screw plug NPT3/4
3
25
1530-1014021
Vent hose bracket
1 4
330-1003014A
Cylinder head short bolt
6
26
150-1003041E
Oil filler cap
1 5
6105Q-1003085
Hanger 2
27
150-1003043B
Seal ring 1
6
D30-1003017
Washer 4
7
D30-1003015B
Cylinder head
1
8
6105Q-1003081
Water jacket plug (1)
8
9
6105QA-1003088
Cylinder head dowel pin sleeve
2
10
D30-1003011A
Cylinder head gasket
1
damageable
11
D30-1003018
Cylinder head short bolt (Ⅱ)
4
12
Q2140620
Screw M6×20
1
13
Q340B06
Nut M6 1
14
D30-1003022C
Cylinder head cover gasket
1
15
Q1840816
Bolt M8×16
10
16
D30-1003060C
Cylinder head cover welded part
1
17
330-1003053
Seal ring 1
18
Q40106
Washer 6 2
19
Q40306
Washer 6 2
20
Q150B0616
Bolt M6×16
2
21
D30--1003120
Breather parts
1
22
Q67638
Circlip 38 1
10
4 D0200-1004000 Piston and connecting rod assembly
11
4 D0200-1004000 Piston and connecting rod assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
A30-1004016
First compression ring
4
damageable
2
A30-1004017
Second compression ring
4
damageable
3
A30-1004030
Oil scraper ring
4
damageable
4
D30-1004001
Piston
4
damageable
5
6105Q-1004019B
Piston pin 4
6
Q43038
Retaining ring 38
8
damageable
7
530-1004052
Connecting rod bushing
4
damageable
8
530-1004051
Connecting rod
4
9
530-1004019
Connecting rod bearing
8
damageable
10
530-1004053
Connecting rod cap
4
11
530-1004054
Connecting rod bolt
8
damageable
12
5 D0800-1005000 Crankshaft and flywheel assembly
13
5 D32-1005000 Crankshaft and flywheel assembly
Item
Part No.
Part Name
Quantity
Remark
Item
Part No.
Part Name
Quantity
Remark
1
GB9877.1-88
Oil seal FB100×125×12F
1
23
6105Q-1005058A
Crankshaft thrust plate
1
damageable
2
D0200-1600015A
Clutch case
1
24
D30-1005055
Crankshaft lower bearing (narrow)
4
damageable
3
Q40114
Washer 14
4
25
D30-1005056A
Crankshaft upper bearing (wide)
1
damageable
4
Q40314
Washer 14
4
26
D30-1005054
Crankshaft upper bearing (narrow)
4
damageable
5
Q150B1455
Bolt M14×55
4
27
Q5511296
Key 12×96
1 6
Q40108
Washer 8 4
28
6105Q-1005021
Crankshaft timing gear
1 7
Q40308
Washer 8 4
29
D30-1005023
Spacer
1 8
Q150B0816
Bolt M8×16
4
30
D30-1005022
Oil pump driving gear
1 9
532-1005062A
Flywheel ring gear
1
31
D30-1005030
Pulley damper assembly
1
10
D32-1005061A
Flywheel 1
32
D30-1005051
Damper tightening bolt gasket
1
11
D32-1600200
Clutch driven plate
1
33
D30-1005052
Damper tightening bolt
1
12
D32-1600050
Clutch cover and pressure plate
1
34
6105Q-1600021
Clutch fork flange
1
13
Q40110
Washer 10
8
35
6105Q-1600022
Clutch fork bushing
2
14
Q40310
Washer 10
8
36
Q150B1035
Bolt M10×35
2
15
Q/YC1821022
Bolt M10×22
n
12 parts
37
Q40310
Washer 10
2
16
Q/YC1821028
Bolt M10×28
n
38
630-1600018
Small cover gasket
1
17
Q5221022
Pin B10×20
2
39
6105Q-1600017
Clutch bottom cover
1
18
330-1005044
Flywheel bolt
7
40
Q40112
Washer 12
6
19
GB/T276-6205-Z
Antifriction bearing 6205-Z
1
41
Q40312
Washer 12
6
20
6105Q-1005042
Dowel pin
1
42
6105Q-1600011
Flat pin
1
21
D0800-1005001
Crankshaft
1
43
Q5221224
Pin B12×24
1
22
D30-1005057
Crankshaft lower bearing (wide)
1
damageable
44
Q150B1250
M12×50
6
14
