User’s
Model
Function
A: Free program
R: Temperature-pressure compensation
S: Addition/Subtraction
T: Multiplication/Division
U: Square root extraction
V: High selector
W: Low selector
Input signal
A: 0 to 50 mA DC Span is 1 mA or more
1: −10 to +10 V DC Span is 0.1 V or more
Output signal
A: 0 to 20 mA DC Span is 2 mA or more
B: 0 to 5 mA DC Span is 1 mA or more
1: 0 to 10 V DC Span is 0.1 V or more
2: 0 to 100 mV DC Span is 10 mV or more
3: −10 to +10 V DC Span is 0.2 V or more
4:
−100 to +100 mV DC Span is 20 mV or more
Power supply
1: 15-40 V DC (Operating range: 12 to 48 V DC)
2: 100-240 V AC (Operating range: 85 to 264 V AC)
Optional specification
/R250: With 250 Ω receiving resistor
MXT- N - *B/
Manual
Model MXT
Universal Computing Unit
(3-input, Isolated 1-output Type)
IM 77J04X13-01E
Please read through this User’s Manual before use for correct handling.
Please keep this User’s Manual for future reference.
IM 77J04X13-01E
1st Edition Aug. 2005 (YK)
2nd Edition Nov. 2005 (YK)
Network Solutions Business Division
2-9-32, Naka-cho Musashino-shi, Tokyo 180-8750 Japan
Phone: +81-422-52-7179 Facsimile: +81-422-52-6793
CAUTIONARY NOTES FOR SAFE USE OF THE PRODUCT
This User’s Manual should be carefully read before installing and operating the product. The following symbol is used on the product and in
this manual to ensure safe use.
This symbol is displayed on the product when it is
necessary to refer to the User’s Manual for information on
personnel and instrument safety. This symbol is displayed
in the User’s Manual to indicate precautions for avoiding
danger to the operator, such as an electric shock.
The following symbols are used only in this manual.
MODEL AND SUFFIX CODES
IMPORTANT
Indicates that operating the hardware or software in a
particular manner may cause damage or result in a system
failure.
NOTE
Draws attention to essential information for understanding
the operations and/or functions of the product.
CHECKING PRODUCT SPECIFICATIONS AND PACKAGED ITEMS
(1) Checking the Model and Product Specifications
Check that the model and specifications indicated on the nameplate
attached to the main unit are as ordered.
(2) Packaged Items
Check that the package contains the following items:
● MXT: 1
● Range label: 1
● Spacer: 1
● Receiving resistor (for current input): 3
● User’s Manual (this manual: IM 77J04X13-01E): 1
* When the optional specification “/R250” is specified, the 250 Ω
receiving resistor is attached. When the optional specification
“/R250” is not specified, the 100 Ω receiving resistor is attached.
GENERAL
This plug-in type universal computing unit receives DC current or DC
voltage signals, applies various computing functions to them, and then
converts them into isolated DC current or DC voltage signals.
1. MOUNTING METHOD
10 11
1 2
39
8 7 6 5
4
10 11
1 2
39
8 7 6 5
4
RES
Power supply
L+
N–
GND
Output
+
-
+
-
Input-1
R
+
-
Input-3
R
R: Receiving resistor
for current input
R: Receiving resistor
for current input
R: Receiving resistor
for current input
+
-
Input-2
R
10
11
1
2
3
4
5
6
7
8
9
Receiving resistor
(for current input)
NOTE
Plug/disconnect the main unit into/from the socket
vertically to the socket face. Otherwise the terminals may
bend and it may cause bad contact.
1.1 Wall Mounting
Unfasten the upper and lower stoppers of the computing unit to disconnect the main unit from the socket. Next, anchor the socket onto the
wall with two M4 screws. Then, plug the main unit into the socket and
secure the main unit with the upper and lower stoppers.
Stopper
Main unit
Socket
Unit: mm
<Mounting Dimensions>
Pitch: 56 or more
40⫾0.2
(51)
5 or more
Socket
2-⭋4.5 or 2-M4
Mounting
screws
Note:
• When mounting the
computing units close
together, leave a space of at
least 5 mm between them.
(85)
• Use the supplied spacer to
keep a space of 5 mm for
DIN rail mounting.
