Xerox 701P47853 User Manual

November 2007

701P47853

Xerox 82xx/83xx Wide Format Printer

Hints and Tips

Prepared by: Xerox Corporation Global Knowledge and Language Services 800 Phillips Road, Bldg. 0218-01A Webster, New York 14580-9791 USA

allowed by statutory judicial law or hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as icons, screen displays, looks, etc.

Printed in the United States of America. XEROX® and all Xerox product names mentioned in this publication are trademarks of XEROX

CORPORATION. Other company trademarks are also acknowledged. PANTONE is a registered trademark of Pantone, Inc. Changes are periodically made to this document. Changes, technical inaccuracies, and typographic

errors will be corrected in subsequent editions.

82xx/83xx Hints & Tips

Paper Loading

• If changing media types, perform a distance adjustment to ensure media advances at the

right rate. An incorrect distance adjustment can result in banding or blurry lines and text.

• When loading a roll of paper lay it on a clean temporary work surface. The roll may pick

up lint or other contaminants if laid on carpet or the floor.

• Ensure the paper roll and take up roll are set firmly on the winder and un-winder. If this

is not done, the drive roller will simply turn within the roll and the paper will not be properly let out or taken up. It is also suggested to turn the winder and un-winder to manual or off at the end of the day or when idle for a significant amount of time to reduce the risk of wearing out the inside of the paper rolls.

• Set the right edge of the media close to the alignment red dots to minimize the

initialization “Undefined Media” errors.

• Ensure the media is fed properly and is taut. Use two hands to press and smooth the

media down against the dryer and lower the pinch rollers with the foot switch.

• If the printer will be idle for a while (as little as 1 hour for some media), release the

pressure rolls to prevent an indentation from forming.

• It is recommended that the media be removed from the printer pinch rollers and rolled up

on the Feed Roll at the end of the day to prevent the paper from retaining the shape from the tensioning rolls and pinch rolls.

Basic maintenance

• Do the daily, weekly, and monthly cleaning as laid out in the user guide.

• Turning on swatches will help ensure all the heads are fired routinely.

• Do not use cleaning solvent on the plastic shield. It will dissolve the plastic and it will no

longer be transparent.

• Run a nozzle check test pattern first thing in the morning. This helps ensure all color

heads are firing properly. It is also suggested to do this if the printer has been idle for over an hour or before an especially important print job.

• When evaluating a nozzle check test pattern, your evaluation should focus on breaks in

the “Step Lines”, as shown in Figure 1. Lines or breaks in the solid bars are not indicative of a clogged nozzle.