6 D30-1006000A Camshaft assembly
15
6 D30-1006000A Camshaft assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
D30-1006015B
Camshaft 1
2
GB/T1096-C0828
Key 8×28
1
damageable
3
6105Q-1006017
Spacer - camshaft timing gear
1
4
D30-1006016
Camshaft thrust plate
1
5
Q/YC1820820
Bolt M8×20
2
6
D30-1006021
Camshaft timing gear
1
7
630-1006019
Washer 1
8
Q40312
Washer 12
1
9
Q150B1238TF2
Bolt M12×28
1
16
7 D30-1007000A Valve & drive train assembly
17
7 D30-1007000A Valve & drive train assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
D30-1003111A
Intake valve
4
Damageable
23
A30-1007092
Washer 4
2
430-1007019A
Intake valve seat
4
Damageable
24
D30-1007036
Hexagon head bolt
4 3
150-1007021E
Valve key
16
Damageable
25
6105Q-1007054
Lock nut
8
Damageable
4
D30-1003116
Valve spring retainer
8
Damageable
26
6105QA-1007053
Valve adjusting screw
8
Damageable
5
430-1007016A
Valve stem oil seal
8
Damageable
27
6105QA-1007032
Rocker arm shaft spring
3 6
6105Q-1007023
Valve inner spring
8
Damageable
28
J3100-1007051
Exhaust valve rocker arm
4 7
6105Q-1007022
Valve outer spring
8
Damageable
29
J3100-1007061
Intake valve rocker arm
4 8
430-1007018
Valve guide
8
Damageable
30
630-1007052
Rocker arm bushing
8
Damageable
9
D30-1003103A
Exhaust valve
4
Damageable
10
430-1007021A
Exhaust valve seat
4
Damageable
11
D30-1007081
Push rod
8
Damageable
12
6105Q-1007091A
Tappet
8
Damageable
13
Q43125
Snap ring 25
2
14
6105QA-1007031
Rocker arm shaft washer
6
15
6105QA-1007042
Bowl type plug
2
16
D30-1007041A
Rocker arm
1
17
6105Q-1007073
Union bolt
2
18
D30-1007075A
Oil pipe welded part
1
19
Q/YC149-8
Compound seal washer 8
4
Damageable
20
D30-1007034
Rocker arm shaft seat (1)
1
21
D30-1007031
Rocker arm shaft washer
2
22
D30-1007033
Rocker arm shaft seat (2)
3
18
8 D0800-1008010 Intake manifold assembly
19
8 D0800-1008010 Intake manifold assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
Q340B10
Nut M10 4
2
Q40310
Washer 10
4
3
Q40110
Washer 10
4
4
Q1201035
Stud M10×35
4
5
E0300-1008017
Intake union pipe
1
6
1530-1008016B
Intake union pipe gasket
1
Damageable
7
D0200-1008015C
Intake manifold
1
8
1D30-1008011
Intake manifold gasket
1
Damageable
9
Q150B08110
Bolt M8×110
4
10
6105Q-3509013
Washer
12
11
Q40308
Washer 8
12
12
Q150B0832
Bolt M8×32
8
20
9 D0200-1008020 Exhaust manifold assembly
21
9 D0200-1008020 Exhaust manifold assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
Q1800865TF2
Bolt M8×65
8
2
430-1008027
Exhaust manifold gasket
4
Damageable
3
D0200-1008101
Exhaust manifold
1
4
D0200-1008028A
Exhaust union pipe for turbocharger
1
5
Q150B0830TF2
Bolt M8×30
5
22
10 D30-1009000 Oil sump assembly
23
10 D30-1009000 Oil sump assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
D30-1009102A
Washer 4
2
6105Q-1009031C
Drain screw plug
1
3
Q/YC149-27
Compound seal washer 27
1
4
6105Q-1009032A
Drain screw plug magnet
1
5
Q/YC1830820TF2
Bolt M8×20
22
6
6105Q-3509013
Washer
18
7
D30-1009020B
Oil sump welded part
1
8
D30-1009011C
Oil sump gasket
1
Damageable
9
10
1
11
1
24
11 D30-1010000 Oil strainer assembly