2. INSTALLATION LOCATIONS
● Avoid the following environments for installation locations:
Areas with vibration, corrosive gases, dust, water, oil, solvents, direct sunlight, radiation, a strong electric field, and/or a strong
magnetic field
Installation altitude: 2000 m or less above sea level.
● If there is any risk of a surge being induced into the power line
and/or signal lines due to lightning or other factors, a dedicated
lightning arrester should be used as protection for both this computing unit and a field-installed device.
● Operating temperature/humidity range: 0 to 50 ⬚C/5 to 90%RH (no
condensation)
3. EXTERNAL WIRING
WARNING
To avoid the risk of an electric shock, turn off the power
supply and use a tester or similar device to ensure that no
power is supplied to a cable to be connected, before carring
out wiring work.
Wires are connected to the terminals of the computing unit’s socket.
M3.5 screw terminals are provided for the connection of external signals. Attach a crimp-on lug to each wire for connection to the terminals.
● Recommended cables: A nominal cross-sectional area of 0.5 mm
or thicker for signal cables, and that of 1.25 mm2 or thicker for
power cables.
2
1.2 DIN Rail Mounting
Locate the computing unit so that the DIN rail fits into the upper part of
the DIN-rail groove at the rear of the socket, and fasten the socket using the slide lock at the lower part of the socket.
1.3 Using Ducts
Wiring ducts should be installed at least 30 mm away from the top or
bottom of the main unit.
DIN rail
Spacer
Push
(Rear of the socket)
Slide lock
Fit into here
DIN rail
IMPORTANT
●
The power line and input/output signal lines should be
installed away from noise-generating sources. Other
wise accuracy cannot be guaranteed.
●
The grounding resistance must be 100 Ω (JIS Class D
grounding). The length and thickness of the grounding
cable should be as short and thick as possible. Directly
connect the lead from the ground terminal (terminal no.
9) of the product to the ground. Do not carry out daisychained inter-ground terminal wiring.
●
Use of the product ignoring the specifications may
cause overheating or damage. Before turning on the
power, ensure the following:
(a) Power supply voltage and input signal value applied
to the product should meet the required
specifications.
(b) The external wiring to the terminals and wiring to
ground are as specifications.
●
Do not operate the product in the presence of
flammable or explosive gases or vapors. To do so is
highly dangerous.
●
The product is sensitive to static electricity; exercise
care in operating it. Before you operate the product,
touch a nearby metal part to discharge static electricity.
2
IM 77J04X13-01E 2nd Edition Nov 30, 2005-00
Power Supply and Isolation
Power supply rated voltage:
15-40 V DC or 100-240 V AC 50/60 Hz
Power supply input voltage:
15-40 V DC (±20%) or 100-240 V AC (−15, +10%) 50/60 Hz
Power consumption:
24 V DC 1.9 W
100 V AC 3.6 VA, 200 V AC 5.2 VA
Insulation resistance:
100 MΩ or more at 500 V DC between input, output, power supply, and grounding terminals mutually.
(Each input terminal is not isolated mutually.)
Withstand voltage:
2000 V AC for 1 minute between input, output, power supply and
grounding terminals mutually.
4. DESCRIPTION OF FRONT PANEL
The figure below shows the computing unit of which the front panel
cover is open.
4.3 Selection Switch and Adjustment Switch
The following adjustments can be performed using the switches on the
front panel (selection switch and adjustment switch) without the dedicated setting tool (refer to “4.2 Connector for Communication”).
The adjusted value is saved about 1 second after operating the adjustment switch. Also when the rotation direction of the adjustment switch
is changed, the adjusted value becomes effective about 1 second after
the change.
Position of selection switch
No function
0
Output zero adjustment
1
Output span adjustment
2
No function
3
No function
4
No function
5
No function
6
No function
7
Rotation direction of adjustment switch
Clockwise
Increase of output adjusted value
Item to be adjusted
Adjustment operation
Connector for
communication
Selection switch
Adjustment switch
Operation indicating lamp:
Turns on at power on.
4.1 Operation Indicating Lamp
The operation indicating lamp shows the operation status, abnormalities in a setting, and adjustment operation status by the adjustment
switch on the front panel.
