Yamaha R CD-S700 User Manual

Compact Disc Player

Lecteur Compact Disque

UAB

OWNER’S MANUAL

MODE D’EMPLOI

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

RISK OF ELECTRIC SHOC K

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

• Explanation of Graphical Symbols

The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert you to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.

The exclamation point within an equilateral triangle is
intended to alert you to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

IMPORTANT

Please record the serial number of this unit in the space
below.
MODEL:
Serial No.:
The serial number is located on the rear of the unit.
Retain this Owner’s Manual in a safe place for future
reference.

FOR CANADIAN CUSTOMERS

To prevent electric shock, match wide blade of plug to
wide slot and fully insert.
This Class B digital apparatus complies with Canadian
ICES-003.

1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance

with the manufacturer’s instructions.

8 Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that
produce heat.

9 Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.

11 Only use attachments/accessories specified by the

manufacturer.

12 Use only with the cart, stand, tripod,

bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.

13 Unplug this apparatus during lightning storms or when unused

for long periods of time.

14 Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.

We Want You Listening For A Lifetime

Yamaha and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or
distortion – and, most importantly, without affecting your sensitive hearing. Since hearing damage from loud sounds is
often undetectable until it is too late, Yamaha and the Electronic Industries Association’s Consumer Electronics Group
recommend you to avoid prolonged exposure from excessive volume levels.

i En

IMPORTANT SAFETY INSTRUCTIONS

FCC INFORMATION (for US customers)

1 IMPORTANT NOTICE: DO NOT MODIFY THIS

UNIT!

This product, when installed as indicated in the
instructions contained in this manual, meets FCC
requirements. Modifications not expressly approved by
Yamaha may void your authority, granted by the FCC, to
use the product.

2 IMPORTANT: When connecting this product to

accessories and/or another product use only high quality
shielded cables. Cable/s supplied with this product
MUST be used. Follow all installation instructions.
Failure to follow instructions could void your FCC
authorization to use this product in the USA.

3NOTE: This product has been tested and found to

comply with the requirements listed in FCC Regulations,
Part 15 for Class “B” digital devices. Compliance with
these requirements provides a reasonable level of
assurance that your use of this product in a residential
environment will not result in harmful interference with
other electronic devices.
This equipment generates/uses radio frequencies and, if
not installed and used according to the instructions found
in the users manual, may cause interference harmful to
the operation of other electronic devices.

CAUTION

Use of controls or adjustments or performance of
procedures other than those specified herein may result
in hazardous radiation exposure.

Compliance with FCC regulations does not guarantee that
interference will not occur in all installations. If this
product is found to be the source of interference, which
can be determined by turning the unit “OFF” and “ON”,
please try to eliminate the problem by using one of the
following measures:
Relocate either this product or the device that is being
affected by the interference.
Utilize power outlets that are on different branch (circuit
breaker or fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient
the antenna. If the antenna lead-in is 300 ohm ribbon
lead, change the lead-in to coaxial type cable.
If these corrective measures do not produce satisfactory
results, please contact the local retailer authorized to
distribute this type of product. If you can not locate the
appropriate retailer, please contact Yamaha Electronics
Corp., U.S.A. 6660 Orangethorpe Ave., Buena Park, CA

90620.
The above statements apply ONLY to those products
distributed by Yamaha Corporation of America or its
subsidiaries.

■ For U.K. customers

If the socket outlets in the home are not suitable for the
plug supplied with this appliance, it should be cut off and
an appropriate 3 pin plug fitted. For details, refer to the
instructions described below.

Note

The plug severed from the mains lead must be destroyed, as a
plug with bared flexible cord is hazardous if engaged in a live
socket outlet.

• This label is attached to U.K. model only.

■ Special Instructions for U.K. Model

IMPORTANT

THE WIRES IN MAINS LEAD ARE COLOURED IN
ACCORDANCE WITH THE FOLLOWING CODE:

Blue: NEUTRAL
Brown: LIVE

As the colours of the wires in the mains lead of this apparatus
may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the
terminal which is marked with the letter N or coloured
BLACK. The wire which is coloured BROWN must be
connected to the terminal which is marked with the letter L or
coloured RED.
Making sure that neither core is connected to the earth
terminal of the three pin plug.

ii En

CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.

CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.

1 To assure the finest performance, please read this manual

carefully. Keep it in a safe place for future reference.

2 Install this sound system in a well ventilated, cool, dry, clean

place – away from direct sunlight, heat sources, vibration,
dust, moisture, and/or cold. Allow ventilation space of at least
10 cm (3 15/16 in) on the top, 10 cm (3 15/16 in) on the left
and right, and 10 cm (3 15/16 in) on the back of this unit.

3 Locate this unit away from other electrical appliances, motors,

or transformers to avoid humming sounds.

4 Do not expose this unit to sudden temperature changes from

cold to hot, and do not locate this unit in an environment with
high humidity (i.e. a room with a humidifier) to prevent
condensation inside this unit, which may cause an electrical
shock, fire, damage to this unit, and/or personal injury.