25
11 D30-1010000 Oil strainer assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
D30-1010050
Compound seal washer
1
2
D30-1010010
Oil inlet pipe welded part
1
3
Q40308
Washer 8 3
4
Q150B0850TF2
Bolt M8×50
2
5
Q150B0820TF2
Bolt M8×20
1
6
6105QA-1010132B
Filter screen
1
Damageable
7
6105QA-1010131A
Filter screen bracket
1
26
12 D30-1011000 Oil pump assembly
27
12 D30-1011000 Oil pump assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
530-1011034
Oil pump shaft bushing (II)
1
Damageable
2
D30-1011041A
Gasket
1
Damageable
3
D30-1011031
Oil pump cover
1
4
D30-1011053
Outer rotor
1
5
D30-1011052
Inner rotor
1
6
D30-1011051
Oil pump shaft
1
7
Q5220412
Pin A4×12
2
8
Q5500419
Half circle key 4×19
1
Damageable
9
D30-1011035
Oil pump body
1
10
Q40108
Washer 8 5
11
Q40308
Washer 8 5
12
530-1011033
Oil pump shaft bushing (I)
1
Damageable
13
Q150B0845TF2
Bolt M8×45
3
14
D30-1011011
Oil pump driven gear
1
15
Q150B0832TF2
Bolt M8×32
2
28
13 D30-1012000 Oil filter assembly
29
13 D30-1012000 Oil filter assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
6105Q-1012002
Oil filter gasket
1
2
D30-1012001A
Oil filter drain guide pipe
1
3
D30-1012010B
Oil filter 1
4
Q40110
Washer 10
2
5
Q40310
Washer 10
2
6
Q150B10105
Bolt M10×105
1
7
Q150B1085
Bolt M10×85
1
30
14 D30-1013000A Oil cooler assembly
31
14 D30-1013000A Oil cooler assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
D30-1013013
Oil cooler core
1
23
Q40308
Washer 8
4 2
D30-1013014
Gasket
2
Damageable
24
Q340B08
Nut M8
4 3
Q1200820
Stud M8×20
2
25
Q40110
Washer 10
4 4
Q1200845
Stud M8×45
2
26
Q40310
Washer 10
4 5
D30-1013012A
Oil cooler cover gasket
1
Damageable
27
Q150B1045
Bolt M10×45
4 6
Q61904
Screw plug NPT 1/2
4
7
D30-1013011A
Oil cooler cover
1
8
GB/T308-14G100b
Steel ball 14 G100b
1
9
530-1013015
Bypass valve spring
1
10
D30-1013017
Washer 1
11
530-1013016
Bypass valve screw plug
1
12
Q40110
Washer 10
2
13
Q40310
Washer 10
2
14
Q150B1030
Bolt M10×30
2
15
Q40110
Washer 10
1
16
Q40310
Washer 10
1
17
Q150B1065
Bolt M10×65
1
18
Q40110
Washer 10
1
19
Q40310
Washer 10
1
20
Q150B1070
Bolt M10×70
1
21
6QA1-1002174
Pipe union
1
22
Q40108
Washer 8 4
32
15 D0800-1104000 Fuel line assembly
33
15 D0800-1104000 Fuel line assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
6105Q-1104100B, C
Fuel injection pump feed line assembly
1
2
6105Q-1104090B, C
Fuel filter feed line assembly
1
Damageable
3
D0800-1104130
One pipe clamp assembly
1
Damageable
4
D0800-11041D1
No.4 cylinder high-pressure pipe
1
5
150-1104019
Fuel line protecting sleeve
1
Damageable
6
150-1104017A
Fuel high-pressure pipe union nut
8
7
D0800-11041C1
No.3 cylinder high-pressure pipe
8
8
D0800-1104140
Two pipes clamp assembly
1
Damageable
9
D0800-11041B1
No.2 cylinder high-pressure pipe
1
10
D0800-1104150
Three pipes clamp assembly
2
Damageable
11
1D30-1104110
Fuel returning hose assembly
1
12
E0200-1104050
Four pipes clamp assembly
1
Damageable
13
D0800-11041A1
No.1 cylinder high-pressure pipe
1
1 Damageable
34
16 D0200-1105000A Fuel filter assembly
35