(1) When the lamp is lit:
Power is turned on and the computing unit is in the normal status
provided that the selection switch is set to the position “0.”
(2) When the lamp is blinking rapidly:
The lamp repeats the rapid blinking until the internal processing is
completed during output adjustment by the adjustment switch.
(3) When the lamp is blinking slowly:
The lamp repeats the slow blinking until the computing unit regains its normal status when the following abnormalities occur.
• Abnormalities in a parameter setting
• The selection switch is set to the positions other than “0.”
4.2 Connector for Communication
Use the connector for communication when setting the parameters using a PC (VJ77 Parameters Setting Tool) or the Handy Terminal.
< How to connect with the setting tool>
JUXTA communication cable
with 5-pin connector (F9182EE)
JHT200
Handy T erminal
[Provided with VJ77 and JHT200]
Counterclockwise
Decrease of output adjusted value
[Adjusted volume by the adjustment switch]
One click changes about 0.005% of output range.
4.3.1 Adjusting Output Using the Switches on the Front Panel
(1) Output zero adjustment
Turn the selection switch to “1.” Then turn the adjustment switch
clockwise to increase the output, or turn it counterclockwise to decrease the output.
(2) Output span adjustment
Turn the selection switch to “2.” Then turn the adjustment switch
clockwise to increase the output, or turn it counterclockwise to decrease the output.
NOTE
• Be sure to set the selection switch back to the position
“0” after each adjustment. Otherwise it may cause an
incorrect operation or malfunction because the
positions other than “0” are adjustment modes.
• When the selection switch is set to the positions other
than “0”, the setting tool can not be used for the setting.
5. SETTING PARAMETERS
Set the parameters using a PC (VJ77 Parameters Setting Tool) or the
Handy Terminal. Refer to “7. List of Parameters” in this manual and the
User’s Manual for VJ77 PC-based Parameters Setting Tool (IM
77J01J77-01E) or the User’s Manual for JHT200 Handy Terminal (IM
JF81-02E). Parameters are indicated inside the [ ].
■ Setting Input Range
Set the 0% value of input range in [D25: INPUT L_RNG] and the 100%
value of input range in [D26: INPUT H_RNG].
NOTE
Dedicated cable (E9786WK)
[Provided with VJ77]
PC which is installed
with the VJ77
Modular jack conversion
adapter (E9786WH)
[Provided with VJ77]
Dedicated adapter (E9789HA)
[Provided with VJ77]
*: Use the VJ77 of version R1.04 or later.
Changing the input range resets the input adjusted value.
■ Setting Output Range
Set the 0% value of output range in [D38: OUT1 L_RNG] and the 100%
value of output range in [D39: OUT1 H_RNG].
NOTE
Changing the output range resets the output adjusted
value.
3
IM 77J04X13-01E 2nd Edition Nov 30, 2005-00
6. COMPUTING FUNCTIONS
6.1 MXT-A Free Program
This computing unit is used to meet individual applications by programming the available commands using a PC (VJ77 Parameters
Setting Tool) or the JHT200 Handy Terminal. Set the computing program in G01 to G59.
6.2 MXT-R Temperature-Pressure Compensation
This computing unit performs temperature-pressure compensation
(for ideal gas) of differential pressure flow meter using the following
expressions.
“With input limit function” or “without input limit function” can be set for
the input signals X1, X2 and X3.
K2
·
Y= ··· (1) [with square root extraction of
Y= ··· (2) [without square root extraction
where Y (Output): Compensated flow output signal (%)
● Gain setting (K1 to K3): Set the gain (K1 to K3) in the fixed con-
● Bias setting (A2, A3): Set the bias (A2, A3) in the fixed constants
Decide gain and bias so as not to exceed ±3.4x1038% during computation. Gain, bias and computation results are 4 significant digits.
● Square root extraction of uncompensated flow input signal:
● Limit of input signal:
● Computation accuracy: ±0.1%
X2+A2
·K1·
·K1·
X1
Output signal
(Y)
Hysteresis
X1
flow input signal]
of flow input signal]
Y=X
0
Lowcut point
Input signal (X)
K3
·
X3+A3
K2
·
X2+A2
K3
·
X3+A3
X1 (Input-1): Uncompensated flow input signal (%)
X2 (Input-2): Pressure input signal (%)
X3 (Input-3): Temperature input signal (%)
K1 to K3: Gain (no unit)
A2 and A3: Bias (%)
With input limit function: Low limit 0%, high limit 100%
stants (H01 to H03).
