Xerox DocuColor 5750 Administrator Guide
Administrator Guide
for the Xerox DocuColor Server
DocuColor Server
Copyright © 1998 Electronics for Imaging, Inc. All rights reserved.
This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose
without express prior written consent from Electronics for Imaging, Inc., except as expressly permitted herein. I nformation in this document is subject to change
without notice and does not represent a commitment on the part of Electronics for Imaging, Inc.
The software described in this publication is furnished under license and may only be used or copied in accordance with the terms of such license.
Patents: 5,666,436; 5,553,200; 5,543,940; 5,537,516; 5,517,334; 5,506,946;5,424,754; 5,343,311; 5,212,546; 4,941,038; 4,837,722; 4,500,919
Trademarks
EFI, the EFI logo, Fiery, the Fiery logo, and the ColorWise logo are trademarks registered with the U.S. Patent and Trademark Office. DocuColor, Fiery XJe,
Fiery XJ+, Fiery Driven, the Fiery Driven logo, XJ RipChips, Rip-While-Print, Continuous Print, Command WorkStation, AutoCal, Starr Compression, and
Memory Multiplier are trademarks of Electronics for Imaging, Inc.
Xerox 5760, 5765, 5790, 5750, MajestiK, Regal, and all Xerox product names mentioned in this publication are trademarks of the Xerox Corporation.
Adobe, the Adobe logo, Adobe Illustrator , P ostScript, Adobe P hotoshop, Adobe S eparator , and A dobe P ageMaker are trademarks of A dobe Systems Incorporated,
registered in certain jurisdictions. EPS (Encapsulated PostScript) is a trademark of Altsys Corporation. Apple, the A pple logo, AppleS hare, A ppleTalk, E therTalk,
LaserWriter, and Macintosh are registered trademarks, and MultiFinder is a trademark of Apple Computer, Inc. Microsoft, MS, and MS-DOS are registered
trademarks, and Windows is a trademark of Microsoft Corporation in the US and other countries. QuarkXPress is a registered trademark of Quark, Inc. Times,
Helvetica, and Palatino are trademarks of Linotype AG and/or its subsidiaries. ITC Avant Garde, ITC Bookman, ITC Zapf Chancery, and ITC Zapf Dingbats
are registered trademarks of International Typeface Corporation. Ethernet is a registered trademark of Xerox Corporation. Farallon, PhoneNET PC, and
PhoneNET Talk are trademarks of Farallon Computing, Inc. COPS and COPSTalk are trademarks of CoOperative Printing Solutions, Inc. NetWare and Novell
are registered trademarks and Internetwork P acket E xchange (IPX) is a trademark of Novell, Inc. UNIX is a registered trademar k of UNIX System Laboratories,
a wholly owned subsidiary of Novell, Inc. Sun, Sun Microsystems and SunOS are trademarks or registered trademarks of Sun Microsystems, Inc. PANTONE is
a registered trademark of Pantone, Inc. X-Rite
®
is a registered trademark of X-Rite, Incorporated.
All other terms and product names may be trademarks or registered trademarks of their respective owners, and are hereby acknowledged.
Legal Notices
APPLE COMPUTER, INC. (“APPLE”) MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THE APPLE SOFTWARE.
APPLE DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE USE
OF THE APPLE SOFTWARE IN TERMS OF ITS CORRECTNESS, ACCURACY, RELIABILITY, CURRENTNESS, OR OTHERWISE. THE ENTIRE
RISK AS TO THE RESULTS AND PERFORMANCE OF THE APPLE SOFTWARE IS ASSUMED BY YOU. THE EXCLUSION OF IMPLIED
WARRANTIES IS NOT PERMITTED BY SOME STATES. THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.
IN NO EVENT WILL APPLE, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE TO YOU FOR ANY CONSEQUENTIAL,
INCIDENTAL OR INDIRECT DAMA GES (INCLUDING DAMA GES FOR LOSS OF BUSINESS PR OFITS, BUSINESS INTERRUPTION, L OSS OF
BUSINESS INFORMATION, AND THE LIKE) ARISING OUT OF THE USE OR INABILITY TO USE THE APPLE SOFTWARE EVEN IF APPLE
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
Apple’s liability to you for actual damages from any cause whatsoever, and regardless of the form of the action (whether in contract, tort [including negligence],
product liability or otherwise), will be limited to $50.
Restricted Rights Legends
For defense agencies: Restricted Rights Legend. Use, reproduction, or disclosure is subject to restrictions set forth in subparagraph (c)(1)(ii) of the Rights in
Technical Data and Computer Software clause at 252.227.7013.
For civilian agencies: Restricted Rights Legend. Use, reproduction, or disclosure is subject to restrictions set forth in subparagraph (a) through (d) of the
commercial Computer Software Restricted Rights clause at 52.227-19 and the limitations set forth in Electronics for Imaging, Inc.’s standard commercial
agreement for this software. Unpublished rights reserved under the copyright laws of the United States.
Printed in the United States of America on recycled paper.
Part Number:
n/a
FCC Information
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void
the user’s authority to operate this equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates,
and uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference
at his own expense.