5 Avoid installing this unit where foreign objects may fall onto

this unit and/or this unit may be exposed to liquid dripping or
splashing. On the top of this unit, do not place:

– Other components, as they may cause damage and/or

discoloration on the surface of this unit.

– Burning objects (i.e. candles), as they may cause fire,

damage to this unit, and/or personal injury.

– Containers with liquid in them, as they may fall and

liquid may cause electrical shock to the user and/or
damage to this unit.

6 Do not cover this unit with a newspaper, tablecloth, curtain,

etc. in order not to obstruct heat radiation. If the temperature
inside this unit rises, it may cause fire, damage to this unit,
and/or personal injury.

7 Do not plug in this unit to a wall outlet until all connections

are complete.

8 Do not operate this unit upside-down. It may overheat,

possibly causing damage.

9 Do not use force on switches, knobs and/or cables.
10 When disconnecting the power cable from the wall outlet,

grasp the plug; do not pull the cable.

11 Do not clean this unit with chemical solvents; this might

damage the finish.

12 Only voltage specified on this unit must be used. Using this

unit with a higher voltage than specified is dangerous and may
cause fire, damage to this unit, and/or personal injury.
Yamaha will not be held responsible for any damage resulting
from use of this unit with a voltage other than specified.

13 To prevent damage by lightning, keep the power cable

disconnected from a wall outlet or the unit during a lightning
storm.

14 Do not attempt to modify or fix this unit. Contact qualified

Yamaha service personnel when any service is needed. The
cabinet should never be opened for any reasons.

15 When not planning to use this unit for long periods of time

(i.e. vacation), disconnect the power cable from the wall
outlet.

16 Install this unit near the wall outlet and where the power cable

can be reached easily.

17 Be sure to read the “TROUBLESHOOTING” section in this

manual on common operating errors before concluding that
this unit is faulty.

18 Before moving this unit, press POWER to turn off this unit

and then disconnect the power cable from the wall outlet.

19 The batteries shall not be exposed to excessive heat such as

sunshine, fire or like.

20 VOLTAGE SELECTOR (Asia and General models only)

The VOLTAGE SELECTOR on the rear panel of this unit
must be set for your local main voltage BEFORE plugging
into the wall outlet. Voltages are:

................................. AC 110/120/220/230–240 V, 50/60 Hz

As long as this unit is connected to the wall outlet, it is
not disconnected from the AC power source even if
you turn off this unit by POWER.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE.

LASER SAFETY

This unit employs a laser. Due to possible eye injury, only a qualified
service person should remove the cover or attempt to service this
device.

DANGER

This unit emits visible laser radiation when open. Avoid direct eye
exposure to beam. When this unit is plugged into the wall outlet, do
not place your eyes close to the opening of the disc tray and other
openings to look into inside.

The laser component in this product is capable of
emitting radiation exceeding the limit for Class 1.

iii En

INTRODUCTION

FEATURES.............................................................2

SUPPLIED ACCESSORIES .................................2

CONTROLS AND FUNCTIONS .........................3

Front panel.................................................................3

Front panel display .................................................... 4

Remote control...........................................................5

Installing batteries in the remote control................... 6

Using the remote control ...........................................6

PREPARATION

CONNECTIONS ....................................................7

Connecting your amplifier......................................... 7

Connecting the supplied power cable........................8

Connecting USB devices...........................................8

CONTENTS

PREPARATIONINTRODUCTION

OPERATION

BASIC OPERATION............................................. 9

Starting playback....................................................... 9

Pausing playback..................................................... 10

Stopping playback ................................................... 10

Turning off the power..............................................10

Playing back a desired track.................................... 10

To improve audio quality (PURE DIRECT mode)

............................................................................. 10

Skipping to the beginning of a desired track ........... 11

Advancing or reversing playback rapidly................ 11

Changing front panel display................................... 12

Changing the brightness of the front panel display

............................................................................. 12

RANDOM-SEQUENCE PLAY .......................... 13

REPEAT PLAY ....................................................13

Repeating a selected item ........................................13

Repeat A-B ..............................................................14

PROGRAM PLAY ...............................................15

Stopping program playback..................................... 16

Clearing programmed track.....................................16

ADDITIONAL INFORMATION

NOTES ABOUT DISCS/MP3, WMA FILES .... 17

TROUBLESHOOTING.......................................19

SPECIFICATIONS .............................................. 20

OPERATION

INFORMATION

ADDITIONAL

■ About this manual

• y indicates a tip for your operation.

• In this manual, audio CDs are referred to as “Audio CD”, MP3/WMA discs as “Data Disc”, and MP3/WMA files
stored on the USB device as “USB”.

• This manual is printed prior to production. Design and specifications are subject to change in part as a result of
improvements, etc. In case of differences between the manual and the product, the product has priority.

English

1 En

INTRODUCTION

FEATURES

◆ Optical Digital Output

◆ Coaxial Digital Output

◆ CD-R, CD-RW Disc Playability

(For details, refer to page 17.)