K1 to K3=±320 corresponds to H01 to H03=±32000%.
Setting range: −320 to +320
Number of significant digits: 4
Minimum unit: 0.00001
(H04, H05).
A2, A3=±32000% corresponds to H04, H05=±32000%.
Setting range: −32000 to +32000%
Number of significant digits: 4
Minimum unit: 0.001%
When extracting the square root of an uncompensated flow input
signal (X1), set in the fixed constant (H06). The lowcut point and
hysteresis shown below can be set in the fixed constants (H07,
H08).
Extract : H06=100%
Not extract: H06=0%
e.g. Set H07=1% to set the lowcut point=1%.
Set H08=0.5% to set the hysteresis=0.5%.
Operation when extracting the square root of an uncompensated flow input signal
The input limit function limits the input signals X1 to X3 between
0% and 100%.
Set the input limit function in the fixed constant (H09).
With input limit function: H09=100%
Without input limit function: H09=0%
The fixed constants (H01 to H09) can be changed using the
Handy Terminal.
However, input (X1) vs. output when K1=K2=K3=1, A2=A3=0%,
and inputs (X2, X3) are fixed at 100%.
6.3 MXT-S Addition / Subtraction
This computing unit adds and subtracts three inputs using the following expression.
“With input limit function” or “without input limit function” can be set for
the input signals X1, X2 and X3.
Y = K4 {K1(X1+A1) + K2(X2+A2) + K3(X3+A3)} + A4
where Y (Output): Output signal (%)
X1 to X3 (Input-1 to Input-3): Input signal (%)
K1 to K4: Gain (no unit)
A1 to A4: Bias (%)
With input limit function: Low limit 0%, high limit 100%
● Gain setting (K1 to K4): Set the gain (K1 to K4) in the fixed constants (H01 to H04).
K1 to K4=±320 corresponds to H01 to H04=±32000%.
Setting range: −320 to +320
Number of significant digits: 4
Minimum unit: 0.00001
● Bias setting (A1 to A4): Set the bias (A1 to A4) in the fixed constants (H05 to H08).
A1 to A4=±32000% corresponds to H05 to H08=±32000%.
Setting range: −32000 to +32000%
Number of significant digits: 4
Minimum unit: 0.001%
Decide gain and bias so as not to exceed ±3.4x1038% during computation. Gain, bias and computation results are 4 significant digits.
● Limit of input signal:
The input limit function limits the input signals X1 to X3 between
0% and 100%.
Set the input limit function in the fixed constant (H09).
With input limit function: H09=100%
Without input limit function: H09=0%
The fixed constants (H01 to H09) can be changed using the
Handy Terminal.
● Computation accuracy: ±0.1%
However, when K1=0.5, K2=0.25, K3=0.25, K4=1, and
A1=A2=A3=A4=0%.
6.4 MXT-T Multiplication / Division
This computing unit inputs three signals, multiplies and divides the
three input signals using the following expressions.
“With input limit function” or “without input limit function” can be set for
the input signals X1, X2 and X3.
Y=K4·
where Y (Output): Output signal (%)
X1 to X3 (Input-1 to Input -3): Input signal (%)
K1 to K4: Gain (no unit)
A1 to A4: Bias (%)
With input limit function: Low limit 0%, high limit 100%
● Gain setting (K1 to K4): Set the gain (K1 to K4) in the fixed constants (H01 to H04).
K1 to K4=±320 corresponds to H01 to H04=±32000%.
Setting range: −320 to +320
Number of significant digits: 4
Minimum unit: 0.00001
● Bias setting (A1 to A4): Set the bias (A1 to A4) in the fixed constants (H05 to H08).
A1 to A4=±32000% corresponds to H05 to H08=±32000%.
Setting range: −32000 to +32000%
Number of significant digits: 4
Minimum unit: 0.001%
Decide gain and bias so as not to exceed ±3.4x1038% during computation. Gain, bias and computation results are 4 significant digits.