Industry Canada Class A Notice
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard
entitled, “Digital Apparatus” ICES-003 from Industry Canada.
Avis de Conformation Classe A de l’Industrie Canada
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la Classe A prescrites dans la
norme sur le matériel brouilleur, “Appareils Numériques” NMB-003 édictée par l’Industrie Canada.
Certificate by Manufacturer/Importer
This is to certify that the FC07 is shielded against radio interference in accordance with the provisions of VFG 243/1991. The G erman Postal Services have been
advised that this device is being put on the market and that they have been given the right to inspect the series for compliance with the regulations.
Electronics for Imaging, Inc.
Bescheinigung des Herstellers/Importeurs
Heirmit wird bescheinigt, daß der FC07 im Übereinstimmung mit den Bestimmungen der VFG 243/1991 Funk-Entstort ist. Der D eutschen Bundespost wurde
das Inverkehrbringen dieses Gerätes angezeigt und die Berechtigung zur Überprüfung der Serie auf Einhaltung der Bestimmungen eingeraumt.
Electronics for Imaging, Inc.
RFI Compliance Notice
This equipment has been tested concerning compliance with the relevant RFI protection requirements both individually and on system level (to simulate normal
operation conditions). However, it is possible that these RFI Requirements are not met under certain unfavorable conditions in other installations. It is the user
who is responsible for compliance of his particular installation.
Dieses Gerät wurde sowohl einzeln als auch in einer Anlage, die einen normalen Anwendungsfall nachbildet, auf die Einhaltung der Funkentstörbestimmungen
geprüft. Es ist jedoch möglich, daß die Funkenstörbestimmungen unter ungünstigen Umständen bei anderen Gerätekombinationen nicht eingehalten werden.
Für die Einhaltung der Funkentstörbestimmungen einer gesamten Anlage, in der dieses Gerät betrieben wird, ist der Betreiber verantwortlich.
Compliance with applicable regulations depends on the use of shielded cables. It is the user who is responsible for procuring the appropriate cables.
Die Einhaltung betreffender Bestimmungen hängt davon ab, daß geschirmte Ausführungen benützt werden. Für die Beschaffung richti ger Ausführungen ist der
Betreiber verantwortlich.
Software License Agreement
Electronics for Imaging, Inc. grants to you a non-exclusive, non-transferable license to use the software and accompanying documentation (“Softwar e”) included
with the Fiery XJ Color Server you have purchased, including without limitation the PostScript
®
software provided by Adobe Systems Incorporated.
You may:
a. use the Software solely for your own customary business purposes and solely with Fiery XJ;
b. use the digitally-encoded machine-readable outline and bitmap programs (“Font P rograms”) pr ovided with F iery XJ in a special encrypted format (“Coded Font
Programs”) to reproduce and display designs, styles, w eights, and versions of letters, numerals, characters and symbols (“Typefaces”) solely for your own customary
business purposes on the screen of the Fiery XJ or Macintosh monitor used with Fiery XJ;
c. use the trademarks used by Electronics for Imaging to identify the Coded Font Programs and Typefaces reproduced therefrom (“Trademarks”); and
d. assign your rights under this Agreement to a transferee of all of your right, title and interest in and to Fiery XJ provided the transfer ee agrees to be bound by all
of the terms and conditions of this Agreement.
You may not:
a. make use of the Software, directly or indirectly, to print bitmap images with print resolutions of 6c00 dots per inch or greater, or to generate fonts or typefaces
for use other than with Fiery XJ;
b. make or have made, or permit to be made, any copies of the Software, Coded Font Programs, accompanying documentation or portions thereof, except as
necessary for use with the Fiery XJ unit purchased by you; provided, however, that under no circumstances may you make or have made, or permit to be made,
any copies of that certain portion of the Software which has been included on the Fiery XJ hard disk drive. You may not copy the documentation;
c. attempt to alter, disassemble, decrypt or reverse engineer the Software, Coded Font Programs or accompanying documentation;
d. rent or lease the Software.
Proprietary Rights
You acknowledge that the Software, Coded Font Programs, Typefaces, Trademarks and accompanying documentation are proprietary to Electronics for Imaging
and its suppliers and that title and other intellectual property rights therein remain with Electronics for Imaging and its suppliers. Except as stated above, this
Agreement does not grant you any right to patents, copyrights, trade secrets, trademarks (whether registered or unregistered), or any other rights, franchises or
licenses in respect of the Software, Coded Font Programs, Typefaces, Trademarks or accompanying documentation. You may not adapt or use any trademark or
trade name which is likely to be similar to or confusing with that of Electronics for Imaging or any of its suppliers or take any other action which impairs or reduces
the trademark rights of Electronics for Imaging or its suppliers. The trademarks may only be used to identify printed output produced by the Coded Font
Programs. At the reasonable request of Electronics for Imaging, you must supply samples of any Typeface identified with a trademark.
The MacApp software is proprietary to Apple Computer, Inc. and is licensed to Electronics for Imaging, Inc. for distribution only for use in combination with
DocuColor software utilities.
