Xerox 7032 User Manual

7032 / 7033 User Manual

Table of Contents

Section 1 Installation and specifications Section 2 Getting started Section 3 Using the control panel Section 4 Performing basic operations Section 5 Setting up and using terminal features Section 6 Printing and using reports Section 7 Setting up the options Section 8 Maintaining your terminal Section 9 Solving problems
Index - A through L Index - M through Z
7032 / 7033 User Manual
1. Installation and Specifications 1-1
Meeting your terminal's site requirements 1-2 Space requirements 1-2 Physical characteristics of the terminal 1-4 Electrical requirements 1-4 Environmental requirements 1-5 Telephone requirements 1-5 Unpacking your terminal 1-6 Installing your terminal 1-9 Install the operator guide 1-9 Install the customer assistance label 1-9 Connect the telephone handset and line cord 1-10 Install output trays and load paper 1-10 Install the power cord 1-12 Verify terminal operation 1-12 Adjust handset ring volume 1-14 Knowing your terminal's specifications 1-15 Type 1-15 Telephone line required 1-15 Compatibility 1-15 Modem communication speeds 1-15 Copy speed 1-15 Resolution 1-16 Document size 1-16 Recording paper sizes 1-16 Automatic document feeder (ADF) 1-16 Scanning line density 1-17 Regulatory notices 1-18 United States data coupler user instructions 1-20 Canadian data coupler user instructions 1-20 United States radio noise emissions statement 1-22 Canadian radio noise emissions statement 1-22

1. Installation and Specifications

1. Installation and specifications
This chapter includes general information about your terminal and how to install the terminal.
Chapter 1 contains the following topics:
Meeting your terminal’s site requirements
- Space
- Physical
- Electrical
- Environmental
- Telephone
Unpacking your terminal
Installing your terminal
Knowing your terminal’s specifications
Regulatory notices
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 1-1
INSTALLATION AND SPECIFICATIONS
aaaaaaaaa
Meeting your terminal’s site requirements
The following items must be considered in determining an appropriate site for the terminal.
Space requirements
Figure 1-1 and Figure 1-2 (front and top terminal views) show the minimum space requirements around the terminal as needed for normal operator functions and routine service maintenance functions. These requirements are the same for one or two paper tray units.
Figure 1-1. Space requirements (front view)
24” (609 mm)
Minimum 18” (457 mm) Maximum 36” (914 mm)
1-2 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
50” (1270 mm)
INSTALLATION AND SPECIFICATIONS
Figure 1-2. Space requirements (top view)
5” (127 mm)
8” (203 mm)
10” (254
mm)
24” (609 mm)
52” (1320 mm)
Floor space required: 50 x 52 inches (1270 x 1320 mm)
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 1-3
INSTALLATION AND SPECIFICATIONS
Physical characteristics of the terminal
Dimensions
One-tray version
20.8 in (w) x 21.2 in (d) x 17.3 in (h) 530 mm (w) x 540 mm (d) x 439.5 (h)
Two-tray version
20.8 in (w) x 21.2 in (d) x 21.5 in (h) 530 mm (w) x 540 mm (d) x 544.5 (h)
Weight
One-tray version
57 lbs (25.7 kg) unpackaged 74 lbs (33.4 kg) packaged
Two-tray version
9.4 lbs (42.6 kg) unpackaged
Electrical requirements
A standard two-pole, three-wire grounded receptacle is required within 5 feet (1.5 meters) of the terminal.
1-4 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
Voltage
The power line should be single phase (2 wires plus ground) with a 60 Hz cycle and a voltage between 104 to 127 VAC (nominal 120 VAC). Standby power consumption is less than 65 watts. The line should support a maximum power consumption of 230 watts during operation.
NOTE: For the European market, the power line should have a 50 Hz cycle and a voltage between 200 to 240 VAC.
Environmental requirements
Temperature
60°F to 90°F (15°C to 32°C)
Humidity
INSTALLATION AND SPECIFICATIONS
15% to 85% without condensation
Elevation
To 9,900 ft. (3,000 meters) above sea level
Heat dissipation
Operating . . . 785 BTU/hr
Standby . . . . . 221 BTU/hr
Telephone requirements
Terminal connecting jack must be within 5 feet (1.5 meters) of the terminal.
NOTE: This distance may vary in the European market.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 1-5
INSTALLATION AND SPECIFICATIONS
Unpacking your terminal
In some locations, the delivery company sets up the terminal and ensures it is operational. In these cases, proceed to Chapter 2, “Getting Started.“
Do the following to unpack your terminal:
1. Cut around the bottom of the shipping
carton. Refer to the directions on the carton.
2. Lift the top portion of the shipping carton
off of the terminal.
3. Remove the accessory items (Figure 1-3 on
the following page). a. Remove the accessory bag. The bag
includes the following items.
• Job reserve cards (1 package)
• Customer assistance labels (North American market only)
• Operator guide
• Clean-ups
b. Remove the bag containing the power
cord and the telephone line cord.
c. Remove the package of paper,
document output tray, and copy output tray.
d. If included, remove the telephone
handset kit.
e. Remove the left and right top end caps.
CAUTION
One person should not attempt to lift the terminal. To avoid injury, a second person should assist when placing the terminal in position.
1-6 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
INSTALLATION AND SPECIFICATIONS
aaaaaaaaa aaaaaaaaa aaaaaaaaa aaaaaaaaa
aaaaaaaaaaaaaaa aaaaaaaaaaaaaaa aaaaaaaaaaaaaaa aaaaaaaaaaaaaaa aaaaaaaaaaaaaaa aaaaaaaaaaaaaaa aaaaaaaaaaaaaaa aaaaaaaaaaaaaaa aaaaaaaaaaaaaaa
aaaaaaa
a
aaaaaaa
a
aaaaaaa
a
aaaaaaa
a
aaaaaaa
a
aaaaaaa
a
aaaaaaa
a
aaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
Figure 1-3. Shipping Carton Contents
Bag with telephone line cord and power cord
Handset in box (USO)
End cap
Terminal
Bag with operator guide, job cards, misc.
End cap
Bag with output trays
Bottom of carton
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 1-7
INSTALLATION AND SPECIFICATIONS
4. Set up the terminal. a. Using the left and right sides as lifting
points, lift the terminal from the bottom of the carton.
b. Position the terminal in the designated
location. (refer to
terminal’s site requirements
guidelines on site selection).
NOTE: The table/stand for the terminal must be capable of supporting 75 pounds and meet the space requirements. A stand is available as an option from Xerox.
5. Remove shipping material. a. Remove all tape from external covers. b. Remove protective film from control
panel.
c. Open printer cover and remove any
packing material from rollers.
6. Refer to next page for additional instructions on terminal setup and installation.
Meeting your
Installing your terminal
for
on the
1-8 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
INSTALLATION AND SPECIFICATIONS
Installing your terminal
If you have purchased an option for the terminal (other than the stand), a customer service representative will install the option(s). If you have not purchased an option, follow the directions below to assemble the terminal and check its operation.
Install the operator guide
1. Remove the operator guide from the accessory bag.
2. Slide the guide into the holder located below the paper tray.
Install the customer assistance label
1. Record the serial number and customer assistance telephone number on the customer assistance label.
a. Copy the serial number from the plate
located under the donor film cartridge near the rear frame.
2. Record the serial number in Chapter 9 of this handbook, in the section titled
Requesting Assistance.
3. Install the customer assistance label. a. Remove the protective cover backing
and carefully position the cover over the label.
b. Place the label on the control panel
base.
European market only:
Record all necessary details required by your organization.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 1-9
INSTALLATION AND SPECIFICATIONS
Connect the telephone handset and line cord
NOTE: These steps only apply when a handset is included.
1. Install the telephone handset. a. Remove the handset from the box and
place the handset on the cradle.
b. Insert the end of the telephone handset
cord into the modular jack marked TEL on the terminal rear cover.
2. Install the telephone line cord. a. Insert one end of the telephone line
cord into the modular jack marked LINE on the terminal rear cover.
b. Insert the other end of the cord into the
modular jack at the telephone wall jack.
3. Verify telephone operation. a. Lift handset and listen for a dial tone. b. If no dial tone is heard, check the
connections. If checking the connections does not resolve the problem, call customer assistance (refer
Requesting assistance
to
c. Place the handset on the cradle.
in Chapter 9).
Install output trays and load paper
1. Install the document output tray (Figure 1-
4). a. Position the document output tray in
the upper slot of the left side cover.
b. Rotate the tray fastener one-quarter
turn counterclockwise to secure the tray in position.
1-10 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
2. Install the copy output tray by sliding the copy output tray into the lower slot of the left side cover. Bias the tray down slightly while sliding it in to secure the front and rear edges (Figure 1-4).
Tray fastener (Rotate 1/4 turn counterclockwise)
INSTALLATION AND SPECIFICATIONS
3. Load paper in the paper tray. a. Slide out the paper tray. b. Press down to latch the metal tray. c. Insert paper between metal guides up to
fill line. If necessary, adjust the paper length block.
d. Close tray.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 1-11
INSTALLATION AND SPECIFICATIONS
Install the power cord
1. Locate and install the power cord. a. Plug one end of the power cord into the
receptacle at the right rear corner.
b. Verify polarity of the AC wall outlet,
then plug the other end of the power cord into the wall outlet.
2. Verify power. Approximately 10 seconds after connecting the power cord, the display indicates:
00:00 ENTER TERMINAL ID/NAME 0-
If this is not displayed, call customer assistance (refer to Chapter 9).