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
231-1105010
Fuel filter 1
2
Q1200825
Stud M8×25
2
3
6105Q-3509013
Washer 2
4
Q40308
Washer 8 2
5
Q340B08
Nut M8 2
16 D0200-1105000A Fuel filter assembly
36
17 D0800-1111000 Fuel injection pump assembly
37
17 D0800-1111000 Fuel injection pump assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
D0800-1111070
Injection timing device
1
Optional
20
Q/YC901-1C1010
Hinged bolt M10×1
1
D0800-1111070A
Injection timing device
1
Optional
21
1D30-1111090
Turbocharger compensation pipe
1
2
D30-1111062A
Connecting plate gasket
1
22
Q150B1075
Bolt M10×75
2
3
Q150B1025TF2
Bolt M10×25
4
4
Q40310
Washer 10
8
5
Q40110
Washer 10
8
6
D0800-1111050
Fuel injection pump part
1
Optional
D0800-1111050A
Fuel injection pump part
1
Optional
D0800-1111050B
Fuel injection pump part
1
Optional
7
Q150B0820
Stud M8×20
2
8
D0800-1111242
Bracket 1
9
Q40308
Washer 8
4
10
Q150B0825
Bolt M8×25
2
11
330-3701035
Washer 4
12
D30-1111040
Oil pipe part for fuel injection pump
1
13
Q1201030TF2
Stud M10×30
4
14
D0800-1111241
Bracket 1
15
Q3400B10
Nut M10 4
16
Q/YC901-1C0810
Hinged bolt M8×1
2
17
D30-1111062A
Compound seal washer 8
4
18
Q40110
Union seat
1
19
Q40310
Washer 10
4
38
18 D0800-1112000 Fuel injector assembly
39
18 D0800-1112000 Fuel injector assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
6105QA-1112013
Injector gasket
N
Damageable
2
D0800-1112011
Injection nozzle precision parts
4
Damageable
3
D0800-1112010
Injector 4
4
150-1112012
Bolt 4
5
150-1112011
Washer 8
6
Q1201035
Stud M10×35
8
7
A30-1112022A
Fastening plate
4
8
Q40310
Washer 10
8
9
Q340B10
Nut M10 8
40
19 D0200-1118000 Turbocharger assembly
41
19 D0200-1118000 Turbocharger assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
D0200-1118020A
Turbocharger
1
2
150-1118031A
Gasket
1
Damageable
3
D0200-1118060
Turbocharger oil returning pipe welded part
1
4
Q40306
Washer 6 2
5
Q150B0620
Bolt M6×20
2
6
Q67527
Circlip 27 2
7
D0300-1118053
Oil returning pipe protection sleeve
1
Damageable
8
1530-1118052
Oil returning pipe union bolt
1
9
150-1118031A
Gasket 1
10
Q/YC901-3C12
Washer 12
4
11
D0200-1118031
Hollow bolt for oil
2
12
D0300-1118040
Oil inlet pipe welded part
1
13
E0200-1118011
Stud 4
14
1530-1118012
Turbocharger gasket
1
15
Q40108
Washer 8 4
16
Q40308
Washer 8 4
17
E0200-1118013
Nut M8×1 4
18
1530-1118072A
Exhaust union pipe gasket
1
19
393-1118001
Hollow bolt for oil
1
42
20 D30-1303000 Water outlet pipe assembly
43
20 D30-1303000 Water outlet pipe assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
Q340B08
Nut M8 5
2
Q40308
Washer 8
13
3
Q40008
Washer 8
13
4
Q1200825
Stud M8×25
2
5
D30-1303011
Thermostat cover
1
6
A3000-1303012
Thermostat cover gasket
1
Damageable
7
6105QA-1306010
Wax thermostat
1
Damageable
8
6105Q-1305100
Water inlet cock assembly for heater
1
9
630-1303014
Thermostat seat
1
10
6105Q-1303013
Thermostat seat gasket
1
Damageable
11
Q1200822
Stud M8×22
3
12
365C-3800020
Water temperature sensor
1
Damageable
13
D30-1303020C
Water outlet pipe parts
1
14
Q150B0820
Bolt M8×20
8
15
6105Q-1303015