Confidentiality
You agr ee to hold the Software and Coded F ont P rograms in confidence, disclosing the Softwar e and Coded Font P rograms only to authoriz ed users having a need
to use the Software and Coded Font Programs as permitted by this Agreement and to take all reasonable precautions to prevent disclosure to other parties.
Remedies
Unauthorized use, copying or disclosure of the Software, Coded F ont Programs, Typefaces, Trademarks or accompanying documentation will result in automatic
termination of this license and will make available to Electronics for Imaging other legal remedies.
Limited Warranty and Disclaimer
Electronics for Imaging warrants that, for a period of ninety (90) days from the date of delivery to you, the Software under normal use will perform without
significant errors that make it unusable. Electronics for Imaging’s entire liability and your exclusive remedy under this warranty (which is subject to you returning
DocuColor to Electronics for Imaging or an authorized dealer) will be, at Electronics for Imaging’s option, to use reasonable commercial efforts to attempt to
correct or work around errors, to replace the Software with functionally equivalent software, or to refund the purchase price and terminate this Agr eement. Some
states do not allow limitations on duration of implied warranty, so the above limitation may not apply to you.
Except for the above express limited warranty, Electronics for Imaging makes and you receive no warranties or conditions on the Products, express, implied, or
statutory, and Electronics for Imaging specifically disclaims any implied warranty or condition of merchantability or fitness for a particular purpose.
For warranty service, please contact your authorized service/support center.
EXCEPT FOR THE ABOVE EXPRESS LIMITED WARRANTY, ELECTRONICS FOR IMAGING MAKES AND YOU RECEIVE NO WARRANTIES
OR CONDITIONS ON THE SOFTW ARE OR CODED FONT PROGRAMS, EXPRESS, IMPLIED, STATUTORY, OR IN ANY OTHER PRO VISION
OF THIS AGREEMENT OR COMMUNICATION WITH YOU, AND ELECTRONICS FOR IMAGING SPECIFICALL Y DISCLAIMS ANY IMPLIED
WARRANTY OR CONDITION OF MER CHANT ABILITY OR FITNESS FOR A PAR TICULAR PURPOSE. Electr onics for Imaging does not warrant that
the operation of the software will be uninterrupted or error free or that the Software will meet your specific requirements.
Limitation of Liability
IN NO EVENT WILL ELECTRONICS FOR IMAGING OR ITS SUPPLIERS BE LIABLE FOR ANY DAMA GES, INCLUDING LOSS OF DATA, LOST
PROFITS, COST OF COVER OR O THER SPECIAL, INCIDENT AL, CONSEQ UENTIAL OR INDIRECT DAMAGES ARISING FR OM THE USE OF
THE SOFTWARE, CODED FONT PROGRAMS OR ACCOMPANYING DOCUMENTATION, HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY. THIS LIMITATION WILL APPLY EVEN IF ELECTRONICS FOR IMAGING OR ANY AUTHORIZED DEALER HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGE. YOU ACKNOWLEDGE THAT THE PRICE OF DOCUCOLOR REFLECTS THIS ALLOCATION OF
RISK. BECAUSE SOME STA TES/JURISDICTIONS DO NO T ALLO W THE EX CLUSION OR LIMIT A TION OF LIABILITY FOR CONSEQUENTIAL
OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
Export Controls
You agr ee that you will not export or re-export the S oftware or Coded Font Programs in any form without the appropriate United States and foreign government
licenses. Your failure to comply with this provision is a material breach of this Agreement.
Government Use
Use, duplication or disclosure of the Software by the United States Government is subject to restrictions as set forth in subdivision (c) (1) (ii) of the Rights in
Technical Data and Computer Software clause at DFARS 252.227-7013 or in subparagraphs (c) (1) and (2) of the Commercial Computer Software—Restricted
Right Clause at 48 CFR 52.227-19, as applicable.
Third Party Beneficiary
You ar e hereby notified that Adobe S ystems Incorporated, a California corporation located at 345 P ark A v e., San J ose, California 95110-2704 (“Adobe”) is a third-
party beneficiary to this Agreement to the extent that this Agreement contains provisions which relate to your use of the Fonts, the Coded Font Programs, the
T ypefaces and the Trademarks licensed hereby. S uch provisions ar e made expressly for the benefit of Adobe and are enforceable b y Adobe in addition to Electronics
for Imaging.
General
This Agreement will be governed by the laws of the State of California.
This Agreement is the entire agreement held between us and supersedes any other communications or advertising with respect to the Software, Coded Font
Programs and accompanying documentation.
If any provision of this Agreement is held invalid, the remainder of this Agreement shall continue in full force and effect.
If you have any questions concerning this Agreement, please write to Electronics for Imaging, Inc., Attn: Licensing Dept. or see Electronics for I maging’s web site
at www.efi.com.
Electronics for Imaging, Inc.