Verify terminal operation
LOAD ORIGINALS FACE DOWN
Requesting assistance
in
1. Perform self test diagnostics. a. Lower the control panel door on the
lower portion of the control panel and press [Diagnostics].
b. Press [Select] until Self Test flashes; then
press [Enter].
c. If an error code is displayed during the
test, record the error code, then press [Start] to continue the test.
d. At the end of diagnostics, a test pattern
prints and the display indicates:
REPORT COMPLETE
e. Close the control panel door.
1-12 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
INSTALLATION AND SPECIFICATIONS
2. Evaluate the diagnostic operation. a. If an error code was displayed during
self test, call customer assistance (refer
Requesting assistance
to
in Chapter 9).
3. Perform a copy operation. a. Place a document face down, with the
lead edge to the left, into the automatic document feeder (ADF). Refer to
Getting started
in Chapter 2 for ADF
location.
b. Adjust the document guides to the
width of the document. This display indicates:
SELECT FEATURES THEN DIAL OR
RESERVE JOB
OR PRESS [COPY]
c. Press [Copy]; then press [Start]. d. The terminal prints a copy. When the
copy operation is complete, a tone sounds and the terminal returns to idle mode after 5 seconds.
e. Compare the copy with the original. If
they compare, the scanner and printer are functioning correctly. If there are quality problems, call customer assistance (refer to
assistance
in Chapter 9).
Requesting
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 1-13
INSTALLATION AND SPECIFICATIONS
aaaaaaaaaaa aaaaaaaaaaa aaaaaaaaaaa aaaaaaaaaaa
Adjust handset ring volume
1. If the ring volume of the handset is not satisfactory, perform the following adjustment:
a. Locate the volume adjustor on the side
of the handset, as shown below in Figure 1-4:
Figure 1-4. Handset ring volume
b. Move the adjustor to the left or right, as
desired. The far left setting (under the largest part of the triangle) is the loudest and the far right setting is the softest.
adjustor
adjustor
louder
1-14 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
INSTALLATION AND SPECIFICATIONS
Knowing your terminal’s specifications
Type
Desktop facsimile terminal
Telephone line required
Public switched telephone network
Compatibility
CCITT Group 2 and Group 3
Modem communication speeds (Group 3)
7033 and 7032 with Trellis modem option
14.4 Kbps, 12.0 Kbps, 9600 bps, 7200 bps, 4800
bps, or 2400 bps
7032 (base)
9600 bps, 7200 bps, 4800 bps, or 2400 bps
Copy speed
Single copy (A4/letter size original)
Approximately 22 seconds
Multiple copy - First page (A4/letter size orig.) Approximately 22 seconds
Multiple copy - Subsequent pages (A4/letter size original) Approximately 11 seconds
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 1-15
INSTALLATION AND SPECIFICATIONS
Resolution
G3 . . . . . . . . . . . . Superfine, Fine, and Standard
G2 . . . . . . . . . . . . . . . . . . . . . . . . . . . Standard only
Document size
Maximum width: . . 11.7 in (297 mm) Minimum width: . . . 4.1 in (105 mm) Maximum length: . . 18.11 in (460 mm) Minimum length: . . 4.5 in (114.3mm)
Thickness: . . . . . . . . . 0.0028 in (0.07 mm) to
Weight: . . . . . . . . . . . 13 to 36 pound bond (45
Recording paper sizes
0.0075 (0.19mm)
grams/sq m to 127.9 grams/ sq m basis weight)
8.5 in (215.9 mm) x 11 in (279.4 mm)
8.5 in (215.9 mm) x 14 in (355.6 mm) A4 - 8.3 in (210 mm) x 11.7 in (297 mm) (European
market only) B4 - 10.1 in (257 mm) x 14.3 in (364 mm)
(European market only)
Automatic document feeder (ADF)
Up to 50 letter size Up to 30 legal size Mixed-weight stacks of more than 30 documents
should include a maximum of four 32 or 36 pound documents.
NOTE: Using heavy weight documents reduces the ADF capacity.
1-16 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
Scanning line density
Horizontal
A3 (European
market) . . . . . . . . . . . . 3507 pels/297 mm ± 1%
B4 (North American
market) . . . . . . . . . . . . 3023 pels/256 mm ± 1%
Vertical
G3 (Super fine) . . . . . . 15.4 lines per mm ± 1%
. . . . . . . . . . . . . . . . . . . (391.2 lines/inch ± 1%)
G3 (Fine) . . . . . . . . . . . 7.7 lines per mm ± 1%
. . . . . . . . . . . . . . . . . . . (195.6 lines/inch ± 1%)
G2/G3 (Standard) . . . 3.85 lines per mm ± 1%
. . . . . . . . . . . . . . . . . . . (97.8 lines/inch ± 1%)
INSTALLATION AND SPECIFICATIONS
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 1-17
INSTALLATION AND SPECIFICATIONS
Regulatory notices
United States data coupler user instructions
This facsimile terminal contains an internal data coupler. Its use is restricted by the FCC (Federal Communications Commission). To comply with the FCC rules, you must carefully read and follow the instructions listed below:
1. If requested, you must give the telephone company the following information:
- The telephone number connected to this
terminal.
- The FCC registration number for the
terminal: AQX63C-19885-DP-E
- The ringer equivalence of the terminal:
0.5 B.
NOTE: The registration number is issued by the FCC, under part 68 of its Rules and Regulations, for direct connection to a telephone line. The number is printed on the rear of the terminal.
WARNING
Ask your local telephone company for the modular jack type installed on your line. Connecting this terminal to an unauthorized jack can severely damage telephone company equipment. You, not Xerox, assume all responsibility and/or liability for any damage caused by the connection of this terminal to an unauthorized jack.
1-18 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
INSTALLATION AND SPECIFICATIONS
2. You may safely connect the terminal to a USOC RJ11C modular jack
. Use the standard line cord (with modular plugs) provided with the installation kit to connect it.
Do not connect this terminal to a party or coin operated phone line.
3. Repairs to the terminal should only be made by Xerox or an authorized Xerox service agency. This applies at any time during or after the service warranty period. If unauthorized repair is performed, the remainder of the warranty period is null and void.
4. If you find the telephone line is damaged or the telephone company notifies you that your terminal is causing damage, disconnect the terminal from the telephone line and call for service. Do not reconnect the terminal until necessary repairs are made.
5. The telephone company will, where practical, notify you when they need to temporarily disconnect service. However, if action is reasonable and necessary, but prior notice is not practical, they may still temporarily disconnect your service. In such cases they must:
- Immediately notify you of their temporary
action.
- Reconnect service when the source of
damage is removed.
- Inform you of your rights to bring a
complaint to the FCC under FCC rules.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 1-19
INSTALLATION AND SPECIFICATIONS
6. The telephone company may make changes to its communications facilities, equipment, operations, or procedures. Such action must be reasonable, required in the operation of their business, and consistent with FCC rules. They must give you prior written notification if the changes can:
- Make your terminal incompatible with
their equipment.
- Require modification or alteration of the
terminal.
- Otherwise physically affect performance
of the terminal.
Canadian data coupler user instructions
Notice
The Canadian Department of Communications label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the company’s inside wiring associated with a single line individual service may be extended by means of a certified connector assembly (telephone extension cord). The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.
1-20 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
INSTALLATION AND SPECIFICATIONS
Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier. Any repairs or alterations made by the user to this equipment or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.
CAUTION
Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.
The Load Number assigned to each terminal device denotes the percentage of the total load to be connected to a telephone loop which is used by the device to prevent overloading. The termination on a loop may consist of any combination of devices subject only to the requirement that the total of the Load Number of all the devices does not exceed 100.
DOC Registration
The terminal contains an internal data coupler. Its use is restricted by the DOC (Department of Communications).
Registered Permissive Mode Type
Certificate number: CS03-5933
Certification number: 482 3386A
DOC Load number: 13
Interface options
The terminal may be connected to the following standard modular jack: RJ11C.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 1-21
INSTALLATION AND SPECIFICATIONS
United States radio noise emissions statement
Class A notice
WARNING
This terminal generates radio frequency energy. It complies with Class A computing device limits defined in Sub-part J of Part 15 of FCC Rules. Those rules provide reasonable protection in a commercial environment against interference with radio communications. If this terminal is not installed or used as instructed in this manual, it may cause interference.
Operation of this equipment in a residential area may also cause radio or television interference. In this case you, at your own expense, will be required to correct the interference. An FCC booklet, ”HOW TO IDENTIFY AND RESOLVE RADIO-TV INTERFERENCE PROBLEMS” (stock number 004-000-00345-4) is available from the U.S. Government Printing Office, Washington, D.C., 20402.
Canadian radio noise emissions statement
Class A notice
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
For any additional information contact: Xerox Canada Inc. 5650 Yonge Street North York, Ontario M2M 4GF
1-22 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
2. Getting Started 2-1
Terminal overview 2-2 Major features of your terminal 2-4 7032/7033 features 2-4 7032/7033 differences 2-5 Basic operations to get started 2-6 Optional features 2-7
14.4 Kbps Trellis modem 2-7 Auxiliary paper tray 2-7 Encryption interface 2-7 Handset (European market only) 2-8 Hard disk drive 2-8 Memory upgrade 2-8 RS-232 (Serial computer interface) 2-8 Stand 2-9

2. Getting Started

http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7033/USER/chp2.htm [28/09/1999 10:28:06]
2. Getting started
Now that the terminal is installed, you need to become familiar with the features of your terminal and available options. This chapter provides an overview of the terminal’s features.
Chapter 2 includes the following topics:
Terminal overview
Major features of the terminal
Basic operations to get started
Optional features
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 2-1
GETTING STARTED
Handset (Optional in European market)
Control panel
Automatic document feeder (ADF)
Paper tray
Copy output tray
Document output tray
Terminal overview
Figure 2-1 shows a tabletop facsimile terminal designed to provide easy access to a multitude of features.