● Limit of input signal:
The input limit function limits the input signals X1 to X3 between
0% and 100%.
Set the input limit function in the fixed constant (H09).
With input limit function: H09=100%
Without input limit function: H09=0%
The fixed constants (H01 to H09) can be changed using the
Handy Terminal.
● Computation accuracy: ±0.1%
However, input (X1) vs. output when K1=K2=K3=K4=1, and
A1=A2=A3=A4=0%, and inputs (X2, X3) are fixed at 100%.
(K1·X1+A1)·(K2·X2+A2)
(K3
·X3+A3)
+A4
4
IM 77J04X13-01E 2nd Edition Nov 30, 2005-00
6.5 MXT-U Square Root Extraction
This computing unit extracts square root of three inputs using the following expression.
“With input limit function” or “without input limit function” can be set for
the input signals X1, X2 and X3. And lowcut point can be set for the
computation result.
Y= K4
where Y (Output): Output signal (%)
X1 to X3 (Input-1 to Input-3): Input signal (%)
K1 to K4: Gain (no unit)
A1 to A4: Bias (%)
With input limit function: Low limit 0%, high limit 100%
● Gain setting (K1 to K4): Set the gain (K1 to K4) in the fixed constants (H01 to H04).
K1 to K4=±320 corresponds to H01 to H04=±32000%.
Setting range: −320 to +320
Number of significant digits: 4
Minimum unit: 0.00001
● Bias setting (A1 to A4): Set the bias (A1 to A4) in the fixed constants (H05 to H08).
A1 to A4=±32000% corresponds to H05 to H08=±32000%.
Setting range: −32000 to +32000%
Number of significant digits: 4
Minimum unit: 0.001%
● Lowcut point setting:
Set the lowcut point in the fixed constant (H09).
Setting range: 0 to 100%; if the computation result is the lowcut
point or less, Input (X1)=Output (Y1).
(K1·X1+A1)·(K2·X2+A2)
·
(K3
·
X3+A3)
+A4
Decide gain and bias so as not to exceed ±3.4x1038% during computation. Gain, bias and computation results are 4 significant digits.
● Limit of input signal:
The input limit function limits the input signals X1 to X3 between
0% and 100%.
Set the input limit function in the fixed constant (H10).
With input limit function: H10=100%
Without input limit function: H10=0%
The fixed constants (H01 to H10) can be changed using the
Handy Terminal.
● Computation accuracy: ±0.1%
However, input (X1) vs. output when K1=K2=K3=K4=1, and
A1=A2=A3=A4=0%, and inputs (X2, X3) are fixed at 100%.
6.6 MXT-V High Selector
This computing unit selects the highest signal out of three input signals (X1, X2, and X3) or out of two input signals (X1 and X2) to output
it (Y).
Set the high selector of three inputs or two inputs in the fixed constant
(H01).
3-input high selector: H01=0%
2-input high selector: H01=200%
6.7 MXT-W Low Selector
This computing unit selects the lowest signal out of three input signals
(X1, X2, and X3) or out of two input signals (X1 and X2) to output it
(Y).
Set the low selector of three inputs or two inputs in the fixed constant
(H01).
3-input low selector: H01=0%
2-input low selector: H01=200%
5
IM 77J04X13-01E 2nd Edition Nov 30, 2005-00
7. LIST OF PARAMETERS
7.1 MXT (except for the function suffix code “A”)
Parameter Display Item
MODEL
TAG NO
SELF CHK
DISPLAY1
A
INPUT1
A01
INPUT2
A02
INPUT3
A03
OUTPUT1
A05
STATUS
A54
REV NO
A56
MENU REV
A58
SELF CHK
A60
DISPLAY2
B
INPUT1
B01
INPUT2
B02
INPUT3
B03
OUTPUT1
B05
SELF CHK
B60
SET (I/O)
D
TAG NO.1
D01
TAG NO.2
D02
COMMENT1
D03
COMMENT2
D04
INP TYPE
D20
IN RESIST
D22
INPUT L_RNG
D25
INPUT H_RNG
D26
OUT1 L_RNG
D38
OUT1 H_RNG
D39
PRGM SELECT
D46
SELF CHK
D60
CONST
H
CONST
H01
CONST
H02
•
•
•
H58
H59
H60
P
P08
P09
P10
P11
P12
P13
P26
P27
P60
Q
Q03
Q60
*1: The displayed status is to let the service staff know the past records
of the product.