2855 Campus Drive
San Mateo, CA 94403
Contents
Introduction
Network administration features
xi
About the documentation
xii
About this manual xiii
Conventions used in DocuColor manuals xiii
Chapter 1: Connecting to the Network
DocuColor on the network
1-1
Stages of installation on the network
1-2
Quick path to installation
1-4
Before you begin
1-11
Ethernet cable connection
1-12
Parallel cable connection
1-14
Chapter 2: Setting up the DocuColor
About DocuColor Setup
2-1
DocuColor Setup from the Control Panel
2-2
Accessing Setup options 2-2
Running DocuColor Setup
2-5
Types of setup screens 2-5
Server Setup options
2-7
Network Setup options
2-9
Port Setup options 2-11
Protocol Setup options 2-14
Service Setup options 2-19
DocuColor printing connections
2-31
Direct connection 2-31
Queues 2-32
Printer Setup options
2-32
viii Contents
PS Setup options
2-34
Color Setup options
2-36
Administrative functions in the Setup menu
2-37
DocuColor Job Log Setup 2-37
Job Log Setup options 2-38
Calibration 2-39
Change Password 2-42
Clear Server 2-43
Exit Setup 2-43
Chapter 3: Setting up network servers
DocuColor on an IPX network
3-1
Tips for experts—IPX networks 3-2
Overview of IPX printing to the DocuColor 3-3
Configuring a NetWare server for printing
3-4
Setting up an NDS connection 3-6
Setting the NetWare 4.x bindery context 3-9
Setting up a DocuColor print queue for bindery 3-12
Setting up NetWare Windows clients for printing
3-15
Configuring Windows 95 workstations for remote utilities
3-16
DocuColor on a TCP/IP network with Windows NT
3-18
Tips for experts—Windows NT with TCP/IP 3-18
Configuring a Windows NT server to support the DocuColor
3-19
Loading the TCP/IP network protocol 3-20
Adding the DocuColor to the TCP/IP network 3-21
Installing the DocuColor as a shared PostScript printer 3-23
Configuring Windows NT clients 3-25
Configuring Windows NT workstations for remote utilities 3-26
Using AppleTalk with NetWare servers
3-27
Using AppleTalk with Windows NT
3-27
Configuring the DocuColor and clients for WebTools
3-28
ix Contents
DocuColor on a network with UNIX workstations
3-29
Tips for experts—UNIX workstations 3-30
Important note about the remote printer name 3-30
Setting up the DocuColor on TCP/IP networks 3-31
Printing and managing print jobs 3-32
Chapter 4: Administering the DocuColor
Administrator functions
4-1
Maintaining optimal server performance
4-2
Troubleshooting the DocuColor
4-3
Troubleshooting during Setup from the Control Panel 4-3
Runtime error messages 4-9
Appendix A: Token Ring Network Option
DocuColor Token Ring option
A-1
Connecting Token Ring hardware A-1
IPX/SPX installations
A-3
TCP/IP installations
A-3
Setting up Token Ring on the DocuColor
A-4
Setting up NetWare Windows clients
A-4
Index
xi Network administration features
This manual is intended for anyone who is responsible for integrating the DocuColor
Color Server
TM
into a business environment that includes networked personal comput-
ers. After the DocuColor and client workstations are set up, as described in this guide
and in
Getting Started
, individual users can print to the color server as a high-perfor-
mance color Adobe
®
PostScript
®
printer.
This manual includes guidelines on the following topics:
• Basic configuration of the DocuColor to support printing over TCP/IP and IPX
(Novell
®
) networks
• Setting up a parallel port connection
• Configuring UNIX
®
systems and Novell and Microsoft
®
Windows NT
®
servers to
provide DocuColor printing services
• Administering network printing
• Using the DocuColor in mixed network environments
• Setting up a Token Ring connection
N
OTE
:
The network guidelines in this book are not intended to replace the services of
an experienced network engineer.
Network administration features
DocuColor software offers several important features that affect you as a network or
printer administrator:
• Direct (native) support of NDS with NetWare
®
4.x
NetWare 4.x can also be supported in bindery emulation.
N
OTE
:
NDS is an abbreviation for either Novell Directory Services or
NetWare Directory Services. The two names are used interchangeably.
• Simultaneous NetWare 4.x and NetWare 3.12 connections supported
One NetWare 4.x NDS server and up to eight NetWare 3.12 bindery servers
(or NetWare 4.x servers in bindery emulation mode) can be connected to the Docu-
Color.
Introduction
xii Introduction
• Remote utilities (Spooler
TM
and Downloader
TM
) for Windows computers
The utilities can be run from a Windows 95
®
workstation running IPX/SPX or from a
Windows NT 4.0 Workstations or Windows NT 4.0 Server running TCP/IP proto-
cols.
• WebTools
TM
(WebSpooler and Installer)
The WebTools allow you to manage the DocuColor from the Internet or from your
company’s intranet. To use the WebTools, you need to set certain options in Network
Setup and Printer Setup.
• Color calibration
AutoCal
TM
is a copier-based calibration option that does not require a densitometer.
Two calibration targets are provided. For more information on calibration, see the
User
Guide.
• Support for Windows (WINS) printing
Windows printing, also known as WINS printing, allows you to print using built-in
Microsoft networking support without additional network software. Printing by this
method allows you to print from your computer to a particular queue (Print or Dir ect)
on the DocuColor.