Figure 2-1. 7032 / 7033 Terminal
2-2 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
GETTING STARTED
Beginning with the control panel and continuing clockwise around Figure 2-1, the illustrated components and their functions are:
The control panel serves the following functions:
- Displays available memory
- Displays available terminal functions
- Contains status and indicator functions
- Contains a display to provide information, prompts, and error messages to the operator.
- Provides access to the numerous terminal features
Place documents face down in the automatic document feeder (ADF) for copying, transmitting, and storing to memory. The ADF has adjustable guides, called document guides, on each side which can be moved to accommodate various paper sizes.
The paper tray holds the paper used to print received or copied documents.
The copy output tray serves as a receptacle for printed documents (copied or received).
The document output tray serves as a receptacle for the original documents fed through the automatic document feeder. It has an extender that can be pulled out if the original document is legal size.
The handset (standard for the North American market, optional for the European market) serves as a telephone handset for regular telephone service and voice contact with a remote operator for a facsimile operation.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 2-3
GETTING STARTED
Major features of your terminal
This section discusses the major features that the 7032 and 7033 have in common, and the differences between the 7032 and 7033.
7032 / 7033 features
In addition to the basic operations of send, receive, and copy, the terminal supports the following additional features:
Use of plain paper provides convenience and increased productivity
One 300-sheet paper tray with an optional 300-sheet auxiliary paper tray
High-speed transmission
Security
- Confidential mailbox
- PIN access
- Junk mail elimination
Digital copying
Use of Xerox High Definition Imaging Process
Time-saving features, such as speed dialing
Ease of operation
- 2-line by 40-character display that provides
easily understood prompts and messages to guide you through any operation
- Pull-out operator guide
2-4 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
7032 / 7033 differences
There is a difference in some features between the 7032 and the 7033. Those differences in features are listed below:
Dual access that allows simultaneous occurrence of more than one operation, such as receiving a document and copying a document is standard on a 7033, and optional on the 7032.
The Trellis modem is standard on the 7033, and optional on the 7032.
The standard memory on the 7032 is 15 pages with ECM turned off and 5 to 10 pages with ECM on. The standard memory on the 7033 is 55 pages.
GETTING STARTED
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 2-5
GETTING STARTED
Basic operations to get started
Table 2-1 below includes some basic operations that you may want to do when you first begin using your terminal, and shows a reference page indicating where the directions for each operation can be found.
Table 2-1. Beginning basic operations
If you want to perform this
operation:
Go to page:
Assigning a local terminal ID 5-61 Setting the time and date 5-114 Sending a document 4-17 Making a copy 4-10 Enabling received/transmitted
5-95
headers Setting up the dial directory 5-24
2-6 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
Optional features
The terminal also supports several optional features. Any of the optional features must be installed by your Xerox service representative, except for the stand.
14.4 Kbps Trellis modem
The high-speed 14400 bit per second Trellis modem is standard on the 7033 terminal and optional for the 7032 terminal. With the higher resolutions of the 7032 / 7033 terminals, this modem offers the optimum transmission speed.
Auxiliary paper tray
One paper cassette comes as part of the terminal. An additional auxiliary paper cassette is available as an option. It is interchangeable with the cassette that comes with the terminal, i.e., it holds the same amount of paper, and accommodates the same paper sizes and weights.
GETTING STARTED
NOTE: This option is required if you purchase the Hard Disk Drive option.
Encryption interface
The Encryption Interface option, required for connection to an encryptor (not supplied by Xerox), provides protection against unauthorized access or alteration of data during transmission. If an encryption device is installed, communications are only possible with units having the same type of encryptor and same encoded key. Normal machine operations apply.
You should only use encryption in a G3 communication environment. The G2 operations should be disabled.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 2-7
GETTING STARTED
Handset (European market only)
A handset is not included as part of the European market configuration base terminal. However, a handset is available as an option in some countries.
Hard disk drive
If more memory is required than available in the memory upgrade options, a 30 megabyte hard disk is available.
NOTE: The auxiliary paper tray option is required if you purchase this option. In the 7032, the 1 megabyte or 3 megabyte memory upgrade is also required.
Memory upgrade
One of the following two memory upgrade options is available:
1 megabyte plug-in board
3 megabyte plug-in board
RS-232 (Serial computer interface)
The RS-232 Computer Interface option provides an alternate input to and output from your terminal.
It provides an alternate input, from the host processor through the computer interface, to the terminal for the following:
To locally print facsimile data or character­coded (ASCII) data.
To send facsimile data or character-coded (ASCII) data to a remote facsimile machine.
2-8 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
Stand
GETTING STARTED
The interface also serves as an alternate output from the terminal for the following:
To record remotely generated facsimile data through the computer interface to the host processor.
To record locally scanned facsimile data through the computer interface to the host processor.
The stand provides a convenient location to place the terminal and to store supplies and the User Handbook.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 2-9
GETTING STARTED
2-10 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
3. Using the Control Panel 3-1
Display 3-2 Liquid crystal display (LCD) 3-2 Using control panel buttons in response to operator prompts 3-3 LED indicators 3-4 Memory available 3-4 Operations being performed (dual access) 3-5 Status indicators 3-7 Upper/lower case 3-10 Additional upper control panel functions 3-11 Using the lower control panel buttons 3-12 Functional variation 3-12 Lower control panel functions 3-12 Idle mode 3-16 Program mode 3-17 To enter program mode 3-17 Time-out on display 3-17 To exit program mode 3-18 Terminal tones and alarms 3-19 Procedure completion alarm 3-19 Voice request tones 3-19 Operator alert and fall back alarm 3-20 Invalid input alarm 3-20 Control button (keypad) tone 3-20

3. Using the Control Panel

http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7033/USER/chp3.htm [28/09/1999 10:28:21]
3. Using the control
panel
Before using the features of the terminal, you should become familiar with control panel use.
Chapter 3 contains information about the following topics:
Control panel display
LED indicators
Upper control panel functions
Lower control panel functions
Idle and program modes
Terminal tones and alarms
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 3-1
USING THE CONTROL PANEL
aaaaaaaaaaaaaaaaaaaaa
a
a
a
Display
Liquid crystal display (LCD)
Figure 3-1 shows the control panel location of the Liquid Crystal Display (LCD), consisting of two lines with 40 characters each.
Figure 3-1. LCD Location
LCD Display
aaaaaaaaaaaaaaaaaaa
a
Control Panel
The LCD provides an area to display the following:
Operator prompts - Brief messages to aid you in executing a procedure.
Error messages - Brief messages to provide information about operational errors or faults.
Fault codes - Four-digit codes that accompany the error messages.
3-2 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
USING THE CONTROL PANEL
Using control panel buttons in response to operator prompts
As noted previously, one of the functions of the LCD is to display operator prompts to aid you in executing a procedure. The prompts often include directions to press the buttons listed in the table below.
Table 3-1. Control Panel Functions (Execution)
Control Panel
Button
Start Initiates operations, such as copy, send, and job
reserve.
Stop • If a job is active on display, aborts that job.
• If a job not currently statused on display, aborts the current programming procedure.
Select During program mode*, moves the cursor from
one displayed feature to another.
Enter During program mode*, causes feature
selections or input data to be stored and moves programming to next level, if that exists.
Clear • When entering data, deletes the character in
the current cursor position.
• If not entering data and a document present in the automatic document feeder, ejects the document or job card.
Exit During program mode*, terminates the current
segment or entire programming sequence. Depending on the point where [Exit] was pressed, entries made up to that point in the programming may or may not be stored.
Function
* Refer to
regarding program mode.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 3-3
Program Mode
in this chapter for information
USING THE CONTROL PANEL
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
LED indicators
The control panel contains LEDs that indicate:
Memory available
Operations being performed
Status of certain feature selections
Selection of upper or lower case
Memory available
This indicator, shown in Figure 3-2, provides a relative percentage of available memory.
Figure 3-2. Location of Memory Available
Indicator
3-4 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
100%10%
MEMORY AVAILABLE
Control Panel
The indicator consists of ten LEDs, representing 10% to 100%, to show the operator the amount of available memory. Since this indicator is continuously updated, the amount shown is the current amount of available memory. This indicator functions like a gas gauge; as memory is used, the LEDs turn off.
USING THE CONTROL PANEL
aaaaa aaaaa aaaaa
aaaaa aaaaa aaaaa aaaaa
aaaaa aaaaa aaaaa
aaaaa aaaaa aaaaa
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaa
a
aaa
a
aaa
a
aaaaa aaaaa aaaaa
Operations being performed (dual access)
This indicator shows the operator the availability of the printer, scanner, and telephone line.
Figure 3-3. Location of indicator
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 3-5
Control Panel
USING THE CONTROL PANEL
This indicator aids the operator in using the dual access feature, which allows two operations to run simultaneously. The combinations of operations allowed vary depending on the current terminal status. For example, if the terminal is receiving to memory, the scanner and printer are available to make a copy.
If the machine is active on a current job, only the functions of the first five buttons under the control panel door, ([Brief Message] through [Long Original]), [Directory Setup], [Pending Job Delete/View], and [Store for Polling] are available. If an operation is requested that cannot be performed, an invalid alarm will sound.
NOTE: If two operations are running simultaneously, there may be an increase in normal operating time.
The arrows indicate to the operator the terminal functions that are in use. Table 3-2 below lists which arrows indicate specific functions.
Table 3-2. Arrow function indicator
Function
Indicated by
Arrows:
Printing from memory 1 Copying 1 and 2 Receiving to memory 3 and 4 Sending from memory 3 and 4 Receiving to printer 1, 3, and 4 Sending from scanner 2, 3, and 4
3-6 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
USING THE CONTROL PANEL
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
Status indicators
Several LEDs indicate the status of various features. Figure 3-4 shows the location of these LEDs on the Control Panel. Refer to Table 3-3 for a summary of the selections.