*2: The parameters are the items to be set at the factory.
•
•
•
CONST
CONST
SELF CHK
ADJUST
IN1 ZERO ADJ
IN1 SPAN ADJ
IN2 ZERO ADJ
IN2 SPAN ADJ
IN3 ZERO ADJ
IN3 SPAN ADJ
OUT1ZERO ADJ
OUT1SPAN ADJ
SELF CHK
TEST
OUT1 TEST
SELF CHK
Model
Tag No.
Self-check result
Display 1
Input-1
Input-2
Input-3
Output-1
*1
Status
REV No.
MENU REV
Self-check result
Display 2
Input-1
Input-2
Input-3
Output-1
Self-check result
Setting (I/O)
Tag No.-1
Tag No.-2
Comment-1
Comment-2
Input type
Input resistor
*2
*2
Input low range
Input high range
Output-1 low range
Output-1 high range
Program selection
Self-check result
Fixed Constant of Computing Unit
Fixed constant
Fixed constant
•
•
•
Fixed constant
Fixed constant
Self-check result
Adjustment
Input-1 zero adjustment
Input-1 span adjustment
Input-2 zero adjustment
Input-2 span adjustment
Input-3 zero adjustment
Input-3 span adjustment
Output-1 zero adjustment
Output-1 span adjustment
Self-check result
Test
Forced output-1
Self-check result
7.2 MXT (for the function suffix code “A”)
Parameter Display Item
MODEL
TAG NO
SELF CHK
DISPLAY1
A
INPUT1
A01
INPUT2
A02
INPUT3
A03
OUTPUT1
A05
T1
A11
T2
A12
T3
A13
T4
A14
DO
A16
LOAD
A17
STATUS
A54
REV NO
A56
MENU REV
A58
SELF CHK
A60
DISPLAY2
B
INPUT1
B01
INPUT2
B02
INPUT3
B03
OUTPUT1
B05
T1
B11
T2
B12
T3
B13
T4
B14
DO
B16
LOAD
B17
SELF CHK
B60
SET (I/O)
D
TAG NO.1
D01
TAG NO.2
D02
COMMENT1
D03
COMMENT2
D04
INP TYPE
D20
IN RESIST
D22
INPUT L_RNG
D25
INPUT H_RNG
D26
OUT1 L_RNG
D38
OUT1 H_RNG
D39
PRGM SELECT
D46
CYCLE TIME
D47
SELF CHK
D60
PROGRAM
G
PROGRAM
G01
PROGRAM
G02
G58
G59
G60
H
H01
H02
H58
H59
H60
P
P08
P09
P10
P11
P12
P13
P26
P27
P60
Q
Q03
Q60
•
•
•
•
•
•
•
•
•
PROGRAM
PROGRAM
SELF CHK
CONST
CONST
CONST
•
•
•
CONST
CONST
SELF CHK
•
•
ADJUST
•
IN1 ZERO ADJ
IN1 SPAN ADJ
IN2 ZERO ADJ
IN2 SPAN ADJ
IN3 ZERO ADJ
IN3 SPAN ADJ
OUT1ZERO ADJ
OUT1SPAN ADJ
SELF CHK
TEST
OUT1 TEST
SELF CHK
Model
Tag No.
Self-check result
Display 1
Input-1
Input-2
Input-3
Output-1
Temporary memory-1
Temporary memory-2
Temporary memory-3
Temporary memory-4
Digital output
Load factor
*1
Status
REV No.