About the documentation
This guide is part of the set of documentation that includes the following manuals for
users and system administrators:
• The
Administrator Guide
explains basic configuration and administration of the
DocuColor for the supported platforms and network environments. It includes
guidelines for setting up UNIX, Windows NT, and NetWare servers to provide
PostScript printing services to clients.
•
Getting Started
describes how to install software to enable users to print to the
DocuColor. Specifically, it describes installation of PostScript printer drivers, printer
description files, and other user software provided on the DocuColor User Software
CD. It also explains how to connect each user to the network.
• The
User Guide
describes the printing features of the DocuColor for users who send
jobs via remote workstations on the network or via a direct parallel port connection.
It also describes the WebTools, the Spooler, and the Downloader, and lists the
printer fonts installed on the DocuColor.
xiii About the documentation
•
Release Notes
provides last-minute product information and workarounds for some
of the problems you may encounter.
About this manual
You’ll find the following information in this manual:
• Chapter 1 illustrates the supported network configurations and shows the network
connectors on the DocuColor.
• Chapter 2 describes configuring the DocuColor from its Control Panel.
• Chapter 3 offers guidelines for setting up Windows network servers and UNIX
systems for printing to the DocuColor.
• Chapter 4 summarizes some administrative features of DocuColor software that are
available for the three major platforms, and offers some troubleshooting hints.
• Appendix A describes the Token Ring option.
Administrator features described in other manuals are summarized on page 4-1.
Conventions used in DocuColor manuals
Actions you should perform are shown as numbered steps in bold-faced type, followed
by a brief explanation if needed. For example:
1. Choose Options in the Print dialog box.
Special options for your printer are available if you have installed the PostScript Level 2
driver and the PPD for your printer.
A special font indicates text you should type or keys you should press. For example:
<Tab>
indicates that you should press the Tab key.
• At the NetWare 4.x drive prompt, type:
rconsole
The special font is also used to highlight options that appear in DocuColor setup
menus. For example:
This option appears only if
Enable Parallel Port
is set to
Yes
.
xiv Introduction
The initial letters of menu options and Control Panel setups are uppercase. Filenames
and settings are listed in the special font only if it is hard to distinguish them from sur-
rounding text.
Occasionally you will be referred to other DocuColor manuals, whose titles will be
shown in italics. For example, see
Getting Started
.
1
1-1 DocuColor on the network
This chapter summarizes the stages in setting up a DocuColor, and includes diagrams
that refer you to other chapters or other manuals for completing your installation. If
you check those references, you should be able to find the information you need
quickly.
DocuColor on the network
When the DocuColor is connected to a network, it behaves as a networked PostScript
printer. The built-in Ethernet interface on the DocuColor supports the following
network protocols:
• TCP/IP (the lpd, nbt, and http protocols)
TCP/IP stands for Transmission Control Protocol/Internet Protocol. The lpd proto-
col is the standard TCP/IP printing protocol. The nbt protocol supports Windows
(WINS) printing. The http protocol is the protocol used for connection to the Inter-
net.
• IPX/SPX (Novell)
IPX/SPX stands for Internetwork Packet Exchange/Sequenced Packet Exchange.
These protocols (rules that enable computers on a network to communicate with each
other) are supported on the Windows, and UNIX platforms and can run concurrently
on the same Ethernet cable. Workstations that use other protocols can print through a
server that uses one of the protocols mentioned, or they can print to the DocuColor
parallel port. A Token Ring option is also available. This option supports the TCP/IP
and IPX protocols. The DocuColor is auto-sensing, and can handle all of these con-
nections simultaneously.
When you add a DocuColor to a network, it is assumed that a network administrator
will have already installed a network cabling system and connected workstations and
servers.
Chapter 1:
Connecting to
the Network
1
1-2 Connecting to the Network
Stages of installation on the network
Installation can be performed by a network or printing administrator. The stages of a
successful installation are:
• Physically connecting the DocuColor to a functioning network
Prepare a network node for the DocuColor—obtain cable and route it to the location
where the DocuColor will be installed (near the copier), and attach the cable to the
network interface of the DocuColor. See page 1-11 for details.
• Configuring the network server
When network servers are required, you need to configure those servers to provide cli-
ent access to the DocuColor as a color PostScript printer. See Chapter 3 for configur-
ing network servers in Windows and UNIX network environments.
• DocuColor Setup
Configure the DocuColor for your particular printing and network environment. See
Chapter 2 for details.
• Client setup
Install the files needed for printing, install additional user software, and connect the
client to the DocuColor over the network. These steps ar e described in G etting Started,
and some information is provided in Chapter 3 of this manual.
• System administration
Monitor and maintain system performance and troubleshoot problems that arise. See
Chapter 4 for details.
1
1-3 DocuColor on the network
Summary of DocuColor network installation
COLOR SERVER SETUP
In the DocuColor Control Panel, configure
Server Setup, Network Setup, Printer
Setup, PS Setup, Color Setup, and Job Log
Setup. Perform AutoCal calibration.