Figure 3-4. Location of Status Indicators
Original Document Resolution Special Features
Contrast Halftone
Dark
Light
Picture+ Text
Superfine
Fine
Job Reserve
Mailbox/Relay
Enlargement
Reduction
Normal
Standard
Control Panel
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 3-7
USING THE CONTROL PANEL
Table 3-3. Function of Status Indicators
LED Group LED Selection Description
Original Document (Contrast) *
Original Document (Halftone)
Dark Select the Dark text setting for
transmission or copy of a document which has higher image densities with little contrast to background density areas.
Light Select the Light text setting for
transmission or copy of a document which has lower than normal image to background density variation.
Normal Select the Light text setting for
transmission or copy of a document which has normal image to background density variation.
Picture+Text Select this for transmission or
copy when neither graphics nor text image is optimum. Provides better representation of text than picture setting. Provides better graphics representation than text contrast settings.
Picture Select for transmission or copy of
a document containing shades of gray, such as a photograph. Provides the best graphics representation.
* The text contrast settings and halftone settings are mutually
exclusive; i.e., text contrast settings are not applicable when you make a halftone selection, and vice versa.
3-8 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
USING THE CONTROL PANEL
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaaaaaaaaaa
a
Upper/lower case
The upper/lower case LEDs, shown in Figure 3-5, indicate the following:
When the control panel door is closed:
- Upper case allows selection of one-touch
- Lower case allows selection of one-touch
When the control panel door is open:
- Upper case indicates the button functions
- Lower case indicates the character shown
dial buttons (assigned numbers 1-29).
dial buttons (assigned numbers 30-58).
as a feature selection button.
below the button is to be entered during programming.
3-10 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
Refer to
Using the lower control panel buttons
this chapter for additional details. Figure 3-5. Location of Upper/Lower Case LED
Upper Case
Lower Case
Control Panel
in
USING THE CONTROL PANEL
Additional upper control panel functions
Refer to Table 3-4 for functions of the remaining buttons on the upper half of the control panel.
Table 3-4. Additional Upper Control Panel
Functions
Control Panel
Button
Function
Job Status Indicates status of foreground or background
operations for dual access feature of 7033 and 7032 with additional memory.
Copy Allows selection of paper tray (if auxiliary paper
tray option installed) and selection of
enlargement/reduction sizes for copying. Poll/Man Rcv Poll/Manual answer mode Telephone
Keypad (0-9, *, #)
Use to:
• Manually enter a telephone number to send or poll a document.
• Enter numbers (such as telephone numbers, date, time, or number of copies) during data entry while programming features or during job setup.
Speed Dial Allows entry of a pre-assigned 3-digit auto dial
number (assigned for a remote terminal).
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 3-11
USING THE CONTROL PANEL
Control Panel
Button
Pause Use to:
• Define a wait period between digits during the automatic dialing of a telephone number. Press [Pause] at desired wait period location during programming of telephone number. More than one pause can be inserted.
• Prior to one-touch/speed dial activation, deactivates the 1 second automatic start procedure for send operations.
• When manually dialing and the terminal is set for pulse dial, [Pause] selects DTMF (tone) dialing and the display indicates tone. This is used for remote devices that require tone dialing input.
Function
3-12 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
USING THE CONTROL PANEL
Using the lower control panel buttons
Functional variation
The buttons on the lower half of the control panel serve different purposes depending on whether the control panel door is closed or open.
Control panel door closed
You can assign two one-touch destinations to each button on the lower portion of the control panel, except the Upper/Lower Case button. When the control panel door is closed, the button allows selection between the two possible one­touch destinations assigned to each button.
Control panel door open
When the control panel door is open, you can select the function listed above the button.
When data entry is required during programming for a function button, press the button with the desired character listed below it. If two characters are listed below the button, such as A and !, the button selects the character on the left; use of the Special Character button allows selection of the character on the right. Upper and lower case characters are available by pressing the Upper/Lower Case button (LED indicates current selection).
Lower control panel functions
Refer to Table 3-5 on the following pages for the functions of the lower control panel buttons during program mode (control panel door open). The buttons are listed from left to right on the control panel, beginning with the top row of this portion.
3-12 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
USING THE CONTROL PANEL
Table 3-5. Lower Control Panel Functions
Control Panel
Button
Function
Brief Message Select a preprogrammed message by number
for the send header. Delayed Start Select and set up a delayed start operation. Voice Request Select a voice request operation. Options for
voice request include pre-job, page end, or job
end. Communication Select the communication mode (ECM, 4800
BPS, or 14400 BPS) (14400 BPS is not applicable
to 7032 base terminal. Long Original Select ON for documents longer than 24“. Activity Report Select manual printing of an activity report for
all terminal activity or individual report if in By
Account mode. Pending Job
Report Job Reserve
Prints a report on current memory status and
pending jobs, including redials.
Prints a report on job reserve recorded data. Report
Dial Directory Report
Prints a report of phone number(s) in the dial
directory. System Reports Select user account/mailbox or options report.
Also, select master journal report in By
Account mode. Terminal
Options
Contains data input menus for selecting user
access, user account, copy inhibit, receive to
memory, print from memory, hard disk
reformat, junk mail elimination, out-of-paper
receive to memory, memory reallocation. Time & Date Enter date and time; includes selection of 12
or 24 hour clock.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 3-13
USING THE CONTROL PANEL
Idle mode
When the terminal is plugged in, it is in idle mode. Following the successful completion of an operation or when an operation is not pending, the terminal returns to idle mode.
Depending on such circumstances as whether a document is in the automatic document feeder, the idle mode display differs. An example of an idle mode display is:
NOTE: In the North American market, the date display format is MM-DD-YY. In the European market, the date display format is DD-MM-YY.
LOAD ORIGINALS FACE DOWN 10:25 AM 1-15-90
Most idle displays provide information regarding loading originals, loading job reserves, copying, or printing from memory.
NOTE: When the terminal is first plugged in, the following is displayed in the idle mode:
LOAD ORIGINALS FACE DOWN 00:00 ENTER TERMINAL ID/NAME 0-
The ENTER TERMINAL ID / NAME portion of the display disappears after you assign the terminal ID and local name. Refer to Local terminal ID in Chapter 5 for directions on assigning the terminal ID. Refer to Local terminal name in Chapter 5 for directions on assigning the local name.
3-16 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
Program mode
The buttons on the bottom half of the control panel serve two functions:
One-touch dial buttons
Selection of options/features for the terminal To use the buttons for option/feature selection,
the terminal must be in program mode.
To enter program mode
1. Open the control panel door. The following is displayed:
PRESS APPROPRIATE BUTTON(S) TO MAKE SELECTIONS
USING THE CONTROL PANEL
2. Press the desired feature button. Refer to Chapters 4-7 in this manual for details on use of these features.
Time-out on display
When the terminal enters program mode (control panel door open or feature programming completed), the following is displayed:
PRESS APPROPRIATE BUTTON(S) TO MAKE SELECTIONS
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 3-17
USING THE CONTROL PANEL
If no further activity is detected by the terminal within one minute following the appearance of the previous display, the following is displayed:
At this point, the terminal is still in program mode.
If you wish to select another feature, press the appropriate feature button.
If you do not want to select another feature at this time, close the control panel door. The terminal returns to idle mode.
To exit program mode
1. One of the following must be displayed:
PRESS APPROPRIATE BUTTON(S) TO MAKE SELECTIONS
CLOSE CONTROL PANEL DOOR
or
CLOSE CONTROL PANEL DOOR
10:25 AM 1-
15-90
2. Close the control panel door.
3-18 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
Terminal tones and alarms
The terminal utilizes the following five audible tones and alarms to indicate various conditions:
Procedure completion alarm
Voice request tones
Operator alert and fall back alarm
Invalid input alarm
Control button (key pad) tone
Procedure completion alarm
A tone sounds to indicate completion of facsimile or copying operation based on the following:
If the procedure is successful, the tone sounds for approximately 1 second.
USING THE CONTROL PANEL
If the procedure is not successful, the tone sounds for 3 - 5 seconds. The tone may be accompanied by a visual fault indication, such as an error message on the display.
Voice request tones
A continuous pattern of three short tones followed by a pause indicates the remote operator wants to establish voice contact.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 3-19
USING THE CONTROL PANEL
Operator alert and fall back alarm
An intermittent tone indicates the terminal requires operator attention.
Invalid input alarm
Two short tones indicate that the action has not been accepted when a control panel button is pushed.
Control button (keypad) tone
If enabled by the operator, this short tone sounds when a control panel button is pressed.
3-20 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
4. Performing Basic Operations 4-1
Dialing 4-2 To manually dial 4-3 To dial with one-touch dialing 4-3 To dial with speed dialing 4-4 To dial permanent dial groups 4-5 Interactive dialing 4-7 Using a pause 4-7 Redialing 4-9 Making copies 4-10 To make copies 4-10 Polling a remote terminal 4-13 Receiving a document 4-15 To automatically receive a document 4-15 To manually receive a document 4-16 Sending a document 4-17 Sending a document to one location 4-17 Sending a document to multiple locations 4-19

4. Performing Basic Operations

http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7033/USER/chp4.htm [28/09/1999 10:28:43]
4. Performing basic
operations
This chapter begins with an overview for the dialing options available with this terminal. The chapter also contains directions for basic terminal operations (refer to Chapter 5 for additional enhancements to the basic operations).
Refer to Table 4-1 below for specific chapter contents.
Table 4-1. Chapter 4 contents
Chapter Section Description Page
Dialing Directions for manual, one-touch,
and speed dialing; directions for adding a pause; and redial information.