Water outlet manifold gasket
1
Damageable
16
D30-1306016
Water returning hose
1
Damageable
17
Q67545
Circlip 45 2
44
21 631-1305000 Water drain cock assembly
45
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
631-1305015
Water drain cock handle
1
2
Q5003225
Pin 3.2×25
1
3
6105Q-1305014
Drain valve core
1
4
6105Q-1305013
Drain valve body
1
5
6105Q-1305012
Washer 1
6
6105Q-1305011
Spring 1
7
Q40006
Washer 6
1
8
Q5001610
Pin 1.6×10
1
20 631-1305000 Water drain cock assembly
46
22 6105Q-1305100 Water inlet cock assembly for heater
47
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
Q5001612
Cotter pin 1.6×12
1
2
6105Q-1305103
Spring 1
3
Q40105
Washer 5
2
4
6105Q-1305101
Valve body
1
5
6105Q-1305102
Valve core
1
6
6105Q-1305104
Control lever
1
22 6105Q-1305100 Water inlet cock assembly for heater
48
23 D30-1307000 Water pump assembly
49
23 D30-1307000 Water pump assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
D30-1307042A
V-ribbed belt
1
Damageable
2
Q150B0850
Bolt M8×50
4
3
Q40308
Washer 8 4
4
D30-1307020C
Water pump
1
5
D30-1307026A
Water pump gasket
1
Damageable
6
Q618B03
Screw plug NPT3/8
1
50
24 D0200-1308000 Fan assembly
51
24 D0200-1308000 Fan assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
Q1841030TF2
Bolt M10×30
4
2
6105Q-1308010B, C
Fan parts
1
3
Q40108
Washer 8
1
4
Q40308
Washer 8
1
5
Q150B0820
Bolt M8×20
1
6
D30-1308021
Protecting plate
1
7
D0200-1308022
Belt pulley
1
8
GB/T276-6206-2RD
Antifriction bearing 6206-2RD
1
9
D30-1308023
Spacer (I)
1
10
GB/T276-6207-2RD
Antifriction bearing 6207-2RD
1
11
Q43072
Snap ring 72
1
12
D30-1308024
Spacer (II)
1
13
Q1841020TF2
Bolt M10×20
4
14
D30-1308025
Fan shaft
1
52
25 D0200-3509000 Air compressor assembly
53
25 D0200-3509000 Air compressor assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
D30-3509011
Air compressor gear
1
2
D30-3509001A
Air compressor gasket
1
Damageable
3
Q151B1030
Bolt M10×1×30
1
4
D30-3509010A
Air compressor
1
5
Q/YC149-8
Compound sealing washer 8
4
Damageable
6
D30-3509030
Air compressor oil inlet pipe welded part
1
7
6105Q-1007073
Union bolt 1
8
Q150B1035
Bolt M10×35
3
9
Q40310
Washer 10 4
10
Q40110
Washer 10 4
54
26 D30-3701000 Charging generator assembly
55
26 D30-3701000 Charging generator assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
D30-3701010
Charging generator
1
2
Q150B0830
Bolt M8×30
1
3
Q40308
Washer 8
1
4
6105Q-3509013
Washer 1
5
Q151B10100
Bolt M10×100
1
6
D30-3701030A
Charging generator adjusting plate
1
7
Q150B10130
Bolt M10×130
1
8
Q40310
Washer 10
1
9
Q40110
Washer 10
1
10
Q340B10
Nut M10
1
56
27 D30-3708000 Starter assembly
57
27 D30-3708000 Starter assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
D30-3708010A
Starter 1
2
Q150B1030
Bolt M10×30
3
3
Q40310
Washer 10
3
4
Q40110
Washer 10
3
58
28 D30-3800000 Gauge assembly
59
28 D30-3800000 Gauge assembly
Item
Part No.
Part Names
Quantity
Remark
Item
Part No.
Part Names
Quantity
Remark
1
365C-3800020
Water temperature sensor
1
Damageable
2
365C-3800030
Oil pressure transmitter
1
Damageable
Loading...