◆ MP3, WMA Disc Playability

◆ MP3, WMA File Playability Stored on USB Device

SUPPLIED ACCESSORIES

Please check that you received all of the following parts:

Remote control RCA stereo cable

Batteries (× 2)
(AA, R6, UM-3)

◆ Program Play (Audio CD only)

◆ Random-Sequence Play

◆ Single Track/Entire Disc Repeat Play

◆ Repeat A-B Play (Audio CD only)

◆ Adjustable Display Information and Brightness

◆ PURE DIRECT Function

Power cable

2 En

Front panel

CONTROLS AND FUNCTIONS

INTRODUCTION

1 POWER

Press to turn the power to ON/OFF.

y

The POWER indicator above lights up when this unit is turned
on.

2 USB port

Connect your USB device. See page 8 for details.

3 PURE DIRECT

Turn PURE DIRECT mode on or off to improve audio
quality.

y

The PURE DIRECT indicator above lights up when this unit is in
PURE DIRECT mode. See page 10 for details.

4 Disc tray

Load a disc.

5 (Open/Close)

Open or close the disc tray.

6 / (Skip/Search backward),

/ (Skip/Search forward)

/ : Skip to the next track.
/ : Skip back to the beginning of the current

track.

/ (twice): Skip to the previous track.
Press and hold / or / to search
backward/ forward.

y

Each time you press and hold / or / , the
search speed increases by 2 levels.

7 (Play)

Start playback.

8 (Pause)

Pause playback. Press or to resume playback.

9 (Stop)

Stop playback.

0 USB indicator

Lights on/off when this unit is in USB/disc mode, and
blinks when this unit is reading the USB device.

A Front panel display

Shows the current status of this unit.

B Remote control sensor

Receives signals from the remote control.

English

3 En

CONTROLS AND FUNCTIONS

Front panel display

Audio CD

Data Disc USB

1 Lights up the icon for the selected playback mode.
2 Shows the time displays. (Refer to page 12.)
3 Shows the track number selected or being played back.
4 Shows the file number.
5 Lights up when this unit is in disc mode (refer to page 9) and

also when an Audio CD is recognized on the tray.

6 Lights up when MP3 file is played back.
7 Lights up when WMA file is played back.

4 En

Remote control

CONTROLS AND FUNCTIONS

1 Infrared signal transmitter (p. 6)

Send infrared signals to this unit.

2 CD/USB (p. 9)

Switch between disc mode and USB mode.

3 DIMMER (p. 12)

Select brightness level for the front panel display.

4 Numeric buttons (p. 10)

Select a track directly.

5 PROGRAM (p. 15)

Turn program mode on or off.

6 / (Search backward/forward) (p. 11)

Search tracks backward/forward.

7 / (Skip backward/forward) (p. 11)

Skip to the next/previous track or skip back to the
beginning of the current track.

8 OPEN/CLOSE (p. 9)

Open or close the disc tray.

9 PURE DIRECT (p. 10)

Turn PURE DIRECT mode on or off.

0 DISPLAY (p. 12)

Switch the time display.

A ENTER (p. 15)

Confirm the track number when this unit is in program
input mode.

INTRODUCTION

B CLEAR (p. 16)

Clear programmed track.

C REPEAT (p. 13)

Repeat playback of a single track or all tracks.

D RANDOM (p. 13)

Set random-sequence play.

E A/B (p. 14)

Set repeat A-B.

F (Pause) (p. 10)

Pause playback.

G (Play) (p. 9)

Start playback.

H (Stop) (p. 10)

Stop playback.

English

5 En

CONTROLS AND FUNCTIONS

Installing batteries in the remote control

1 Press the part and slide the battery

compartment cover off.

2 Insert two supplied batteries (AA, R6, UM-3)

according to the polarity markings (+ and –)
on the inside of the battery compartment.

3 Slide the cover back until it snaps into place.

■ Notes on batteries

• Change both batteries when the operation range of the
remote control decreases.

• Use AA, R6, UM-3 batteries.

• Make sure that the polarities are correct. See the
illustration inside the battery compartment.

• Remove the batteries if the remote control is not to be
used for an extended period of time.

• Do not use old batteries together with new ones.

• Do not use different types of batteries (such as alkaline
and manganese batteries) together. Read the packaging
carefully as these different types of batteries may have
the same shape and color.

• If the batteries have leaked, dispose of them
immediately. Avoid touching the leaked material or
letting it come into contact with clothing, etc. Clean the
battery compartment thoroughly before installing new
batteries.

• Do not throw away batteries with general house waste;
dispose of them correctly in accordance with your local
regulations.

Using the remote control

The remote control transmits a directional infrared beam.
Be sure to aim the remote control directly at the remote
control sensor on the front panel of this unit during
operation.

Within 6 m
(20 ft)

■ Handling the remote control

• The area between the remote control and this unit must
be clear of large obstacles.

• Do not spill water or other liquids on the remote
control.

• Do not drop the remote control.