Making copies Directions for making single or
multiple copies.
Polling a remote terminal
Receiving a document
Sending a document
Directions for polling operation. 4-13
Directions for manually or automatically receiving a document.
Directions for sending a document. 4-17
4-2
4-10
4-15
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 4-1
PERFORMING BASIC OPERATIONS
Dialing
There are four different methods for dialing telephone numbers:
Manual dialing
Interactive dialing
Speed dialing
One-touch dialing
manual dialing,
With number by using the keypad on the control panel or other attached telephone. A maximum of 128 digits can be entered using this method.
Interactive dialing
they are pressed on the telephone keypad of the terminal. This feature is used when dialing remote devices that require tone commands such as Xerox FaxMaster or telephone messaging services.
Up to 150 numbers can be stored in the dial directory. With one of these 150 telephone numbers Speed Dial button and entering the 3-digit code.
Even though numbers 001 through 150 can be used for speed dialing, you can use numbers 001 through 058 for the one-touch dialing. With
touch dialing,
by using the One-touch keys. located on the bottom portion of the control panel.
Refer to directions on assigning the telephone numbers in the dial directory.
you can dial the telephone number
Directory Setup
you can dial the telephone
allows digits to be dialed as
speed dialing,
you can dial any
by using the
in Chapter 5 for
one-
4-2 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
To manually dial
PERFORMING BASIC OPERATIONS
1. Place the document face down in the automatic document feeder. The following is displayed:
SELECT FEATURES THEN DIAL OR RESERVE JOB OR PRESS [COPY]
2. Enter the desired telephone number using the telephone keypad. As you enter the number, the following is displayed:
NOTE: With this procedure, the number is not dialed until all digits are entered and the terminal has started. Pauses may be required for proper dialing sequence. Refer to “Using a pause“ on page 4-7.
>(numbers appear here as entered) DIAL NUMBER THEN PRESS
3. After entering the number, press [Start]. The terminal scans the document into
memory, automatically dials, and starts the send operation.
To dial with one-touch dialing
1. Place the document face down in the automatic document feeder. The following is displayed:
SELECT FEATURES THEN DIAL OR RESERVE JOB OR PRESS [COPY]
2. If needed, press the Upper/Lower Case button to indicate whether you want the telephone number above or below the one-touch key.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 4-3
PERFORMING BASIC OPERATIONS
3. Press the one-touch key assigned to the desired telephone number. The following is displayed briefly:
>(number)
where (NUMBER) is the telephone number or name assigned to the one-touch key pressed in this step and nnn is the dial directory number.
4. Then, the following is displayed:
SIZE % : 100
The SIZE shows the percentage of reduction selected (100 in the example display).
5. The terminal then dials the telephone number and automatically sends the document.
PREPARING TO SEND :nnn
STORING PAGE TO MEMORY
To dial with speed dialing
1. Place the document face down in the automatic document feeder. The following is displayed:
SELECT FEATURES THEN DIAL OR RESERVE JOB OR PRESS [COPY]
2. Press [Speed Dial]. The following is displayed:
ENTER SPEED DIAL NUMBER >
3. Using the telephone keypad, enter the 3­digit code assigned to the desired telephone number.
4-4 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
4. After the last digit of the code is entered, the following is displayed:
>(number)
PREPARING TO SEND :nnn
where:
(number) is the telephone number or
nnn is the code entered in Step 3.
5. The terminal scans the document to memory, automatically dials, and starts the send operation.
To dial permanent dial groups
1. If sending, place document face down in the automatic document feeder.
PERFORMING BASIC OPERATIONS
name assigned to the code entered in Step 3.
2. Press [Speed Dial].
3. Using the telephone keypad, enter the 3­digit code assigned to the desired permanent dial group. Refer to Table 4-2 at the top of the next page.
4. After the [*] is entered, another speed dial entry can be selected.
5. When all speed dial selections have been entered, press [Start] to send or [Poll] to receive.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 4-5
PERFORMING BASIC OPERATIONS
Table 4-2. Permanent Dial Groups
Permanent Group
Access Code
00* 001-009 01* 010-019 02* 020-029 03* 030-039 04* 040-049 05* 050-059 06* 060-069 07* 070-079 08* 080-089 09* 090-099 10* 100-109 11* 110-119 12* 120-129
Dial Directory
Number
13* 130-139 14* 140-149 *** 001-150
4-6 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
Interactive dialing
1. If sending, place document face down in
2. Lift handset (not available in all countries)
3. Using the terminal’s telephone keypad,
4. After the dialing sequence, press [Start] to
Using a pause
If the terminal is set for pulse dialing (and in manual dial mode), the operator can press the Pause button to switch to DTMF (tone) dialing.
PERFORMING BASIC OPERATIONS
the automatic document feeder.
or press [Speed Dial] followed by [#].
dial the required digits. Digits are dialed as the keys are pressed.
send or [Poll] to receive. To terminate the connection, hang up the handset or press [Stop].
Once pressed, the terminal transmits DTMF tones for each depression of a keypad button. The terminal remains in the DTMF mode of operation until one of the following occurs:
The terminal is powered off.
The telephone operation is completed.
The associated facsimile operation is completed.
If the Pause key is selected before using a one­touch or speed dial number, the auto start function is turned off and multiple one­touch/speed dial numbers may be entered for store and forward (broadcast) and multipolling operations.
When programming the dial directory, a pause may be included anywhere in the telephone number by pressing the Pause button. Add multiple pauses as necessary to increase the pause time. Use the Pause button whenever waiting is required before the next number can be dialed.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 4-7
PERFORMING BASIC OPERATIONS
Do not insert a pause unless there is an expected delay.
An example would be dialing into a system that uses charge code numbers after your telephone number. A pause should be entered to ensure the system is ready to accept these numbers.
1. While using the telephone keypad to enter
the number, press [Pause] after the appropriate number.
A dash appears after the appropriate number each time [Pause] is pressed.
Figure 4-1 shows an example of a pause. Figure 4-1. Pause example
9 - 5551212 - 4321
Charge code (North American market only)
Pause
Phone number
Pause
Outside line
4-8 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
Redialing
PERFORMING BASIC OPERATIONS
Redialing automatically occurs if the remote terminal is busy.
The terminal automatically redials a telephone number every five minutes (time that can be changed by the operator). It attempts to redial three times.
NOTE: In the North American market, the number of redial attempts (0 to 10) and the time between attempts (0 to 255 minutes) can be changed by using the Redial Options button (refer to Redial options in Chapter 5 for this procedure). The time can be modified in one minute intervals.
If the telephone rings while the terminal is waiting to redial, the terminal automatically answers the telephone and proceeds with the new job. When the new job is complete, the terminal returns to the pending redial.
To terminate a pending redial, print a Pending Job Report (refer to Chapter 6). From the report, obtain the job number (in the No. column).
Then, use [Pending Job View/Delete] to delete the job number (refer to
viewing/deleting
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 4-9
in Chapter 5).
Pending job report
Pending job
in
PERFORMING BASIC OPERATIONS
Making copies
The terminal can serve as a copier that allows user selection of:
Number of copies
Paper tray selection (if auxiliary paper tray option installed)
Original Document (text or half-tone image)
Resolution
Image enlargement or reduction
To make copies
1. Load the originals face down in the automatic document feeder and adjust the document guides. If the document is legal size paper, adjust the extender on the document output tray.
2. Press [Copy]. The following is displayed:
NUMBER OF COPIES>01,
<100% >
Note: If the auxiliary paper tray option is installed, the following is displayed:
NUMBER OF COPIES>01, UPPER TRAY <100%> PRESS [SELECT] FOR LOWER TRAY OR
3. Using the telephone keypad, enter the number of copies desired (1-99).
NOTE: If multiple copies of multiple originals are desired, the terminal copies the originals to memory (provided enough memory exists), and then automatically collates the copies as they are printed.
4-10 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
PERFORMING BASIC OPERATIONS
4. If the auxiliary paper tray option is installed, select the desired paper tray.
a. If the upper tray is desired, no action is
required.
b. If the lower tray is desired, press [Select].
Note: The display indicates the selected paper tray.
5. Select the original document features (refer to
Status Indicators
in Chapter 3).
6. Select the resolution (refer to
Indicators
in Chapter 3).
Status
7. If no enlargement or reduction is required, go to Step 8.
a. If enlargement is desired, go to
Enlargement
on the next page.
b. If reduction is desired, go to
Reduction
on the next page.
A.
B.
8. Once all of the desired functions are set, press [Start]. The following is displayed:
COPYING DOCUMENT: nm/NM 10:25 AM 1-15-90
where:
nm = number of copies currently made NM = number of copies to be made.
9. Once copying is complete, the following is displayed:
COPY OPERATION COMPLETE nm/NM 10:25 AM 1-15-90
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 4-11
PERFORMING BASIC OPERATIONS
A. Enlargement
1. Press the Enlargement/Reduction button until the Enlargement LED is lit. The following is displayed:
SIZE % > 122,141 PRESS [SELECT] THEN [ENTER] OR [START]
2. Press [Select] until the desired percentage flashes; then press [Enter].
3. Return to Step 8 of the Making Copies procedure.
B. Reduction
1. Press the Enlargement/Reduction button until the Reduction LED is lit. The following is displayed:
SIZE % > 100,97,91,84,76,50,AUTO PRESS [SELECT] THEN [ENTER] OR
NOTE: AUTO means that the terminal automatically calculates the best percentage for reduction of the document.
2. Press [Select] until the desired percentage flashes; then press [Enter].
3. Return to Step 8 of the Making Copies procedure.
4-12 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
Polling a remote terminal
Polling is a basic receive operation. The only way it differs from the normal receive operation is that you initiate the operation by dialing the remote terminal. The remote terminal must have documents loaded for this operation.