Configure UNIX, Windows NT and IPX
(Novell) servers to specify DocuColor
print queues and DocuColor users.
Install PostScript printer drivers and
remote utilities on the server.
SERVER CONFIGURATION
Prepare a network node. Connect the
DocuColor to the copier and to the
network.
CLIENT SETUP
At each workstation that will print to the
DocuColor:
• Install the appropriate printer drivers
and printer description files (PPDs),
and connect to one or more queues.
• For computers that will use them,
install the remote utilities and an
Internet browser.
• Verify the DocuColor in the list of
printers and run a test print.
CONNECTION
DocuColor available on the network
Copier
Network server
UNIX Mac OS Windows
DocuColor
DocuColor
1
1-4 Connecting to the Network
Quick path to installation
The diagrams in the following pages show typical systems that can be used for printing
and for using the DocuColor utilities. To use the diagrams, find the page with your
preferred platform and network type. Then look up the setup procedures in the pages
and books referred to in the keys.
The diagrams describe devices that use the supported networking protocols. They are
logical diagrams and are not intended to describe the physical arrangement (topology)
of devices on the network. A variety of physical arrangements is possible with each
logical arrangement. For example, twisted pair Ethernet networks commonly use a star
configuration around a hub, rather than a bus arrangement. The design of physical
networks is beyond the scope of this manual.
If the network uses more than one protocol or more than one type of workstation,
combine the setups listed for each component of your system. Note that multiple
protocols (shown in the diagrams as parallel lines) can run on the same cable. A solid
connection from the DocuColor with an arrow indicates that other supported network
types can be operational at the same time.
NOTE: The networking functionality outlined in this section is available on both Ether-
net and Token Ring networks. A Token Ring card is required for connection to a
Token Ring network. Token Ring drivers are included with DocuColor system soft-
ware. See Appendix A for details.
The protocols used in these diagrams are indicated as follows:
AppleTalk
IPX (Novell)
Parallel
Other
TCP/IP (lpd or
nbt)
1
1-5 DocuColor on the network
Windows computers in a Novell environment
Windows computer:
IPX
NetWare server
Key to setup:
1 NetWare server page 3-4
2 DocuColor Setup Chapter 2
3 NetWare client Getting Started
4 Windows computer page 3-16,
Getting Started
Printing on this network
All Windows computers can print through the
NetWare server
For running utilities
A Windows computer with IPX/SPX protocols
loaded
1
2
3
IPX protocol
Another supported
protocol
DocuColor connected to copier
SPX for running utilities
IPX
SPX protocol
3, 4
NetWare client
Windows computer:
3
NetWare client
Windows computer:
NetWare client
running SPX
1
1-6 Connecting to the Network
Mac OS computers in a Novell environment
Mac OS computer
Mac OS computer
Key to setup:
1 NetWare Server page 3-4
page 3-27
2 DocuColor Setup Chapter 2
3 Mac OS computer Getting Started
2
3
3
Another supported
protocol
DocuColor connected to copier
AppleTalk
Printing on this network
Mac OS clients computers can print
through the NetWare server using the
AppleTalk protocol; the NetWare server
sends jobs to the DocuColor using the IPX
protocol
For running utilities
Remote utilities are not available on
Mac OS workstations
AppleTalk
NetWare server
1
IPX
IPX protocol
1
1-7 DocuColor on the network
Windows NT Server environment
Windows computer
Windows computer
Key to setup:
1 Windows NT Server page 3-18
2 DocuColor Setup Chapter 2
3 Windows NT client page 3-25,
Getting Started
1
2
3
3
TCP/IP protocol
Another supported
protocol
DocuColor connected to copier
LAN with
NETBEUI, etc.
Printing on this network
Windows 3.1x or Windows 95 clients can
print using a protocol available on the
Windows NT print server; Windows NT
machines can print using T CP/IP with the
lpd protocol
For running utilities
A Windows NT Server or Windows NT
Workstation, with TCP/IP loaded
NETBEUI or other protocol available on
the clients and the server
lpd (TCP/IP) for printing
TCP/IP for utilities
1
Windows NT Workstation
or Windows NT Server with
TCP/IP loaded
Windows NT Workstation
or Windows NT Server
acting as print server
1
1-8 Connecting to the Network
Windows computers using Windows (nbt) printing
Windows computer
Key to setup:
1 Windows computer Getting Started
2 DocuColor Setup Chapter 2
For Windows printing
Windows computers
WINS printing enabled
1
Another supported
protocol
TCP/IP (nbt) protocol
2
DocuColor connected to copier
Windows computer
1
Windows computer
1
1
1-9 DocuColor on the network
UNIX workstations and Windows NT computers on a TCP/IP network
UNIX server
Key to setup:
1 UNIX server/host page 3-30
2 DocuColor Setup Chapter 2
3 UNIX workstation page 3-30
4 TCP/IP client Getting Started,
page 3-30
5 Windows NT client page 3-18
2
TCP/IP (lpd) protocol
Another supported
protocol
TCP/IP client
4
DocuColor connected to copier
Printing on this network
UNIX workstations with lpd
protocol can print directly and act
as host for shared printing
TCP/IP clients can print through
UNIX server or directly
For running utilities
Requires Windows NT computer
with TCP/IP and lpd loaded
Remote utilities are not available
on UNIX workstations
1, 3
TCP/IP (lpd)
or workstation
5
Windows NT computer with
TCP/IP loaded
1
1-10 Connecting to the Network
DocuColor parallel port connection
The rest of this chapter and the next cover the parts of a installation that are performed
on the DocuColor itself. This chapter describes the physical network connections;
Chapter 2 summarizes DocuColor Setup and other administrative functions available
from the Control Panel.