• Do not leave or store the remote control in the
following types of conditions:
– high humidity, such as near a bath
– high temperature, such as near a heater or a stove
– extremely low temperatures
– dusty places

• Do not expose the remote control sensor to strong
lighting, in particular, an inverter type fluorescent
lamp; otherwise, the remote control may not work
properly. If necessary, position the unit away from
direct lighting.

6 En

PREPARATION

CONNECTIONS

Connecting your amplifier

CAUTION

• Before making any connection, switch OFF the power to the unit, the amplifier and any other component.

• Connections should be made to the correct input terminals of the amplifier or another component.

• If the placement of this unit causes noise to another equipment, such as a tuner, move them further away from each
other.

PREPARATION

RCA stereo
cable
(supplied)

• The digital output is turned off when this unit is in PURE DIRECT mode.

To connect this unit to your amplifier, choose one of the ways listed below.

When the ANALOG OUT terminals of this
unit are used ( )

Connect these terminals to the CD (or AUX) terminals of
the amplifier by using a supplied RCA stereo cable. For
details concerning these connections, refer to the
operation instructions of the amplifier being used.

• Be sure that the left (L) and right (R) of these terminals
are connected to the corresponding (left and right)
terminals of the amplifier or other component.

Coaxial cableOptical cable

When the DIGITAL OUT (COAXIAL) terminal
of this unit is used ( )

Connect this terminal to the digital input terminal of an
amplifier with a commercially available coaxial cable.

When the DIGITAL OUT (OPTICAL) terminal
of this unit is used ( )

Connect this terminal to the optical input terminal of an
amplifier with a commercially available optical cable.

• Use a reliable optical cable.

Amplifier

English

7 En

CONNECTIONS

Connecting the supplied power cable

Asia and General models
only

Europe and U.K. models

To the wall outlet with the
supplied power cable

■ VOLTAGE SELECTOR
(Asia and General models only)

The VOLTAGE SELECTOR on the rear panel of this unit
must be set for your local main voltage BEFORE plugging
the supplied power cable into the wall outlet.
Improper setting of the VOLTAGE SELECTOR may
cause damage to this unit and create a potential fire
hazard.
Rotate the VOLTAGE SELECTOR clockwise or
counterclockwise to the correct position using a straight
slot screwdriver.
Voltages are as follows:

.............................. AC 110/120/220/230-240 V, 50/60 Hz

■ Connecting this unit to the wall outlet

Plug the supplied power cable into the AC IN on the rear
panel of this unit and then plug the power cable into the
wall outlet after all other connections are complete.

Connecting USB devices

This unit has a USB port and can access MP3 or WMA
files saved on your USB device. Connect your USB
device to the USB port on the front panel of this unit.

CAUTION

Do not disconnect your USB device while playing back
from the USB device, or when the USB indicator blinks.

■ Supported USB devices

This unit supports USB mass storage class devices (e.g.,
flash memories, card readers or portable audio players)
that use FAT16 or FAT32 format.

Notes

• Some devices may not work properly even if they meet the
requirements.

• Do not connect devices other than USB mass storage class
devices: USB chargers, USB hubs, PCs, external HDD, etc.

• When you insert two or more memory cards at the same time
into a card reader connected to the USB port on this unit, only
one of the memory cards is recognized.

• Yamaha and suppliers accepts no liability for the loss of data
saved on the USB devices connected to this unit. As a
precaution, it is recommended that the files are made backup
copies.

• Playability of and power supply to all kind of USB devices are
not guaranteed.

8 En

OPERATION

This manual describes how to operate this unit by using the remote control.
To operate this unit from the front panel, use the corresponding buttons on the front panel.
The , and icons indicate music data formats that can be

Audio CD Data Disc USB

used in the operation.

BASIC OPERATION

Notes

• When you load a disc, set the disc on the inside of the disc
guides (4 marks on the disc tray).

• The disc may not be read correctly, if it is set incorrectly. In this
case, open the disc tray and set the disc again.

2 Press OPEN/CLOSE to close the disc tray.

1 Press POWER to turn on the power.

y

You can also close the disc tray by pressing h, a numeric button,
or by pressing the front edge of the disc tray gently. If the tray is
closed in one of these ways, playback starts automatically.

OPERATION

2 Press CD/USB to switch between disc mode

and USB mode.

When USB mode is selected, the USB indicator lights
up, and when disc mode is selected, the USB
indicator lights off.

y

This setting is retained even if you turn off this unit.

Starting playback

■ Playing back discs

Audio CD Data Disc

1 Press OPEN/CLOSE to open the disc tray,

and load a disc.

Label side up.

3 Press h to start playback.

For an Audio CD, playback starts from the first track,
and for a Data Disc, in alphanumeric order by
filename.

Display information in step 2

Audio CD

Total number of tracks Total recorded time of a disc

Data Disc

Total number of files

Disc tray

English

9 En

BASIC OPERATION

■ Playing back USB devices

USB

Turning off the power

Connect your USB device to the USB port on the
front panel. (For details, refer to page 8.)