1. Enter the number of the remote terminal.
2. Press [Poll/Man Rcv]. If your terminal is not set up to receive and store documents to memory, the following is displayed (refer
Memory options
to
RECEIVING DOCUMENT (96) # 1
The display shows the communication mode and speed, and the number of each page as it is received.
PERFORMING BASIC OPERATIONS
in Chapter 5.):
CCITT G3
If your terminal is set up to receive and store documents to memory, the following is displayed:
RECEIVING DOCUMENT TO MEMORY
3. Once the document is received, one of the following occurs:
• If your terminal is not set up to receive
to memory, the document is printed.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 4-13
PERFORMING BASIC OPERATIONS
• If your terminal is set up to receive to memory, the document can be printed by doing one of the following:
- Select PRINT FROM MEMORY from
- Print a Pending Job Report (refer to
4. Once the operation is complete, the terminal returns to idle mode.
the [Terminal Options] menu (refer to
Memory options
in Chapter 5).
Memory clears after printing.
Pending Job Report
in Chapter 6). From the report, obtain the number of the document to be printed (in No. column). Then use [Pending Job View/Delete] to print the document (refer to
viewing/deleting
Pending job
in Chapter 5). Using the view selection does not clear memory.
4-14 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
PERFORMING BASIC OPERATIONS
Receiving a document
There are two basic ways to receive a document on your terminal:
Automatically by an unattended terminal
Manually which requires user action
To automatically receive a document
NOTE: On the 7033, the displays in Steps 1­3 are only displayed if [Job Status] has been pressed after the terminal has answered the call.
1. When your terminal detects an incoming telephone call and [Job Status] is pressed, the following is displayed:
INCOMING CALL
2. The terminal automatically answers the telephone. The following is displayed:
RECEIVING DOCUMENT (96)
(CCITT G3)
3. As each page is received, the page number is displayed.
RECEIVING DOCUMENT (96) #
1
(CCITT G3)
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 4-15
PERFORMING BASIC OPERATIONS
4. Once the document is received, one of the following occurs:
• If the terminal is not set up to receive to memory, the document is printed.
• If the terminal is set up to receive to memory, the document can be printed by doing one of the following:
- Select PRINT FROM MEMORY from
- Print a Pending Job Report (refer to
the [Terminal Options] menu (refer to
Memory options
in Chapter 5).
Memory clears after printing.
Pending Job Report
in Chapter 6). From the report, obtain the number of the document to be printed (in No. column). Then use [Pending Job View/Delete] to print the document (refer to
viewing/deleting
Pending job
in Chapter 5). Using the view selection does not clear memory.
5. The terminal returns to idle mode.
To manually receive a document
There are two ways to manually receive a document on your terminal:
In the manual answer mode, answer a call and then receive documents by pressing [Poll/Man Rcv] on the upper portion of the control panel.
Initiate a call and have a document sent from the remote terminal. This is called polling; refer to
Polling a remote terminal
chapter for this procedure.
4-16 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
in this
PERFORMING BASIC OPERATIONS
Sending a document
Sending a document to one location
1. Place the document face down in the automatic document feeder. The following is displayed:
SELECT FEATURES THEN DIAL OR RESERVE JOB OR PRESS [COPY]
2. Enter the desired telephone number using the telephone keypad. As you enter the number, the following is displayed:
>(numbers appear here as entered) DIAL NUMBER THEN PRESS
3. After entering the desired number, press [Start]. The terminal then loads (into memory) the document in the automatic document feeder as the following is displayed:
STORING PAGE TO MEMORY
SIZE % : 100
The SIZE shows the percentage of reduction selected (100 in the example display).
NOTE: If the Page Count feature of the terminal is on, you are prompted to enter the number of pages in the batch (refer to Page count requirements in Chapter 5).
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 4-17
PERFORMING BASIC OPERATIONS
4. After the document is stored to memory, the following is displayed:
>(number)
NOTE: The number displayed is the same number entered in Step 2.
5. After the telephone connection has been made, the status of the transmission is displayed. The status notes the document is being sent (SENDING), the sending speed (96 in example), and the communication mode (CCITT G3 in example is displayed only if no remote terminal ID is available).
SENDING DOCUMENT (96)
6. As each page is completed, the page number is displayed. On the 7033, select [Job Status].
DIALING TELEPHONE NUMBER
(CCITT G3)
SENDING DOCUMENT (96) # 1
(CCITT G3)
7. When the operation successfully completes, a tone sounds.
8. The terminal returns to idle mode.
4-18 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
PERFORMING BASIC OPERATIONS
Sending a document to multiple locations
Store and forward, commonly referred to as broadcast, is sending to multiple locations. The terminal can send to multiple locations using group dial for repetitive operations. Refer to
groups
and forward operation not using group dial, use the following procedure.
in Chapter 5 for this operation. For a store
1. Place the document face down in the automatic document feeder.
2. Press [Pause].
3. Enter the desired dial directory locations using speed dial or one-touch.
4. After all of the dial directory locations are entered, press [Start]. The terminal then loads (into memory) the document and starts the store and forward operation.
Dial
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 4-19
PERFORMING BASIC OPERATIONS
4-20 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
5. Setting Up and Using Terminal Features 5-1
Auto/manual answer, selecting 5-3 Specifying auto or manual answer 5-3 Specifying length of auto answer delay 5-4 Brief messages, using 5-6 Defining a brief message 5-6 Viewing a brief message 5-7 Sending a brief message 5-8 Communication mode, setting 5-9 Setting the default communication mode 5-9 Setting communication mode for a specific job 5-12 Company logo, assigning 5-15 Continuous poll option, enabling 5-17 Contrast level for original document, setting up 5-18 Copy availability 5-20 Delayed start option, setting up 5-21 Planning for the dial directory 5-24 Setting up the dial directory 5-25 Setting up additional dial directory features 5-33 Dial groups, setting up 5-41 Planning for the dial groups 5-41 Defining a dial group 5-42 Document storage for polling and delection after polling 5-45 Storing a document for polling 5-45 Specifying stored document deletion/storing after poll operation 5-46 Dual Tone Multi Frequency (DTMF) feature 5-48 DTMF command sequence overview 5-48 FaxMaster DTMF commands supported by the 7032/7033 5-50 Hard disk, reformatting 5-51 Job reserve feature, using 5-53 Reserving a new job 5-53 Using a reserved job 5-56 Viewing a reserved job 5-57

5. Setting Up and Using Terminal Features

http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7033/USER/chp5.htm (1 of 3) [28/09/1999 10:29:06]
Canceling a reserved job 5-58 Junk mail, eliminating 5-59 Local terminal ID, assigning 5-61 Local terminal name, assigning 5-62 Long original transmission/scan, enabling 5-64 Mailbox functions, using 5-65 Clearing mailbox contents 5-65 Retrieving mail 5-66 Sending mail 5-70 Storing mail in a local mailbox 5-73 Memory options, specifying (receive, out of paper receive, print, memory full) 5-76 Specifying receive to memory option 5-76 Specifying out of paper receive to memory option 5-78 Specifying print from memory option 5-80 Specifying memory full option 5-81 Memory reallocation 5-82 Page count requirements, specifying 5-85 Pending job, view/deleting 5-86 Viewing/deleting a document and associated job information 5-86 Deleting a pending poll operation 5-89 Receive interval, specifying 5-91 Received document reduction ratio, selecting 5-93 Received/transmitted header, enabling 5-95 Enabling a received header 5-95 Enabling a transmitted header 5-98 Redial options, specifying 5-100 Specifying the number of redial attempts 5-100 Specifying the redial attempt interval 5-101 Relay send operation, performing 5-103 Using DTMF to relay send 5-103 Using the mailbox/relay button to relay send 5-104 Using dial directory to relay send 5-106 Resend operation (after interruption), setting up 5-107
5. Setting Up and Using Terminal Features
http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7033/USER/chp5.htm (2 of 3) [28/09/1999 10:29:06]
Resolution and original document defaults, setting 5-109 Terminal volume levels (alarms, control panel, dialing), setting 5-110 Setting the alarm volume 5-110 Setting the control panel volume 5-111 Setting the dialing volume 5-112 Time and date, setting 5-114 User access, setting 5-116 User account, setting up/deleting 5-118 A. Mailbox 5-121 B. Name 5-122 Voice request, signaling 5-123
5. Setting Up and Using Terminal Features
http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7033/USER/chp5.htm (3 of 3) [28/09/1999 10:29:06]
5. Setting up and using terminal features
This chapter contains information about setting up the terminal and using the terminal features not discussed in Chapter 4. Refer to Table 5-1 below for specific chapter contents.
Table 5-1. Chapter 5 contents
Function Page
Auto/manual answer, selecting 5-3 Brief messages, using 5-6 Communication mode, setting 5-9 Company logo, assigning 5-15 Continuous poll option, enabling 5-17 Contrast level for original document, setting up 5-18 Copy availability, specifying 5-20 Delayed start operation, setting up 5-21 Dial directory, setting up 5-24 Dial groups, setting up 5-41 Document storage for polling and deletion after
polling Dual Tone Multi Frequency (DTMF) feature 5-48 Hard disk, reformatting 5-51 Job reserve feature, using 5-53 Junk mail, eliminating 5-59
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 5-1
5-45
SETTING UP AND USING TERMINAL FEATURES
Table 5-1. Chapter 5 contents (cont.)