Key to setup:
1 DocuColor Setup Chapter 2
2 Windows computer User Guide
PC workstation,
server, or laptop
1
Parallel input
2
Protocol not directly
supported on DocuColor
A supported
network protocol
With the parallel port enabled, the
DocuColor can accept and print jobs sent
to its parallel port.
DocuColor connected to copier
Parallel
1
1-11 DocuColor on the network
Before you begin
The following steps should be completed before you configure the DocuColor and the
workstations that will print to the DocuColor. A service technician will have
performed some initial installation.
TO PREPARE FOR DOCUCOLOR INSTALLATION:
1. Print a copier test page to make sure the copier is functioning normally.
2. Turn off the copier and connect the interface cable from the copier to the
DocuColor.
While the DocuColor is turned off, verify that the SCSI terminator is installed on the
SCSI connector on the back of the DocuColor.
3. To confirm this connection, turn on the copier and the DocuColor and print a Test Page
from the Control Panel.
To print a Test Page, press the Menu button on the Control Panel to display the
Functions menu. (See “DocuColor Control Panel” on page 2-3.) Choose Print Pages,
and then Test Page.
4. With both the copier and the DocuColor turned off, connect the network cable to the
DocuColor, as described in the next section.
The network should already be installed and operational.
5. Turn on the copier and then the DocuColor.
6. Prepare network servers to share DocuColor user software and to enable networked
users to print to the DocuColor, and proceed to Setup.
See Chapters 2 and 3 for details.
1
1-12 Connecting to the Network
Ethernet cable connection
The DocuColor supports Ethernet cabling of three types:
• Thinnet (thin coaxial Ethernet cable or 10Base2)
Uses an external transceiver to attach to the AUI (attachment unit interface) connec-
tor on the Ethernet interface of the DocuColor.
• Thicknet (thick coaxial Ethernet cable or 10Base5)
Connects directly to the AUI connector on the Ethernet interface of the DocuColor.
• Unshielded Twisted Pair (UTP), defined as Category 5 (10BaseT or 100BaseT)
Uses an 8-pin RJ-45 connector that plugs into the RJ-45 socket on the DocuColor.
NOTE: The DocuColor 100BaseT option is of type 100BaseTX, also known as Fast
Ethernet. If an Ethernet hub is used, it must be a 100BaseTX hub. Only Category 5
Unshielded Twisted Pair (UTP) cabling can be used with 100BaseTX. The term
“100BaseT” is used in this manual to refer to 100BaseTX.
1
1-13 Ethernet cable connection
Back view of the DocuColor
Shut down the DocuColor before connecting it to any network device
.
NOTE: Do not attach the cable to more than one Ethernet connector on the DocuColor
at one time.
If the Token Ring option is installed, you can attach an unshielded twisted pair cable to
the RJ-45 connector on the Token Ring board and attach a second cable to the RJ-45
Ethernet connector. For more information on Token Ring, see Appendix A.
TO USE THINNET CABLE:
1. With the DocuColor turned off, connect the transceiver to the AUI connector on the
back of the DocuColor. Press down on the latch to lock the transceiver connection.
2. Connect the thinnet cable to the BNC connector on the transceiver.
3. Configure network servers for printing and then proceed to Setup.
Centronics-type parallel connector
AUI connector for thinnet and thicknet
RJ-45 connector for twisted pair Ethernet
SCSI connector for external CD-ROM drive
Power switch
Serial port
Slots for Token Ring option
Slot for 100BaseT option
Copier connector slot
!
1
1-14 Connecting to the Network
TO USE THICKNET CABLE:
1. With the DocuColor turned off, connect the thicknet cable connector to the AUI con-
nector on the back of the DocuColor. Press down on the latch to lock the connector.
2. Configure network servers for printing and then proceed to Setup.
TO USE UNSHIELDED TWISTED PAIR CABLE:
1. With the DocuColor turned off, connect the RJ-45 cable connector to the RJ-45 socket
on the back of the DocuColor.
2. Configure network servers for printing and then proceed to Setup.
Parallel cable connection
In addition to receiving print jobs over Ethernet and Token Ring, the DocuColor can
accept print jobs from a Windows computer through its high-speed parallel port. This
connection is advantageous for portable computers and for workstations that use
dedicated networks using protocols other than TCP/IP or IPX.
The parallel port connection is active at the same time as the network ports.
TO USE PARALLEL CABLE:
1. With the DocuColor and the Windows computer or server turned off, attach the Cen-
tronics-type parallel cable to the parallel port of the DocuColor.