When USB mode is selected (USB indicator lights up),
first filename is displayed in the front panel display (refer
to page 12), and playback starts automatically in order by
date and time of creation if playable files are in the USB
device.

To disconnect USB devices

Press to stop playback, and then disconnect the USB
device.

Note

Do not disconnect your USB device while playing back from the
USB device, or when the USB indicator blinks.

Pausing playback

USBAudio CD Data Disc

Press e.

To resume playback, press e again (or press h).

Press POWER again.

If you turn off the power when disc mode is selected, the
next time you turn the power on, playback starts
automatically of the disc on the tray. If you turn off the
power when USB mode is selected, playback will start
automatically of the USB device connected.

Playing back a desired track

Audio CD

Select a desired track by using the numeric
buttons.

Example: To select track number 12
Press “1”, and then press “2”.

+

Following information is displayed.

The selected track number

Playback starts in 2 seconds.

Note

This operation is not available for Data Disc and USB.

y

You can also select and playback a desired track during playback.

Stopping playback

USBAudio CD Data Disc

Press s.

If you press h again, playback starts from the first track.

10 En

To improve audio quality (PURE DIRECT mode)

USBAudio CD Data Disc

Press PURE DIRECT.

This unit is set to PURE DIRECT mode.

• The PURE DIRECT indicator lights up.

• The digital output is turned off.

• The front panel display is turned off and only the minimum
required indicators and messages are displayed during
playback.

Note

Connect using the ANALOG OUT terminals when you use
PURE DIRECT mode (refer to page 7).

y

• Press PURE DIRECT again to turn off PURE DIRECT mode.

• This setting is retained even if you turn off this unit.

BASIC OPERATION

Advancing or reversing playback rapidly

Skipping to the beginning of a desired track

USBAudio CD Data Disc

To play back from the beginning of the next
track, press once.

To play back from the beginning of the current
track, press once.

To play back from the beginning of the previous
track, press twice.

y

• These operations can also be performed for Data Disc/USB.

• These operations can also be performed when the unit is
paused.

• These operations can also be performed using b/w and
f/a on the front panel.

USBAudio CD Data Disc

To advance rapidly, press once during
playback.

To reverse rapidly, press once during
playback.

To resume playback, press at the desired
point.

y

• These operations can also be performed for Data Disc/USB.

• The sound can be heard (although slightly garbled) during these
operation in either direction. This is convenient for locating a
precise position within a track, or for reviewing the contents
quickly. Sound may not be heard depending on the MP3/WMA
file.

• Each time you press or , the search speed increases
by 2 levels.

• These operations can also be performed pressing and holding
b/w or f/a on the front panel for more than 2
seconds.

OPERATION

11 En

English

BASIC OPERATION

Changing front panel display

■ When playing back an Audio CD

Audio CD

You can select the following front panel displays (1 - 3) by pressing DISPLAY.

1 Elapsed time of the current track (Default)

2 Remaining time of the current track

3 Remaining time of the disc

■ When playing back a Data Disc or USB device

USBData Disc

You can temporarily display the filename by pressing DISPLAY.

These front panel display examples are for an MP3 file.

1 Elapsed time of the current track

Returns to the normal display after displaying

2 Filename*

* 28 characters maximum

Note

This unit can only show alphanumeric characters.

a filename.

Changing the brightness of the front panel display

Press DIMMER to change the brightness level for
the front panel display.

Each time you press DIMMER, the brightness level
changes in the following order:
Max (brightest) J Level1 (default) J Level2 J Level3
(darkest) J Max

Notes

• Brightness is slightly decreased during playback, except when
the level is set to maximum.

• Brightness may temporarily be decreased for some operations,
except when the level is set to maximum.

• This setting is retained even if you turn off this unit.

12 En

RANDOM-SEQUENCE PLAY

USBAudio CD Data Disc

You can play back the tracks in random sequence.

To perform random-sequence play

Press , and then, RANDOM.

+

To cancel random-sequence play

Press .

REPEAT PLAY

Repeating a selected item

Note

These operations can also be performed for Data Disc/USB.

OPERATION

USBAudio CD Data Disc

You can play back a single track or all tracks repeatedly
by pressing REPEAT during playback. The repeat
playback mode changes each time you press REPEAT.

(Single repeat)

(Full repeat)

(off)

S (Single repeat)

A single track is played back repeatedly.

ALL (Full repeat)

All tracks (the entire disc) are played back repeatedly.

Note

These operations can also be performed for Data Disc/USB.

y

Repeat play also works for program play and random-sequence
play.

English

13 En

REPEAT PLAY

Repeat A-B

Audio CD

You can repeat a specified section of a track by pressing
A/B during playback to set two points (start and end
points).

1 Press A/B to select the start point of repeat

play.

“A-” lights up.

2 Press A/B to select the end point of repeat

play.

“A-B” lights up.

The selected section is played back repeatedly.

To cancel repeat A-B

Press A/B again to make “A-B” disappear from the front
panel display.