Function Page
Local terminal ID, assigning 5-61 Local terminal name, assigning 5-62 Long original transmission/scan, enabling 5-64 Mailbox functions, using 5-65 Memory options (receive, out of paper receive,
5-76
print, memory full), specifying Memory reallocation 5-82 Page count requirements, specifying 5-85 Pending job, viewing/deleting 5-86 Receive interval, specifying 5-91 Received document reduction ratio, selecting 5-93 Received/transmitted header, enabling 5-95 Redial options, specifying 5-100 Relay send operation, performing 5-103 Resend operation (after interrupt), setting up 5-107 Resolution and original document defaults, setting 5-109 Terminal volume levels (alarms, control panel,
5-110
dialing), setting Time and date, setting 5-114 User access, setting up 5-116 User account, setting up/deleting 5-118 Voice request, signaling 5-123
5-2 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
SETTING UP AND USING TERMINAL FEATURES
Auto/manual answer, selecting
You can specify whether the terminal will automatically answer an incoming call or the operator must manually answer the call. If automatic answering is selected, you can also specify the length of the delay before the call is answered.
Specifying auto or manual answer
NOTE: Manual answer allows operator to answer the incoming call before using normal terminal operations. This feature disables the automatic answering mode.
To select the mode of answering, do the following:
1. Open the control panel door.
2. Press [Receive Options]. The following is displayed:
RECEIVE REDUCTION, CONTINUOUS POLL, MORE PRESS [SELECT] THEN [ENTER] OR
3. Press [Select] until MORE flashes.
4. Press [Enter]. The following is displayed:
AUTO ANSWER DELAY, MANUAL ANSWER, MORE PRESS [SELECT] THEN [ENTER] OR
5. Press [Select] until MANUAL ANSWER flashes.
6. Press [Enter]. The following is displayed:
MANUAL ANSWER > OFF, ON PRESS [SELECT] THEN [ENTER] OR
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 5-3
SETTING UP AND USING TERMINAL FEATURES
7. Press [Select] until the desired choice flashes.
Selections Functions
OFF The terminal will
automatically answer an incoming call.
ON The terminal will not
answer an incoming call.
8. Press [Enter]. The original Receive Options menu displays, as shown below, allowing you to make additional choices.
RECEIVE REDUCTION, CONTINUOUS POLL, MORE PRESS [SELECT] THEN [ENTER] OR
Specifying length of auto answer delay
NOTE: The terminal can be set to delay answering by 5, 10, or 15 seconds to allow for voice answering when the office is attended. This feature is not available in all countries.
To select the mode of answering, do the following:
1. Open the control panel door.
2. Press [Receive Options]. The following is displayed:
RECEIVE REDUCTION, CONTINUOUS POLL, MORE PRESS [SELECT] THEN [ENTER] OR
3. Press [Select] until MORE flashes.
4. Press [Enter]. The following is displayed:
AUTO ANSWER DELAY, MANUAL ANSWER, MORE PRESS [SELECT] THEN [ENTER] OR
5. Press [Select] until AUTO ANSWER DELAY flashes.
5-4 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
SETTING UP AND USING TERMINAL FEATURES
6. Press [Enter]. The following is displayed:
AUTO ANSWER DELAY > 0, 5, 10, 15 SEC PRESS [SELECT] THEN [ENTER] OR
7. Press [Select] until the desired choice flashes.
8. Press [Enter]. The original Receive Options menu displays, as shown below, allowing you to make additional choices.
RECEIVE REDUCTION, CONTINUOUS POLL, MORE PRESS [SELECT] THEN [ENTER] OR
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 5-5
SETTING UP AND USING TERMINAL FEATURES
Brief messages, using
Up to 50 brief messages from 1-15 characters in length can be defined. Then, any of these brief messages can be included in the header of a transmitted document.
Before using this feature, the transmitted header must be enabled. Refer to
received/transmitted header
directions.
Defining a brief message
1. Open the control panel door.
2. Press [Header Setup]. The following is displayed:
RECEIVE HEADER, SEND HEADER, CONTENTS PRESS [SELECT] THEN [ENTER] OR
3. Press [Select] until CONTENTS flashes.
4. Press [Enter]. The following is displayed:
Enabling a
in this chapter for
CONTENTS>LOCAL NAME, LOGO, BRIEF MESSAGE PRESS [SELECT] THEN [ENTER] OR
5. Press [Select] until BRIEF MESSAGE flashes.
6. Press [Enter]. The following is displayed:
ENTER BRIEF MESSAGE NUMBER >_ THEN PRESS [ENTER] OR
7. Using the telephone keypad, enter a 2-digit number (01-50) and press [Enter].
8. The following is displayed:
BRIEF MESSAGE NN >_ ENTER MESSAGE THEN PRESS [ENTER]
5-6 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
where NN is the message number entered in Step 2.
NOTE: If the number entered in Step 2 is already associated with a message, that message is displayed for viewing and/or editing.
9. Enter up to a 15-character message and then press [Enter]. The Contents menu is displayed, as shown below, allowing you to make additional choices.
CONTENTS>LOCAL NAME, LOGO, BRIEF MESSAGE PRESS [SELECT] THEN [ENTER] OR
Viewing a brief message
1. Open the control panel door.
2. Press [Brief Message]. The following is displayed:
SETTING UP AND USING TERMINAL FEATURES
ENTER BRIEF MESSAGE NUMBER
>_
THEN PRESS [ENTER] OR [EXIT]
3. Using the telephone keypad, enter the 2­digit number (01-50) of the message you want to view and press [Enter].
4. The message associated with the number entered in Step 3 is displayed. After viewing the message, you can do one of the following:
a. Press [Enter] to return the terminal to
program mode.
b. Press [Select] to view the next
programmed message.
NOTE: Another way to view all defined Brief Messages is to print an Options Report in System Reports, which contains a list of all brief messages (refer to Options Report in Chapter 6).
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 5-7
SETTING UP AND USING TERMINAL FEATURES
Sending a brief message
1. Before transmitting a document, open the control panel door.
2. Press [Brief Message]. The following is displayed:
ENTER BRIEF MESSAGE NUMBER
>_
THEN PRESS [ENTER] OR [EXIT]
3. Using the telephone keypad, enter the 2­digit number (01-50) of the message you want to send and press [Enter].
4. The message associated with the number entered in Step 3 is displayed. After confirming this is the desired message, press [Enter].
NOTE: If you are not sure of the number of the desired message, press [Select] to scroll through the messages or print an Options Report, which contains a list of all brief messages (refer to Options Report in Chapter 6).
5. Perform the desired send operation.
5-8 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
SETTING UP AND USING TERMINAL FEATURES
Communication mode, setting
Use the Terminal Defaults button to specify the terminal’s default communication mode.
Use the Communication button to select the communication mode for a specific job. The communication mode returns to the specified default after the job completion.
Setting the default communication mode
To set the default communication mode, do the following:
1. Open the control panel door.
2. Press [Terminal Defaults]. The following is displayed:
TERMINAL DEFAULTS > COMMUNICATION, PANEL PRESS [SELECT] THEN [ENTER] OR
3. Press [Select] until COMMUNICATION flashes.
4. Press [Enter]. The following is displayed:
COMM MODE > ECM, 4800 BPS, 14400 BPS PRESS [SELECT] THEN [ENTER] OR
5. Press [Select] until the desired choice flashes.
Selections Functions
ECM Select Error Correct Mode
(ECM) communication.
4800 BPS Select maximum
communication speed of 4800 bits per second.
14400 BPS Select maximum
communication speed of 14400 bits per second.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 5-9
SETTING UP AND USING TERMINAL FEATURES
6. Press [Enter].
If you selected: Go to:
ECM A 4800 BPS B 14400 BPS C
A. ECM
1. The following is displayed:
ECM > OFF, ON PRESS [SELECT] THEN [ENTER] OR [EXIT]
2. Press [Select] until the desired choice flashes.
Selections Functions
OFF Error Correct Mode not
activated.
ON Error Correct Mode
activated.
3. Press [Enter]. The original Communication menu is displayed, as shown below, allowing you to make additional choices.
COMM MODE > ECM, 4800 BPS, 14400 BPS PRESS [SELECT] THEN [ENTER] OR
B. 4800 BPS
1. The following is displayed: 2. Press
4800 BPS > OFF, ON
PRESS [SELECT] THEN [ENTER] OR [EXIT]
[Select]
5-10 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
2. Press [Select] until the desired choice
3. Press [Enter]. The original Communication
C. 14400 BPS
1. The following is displayed:
SETTING UP AND USING TERMINAL FEATURES
flashes.
Selections Functions
OFF Allows highest possible
communication speed.
ON Selects maximum
communication speed of 4800 bits per second.
menu is displayed, as shown below, allowing you to make additional choices.
COMM MODE > ECM, 4800 BPS, 14400 BPS PRESS [SELECT] THEN [ENTER] OR [EXIT]
14400 BPS > OFF, ON PRESS [SELECT] THEN [ENTER] OR [EXIT]
2. Press [Select] until the desired choice flashes.
Selections Functions
OFF Selects maximum
communication speed of 9600 bits per second.
ON Selects maximum
communication speed of 14400 bits per second.
3. Press [Enter]. The original Communication menu is displayed, as shown below, allowing you to make additional choices.
COMM MODE > ECM, 4800 BPS, 14400 BPS PRESS [SELECT] THEN [ENTER] OR [EXIT]
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 5-11
SETTING UP AND USING TERMINAL FEATURES
Setting communication mode for a specific job
To specify the communication mode for a specific job, do the following:
1. Open the control panel door.
2. Press [Communication]. The following is displayed:
COMM MODE > ECM, 4800 BPS, 14400 BPS PRESS [SELECT] THEN [ENTER] OR
3. Press [Select] until the desired choice flashes.
Selections Functions
ECM Select Error Correct
Mode (ECM) communication.
4800 BPS Select maximum
communication speed of 4800 bits per second.
14400 BPS Select maximum
communication speed of 14400 bits per second.