MENU REV
Self-check result
Display 2
Input-1
Input-2
Input-3
Output-1
Temporary memory-1
Temporary memory-2
Temporary memory-3
Temporary memory-4
Digital output
Load factor
Self-check result
Setting (I/O)
Tag No.-1
Tag No.-2
Comment-1
Comment-2
Input type
Input resistor
Input low range
Input high range
Output-1 low range
Output-1 high range
Program selection
Computation cycle
Self-check result
Program of Computing Unit
Program
Program
Program
Program
Self-check result
Fixed Constant of Computing Unit
Fixed constant
Fixed constant
Fixed constant
Fixed constant
Self-check result
Adjustment
Input-1 zero adjustment
Input-1 span adjustment
Input-2 zero adjustment
Input-2 span adjustment
Input-3 zero adjustment
Input-3 span adjustment
Output-1 zero adjustment
Output-1 span adjustment
Self-check result
Test
Forced output-1
Self-check result
*2
*2
•
•
•
•
•
•
6
IM 77J04X13-01E 2nd Edition Nov 30, 2005-00
8. MAINTENANCE
The product starts running immediately when the power is turned on;
however, it needs 10 to 15 minutes of warm-up before it meets the
specified performance.
8.1 Calibration Apparatus
● A DC voltage/current standard (Yokogawa 7651 or the equivalent)
● A digital multimeter (Yokogawa 7561 or the equivalent)
● A precision resistor of 250 ⍀ ±0.01%, 1 W
● Setting tool for adjustment (Refer to “4.2 Connector for Communi-
cation” in this manual.)
8.2 Calibration Procedure
(1) Connect the instruments as shown below.
(2) Use the DC voltage/current standard and apply input signals
equivalent to 0, 25, 50, 75, and 100% of input span to the computing unit.
(3) Check to see the output values obtained from the computation of
each input are within the specified accuracy rating. “R” is used for
current output.
● Use the setting tool (VJ77 Parameters Setting Tool or JHT200
Handy Terminal) or the switches on the front panel (selection
switch and adjustment switch) to adjust the input/output signals.
Input Adjustment Procedure
(1) Input the value equivalent to 0% value of input range.
(2) Call the display item (A: DISPLAY1) to check the input value in
A01: INPUT1.
(3) If the adjustment is necessary, call the adjustment item (P: AD-
JUST).
(4) Select P08: IN1 ZERO ADJ to enter the adjustment mode. Select
EXECUTE (adjustment) for adjustment. (If RESET is selected,
the adjusted value is reset to the factory-set default.)
(5) Input the value equivalent to 100% value of input range.
(6) Call the display item (A: DISPLAY1) to check the input value in
A01: INPUT1.
(7) If the adjustment is necessary, call the adjustment item (P: AD-
JUST).
(8) Select P09: IN1 SPAN ADJ to enter the adjustment mode. Select
EXECUTE (adjustment) for adjustment. (If RESET is selected,
the adjusted value is reset to the factory-set default.)
Input-2 and Input-3 can be adjusted by the same operation as the
above.
Output Adjustment Procedure
(1) When adjusting 0% value of output, call the adjustment item (P:
ADJUST) to select P26: OUT1ZERO ADJ.
(2) If there is a positive deviation, correct it by setting a negative
value to offset the deviation. If there is a negative deviation, correct it by setting a positive value.
*: The 100% value of output can be adjusted by the same operation
as the above.
For adjustment using a setting tool, refer to the User’s Manual for
each setting tool and “7. List of Parameters” in this manual.
For adjustment using the switches on the front panel, refer to “4.3
Selection Switch and Adjustment Switch.”
User’s Manual for VJ77 [Document No.: IM 77J01J77-01E]; however, use the VJ77 of version R1.04 or later.
User’s Manual for JHT200 [Document No.: IM JF81-02E]
Receiving resistor
(for current input)
Power supply
L+
N–
GND
Input-3
⫹
DC voltge/
current
standard
⫺
R: Receiving resistor
for current input
7
8
9
10
R
11
8 7 6 5
10 11
1 2
Input-1
DC voltge/
current
standard
R: Receiving resistor
RES
for current input
4
39
Input-2
DC voltge/
current
standard
R: Receiving resistor
for current input
Output
1
R
2
R: 250 Ω precision resistor
for current output
⫹
5
R
⫺
6
⫹
3
R
⫺
4
⫹
DMM
⫺
7
IM 77J04X13-01E 2nd Edition Nov 30, 2005-00
8
IM 77J04X13-01E 2nd Edition Nov 30, 2005-00
Loading...