Notes

• You cannot set repeat A-B from one track to another track.

• This operation is not available for Data Disc and USB.

• If you stop playback by pressing , repeat A-B is canceled.

• You cannot use repeat A-B when this unit is in PURE DIRECT
mode.

14 En

PROGRAM PLAY

Audio CD

You can customize the playback order of up to 50 tracks
stored on an Audio CD. This operation is not available for
Data Disc and USB.

1 Press s to stop playback.

Following information is displayed.
When you press “6”:

The selected track number

When you press ENTER:

Total number of tracks
currently programmed

Total time of the tracks
currently programmed

Repeat this operation to program more tracks.
You can select the same track again.

Note

Pressing PROGRAM in program input mode exits to normal
playback mode, though programmed tracks are stored.

4 Press h to start program play.

OPERATION

2 Press PROGRAM.

• In this mode, the front panel
display shows as normally, even
when this unit is in PURE
DIRECT mode.

This unit is set to program input mode.

3 Program a desired track by pressing the

corresponding numeric button and ENTER.

+

Following information is displayed.

Current track

Elapsed time of the
current track

English

15 En

PROGRAM PLAY

Stopping program playback

Press s.

To restart program play, press h after pressing
PROGRAM.

Playback starts from the first programmed track number.

Clearing programmed track

There are several methods, as described below.

■ Clearing the last programmed track

Press CLEAR during program input mode.

Following information is displayed.

Total number of the
tracks currently
programmed

The last programmed track is cleared.

Total time of the
tracks currently
programmed

■ Clearing all programmed tracks

Press CLEAR after exiting program input
mode.

Following information is displayed.

All programmed tracks are cleared.
The display is turned off after 2 seconds.

Note

Switching to USB mode, opening the disc tray or switching off
the POWER clears all programmed tracks.

16 En

ADDITIONAL INFORMATION

NOTES ABOUT DISCS/MP3, WMA FILES

■ Discs playable with this unit

Audio CD Data Disc

This player is designed for playing back compact discs
bearing the marks shown below. Never attempt to load
any other type of disc into the unit. The unit can also play
back 8-cm (3-inch) compact discs.

....

Compact discs (digital audio)

The most popular discs for commercially
available audio CDs.

....

CD-R,CD-RW digital audio discs

Music CDs made by copying onto a CD-R
or CD-RW (including MP3 or WMA
format files).

Notes

• Be sure to use a CD-R or CD-RW disc made
by a reliable manufacture.

• Be sure to use a CD-R or CD-RW disc which
has at least one of the following phrases on
the disc or disc case.
FOR CONSUMER
FOR CONSUMER USE
FOR MUSIC USE ONLY

• Be sure to use a finalized CD-R or CD-RW
disc.

....

CD-TEXT discs

The discs recorded with text data such as
album titles, track titles and artist names.
Though these discs can be played back
with ordinary CD players, the text data is
not displayed.

MP3

MP3 is a standard technology and format for compressing
an audio sequence into a small-sized file. However, the
original level of sound quality is preserved during
playback.
The playable formats are:

• MPEG-1 Audio Layer-3
Bitrate*: 32-320 kbps
Sampling frequency: 44.1/48/32 kHz

• MPEG-2 Audio Layer-3, 2
Bitrate*: 8-160 kbps
Sampling frequency: 24/22.05/16 kHz

• MPEG-2.5 Audio Layer-2
Bitrate*: 8-160 kbps
Sampling frequency: 12/11.025/8 kHz

* Variable bitrate is supported.

WMA

“WMA (Windows Media Audio)” is a Microsoft file
format for encoding digital audio files similar to MP3
though can compress files at a higher rate than MP3.
The playable formats are:

•Version 8

• Version 9 (Standard and variable bitrates are
supported. Professional and Lossless are not
supported.)

• High Profile
Bitrate*: 32-320 kbps
Sampling frequency: 48/44.1/32 kHz

• Mid Profile
Bitrate: 16-32 kbps
Sampling frequency: 22.05/16 kHz

* Both constant and variable bitrates are supported.

INFORMATION

ADDITIONAL

Note

This compact disc player may not be able to play back some
CD-RW discs or discs on which recording was not made
correctly.

To prevent a malfunction of this unit:

• Do not use any nonstandard
shaped disc (heart, etc.) available
on the market because it might
damage the unit.

• Do not use a disc with tape, stickers, or paste on it. If
you use such a disc, the disc may get stuck in the
unit, or damage to the unit may result.

■ About MP3 and WMA files

Data Disc USB

You can play back MP3 and WMA files recorded on a
CD-R/CD-RW and those stored on a USB device.

Notes

• Playback for Data Disc starts in alphanumeric order.

• Playback for USB starts in order by date and time of creation.

• Copyright-protected WMA (DRM) files cannot be played back
by this unit.

• The disc must be ISO9660 compatible.

• Text data contained in files is not displayed on this unit.

• The maximum file and folder numbers are as follows.