4. Press [Enter].
If you selected: Go to:
ECM A 4800 BPS B 14400 BPS C
A. ECM
1. The following is displayed:
ECM > OFF, ON PRESS [SELECT] THEN [ENTER] OR [EXIT]
5-12 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
2. Press [Select] until the desired choice
3. Press [Enter]. The original Communication
B. 4800 BPS
1. The following is displayed:
SETTING UP AND USING TERMINAL FEATURES
flashes.
Selections Functions
OFF Error Correct Mode is
not activated.
ON Error Correct Mode is
activated.
menu is displayed, as shown below, allowing you to make additional choices.
COMM MODE > ECM, 4800 BPS, 14400 BPS PRESS [SELECT] THEN [ENTER] OR
4800 BPS > OFF, ON
PRESS [SELECT] THEN [ENTER] OR [EXIT]
2. Press [Select] until the desired choice flashes.
Selections Functions
OFF Allows highest possible
communication speed.
ON Selects maximum
communication speed of 4800 bits per second.
3. Press [Enter]. The original Communication menu is displayed, as shown below, allowing you to make additional choices.
COMM MODE > ECM, 4800 BPS, 14400 BPS PRESS [SELECT] THEN [ENTER] OR
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 5-13
SETTING UP AND USING TERMINAL FEATURES
C. 14400 BPS
1. The following is displayed:
14400 BPS > OFF, ON
PRESS [SELECT] THEN [ENTER] OR [EXIT]
2. Press [Select] until the desired choice flashes.
Selections Functions
OFF Selects maximum
ON Select maximum
3. Press [Enter]. The original Communication menu is displayed, as shown below, allowing you to make additional choices.
communication speed of 9600 bits per second.
communication speed of 14400 bits per second.
COMM MODE > ECM, 4800 BPS, 14400 BPS PRESS [SELECT] THEN [ENTER] OR
5-14 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
SETTING UP AND USING TERMINAL FEATURES
Company logo, assigning
The terminal can print a company logo on the headers of received or transmitted documents.
First, the received and/or transmitted headers must be enabled. Refer to
received/transmitted header
directions. Next, the company logo must be enabled and
assigned. Do the following steps:
1. Open the control panel door.
2. Press [Header Setup]. The following is displayed:
RECEIVE HEADER, SEND HEADER, CONTENTS PRESS [SELECT] THEN [ENTER] OR
3. Press [Select] until CONTENTS flashes.
Enabling a
in this chapter for
4. Press [Enter]. The following is displayed:
CONTENTS>LOCAL NAME, LOGO, BRIEF MESSAGE PRESS [SELECT] THEN [ENTER] OR
5. Press [Select] until LOGO flashes.
6. Press [Enter]. The following is displayed:
COMPANY LOGO > OFF , ON PRESS [SELECT] THEN [ENTER] OR [EXIT]
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 5-15
SETTING UP AND USING TERMINAL FEATURES
7. Press [Select] until the desired choice flashes.
Selections Functions
OFF Company name is not
ON Company name is
8. Press [Enter]. a. If you select OFF, the Content menu, as
shown below, is displayed, allowing you to make additional choices.
CONTENTS>LOCAL NAME, LOGO, BRIEF MESSAGE PRESS [SELECT] THEN [ENTER] OR
b. If you select ON, go to Step 9.
printed on received or transmitted header.
printed on received or transmitted header.
9. The following is displayed:
> ENTER COMPANY LOGO THEN PRESS [ENTER]
10. Type the company logo and press [Enter]. The Contents menu, as shown below, is displayed, allowing you to make additional choices.
CONTENTS>LOCAL NAME, LOGO, BRIEF MESSAGE PRESS [SELECT] THEN [ENTER] OR
5-16 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
SETTING UP AND USING TERMINAL FEATURES
Continuous poll option, enabling
The continuous poll option allows the terminal to continue polling after a group poll is completed until the operator disables the option.
To enable/disable the continuous poll option, do the following:
1. Open the control panel door.
2. Press [Receive Options]. The following is displayed:
RECEIVE REDUCTION, CONTINUOUS POLL, MORE PRESS [SELECT] THEN [ENTER] OR
3. Press [Select] until CONTINUOUS POLL flashes.
4. Press [Enter]. The following is displayed:
CONTINUOUS POLL > OFF, ON PRESS [SELECT] THEN [ENTER] OR
5. Press [Select] until the desired choice flashes.
Selections Functions
OFF Once the group poll is
completed, the terminal does not continue polling.
ON Once the group poll is
completed, the terminal continues polling until the operator selects the OFF option to stop the polling.
6. Press [Enter]. The original Receive Options menu displays, as shown below, allowing you to make additional choices.
RECEIVE REDUCTION, CONTINUOUS POLL, MORE PRESS [SELECT] THEN [ENTER] OR
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 5-17
SETTING UP AND USING TERMINAL FEATURES
Contrast level for original document, setting up
The upper portion of the control panel contains buttons used to select contrast level normal, dark, and light choices (located under Original Document on the control panel). Refer to
indicators
in Chapter 3 for details on the use of
these buttons. Use the Contrast Control button on the lower
portion of the control panel to establish reference points for the selections made on the upper portion of the control panel.
To establish the reference points, do the following:
1. Open the control panel door.
2. Press [Contrast Control]. The following is displayed:
Status
ENTER CONTRAST LEVEL > 60­42- 72 THEN PRESS [ENTER] OR [EXIT] N -
NOTE: N, D, and L in the display refer to Normal, Dark, and Light. The numbers displayed are the default settings.
3. Using the telephone keypad, enter the two-digit number that is to be the contrast value for a Normal setting and press [Enter].
NOTE: Entering a higher value lightens a setting. Entering a lower value darkens a setting.
5-18 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
SETTING UP AND USING TERMINAL FEATURES
4. The cursor is now located for selection of the Dark value, as shown below:
ENTER CONTRAST LEVEL > 60­42
- 72
THEN PRESS [ENTER] OR [EXIT] N
Using the telephone keypad, enter the two-digit number that is to be the contrast value for a Dark setting and press [Enter].
5. The cursor is now located for selection of the Light value as shown below:
ENTER CONTRAST LEVEL > 60­42- 72 THEN PRESS [ENTER] OR [EXIT] N
Using the telephone keypad, enter the two-digit number that is to be the contrast value for a Light setting and press [Enter].
6. The terminal returns to program mode.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 5-19
SETTING UP AND USING TERMINAL FEATURES
Copy availability
You can specify whether or not the terminal is to be available as a copier.
To specify this availability, do the following:
1. Open the control panel door.
2. Press [Terminal Options]. After the prompt, enter the 4-digit key operator account number using the telephone keypad.
3. Press [Enter]. The following is displayed:
USER ACCESS, USER ACCOUNT,
COPY, MORE PRESS [SELECT] THEN [ENTER] OR
4. Press [Select] until COPY flashes. Then press [Enter].
5. The following is displayed:
COPY AVAILABLE? > NO, YES PRESS [SELECT] THEN [ENTER] OR [EXIT]
6. Press [Select] until the desired choice flashes:
Selections Functions
NO Copy mode is not
available on this terminal.
YES Copy mode is available
on this terminal.
7. Press [Enter]. The original Terminal Options menu is displayed, as shown below, allowing you to make additional choices:
USER ACCESS, USER ACCOUNT,
COPY, MORE PRESS [SELECT] THEN [ENTER] OR
5-20 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
SETTING UP AND USING TERMINAL FEATURES
Delayed start operation, setting up
You can program the terminal to send or poll a document unattended at a later time. This feature allows you to send or poll documents at a time when telephone rates are lower. Multiple delayed starts can be programmed. “Batch send” refers to multiple delayed start transmissions to the same location.
To use the delayed start feature, do the following:
1. Open the control panel door.
2. Press [Delayed Start]. The following is displayed:
DELAYED START > OFF, ON PRESS [SELECT] THEN [ENTER] OR
3. Press [Select] until the desired choice flashes.
Selections Functions
OFF Delayed start not active. ON Allows you to continue
the process and set the time and date when the operation is to start.
4. Press [Enter]. a. If you select OFF, the terminal returns to
the program mode.
b. If you select ON, the following is
displayed:
ENTER DATE THEN TIME > MM-DD-YY HH:MM AM PRESS [ENTER] AFTER DATE AND
where MM-DD-YY (North American market only) is the current date (month, day, year) and HH:MM is the current time (hour, minute). In the European market, the date format is DD-MM-YY.
7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK 5-21
SETTING UP AND USING TERMINAL FEATURES
NOTE: If your clock is set up on a 24-hour basis, the AM or PM designation does not display.
5. The cursor is positioned in the first position of the MM (month) field. Use the [Clear] key to delete any previous numbers in this field. Using the numbers on the telephone keypad, enter the current month and press [Enter].
6. The cursor is now positioned in the first position of the DD (day) field. Follow the same procedure for entering the DD (day), YY (year), HH (hour), and MM (minute) fields as in Step 5. Depending on whether the time is set up on a 12 hour or 24 hour basis, the following occurs after pressing [Enter] following the MM entry,:
Time
Setup
Result
12 HOUR Go to Step 7. 24 HOUR Go to Step 9.
7. The following is displayed:
SELECT AM OR PM MM-DD-YY HH:MM > AM, PM PRESS [SELECT] THEN [ENTER] OR
8. Press [Select] until the desired choice (AM or PM) flashes and then press [Enter].
9. The following is displayed:
DIAL NUMBER OR CONTINUE SETUP NN SEC PRESS [STOP] TO CANCEL SETUP
10. Additional features may be selected for a 1 minute time period. If selections are complete, enter telephone number of remote.
5-22 7032 / 7033 FACSIMILE TERMINAL USER HANDBOOK
Loading...