The parallel port is the top connector on the back of the DocuColor.
2. Connect the other end of the cable to the parallel port on the Windows computer.
3. Turn on the computer and the DocuColor.
4. Proceed to Setup.
To print to the parallel port, you will need to set up the parallel port connection. See
“Parallel P ort S etup options ” on page 2-13. For information on setting up printing, see
Getting Started; for printing to the parallel port, see the User Guide.
2
2-1 About DocuColor Setup
The DocuColor Color Server fits into a variety of work environments. To prepare for
printing at your site, you need to do some initial configuration to specify the network
environment and the kind of printing you will do.
About DocuColor Setup
When the DocuColor is powered on after new system software is loaded, you (or the
service technician who loads the software) choose the language you want to use for
Control Panel screens. After that, the S erver, Network, Printer , PS, Color, and Job Log
Setups, in that order, must be configured from the Control Panel.
On Novell or Windows NT (using TCP/IP), and Token Ring networks, the network
servers should be configured for printing to the DocuColor before you enter network
settings on the DocuColor. The diagrams on pages 1-4 through 1-10 give chapter
references for Network Setup.
You’ll need a live network connection so the DocuColor can query the network for
zones, servers, and server-based queues.
Whenever the configuration of servers, printers, or the network itself changes at your
site, you can alter individual settings to correspond to the changed environment. Like-
wise, if printing needs or administrative requirements change, you can alter the corre-
sponding settings.
NOTE: Changing network or port settings may require that you make changes in more
than one Setup area.
Chapter 2:
Setting up the
DocuColor
2
2-2 Setting up the DocuColor
DocuColor Setup from the Control Panel
Setup, performed from the Control Panel right after powering on the DocuColor,
configures the DocuColor to communicate with other devices and manage print jobs
sent to it.
There are six groups of Setup options:
• Server Setup to specify system options
• Network Setup to specify all the active network systems that will transmit print jobs
to the DocuColor
• Printer Setup to specify the way print jobs and queues are managed on the color
server
•
PS Setup to specify PostScript options
• Color Setup to specify color printing parameters
• Job Log Setup to specify how the DocuColor handles its log of printed jobs
The Setup menus also allow you to calibrate the DocuColor, create and change an
administrator password, and clear the jobs queued on the server.
Accessing Setup options
The Control Panel on the front of the DocuColor enables y ou to set options and view
information about jobs printed to the DocuColor.
It comprises the following parts:
• Display window showing status information and options for setting up the
DocuColor
• Line selection buttons
• Up and down arrow buttons
• Menu button (escape)
• Activity light that indicates normal or problem activity
2
2-3 About DocuColor Setup
DocuColor Control Panel
The User Guide describes the online display screens in detail. This chapter describes
only the screens you might see when performing Setup.
TO ACCESS SETUP WHEN THE DOCUCOLOR IS AT IDLE:
1. When the DocuColor displays the Idle screen, press the Menu button on the Control
Panel to go to the Functions menu.
The Functions menu has two screens, as shown to the left.
2. Press the down arrow button to view the second screen of the Functions menu.
3. In the second screen, press the button to choose Reboot Server.
After automatic startup diagnostics, the DocuColor displays the entry screen.
Line selection buttons
DocuColor at Idle (ready);
message shown in display window
Up and down arrow buttons
Menu button
Activity light
Server Name
Idle
850 MB 1.0
Server Info
Print Pages
Suspend Printing
Resume Printing
Run Diagnostics
Functions
Reboot Server
Functions
2
2-4 Setting up the DocuColor
TO ACCESS SETUP WHEN THE DOCUCOLOR IS OFF:
1. Make sure the DocuColor is connected to the copier and connected to the network you
will use.
2. Turn on the DocuColor.
The startup diagnostics are performed.
3. At the startup message, press any button.
4. Continue with step 5 from the previous procedure.
Review the settings described in this chapter. F or more information on calibration, and
on Control Panel screens other than those in Setup, see the User Guide.
4. At the startup message, press any button.
The Start Up screen is displayed.
5. Choose Run Setup to access all setup menus.
The Install Software and Format Disk commands are for service technicians.
6. Press the line selection button to choose a Setup menu or command.
Press the down arrow to view the second and third screens of the main Setup
menu.
7. Choose setups in the same order as they appear in the menu: Server Setup, Network
Setup, Printer Setup, PS Setup, Color Setup, and then Job Log Setup.
The sequence is important for first-time Setup.
Later, just go directly to the menu you want to change. However, if you make
changes in Network Setup, y ou may need to change some settings in P rinter Setup
as well.
NOTE: If you make changes in Server, Network, or Printer Setup, you’ll need to
update the system configuration by opening and saving the other Setups even if
you haven’t changed any other settings.
For software
update or setup,
press any key.
Run Setup
Install Software
Format Disk
Start Up
Exit Setup
Server Setup
Network Setup
Printer Setup
Setup
PS Setup
Color Setup
Job Log Setup
Calibration
Setup
Change Password
Clear Server
Setup