Data Disc USB

Maximum file number

Maximum folder number

Maximum file number per
folder

512 999

255 255

511 255

(continued on the next page)

17 En

English

NOTES ABOUT DISCS/MP3, WMA FILES

■ Notes about handling compact discs

• Always handle a disc with care so that its surface is not
scratched.

• Compact discs are not subjected to wear during
playback, but damage to the disc surface when the disc
is being handled can adversely affect the disc playback.

• Be sure to use a felt-tip pen or similar writing tool
when writing on the label side of the disc. Do not use a
ballpoint pen, pencil, or other hard-tipped writing tool,
as these may damage the disc and may adversely affect
the disc playback.

• Do not warp discs.

• When a disc is not being used, remove it from the unit
and store in an appropriate case.

• When removing or storing a disc, be careful not to
scratch the playing surface.

• Compact discs are not affected by small particles of
dust or fingerprints on their playing surface, but even
so they should be kept clean. Wipe by using a clean,
dry cloth.
Do not wipe with a circular motion; wipe straight
outward from the center.

To play back an 8-cm (3-inch) CD

Place it in the inner recessed area of the disc tray. Do not
put a normal (12-cm) CD on top of an 8-cm (3-inch) CD.

• Do not try to clean the disc’s surface by using any type
of disc cleaner, record spray, anti-static spray or liquid,
or any other chemical-based liquid because such
substances might irreparably damage the disc’s
surface.

• Do not expose discs to direct sunlight, high
temperature or high humidity for a long period of time,
as these might warp or otherwise damage the disc.

No!

18 En

TROUBLESHOOTING

If the unit fails to operate normally, check the following points to determine whether the problem can be corrected by the
simple measures suggested. If it cannot be corrected, or if the problem is not listed in the Problems column, disconnect
the power cable and contact your authorized Yamaha dealer or service center for help.

Problems Possible Causes Solutions

This unit fails to turn
on.

The disc tray does
not close completely.

Disc playback does
not start.

USB playback does
not start.

Playback is delayed,
or begins at the
wrong place.

No sound. Improper output cable connections. Connect the cables properly. If the problem

Sound of a
component
connected to the
DIGITAL OUT jacks
is not played.

Sound “skips”. This unit is being subjected to vibrations or

Sound “hums”. Improper cable connections. Securely connect the audio cables. If the

Noise from a nearby
tuner.

Noise from inside of
the disc tray.

The power cable is not connected to the AC IN
inlet on the rear panel or not plugged in the wall
outlet.

A foreign object is obstructing the tray. Carefully check the disc tray and remove the

The disc is damaged. Check the disc carefully; replace it if necessary. —

There is moisture on the laser pickup. Wait 20 to 30 minutes after switching on the

The disc is loaded upside down. Reload the disc with the label side up. 9

The disc is dirty. Clean the disc. 18

The format of the MP3 or WMA file is not
compatible with this unit.

The CD-RW (ReWritable) disc is not recorded
correctly.

The disc is a non-standard disc not playable with
this unit.

This unit is in USB mode. Switch to disc mode by pressing CD/USB.5, 9

Improper USB device connections. Connect the USB device again. 8

The format of the MP3 or WMA file is not
compatible with this unit.

This unit is in disc mode. Switch to USB mode by pressing CD/USB.5, 9

The disc may be scratched or damaged. Check the disc carefully; replace it if necessary.

Improper amplifier operation. Set the amplifier controls to the correct input

PURE DIRECT is turned on. Turn PURE DIRECT off. Or make an analog

impacts.

The disc is dirty. Clean the disc. 18

The tuner is too close to this unit. Move the tuner and this unit farther apart.

The disc may be warped. Replace the disc.

Connect the power cable firmly.

foreign object.

unit ON before trying to play back a disc.

Replace the disc with a correctly recorded disc
playable with this unit.

Replace the disc with a correctly recorded disc
playable with this unit.

Replace the disc with a correctly recorded disc
playable with this unit.

Replace the file with a correctly recorded file
playable with this unit.

persists, the cables may be defective.

selection.

connection.

Relocate this unit.

problem persists, the cables may be defective.

Refer to

page

8

—

—

17

17

17

17

18

7

—

10

—

7

—

—

INFORMATION

English

ADDITIONAL

19 En

TROUBLESHOOTING

Problems Possible Causes Solutions

The remote control
does not work or
function properly.

Wrong distance or angle. The remote control functions within a

Direct sunlight or lighting (from an inverter type
of fluorescent lamp, etc.) is striking the remote
control sensor of this unit.

The batteries are weak. Replace all batteries. 6

maximum range of 6 m (20 ft) and no more than
30 degrees off-axis from the front panel.

Reposition this unit.

SPECIFICATIONS

Audio Section

• Frequency response......................................2 Hz - 20 kHz, ± 0.5 dB

• Harmonic distortion + noise (1 kHz) .........................0.002 % or less

• S/N ratio .................................................................... 110 dB or more

• Dynamic ................................................................... 100 dB or more

• Output voltage (1 kHz, 0 dB)...........................................2.0 ± 0.3 V

Laser Diode Properties

• Material.................................................................................GaAlAs

• Wavelength ............................................................................790 nm

• Laser Output.............................................................. max. 1.23 μW*

* This output is the value measured at a distance of about 200 mm

from the objective lens surface on the Optical Pick-up Block.

General

• Power requirements

U.S.A. and Canada models...............................AC 120 V, 60 Hz

Australia model ................................................AC 240 V, 50 Hz

Europe and U.K. models .......................... AC 220-240 V, 50 Hz

Asia and General models.......AC 110-120/220-240 V, 50/60 Hz

Korea model .....................................................AC 220 V, 60 Hz

China model......................................................AC 220 V, 50 Hz

• Power consumption ...................................................................16 W

• Dimensions (W × H × D) ...................................435 × 96 × 300 mm

• Weight ......................................................................................6.2 kg

Please note that all specifications are subject to change
without notice.

Refer to

page

6

—

20 En

Limited Guarantee for European Economic Area (EEA) and Switzerland

Thank you for having chosen a Yamaha product. In the unlikely event that your Yamaha product needs guarantee service, please contact the dealer from
whom it was purchased. If you experience any difficulty, please contact Yamaha representative office in your country. You can find full details on our
website (http://www.yamaha-hifi.com/ or http://www.yamaha-uk.com/ for U.K. resident).

The product is guaranteed to be free from defects in workmanship or materials for a period of two years from the date of the original purchase. Yamaha
undertakes, subject to the conditions listed below, to have the faulty product or any part(s) repaired, or replaced at Yamaha’s discretion, without any charge
for parts or labour. Yamaha reserves the right to replace a product with that of a similar kind and/or value and condition, where a model has been
discontinued or is considered uneconomic to repair.

Conditions

1. The original invoice or sales receipt (showing date of purchase, product code and dealer’s name) MUST accompany the defective product, along with a

statement detailing the fault. In the absence of this clear proof of purchase, Yamaha reserves the right to refuse to provide free of charge service and the
product may be returned at the customer’s expense.

2. The product MUST have been purchased from an AUTHORISED Yamaha dealer within the European Economic Area (EEA) or Switzerland.

3. The product must not have been the subject of any modifications or alterations, unless authorised in writing by Yamaha.

4. The following are excluded from this guarantee:
a. Periodic maintenance and repair or replacement of parts due to normal wear and tear.

b. Damage resulting from:

(1) Repairs performed by the customer himself or by an unauthorised third party.
(2) Inadequate packaging or mishandling, when the product is in transit from the customer. Please note that it is the customer’s responsibility to

ensure the product is adequately packaged when returning the product for repair.

(3) Misuse, including but not limited to (a) failure to use the product for its normal purpose or in accordance with Yamaha’s instructions on the

proper use, maintenance and storage, and (b) installation or use of the product in a manner inconsistent with the technical or safety standards in
force in the country where it is used.

(4) Accidents, lightning, water, fire, improper ventilation, battery leakage or any cause beyond Yamaha’s control.
(5) Defects of the system into which this product is incorporated and/or incompatibility with third party products.
(6) Use of a product imported into the EEA and/or Switzerland, not by Yamaha, where that product does not conform to the technical or safety

standards of the country of use and/or to the standard specification of a product sold by Yamaha in the EEA and/or Switzerland.

(7) Non AV (Audio Visual) related products.

(Products subject to “Yamaha AV Guarantee Statement” are defined in our website at http://www.yamaha-hifi.com/ or
http://www.yamaha-uk.com/ for U.K. resident.)

5. Where the guarantee differs between the country of purchase and the country of use of the product, the guarantee of the country of use shall apply.

6. Yamaha may not be held responsible for any losses or damages, whether direct, consequential or otherwise, save for the repair or replacement of the

product.

7. Please backup any custom settings or data, as Yamaha may not be held responsible for any alteration or loss to such settings or data.

8. This guarantee does not affect the consumer’s statutory rights under applicable national laws in force or the consumer’s rights against the dealer arising

from their sales/purchase contract.

■ For U.K. customers

Information for Users on Collection and Disposal of Old Equipment
and Used Batteries

These symbols on the products, packaging, and/or accompanying documents mean that used electrical and
electronic products and batteries should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them to
applicable collection points, in accordance with your national legislation and the Directives 2002/96/EC
and 2006/66/EC.

By disposing of these products and batteries correctly, you will help to save valuable resources and prevent
any potential negative effects on human health and the environment which could otherwise arise from
inappropriate waste handling.

For more information about collection and recycling of old products and batteries, please contact your
local municipality, your waste disposal service or the point of sale where you purchased the items.

[Information on Disposal in other Countries outside the European Union]

These symbols are only valid in the European Union. If you wish to discard these items, please contact
your local authorities or dealer and ask for the correct method of disposal.

Note for the battery symbol (bottom two symbol examples):

This symbol might be used in combination with a chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical involved.

©

2008 Yamaha Corporation All rights reserved.

Printed in Malaysia WQ01730
